Bosch DFS067A50B Product spec sheet
Telescopic cooker hoods extend when
in use and slide neatly away when not in
operation.
●
Extra quiet: maximum extractor performance with minimal
noise.
●
Grease filtration level: filters out over 85% of the grease from
kitchen air
●
EcoSilence Drive: our highly efficient motor saves on energy,
not on performance.
●
LED Illumination: The energy-saving lighting provides bright
and clear lighting for the hob area.
●
Intensive speed setting: removes strong kitchen odours
quickly and effectively.
Technical Data
Typology : Pull-out
Approval certificates : CE, VDE
Length of electrical supply cord (cm) : 175
Required niche size for installation (HxWxD) :
385mm x 524.0mm x 290mm
Minimum distance above an electric hob : 430
Minimum distance above a gas hob : 650
Net weight (kg) : 11.166
Type of control : Electronic
Maximum output air extraction (m3/h) : 391
Boost position output recirculating (m3/h) : 488.0
Maximum output recirculating air (m3/h) : 303
Boost position air extraction (m³/h) : 739
Number of lights (Stck) : 2
Noise level (dB(A) re 1 pW) : 54
Diameter of air outlet (mm) : 150 / 120
Grease filter material : Washable aluminium
EAN code : 4242002918327
Connection rating (W) : 146
Current (A) : 10
Voltage (V) : 220-240
Frequency (Hz) : 60; 50
Plug type : GB plug
Installation type : Built-in
'!2E20AC-jbidch!
Serie | 4, Telescopic cooker hood, 60
cm, Silver metallic
DFS067A50B
Optional accessories
DSZ4561 : Standard odor filter (replacement)
DSZ4565 : Standard recirculation kit
DSZ4656 : Handle strip black
DSZ4660 : Lowering frame
DWZ0IT0P0 :
DWZ1IT1D1 : Long Life recirculation kit external
DWZ1IX1B6 : Clean Air Plus odor filter (replacement)
DWZ1IX1C6 : Clean Air Plus recirc. kit external
1/4
Serie | 4, Telescopic cooker hood, 60 cm,
Silver metallic
DFS067A50B
Telescopic cooker hoods extend when in use
and slide neatly away when not in operation.
Key Information
Electronic control
-
Electronic control via Soft touch button control
-
Efficient BLDC technology
-
Design
60 cm wide
-
Silver metallic lacquer
-
Telescopic hood
-
Handle strip specification: stainless steel without logo
-
For installation into a 60cm wide cupboard
-
Features
Soft touch button control with Electronic display
-
3 power levels & intensive setting
-
Automatic intensive revert (6mins)
-
Automatic after running (Automatic after running (10 min))
-
Pyramid filter
-
2 x LED lights
-
Neutral white lights
-
2 removable metal grease filter cassettes
-
Removable metal grease filters
-
Performance/technical information
Telescopic easy installation
-
Suitable for ducted or recirculating operation
-
Extraction rate according to EN 61591 ø 15 cm:
-
max. Normal use 391 m³/h
Intensive 739 m³/h
Extraction rate exhaust air according to EN 61591:
-
max. normal use 391 m³/h, intensive 739 m³/h
Power rating: 146 W
-
Noise level according to EN 60704-3 and EN 60704-2-13
-
exhaust air:
Max. normal use: 54 dB(A) re 1 pW
Intensive: 68 dB(A) re 1 pW
Noise max. Normal Level: Noise, max. speed in normal us: 54
-
dB dB*
With the Clean Air Plus recirculation kit (available as optional
-
accessory) your appliances reaches:
Extraction rate in recirculation mode:
Max. normal use: 358 m³/h
Intensive: 496 m³/h
Noise level in recirculation mode:
Max. normal use: 60 dB(A) re 1 pW
Intensive: 67 dB(A) re 1 pW
Average Energy Consumption: 38.8 kWh/year*
-
Energy Efficiency Class: B (at a range of energy efficiency
-
classes from A+++ to D)
Blower Efficiency Class: A*
-
Lighting Efficiency Class: A*
-
Grease Filtering Efficiency Class: B*
-
Dimensions (HxWxD): 426 x 598 x 290 mm
-
Dimensions exhaust air (HxWxD): 426-426 x 598 x 290 mm
-
Dimensions recirculating (HxWxD): 426-426 x 598 x 290 mm
-
Diameter pipe Ø 150 mm (Ø 120 mm enclosed)
-
Light Intensity: 740 lux
-
Colour Temperature: 3500 K
-
Accessories
For recirculated extraction recirculating kit or CleanAir
-
recirculating kit (accessory) needed
