Hob
PKK6..FP..
[en]
User manual
PKK6..FP..
Ø 14,5
Ø 18/12
Ø 27,5/21
Ø = cm2
Safety en
Table of contents
1 Safety....................................................................3
2 Preventing material damage ...............................4
3 Environmental protection and saving en-
ergy .......................................................................5
4 Familiarising yourself with your appliance ........6
5 Basic operation ....................................................7
6 PowerBoost function ...........................................8
7 Childproof lock.....................................................8
8 Time-setting options............................................9
9 Automatic switch-off..........................................10
10 Wipe protection..................................................10
11 Energy consumption display ............................10
12 Basic settings.....................................................10
13 Cleaning and servicing......................................11
14 Troubleshooting.................................................12
15 Disposal..............................................................13
16 Customer Service...............................................13
1 Safety
Observe the following safety instructions.
1.1 General information
¡ Read this instruction manual carefully.
¡ Keep the instructions, the appliance pass
and the product information safe for future
reference or for the next owner.
¡ Do not connect the appliance if it has been
damaged in transit.
1.2 Intended use
Only a licensed professional may connect appliances without plugs. Damage caused by incorrect connection is not covered under the
warranty.
Only use this appliance:
¡ To prepare meals and drinks.
¡ Under supervision. Never leave the appli-
ance unattended when cooking for short
periods.
¡ In private households and in enclosed
spaces in a domestic environment.
¡ Up to an altitude of max. 2000m above
sea level.
Do not use the appliance:
¡ With an external timer or a separate remote
control. This does not apply if operation
with appliances included in EN 50615 is
switched off.
1.3 Restriction on user group
This appliance may be used by children aged
8 or over and by people who have reduced
physical, sensory or mental abilities or inadequate experience and/or knowledge,
provided that they are supervised or have
been instructed on how to use the appliance
safely and have understood the resulting
dangers.
Children must not play with the appliance.
Children must not perform cleaning or user
maintenance unless they are at least 15 years
old and are being supervised.
Keep children under the age of 8 years away
from the appliance and power cable.
1.4 Safe use
WARNING‒Risk of fire!
Leaving fat or oil cooking on an unattended
hob can be dangerous and may lead to fires.
▶
Never leave hot oil or fat unattended.
▶
Never attempt to extinguish a fire using water; instead, switch off the appliance and
then cover with a lid or a fire blanket.
The cooking surface becomes very hot.
▶
Never place flammable objects on the
cooking surface or in its immediate vicinity.
▶
Never place objects on the cooking surface.
The appliance will become hot.
▶
Do not keep combustible objects or aerosol cans in drawers directly underneath the
hob.
The hob switches off automatically and can
no longer be operated. It may switch on unintentionally at a later point.
▶
Switch off the fuse in the fuse box.
▶
Call the customer service.
Hob covers can cause accidents, for example
due to overheating, catching fire or materials
shattering.
▶
Do not use hob covers.
Food may catch fire.
▶
The cooking process must be monitored. A
short process must be monitored continu-
ously.
3
en Preventing material damage
WARNING‒Risk of burns!
The appliance and its parts that can be
touched become hot during use, particularly
the hob surround, if fitted.
▶
Caution should be exercised here in order
to avoid touching heating elements.
▶
Young children under 8 years of age must
be kept away from the appliance.
The hotplate heats up but the display does
not work.
▶
Switch off the fuse in the fuse box.
▶
Call the customer service.
Hob protective grilles may cause accidents.
▶
Never use hob protective grilles.
The appliance becomes hot during operation.
▶
Allow the appliance to cool down before
cleaning.
▶
Never operate an appliance with a cracked
or fractured surface.
▶
Call customer services. →Page13
An ingress of moisture can cause an electric
shock.
▶
Do not use steam- or high-pressure clean-
ers to clean the appliance.
The insulation on cables of electrical appliances may melt if it touches hot parts of the
appliance.
▶
Never bring electrical appliance cables into
contact with hot parts of the appliance.
WARNING‒Risk of injury!
Saucepans may suddenly jump due to liquid
between the saucepan base and the hotplate.
▶
Always keep hotplates and saucepan
bases dry.
WARNING‒Risk of electric shock!
Incorrect repairs are dangerous.
▶
Repairs to the appliance should only be
carried out by trained specialist staff.
▶
Only use genuine spare parts when repairing the appliance.
▶
If the power cord of this appliance is damaged, it must be replaced with a special
connection cable, which is available from
the manufacturer or his Customer Service.
If the appliance or the power cord is damaged, this is dangerous.
▶
Never operate a damaged appliance.
2 Preventing material damage
ATTENTION!
Rough pot and pan bases will scratch the ceramic.
▶
Check your cookware.
Boiling pans dry may damage cookware or the appli-
ance.
▶
Never place empty pans on a heated hotplate or al-
low to boil dry.
Incorrectly positioned cookware can cause the appli-
ance to overheat.
▶
Never place hot pots or pans on the controls or the
hob surround.
Damage can occur if hard or pointed objects fall onto
the hob.
▶
Do not let hard or pointed objects fall onto the hob.
Non heat-resistant materials will melt on heated hot-
plates.
▶
Do not use oven protective foil.
▶
Do not use aluminium foil or plastic containers.
WARNING‒Risk of suffocation!
Children may put packaging material over
their heads or wrap themselves up in it and
suffocate.
▶
Keep packaging material away from children.
▶
Do not let children play with packaging ma-
terial.
Children may breathe in or swallow small
parts, causing them to suffocate.
▶
Keep small parts away from children.
▶
Do not let children play with small parts.
2.1 Overview of the most common damage
Here you can find the most common types of damage
and tips on how to avoid them.
Damage Cause Measure
Stains Food boiling
over
Stains Unsuitable
cleaning
products
ScratchesSalt, sugar or
sand
ScratchesRough pot or
pan bases
Discolouration
Unsuitable
cleaning
products
Remove boiled-over food
immediately with a glass
scraper.
Only use cleaning
products that are suitable
for glass ceramic.
Do not use the hob as a
work surface or storage
space.
Check your cookware.
Only use cleaning
products that are suitable
for glass ceramic.
4
Environmental protection and saving energy en
Damage Cause Measure
Discolouration
Pan abrasion,
e.g. aluminium
Lift pots and pans to
move on the hob.
Damage Cause Measure
Blisters Sugar or food
with a high
sugar content
3 Environmental protection and saving energy
3.1 Disposing of packaging
The packaging materials are environmentally compatible and can be recycled.
▶
Sort the individual components by type and dispose
of them separately.
3.2 Saving energy
If you follow these instructions, your appliance will use
less energy.
Select the cooking zone to match the size of your
pan. Centre the cookware on the hob.
Use cookware whose base diameter is the same diameter as the hotplate.
Tip:Cookware manufacturers often give the upper
diameter of the saucepan. It is often larger than the
base diameter.
Unsuitable cookware or incompletely covered cook-
¡
ing zones consume a lot of energy.
Cover saucepans with suitable lids.
Cooking without a lid consumes far more energy.
¡
Lift lids as infrequently as possible.
When you lift a lid, a lot of energy escapes.
¡
Using a glass lid
You can see into the pan through a glass lid
¡
without having to lift it.
Use pots and pans with flat bases.
Uneven bases increase energy consumption.
¡
Use cookware suited to the quantity of food.
Large items of cookware containing little food need
¡
more energy to heat up.
Cook with little water.
The more water contained in cookware, the more
¡
energy is required to heat it up.
Turn down to a lower heat setting early on. Use a suitable ongoing cooking setting to continue cooking.
If you continue cooking with an ongoing cooking
¡
setting that is too high, you'll waste energy
Take advantage of the hob's residual heat. With
longer cooking times switch off the hotplate
5-10minutes before the end of cooking.
Unused residual heat increases energy consump-
¡
tion.
Remove boiled-over food
immediately with a glass
scraper.
5
en Familiarising yourself with your appliance
4 Familiarising yourself with your appliance
4.1 Control panel
You can use the control panel to configure all functions
of your appliance and to obtain information about the
operating status.
4.2 Indicators/symbols
The displays show selected values and functions.
Display Name
- Heat settings
/ Residual heat
PowerBoost function
Timer
4.3 Touch fields
Touch fields are touch-sensitive surfaces. To select a
function, touch the relevant field.
Touch field Name
Main switch
Wipe protection
Childproof lock
Automatic zone control
Hotplate selection
... Control panel
Timer
Powerboost
Notes
¡ Always keep the control panel dry. Moisture impairs
the function.
¡ Do not pull pans close to the displays and touch
fields. The electronics may overheat.
4.4 Hotplates
You can find an overview of the different activations of
the hotplates here.
If you operate the activations, the relevant displays light
up.
If you switch on a hotplate, it will switch to the setting
last selected.
Hotplate
Notes
¡ Dark areas in the glow pattern of the hotplate are
¡ The hotplate regulates the temperature by switching
¡ With multi-circuit hotplates, the heating of the hot-
Name Activating and deactivating
Single-circuit
cooking zone
Dual-circuit
hotplate
part of the technical design. They do not affect the
functionality of the hotplate.
the heat on and off. The heat may also switch on
and off when at the highest setting.
plate and the activated areas may switch on or off
at different times.
Reasons:
– Easily damaged components are protected
against overheating.
– The appliance is protected against electrical
overload.
– This achieves a better cooking result.
Select a hotplate.
Select a hotplate.
Touch .
4.5 Residual heat indicator
The hob has a two-stage residual heat indicator for
each hotplate. Do not touch the hotplate while the residual heat indicator is lit up.
Display Meaning
The hotplate is so hot that you can
keep small dishes warm or melt cooking chocolate.
The hotplate is hot.
6
5 Basic operation
2 63 4 5
2 63 4 5
Basic operation en
5.1 Switching the hob on or off
The main switch is used to switch the hob on and off.
If you switch the appliance back on again within
4seconds after switching off, the hob will start up with
the previously stored settings.
5.2 Switching on the hob
▶
Touch .
a The light bar above lights up brightly.
a The displays for the controls and the heat setting
displays light up.
a The hob is ready for use.
5.3 Switching off the hob
The hob will switch off automatically when all hotplates
have been switched off for a while (10-60seconds).
▶
Touch .
a The indicator lamp above goes out.
a The displays go out.
a All hotplates are switched off.
a The residual heat indicator remains on until the hot-
plates have cooled down sufficiently.
5.4 Setting the hotplates
To set a hotplate, it has to be selected.
Select the required heat setting on the control panel.
Heat setting
1 Lowest setting
9 Highest setting
. Every heat setting has an intermediate
setting, e.g. 4. .
5.5 Selecting heat settings
Requirement:The hob is switched on.
1.
Select the hotplate with .
a lights up in the heat setting indicator. lights up
under the heat setting indicator.
2.
Select a heat setting on the control panel.
5.7 Switching off the hotplate
1.
Select the hotplate with .
2.
Select 0 on the control panel.
a If you have switched off a hotplate, the residual heat
indicator appears after approx. 10seconds.
Note:The hotplate last selected remains activated. You
can adjust the hotplate without selecting it again.
5.8 Recommended cooking settings
You can find an overview of different foods with appropriate heat settings here.
The cooking time will vary depending on the type,
weight, thickness and quality of the food. The ongoing
cooking setting depends on the cookware used.
Cooking tips
¡ To bring food to the boil, use heat setting 9.
¡ Stir thick liquids occasionally.
¡ Food that needs to be seared quickly or that initially
loses a lot of liquid during frying should be fried in
small portions.
¡ Tips for saving energy when cooking. →Page5
Melting
Food Ongoing
cooking
setting
Chocolate, cooking chocolate 1-1. Butter, honey, gelatine 1-2 -
Heating or keeping warm
Stew, e.g. lentil stew 1-2 -
1
Milk
Sausages in water
1
Prepare the dish without the lid.
1
1.-2. 3-4 -
Defrosting and heating
Spinach, frozen 2.-3. 10-20
Goulash, frozen 2.-3. 20-30
Ongoing
cooking
time in
minutes
5.6 Changing heat settings
1.
Select the hotplate with .
2.
Select a heat setting on the control panel.
Poaching or simmering
Dumplings
1, 2
Fish
1, 2
4.-5. 20-30
4-5 10-15
White sauce, e.g. béchamel 1-2 3-6
Whisked sauces, e.g. sauce
3-4 8-12
béarnaise or hollandaise
1
Bring the water to the boil with the lid on.
2
Continue to cook the dish without a lid.
Boiling, steaming or stewing
Rice with double the volume of
2-3 15-30
water
1
Bring the water to the boil with the lid on.
2
Continue to cook the dish without a lid.
7
en PowerBoost function
Rice pudding 1.-2. 35-45
Unpeeled boiled potatoes 4-5 25-30
Boiled potatoes 4-5 15-20
Pasta, noodles
1, 2
6-7 6-10
Stew, soup 3.-4. 15-60
Vegetables, fresh 2.-3. 10-20
Vegetables, frozen 3.-4. 10-20
Food in a pressure cooker 4-5 -
1
Bring the water to the boil with the lid on.
2
Continue to cook the dish without a lid.
Braising
Beef olives 4-5 50-60
Pot-roasting 4-5 60-100
Goulash 2.-3. 50-60
Frying with little oil
Fry food without a lid.
Escalope, plain or breaded 6-7 6-10
Escalope, frozen 6-7 8-12
Chops, plain or breaded
1
6-7 8-12
Steak, 3cm thick 7-8 8-12
Patties, 3cm thick
Hamburgers, 2cm thick
Poultry breast, 2cm thick
Poultry breast, frozen
1
1
1
1
4.-5. 30-40
6-7 10-20
5-6 10-20
5-6 10-20
Fish or fish fillet, plain 5-6 8-20
1
Turn the dish several times.
Fish or fish fillet, breaded 6-7 8-20
Fish or fish fillet, breaded and
6-7 8-12
frozen, e.g. fish fingers
Scampi, prawns 7-8 4-10
Vegetables or mushrooms,
7-8 10-20
fresh, sautéing
Vegetables or meat in strips
7.-8. 15-20
cooked Asian-style
Stir fry, frozen 6-7 6-10
Pancakes 6-7 one by
one
Omelette 3.-4. one by
one
Fried eggs 5-6 3-6
1
Turn the dish several times.
Deep-frying
Deep-fry food in 1-2l oil in batches, 150-200g per
batch. Cook food without a lid.
Frozen products, e.g. chips or
8-9 -
chicken nuggets
Croquettes, frozen 7-8 Meat, e.g. chicken 6-7 Fish, breaded or battered 5-6 Vegetables or mushrooms,
5-6 breaded or battered
Tempura
Small pastries, e.g. doughnuts,
4-5 fruit in batter
6 PowerBoost function
PowerBoost lets you heat up large volumes of water
even faster than on heat setting 9.
The PowerBoost function is only available on hotplates
marked .
6.1 Switching on PowerBoost
WARNING‒Risk of fire!
Oil and fat heat up quickly with the PowerBoost function. Oil and fat ignite quickly if overheated.
▶
When cooking, never leave the hob unattended.
Requirement:With dual-circuit hotplates, the second
filament circuit has to be activated for use with the
PowerBoost function.
7 Childproof lock
You can use the childproof lock to prevent children
from switching on the hob.
7.1 Activating the childproof lock
Requirement:The hob is switched off.
▶
Press and hold for approx. 4seconds.
1.
Select the hotplate.
2.
Touch on the control panel.
a The indicator lights up.
6.2 Switching off PowerBoost
If you do not switch off the PowerBoost function, it will
switch off automatically after a certain period of time.
The hotplate switches back to heat setting 9.
1.
Select the hotplate.
2.
Select any ongoing cooking setting.
a The display goes out.
a The indicator lamp above lights up for
10seconds.
a The hob is now locked.
8
Time-setting options en
7.2 Deactivating the childproof lock
▶
Press and hold for approx. 4seconds.
a The lock is now released.
8 Time-setting options
Your appliance has different time-setting options which
can be used to set a cooking time, an automatic timer
or a kitchen timer.
8.1 Cooking time
Enter a cooking time for the relevant hotplate. When
the cooking time has elapsed, the hotplate switches off
automatically.
You can set a cooking time of up to 99 minutes.
Setting the cooking time
Requirement:The hotplate is selected and set.
1.
Touch .
a The display for the hotplate lights up. lights
up on the timer display.
2.
Within the next 10seconds set the required cooking
time on the control panel.
7.3 Automatic childproof lock
This function automatically activates the childproof lock
when you switch off the hob.
The automatic childproof lock can be activated in the
basic settings. →Page10
Automatic timer
You can use this function to preselect a cooking time
for all hotplates. Each time a hotplate is switched on,
the preselected cooking time counts down. When the
cooking time has elapsed, the hotplate switches off
automatically.
Switch on the automatic timer in the basic settings.
→Page10
Tip:The automatic timer is valid for all hotplates. You
can reduce or delete the cooking time for individual
hotplates. →Page9
8.2 Kitchen timer
You can set a time of up to 99 minutes after which a
signal will then sound. The kitchen timer runs independently of all other settings.
Setting the kitchen timer
1.
Switch on the kitchen timer.
There are 2 different ways of switching the kitchen
timer on.
a The cooking time counts down. If you have set a
cooking time for more than one hotplate, the cooking time of the hotplate selected is displayed.
a When the cooking time has elapsed, the hotplate
switches off. A signal sounds and flashes on the
display for 10seconds. The display lights up
brightly.
Changing or cancelling the cooking time
1.
Select the hotplate.
2.
Touch .
a The display lights up brightly.
3.
On the control panel change the cooking time or set
it to .
Switching off the continuous signal
You can switch the signal off manually.
▶
Touch any symbol.
a The displays will go out and the audible signal will
stop.
If a hotplate has been
selected.
If a hotplate has not
been selected.
a The indicator lights up.
2.
Within the next 10seconds set the required time on
the control panel.
a The time counts down.
a When the time has elapsed, a signal sounds.
lights up on the timer display. The indicator for
the kitchen timer lights up brightly. It switches off
after 10seconds.
Touch twice within
10seconds.
Touch .
Displaying the time
▶
Select the kitchen timer with .
a The time is displayed for 10seconds.
Setting the correct time
1.
Select the kitchen timer with .
2.
Set the required time on the control panel.
Switching off the timer signal
You can switch the signal off manually.
▶
Touch any touch field.
a The display goes out and the audible signal ceases.
9
en Automatic switch-off
9 Automatic switch-off
If you do not change the settings of a hotplate for a
long time, automatic switch-off will be activated.
When the hotplate switches off depends on the heat
setting selected (1to 10hours).
The heat to the hotplate is switched off. and the residual heat indicator / flash alternately on the hotplate display.
10 Wipe protection
Wiping over the control panel while the hob is switched
on may alter settings. Your hob has a wipe protection
function to prevent this.
The main switch is excluded from the wipe protection
function. You can switch the hob off at any time.
11 Energy consumption display
This function indicates the total amount of energy consumed between switching the hob on and switching it
off again.
Once switched off, the energy consumption is displayed in kilowatt hours, e.g. 1.08kWh, for
10seconds.
9.1 Continuing cooking after automatic
switch-off
1.
Touch any control.
a The display goes out.
2.
Reset.
10.1 Activating wipe protection
▶
Touch .
a A signal sounds.
a The indicator lamp above lights up.
a The control panel is locked for 30 seconds.
The accuracy of the display depends on various factors
such as the voltage quality of the power supply.
The display can be activated in the basic settings.
→Page10
12 Basic settings
You can configure the appliance to meet your needs.
12.1 Overview of the basic settings
You can find an overview of the basic settings and the
default factory settings here.
Display
Signal tone
1
Selection
Automatic childproof lock
– Switched off
– Switched on
– Manual and automatic childproof lock are
switched off.
– Confirmation signal and operating error
signal are switched off. The main switch signal remains switched on.
– Only the operating error signal is
switched on.
– Only the confirmation signal is switched
on.
– Confirmation signal and operating error
signal are switched on.
Factory setting
1
1
Display
Energy consumption display
Automatic timer
Duration of the timer end signal
Activation of the heating elements
1
Selection
Ask your electricity supplier what the mains
voltage is.
– Consumption display is switched off.
– Consumption display at mains voltage of
230V.
– Consumption display at mains voltage of
400V.
– Consumption display at mains voltage of
220V.
– Consumption display at mains voltage of
240V.
- Switched off.
- - Cooking time after which the hotplates
switch off.
– 10seconds.
– 30seconds.
– 1minute.
– Switched off
– Switched on
– The last setting before switching off the
hotplate.
Factory setting
1
1
1
1
10
Dis-
Selection
play
Time for selecting hotplates
– Unlimited: The last hotplate selected can
always be adjusted without having to select it
1
again.
– You can adjust the last hotplate selected
within 10seconds after selecting it. After this
time you have to select the hotplate again before adjusting it.
Resetting to the factory settings
– Switched off.
1
– Switched on.
1
Factory setting
12.2 Changing basic settings
Requirement:The hob is switched off.
1.
Switch on the hob.
2.
Within the next 10seconds press and hold for
4seconds.
Cleaning and servicing en
3.
Touch repeatedly until the required indicator appears on the left-hand display.
4.
Set the desired value on the control panel.
5.
Press and hold for 4seconds.
a The setting is activated.
Tip:To exit the basic settings, switch off the hob using
. Switch the hob on again and reset.
a and flash alternately on the left-hand display.
a lights up on the right-hand display.
13 Cleaning and servicing
To keep your appliance working efficiently for a long
time, it is important to clean and maintain it carefully.
13.1 Cleaning products
You can obtain suitable cleaning products and glass
scrapers from customer service, the online shop or a
retailer.
ATTENTION!
Unsuitable cleaning products may damage the surfaces of the appliance.
▶
Never use unsuitable cleaning products.
Unsuitable cleaning products
¡ Undiluted detergent
¡ Detergent intended for dishwashers
¡ Abrasive cleaners
¡ Aggressive cleaning products such as oven spray
or stain remover
¡ Abrasive sponges
¡ High-pressure or steam jet cleaners
13.2 Cleaning the glass ceramic
Clean the hob after every use to stop cooking residues
from getting burnt on.
Note:Note the information on unsuitable cleaning
products. →Page11
Requirement:The hob has cooled down.
1.
Remove heavy dirt using a glass scraper.
2.
Clean the hob with a cleaning product for glass
ceramic.
Follow the cleaning instructions on the product
packaging.
Tip:You can achieve good cleaning results if you
use a special sponge for glass ceramic.
13.3 Cleaning the hob surround
Clean the hob frame after use if dirty or stained.
Notes
¡ Note the information on unsuitable cleaning
products. →Page11
¡ Do not use the glass scraper.
11
en Troubleshooting
1.
Clean the hob frame with hot soapy water and a soft
cloth.
14 Troubleshooting
Wash new sponge cloths thoroughly before use.
2.
Dry with a soft cloth.
You can rectify minor faults on your appliance yourself.
Read the troubleshooting information before contacting
after-sales service. This will avoid unnecessary costs.
WARNING‒Risk of injury!
Improper repairs are dangerous.
▶
Repairs to the appliance should only be carried out
by trained specialist staff.
▶
If the appliance is defective, call Customer Service.
WARNING‒Risk of electric shock!
Incorrect repairs are dangerous.
▶
Repairs to the appliance should only be carried out
by trained specialist staff.
▶
Only use genuine spare parts when repairing the
appliance.
▶
If the power cord of this appliance is damaged, it
must be replaced with a special connection cable,
which is available from the manufacturer or his Customer Service.
14.1 Information on display panel
Fault Cause and troubleshooting
None There has been a power cut.
1.
Check the household fuse for the appliance.
2.
Check whether there has been a power failure by trying other electrical appliances.
All displays flash Controls are wet or objects are lying on top.
▶
Dry the controls or remove the object.
Several hotplates have been used over a prolonged period at high power settings. The hotplate has been switched off to protect the electronics.
1.
Wait a while.
2.
Touch any control.
a When the message no longer appears, the electronics have cooled down
sufficiently. You can continue cooking.
Despite being switched off by , the electronics have become hot again. All
hotplates have therefore been switched off.
1.
Wait a while.
2.
Touch any control.
a When the message no longer appears, the electronics have cooled down
sufficiently. You can continue cooking.
and the heat setting flash al-
ternately. A signal sounds.
and audible signal Hot pan near the control elements. The hotplate has been switched off to pro-
The hotplate was on for too long and has switched off automatically.
and hotplates do not heat up Demo mode is activated.
Hot pan near the control elements. There is a risk of the electronics overheating.
▶
Remove the pan.
a The display goes out shortly afterwards.
tect the electronics.
1.
Remove the pan.
2.
Touch any control.
a When the message no longer appears, the electronics have cooled down
sufficiently. You can continue cooking.
You can switch the hotplate back on again immediately.
1.
Disconnect the appliance from the power supply for 30seconds by briefly
switching off the circuit breaker in the fuse box.
2.
Touch any control within the next 3minutes.
12
Fault Cause and troubleshooting
A message with "E" appears on
the display, e.g. E0111.
The electronics have detected a fault.
1.
Switch the appliance off and on again.
a If the fault was a one-off, the message disappears.
2.
If the message appears again, call the after-sales service. Please specify the
exact error message when calling.
→"Customer Service", Page13
15 Disposal
Disposal en
Find out here how to dispose of old appliances correctly.
15.1 Disposing of old appliance
Valuable raw materials can be reused by recycling.
▶
Dispose of the appliance in an environmentally
friendly manner.
Information about current disposal methods are
available from your specialist dealer or local authority.
16 Customer Service
If you have any queries on use, are unable to rectify
faults on the appliance yourself or if your appliance
needs to be repaired, contact Customer Service.
Function-relevant genuine spare parts according to the
corresponding Ecodesign Order can be obtained from
Customer Service for a period of at least 10 years from
the date on which your appliance was placed on the
market within the European Economic Area.
Note:Under the terms of the manufacturer's warranty
the use of Customer Service is free of charge.
Detailed information on the warranty period and terms
of warranty in your country is available from our aftersales service, your retailer or on our website.
If you contact Customer Service, you will require the
product number (E-Nr.) and the production number
(FD) of your appliance.
The contact details for Customer Service can be found
in the enclosed Customer Service directory or on our
website.
This appliance is labelled in accordance with European Directive
2012/19/EU concerning used electrical and electronic appliances
(waste electrical and electronic equipment - WEEE).
The guideline determines the framework for the return and recycling of
used appliances as applicable
throughout the EU.
16.1 Product number (E-Nr.) and production
number (FD)
You can find the product number (E-Nr.) and the production number (FD) on the appliance's rating plate.
The rating plate is located on the appliance certificate.
Make a note of your appliance's details and the Customer Service telephone number to find them again
quickly.
13
Thank you for buying a
Bosch Home Appliance!
Register your new device on MyBosch now and profit directly from:
• Expert tips & tricks for your appliance
• Warranty extension options
• Discounts for accessories & spare-parts
• Digital manual and all appliance data at hand
• Easy access to Bosch Home Appliances Service
Free and easy registration – also on mobile phones:
www.bosch-home.com/welcome
Looking for help?
You'll find it here.
Expert advice for your Bosch home appliances, help with problems
or a repair from Bosch experts.
Find out everything about the many ways Bosch can support you:
www.bosch-home.com/service
Contact data of all countries are listed in the attached service directory.
Robert Bosch Hausgeräte GmbH
Carl-Wery-Straße 34
81739 München
GERMANY
www.bosch-home.com
*9001598548*
9001598548 (010210)
en
Valid within Great Britain:
Imported to Great Britain by
BSH Home Appliances Ltd.
Grand Union House
Old Wolverton Road
Wolverton, Milton Keynes
MK12 5PT
United Kingdom
Loading...
