Bosch FCP-500-P, FCP-500-K, FCP-500, FCP-500-C-P, FCP-500-CPK Installation Manual

...
500 Series Photoelectric Detectors
FCP-500 | FCP-500-P | FCP-500-C | FCP-500-C-P
en Installation Guide
FCP-500 Series
1. Specifications
Type Description Material No.
1
FCP-500-C Photoelectric Detector with Carbon Monoxide Detection,
Color White
FCP-500-C-P Photoelectric Detector with Carbon Monoxide Detection,
Transparent with Color Inserts
FCP-500 Photoelectric Detector, Color White 4.998.150.702
FCP-500-P Photoelectric Detector, Transparent with Color Inserts 4.998.150.704
The CO sensor has not been evaluated to the requirements of UL 2075 or for its ability to
i
Table 2: Options (included)
Type Description Material No.
FAA-500-BB-UL Ceiling Mount Back Box for US F.01U.510.767
FCA-500 Four-Wire Base (six conductors) 4.998.151.300
FCA-500-E Four-Wire EOL Base (six conductors) 4.998.151.301
FAA-500-TR-W Trim Ring, White 4.998.151.295
FAA-500-TR-P Trim Ring, Transparent with Color Inserts 4.998.151.296
detect a fire. The FCP-500-C and FCP-500-C-P detect CO as a component of a fire. Do not use the FCP-500-C and FCP-500-C-P as CO detectors.
4.998.150.703
4.998.150.705
Table 3: Options (optional)
Type Description Material No.
DRA-5 Remote LED Annunciator -
FAA-500-TTL Test Adapter with Magnet F.01U.508.725
FAA-500-RTL Removal Tool F.01U.508.720
Table 4: Technical Data
Operating Voltage 9.7 V DC to 30 V DC
Current Consumption Standby Alarm/Trouble
- FCA-500 / FCA-500 with DRA-5 3mA/3mA 47 mA / 52 mA
- FCA-500-E / FCA-500-E with DRA-5 24 mA / 24 mA 47 mA / 58 mA
Alarm Output Alarm resistance 680 Ω or 0 Ω (US only)
Remote LED Output Maximum 20 mA
Rating of Trouble/Alarm Relay 1A@30VDC
Reset Time
Max. Start-up Time 22 sec
Sensitivity 1.3 ...2.9 %/ft (4.3 ... 9.5 %/m)
Mounting Locations Refer to NFPA-72 guidelines.
Maximum Mounting Height Refer to NFPA-72 guidelines.
Minimum Mounting Height 9.0 ft (2,7 m)
The detector resets if power is interrupted for at least 2 sec.
Bosch Security Systems
BDL-F01U000626 | A7 | 2007.07
