15SBi & 24SBi SYSTEM BOILERS

TWIN CHANNEL DIGITAL

PROGRAMMER INSTALLATION &

OPERATING INSTRUCTIONS

General information is given in the users instruction leaflet despatched with the
appliance and/or on the lighting instruction plate fitted to the appliance.

THESE INSTRUCTIONS APPLY IN THE UK ONLY THESE INSTRUCTIONS

ARE TO BE LEFT WITH THE USER OR AT THE APPLIANCE

M T W Th F S Su

P

DAY HR MIN ADV

Reset

I AUTO O

RUN DHW C H

Set

8:37

1

Gas Safety (Installation and Use) Regulations 1998: All gas appliances must be installed
by a competent person, in accordance with the above regulations. Failure to install the
appliance correctly could lead to prosecution. The manufacturers notes must not be
taken, in any way, as overriding statutory obligations.
IMPORTANT: Read these instructions carefully in order to get the best from your appliance.
WA R N I N G : This appliance must be earthed and protected by a 3A fuse if a 13A plug is used,

or, if any other type of plug is used, by a 5A fuse either in the plug or adaptor or at the
distribution board.

5 day/2 day (simple setting) or multiday (full function setting) twin channel digital programmer.
The HW and CH channels can be set independently.

Integral lithium battery provides 5 year back up in case of mains failure.

Before starting work, turn off the mains electricity supply to the appliance.
Remove the front panel from the appliance by sliding it upwards to clear the locating pegs and
securing clips.
Remove the three screws securing the bottom panel to the fascia.
Remove the two screws securing the fascia assembly to the appliance and lower it forwards to
the servicing position.
Remove the programmer blanking plate from the front of the fascia by carefully releasing the
clips at the rear right-hand side and withdrawing the plate from the front.
Feed the electrical lead from the programmer through the fascia to exit directly underneath it
and fit the programmer by hooking the top two lugs up into the facia slots and then push the
bottom two clips until they snap into position.
From the rear of the fascia, remove the plastic splash cover to reveal the electrical connection
box and remove the two screws securing the cover to the box.
Secure the cable from the programmer using the clamping positions on the underside of the
fascia and the rear of the electrical connection box and plug the cable into the corresponding
five-way socket on the rear of the fascia.

Replace the electrical box cover, splash cover and fascia bottom panel, and secure the fascia
using the two screws and refit the front panel.

PROGRAMMER

TO FIT THE PROGRAMMER

Clamp cable here

Connect plug from
timeswitch here

Fig. 1.
