Bosch HIIP055U Instruction Manual

Induction Ranges

Use and Care Manual

HIIP055U, HIIP055C

() = cm

Table of Contents

Use and care manual

Safety Definitions .......................................................... 4

IMPORTANT SAFETY INSTRUCTIONS ........................ 5

Proper Installation and Maintenance ................................ 5

Fire Safety .............................................................................. 6

Burn Prevention .................................................................... 6

Electromagnetic Interference ............................................. 7

Child Safety ........................................................................... 7

Cleaning Safety ..................................................................... 7

Cookware Safety .................................................................. 8

State of California Proposition 65 Warnings ................... 8

Food Safety ........................................................................... 8

Causes of Damage ........................................................ 9

Protecting the Environment ........................................ 10

Saving Energy .................................................................... 10

Getting Started ............................................................. 11

Parts ..................................................................................... 11

Accessories ........................................................................ 12

Getting familiar with the appliance ............................ 14

Control panel ...................................................................... 14

The elements ...................................................................... 15

Residual heat indicator .................................................... 15

Operation ...................................................................... 15

Main power switch ............................................................ 15

Setting the cooktop ........................................................... 15

FlexInduction

PowerMove function ......................................................... 18

Time-setting options .......................................................... 19

SpeedBoost® function ...................................................... 20

ShortBoost function .......................................................... 20

Keep Warm function ......................................................... 21

Panel Lock .......................................................................... 21

Wipe protection .................................................................. 21

Automatic time limitation .................................................. 21

Basic settings ..................................................................... 21

Energy consumption indicator ........................................ 23

Cooking with Induction ............................................... 23

Advantages of induction cooking ................................... 23

Cookware ............................................................................ 23

Cleaning and Maintenance ......................................... 25

Daily Cleaning .................................................................... 25

Cleaning guidelines .......................................................... 26

Cleaning charts .................................................................. 26

Maintenance ....................................................................... 27

Operation-Oven ........................................................... 28

Oven Control Panel ........................................................... 28

About the Oven .................................................................. 29

Basic Features ................................................................... 29

Special Features ................................................................ 32

cooking zone .......................................... 17

Settings Menu Options ..................................................... 35

Getting the Most Out of Your Appliance ................... 36

General Tips ....................................................................... 36

% ............................................................................... 37

Bake

Auto Convection Conversion .......................................... 37

Convection Bake Convection Multi-Rack Pizza

2 ............................................................................... 38

Roast % .............................................................................. 39

Convection Roast Broil

( ................................................................................ 39

Convection Broil 4 .......................................................... 40

$ .............................................................................. 40

Proof Warm

Cleaning and Maintenance-Oven ............................... 41

Cleaning the Oven ............................................................ 41

Maintenance ....................................................................... 43

Operation-Warming Drawer ........................................ 45

About the Warming Drawer ............................................. 45

Warming Drawer Specifications ..................................... 45

Operation ............................................................................ 45

Getting the Most Out of Your Warming Drawer ........ 46

About the Appliance ......................................................... 46

General Tips ....................................................................... 46

Use of Your Appliance ..................................................... 46

Preheating .......................................................................... 46

Warming Empty Serving Bowls and Plates .................. 46

Crisping Stale Items ......................................................... 46

Temperature Recommendations .................................... 46

Cleaning and Maintenance-Warming Drawer ........... 47

Cleaning the Warming Drawer ....................................... 47

Removing Drawer from Housing .................................... 47

Installing Drawer to Housing ........................................... 48

Service ......................................................................... 50

Frequently-asked questions and answers (FAQ) ........ 50

Fixing Malfunctions ........................................................... 51

Oven Troubleshooting ...................................................... 53

How to Obtain Service or Parts ...................................... 54

STATEMENT OF LIMITED PRODUCT WARRANTY ... 54

What this Warranty Covers & Who it Applies to ......... 54

How Long the Warranty Lasts ........................................ 54

Repair/Replace as Your Exclusive Remedy ................ 55

Out of Warranty Product .................................................. 55

Warranty Exclusions ......................................................... 55

Cooking Charts ........................................................... 56

Baked Goods/Entrees ..................................................... 56

Meats ................................................................................... 57

% ............................................................................. 40

2 ......................................................... 38

: ................................................. 38

2 ........................................................ 39

7KLV%RVFK$SSOLDQFHLVPDGHE\

%6++RPH$SSOLDQFHV&RUSRUDWLRQ

0DLQ6WUHHW6XLWH

ZZZERVFKKRPHFRPXV

:HORRNIRUZDUGWRKHDULQJIURP\RX

Safety Definitions

9 WARNING

This indicates that death or serious injuries may occur as a result of non-observance of this warning.

,UYLQH&$

4XHVWLRQV"



9 CAUTION

This indicates that minor or moderate injuries may occur as a result of non-observance of this warning.

NOTICE: This indicates that damage to the appliance or property may occur as a result of non-compliance with this advisory.

Note: This alerts you to important information and/or tips.

9 IMPORTANT SAFETY INSTRUCTIONS

READ AND SAVE THESE INSTRUCTIONS

IMPORTANT SAFETY INS READ AND SAVE THESE INSTRUCTIONS

WARNING

When properly cared for, your new appliance has been designed to be safe and reliable. Read all instructions carefully before use. These precautions will reduce the risk of burns, electric shock, fire, and injury to persons. When using kitchen appliances, basic safety precautions must be followed, including those in the following pages.

Do not repair or replace any part of the appliance unless specifically recommended in this manual. Refer all servicing to an authorized servicer.

In the event of an error the display flashes and beeps continuously. Disconnect appliance from the power supply and call an authorized servicer.

WARNING

This appliance is intended for use at an elevation of no more than 2000 meters above sea level.

Proper Installation and Maintenance

WARNING

TIP OVER HAZARD

A child or adult can tip the range over and be killed. Verify that the anti-tip bracket is engaged whenever the range is moved to a new location.

Do not operate the range without the anti-tip bracket in place. Failure to follow the instructions in this manual can result in death or serious burns to children and adults.

Check for proper installation and use of the anti-tip bracket. Carefully tip the range forward pulling from

the back to ensure that the anti-tip bracket engages the range leg and prevents tip-over. The range should not move more than 1” (2.5cm).

Have the installer show you the location of the circuit breaker or fuse. Mark it for easy reference.

This appliance must be properly installed and grounded by a qualified technician. Connect only to properly grounded outlet. Refer to Installation Instructions for details.

This appliance is intended for normal family household use only. It is not approved for outdoor use. See the Statement of Limited Product Warranty. If you have any questions, contact the manufacturer.

Do not store or use corrosive chemicals, vapors, flammables or nonfood products in or near this appliance. It is specifically designed for use when heating or cooking food. The use of corrosive chemicals in heating or cleaning will damage the appliance and could result in injury.

Do not operate this appliance if it is not working properly, or if it has been damaged. Contact an authorized servicer.

Do not obstruct oven vents.

When removing the door make sure oven is cool and power to the oven has been turned off before removing the door. Failure to do so could result in burns.

The oven door is heavy and fragile. Use both hands to remove the oven door. The door front is glass. Handle carefully to avoid breaking.

Grasp only the sides of the oven door. Do not grasp the handle as it may swing in your hand and cause injury or damage.

Failure to grasp the oven door firmly and properly could result in personal injury or product damage.

Lay the door on a flat smooth surface so that the door cannot fall over. Failure to do so may result in personal injury or damage to the appliance.

WARNING

To avoid injury from hinge bracket snapping closed, be sure that both levers are securely in place before removing door. Also, do not force door open or closed the hinge could be damaged and injury could result.

WARNING

Make sure the appliance and lights are cool and power to the appliance has been turned off before replacing the light bulb(s). Failure to do so could result in electrical shock or burns. The lenses (if equipped) must be in place when using the appliance. The lenses (if equipped) serve to protect the light bulb from breaking. The lenses (if equipped) are made of glass. Handle carefully to avoid breaking. Broken glass can cause an injury.

WARNING

Light socket is live when door is open if main power supply is not turned off.

9 IMPORTANT SAFETY INSTRUCTIONS

READ AND SAVE THESE INSTRUCTIONS

Fire Safety

WARNING

NEVER cover any slots, holes or passages in the oven bottom or cover an entire rack with materials such as aluminum foil. Doing so blocks air flow through the oven. Aluminum foil linings may also trap heat, causing a fire hazard.

If materials inside an oven or warming drawer should ignite, keep door closed. Turn off the appliance and disconnect the circuit at the circuit breaker box.

WARNING

Use this appliance only for its intended use as described in this manual. NEVER use this appliance as a space heater to heat or warm the room. Doing so may result in overheating the appliance. Never use the appliance for storage.

Always have a working smoke detector near the kitchen. In the event that personal clothing or hair catches fire,

drop and roll immediately to extinguish flames. Have an appropriate fire extinguisher available, nearby,

highly visible and easily accessible near the appliance. Smother flames from food fires other than grease fires

with baking soda. Never use water on cooking fires.

WARNING

TO REDUCE THE RISK OF INJURY TO PERSONS IN THE EVENT OF A GREASE FIRE, OBSERVE THE FOLLOWING:

SMOTHER FLAMES with a close-fitting lid, cookie sheet, or metal tray, then turn off the burner. BE CAREFUL TO PREVENT BURNS. If the flames do not go out immediately, EVACUATE AND CALL THE FIRE DEPARTMENT.

NEVER PICK UP A FLAMING PAN – You may be burned.

DO NOT USE WATER, including wet dishcloths or towels – a violent steam explosion will result.

Use an extinguisher ONLY if:

- You know you have a Class ABC extinguisher, and you already know how to operate it.

- The fire is small and contained in the area where it started.

- The fire department is being called.

- You can fight the fire with your back to an exit.

Burn Prevention

DO NOT TOUCH HEATING ELEMENTS OR INTERIOR SURFACES OF OVEN - Heating elements may be hot even though they are dark in color. Interior surfaces of an oven become hot enough to cause burns. During and after use, do not touch, or let clothing, potholders, or

other flammable materials contact heating elements or interior surfaces of oven until they have had sufficient time to cool. Other surfaces of the appliance may become hot enough to cause burns. Among these surfaces are oven vent openings, surfaces near these openings and oven doors.

Do not touch interior surface of the drawer while it is in use. The interior drawer could become hot enough to cause burns. Allow drawer and rack (if equipped) to cool before handling.

Exercise caution when opening the appliance. Standing to the side, open the door (or drawer) slowly and slightly to let hot air and/or steam escape. Keep your face clear of the opening and make sure there are no children or pets near the unit. After the release of hot air and/or steam, proceed with your cooking. Keep doors shut unless necessary for cooking or cleaning purposes. Do not leave open doors unattended.

Do not heat or warm unopened food containers. Build-up of pressure may cause the container to burst and cause injury.

Use high heat settings on the cooktop only when necessary. To avoid bubbling and splattering, heat oil slowly on no more than a low-medium setting. Hot oil is capable of causing extreme burns and injury.

Use caution when cooking foods with high alcohol content (e.g. rum, brandy, bourbon) in the oven. Alcohol evaporates at high temperatures. There is a risk of burning as the alcohol vapors may catch fire in the oven. Use only small quantities of alcohol in foods, and open the oven door carefully.

Always place oven racks in desired location while oven is cool. Always use oven mitts, when the oven is warm. If a rack must be moved while oven is hot, do not let potholder contact the heating elements.

Never move a pan of hot oil, especially a deep fat fryer. Wait until it is cool.

CAUTION

To avoid possible injury or damage to the appliance, ensure rack is installed exactly per installation instructions and not backwards or upside down.

Always use dry potholders. Moist or damp potholders on hot surfaces may result in burns from steam. Do not let potholder touch hot heating elements. Do not use a towel or other bulky cloth.

Secure all loose garments, etc. before beginning. Tie long hair so that it does not hang loose, and do not wear loose fitting clothing or hanging garments, such as ties, scarves, jewelry, or dangling sleeves.

Avoid reaching or leaning over the appliance. Be aware that certain clothing and hair sprays may contain flammable chemicals that could be ignited if brought in to contact with hot surface units or heating elements and may cause severe burns.

9 IMPORTANT SAFETY INSTRUCTIONS

READ AND SAVE THESE INSTRUCTIONS

Electromagnetic Interference

WARNING

This induction cooktop generates and uses ISM frequency energy that heats cookware by using an electromagnetic field. It has been tested and complies with Part 18 of the FCC Rules for ISM equipment. This induction cooktop meets the FCC requirements to minimize interference with other devices in residential installation. Induction cooktops may cause interference with television or radio reception. If interference occurs, the user should try to correct the interference by:

▯ Relocating the receiving antenna of the radio or

television.

▯ Increasing the distance between the cooktop and the

receiver.

▯ Connecting the receiver into an outlet different than the

receiver.

It is the user’s responsibility to correct any interference.

CAUTION

Persons with a pacemaker or similar medical device should exercise caution when standing near an induction cooktop while it is in use. Consult your doctor or the manufacturer of the pacemaker or similar medical device for additional information about its effects with electromagnetic fields from an induction cooktop.

WARNING

Child Safety

When children become old enough to use the appliance, it is the responsibility of the parents or legal guardians to ensure that they are instructed in safe practices by qualified persons.

Do not allow anyone to climb, stand, lean, sit, or hang on any part of an appliance, especially a door, warming drawer, or storage drawer. This can damage the appliance, and the unit may tip over, potentially causing severe injury.

Do not allow children to use this appliance unless closely supervised by an adult. Children and pets should not be left alone or unattended in the area where the appliance is in use. They should never be allowed to play in its vicinity, whether or not the appliance is in use.

CAUTION

Items of interest to children should not be stored in an appliance, in cabinets above an appliance or on the backsplash. Children climbing on an appliance to reach items could be seriously injured.

Cleaning Safety

WARNING

RISK OF BURNS

; The appliance will become very hot on the outside

during the cleaning function. Never touch the appliance door. Allow the appliance to cool down. Keep children away from the appliance.

HAZARD DUE TO MAGNETISM The probe is magnetic. The magnetic elements can

damage electronic implants such as pacemakers or insulin pumps. People with electronic implants should therefore not put the temperature sensor in the pockets of their clothes and should maintain a minimum distance of 4 inches (10 cm) with respect to their pacemaker or similar medical device.

Notes

▯ Do not clean the appliance while it is still hot. Some

cleaners produce noxious fumes when applied to a hot surface. Wet cloths or sponges can cause burns from steam.

▯ When self-cleaning, confirm that the door locks and

will not open. If the door does not lock, do not run Self Clean. Contact service.

▯ Birds have very sensitive respiratory systems. Keep

pet birds out of the kitchen or other rooms where kitchen fumes could reach them. During Self Clean, fumes are released that may be harmful to birds. Other kitchen fumes such as overheating margarines and cooking oils may also be harmful.

▯ Keep oven free from grease build up.

9 IMPORTANT SAFETY INSTRUCTIONS

READ AND SAVE THESE INSTRUCTIONS

Cookware Safety

Notes

▯ Do not place food directly on oven bottom. ▯ Follow the manufacturer’s directions when using

cooking or roasting bags.

▯ Hold the handle of the pan when stirring or turning

food. This helps prevent spills and movement of the pan.

▯ Use proper pan size.

The use of undersized cookware will expose a portion of the heating element or burner to direct contact and may result in ignition of clothing. Select cookware having flat bottoms large enough to cover the surface heating unit. This appliance is equipped with one or more surface units of different size. Proper relationship of cookware to heating element or burner will also improve efficiency.

▯ Cookware not approved for use with ceramic

cooktops may break with sudden temperature changes. Use only pans that are appropriate for ceramic cooktops. See Cookware Selection Guide.

▯ Always position handles of utensils inward so they do

not extend over adjacent work areas, burners or the edge of the cooktop. This reduces the risk of fires, spills and burns.

CAUTION

Plastic containers or plastic wrap can melt if in direct contact with the drawer or hot utensil. If it melts on to the drawer, it may not be removable.

State of California Proposition 65 Warnings

WARNING

This product can expose you to chemicals including vinyl chloride, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov.

Note: IMPORTANT SAFETY NOTICE: The California Safe Drinking and Toxic Enforcement Act requires the Governor of California to publish a list of substance known to the state to cause cancer, birth defect or other reproductive harm, and requires businesses to warn customers of potential exposure to such substances. The burning of gas cooking fuel and the elimination of soil during self-cleaning can generate small amounts of carbon monoxide. The fiberglass insulation in Self Clean ovens gives off very small amounts of formaldehyde during the first several cleaning cycles. California lists formaldehyde as a potential cause of cancer. Carbon monoxide is a potential cause of reproductive toxicity. Exposure to these substances can be minimized by:

Providing good ventilation when cooking with gas.

Providing good ventilation during and immediately after self-cleaning the oven.

Operating the unit according to the instructions in this manual.

Food Safety

WARNING

RISK OF INJURY When cooking with a bain-marie, the cooktop and

cooking vessel may crack due to overheating. The cooking vessel in the bain-marie must not come in direct contact with the bottom of the pot filled with water. Use only heat-resistant cookware.

WARNING

DANGER OF INJURY Cookware may spring or bounce upward due to fluid

trapped between the cookware bottom and cooking zone. Always keep cooking zone and cookware bottom dry.

CAUTION

To maintain food safety, follow these guidelines:

a. DO NOT use a warming drawer to heat cold food. It is

safe to use the drawer to crisp crackers, chips or dry cereal and to warm plates.

Be sure to maintain proper food temperature. The USDA recommends holding hot food at 140°F or warmer.

DO NOT warm food for longer than one hour.

Causes of Damage

9 WARNING

RISK OF INJURY

NOTICES

▯ DO NOT place accessories or items such as foil,

greaseproof paper, oven liners or bakeware on the oven cavity floor. This will cause heat to accumulate. The baking and roasting times will no longer be correct and the enamel will be damaged.

▯ Aluminum foil in the cooking compartment must not

come into contact with the door glass. This could cause permanent discoloration of the door glass.

▯ Aluminum foil and plastic will melt in hot cooking

areas. Stove protective film is not suitable for your cooktop.

▯ Do not cook on a broken cooktop. Cleaning solutions

and spillovers may create risk of electric shock.

▯ Cookware with rough bottoms will scratch the glass

ceramic surface.

▯ Salt, sugar and grains of sand will scratch the glass

ceramic surface. Never use the cooktop as a working surface or for setting things down.

▯ Avoid heating pots or pans that are empty. ▯ Hard or sharp objects falling off the cooktop may

damage it.

▯ Sugar and products containing sugar may damage the

cooktop. Immediately eliminate spills of these products with a glass scraper once the cooktop has had sufficient time to cool.

▯ Never set down hot pans and pots on the control

panel or frame. This may cause damage.

▯ Always turn hood ON when cooking at high heat or

when flambéing food (i.e. Crepe Suzette, Cherries Jubilee, Peppercorn Beef Flambé).

▯ When baking particularly juicy fruit pies, do not pack

the baking tray too generously. Fruit juice dripping from the baking tray leaves stains that cannot be removed. If possible, use the deeper universal pan.

▯ If the seal is very dirty, the appliance door will no

longer close properly during operation. The fronts of adjacent units could be damaged. Always keep the seal clean.

▯ Shimmering metallic discolorations on the glass

ceramic surface result from the use of inappropriate

cleaning agents and abrasion from cookware.

▯ Do not use the appliance door as a seat, shelf or

worktop. Do not place any cookware or accessories

on the appliance door.

▯ Depending on the appliance type, accessories can

scratch the door glass when closing the door. Always

slide accessories into the cooking compartment as far

as they will go.

▯ Do not carry or hold the appliance by the door handle.

The door handle cannot support the weight of the

appliance and could break.

Protecting the Environment

Your new appliance is energy-efficient. Here you can find tips on how to save even more energy when using the appliance, and how to dispose of your appliance properly.

Unpack the appliance and dispose of the packaging in an environmentally friendly manner.

Saving Energy

▯ Only preheat the appliance if this is specified in the

recipe or in the tables in the operating instructions.

▯ Use baking tins that are dark-colored, painted black or

have an enamel coating. They absorb the heat particularly well.

▯ Open the appliance door as infrequently as possible

when the appliance is in use.

▯ It is best to bake several cakes one after the other.

The cooking compartment is still warm. This reduces the baking time for the second cake. You can place two cake tins next to each other in the cooking compartment.

▯ For longer cooking times, you can switch the

appliance off 10 minutes before the end of the cooking time and use the residual heat to finish cooking.

▯ Always place a fitting lid on cookware. Cooking with

an uncovered pan will result in a four-fold increase in energy use. Use a glass lid to provide visibility and avoid having to lift the lid.

▯ Use cookware equipped with a solid, flat bottom.

Curved pan bases increase energy consumption.

▯ The diameter of the pan base must match the size of

the element. If not, energy may be wasted. Note: The manufacturer normally indicates the pan’s

upper diameter. This is normally greater than the diameter of the pan’s base.

▯ Choose cookware of a size suited to the amount of

food you are going to cook. A large pan that is only half full will use more energy.

▯ Use a small amount of water when cooking. This

saves energy and vegetables retain a larger percentage of their vitamins and minerals.

▯ Select a lower power level. ▯ When cooking, ensure that there is sufficient supply air

so that the extractor hood works efficiently and quietly.

▯ Fan level adjust to the intensity of the cooking fumes.

Only use the high mode if necessary. A lower fan level means lower energy consumption.

▯ With intensive cooking fumes, select a higher fan level

early on. Cooking fumes that are already distributed in the kitchen mean that the extractor hood will have to be operated longer.

▯ Switch off the extractor hood when it is no longer

required.

▯ Switch off the lighting when it is no longer required.

▯ Clean and change the filter at the specified intervals in

order to increase the effectiveness of the ventilation

and prevent a risk of fire.

Getting Started

Parts

Your appliance may vary slightly.

1 Cooktop Control Panel 2 Oven Control Panel 3 Door Gasket 4 Door Latch 5 Probe Jack 6 Convection Fan 7 Rack Position Guides with 6 rack positions 8 Oven Bottom 9 Door Hinge 10 Warming Drawer

Range Features Retained Heat

The glass cooking surface retains heat and stays hot after the element(s) have been turned off. The retained heat may be used to hold foods at serving temperatures for a short time. If a hot surface light is on, use caution when working or cleaning around the cooktop as the cooktop is still hot.

Hot Surface Indicator

The cooktop displays a hot indicator light to show when the cooking surface is too hot to touch. If a hot surface light is on, use caution when working or cleaning around the cooktop as the cooktop is still hot.

Oven Features

Accessories

Cooling Fan

The cooling fan runs during all cooking modes. The fan can be heard when it is running, and warm air may be felt as it is released from the oven vent. The fan may also run after the oven is off.

Convection Fan

The convection fan operates during all convection modes. When the oven is operating in a convection mode, the fan turns off automatically when the door is opened. The convection fan may also run during Fast Preheat and Self-Clean.

Oven Bottom

The oven bottom conceals the lower heating element. As a result the element is protected from damage and spills.

Tip: Do not place food directly on the oven bottom.

9 WARNING

Do not use aluminum foil or protective liners to line any part of the appliance, especially the oven bottom. Installation of these liners may result in a risk of electric shock or fire.

Oven Vent

The oven vent is located at the bottom of the unit. Warm air may be released from the vent before, during and after cooking. It is normal to see steam escaping from the vent, and condensation may collect in this area. This area may be warm when the oven is in use. Do not block the vent, since it is important for air circulation.

Automatic Shutoff

Probe

The probe can be used to determine the internal doneness or the end temperature of many foods, especially meats and poultry.

Do not clean in the Self Clean oven or dishwasher.

Flat Rack Use for most cooking. Can use multiple racks in some modes.

Do not clean in the self-clean oven.

Telescopic Rack (some models)

Additional 30-inch racks available from e-Shop: #HEZTR301

Use with heavier dishes to make easier to place dishes into the oven. Check on food while cooking and remove dishes from oven when done.

Do not clean in the self-clean oven.

Broiling Pan (available from e-Shop) Pan: #00449757 Grill top: #00449756

The oven will automatically shut off after 24 hours.

Self-cleaning

The oven features a self-cleaning function that eliminates the manual labor involved with cleaning your oven.

Indicators and Other Features

Default Settings-The cooking modes automatically

select the default temperature. These can be changed when a different one is needed.

E Number Codes-These codes display when there is a problem with the range.

Standby Mode-Standby mode means that the oven has power but no cooking mode or timer is running.

Use for broiling and roasting.

Do not clean in the self-clean oven.

Inserting Racks

9 CAUTION

▯ To avoid burns, place oven racks in desired

positions before turning oven on. Always use oven mitts when the oven is warm. If a rack must be moved while the oven is hot, do not let oven mitts contact hot heating elements.

▯ Use caution when removing oven racks from the

lowest rack position to avoid contact with the hot oven door.

▯ To avoid possible injury or damage to the

appliance, ensure racks are installed exactly per installation instructions and not backwards or upside down.

Flat Rack

The rack is designed with a stop so it will stop before coming completely out of the oven and not tilt.

To insert Flat Rack into Oven:

Grasp rack firmly on both sides.

Insert rack (see picture).

Telescopic Rack To insert Telescopic Rack into Oven:

Slide the rack in evenly until the rear of the rack is

about two (2) inches from the back of the oven.

Tilt the front of the rack up about 3/4” (A) and finish

pushing the rack all the way back (B).

Note: Avoid striking the oven light cover glass when

pushing the rack into position.

Tilt rack up to allow stop into rack guide.

Bring rack to a horizontal position and push the rest of the way in.

Rack should be straight and flat, not crooked.

To remove Flat Rack from Oven:

Grasp rack firmly on both sides and pull rack toward you.

When the stop is reached, tilt rack up and pull the rest of the way out.

The back of the telescopic rack drops in to place.

Pull the rack forward to engage the bottom of the rack

onto the rear of the rack position guide.

Lower the front of the rack to finish seating it on the

rack guide. The rack should feel stable when properly

seated.

Slide the movable part of the telescopic rack in and

out a few times to make sure it is able to move freely

and that the non-moving part of the telescopic rack is

securely anchored.

9 CAUTION

To avoid possible injury or damage to the appliance, ensure the telescopic rack is installed exactly per installation instructions and not backwards or upside down.

To Remove Telescopic Rack from the Oven:

Lift the front of the telescopic rack assembly about 1/

2” and push the rack to the rear about 3/4”. This

allows the rack to disengage from the rack position

guide.

Lift the rear of the telescopic rack assembly so it

clears the rack position guide and gently pull the rack

from the oven.

Note: Take care to avoid pulling the rack unevenly

which will cause it to bind during removal, catching on

the oven walls.

Before Using the Appliance for the First Time

▯ Remove all packaging materials and labels from the

▯ Apply the glass ceramic cooktop cleaner to the glass

range.

▯ Range must be properly installed by a qualified

▯ There may be a slight odor during first uses. This is

technician before use.

▯ Remove packing materials from inside the oven and

▯ Optimum cooking results depend on proper cookware

inside the drawer.

▯ While cool, wipe with clean, damp sponge and dry.

▯ The cooking surface will hold the heat and remain hot

▯ Read and understand all safety precautions and Use

Getting familiar with the appliance

In this section we describe the control panel, elements and displays.

Control panel

ceramic cooktop. Buff with a clean cloth. See Care

and Cleaning Section.

normal and will disappear.

and bakeware being used.

after the elements have been turned off.

and Care Manual information prior to operating.

3RZHU

)OH[

0RYH

-RLQ6SOLW

3DQHO

/RFN

Display icons

‹.‹ ‚-Š

•/œ ‹‹ >

Š y

ö / ô

›. ˜›.

–©

Cooktop ready Power levels Residual heat Time programming functions Wipe protection Child lock Cook timer Timer indicator SpeedBoost® function ShortBoost function Energy consumption Keep Warm function

Touch keys On/Off Main switch

ø/ã

0 1û2û...û8û9

Speed Boost

Select a cooking zone Settings range SpeedBoost® and ShortBoost function

Panel Lock Panel lock for child safety/wipe protec-

tion

Keep Warm Keep warm function

.HHS :DUP

6SHHG

.LWFKHQ

&RRN

7LPHU

&RXQW8S

7LPHU

%RRVW

Touch keys Flex Join/

Flexible cooking zone

Split Power Move PowerMove function Kitchen

Kitchen Timer function

Timer Cook Timer Setting the cooking time Count Up

Stopwatch function

Timer

Touch controls

When the cooktop heats up, the keys for the touch controls available at this time light up.

Touching a key activates the respective function.

Notes

▯ The corresponding keys for the controls light up

depending on whether they are available.

The displays for the elements or the selected functions

get brighter.

▯ Always keep the control panel clean and dry. Moisture

can prevent it from working properly.

The elements

Element

$ / Û á

Only use suitable cookware for induction cooking; see section on Cooking with Induction

Single element Use cookware of suitable size. Flexible cooking zone

See section on ~ "FlexInduction

cooking zone"

Residual heat indicator

The cooktop has a residual heat indicator for each element. This indicates that an element is still hot. Do not touch an element while the residual heat indicator is lit up.

The following are shown depending on the amount of residual heat:

▯ Display •: High temperature ▯ Display œ: Low temperature

Operation

9 WARNING

BOILOVER HAZARD Never leave surface units unattended at high heat

settings. Boilover causes smoking and greasy spillovers that may ignite.

Main power switch

Use the main switch to turn on the electronic circuitry for the control panel. The cooktop is now ready to use.

Turning the cooktop on

Touch the On/Off touch key. An acoustic signal will sound. The __ indicator located on top of the On/Off touch key and the symbols for the cooking zones light up. ‹:‹ lights up next to the cooking zones. The cooktop is ready to use.

Turning the cooktop off

Touch the On/Off touch key. The __ indicator goes out. The cooktop is switched off. The residual heat indicators will remain on until the elements have cooled off sufficiently.

Note: The cooktop switches off automatically when all the elements have been switched off for more than 20 seconds.

The residual heat indicator remains lit until the elements have cooled down sufficiently. •/œ is displayed next to the corresponding element symbol.

If you remove the cookware from the element during cooking, the residual heat indicator and the selected heat setting will flash alternately.

When the element is switched off, the residual heat indicator will light up. Even after the cooktop has been switched off, the residual heat indicator will stay lit for as long as the element is still warm.

Setting the cooktop

This section will show you how to set the elements. The table contains details on the heat settings for a variety of dishes.

Setting the element

Select the desired heat level using the number keys 1 to 9.

Heat level 1 = minimum power Heat level 9 = maximum power Each heat setting has an intermediate level. This level is

indicated by .5 in the element display and is set by touching the Ú symbols between the number keys.

Selecting the heat level

The cooktop must be turned on.

Select the desired element with by touching the ã or

ø symbol of the desired element. In the cooking zone

display ‹.‹ lights up brighter.

Then select the desired power level using the number

keys.

 

The power level is set.

Changing the power level

Select the cooking zone and then set the required power level in the control panel.

Turning off the cooking zone

Select the cooking zone and set the power level to 0. The cooking zone is turned off and the residual heat indicator is displayed.

Notes

▯ If there is no cookware on the induction cooking zone,

the heat setting display blinks. After a while, the cooking zone will switch itself off.

▯ If cookware has been placed on the cooking zone

before you turn on the cooktop, it will be detected within 20 seconds after you have touched the main switch and the cooking zone will be selected automatically. Once detected, set the power level within the next 20 seconds, otherwise the cooking zone will turn off.

Even if there are several pots and pans on the cooktop when it is switched on, only one piece of cookware is detected.

Settings table

The following table provides some examples. Cooking times may vary depending on the type of food, its weight and quality. Deviations are therefore possible.

Recommendations for cooking

▯ Set heat setting 8 to 9 for preheating ; for delicate

dishes like milk, pudding, rice pudding or cereals heat

up with setting 8 - 8.5.

▯ When cooking with the lid on, turn the heat setting

down as soon as steam escapes between the lid and

the cookware. Steam does not need to escape for a

good cooking result.

▯ After cooking, keep the lid on the cookware until you

serve the food.

▯ To cook with the pressure cooker, observe the

manufacturer's instructions.

▯ Do not cook food for too long, otherwise more

nutrients than necessary will be lost. The kitchen timer

can be used to set the optimum cooking time.

▯ For a more healthy cooking result, smoking oil should

be avoided.

▯ To brown food, fry small portions in succession. ▯ Cookware may reach high temperatures while the food

is cooking. We recommend that you use oven mits.

9 CAUTION

During cooking, stews or liquid meals such as soups, sauces or drinks can heat up too quickly unnoticed and overflow or spatter. For this reason we recommend that you stir continuously, gradually heating the food at a suitable power level.

Power levels

Melting

chocolate 1.5 butter 1.0 - 2.0

Heating

frozen vegetables, e.g. spinach 2.5 - 3.5 broth 7.0 - 8.0 thick soup 1.5 - 2.5 milk** 1.0 - 2.0

Simmering

delicate sauce e.g. Béchamel sauce 4.0 - 5.0 spaghetti sauce 2.0 - 3.0 pot roast 4.0 - 5.0 fish** 4.0 - 5.0

Cooking

rice (with double amount of water) 2.0 - 3.0 potatoes boiled in their skins (with 1-2 cups of water) 4.0 - 5.0 boiled potatoes (with 1-2 cups of water) 4.0 - 5.0 fresh vegetables (with 1-2 cups of water) 2.0 - 3.5 frozen vegetables (with 1-2 cups of water) 3.5 - 4.5 pasta (with 2-4 qt. water)* 6.0 - 7.0

Power levels

pudding** 1.0 - 2.0 cereals 2.0 - 3.0

Frying

pork chop 5.5 - 6.5 chicken breast 5.0 - 6.0 bacon 6.0 - 7.0 eggs 5.0 - 6.0 fish 5.0 - 6.0 pancakes 6.0 - 7.0 Deep fat frying** (in 1-2 qt. oil) deep frozen foods, e.g. chicken nuggets (0.5 lb per serving) 8.0 - 9.0 other, e.g. doughnuts (0.5 lb per serving) 4.5 - 5.5

Keep warm

tomato sauce 1.5 * ongoing cooking without lid ** without lid

FlexInduction® cooking zone

You can combine the elements into a large cooking zone as needed or use two elements that are independent of one another.

The FlexInduction® cooking zone consists of 4 inductors, which are controlled independently of one another. When FlexInduction® is in use, only the area is activated that is covered by cookware.

Cookware use recommendations

Place the cookware in the middle. This guarantees optimal pot detection and heat distribution.

Flexible cooking zone - as an individual element

Diameter of the cookware max. 5X" (13 cm)

Place the cookware on one of the 4 positions visible in the figure.

Diameter larger than 5X" (13 cm) Place the cookware on one of the 3 positions visible in the figure.

If the cookware takes up more than one element, place it on the upper or lower edge of the flexible cooking zone.

Flexible cooking zone - two independent elements

The front and rear elements with two inductors apiece can be used independently. The heat setting is set individually for each element. Use only one piece of cookware on each element.

As two independent elements

The flexible cooking zone is used like two independent elements.

Turning on

See section on ~ "Setting the cooktop"

As a single element

Using the entire cooking zone by connecting both elements.

Linking the two elements

The cooktop must be turned on.

Set down the cookware. Select one of the two

elements assigned to the flexible cooking zone and

set the power level.

Touch the Flex Join/Split key. The display lights up.

The heat setting appears in the display for the lower

element.

The flexible cooking zone is activated.

Changing the power level

Select one of the element in the flexible cooking zone and change the power level with the number keys.

Add another piece of cookware

Set the new item of cookware down on the cooktop, select one of the two elements in the flexible cooking zone and then touch the Flex Join/Split key twice. The new item of cookware will be detected and the power level that was previously selected will be retained.

Note: If the cookware is moved to the element being used or lifted up, the element begins an automatic search and the heat setting selected previously is retained.

Separating the two elements

Select one of the two elements in the flexible cooking zone and touch the Flex Join/Split key.

This deactivates the flexible cooking zone. The two elements will now function independently.

Notes

▯ If the element is switched off, and then switched back

on again later, the flexible cooking zone is reset to function as two independent elements.

▯ To change the configuration settings for the flexible

cooking zone, refer to the section on ~ "Basic settings"

PowerMove function

This function activates the entire flexible cooking zone, which is divided into three cooking areas and which has preset power levels.

Only use one item of cookware. The size of the cooking area depends on the cookware used and whether it is positioned correctly.

Cooking areas

Notes

▯ If more than one item of cookware is detected on the

flexible cooking zone, the function is deactivated.

▯ If the cookware is moved within the flexible cooking

zone or lifted up, the cooktop automatically starts

searching and the power level of the area in which the

cookware was detected is set.

▯ You can find information on the size and positioning of

the cookware in the section on the function

~ "FlexInduction

cooking zone"

Activation

Select one of the two elements in the flexible cooking

zone.

Touch the Power Move key. The indicator beside the

Power Move key lights up. The flexible cooking zone is

activated as a single cooking zone.

The power level in the area in which the cookware is

located lights up in the cooking zone display.

The function has now been activated.

Changing the power level

The power levels for the individual cooking areas can be changed during the cooking process. Set the cookware down on the cooking area and change the power level using the number keys.

Notes

▯ Only the power level in the area in which the cookware

is located is changed.

▯ If the function is deactivated, the power levels for the

three cooking areas are reset to the preset values.

This means that an item of cookware can be moved during the cooking process to another cooking area with another power level:

Preset power levels: Front area = power level

Middle area = power level † Rear area = power level‚.† The preset power levels can be changed independently

of one another. You can find out how to change these in the section on ~ "Basic settings"

Deactivating Touch the Power Move key. The indicator beside the

Power Move key goes out.

The function was deactivated. Note: If one of the cooking areas is set to ‹, the function

deactivates after a few seconds.

Time-setting options

Your cooktop has three timer functions:

▯ Programming the cooking time ▯ Kitchen timer ▯ Stopwatch function

Programming the cooking time

The element automatically switches off after the set time has elapsed.

Setting procedure:

Select the element and the required power level.

Touch the Cook Timer key. The ‹‹ symbol and theV indicator light up in the Cook Timer display.

y lights up in the display for the element.

.HHS

:DUP

6SHHG

.LWFKHQ

&RRN

%RRVW

7LPHU

&RXQW8S

7LPHU

Changing or deleting the time

Select the element and then touch the Cook Timer key. Change the cooking time using the number keys or set

‹‹ to delete the programmed cooking time.

Touch the Cook Timer key to confirm the selected setting.

When the time has elapsed

The element switches off, the

y display flashes and the

element switches to power level ‹‹. An acoustic signal sounds.

‹‹ and the V indicator flash in the timer display.

When the and the acoustic signal ceases.

Notes

▯ To set a cooking time of under 10 minutes, always

touch 0 before you select the required value.

▯ If a cooking time was set for several elements, the time

information for the selected element is shown in the

timer display.

▯ Select the relevant element to call up the remaining

cooking time.

▯ You can set a cooking time of up to ŠŠ minutes.

y symbol is touched, the indicators go out

Within the next 10 seconds, set the required cooking time using the number keys.

.HHS

:DUP

6SHHG

.LWFKHQ

&RRN

%RRVW

7LPHU

Touch the Cook Timer key to confirm the selected

7LPHU

&RXQW8S

7LPHU

setting.

The cooking time begins to elapse.

Notes

▯ The same cooking time can be set automatically for all

elements. The set time for each of the elements counts down independently.

You can find information on automatically programming the cooking time in section on “Cook timer”.

▯ If the flexible cooking zone is selected as the only

element, the set time for the entire cooking zone is the same.

▯ If the Move function is selected for the combined

cooking zone, the set time for the three elements is the same.

Kitchen timer

The timer can be set for periods of up to 99 minutes. It is independent of the other settings. You can also use the kitchen timer when the cooktop is turned off or locked.

This function does not automatically switch off an element.

Setting procedure

Touch the Kitchen Timer key. The ‹‹ symbol and the

V indicator light up in the timer display.

Select the required time on the control panel and

touch the Kitchen Timer key to confirm.

After a few seconds, the time begins to elapse.

Changing or deleting the time

Touch the Kitchen Timer key. Change the cooking time using the number keys or set

‹‹ to delete the programmed cooking time.

Touch the Kitchen Timer key to confirm the selected setting.

When the time has elapsed

An audible signal sounds once the time has elapsed. ‹‹ and the V symbol flash in the timer display.

The indicators go out after touching the Kitchen Timer key.

Count-up timer function

The count-up timer function displays the time that has elapsed since activation.

This functions independently from the elements and from other settings. This function does not automatically switch off an element.

Activating



Touch the Count Up Timer key. The ‹‹ symbol and the

V indicator light up in the timer display.

The time begins to count up.

Deactivating

Touching the Count Up Timer key the stopwatch function. The timer displays remain lit.

If you touch the Count Up Timer key again, the displays go out.

The function is deactivated.

SpeedBoost® function

The SpeedBoost® function enables you to heat up large quantities of water faster than when using heat setting

This function can always be activated for an element, provided the other element in the same group is not in use (see illustration).

Note: The SpeedBoost® function can also be activated in the FlexInduction® area if it is being used as a single cooking zone.

Activating

Select a element.

Touch the Speed Boost key. The › indicator lights up.

The function is activated.

Deactivating

Select a element.

Touch the Speed Boost key. The › display goes out and the element switches back

to heat setting Š.

The function is deactivated. Note: In certain circumstances, the SpeedBoost®

function can switch itself off automatically in order to protect the electronic elements inside the cooktop.

Š.

ShortBoost function

The ShortBoost function enables you to heat cookware faster than when using heat setting

After deactivating the function, select the appropriate heat setting for your food.

This function can always be activated for an element, provided the other element in the same group is not in use (see illustration).



Note: The ShortBoost function can also be activated in the FlexInduction® area if it is being used as a single cooking zone.

Recommendations for use

▯ Always use cookware that has not been pre-heated. ▯ Use pots and pans with a flat base. Do not use

containers with a thin base.

▯ Never leave empty cookware, oil, butter or lard to heat

up unattended.

▯ Do not place a lid on the cookware. ▯ Place the cookware on the center of the element.

Ensure that the diameter of the base of the cookware

corresponds to the size of the element.

▯ You can find information on the type, size and

positioning of the cookware in section Cooking with

Induction.

Activating

Select an element.

Touch the Speed Boost key twice.

The ˜›Ú indicator lights up.

The function is activated.

Deactivating

Select an element.

Touch the Speed Boost key.

The ˜›Ú display goes out and the element switches

back to heat setting Š.

The function is deactivated. Note: In certain circumstances, the ShortBoost function

can switch itself off automatically to protect the electronic elements inside the cooktop.

Š.

Keep Warm function

This function is suitable for melting chocolate or butter and for keeping food warm.

Activating

Select the required power level.

Within the next 10 seconds, touch the Keep Warm key.

The

The function is activated.

Deactivating

Select an element.

off and the residual heat indicator appears.

The function is deactivated.

Panel Lock

You can use the panel lock to prevent children from accidentally turning the appliance on.

Activating and deactivating the panel lock

The cooktop must be turned off. To activate:

Switch on the cooktop using the main switch.

Touch the Panel Lock key for approx. 4 seconds. The D indicator lights up for 10 seconds.

The cooktop is locked. To deactivate:

Switch on the cooktop using the main switch.

Touch the Panel Lock key for approx. 4 seconds.

The lock is released.

Automatic panel lock

With this function, the panel lock is automatically activated whenever you turn off the cooktop.

Turning on and off

See "Basic settings" section.

Wipe protection

Cleaning the control panel while the cooktop is on may change the settings. In order to avoid this the cooktop has a wipe protection function.

To activate: Touch the Panel Lock key. An acoustic signal sounds. The control panel is locked for 35 seconds. You can now wipe over the surface of the control panel without altering any settings.

To deactivate: The control panel will be unlocked once 35 seconds have elapsed. To release the function early, touch the Panel Lock key.

Notes

▯ An audible signal sounds 30 seconds after activation.

This indicates that the function is about to finish.

▯ The wipe protection function does not lock the main

switch. The cooktop can be switched off at any time.

Automatic time limitation

If the element is used for prolonged periods of time without changes in the settings being made, the automatic time limitation function is triggered.

The element stops heating. ”‰ and the residual heat indicator •/œ flash alternately in the display.

The indicator goes out when any symbol is pressed. The element can now be reset.

When the automatic time limitation is activated depends on the selected heat level (from 1 to 10 hours).

Basic settings

The appliance has various basic settings. You can adjust these settings to the way you usually cook.

Display Function

Automatic child lock/panel lock

‹ Manual*. ‚ Automatic.

™‚

™ƒ

™„

* Factory settings

ƒ Function deactivated.

Signal tones

‹ Confirmation and error signals are switched off. ‚ Only the error signal is switched on. ƒ Only the confirmation signal is switched on. „ All signal tones are switched on.*

Display energy consumption

‹ Switched off.* ‚ Switched on

Display Function

Automatically setting the cooking time

‹‹ Switched off.*

™†

‹‚-ŠŠ Time until automatic switch-off.

Audible signal duration for the timer function

‚ 10 seconds.* ƒ 30 seconds.

™‡

„ 1 minute.

Power management function. Limiting the total power of the cooktop

‹ Switched off.* ‚ 1000 W minimum power. ‚. 1500 W ƒ 2000 W

...

™ˆ

Š Maximum power of the cooktop.

Changing the preset heat settings for the PowerMove function

×Š Preset heat setting for the front cooking zone. Ù† Preset heat setting for the central cooking zone.

™‚‚

Ø‚ Preset heat setting for the rear cooking zone.

™‚ƒ

Checking cookware, result of the cooking process

‹ Not suitable ‚ Not perfect ƒ Suitable

™‚„

Configure the flexible cooking zone activation.

‹ As two independent elements.* ‚ As a single element.

Restoring the factory settings

‹ Individual settings.*

™‹

* Factory settings

Changing the basic settings

The cooktop must be turned off.

Turn on the cooktop with the main switch.

Within10 seconds, touch the Kitchen Timer key for about 4 seconds.

The first four displays provide product information. Touch the settings area to view the individual displays.

Product information Display

Directory for the technical after-sales service (TK)

FD number FD number 1 FD number 2

‚ Restore factory settings.

‹‚

”š Š†. ‹.†

Touching the Kitchen Timer key again takes you to

the basic settings.

™ ‚ lights up in the timer display and ‹ light up in the

displays.

.HHS

:DUP

6SHHG

.LWFKHQ

7LPHU

&RRN 7LPHU

%RRVW

&RXQW8S

7LPHU

Touch the Kitchen Timer key repeatedly until the

indicator for the required function is displayed.

Set the required value with the number keys.

.HHS :DUP

6SHHG

%RRVW

Touch the Kitchen Timer key again for at least 4 seconds. The settings have been stored.

Quit basic settings

Turn the cooktop off with the main switch.

.LWFKHQ

7LPHU

&RRN 7LPHU

Energy consumption indicator

This function indicates the total amount of energy consumed by this cooktop the last time it was used for cooking.

Once switched off, the energy consumption in kWh is displayed for 10 seconds.

The picture shows an example with an energy consumption of

You can find out how to turn this function on in the section on ~ "Basic settings"

‚.‹‰ kWh.

Cooking with Induction

Advantages of induction cooking

Induction cooking is very different from traditional cooking methods, as heat builds up directly in the item of cookware. This offers numerous advantages:

▯ Saves time when boiling and frying. ▯ Saves energy. ▯ Easier to care for and clean. Spilled food does not

burn on as quickly.

▯ Heat control and safety – the cooktop increases or

decreases the heat supply as soon as the user changes the setting. The induction element stops the heat supply as soon as the cookware is removed from the element, without having to switch it off first.

Cookware

Only use ferromagnetic cookware for induction cooking, such as:

▯ Cookware made from enameled steel ▯ Cookware made from cast iron ▯ Special induction-compatible cookware made from

stainless steel.

To check whether your cookware is suitable for induction cooking, refer to the section on ~ "Suitability test of cookware".

To achieve a good cooking result, the ferromagnetic area on the base of the pan should match the size of the element. If a element does not detect an item of cookware, try placing it on another element with a smaller diameter.

FP

LQ LQ LQ

FP

FP

If the only element being used is the flexible cooking zone, larger cookware that is particularly suited to this zone can be used. You can read more information on the positioning of the cookware in the Flex Induction Cooking Zone section.

Some induction cookware does not have a fully ferromagnetic base:

▯ If the base of the cookware is only partially

ferromagnetic, only the area that is ferromagnetic will heat up. This may mean that heat will not be distributed evenly. The non-ferromagnetic area may not heat up to a sufficient temperature for cooking.

▯ The ferromagnetic area will also be reduced if the

material of which the base of the cookware is made contains aluminum, for example. This may mean that the cookware will not become sufficiently hot or even that it will not be detected.

Empty pans or pans with a thin base

Do not heat up empty pans, or use pans with a thin base. The cooktop is equipped with an internal safety system. However, an empty pan may heat up so quickly that the "automatic switch off" function may not have time to react and the pan may reach very high temperatures. The pan base could melt and damage the cooktop glass. In this case, do not touch the pan and switch the cooktop off. If the cooktop fails to work after it has cooled down, please contact technical service.

Pan detection

Each element has a lower limit for pan detection. This depends on the diameter of the ferromagnetic area of the cookware and the material of which its base is made. For this reason, you should always use the element that best matches the diameter of the base of the pan.

Unsuitable cookware

Never use adapter plates for induction or cookware made of:

▯ Traditional stainless steel ▯ Glass ▯ Clay ▯ Copper ▯ Aluminum

Properties of the base of the cookware

The material(s) of which the base of the cookware is made can affect the cooking result. Using pots and pans made from materials that distribute heat evenly through them, such as stainless-steel pans with a three-layer base, saves time and energy.

Use cookware with a flat base; if the base of the cookware is uneven, this may impair the heat supply.

No pan or improper size

If no pan is placed on the selected element, or if it is made of unsuitable material or is not the correct size, the power level displayed on the element indicator will flash. Place a suitable pan on the element to stop the flashing. If you take longer than 90 seconds to place a suitable pan on the element, it will automatically turn off.

Cleaning and Maintenance

Daily Cleaning

Notes

▯ Clean only parts listed in manual. ▯ Bosch cleaners have been tested and approved for

use on Bosch appliances. Other recommended cleaners do not constitute an endorsement of a specific brand.

Cleaning the Cooktop

9 WARNING

DO NOT TOUCH SURFACE UNITS OR AREAS NEAR UNITS

Surface units may be hot even though they are dark in color. Areas near surface units may become hot enough to cause burns. During and after use, do not touch, or let clothing or other flammable materials contact surface units or areas near units until they have had sufficient time to cool. Among those areas are the cooktop and surfaces facing the cooktop.

9 CAUTION

Do not use any kind of cleaner on the glass while the surface is hot. The resulting fumes can be hazardous to your health. Heating the cleaner can chemically attack and damage the surface.

Precautions for Long Life and Good Appearance of the Surface

▯ Regular, daily care using the glass ceramic cooktop

cleaner will protect the surface and make it easier to remove food soil and water spots.

▯ The glass ceramic cooking surface is a durable

material resistant to impact but not unbreakable if a pan or other object is dropped on it.

▯ Never cook food directly on the glass. ▯ Avoid placing a wok support ring, trivet or other metal

stand on glass surface.

▯ Do not use the glass surface as a cutting board. ▯ Do not slide cookware across the cooking surface as

it may scratch the surface.

▯ Do not place wet pans on the glass surface.

Care Before Use

Care is easy when preventative steps are taken. For example, apply a small amount of glass ceramic cooktop cleaner (packaged with range) on a daily basis. This provides a protective film that makes it easy to remove water spots or food spatters. The temperature of the cooking surface reduces the protective qualities of this cleaner. It must be reapplied before each use. Use a clean cloth and apply glass ceramic cooktop cleaner before each use to remove dust or metal marks that can occur on the counter level surface between uses.

Daily Cleaning Techniques

9 WARNING

RISK OF BURNS Be extremely careful as the cooking surface is hot. If

using damp sponge or cloth, wait until the cooktop has cooled sufficiently to prevent steam burns. Also, some cleaners give off noxious fumes when applied to hot surfaces.

Clean the surface when it is completely cool with glass

ceramic cooktop cleaner.

Exception: Remove dry sugar, sugar syrup, tomato

products and milk with the razor blade scraper once

the cooktop has sufficiently cooled. See Cooktop Care

Chart on the next page.

Wipe off spatters with a clean, damp sponge or a

paper towel. Rinse and dry. Use white vinegar if

smudge remains; rinse.

Apply a small amount of the glass ceramic cooktop

cleaner. When dry, buff surface with a clean paper

towel or cloth.

Using the Razor Blade Scraper

Use the scraper to remove dried or baked on foods. Wait until the cooktop has cooled sufficiently. Hold the scraper at a 30° angle. Move it over the soil to lift it off of the cooktop. Finish with a clean, damp sponge or paper towel. Apply white vinegar if smudge remains and rinse.

9 WARNING

RISK OF INJURY The blade is extremely sharp. Risk of cuts. Protect

the blade when not in use. Replace the blade immediately when any imperfections are found. Follow manufacturer’s instructions.

Cleaning the Control Knobs

Pull out and off to remove knobs. Wipe with hot, soapy cloth. Rinse and dry. Do not soak.

To replace, push knob straight onto shaft.

Avoid these cleaners

▯ Glass cleaners which contain ammonia or chlorine

bleach. These ingredients may damage or

permanently stain the cooktop.

▯ Caustic cleaners such as Easy Off® may stain the

cooktop surface.

Cleaning guidelines

When using a cleaner, use only a small amount; apply to a clean paper towel or cloth. Wipe on the surface and buff with a clean dry towel.

For best results, use a glass cooktop cleaner such as the Bosch Glass Cooktop Cleaner (part number 12010030), which can be ordered online at www.bosch-home.com/ us/store (for U.S. customers only). Other cleaners include Bon Ami®, Soft Scrub® (without bleach), and

▯ Abrasive cleaners. ▯ Metal scouring pads and scrub sponges such as

Scotch Brite® can scratch and/or leave metal marks.

▯ Soap-filled scouring pads such as SOS® can scratch

the surface.

▯ Powdery cleaners containing chlorine bleach can

permanently stain the cooktop.

▯ Flammable cleaners such as lighter fluid or WD-40.

white vinegar.

Cleaning charts

Type of Soil Possible Solution Dry sugar, sugar syrup, milk or tomato spills. Melted

plastic film or foil. All these items require removal after the cooktop has sufficiently cooled. Be extremely careful as the cooking surface is hot. Failure to remove these can permanently damage the surface.

Remove these types of spills after the surface has sufficiently cooled using the razor blade scraper. Use a new, sharp razor in the scraper. Remove pan and turn off the element. Wearing an oven mitt, hold scraper at 30° angle, using care not to gouge or scratch the glass. Push soil off the heated area. After the surface has cooled, remove the residue and apply the glass ceramic cooktop cleaner.

9 WARNING

RISK OF INJURY The blade is extremely sharp. Risk of cuts. Protect

the blade when not in use. Replace the blade immediately when any imperfections are found. Follow manufacturer’s instructions.

Burned-on food soil, dark streaks, and specks Soften by laying a damp paper towel or sponge on top of

soil for 30 minutes. Use a plastic scrubber and glass ceramic cooktop cleaner or use the razor blade scraper. Rinse and dry.

Greasy spatters Use a soapy sponge or cloth to remove grease; rinse

thoroughly and dry. Apply glass ceramic cooktop cleaner.

Metal marks: Iridescent stain Pans with aluminum, copper or stainless steel bases may

leave marks. Treat immediately after surface has cooled with glass ceramic cooktop cleaner. If this does not remove the marks, try a mild abrasive (Bon Ami®, Soft Scrub® without bleach) with a damp paper towel. Rinse and reapply glass ceramic cooktop cleaner. Failure to remove metal marks before the next heating makes removal very difficult.

Type of Soil Possible Solution Hard water spots:

Hot cooking liquids dripped on surface

Surface scratches:

Small scratches are common and do not affect cooking. They become smoother and less noticeable with daily use of the glass ceramic cooktop cleaner.

Minerals in some water can be transferred onto the surface and cause stains. Use undiluted white vinegar, rinse and dry. Recondition with glass ceramic cooktop cleaner. Remove boilovers and stains before using the cooktop again.

Apply glass ceramic cooktop cleaner before using to remove sand-like grains and grit such as salt and seasoning. Scratches can be reduced by using pans with bases that are smooth, clean, and dry before use. Use recommended glass ceramic cooktop cleaner daily.

NOTE: Diamond rings may scratch the surface.

Maintenance

This appliance requires no maintenance other than daily cleaning. For best results, apply cooktop cleaning cream daily.

Operation-Oven

Oven Control Panel

800 Series Oven Control Panel

1 Mode Selection Buttons 2 Display 3 Numeric Keypad Buttons 4 Special Function Buttons

Note: You only need to press lightly on the buttons to operate them.

Button Descriptions

Turns Panel Lock mode on and off.

Turns the oven lights on or off.

'BTU

1SFIFBU

Press to edit the oven timer for the selected oven. Turns off the oven at the end of the specified time.

Provides access to user settings to allow customization of basic display, language and other features. Use also to set clock.

Sets probe target temperature. Probe allows monitoring of internal meat temperature during cooking.

Enables Fast Preheat option.

Starts and stops the kitchen timer(s). Press to edit a timer.

6HOI

&OHDQ

Activates Self Clean mode.

About the Oven

8BSNJOH

%SBXFS

POPGG

Turns the warming drawer on or off.

Allows access to cooking/heating modes that do not have a direct access button.

More Modes

Additional modes are available by pressing the More Modes button. These modes include Convection Broil,

Warm, Pizza, Proof and Roast. These are discussed in the Getting the Most Out of Your Appliance section later in this manual.

Display Symbols

Door Lock- Is displayed when the oven

door is locked.

Your new oven combines premium cooking results and simple operation.

The oven design has been optimized to improve heat distribution in the oven cavity. The result is even browning, shorter cooking times and lower energy consumption.

Thanks to the Self Clean mode, hours of scrubbing into the darkest corners of the oven is a thing of the past. The oven burns off soil simply and easily. All that is left to do is to remove a few ashes from the oven when Self Clean is done.

Clear labeling of the touch pads makes operating the oven very easy. This manual includes all instructions for operating the oven.

Please call us if you ever have any questions. Our telephone number is located at the beginning of this manual. We welcome your comments and suggestions.

Basic Features

Setting the Clock

Fast Preheat Symbol- Is displayed when

Fast Preheat is active.

Probe Symbol- Appears when a probe is detected.

Panel Lock- Is displayed when the control panel is locked.

Self Clean- Is displayed when Self Clean is active.

The oven includes time functions that require the current time to be set. It is therefore important to set the clock before beginning to use the oven. The oven cannot be in a cooking mode to access the clock set mode.

To set the clock:

The oven must be in Standby mode (oven is powered

on, but no cooking mode or timer in operation).

To access the clock set mode:

Press the Settings button. The display shows “SET

CLOCK”. Press Enter to edit the clock.

Use the numeric keypad to enter the desired time.

Each number pressed is entered at the right and

moving previously entered digits to the left. To set

“12:45 pm”, press 1,2,4,5.

When the desired time is entered, set the time by

pressing Enter.

The clock is now set and running.

Setting the Cooking Mode and Temperature

There are two alternate methods to set cooking mode and temperature.

To set the Cooking Mode first, then the temperature:

Press the desired Cooking Mode button. The cooking mode and default temperature are displayed. The temperature flashes to show it can be edited.

Press Enter to start the mode using the default temperature.

To change the temperature, enter the new temperature using the numeric buttons. For example, changing temperature to 375°. Press Enter to set the updated temperature.

Note: The new temperature is automatically set after 10 seconds if Enter is not pressed.

Preheating starts.

To set the Temperature first and then the Cooking Mode (not for Broil or Convection Broil):

Press the numeric keys to enter the desired

temperature setting. The temperature entered is

displayed beside the current time.

Select a cooking mode that is compatible with the

temperature entered. If no cooking mode is selected

within 5 seconds of setting the temperature, an error

tone sounds and a “SELECT MODE” message is

displayed and blinks.

Press a Mode Selection button to select a cooking

mode.

The new mode and temperature set automatically after

10 seconds if Enter is not pressed.

Note: If a temperature is entered that is not within the allowed range for the mode, an error tone will sound and the lower part of the screen will display “TEMP NOT ALLOWED”.

Note: If a temperature is entered that is not within the

allowed range for the mode selected, an error tone will

sound and the lower part of the screen will display

“TEMP NOT ALLOWED”.

To change the Oven Temperature:

Press the Cooking Mode button.

The current temperature flashes. Use the numeric

buttons to enter a new temperature. Press Enter.
