CCTV | UML-1x1 Series 15-, 17-, 19-inch General Purpose LCD Flat Panel Monitors
UML-1x1 Series 15-, 17-, 19-inch General
Purpose LCD Flat Panel Monitors
Supports high-resolution 500 TVL, up to 1280 x 1024
▶
resolution–1.3 Megapixels (UML‑191‑90 and
UML‑171‑90) or 1024 x 768 resolution (UML‑151‑90)
▶
Maximum brightness of 250 to 300 cd/m
Maximum contrast ratio of 600:1 to 1000:1 for
▶
excellent color accuracy and consistency
Minimum response time of five to eight ms reduces
▶
smearing and ghosting
100/240 VAC, 50/60 Hz auto-ranging internal power
▶
supply
Low power consumption (less than 45 W)
▶
Looping composite and Y/C (S-video) inputs
▶
VGA input for DVR or PC applications
▶
3D comb filter and de-interlace circuitry for high-
▶
quality video
Front panel control lockout
▶
2
Bosch LCD flat panel monitors are high-resolution color
monitors ideal for use with analog video, digital video
recorder (DVR), and PC applications. The monitors feature
a color liquid crystal display (LCD) flat-screen panel and are
available with 15-in., 17-in., and 19-in. viewable picture
areas. Each monitor also features a wide range of horizontal
and vertical viewing angles that provide comfortable, clear
viewing – whether you place it on a desktop or mount it to
a wall or in a rack.
Functions
Excellent image quality
Bosch LCD monitors automatically adapt to the input
resolution of the incoming video signal (up to 1280 x 1024
pixels or 1.3 Megapixels). The monitors' analog VGA input
easily accommodates the widespread use of PCs in today's
security surveillance systems. Their high contrast ratio
(600:1 to 1000:1) and high brightness rating (250 to 300
cd/m2) offer excellent color accuracy and imaging for easier
viewing and interpretation of images. The panel refreshes
every five to eight milliseconds, so you get crisp, clear
images with less smearing - and less image “ghosting” in
fast-motion video.
Key benefits of LCD monitors
Long-life fluorescent backlights help avoid luminance
degradation on the LCD monitor – so it easily maintains its
brightness level over time. This is an advantage over aging
CRT-type monitors that become progressively dimmer. The
consistent brightness also provides a sharp display image,
without the constant flickering that you typically see in CRT
monitors. This allows you to use the LCD monitor longer
without eyestrain or excessive fatigue.
Additional advantages
The Bosch family of standard-performance LCD monitors
also features:
Low power consumption
•
Automatic adaptation to fluctuating electricity loads
•
while protecting your circuitry
Standard 100 mm (3.9 in.) mounting holes to easily
•
accommodate a range of VESA wall mounts
User-friendly, on-screen menus and front panel controls
•
for adjusting monitor display parameters to your
specific preferences
www.boschsecurity.com
2 | UML-1x1 Series 15-, 17-, 19-inch General Purpose LCD Flat Panel Monitors
Certifications and Approvals
Electromagnetic Compatibility (EMC)
Product Safety Complies with CE regulations, UL, CSA, EN, and
Complies with FCC Part 15, ICES-003, and CE
regulations
IEC standards
Technical Specifications
Electrical
UML-151-90 UML-171-90 UML-191-90
Rated Voltage 120/230 VAC,
50/60 Hz
Voltage Range 100-240 VAC 100-240 VAC 100-240 VAC
Power at Rated
Voltage
Sync Format PAL/NTSC PAL/NTSC PAL/NTSC
LCD Panel TFT LCD TFT LCD TFT LCD
Screen Size
(H x V)
Viewable Picture Area
Pixel Pitch:
(H x V)
Resolution 1024 x 768 pix-
Aspect Ratio 4:3 5:4 5:4
Display Colors 16.7 million col-
Response Time < 8 ms < 5 ms < 5 ms
Backlight Two (2) cold
LCD Panel
Optical
Characteristics
Luminance
Contrast Ratio 600:1 1000:1 800:1
Viewing Angle 160°/160° 160°/160° 160°/160°
25 W operation,
5 W standby
304.1 x
228.1 mm
(12.0 x 9.0 in.)
15 in. (381 mm)
measured
diagonally
0.297 x
0.297 mm
(0.01 x 0.01 in.)
els, 500 TV lines
typical
ors
cathode fluorescent tubes, rated
life 50,000
hours
UML-151-90 UML-171-90 UML-191-90
250 cd/m2, antiglare, hard-coating treatment
120/230 VAC,
50/60 Hz
40 W operation,
5 W standby
338.0 x 270.0 mm
(13.3 x 10.6 in.)
17 in. (432 mm)
measured
diagonally
0.264 x 0.264 mm
(0.01 x 0.01 in.)
1280 x 1024 pixels, 500 TV lines
typical
16.7 million colors 8-bit interface;
Two (2) cold cathode fluorescent
tubes, rated life
50,000 hours
300 cd/m2, antiglare, hard-coating
treatment
120/230 VAC,
50/60 Hz
45 W operation,
5 W standby
376.0 x 301.0 mm
(14.8 x 11.9 in.)
19 in. (483 mm)
measured
diagonally
0.294 x 0.294 mm
(0.01 x 0.01 in.)
1280 x 1024 pixels, 500 TV lines
typical
16.7 million colors
Four (4) cold cathode fluorescent
tubes, rated life
50,000 hours
300 cd/m2, antiglare, hard-coating
treatment
Video Input UML-151-90 UML-171-90 UML-191-90
Composite Video (CVBS)
Y/C (S-video) 0.7 Vp-p (Y-signal), 0.3 Vp-p (C-signal), 75 Ω termination
PC Input UML-151-90 UML-171-90 UML-191-90
Analog RGB 0.7 Vp-p (0.5–1 Vrms)
PC Timing Modes
640 x 480 60/72/75 Hz 60/72/75 Hz 60/72/75 Hz
800 x 600 60/72/75 Hz 60/72/75 Hz 60/72/75 Hz
1024 x 768 60/70/75 Hz 60/70/75 Hz 60/70/75 Hz
1280 x 1024 60/75 Hz 60/75 Hz
Controls
Video Input UML-151-90 UML-171-90 UML-191-90
Front Panel Push-buttons
Input Selects: Video1, Video2, S-video, VGA
Menu Selects on-screen display (OSD), up cursor, down cur-
Power On/Off
Front Panel Lockout
On-screen Display
Video Mode Input Source, Screen, OSD, Utility
PC Mode Input Screen, OSD, Color, Utility
Indicators UML-151-90 UML-171-90 UML-191-90
LED Power On (green)
On-screen VGA: Check input signal
Connectors UML-151-90 UML-171-90 UML-191-90
Video 1 (AV1) Composite video: two (2) BNC (1 in, 1 out)
Video 2 (AV2) Composite video: two (2) BNC (1 in, 1 out)
Y/C (S-video) Two (2) mini-DIN, 4-pin (1 in, 1 out)
RGB One (1) VGA cable included
Power Input 5.5 mm DC input jack
Power Adapter
(included)
1.0 Vp-p (0.5–1.5 Vp-p), automatic switching from
75 Ω unbalanced termination to Hi-Z with passive loop-
through operation
sor/auto adjust, left cursor, right cursor
Multiple push-button combination
UML-151-90 UML-171-90 UML-191-90
Standby (blinking red)
Unsupported Mode (green)
Power Off (red)
Video: Flashes “AV1” or “AV2” when there is a black
screen
Input: 100–
240 VAC, 50/60 Hz
Output: 12 VDC,
3.3 A
Input: 100–240 VAC, 50/60 Hz
Output: 12 VDC, 4.1 A
UML-1x1 Series 15-, 17-, 19-inch General Purpose LCD Flat Panel Monitors | 3
Mechanical
UML-151-90 UML-171-90 UML-191-90
Cabinet Material
Finish Black
Mount Wall mounting compatible with standard bracket, 100 mm
Dimensions (W x H x D)
Monitor with
Base
Monitor Only 352 x 292 x
Weight
Monitor with
Base
Monitor Only 2.5 kg (5.6 lb) 4.1 kg (9.05 lb) 5.9 kg (13.1 lb)
Environmental
Operating Temperature
Storage Temperature
Humidity Maximum 90%, non-condensing
Parts Included
352 x 355 x
200 mm
(13.86 x 14.0 x
7.9 in.)
58 mm
(13.9 x 11.5 x
2.2 in.)
3.7 kg (8.1 lb) 6.6 kg (14.6 lb) 7.6 kg (16.9 lb)
UML-151-90 UML-171-90 UML-191-90
ABS plastic
(3.9 in.) centers, M4 thread
382.4 x 390.5 x
200 mm
(15.1 x 15.4 x
7.9 in.)
382.4 x 330.0 x
58.7 mm
(15.1 x 13.0 x
2.3 in.)
0°C to 40°C (32°F to 104°F)
–20°C to 60°C (–4°F to 140°F)
430 x 428 x
200 mm
(16.9 x 16.9 x
7.9 in.)
420 x 374 x
60 mm
(16.9 x 14.7 x
2.4 in.)
Ordering Information
UML-151-90 15-inch Color LCD Display
Monitor
15-inch (381 mm) color LCD monitor, 3D image, 500 TVL, 1024 X 768 resolution, VGA,
CVBS, AUDIO, 120/230 VAC, 50/60 HZ
UML-171-90 17-inch Color LCD Display
Monitor
17-inch (432 mm) color LCD monitor, 3D image, 500 TVL, 1280 x 1024 resolution, VGA,
CVBS, audio, 120/230 VAC, 50/60 HZ
UML-191-90 19-inch Color LCD Display
Monitor
19-inch (483 mm) color LCD monitor, 3D image, 500 TVL, 1280 x 1024 resolution, VGA,
CVBS, audio, 120/230 VAC, 50/60 HZ
Accessories
UMM-LW-20B Fixed Wall Mount
Fixed wall mount for flat panel LCD monitors,
black
UMM-LW-30B Swivel/Tilt Wall Mount
Swivel/Tilt wall mount for flat panel LCD monitors, black
UMM-LCDUB-RM Rack Mount Bracket for
LCD Monitors
Supports dual 8.4-in. and single 8.4- to 19-in.
LCD monitors in a standard VESA rack cabinet
UML-151-90
UML-171-90
UML-191-90
UMM-LW-20B
UMM-LW-30B
UMM-LCDUB-RM
One (1) Bosch General Purpose Color LCD Flat Panel Monitor
One (1) VGA to VGA cable
Two (2), 3-wire power cords with a grounded plug: one (1) with a European/
Continental plug type and one (1) with a U.S. plug type
www.boschsecurity.com
