Communications Systems | PLE‑1MAxx0‑EU Plena Mixer Amplifier
PLE‑1MAxx0‑EU Plena Mixer Amplifier
4 microphone/line inputs, plus 3 music source inputs
▶
100 V and telephone input with priority & VOX
▶
Announcement only output, 3-wire volume override
▶
Voice-activated emergency override
▶
Wide range of power (30, 60 and 120 Watts)
▶
2-tone chime
▶
Outputs for line out and music only out
▶
Unique easy-to-use intuitive tone controls
▶
These Plena mixer amplifiers are high performance,
professional public address units with modern state of the
art features. They are easy to use, taking the complexity
away from the user and putting it where it belongs, inside
the equipment. Providing a crisp call or clear music is as
easy as turning on the radio.
The amplifier is also surprisingly affordable, without
sacrificing features such as ducking, priority and
flexibility.
Functions
Microphone and line inputs
All Mic/line inputs can be switched between microphone
level and line level sensitivity. The inputs are balanced but
can be used unbalanced. Phantom power can be switched
on to provide power to condenser microphones.
Input channels 1 and 2 can take priority over all other
microphone and music inputs:
Input 1 can be activated by contact closure on the PTT
•
(push to talk). A 2-tone chime can be configured to
precede an announcement.
Input 2 can be switched automatically if a signal is fed
•
to the input i.e. if someone speaks into the
microphone (VOX activation).
When one or both inputs are configured to have priority,
the amount of attenuation (reduction) of the cinch inputs,
can be set between ‑2 dB (little attenuation) or -∞ dB
(mute). This provides a talk-over or voice-over function.
Input channels 1 and 2 also feature selectable speech
filters to enhance the clarity of announcements.
Music inputs
Separate music inputs are available with their own input
selector and volume control. The user can choose a music
source like a CD player or radio (like the PLN-DVDT), and
set the level of music.
Personalized settings
More unique features are available such as detachable
labels where the user can write the names for inputs,
music sources and zones. These labels can then be
mounted on the front, protected by the clear window.
Another useful feature is to indicate preferred settings on
the front panel by inserting colored pins at the preset
levels of all knobs. You can then instruct a user to set all
the controls to the silver pins to configure the system for
their particular use. A second user can set all controls to
the red pins for their configuration.
www.boschsecurity.com
Page 2
2 | PLE‑1MAxx0‑EU Plena Mixer Amplifier
Integration
A telephone / 100 V emergency input with VOX activation
is provided for easy integration with another PA system or
a telephone paging system. It has its own preset volume
control and overrides all other inputs, including call
station and inputs 1 and 2.
The unit also has a line output to add amplifiers for larger
systems with more output power. This output can be
switched to music only, for example, so that music on
hold can be provided for the telephone system.
Power
The mixer amplifiers come in 30, 60 and 120 Watt output
power. This power is directly available on 100 V constant
voltage connections and on a low impedance connection
for an 8 ohm load. Moreover, the amplifiers have a
separate 100 V call-only output channel for addressing
areas where only priority announcements are required.
The call-only output can also be used for 3-wire remote,
volume control override.
Output status
An LED VU meter monitors the master output. A
headphone socket, below the VU meter, provides the
mixer output. For total reliability and ease of use, a limiter
is integrated into the output stage to restrict output if the
user applies too much signal.
Controls and indicators
Front
On/off switch
•
Power on LED
•
LED VU meter for master output (LEDs for -18, -12 -6,
•
-3, 0 dB)
Master volume knob
•
Four volume knobs for microphone inputs
•
Knob for treble level
•
Knob for bass level
•
Headphone socket
•
Background music button
•
Back
Dip switches
•
Ducking level
•
Tel/100 V volume control
•
Interconnections
See Technical Specifications.
Certifications and Approvals
Safety acc. to EN 60065
EMC emission acc. to EN 55103-1
EMC immunity acc. to EN 55103-2
Installation/Configuration Notes
Rear view
Parts Included
Quantity Components
1 PLE-1MAxx0-EU Plena Mixer Amplifier
1 Power cord
1 Manual
1 Set of 19”mounting brackets
1 Plena Easy Line CD
Technical Specifications
Electrical
Mains power supply
Voltage 230 VAC ±10%, 50/60 Hz (reduced
power at lower mains or battery voltage)
Inrush current PLE-1MA030-EU 4.5 A
Inrush current PLE-1MA060-EU 5 A
Inrush current PLE-1MA120-EU 10 A
Power consumption
PLE-1MA030-EU 100 VA
PLE-1MA060-EU 200 VA
PLE-1MA120-EU 400 VA
Performance
Frequency response 50 Hz to 20 kHz (+1/‑3 dB @ ‑10 dB
ref. rated output)
Distortion <1% @ rated output power, 1 kHz
Bass Control Max -12/+12 dB (frequency is setting
dependent)
Treble Control Max -12/+12 dB (frequency is setting
dependent)
RJ-45 input 1 x
Wall panel input For PLE-WP3S2Z
Page 3
PLE‑1MAxx0‑EU Plena Mixer Amplifier | 3
Mic/Line input 4 x
Input 1 (Push-to-talk contact with
ducking functionality)
Input 2-4 (VOX with ducking functionality on input 2)
Sensitivity 1 mV (mic); 1 V (line)
Impedance >1 kohm (mic); >5 kohm (line)
Dynamic range 93 dB
S/N (flat at max volume) >63 dB (mic); >70 dB (line)
S/N (flat at min volume/muted) >75 dB
CMRR (mic) >40 dB (50 Hz to 20 kHz)
Headroom >17 dB
Speech filter -3 dB @ 315 Hz, high-pass, 6 dB/oct
Phantom power supply 16 V via 1.2 kohm (mic)
Music input 3 x
Connector Cinch, stereo converted to mono
Sensitivity 300 mV
Impedance 22 kohm
S/N (flat at max volume) >70 dB
S/N (flat at min volume/muted) >75 dB
Headroom >25 dB
Emergency / telephone 1 x
Connector 7-pin Euro style pluggable screw con-
Sensitivity Tel 1 V maximum
Sensitivity 100V 100 V maximum
Impedance >10 kohm
S/N (flat at max volume) >65 dB
VOX threshold 50 mV; attack time
5-pin Euro style, balanced, phantom
3-pin XLR, balanced, phantom
3-pin XLR, balanced, phantom
nector
150 ms; release time 2 s
Mechanical
Dimensions (H x W x D) 100 x 430 x 270 mm
(19" wide, 2U high)
Mounting Stand-alone, 19" rack
Color Charcoal
Weight
PLE-1MA030-EU Approx. 5 kg
PLE-1MA060-EU Approx. 8.5 kg
PLE-1MA120-EU Approx. 10.5 kg
Environmental
Operating temperature -10 ºC to +45 ºC
Storage temperature -40 ºC to +70 ºC
Relative humidity <95%
Acoustic noise level of fan
(PLE-1MA120-EU)
<33 dB SPL @ 1 m
Ordering Information
PLE‑1MA030‑EU Plena Mixer Amplifier
30 W, 4 mic. and 3 BGM input mixer amplifier
PLE‑1MA060‑EU Plena Mixer Amplifier
60 W, 4 mic. and 3 BGM input mixer amplifier
PLE‑1MA120‑EU Plena Mixer Amplifier
120 W, 4 mic. and 3 BGM input mixer amplifier
PLE-1MA030-EU
PLE-1MA060-EU
PLE-1MA120-EU
Master/music output 1 x
Connector 3-pin XLR, balanced
Nominal level 1 V
Impedance <100 ohm
Loudspeaker output 100 V
Connector Euro style pluggable screw terminal,
floating
Max / rated PLE-1MA030 45 W / 30 W
Max / rated PLE-1MA060 90 W / 60 W
Max / rated PLE-1MA120 180 W / 120 W
Loudspeaker output 8 ohm
Connector Euro style pluggable screw terminal,
floating
PLE-1MA030-EU 16 V (30 W)
PLE-1MA060-EU 22 V (60 W)
PLE-1MA120-EU 31 V (120 W)
