30" Induction Cooktop, NIT5060UC, Black Frameless
Features and Benefits
Design
•
4 Induction Cooking Zones
•
PreciseSelect® - Direct Cooking Level Selection (17 Settings)
Efficiency
•
SpeedBoost® - Adds Even More Power to Speed Up the Cooking
Process
•
PotSense - Automatically Recognizes Bottom of Pan on Cooking Element
Convenience
•
Use the Kitchen Timer to Measure Cooking Time or as a Reminder
Safety
•
ChildLock - Prevents the Cooktop from Being Accidentally Switched On,
Locks Temperature Settings if in Use
•
Digital 2-Stage Residual Heat Indicator for Each Cooking Zone
•
Wipe Protection - Quickly Pauses Settings to Clean as You Go
Notes: All height, width and depth dimensions are shown in inches. *Please refer to installation instructions prior to making cutout. BSH reserves the absolute and unrestricted right to
change product materials and specifications, at any time, without notice.Consult the product’s installation instructions for final dimensional data and other details. Applicable product
warranty can be foundin a ccompanying product literature or you may contact your account manager for further details.
For more information on our entire line of products, go to boschappliances.com or call 1-800-944-2904.
Copyright ©2022 BSH Home Appliances Corporation. All rights reserved. Bosch is a registered trademark of Robert Bosch GmbH.
Litho Date: 04/2022
30" Induction Cooktop, NIT5060UC, Black Frameless
Features
Knob Material
Sealed Burners No
Burners with booster All
Type of grate
Total BTU load
LP Gas Connection Rating
Power of heating element (kW in boost) [2.2]
Dimension of 1st heating element (in) 6''
Dimension of 2nd heating element (in)
Power of 3rd heating element (kW in boost) [3.6]
Dimension of 3rd heating element (in) 9''
Power of 4th heating element (kW in boost)
Dimension of 4th heating element (in)
Power of 5th heating element (kW in boost) [3.6]
Dimension of 5th heating element (in) 11''
Power of 6th heating element (kW in boost)
Dimension of 6th heating element (in)
Technical Specification
UPC code 825225961451
Variant color Black
Energy source Electric
Gas type
Alternative gas type
Watts 6240
Fuse protection 30
Volts 208-240
Frequency 60
Approval certificates Dekra Mark C+US, FCC
Power Cord Length 37''
Plug type no plug
Required cutout size (HxWxD) (in) 3 3/4'' x 28 7/8'' x 20''
Minimum distance from counter front (in) 2 1/4''
Minimum distance from rear wall (in) 2''
Overall appliance dimensions (HxWxD) (in) 1/4''+3 3/4'' x
Product packaging dimensions (HxWxD) 7 1/16'' x 36
Net weight 40.000
Gross weight 48.000
Total number of cooktop burners 4
31'' x 21 1/4''
5/8'' x 26 5/8''
