Built-in oven
CMG656B.1
[en] Instruction manual Built-in oven
Table of contents
[en]I n st r u ct i on manual Bui l t - i n oven
8 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
( Important safety information . . . . . . . . . . . . . . . 5
General information . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Microwave . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Cleaning function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
] Causes of damage . . . . . . . . . . . . . . . . . . . . . . . . 7
General information . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Microwave . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
7 Environmental protection . . . . . . . . . . . . . . . . . . 8
Saving energy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Environmentally-friendly disposal . . . . . . . . . . . . . . . . . 9
* Getting to know your appliance . . . . . . . . . . . . 10
Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Operating modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Types of heating. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Microwave . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Further information . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Cooking compartment functions . . . . . . . . . . . . . . . . 13
_ Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Accessories included . . . . . . . . . . . . . . . . . . . . . . . . . 13
Inserting accessories . . . . . . . . . . . . . . . . . . . . . . . . . 14
Optional accessories . . . . . . . . . . . . . . . . . . . . . . . . . 14
K Before using for the first time. . . . . . . . . . . . . . 15
Initial use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Cleaning the cooking compartment and accessories 15
1 Operating the appliance . . . . . . . . . . . . . . . . . . 15
Switching the appliance on and off . . . . . . . . . . . . . . 15
Starting the operation. . . . . . . . . . . . . . . . . . . . . . . . . 16
Selecting an operating mode . . . . . . . . . . . . . . . . . . . 16
Setting the type of heating and temperature . . . . . . . 16
Rapid heating. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
en
A Childproof lock. . . . . . . . . . . . . . . . . . . . . . . . . . 21
Activating and deactivating. . . . . . . . . . . . . . . . . . . . .21
Q Basic settings. . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Changing the basic settings . . . . . . . . . . . . . . . . . . . .21
List of basic settings. . . . . . . . . . . . . . . . . . . . . . . . . .21
Power cut . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Changing the time . . . . . . . . . . . . . . . . . . . . . . . . . . .22
F Sabbath mode . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Starting Sabbath mode. . . . . . . . . . . . . . . . . . . . . . . .22
D Cleaning agent . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Suitable cleaning agents . . . . . . . . . . . . . . . . . . . . . .23
Surfaces in the cooking compartment . . . . . . . . . . . .24
Keeping the appliance clean . . . . . . . . . . . . . . . . . . .24
. Cleaning function. . . . . . . . . . . . . . . . . . . . . . . . 24
EcoClean . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Drying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
p Rails. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Detaching and refitting the rails . . . . . . . . . . . . . . . . .25
q Appliance door . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Removing the door cover . . . . . . . . . . . . . . . . . . . . . .26
Removing and fitting the door panels. . . . . . . . . . . . .27
3 Trouble shooting . . . . . . . . . . . . . . . . . . . . . . . . 28
Rectifying faults yourself . . . . . . . . . . . . . . . . . . . . . . .28
Maximum operating time . . . . . . . . . . . . . . . . . . . . . .28
Cooking compartment bulbs . . . . . . . . . . . . . . . . . . .29
4 Customer service . . . . . . . . . . . . . . . . . . . . . . . . 29
E number and FD number . . . . . . . . . . . . . . . . . . . . .29
P Dishes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Information on the settings . . . . . . . . . . . . . . . . . . . . .29
Selecting a dish . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Applying settings for dishes . . . . . . . . . . . . . . . . . . . .30
O Time-setting options . . . . . . . . . . . . . . . . . . . . . 17
Setting the cooking time . . . . . . . . . . . . . . . . . . . . . . 17
Setting the end time . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Setting the timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
^ Microwave. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Cookware. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Microwave power settings . . . . . . . . . . . . . . . . . . . . . 19
Setting the microwave . . . . . . . . . . . . . . . . . . . . . . . . 19
Setting MicroCombi . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Drying. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
J Tested for you in our cooking studio. . . . . . . . 31
Silicone moulds . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
Cakes and small baked items . . . . . . . . . . . . . . . . . .31
Bread and rolls. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
Pizza, quiche and savoury cakes . . . . . . . . . . . . . . . .35
Bakes and soufflés . . . . . . . . . . . . . . . . . . . . . . . . . . .37
Poultry . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .38
Meat . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Fish . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Vegetables and side dishes . . . . . . . . . . . . . . . . . . . .45
3
en Intended use
Dessert. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Eco heating functions. . . . . . . . . . . . . . . . . . . . . . . . .47
Acrylamide in foodstuffs . . . . . . . . . . . . . . . . . . . . . . . 49
Slow cook . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Drying. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Preserving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
Prove dough. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Defrosting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Heating food in a microwave . . . . . . . . . . . . . . . . . . .54
Keeping warm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Test dishes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Produktinfo
Additional information on products, accessories,
replacement parts and services can be found at
www.bosch-home.com and in the online shop
www.bosch-eshop.com
8Intended use
Intended use
Read these instructions carefully. Only then
will you be able to operate your appliance
safely and correctly. Retain the instruction
manual and installation instructions for future
use or for subsequent owners.
This appliance is only intended to be fully fitted
in a kitchen. Observe the special installation
instructions.
Check the appliance for damage after
unpacking it. Do not connect the appliance if it
has been damaged in transport.
Only a licensed professional may connect
appliances without plugs. Damage caused by
incorrect connection is not covered under
warranty.
This appliance is intended for domestic use
only. The appliance must only be used for the
preparation of food and drink. The appliance
must be supervised during operation. Only
use this appliance indoors.
This appliance is intended for use up to a
maximum height of 4000 metres above sea
level.
This appliance may be used by children over
the age of 8 years old and by persons with
reduced physical, sensory or mental
capabilities or by persons with a lack of
experience or knowledge if they are
supervised or are instructed by a person
responsible for their safety how to use the
appliance safely and have understood the
associated hazards.
Children must not play with, on, or around the
appliance. Children must not clean the
appliance or carry out general maintenance
unless they are at least 15 years old and are
being supervised.
Keep children below the age of 8 years old at
a safe distance from the appliance and power
cable.
Always slide accessories into the cooking
compartment the right way round.
~ "Accessories" on page 13
4
(Important safety
information
Impor t ant safety informat i on
General information
:Warning – Risk of fire!
■ Combustible items stored in the cooking
compartment may catch fire. Never store
combustible items in the cooking
compartment. Never open the appliance
door if there is smoke inside. Switch off the
appliance and unplug it from the mains or
switch off the circuit breaker in the fuse box.
Risk of fire!
■ Loose food remnants, fat and meat juices
may catch fire. Before using the appliance,
remove the worst of the food remnants from
the cooking compartment, heating elements
and accessories.
Risk of fire!
■ A draught is created when the appliance
door is opened. Greaseproof paper may
come into contact with the heating element
and catch fire. Do not place greaseproof
paper loosely over accessories during
preheating. Always weight down the
greaseproof paper with a dish or a baking
tin. Only cover the surface required with
greaseproof paper. Greaseproof paper
must not protrude over the accessories.
:Warning – Risk of burns!
■ The appliance becomes very hot. Never
touch the interior surfaces of the cooking
compartment or the heating elements.
Always allow the appliance to cool down.
Keep children at a safe distance.
Risk of serious burns!
■ Accessories and ovenware become very
hot. Always use oven gloves to remove
accessories or ovenware from the cooking
compartment.
Risk of burns!
■ Alcoholic vapours may catch fire in the hot
cooking compartment. Never prepare food
containing large quantities of drinks with a
high alcohol content. Only use small
quantities of drinks with a high alcohol
content. Open the appliance door with care.
:Warning – Risk of scalding!
■ The accessible parts become hot during
operation. Never touch the hot parts. Keep
children at a safe distance.
Risk of scalding!
■ When you open the appliance door, hot
steam can escape. Steam may not be
visible, depending on its temperature. When
opening, do not stand too close to the
appliance. Open the appliance door
carefully. Keep children away.
Important safety information en
Risk of scalding!
■ Water in a hot cooking compartment may
create hot steam. Never pour water into the
cooking compartment when the cooking
compartment is hot.
:Warning – Risk of injury!
■ Scratched glass in the appliance door may
develop into a crack. Do not use a glass
scraper, sharp or abrasive cleaning aids or
detergents.
Risk of injury!
■ The hinges on the appliance door move
when opening and closing the door, and
you may be trapped. Keep your hands away
from the hinges.
Risk of injury!
■ Components inside the appliance door may
have sharp edges. Wear protective gloves.
:Warning – Risk of electric shock!
■ Incorrect repairs are dangerous. Repairs
may only be carried out and damaged
power cables replaced by one of our
trained after-sales technicians. If the
appliance is defective, unplug the appliance
from the mains or switch off the circuit
breaker in the fuse box. Contact the aftersales service.
Risk of electric shock and serious injury!
■ The cable insulation on electrical
appliances may melt when touching hot
parts of the appliance. Never bring
electrical appliance cables into contact with
hot parts of the appliance.
Risk of electric shock!
■ Do not use any high-pressure cleaners or
steam cleaners, which can result in an
electric shock.
Risk of electric shock!
■ A defective appliance may cause electric
shock. Never switch on a defective
appliance. Unplug the appliance from the
mains or switch off the circuit breaker in the
fuse box. Contact the after-sales service.
:Warning – Hazard due to magnetism!
Permanent magnets are used in the control
panel or in the control elements. They may
affect electronic implants, e.g. heart
pacemakers or insulin pumps. Wearers of
electronic implants must stay at least 10 cm
away from the control panel.
5
en Important safety information
Microwave
:Warning – Risk of fire!
■ Using the appliance for anything other than
its intended purpose is dangerous and may
cause damage.
The following is not permitted: drying out
food or clothing, heating slippers, grain or
cereal pillows, sponges, damp cleaning
cloths or similar.
For example, heated slippers and grain or
cereal pillows may catch fire, even several
hours after they have been heated.The
appliance must only be used for the
preparation of food and drinks.
Risk of fire!
■ Food may catch fire. Never heat food in
heat-retaining packages.
Do not leave food heating unattended in
containers made of plastic, paper or other
combustible materials.
Do not select a microwave power or time
setting that is higher than necessary. Follow
the information provided in this instruction
manual.
Never use the microwave to dry food.
Never defrost or heat food with a low water
content, e.g. bread, at too high a microwave
power or for too long.
Risk of fire!
■ Cooking oil may catch fire. Never use the
microwave to heat cooking oil on its own.
:Warning – Risk of explosion!
Liquids and other food may explode when in
containers that have been tightly sealed.
Never heat liquids or other food in containers
that have been tightly sealed.
:Warning – Risk of burns!
■ Foods with peel or skin may burst or
explode during, or even after, heating.
Never cook eggs in their shells or reheat
hard-boiled eggs. Never cook shellfish or
crustaceans. Always prick the yolk when
baking or poaching eggs. The skin of foods
that have a peel or skin, such as apples,
tomatoes, potatoes and sausages, may
burst. Before heating, prick the peel or skin.
Risk of burns!
■ Heat is not distributed evenly through baby
food. Never heat baby food in closed
containers. Always remove the lid or teat.
Stir or shake well after the food has been
heated. Check the temperature of the food
before it is given to the child.
Risk of burns!
■ Heated food gives off heat. The ovenware
may become hot. Always use oven gloves
to remove ovenware or accessories from
the cooking compartment.
Risk of burns!
■ Airtight packaging may burst when food is
heated. Always observe the instructions on
the packaging. Always use oven gloves to
remove dishes from the cooking
compartment.
Risk of burns!
■ The accessible parts become very hot when
in operation. Never touch hot parts. Keep
children at a safe distance.
Risk of burns!
■ At the highest settings in microwave only
mode, the drying function will automatically
switch on an additional heating element to
heat the cooking compartment. Never touch
the inside surfaces of the cooking
compartment or the heating elements while
they are hot. Keep children at a safe
distance.
Risk of burns!
■ Using the appliance for anything other than
its intended purpose is dangerous.
You are not permitted to use it to dry food
or clothing or to warm slippers, grain or
cereal pillows, sponges, damp cleaning
cloths or the like.
This is because, for instance, overheated
slippers, grain or cereal pillows, sponges
and damp cleaning cloths, etc., may cause
burns to the skin.
:Warning – Risk of scalding!
■ There is a possibility of delayed boiling
when a liquid is heated. This means that the
liquid reaches boiling temperature without
the usual steam bubbles rising to the
surface. Even if the container only vibrates a
little, the hot liquid may suddenly boil over
and spatter. When heating, always place a
spoon in the container. This will prevent
delayed boiling.
:Warning – Risk of injury!
■ Unsuitable ovenware may crack. Porcelain
or ceramic ovenware can have small
perforations in the handles or lids. These
perforations conceal a cavity below. Any
moisture that penetrates this cavity could
cause the ovenware to crack. Only use
microwave-safe ovenware.
Risk of injury!
6
Causes of damage en
■ If using the appliance in microwave mode
only, placing cookware and containers
made of metal or featuring metal detailing
inside the appliance may cause sparks
when the appliance is operating. This may
damage the appliance. Never use metal
containers when using the appliance in
microwave mode only.
:Warning – Risk of electric shock!
The appliance is a high-voltage appliance.
Never remove the casing.
:Warning – Risk of serious damage to
health!
■ The surface of the appliance may become
damaged if it is not cleaned properly.
Microwave energy may escape. Clean the
appliance on a regular basis, and remove
any food residue immediately. Always keep
the cooking compartment, door seal, door
and door stop clean.
Risk of serious damage to health!
■ Microwave energy may escape if the
cooking compartment door or the door seal
is damaged. Never use the appliance if the
cooking compartment door, the door seal
or the plastic door frame is damaged. Call
the after-sales service.
Risk of serious damage to health!
■ Microwave energy will escape from
appliances that do not have any casing.
Never remove the casing. For any
maintenance or repair work, contact the
after-sales service.
Cleaning function
:Warning – Risk of burns!
; The appliance becomes very hot on the
outside during the cleaning function. Never
touch the appliance door. Allow the appliance
to cool down. Keep children at a safe
distance.
]Causes of damage
Cau s e s of damage
General information
Caution!
■ Accessories, foil, greaseproof paper or ovenware on
the cooking compartment floor: do not place
accessories on the cooking compartment floor. Do
not cover the cooking compartment floor with any
sort of foil or greaseproof paper. Do not place
ovenware on the cooking compartment floor if a
temperature of over 50 ºC has been set. This will
cause heat to accumulate. The baking and roasting
times will no longer be correct and the enamel will
be damaged.
■ Aluminium foil: Aluminium foil in the cooking
compartment must not come into contact with the
door glass. This could cause permanent
discolouration of the door glass.
■ Water in a hot cooking compartment: do not pour
water into the cooking compartment when it is hot.
This will cause steam. The temperature change can
cause damage to the enamel.
■ Moisture in the cooking compartment: Over an
extended period of time, moisture in the cooking
compartment may lead to corrosion. Allow the
cooking compartment to dry after use. Do not keep
moist food in the closed cooking compartment for
extended periods of time. Do not store food in the
cooking compartment.
■ Cooling with the appliance door open: Following
operation at high temperatures, only allow the
cooking compartment to cool down with the door
closed. Do not trap anything in the appliance door.
Even if the door is only left open a crack, the front of
nearby furniture may become damaged over time.
Only leave the cooking compartment to dry with the
door open if a lot of moisture was produced whilst
the oven was operating.
■ Fruit juice: when baking particularly juicy fruit pies,
do not pack the baking tray too generously. Fruit
juice dripping from the baking tray leaves stains that
cannot be removed. If possible, use the deeper
universal pan.
■ Extremely dirty seal: If the seal is very dirty, the
appliance door will no longer close properly during
operation. The fronts of adjacent units could be
damaged. Always keep the seal clean. Never
operate the appliance if the seal is damaged or
missing.
■ Appliance door as a seat, shelf or worktop: Do not
sit on the appliance door, or place or hang anything
on it. Do not place any cookware or accessories on
the appliance door.
■ Inserting accessories: depending on the appliance
model, accessories can scratch the door panel
when closing the appliance door. Always insert the
accessories into the cooking compartment as far as
they will go.
■ Carrying the appliance: do not carry or hold the
appliance by the door handle. The door handle
cannot support the weight of the appliance and
could break.
7
en Environmental protection
Microwave
Caution!
■ Creation of sparks: Metal – e.g. a spoon in a glass –
must be kept at least 2 cm from the cooking
compartment walls and the inside of the door.
Sparks can irreparably damage the glass on the
inside of the door.
■ Combining accessories: Do not combine the wire
rack with the universal pan. Sparks may be created if
they are inserted directly on top of one another. Only
insert them into their own shelf level.
■ Microwave only: The universal pan and baking tray
are unsuitable when using the microwave only. If you
use either of these, this may create sparks, which
may damage the cooking compartment. Place
cookware on the wire rack provided, or place it in
the microwave and set a type of heating.
■ Foil containers: Do not use foil containers in the
appliance. They damage the appliance by producing
sparks.
■ Operating the microwave without food: Operating the
appliance without food in the cooking compartment
may lead to overloading. Never switch on the
microwave unless there is food inside. The short
crockery test is the exception to this rule.
~ "Microwave" on page 19
7Environmental protection
Env i r on ment al pr ot ec t i on
Your new appliance is particularly energy-efficient.
Here you can find tips on how to save even more
energy when using the appliance, and how to dispose
of your appliance properly.
Saving energy
■ Only preheat the appliance if this is specified in the
recipe or in the tables in the operating instructions.
■ Leave frozen food to defrost before placing it in the
cooking compartment.
■ Use baking tins that are dark-coloured, painted black
or have an enamel coating. These absorb the heat
particularly well.
■ Microwave popcorn: Never set the microwave output
too high. Use a maximum microwave output of 600
watts. Always place the popcorn bag on a glass
plate. The door panels may crack if overloaded.
This appliance corresponds to the standards EN 55011
and CISPR 11. It is a Group 2, Class B product.
Group 2 means that microwaves are produced for the
purpose of heating food. Class B states that the
appliance is suitable for private households.
■ Remove any unnecessary accessories from the
cooking compartment.
8
■ Open the appliance door as infrequently as possible
when the appliance is in use.
■ It is best to bake several cakes one after the other.
The cooking compartment stays warm. This reduces
the baking time for the second cake. You can place
two cake tins next to each other in the cooking
compartment.
Environmental protection en
■ For longer cooking times, you can switch the
appliance off 10 minutes before the end of the
cooking time and use the residual heat to finish
cooking.
Environmentally-friendly disposal
Dispose of packaging in an environmentally-friendly
manner.
This appliance is labelled in accordance with
European Directive 2012/19/EU concerning
used electrical and electronic appliances
(waste electrical and electronic equipment WEEE). The guideline determines the
framework for the return and recycling of used
appliances as applicable throughout the EU.
9
en Getting to know your appliance
*Getting to know your
appliance
Gett i ng to know your appl i anc e
In this section, we will explain the indicators and
controls. You will also find out about the various
functions of your appliance.
Note: Depending on the appliance model, individual
details and colours may differ.
7\SHVRI
KHDWLQJ
$VVLVW
0LFURZDYH
Control panel
In the control panel, you can use the various buttons,
touch fields, touch-screen displays and the rotary
selector to set the different appliance functions. The
current settings are shown on the display.
The overview shows the control panel when the
appliance is switched on with the menu display.
0LFURFRPEL
0DLQPHQX
&OHDQLQJ
6HOHFW
%DVLF
VHWWLQJV
+ +
( Buttons
The buttons on the left- and right-hand side of the
control panel have a pressure point. Press these
buttons to activate them.
For appliances that do not have a stainless steel
front, these two button touch fields do not have a
pressure point.
0 Touch fields
There are sensors under the touch fields. Simply
touch the respective symbol to select the function.
8 Rotary selector
The rotary selector is fitted so that you can turn it
indefinitely to the left or right. Press it lightly and
move it in the direction required using your finger.
@ Display
You can see the current adjustment values,
options or notes in the display.
H Touch-screen displays
You can see the current selection options in the
touch-screen displays. You can select these here
directly by touching the appropriate text field. The
text fields change depending on the selection.
#
Controls
The individual controls are adapted for the various
functions of your appliance. You can set your appliance
simply and directly.
Buttons and touch fields
Here you can find a short explanation of the various
buttons and touch fields.
Symbol Meaning
Buttons
ÿ on/off Switching the appliance on and off
l Start/Stop Starting, pausing or cancelling (hold down
for approx. 3 secs) an operation
Touch fields
Menu Menu Opens the "Operating modes" menu
t Timer Selects the timer
° Information Displays information
D Childproof lock Activating and deactivating (hold down for
approx. 4 secs) the childproof lock
--------
Rotary selector
You can use the rotary selector to change the setting
values shown on the display.
You can also use the rotary selector to scroll through
the selection lists on the touch-screen displays.
In most selection lists, you have to turn the rotary
selector in the opposite direction once you reach the
beginning or the end of the list.
10
Getting to know your appliance en
Display
The display is structured so that the information can be
read at a glance in any situation.
The value that you can currently set is highlighted in
white text in the display. The value in the background is
displayed in grey text.
Highlighted information
Enlargement As long as you use the rotary selector to change
The highlighted value can be changed immediately without first being selected.
After starting an operation, either the temperature
or level remains highlighted. The white line also
serves as the heating line and gradually turns red.
Note: When using the Microwave operating
mode, the cooking time is highlighted. The heating
line does not appear.
the highlighted value, only this value will be displayed larger.
P
&
a
V
7HPSH
UDWXUH
&
Note: Due to thermal inertia, the temperature displayed
may be slightly different to the actual temperature inside
the oven.
Touch-screen displays
The touch-screen displays are both a display medium
and control element at the same time. They show the
options that you can select for a function and the
current setting. To select a function, simply touch the
text field directly.
The function currently selected is identified by a red
vertical bar next to it. Its corresponding value is
highlighted in white on the display.
The small red arrow next to the text field shows the
functions to which you can scroll forwards or
backwards.
7\SHRIKHDWLQJ
7HPSHUDWXUH
'KRWDLU
Operating modes
Your appliance has various operating modes which
make your appliance easier to use.
You can find more precise descriptions of these in the
corresponding sections.
Display ring
The display ring can be found around the outside of the
display.
If you change a value, the display ring shows you where
you are in the selection list. Depending on the settings
area and length of the selection list, the display ring
may be continuous or divided into segments.
During operation, the display ring turns red at secondlong intervals. After every full minute, the segments turn
red again from the beginning. As the cooking time
counts down, one segment disappears every second.
Temperature display
After the operation has started, the current cooking
compartment temperature is displayed graphically on
the display.
Heating line The white line under the temperature turns red from
left to right as the cooking compartment heats up.
When you are preheating the appliance, the optimal
time to place the food in the cooking compartment
is when the line has completely turned red.
For set levels, e.g. the grill setting, the heating line
turns red immediately.
Residual heat
indicator
When the appliance is switched off, the display ring
shows the residual heat in the cooking compartment. As the residual heat cools down, the display
ring becomes darker and disappears completely at
some point.
Operating mode Use
Heating types
~ "Operating the appliance"
on page 15
Assist
~ "Dishes" on page 29
Microwave
~ "Microwave" on page 19
MicroCombi
~ "Microwave" on page 19
Cleaning
~ "Cleaning function"
on page 24
Basic settings
~ "Basic settings"
on page 21
--------
There are various finely tuned heating
types for the optimal preparation of
your food.
For many dishes, there are preprogrammed setting values.
You can use the microwave to cook,
heat up or defrost your dishes more
quickly.
You can use the microwave combination function to switch on the microwave and a type of heating.
There are several cleaning functions
available: EcoClean and Drying.
You can change your appliance's
basic settings to suit your needs.
11
en Getting to know your appliance
Types of heating
To make sure that you always use the right type of
heating to cook your food, we have explained the
differences and applications below.
The symbols for each type of heating help you to
remember them.
Heating type Temperature Use
<
%
.
#
7
(
*
$
.
$
4D hot air 30-275 °C For baking and roasting on one or more levels.
The fan distributes heat from the ring heating element in the back panel evenly
around the cooking compartment.
Top/bottom heating 30-300 °C For traditional baking and roasting on one level. Especially suitable for cakes with
moist toppings.
Heat is emitted evenly from the top and bottom.
Hot air eco 30-275 °C For gently cooking selected types of food on one level without preheating.
The fan distributes the heat from the ring-shaped heating element in the back
panel around the cooking compartment.
This heating function is most effective between 125 and 275 °C.
This heating function is used to measure both the energy consumption in air recir-
culation mode and the energy efficiency class.
Top/bottom heating eco 30-300 °C For gently cooking selected types of food.
Heat is emitted from above and below.
This heating function is most effective between 150 and 250 °C.
This heating function is used to measure the energy consumption in the conven-
tional mode.
Hot air grilling 30-300 °C For roasting poultry, whole fish and larger pieces of meat.
The grill element and the fan switch on and off alternately. The fan circulates the
hot air around the food.
Grill, large area Grill settings:
1 = low
2 = medium
3 = high
Grill, small area Grill settings:
1 = low
2 = medium
3 = high
Pizza setting 30-275 °C For preparing pizza and dishes which require a lot of heat from underneath.
Slow cooking 70-120 °C For gentle and slow cooking of seared, tender pieces of meat in ovenware without
Bottom heating 30-250 °C For cooking in a bain marie and for the final baking stage.
Keeping warm 60-100 °C For keeping cooked food warm.
For grilling flat items for grilling, such as steaks and sausages, for making toast,
and for cooking au gratin.
The whole area below the grill element becomes hot.
For grilling small amounts of steaks or sausages, for making toast, and for cooking au gratin.
The centre area under the grill heating element becomes hot.
The bottom heating element and the ring heating element in the back panel heat
up.
a lid.
The heat is emitted evenly from the top and bottom at low temperatures.
The heat is emitted from below.
O
For temperature settings above 275 °C and grill
setting 3, the appliance reduces the temperature to
approx. 275 °C or grill setting 1 after approx.
40 minutes.
P
Preheating ovenware 30-70 °C For preheating ovenware.
--------
Default values
For each heating type, the appliance specifies a default
temperature or level. You can accept this value or
change it in the appropriate area.
12
Microwave
Accessories en
To ensure that you always use the correct microwave
power setting, we have provided a general overview of
what the different power settings can be used for below.
The microwave power settings do not always
correspond to the exact wattage that the appliance
uses.
Microwave power setting Maximum cooking time Use
90 watts 1 hour 30 mins For defrosting delicate foods.
180 watts 1 hour 30 mins For defrosting and continued cooking.
360 watts 1 hour 30 mins For cooking meat and for heating delicate foods.
600 watts 1 hour 30 mins For heating and cooking food.
Max. watts 30 minutes For heating liquids.
--------
MicroCombi
Various types of heating can be combined with the
Microwave operating mode. The appliance heats up
Cooling fan
The cooling fan switches on and off as required. The
hot air escapes above the door.
and the microwave is switched on at the same time. As
a result, the food is ready in a much shorter time.
Microwave power settings between 90 and 360 watts
are suitable for this.
Caution!
Do not cover the ventilation slots. Otherwise, the
appliance may overheat.
So that the cooking compartment cools down more
Further information
In most cases, the appliance provides notes and further
information on the action just carried out.
Touch the ° field. The note is shown in the display for a
quickly after the operation, the cooling fan continues to
run for a certain period afterwards.
Note: You can change how long the cooling fan
continues to run in the basic settings. ~ "Basic
settings" on page 21
few seconds. Use the rotary selector to scroll to the end
of longer notes.
Some notes are displayed automatically, for example as
confirmation, or to provide an instruction or warning.
_Accessories
Cooking compartment functions
The functions in the cooking compartment make your
appliance easier to use. This, for example, enables the
cooking compartment to be well lit and a cooling fan to
prevent the appliance from overheating.
Opening the appliance door
If you open the appliance door during an operation, the
operation is paused. The operation continues to run
when you close the door.
Note: When using the Microwave operating mode, you
must touch the l Start/Stop button once the door has
been closed to resume the operation. You can change
the basic setting for this. ~ "Basic settings"
on page 21
Interior lighting
When you open the appliance door, the interior lighting
switches on. If the door remains open for longer than
around 15 minutes, the lighting switches off again.
For most operating modes, the interior lighting switches
on as soon as the operation is started. When the
operation has finished, the lighting switches off.
Note: You can set the interior lighting not to come on
during the operation in the basic settings. ~ "Basic
settings" on page 21
Acc e s s o r i e s
Your appliance is accompanied by a range of
accessories. Here, you can find an overview of the
accessories included and information on how to use
them correctly.
Accessories included
Your appliance is equipped with the following
accessories:
Wire rack
For ovenware, cake tins and ovenproof
dishes.
For roasts, grilled items and frozen
meals.
The wire rack is suitable for use in the
microwave.
Universal pan
For moist cakes, pastries, frozen meals
and large roasts.
It can be used to catch dripping fat when
--------
Only use original accessories. They are specially
adapted for your appliance.
You can buy accessories from the after-sales service,
from specialist retailers or online.
you are grilling directly on the wire rack.
13
en Accessories
Note: The accessories may deform when they become
hot. This does not affect their function. Once they have
cooled down again, they regain their original shape.
Microwave
Only the wire rack provided is suitable when using the
microwave only. If you use the universal pan or the
baking tray, this may create sparks, which may damage
the cooking compartment.
When using the appliance in combination with the
microwave or "Dishes" mode, you can use the universal
pan, baking tray or any other accessories that have
been included with the appliance.
Inserting accessories
The cooking compartment has three shelf positions.
The shelf positions are counted from the bottom up.
When using positions 1, 2 and 3, always insert the
accessory between the two guide rods for a shelf
position.
Notes
■ Ensure that you always insert the accessories into
the cooking compartment the right way round.
■ Always insert the accessories fully into the cooking
compartment so that they do not touch the appliance
door.
Locking function
The accessories can be pulled out approximately
halfway until they lock in place. The locking function
prevents the accessories from tilting when they are
pulled out. The accessories must be inserted into the
cooking compartment correctly for the tilt protection to
work properly.
When inserting the wire rack, ensure that the lug ‚ is at
the rear and is facing downwards. The word
"microwave" must be at the front and the curvature must
be facing downwards ¾.
D
D
When inserting baking trays, make sure that the recess
‚ is at the rear and is facing downwards. The sloping
edge of the accessory ƒ must be facing towards the
appliance door.
Example in the picture: universal pan
D
D
E
Optional accessories
You can buy optional accessories from the after-sales
service, from specialist retailers or online. *You will find
a comprehensive range of products for your appliance
in our brochures and online.
Both availability and whether it is possible to order
online differ between countries. Please see your sales
brochures for more details.
Note: Not all optional accessories are suitable for every
appliance. When purchasing, please always quote the
exact identification number (E-no.) of your appliance.
~ "Customer service" on page 29
Special accessories
Wire rack
For ovenware, cake tins and ovenproof dishes, and for roasts and
grilled food.
Universal pan
For moist cakes, pastries, frozen meals and large roasts.
It can be used to catch dripping fat when you are grilling directly on
the wire rack.
Baking tray
For tray bakes and small baked products.
Wire insert
For meat, poultry and fish.
For inserting into the universal pan to catch dripping fat and meat
juices.
Universal pan, non-stick
For moist cakes, pastries, frozen meals and large roasts.
Pastries and roasts can be removed more easily from the universal
pan.
Baking tray, non-stick
For tray bakes and small baked products.
The pastries can be removed more easily from the baking tray.
Profi pan
For preparing large quantities.
Lid for the Profi pan
The lid turns the Profi pan into a Profi roasting dish.
Pizza tray
For pizzas and large round cakes.
14
Before using for the first time en
Grill tray
Use for grilling in place of the wire rack or as a splatter guard.Only use
in the universal pan.
Bread-baking stone
For home-made bread, bread rolls and pizzas that require a crispy
base.
The baking stone must be preheated to the recommended temperature.
Glass roasting dish (5.1 litres)
For stews and bakes.
Particularly suitable for the "Meals" operating mode.
Glass tray
For large roasts, moist cakes and bakes.
Glass tray
For bakes, vegetable dishes and baked goods.
Decorative trims
For concealing the lower shelf of the unit and the base of the appliance.
--------
KBefore using for the first
time
Bef or e usi ng for the first time
Before you can use your new appliance, you must
make some settings. You must also clean the cooking
compartment and accessories.
Initial use
After connecting the appliance to the power or following
a power cut, the settings for initial use are shown on the
display. It may take a few seconds for the instruction to
appear.
Note: You can change these settings at any time in the
basic settings. ~ "Basic settings" on page 21
Setting the language
The language is the first setting displayed. "German" is
the preset language.
1. Turn the rotary selector to set the required language.
2. Touch the next text field to confirm.
The next setting appears.
Setting the time
The time starts at "12:00".
1. Touch the "Clock" text field.
2. Set the time using the rotary selector.
3. Touch the "Complete the settings" text field to
confirm.
A message appears on the display to confirm that the
initial use has been completed.
Cleaning the cooking compartment and
accessories
Before using the appliance to prepare food for the first
time, you must clean the cooking compartment and
accessories.
Cleaning the cooking compartment
To remove the new-appliance smell, heat up the
cooking compartment when empty and with the oven
door closed.
Make sure that there is no leftover packaging, such as
polystyrene pellets, in the cooking compartment and
remove the adhesive tape that is in or on the appliance.
Before heating up the appliance, wipe the smooth
surfaces in the cooking compartment with a soft, wet
cloth. Keep the kitchen ventilated while the appliance is
heating up.
Adjust the settings indicated. You can find out how to
set the heating type and the temperature in the next
section. ~ "Operating the appliance" on page 15
Settings
Heating type 4D hot air <
Temperature maximum
Cooking time 1 hour
Switch off the appliance after the indicated cooking time
using the ÿ On/Off button.
After the cooking compartment has cooled down, clean
the smooth surfaces with soapy water and a dish cloth.
Cleaning the accessories
Clean the accessories thoroughly using soapy water
and a dish cloth or soft brush.
1Operating the appliance
Operat i ng the appl i ance
You have already learnt about the controls and how
they work. Now we will explain how to set your
appliance. You will learn about what happens when you
switch the appliance on and off, and how to select the
operating mode.
Switching the appliance on and off
Before you are able to set the appliance, you must
switch it on.
Note: The childproof lock and the timer can also be set
when the appliance is switched off. Certain displays and
notes, such as those relating to the residual heat in the
cooking compartment, remain visible on the display
after the appliance has been switched off.
Switch off your appliance when you do not need to use
it. If no settings are applied for a long time, the
appliance switches itself off automatically.
15
en Operating the appliance
&
Switching on the appliance
Press the ÿ On/Off button to switch on the appliance.
The Bosch logo appears on the display, followed by the
selection list for the types of heating.
Note: In the basic settings, you can specify which
operating mode should appear after the appliance is
switched on. ~ "Basic settings" on page 21
Switching off the appliance
Press the ÿ On/Off button to switch off the appliance.
Any functions that may be running are cancelled.
The time, or if applicable, the residual heat indicator,
appears on the display.
Note: You can set whether or not the time should be
displayed when the appliance is switched off in the
basic settings. ~ "Basic settings" on page 21
Starting the operation
You must press the l Start/Stop button to start each
operation.
After starting the appliance, the time display is shown
on the display along with the settings. The display ring
and the heating line also appear.
Pausing the operation
You can also interrupt and then continue an operation
using the l Start/Stop button.
If you press and hold the l Start/Stop button for
approx. 3 seconds, the operation is cancelled and all
settings are reset.
Note: The fan may continue to run after an operation
has been paused or cancelled.
Setting the type of heating and temperature
If the "Types of heating" operating mode has not been
selected, touch the "Types of heating" text field in the
menu. The selection list for the types of heating appears
on the touch-screen displays.
Example in the picture: Hot air eco . at 195 °C.
1. Touch the text field with the required type of heating.
If necessary, scroll though the selection list using the
rotary selector.
'KRWDLU
7RS_
ERWWRPKHDWLQJ
+RWDLUHFR
7\SHV
RIKHDWLQJ
6HOHFW
The temperature is highlighted white.
2. Set the temperature using the rotary selector.
7\SHRIKHDWLQJ
+RWDLUHFR
7HPSHUDWXUH
3. Press the l Start/Stop button to start.
7HPSH
UDWXUH
The time on the display shows how long the
operation has already been running.
7RS_ERWWRP
KHDWLQJHFR
+RWDLUJULOOLQJ
*ULOO
ODUJHDUHD
&RRNWLPH
PV
(QG
Selecting an operating mode
Once the appliance is switched on, the default
operating mode is displayed.
If you would like to select a different operating mode,
you can do so using the menu. You can find detailed
descriptions of the individual operating modes in the
corresponding sections.
The following always applies:
1. Touch the appropriate text field.
The function is highlighted.
2. Turn the rotary selector to change the highlighted
selection.
3. If necessary, apply other settings.
To do this, touch the appropriate text field and
change the value using the rotary selector.
4. Press the l Start/Stop button to start.
The appliance starts the operation.
&RRNWLPH
PV
PV
a
&
(QG
The appliance begins to heat up.
When your dish is ready, switch off the appliance using
the ÿ On/Off button.
Note: You can also set the cooking time and an end
time for the operation on the appliance. ~ "Time-
setting options" on page 17
Changing
After starting the appliance, the temperature is
highlighted. When you move the rotary selector, the
temperature is changed and applied immediately.
To change the type of heating, first use the l Start/Stop
button to interrupt the operation and then touch the
"Type of heating" text field. The selection list is
displayed. Touch the required type of heating. The
16
Time-setting options en
corresponding default temperature appears on the
display.
Note: When you change the type of heating, the other
settings are also reset.
Rapid heating
With Rapid heating, you can shorten the heat-up time
for some heating types.
The heating types suitable for Rapid heating are:
■ < 4D hot air
■ % Top/bottom heating
To achieve an even cooking result, do not place your
food or accessories into the cooking compartment until
"Rapid heating" is complete.
Applying settings
Ensure you have selected a suitable type of heating and
set a temperature of at least 100 °C. Otherwise, rapid
heating cannot be activated.
1. Set the type of heating and temperature.
2. Touch the "Rapid heating" text field.
"On" is displayed in the text field. A confirmation
message appears on the display.
When rapid heating comes to an end, an audible signal
sounds and a message appears on the display. "Off" is
displayed in the text field. Place your dish in the
cooking compartment.
An audible signal sounds after a cooking time or timed
period has elapsed. You can cancel the audible signal
early by touching a field or touch-screen display.
Note: You can change how long the audible signal
sounds for in the basic settings. ~ "Basic settings"
on page 21
Setting the cooking time
You can set the cooking time for your dish on the
appliance. This means that the cooking time is not
unintentionally exceeded and you do not need to
interrupt other work in order to end the operation.
Applying settings
Depending on which direction you turn the rotary
selector first, the cooking time starts at a particular
default value: Left = 10 minutes, right = 30 minutes.
The cooking time can be set in one-minute increments
up to one hour, and then in five-minute increments.
The maximum setting is 23 hours and 59 minutes.
Example in the picture: It is 10:00, cooking time of 45
minutes.
1. Set the operating mode, and temperature or level.
2. Before starting the operation, touch the "Cooking
time" text field.
The cooking time is highlighted white in the display.
3. Turn the rotary selector to set the cooking time.
The end time is calculated automatically.
Note: The "Cooking time" time-setting option starts at
the same time as rapid heating. Therefore, only set a
cooking time when rapid heating has come to an end.
Cancelling
To cancel the rapid heating, touch the "Rapid heating"
text field again. "Off" is displayed in the text field.
OTime-setting options
Ti me-set ti ng opt i ons
Your appliance has different time-setting options.
Time-setting option Use
q Cooking time After the set cooking time has elapsed, the
appliance ends the operation automatically.
r End Enter a cooking time and the required end
time. The appliance starts automatically so
that the operation ends at the required time.
t Timer The timer functions like an egg timer. It runs
independently of the operation and the other
time-setting options. After the set time has
elapsed, the appliance does not switch on or
off automatically.
You can call up the cooking time and the end time after
setting an operation using the touch-screen displays.
The timer has a separate field t and can be adjusted at
any time.
7\SHRIKHDWLQJ
+RWDLUHFR
7HPSHUDWXUH
&
4. Press the l Start/Stop button to start.
P
&RRNWLPH
V
&RRNWLPH
(QG
The cooking time counts down.
&RRNWLPH
PV
PV
a
&
(QG
The appliance begins to heat up.
Once the cooking time has elapsed, an audible signal
sounds. The appliance stops heating. The cooking time
00 m 00 s is shown on the display.
You can reset the cooking time using the "Cooking
time" text field or you can press the l Start/Stop button
to continue the operation without a cooking time.
When your dish is ready, switch the appliance off using
the ÿ On/Off button.
17
en Time-setting options
Changing and cancelling
To change the cooking time, touch the "Cooking time"
text field. The cooking time is highlighted, and can be
changed using the rotary selector. The change is
adopted immediately.
If you want to cancel the cooking time, reset the
cooking time to zero. After the change has been
adopted, operating continues without a cooking time.
Setting the end time
You can delay the time that the cooking time ends. You
can, for example, put your dish in the cooking
compartment in the morning and set the cooking time
so that it is ready at lunch time.
Notes
■ Ensure that food is not left in the cooking
compartment for too long as it may spoil.
■ Do not adjust the end time once the operation has
started. The cooking result would no longer be
satisfactory.
Applying settings
The end of the cooking time can be delayed by a
maximum of 23 hours and 59 minutes.
Example in the picture: It is 10:00, the set cooking time
is 45 minutes and the dish should be ready at 12:00.
1. Set the operating mode, and temperature or level.
2. Set the cooking time.
3. Before starting the operation, touch the "End" text
field.
The projected end time is highlighted white in the
display.
4. Set a later end time using the rotary selector.
7\SHRIKHDWLQJ
+RWDLUHFR
7HPSHUDWXUH
&
5. Press the l Start/Stop button to start.
(QG
The time at which the appliance will start is shown in
the display.
&RRNWLPH
PV
6WDUW
(QG
The appliance is in standby mode. When the appliance
starts, the cooking time counts down on the display.
&RRNWLPH
PV
(QG
Once the cooking time has elapsed, an audible signal
sounds. The appliance stops heating. The cooking time
00 m 00 s is shown on the display.
You can reset the cooking time using the "Cooking
time" text field or you can press the l Start/Stop button
to continue the operation without a cooking time.
When your dish is ready, switch the appliance off using
the ÿ On/Off button.
Changing and cancelling
After starting the appliance, the end time can no longer
be changed.
If you want to cancel the cooking time and end time,
interrupt the operation by pressing the l Start/Stop
button. You can continue the operation without a
cooking time or end time.
Setting the timer
The timer runs alongside other settings. You can set it
at any time, even if the appliance is switched off. It has
its own audible signal so that you can tell whether it is
the timer or a cooking time which has elapsed.
Adjusting settings
The timer duration always starts at zero minutes.
The higher the value, the greater the time steps when
setting the timer.
The maximum setting is 24 hours.
1. Touch the t field.
The symbol lights up red. On the display, the timer
duration is shown in white and in focus.
2. Set the timer duration using the rotary selector.
3. Press the t field to start.
Note: After a few seconds, the timer also starts
automatically.
The timer duration counts down.
The timer remains visible on the display if the appliance
is switched off. When an operation is running, the
settings for this operation are shown in the foreground.
When you touch the t field, the timer duration is
displayed for a few seconds.
When the timer duration comes to an end, an audible
signal sounds and a note appears on the display. The
symbol is no longer lit up.
Tip: If the set timer duration relates to the appliance
operation, use the cooking time. The time is visible in
the foreground and the appliance switches off
automatically.
Changing and cancelling
To change the timer duration, touch the t field. The
timer duration is displayed in white and in focus, and
can be changed by using the rotary selector.
If you want to cancel the timer, reset the timer duration
to zero. Once the change has been applied, the symbol
is no longer lit up.
18
Loading...
