Video | BVMS Plus 9.0

BVMS Plus 9.0

www.boschsecurity.com

u Flexible deployment - choose between cost-effective

appliances or a software-only deployment.

u Embedded resilience - keep operations up and

running even when multiple system components fail.

BVMS Plus is a unique IP video security solution that
provides seamless management of digital video, audio,
and data across any IP network. It provides the best
video management system to go with Bosch video
surveillance devices, leveraging the unique capabilities
of Bosch cameras and recording solutions. It
nevertheless offers interfaces and standards to
integrate other systems and manufacturers.
The software is provided as an e-license via e-mail.

Certifications and approvals

General Data Protection Regulation

The General Data Protection Regulation (GDPR) is
enforced on the 25th of May 2018. As a regulation it
will be directly applicable to all EU member states
without the need for national implementing legislation.
As information captured, processed and stored by
video surveillance systems is classified as "sensitive"
the GDPR will cause significant impact on the video
surveillance installations throughout Europe.
BVMS includes the required functionality to ensure an
organization can be GDPR compliant, which is further
explained in the BVMS - GDPR document, which can
be found on the following web page:

u Bosch video at its best - the best user-experience

combining Bosch cameras with BVMS.

u Integration - integrate third-party cameras, storage

and further systems into BVMS .

u IT environments and data security - benefit from full

IT compatibility from installation to day-to-day
management in a secure way.

Bosch Building Technologies Community.

Installation/configuration notes

The BVMS system design guide is published on the
following web page: Bosch Building Technologies
Community.
The system design guide summarizes the BVMS design
details, and serves as a guide to planning a BVMS
system with Bosch cameras and storage. It focuses on
BVMS combined with the VRM.

BVMS Enterprise

Multiple BVMS Plus or BVMS Professional systems can
be combined into one BVMS Enterprise System.

Cameras within system context

Cameras per operator 10.000

Sub-systems 10 sub-systems with 1000

200.000

cameras per system or 50 sub­systems with 200 cameras per
system

2 | BVMS Plus 9.0

Software assurance

In addition to the Bosch Security Systems standard
terms and conditions of sale, the Bosch Software
Assurance is a great option to keep BVMS always up to
date. With continuously changing platforms and
version compatibility, regular updates are essential.
With Bosch Software Assurance, you can relax
knowing you are always entitled to the latest software
enhancements. It ensures full technical support and
access to hotfixes. The Bosch Software Assurance is
available in the online product catalog.

Technical specifications

The release notes give a detailed overview on the
changes that are implemented, compared to the
previous BVMS version.
The architects and engineering specifications specify
in detail what the system is capable of.
Both documents can be found on the following web
page: Bosch Building Technologies Community.

System limits

Notice

The system limits are based on the hardware
recommendations.

Languages

Component Languages

Quick installation guide English, French, German,

Simplified Chinese and Spanish

Configuration manual English, German, Dutch, Italian,

Portuguese, French, Spanish,
Simplified Chinese, Traditional
Chinese, Russian, Czech, Greek,
Polish, Swedish, Turkish and
Korean.

Operation manual English, German, Dutch, Italian,

Portuguese, French, Spanish,
Simplified Chinese, Traditional
Chinese, Russian, Czech, Greek,
Polish, Swedish, Turkish and
Korean.

Software English, German, Dutch, Italian,

Portuguese, French, Spanish,
Simplified Chinese, Traditional
Chinese, Russian, Hungarian,
Japanese, Czech, Danish,
Finnish, Greek, Norwegian,
Polish, Swedish, Thai, Turkish,
Korean, Arabic, and Vietnamese

Maximum number of workstations 10

Maximum number of cameras 256

Maximum number of live and
playback sites

Maximum number of stitching
channels

Maximum number of intrusion
panels

Maximum number of DVRs 5

Maximum number of VRMs 2

Maximum number of sustained
events (Logbook) / sec

Maximum number of sustained
events (without logbook) / sec

Maximum peak event load / sec
(within 60 minutes)

Maximum number of events / sec
from ONVIF cameras

Logbook size 4GB

Notice

The logbook size can be increased by moving the
logbook to a separate database server.

0

100

10

500

2500

5000

500

Hardware recommendations
Cameras

All Bosch cameras can be used under the device
compatibility concept, which you can find on the
Bosch Security & Safety community in the following
article:
How-to: BVMS - Device compatibility.
The list of supported ONVIF cameras can be found on:
http://ipp.boschsecurity.com/bvms.
If a camera is not listed, testing can be ordered by
filling in the custom camera integration form.

Management Server and Mobile Video Service

It is recommended to run the Video Recording
Manager and the BVMS Management Server on the
same computer.

Item Description

Operating System Windows Server 2012 R2 (64-

bit)
Windows Server 2016 (64-bit)
Windows 10 Professional (64­bit) Spring Creators update
(1803)
Windows 10 Professional (64­bit) Fall Creators update (1709)
Windows 10 Enterprise (64-bit)
LTSB 2016 (1607)

CPU Intel Xeon E3-1275 V3 (3.5 GHz,

4-core, 8MB, 84W)

RAM 8GB

3 | BVMS Plus 9.0

Item Description

Free disk space 15GB (+ 15% of the hard-drive

after installation)

Network 1 Gigabit/s network interface

card

Operator Client

Item Description

Operating System Windows 10 Professional (64-

bit) Spring Creators update
(1803)
Windows 10 Professional (64­bit) Fall Creators update (1709)
Windows 10 Enterprise (64-bit)
LTSB 2016 (1607)

CPU Intel Core i7 4770 3.4 GHz (up to

3.9 GHz)

RAM 8GB

Free disk space Minimum 5GB for Single Site

Systems
Minimum 10GB for Enterprise
Systems

Network 1 Gigabit/s network interface

card

Display resolution Minimum: 1280 x 1024

Maximum: 1920 x 1080

Graphic card Nvidia Quadro K620

Nvidia Quadro M2000
Nvidia Quadro M4000
Nvidia Quadro P2000
Nvidia Quadro P4000
Intel HD Graphics 530

Network

To achieve the performance listed in the table below, a
1 Gigabit/s network is a minimum requirement
between the Operator Client and Management Server.

(Unicast) Maximum number of
workstations simultaneously
viewing the same camera

(Multicast) Maximum number of
workstations simultaneously
viewing the same camera

5

100

Event response time (assuming
sufficient network performance
considering bandwidth and
delay)

Alarm visibility time (assuming
sufficient network performance
considering bandwidth and
delay), including 1 live image
pane, 1 instant playback image
page, and 1 map image pane.

Notice

When the system does not have enough network
resources, or is experiencing a temporary
decrease in network performance, the event
response time and alarm visibility time may
increase.

Notice

The list of communication channels and required
network ports can be found in the BVMS
Configuration manual.

< 1 second

< 2 seconds

Storage devices

The storage quick selection guide, which also includes
non-Bosch storage devices, can be found on:
http://ipp.boschsecurity.com/bvms

Device Series

Bosch DIVAR IP 2000, 3000, 5000, 6000, 7000

Bosch DSA E-Series 2300, 2400, 2500, 2600,

2700, 2800

Bosch DIVAR AN 3000, 5000

Bosch DIVAR network 2000, 3000, 5000

Bosch DIVAR hybrid 3000, 5000

Bosch DVR 700, 4xx, 6xx

Bosch DiBos Firmware 8.7

Bosch Recording Station (BRS) Firmware 8.10 / 8.11

Other hardware

Type Device Remarks

Decoder Bosch VIDEOJET

decoder 3000

n/a

Decoder Bosch VIDEOJET

decoder 7000

Decoder Bosch VIDEOJET

decoder 8000

Foyer card reader MINITER 485 n/a

Serial input Werner Electronic

DTP3N

n/a

Supports displaying
of 4K cameras

n/a

4 | BVMS Plus 9.0

Type Device Remarks

Intrusion panel Bosch G-series

B9512G 3.03.14,
Bosch B5812G

3.03.14,
Bosch B5512

3.03.14,
Bosch B4512

3.03.14,
Bosch B3512

3.03.14

Intrusion panel Bosch D9412GV4

2.03.018,
Bosch D7412GV4

2.03.018

Monitor wall Barco Transform N

series

Analog matrix switch Bosch Allegiant

Series

ATM/POS Bridge Bosch ATM/POS

Bridge

Keyboard Bosch KBD-UniversalXFUSB

Keyboard Bosch Intuikey Serial, firmware

Digital I/O Advantech

ADAM-6050,
Advantech
ADAM-6052,
Advantech
ADAM-6060,
Advantech
ADAM-6066

USB to serial Belkin serial adapter

F5U103VEA

Ethernet to serial Comtrol

DeviceMaster RTS 4­port

Automation Device
in the intrusion
panels must be
configured as Mode
2

Microsoft Windows
Patch 3155464
should not be
installed

RCPPlus agent

0.9.5.0

Firmware 8.75 or
later, Master control
software 2.94

Version 1.10.00.12

1.96

n/a

n/a

n/a

Ordering information

MBV-BPLU-90 License Plus base

Base license for Plus edition. Includes 8 camera/
decoder expansions, 5 workstation expansions, 8 fail­over recording channels, 8 dual-recording channels, 5
keyboard expansions and ATM/POS, Allegiant and OPC
functionality.

Order number MBV-BPLU-90

MBV-XCHANPLU-90 License Camera/decoder expansion

Expansion license for 1 encoder/decoder channel.
Order the exact number required.

Order number MBV-XCHANPLU-90

MBV-XWSTPLU-90 License Workstation expansion

Expansion license for 1 workstation. Order the exact
number required. One MBV-XWSTPLU-xx is consumed
when using one CameoSDK connection.

Order number MBV-XWSTPLU-90

MBV-XDVRPLU-90 License DVR expansion

Expansion license for 1 DVR. Order the exact number
required.

Order number MBV-XDVRPLU-90

MBV-XKBDPLU-90 License Keyboard expansion

Expansion license for 1 video surveillance keyboard.
Order the exact number required.

Order number MBV-XKBDPLU-90

MBV-XMVSPLU-90 License Mobile video service expan­sion

Expansion license for 1 mobile video service. Order
the exact number required.

Order number MBV-XMVSPLU-90

MBV-XFOVPLU-90 License VRM Failover channel expan­sion

Expansion license for 1 VRM failover channel. Order
the exact number required.

Order number MBV-XFOVPLU-90

MBV-XDURPLU-90 License Camera dual recording ex­pansion

Expansion license for 1 camera dual recording
channel. Order the exact number required.

Order number MBV-XDURPLU-90

MBV-XINTPLU-90 License Intrusion panel expansion

Expansion license for 1 Intrusion panel. Order the
exact number required.

Order number MBV-XINTPLU-90

MBV-1STCHPLU-90 License Stitching channel expansion

Expansion license for 1 stitching camera.

Order number MBV-1STCHPLU-90

MBV-5AGRPLU-90 License Augmented reality expansion

Expansion license for 5 static augmented reality tags.

Order number MBV-5AGRPLU-90

MBV-MPLU Licnese for MBV-BPLU-*, 1yr

1 year of maintenance cover for the Plus Edition base
license.

Order number MBV-MPLU

MBV-MPLU-3YR License for MBV-BPLU-*, 3yr

3 years of maintenance cover for the Plus Edition base
license.

Order number MBV-MPLU-3YR

MBV-MCHANPLU License for MBV-XCHANPLU-*, 1yr

1 year of maintenance cover for the Plus Edition
camera/decoder expansion license.

Order number MBV-MCHANPLU

5 | BVMS Plus 9.0

Represented by:

Europe, Middle East, Africa: Germany: North America: Asia-Pacific:

Bosch Security Systems B.V.
P.O. Box 80002
5600 JB Eindhoven, The Netherlands
Phone: + 31 40 2577 284
[e-mail]
emea.boschsecurity.com

Bosch Sicherheitssysteme GmbH
Robert-Bosch-Ring 5
85630 Grasbrunn
Germany
www.boschsecurity.com

Bosch Security Systems, Inc.
130 Perinton Parkway
Fairport, New York, 14450, USA
Phone: [phone]
Fax: [phone]
[e-mail]
www.boschsecurity.us

Robert Bosch (SEA) Pte Ltd, Security Systems
11 Bishan Street 21
Singapore 573943
Phone: [phone]
Fax: [phone]
[e-mail]
www.boschsecurity.asia

© Bosch Security Systems 2018 | Data subject to change without notice
43969411211 | en, V2, 12. Sep 2018

MBV-MCHANPLU-3YR License for MBV-XCHANPLU-*,
3yr

3 years of maintenance cover for the Plus Edition
camera/decoder expansion license.

Order number MBV-MCHANPLU-3YR

MBV-MWSTPLU License for MBV-XWSTPLU-*, 1yr

1 year of maintenance cover for the Plus Edition
workstation expansion license.

Order number MBV-MWSTPLU

MBV-MWSTPLU-3YR License for MBV-XWSTPLU-*, 3yr

3 years of maintenance cover for the Plus Edition
workstation expansion license.

Order number MBV-MWSTPLU-3YR

MBV-MDVRPLU License for MBV-XDVRPLU-*, 1yr

1 year of maintenance cover for the Plus Edition DVR
expansion license.

Order number MBV-MDVRPLU

MBV-MDVRPLU-3YR License for MBV-XDVRPLU-*, 3yr

3 years of maintenance cover for the Plus Edition DVR
expansion license.

Order number MBV-MDVRPLU-3YR

MBV-MKBDPLU License for MBV-XKBDPLU-*, 1yr

1 year of maintenance cover for the Plus Edition
keyboard expansion license.

Order number MBV-MKBDPLU

MBV-MKBDPLU-3YR License for MBV-XKBDPLU-*, 3yr

3 years of maintenance cover for the Plus Edition
keyboard expansion license.

Order number MBV-MKBDPLU-3YR

MBV-MMVSPLU-3YR License for MBV-XMVSPLU-*, 3yr

3 years of maintenance cover for the Plus Edition
Mobile Video Service expansion license.

Order number MBV-MMVSPLU-3YR

MBV-MFOVPLU License for MBV-XFOVPLU-*, 1yr

1 year of maintenance cover for the Plus Edition
Failover VRM expansion license.

Order number MBV-MFOVPLU

MBV-MFOVPLU-3YR License for MBV-XFOVPLU-*, 3yr

3 years of maintenance cover for the Plus Edition
Failover VRM expansion license.

Order number MBV-MFOVPLU-3YR

MBV-MDURPLU License for MBV-XDURPLU-*, 1yr

1 year of maintenance cover for the Plus Edition Dual
Recording VRM expansion license.

Order number MBV-MDURPLU

MBV-MDURPLU-3YR License for MBV-XDURPLU-*, 3yr

3 years of maintenance cover for the Plus Edition Dual
Recording VRM expansion license.

Order number MBV-MDURPLU-3YR

MBV-MINTPLU License for MBV-XINTPLU-*, 1yr

One year of maintenance cover for the BVMS Plus
Intrusion panel expansion license.

Order number MBV-MINTPLU

MBV-MINTPLU-3YR License for MBV-XINTPLU-*, 3yr

3 years of maintenance cover for a Plus Edition
intrusion panel expansion license.

Order number MBV-MINTPLU-3YR

MBV-MMVSPLU License for MBV-XMVSPLU-*, 1yr

1 year of maintenance cover for the Plus Edition
Mobile Video Service expansion license.

Order number MBV-MMVSPLU
