Instruction Manual

EN Sunshields

LTC 9083/01, LTC 9083/01S,
LTC 9084/01, LTC 9088/01

EN|2

LTC 9083/01, LTC 9083/01S, LTC 9084/01, LTC 9088/01 | Instruction Manual | Sunshields

1.0 UNPACKING

This equipment should be unpacked and handled with
care. If an item appears to have been damaged in
shipment, replace it properly in its carton and notify
the shipper.

Check for the following items:

• Verify the unit model number

• Verify that the parts shown in the
Parts List have been included

If any items are missing, notify your Bosch Security
Systems Inc. Sales Representative or Customer Service.
The original packing carton is the safest container in
which to transport the unit. Save it for possible future use.

1.1 Parts List

2.0 DESCRIPTION

These sunshields provide protection from the direct
rays of the sun and promote cooling to reduce internal
housing temperatures.

LTC 9083/01: For use with LTC 9483 Series Housings
LTC 9083/01S: For use with LTC 9480 SeriesHousings
LTC 9084/01: For use with LTC 9484 Series Housings
LTC 9088/01: For use with LTC 9488 Series Housings

3.0 INSTALLATION

3.1 Installing Sunshield

1. Place the sunshield over the housing and align
the screw, washer, and bushing with the threads
in the rear cap.

2. Insert the screws into the sunshield and screw
them into the rear cap (see FIGURE 1).

3. Pivot the sunshield to cover the housing while
lining up the top screw with the hole in the
housing's front cap (see FIGURE 2).

4. The sunshield can then be adjusted forward to
obtain additional front coverage.

5. Secure the

sunshield by tightening the top and the

back two screws

.

Figure 1: Insert Screws in Sunshield

Figure 2: Adjusting and Securing the Sunshield

© 2005 Bosch Security Systems GmbH

3935 890 18916 05-07 | Updated February 16, 2005 | Data subject to change without notice.

Americas

Bosch Security Systems
130 Perinton Parkway
Fairport, New York, 14450, USA
Phone: [phone]
Fax: [phone]
E-mail:
[e-mail]
www.boschsecurity.us

Europe, Middle East, Africa

Bosch Security Systems B.V.
P.O. Box 80002
5600 JB Eindhoven, The Netherlands
E-mail: [e-mail]
http://www.boschsecurity.com

Asia-Pacific

Bosch Security Systems Pte Ltd
38C Jalan Pemimpin
Singapore 577180, Singapore
Phone: [phone]
Fax: [phone]
E-mail:
[e-mail]
http://www.boschsecurity.com

Qty Item

LTC 9083/01, LTC 9083/01S,
LTC 9084/01, LTC 9088/01

1 Sunshield

Hardware Kit (315 3169 003)
2 Screws
2 Washers
2 Bushings

Attach to Top

of Front Cap

Sunshield Assembly

Screw, Washer,
Bushing, (2 Each)

from Hardware Kit

Housing

Adjust shield to
desired position;
Secure with screw
as shown.
