October 1997
View Technical Bulletin
INDUSTRIAL
JIGSAW
1584AVS
Model 0601584651
A
113
82
770
151
39
85
53
150
26
75
71
72
68
154
25
830
57
855
152
77
874
27
29
25
824
102
77
120
20
59
74
23
157
22
20
21
58
A
108
19
129
18
4
17
130
16
42
105/1
109
43
854
15
41
851
802
14
45
106
119
13
813
14
171
107
12
13
133
116
46
105
60
36
44
172
48
49
50
131
137
810
29
32
47
156
155
801
840
134
133
135
35
104
9
34
135
5
38
M
153
6
34
139
7
37
8
133
137133
136
118
134
132
103/6
103
0
15
30
45
2
3
132
104
CORD
861
62
70
63
770
64
79
80
81
65
79
757
658
1
136
S-B Power Tool Company Chicago IL 60646-5999
1584AVS JIGSAW
F/CPos. Part Number Description {Qty} F/CPos. Part Number Description {Qty}
4 1 903 201 042 Needle {2} 66
5 2 600 108 077 Felt Seal 77
6 2 600 500 002 Washer 65
7 2 600 905 021 Ball Bearing 61
8 2 916 669 008 Retaining Ring 89
9 2 600 400 008 Bushing 82
12 2 600 101 616 Washer 65
13 2 600 913 036 Needle Cage {2} 56
14 2 603 201 037 Needle {20} 56
15 2 606 320 048 Eccentric Gear 34
16 2 600 102 653 Shim 1.0mm 65
* 17 2 600 100 515 Shim 0.3mm 65
* 17.1 2 600 100 516 Shim 0.5mm 65
18 2 601 923 004 Fork Lever 62
19 2 916 080 907 Circlip 89
20 2 600 102 652 Shim 0.5mm {2} 65
* 21 2 600 100 625 Shim 0.1mm 65
* 21.1 2 600 100 626 Shim 0.2mm 65
* 21.2 2 600 100 627 Shim 0.3mm 65
22 2 601 098 003 Plate 68
23 2 600 309 009 Bushing 82
* 25 2 600 100 575 Shim 0.2mm 65
* 25.1 2 600 100 576 Shim 0.3mm 65
* 25.2 2 600 100 577 Shim 0.5mm 65
26 2 916 080 010 Circlip 89
27 2 914 551 176 Screw & Washer {2} 89
* 29 2 600 100 568 Shim 0.5mm 65
* 29.1 2 600 100 569 Shim 1.0mm 65
* 29.2 2 600 100 607 Shim 0.3mm 65
32 2 602 305 042 Air Eliminator 9
34 2 600 590 006 Cap/spring {2} 9
35 2 602 026 036 Orbital Lever 63
36 2 916 080 008 Circlip 89
37 2 602 026 037 Air Blower Lever 64
38 2 600 116 006 Circlip 89
39 2 601 015 050 Gasket 79
41 2 603 410 042 Screw {2} 89
42 2 604 613 000 Spring {2} 27
43 2 601 322 010 Bow 43
44 2 600 780 012 Plunger 52
45 2 602 329 011 Clamp 80
46 2 601 321 017 Yoke 57
47 2 603 421 040 Screw {2} 89
48 2 600 112 031 Washer 65
49 2 600 290 017 Felt Washer 77
50 2 600 101 612 Washer 65
53 2 603 490 007 Blade Screw 85
57 2 600 116 011 Circlip 89
58 2 917 530 101 Pin 66
59 2 916 080 006 Circlip 89
60 2 610 323 133 Screw {4} 89
62 2 915 011 007 Nut {2} 89
63 2 608 000 073 Foot Plate 88
64 2 601 030 007 Plate 65
65 2 910 141 197 Screw 89
68 2 605 702 016 Cover 9
70 2 605 730 033 Suction Flange 9
71 2 604 617 003 Spring 80
72 2 914 501 023 Screw & Washer {2} 89
74 2 914 501 012 Screw & Washer {4} 89
75 2 606 491 015 Ratchet 80
77 2 600 100 032 Shim 0.2mm {2} 65
+ 78 2 610 907 132 Label "clic directions" 9
+ = Not Illustrated * = As Required F/C = Failure Code AW = Refer to AW Labor Time Chart
79 2 601 099 013 Cover 9
80 2 601 099 029 Plastic Base 88
81 2 910 001 116 Screw {6} 89
82 2 601 320 022 Cover 92
85 2 604 610 040 Spring 27
102 2 610 909 245 Field 120V 22
103 2 610 909 242 Armature w/Fan 120V AW
103/6 2 610 909 244 Fan 23
104 2 607 200 093 Switch On/Off 15
105 3 604 460 555 Cord 120V 18/2 11
105/1 1 900 452 012 Terminal {2} 10
106 2 600 703 028 Strain Relief 11
107 2 601 035 001 Cord Clamp 89
108 2 610 994 118 Nameplate 9
109 2 610 994 117 Label "1584AVS" 9
113 1 900 905 018 Ball Bearing 60
116 2 601 323 021 Brush Holder {2} 25
118 2 603 410 001 Screw {4} 89
119 2 610 315 386 Screw {2} 89
120 2 610 906 855 Label "Caution" 9
129 2 910 601 321 Screw 89
130 2 602 026 015 Switch Button 9
131 1 907 950 006 Allen Wrench 5mm 9
132 2 607 230 011 Switch VS 17
133 2 604 448 034 Cable 88mm {2} 10
134 2 604 448 044 Cable 86mm 10
135 2 604 448 045 Cable 100mm 10
136 2 604 448 046 Cable 128mm 10
137 2 604 448 040 Cable 125mm 10
139 2 910 611 006 Screw 89
* 150 2 600 101 023 Shim 0.3mm 65
* 150.1 2 600 101 022 Shim 0.2mm 65
151 2 600 150 004 Spring Washer 65
152 2 603 435 015 Screw {2} 89
153 2 602 319 005 Switch Slide 15
154 2 601 328 045 Air Deflector 24
155 2 910 611 005 Screw {4} 89
156 1 604 652 014 Brush Spring {2} 27
157 2 605 500 074 Motor Housing Cover 9
171 2 600 301 046 Bushing 82
172 2 600 301 045 Bushing 82
+ 656 2 600 306 005 Vacuum Tube 9
658 2 910 771 118 Screw {6} 89
757 2 607 001 085 Metal Base w/pos. 658 88
770 2 610 994 544 Dust Collection Kit 9
w/pos. 70, 79, 82, 656
801 2 605 808 917 Gear Housing 72
802 2 605 108 904 Motor Housing Assembly 71
w/pos. 116, 155, 156
810 2 604 320 910 Brush Set 26
813 2 607 001 130 Needle Bearing Assembly 56
w/pos. 13, 14
824 2 601 072 901 Eccentric 53
830 2 600 917 900 Needle Bearing Assembly 56
840 2 605 808 921 Gear Cover Assembly 70
w/pos.
851 2 601 015 901 Gasket Assembly 77
854 2 601 321 902 Roller Guide Assembly 87
w/pos. 58, 851, 855
855 2 600 326 903 Roller Assembly 87
w/pos. 57, 59, 77
861 2 605 500 900 Cover w/pos. 62 9
874 2 602 026 900 "Clic" Handle Assembly 74
4, 41-50, 171, 172, 854
