Introduction
Congratulations on selecting the ICP-SOL2-P/ICP-SOL3-P Control Panel to protect you and
your property. To obtain the most from your unit, take time to read through this manual and
familiarize yourself with the numerous outstanding operating features of this system. In all
aspects of planning, engineering, styling, operation, convenience, and adaptability, we have
sought to anticipate your every possible requirement.
Programming simplicity and speed were some of the major considerations and we believe that
our objectives in this area were more than satisfied.
This manual explains all aspects of operating the control panel. All system parameters and
options are detailed; however, suitability is left up to the individual. Every system can be
tailored to meet all requirements quickly and easily.
1
Control Panel Introduction | en 5
Bosch Security Systems, Inc. User's Guide 2014.05 | 01 | F01U298028
Specifications
Temperature Range 0℃ to +50℃
Humidity 20% to 90%
Power Source TF008 Plug Pack – 240 V/18 VAC @ 1.3A
Stand-By Current 65 mA
Current Draw in Alarm Condition 115 mA
Current Draw in Alarm Condition with
Codepad
105 mA
Back-Up Battery 7 Ah/12 VDC Rechargeable Sealed Lead Acid
Battery
Dimensions (Case, packed in carton) 306 mm x 262 mm x84 mm
Weight 2.5 kg
Supplier Code N771
Table 2.1: Specifications
Notice!
Test the sirens, strobe, and zones at weekly intervals.
2
6 en | Specifications Control Panel
2014.05 | 01 | F01U298028 User's Guide Bosch Security Systems, Inc.
Codepad Introduction
Codepad
IUI – SOL -TEXT IUI – SOL – ICON
Quick Codepad Operation Instructions
Codepad Indicators
Codepad indicator
icons
Status Definition
ZONE 1 – 8 for ICPSOL2-P
ZONE 1 – 16 for ICPSOL3-P
On Zone is unsealed.
Off Zone is sealed.
Flashing Fast (0.25 sec
on/0.25 sec off)
Zone is in alarm condition.
Flashing Slow (1 sec on/1
sec off)
Zone is manually isolated or selected to
be isolated.
AWAY
On System is armed in AWAY Mode.
Off System is not armed in AWAY Mode.
Flashing twice a sec with
STAY indicator
Setting STAY Mode 2 zones.
3
3.1
3.2
3.3
Control Panel Codepad Introduction | en 7
Bosch Security Systems, Inc. User's Guide 2014.05 | 01 | F01U298028
Codepad indicator
icons
Status Definition
STAY
On System is armed in STAY Mode 1 or
STAY Mode 2.
Off System is not armed in STAY Mode 1 or
STAY Mode 2.
Flashing twice a sec Zone isolating mode
Flashing twice a sec with
AWAY indicator
Setting STAY Mode 2 zones.
Flashing once every 3 sec Day alarm status – day alarm turned on.
On System is disarmed.
MAINS
On AC MAINS power normal.
Flashing AC MAINS supply has failed.
FAULTS
On There is a system fault that needs to be
rectified.
Off The system is normal, there are no
faults.
Flashing There is a system fault that needs to be
acknowledged.
Programming Mode
Flashing These two indicators flash when you
enter Installer’s Programming Mode or
use any Master Code function.
The OFF indicator lights when the
system is disarmed and flashes when a
zone becomes unsealed when
disarmed. The indicator stops flashing
when all zones are sealed.
The ON indicator lights when the
system is armed and flashes when an
alarm occurs. The indicator is reset
after a valid User Code is entered.
8
en | Codepad Introduction Control Panel
2014.05 | 01 | F01U298028 User's Guide Bosch Security Systems, Inc.
Audible Indications
Below table defines the audible indicators given out by the codepad buzzer.
Audible Indicator Definition
One short beep A button was pressed on the codepad, or Exit Time ended
when armed in STAY Mode 1 or STAY Mode 2.
Two short beeps The system accepted your code.
Three short beeps The requested function was executed.
One long beep Indicates the last 10 seconds of Exit Time when armed in AWAY
Mode, or the requested operation was denied or aborted.
Indicates codepad panic/fire/medical alarm operation.
One beep every sec Walk Test Mode is currently active.
One short beep every min There is a system fault waiting to be acknowledged.
One beep every 4 sec. During Auto Arming Pre-Alert Time, the warning before
automatic arming takes place.
One beep every 2 sec. During Exit Time when armed in AWAY Mode.
Table 3.1: Audible Indicators
3.4
Control Panel Codepad Introduction | en 9
Bosch Security Systems, Inc. User's Guide 2014.05 | 01 | F01U298028
