Bosch Power Tools 11536C, 11536C-1, 11536C-2 User Manual
BM 1619929800 01-08 1/8/08 9:39 AM Page 1
IMPORTANT: IMPORTANT : IMPORTANTE:
Read Before Using Lire avant usage Leer antes de usar
Operating/Safety Instructions
Consignes de fonctionnement/sécurité
Instrucciones de funcionamiento y seguridad
11536C
Call Toll Free for
Consumer Information
& Service Locations
1-877-BOSCH99 (1-877-267-2499) www.boschtools.com
Pour obtenir des informations
et les adresses de nos centres
de service après-vente,
appelez ce numéro gratuit
Llame gratis para
obtener información
para el consumidor y
ubicaciones de servicio
For English Version Version française Versión en español
See page 2 Voir page 16 Ver la página 30
BM 1619929800 01-08 1/8/08 9:39 AM Page 2
General Safety Rules
WARNING
!
of the warnings listed below refers to your mains-operated (corded) power tool or battery-operated
(cordless) power tool.
Read all instructions. Failure to follow all instructions listed below may
result in electric shock, fire and/or serious injury.
The term “power tool” in all
SAVE THESE INSTRUCTIONS
Work area safety
Keep work area clean and well lit. Cluttered
or dark areas invite accidents.
Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust.
tools create sparks which may ignite the dust
or fumes.
Keep children and bystanders away while
operating a power tool.
cause you to lose control.
Distractions can
Power
Electrical safety
Power tool plugs must match the outlet.
Never modify the plug in any way. Do not
use any adapter plugs with earthed
(grounded) power tools.
and matching outlets will reduce risk of electric
shock.
Avoid body contact with earthed or
grounded surfaces such as pipes,
radiators, ranges and refrigerators.
an increased risk of electric shock if your body
is earthed or grounded.
Do not expose power tools to rain or wet
conditions.
increase the risk of electric shock.
Do not abuse the cord. Never use the cord
for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil,
sharp edges or moving parts.
entangled cords increase the risk of electric
shock.
When operating a power tool outdoors, use
an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces
the risk of electric shock.
Do not use AC only rated tools with a DC
power supply.
work, the electrical components of the AC
rated tool are likely to fail and create a hazard
to the operator.
If operating the power tool in damp
locations is unavoidable a Ground Fault
Water entering a power tool will
While the tool may appear to
Unmodified plugs
There is
Damaged or
Circuit Interrupter (GFCI) must be used to
supply the power to your tool.
personal protection devices like electrician’s
rubber gloves and footwear will further
enhance your personal safety.
GFCI and
Personal safety
Stay alert, watch what you are doing and
use common sense when operating a
power tool. Do not use a power tool while
you are tired or under the influence of
drugs, alcohol or medication.
inattention while operating power tools may
result in serious personal injury.
Use safety equipment. Always wear eye
protection.
mask, non-skid safety shoes, hard hat, or
hearing protection used for appropriate
conditions will reduce personal injuries.
Avoid accidental starting. Ensure the
switch is in the off-position before plugging
in.
Carrying power tools with your finger on the
switch or plugging in power tools that have the
switch on invites accidents.
Remove any adjusting key or wrench
before turning the power tool on.
or a key left attached to a rotating part of the
power tool may result in personal injury.
Do not overreach. Keep proper footing and
balance at all times.
control of the power tool in unexpected
situations.
Dress properly. Do not wear loose clothing
or jewelry. Keep your hair, clothing and
gloves away from moving parts.
clothes, jewelry or long hair can be caught in
moving parts.
If devices are provided for the connection
of dust extraction and collection facilities,
ensure these are connected and properly
used.
related hazards.
Keep handles dry, clean and free from oil
and grease.
control the power tool.
Safety equipment such as dust
Use of these devices can reduce dust-
Slippery hands cannot safely
A moment of
A wrench
This enables better
Loose
-2-
BM 1619929800 01-08 1/8/08 9:39 AM Page 3
Power tool use and care
Do not force the power tool. Use the correct
power tool for your application.
power tool will do the job better and safer at
the rate for which it was designed.
Do not use the power tool if the switch
does not turn it on and off.
that cannot be controlled with the switch is
dangerous and must be repaired.
Disconnect the plug from the power source
and/or the battery pack from the power tool
before making any adjustments, changing
accessories, or storing power tools.
preventive safety measures reduce the risk of
starting the power tool accidentally.
Store idle power tools out of the reach of
children and do not allow persons
unfamiliar with the power tool or these
instructions to operate the power tool.
Power tools are dangerous in the hands of
untrained users.
Maintain power tools. Check for
misalignment or binding of moving parts,
breakage of parts and any other condition
that may affect the power tools operation. If
damaged, have the power tool repaired
before use.
poorly maintained power tools.
Keep cutting tools sharp and clean.
Properly maintained cutting tools with sharp
cutting edges are less likely to bind and are
easier to control.
Use the power tool, accessories and tool
bits etc., in accordance with these
instructions and in the manner intended for
the particular type of power tool, taking into
account the working conditions and the
work to be performed.
for operations different from those intended
could result in a hazardous situation.
Use clamps or other practical way to
secure and support the workpiece to a
stable platform.
Many accidents are caused by
Use of the power tool
Holding the work by hand or
The correct
Any power tool
Such
against your body is unstable and may lead to
loss of control.
Battery tool use and care
Ensure the switch is in the off position
before inserting battery pack.
battery pack into power tools that have the
switch on invites accidents.
Recharge only with the charger specified
by the manufacturer.
suitable for one type of battery pack may
create a risk of fire when used with another
battery pack.
Use power tools only with specifically
designated battery packs.
battery packs may create a risk of injury and
fire.
When battery pack is not in use, keep it
away from other metal objects like paper
clips, coins, keys, nails, screws, or other
small metal objects that can make a
connection from one terminal to another.
Shorting the battery terminals together may
cause burns or a fire.
Under abusive conditions, liquid may be
ejected from the battery, avoid contact. If
contact accidentally occurs, flush with
water. If liquid contacts eyes, additionally
seek medical help.
battery may cause irritation or burns.
Liquid ejected from the
Inserting the
A charger that is
Use of any other
Service
Have your power tool serviced by a
qualified repair person using only identical
replacement parts.
safety of the power tool is maintained.
Develop a periodic maintenance schedule
for your tool. When cleaning a tool be
careful not to disassemble any portion of
the tool since internal wires may be
misplaced or pinched or safety guard
return springs may be improperly mounted.
Certain cleaning agents such as gasoline,
carbon tetrachloride, ammonia, etc. may
damage plastic parts.
This will ensure that the
SAVE THESE INSTRUCTIONS
-3-
BM 1619929800 01-08 1/8/08 9:39 AM Page 4
Safety Rules for Cordless Hammer Drills
H
old power tools by insulated gripping
surfaces when performing an operation
where the cutting tools may contact hidden
wiring.
exposed metal parts of the tool “live” and
shock the operator.
Use clamps or other practical way to
secure and support the workpiece to a
stable platform.
against your body is unstable and may lead to
loss of control.
Do not drill, fasten or break into existing
walls or other blind areas where electrical
wiring may exist.
unavoidable, disconnect all fuses or circuit
breakers feeding this worksite.
Wear ear protectors when using the tool for
extended periods.
high intensity noise can cause hearing loss.
Always use auxiliary handle for maximum
control over torque reaction or kick-back.
High torque 3/8" and larger chuck capacity
drills are equipped with auxiliary handles.
Always wear safety goggles or eye
protection when using this tool. Use a dust
mask or respirator for applications which
generate dust.
Use thick cushioned gloves and limit the
exposure time by taking frequent rest
periods.
action may be harmful to your hands and
arms.
Secure the material being drilled. Never
hold it in your hand or across legs.
Unstable support can cause the drill bit to bind
causing loss of control and injury.
Disconnect battery pack from tool before
making any assembly, adjustments or
changing accessories
safety measures reduce the risk of starting the
tool accidentally.
Position yourself to avoid being caught
between the tool or side handle and walls
or posts.
jammed in the work, the reaction torque of the
tool could crush your hand or leg.
If the bit becomes bound in the workpiece,
release the trigger immediately, reverse the
Contact with a “live” wire will make
Holding the work by hand or
If this situation is
Prolonged exposure to
Vibration caused by hammer-drill
. Such preventive
Should the bit become bound or
d
irection of rotation and slowly squeeze
the trigger to back out the bit.
a strong reaction torque. The drill body will
tend to twist in the opposite direction as the
drill bit is rotating.
Do not grasp the tool or place your hands
too close to the spinning chuck or drill bit.
Your hand may be lacerated.
When installing a drill bit, insert the shank
of the bit well within the jaws of the chuck.
If the bit is not inserted deep enough, the grip
of the jaws over the bit is reduced and the loss
of control is increased.
Do not use dull or damaged bits and
accessories.
greater tendency to bind in the workpiece.
When removing the bit from the tool avoid
contact with skin and use proper protective
gloves when grasping the bit or accessory.
Accessories may be hot after prolonged use.
Check to see that keys and adjusting
wrenches are removed from the drill before
switching the tool "ON".
can fly away at high velocity striking you or a
bystander.
Do not run the tool while carrying it at your
side.
entangled with clothing and injury may result.
!
drilling, and other construction activities
contains chemicals known to cause cancer,
birth defects or other reproductive harm.
Some examples of these chemicals are:
• Lead from lead-based paints,
• Crystalline silica from bricks and cement and
other masonry products, and
• Arsenic and chromium from chemicallytreated lumber.
Your risk from these exposures varies,
depending on how often you do this type of
work. To reduce your exposure to these
chemicals: work in a well ventilated area, and
work with approved safety equipment, such as
those dust masks that are specially designed
to filter out microscopic particles.
Be ready for
Dull or damaged bits have a
Keys or wrenches
A spinning drill bit could become
WARNING
Some dust created by power
sanding, sawing, grinding,
-4-
BM 1619929800 01-08 1/8/08 9:39 AM Page 5
Battery/Charger
Before using battery charger, read all
instructions and cautionary markings on
(1) battery charger, (2) battery pack, and (3)
product using battery.
Use only the charger which accompanied
your product or direct replacement as
listed in the catalog or this manual.
substitute any other charger. Use only Bosch
approved chargers with your product. See
Functional Description and Specifications.
Do not disassemble charger or operate the
charger if it has received a sharp blow,
been dropped or otherwise damaged in any
way. Replace damaged cord or plugs
immediately.
may result in electric shock or fire.
Do not recharge battery in damp or wet
environment. Do not expose charger to rain
or snow. If battery case is cracked or
otherwise damaged, do not insert into
charger.
Charge only Bosch approved rechargeable
batteries.
Specifications. Other types of batteries may
burst causing personal injury and damage.
Charge battery pack in temperatures above
+32 degrees F (0 degrees C) and below
Incorrect reassembly or damage
Battery short or fire may result.
See Functional Description and
Do not
+113 degrees F (45 degrees C). Store tool
and battery pack in locations where
temperatures will not exceed 120 degrees F
(49 degrees C).
s
erious damage to the battery cells.
Battery leakage may occur under extreme
usage or temperature conditions. Avoid
contact with skin and eyes.
liquid is caustic and could cause chemical
burns to tissues. If liquid comes in contact with
skin, wash quickly with soap and water. If the
liquid contacts your eyes, flush them with water
for a minimum of 10 minutes and seek medical
attention.
Place charger on flat non-flammable
surfaces and away from flammable
materials when re-charging battery pack.
The charger and battery pack heat during
charging. Carpeting and other heat insulating
surfaces block proper air circulation which may
cause overheating of the charger and battery
pack. If smoke or melting of the case are
observed unplug the charger immediately and
do not use the battery pack or charger.
Use of an attachment not recommended or sold by Bosch will result in a
risk of fire, electric shock or injury to
persons.
This is important to prevent
The battery
Battery Care
WARNING
!
away from metal objects.
protect terminals from shorting
place batteries in a tool box or pocket with
When batteries are not in
tool or charger, keep them
For example, to
DO NOT
nails, screws, keys, etc. Fire or injury may
result.
DO NOT PUT BATTERIES INTO FIRE OR
EXPOSE TO HIGH HEAT.
explode.
-5-
They may
BM 1619929800 01-08 1/8/08 9:39 AM Page 6
Battery Disposal
WARNING
!
remove any component projecting from the
battery terminals.
Prior to disposal, protect exposed terminals
with heavy insulating tape to prevent shorting.
If equipped with a lithium-ion battery, the
battery must be collected, recycled or disposed
of in an environmentally sound manner.
Do not attempt to disassemble the battery or
Fire or injury may result.
LITHIUM-ION BATTERIES
“The EPA certified RBRC
Battery Recycling Seal on the
lithium-ion (Li-ion) battery
indicates Robert Bosch Tool
Corporation is voluntarily
participating in an industry
program to collect and recycle these batteries
at the end of their useful life, when taken out
of service in the United States or Canada. The
RBRC program provides a convenient
alterative to placing used Li-ion batteries into
the trash or the municipal waste stream, which
may be illegal in your area.
Please call 1-800-8-BATTERY for information
on Li-ion battery recycling and disposal
bans/restrictions in your area, or return your
batteries to a Skil/Bosch/Dremel Service
Center for recycling. Robert Bosch Tool
Corporation’s involvement in this program is
part of our commitment to preserving our
environment and conserving our natural
resources.”
-6-
0
BM 1619929800 01-08 1/8/08 9:39 AM Page 7
Symbols
IMPORTANT: Some of the following symbols may be used on your tool. Please study them
and learn their meaning. Proper interpretation of these symbols will allow you to operate the
tool better and safer.
Symbol Name Designation/Explanation
V Volts Voltage (potential)
A Amperes Current
Hz Hertz Frequency (cycles per second)
W Watt Power
kg Kilograms Weight
min Minutes Time
s Seconds Time
Diameter Size of drill bits, grinding wheels, etc.
n
0
.../min Revolutions or reciprocation per minute Revolutions, strokes, surface speed,
0 Off position Zero speed, zero torque...
1, 2, 3, ... Selector settings Speed, torque or position settings.
I, II, III, Higher number means greater speed
No load speed Rotational speed, at no load
orbits etc. per minute
Infinitely variable selector with off Speed is increasing from 0 setting
Arrow Action in the direction of arrow
Alternating current Type or a characteristic of current
Direct current Type or a characteristic of current
Alternating or direct current Type or a characteristic of current
Class II construction Designates Double Insulated
Construction tools.
Earthing terminal
Grounding terminal
Warning symbol Alerts user to warning messages
Li-ion RBRC seal Designates Li-ion battery recycling
program
This symbol designates
that this tool is listed by
Underwriters Laboratories.
This symbol designates
that this tool is listed to
Canadian Standards by
Underwriters Laboratories.
This symbol
designates
that
this tool
complies
to NOM
Mexican
Standards.
This symbol designates
that this tool is listed by
the Canadian Standards
Association.
This symbol designates that
this tool is listed by
Underwriters Laboratories,
and listed to Canadian
Standards by Underwriters
Laboratories.
-7-
BM 1619929800 01-08 1/8/08 9:39 AM Page 8
Functional Description and Specifications
WARNING
!
accessories.
HANDLE / HAMMER MECHANISM
DEPTH GAUGE
RELEASE LEVER
LOCKING
SLEEVE
DUST
SHIELD
DEPTH
GAUGE
Disconnect battery pack from tool or place the switch in the locked or off
position before making any assembly, adjustments or changing
Such preventive safety measures reduce the risk of starting the tool accidentally.
VIBRATION DAMPER
Cordless Hammer Drill
FIG. 1
VENTILATION OPENINGS
FORWARD/REVERSING
LEVER
& TRIGGER LOCK
VARIABLE
SPEED
CONTROLLED
TRIGGER
SWITCH
DRILL/HAMMER DRILL
SELECTION DIAL
WING KNOB
AUXILIARY
HANDLE
BATTERY PACK
BUTTON
BATTERY CHARGED
CONDITION INDICATOR
Model Number 11536C
Voltage rating
Shank style
36 V
SDS-plus
Maximum Capacities:
Material
Concrete 3/4"
"
Steel
1/2
Wood 1-1/4"
BATTERY PACK
RELEASE BUTTON
TEMPERATURE
INDICATOR LIGHT
Charger BC830
®
Voltage rating 120 V 60 Hz
Battery pack BAT810 thru BAT840
Charge time 1 hour
(80% charged in 30 minutes)
NOTE: For tool specifications refer to the
nameplate on your tool.
-8-
BM 1619929800 01-08 1/8/08 9:39 AM Page 9
Assembly
!
WARNING
switch in the locked or off position before
making any assembly, adjustments or
changing accessories.
safety measures reduce the risk of starting the
tool accidentally.
INSTALLING SDS-plus®ACCESSORIES
Clean the insert shank end of the accessory to
remove any debris, then lightly grease with a
light oil or lubricant
Insert accessory into the chuck through the
dust shield, while twisting and pushing inward
until it locks automatically into place. Pull
outward on the accessory to be certain it is
locked into the chuck (Fig. 2).
FIG. 2
DUST
SHIELD
Disconnect battery pack
from tool or place the
Such preventive
®
SDS-plus
CHUCK
NOTE: The high efficiency available from the
rotary hammers can only be obtained if sharp
and undamaged accessories are used. The
"cost" to maintain sharp and undamaged
accessories is more than offset by the "time
saved" in operating the tool with sharp
accessories.
REMOVING SDS-plus®ACCESSORIES
!
WARNING
and use proper protective gloves or cloth to
remove.
To remove an accessory, pull locking sleeve
backward and pull bit forward. All accessories
should be wiped clean after removing (Fig. 3).
Accessories may be hot after
use. Avoid contact with skin
FIG. 3
LOCKING
SLEEVE
!
WARNING
switch in the locked or off position before
making any assembly, adjustments or
changing accessories.
safety measures reduce the risk of starting the
tool accidentally.
INSTALLING & REMOVING 3-JAW CHUCK
(Not included, available as accessory)
The 3 Jaw Chuck with SDS Shank can convert
your tool for use with straight shank bits (Fig. 4).
Disconnect battery pack
from tool or place the
Such preventive
FIG. 4
Clean the insert shank end of the accessory to
remove any debris, then lightly grease with a
light oil or lubricant
Insert accessory into the chuck through the
dust shield, while twisting and pushing inward
until it locks automatically into place. Pull
outward on the accessory to be certain it is
locked into the chuck (Fig. 5).
To remove the chuck, pull the locking sleeve
backward (towards the rear of tool), while
pulling the chuck forward.
FIG. 5
3-JAW CHUCK
(Not included, available
as accessory)
-9-
LOCKING
SLEEVE
BM 1619929800 01-08 1/8/08 9:39 AM Page 10
INSTALLING & REMOVING ACCESSORIES
3-JAW CHUCK
For small bits, open jaws enough to insert the
bit up to the flutes. For large bits, insert the bit
as far as it will go. Center the bit as you close
the jaws by hand. This positions the bit
properly, giving maximum contact between the
c
huck jaws and the bit shank (Fig. 6).
To tighten chuck, insert key into each of the
three key holes in succession and tighten
clockwise firmly.
The chuck can be released by using one hole only.
Note: The 3-Jaw Chuck is for use only in “Drill
only” mode. The 3-Jaw Chuck is not for use
when drilling with hammering action.
AUXILIARY HANDLE
The auxiliary handle will provide additional
control, support and guidance for the tool. The
handle is adjustable around the 360° handle
collar mount.
To mount, loosen wing knob and slide handle
completely over chuck onto the collar mount
and tighten wing knob (Fig. 7).
FIG. 6
FIG. 7
WING KNOB
Your drilling depth can be pre-set and/or
DEPTH GAUGE
repeated by using the depth gauge.
Setting depth: After the auxiliary handle is
installed, make sure the accessory has been
fully inserted into the tool holder before setting
the depth gauge (Fig. 8).
To adjust depth, push down on the depth
gauge release lever, slide the depth gauge to
desired depth and release pressure on lever to
lock the depth gauge in place (Fig. 8).
AUXILIARY
HANDLE
FIG. 8
DEPTH GAUGE
RELEASE LEVER
DEPTH GAUGE
-10-
BM 1619929800 01-08 1/8/08 9:39 AM Page 11
Operating Instructions
V
ARIABLE SPEED CONTROLLED
Your tool is equipped with a variable speed
trigger switch. The tool can be turned "ON" or
"OFF" by squeezing or releasing the trigger.
The speed can be adjusted from the minimum
to maximum nameplate RPM by the pressure
you apply to the trigger. Apply more pressure
to increase the speed and release pressure to
decrease speed Fig. 1).
WARNING
!
of the tool if the variable speed control ceases
to function. Subsequent loss of on/off control
of the trigger switch is likely.
Your tool is equipped with a forward/
reversing lever and trigger lock located above
the trigger (Fig. 9). This lever was designed for
changing rotation of the chuck, and for locking
the trigger in an “OFF” position to help prevent
accidental starts and accidental battery
discharge.
The selector dial allows the tool to be set for
various drilling/hammer drilling applications.
Rotate the selector dial right or left
depending on the below applications (Fig. 1).
CAUTION
!
come to a complete stop.
rotation of the chuck can cause damage to
the tool.
Do not use demolition or chipping bits such
as bull points, chisels, spades, gouges, etc.
TRIGGER SWITCH
To reduce the risk of injury
immediately discontinue use
FORWARD/REVERSING LEVER &
TRIGGER LOCK
DRILL/HAMMER DRILL SELECTION DIAL
Do not operate the
selection dial until the tool
Shifting during
F
or forward rotation, (with chuck pointed away
from you) move the lever to the far left. For
reverse rotation move the lever to the far right.
To activate trigger lock move lever to the
center off position.
CAUTION
!
a complete stop. Shifting during rotation of the
chuck can cause damage to the tool.
Do not change direction of
rotation until the tool comes to
FIG. 9
FORWARD/REVERSING LEVER
& TRIGGER LOCK
Drill only action: For drilling in
woods, metals, plastics or other
non concrete materials.
Drill with hammer action: For
drilling in concrete, asphalt, tile or
other similar hard materials.
The tool has a internal pre-set slip clutch. The
SLIP CLUTCH
output spindle will stop rotating if the
accessory binds and overloads the tool.
BRAKE
When the trigger is released it activates the
electrical brake to stop the chuck quickly. This
is especially useful in the repetitive driving and
removal of screws.
VIBRATION DAMPER HANDLE /
HAMMER MECHANISM
The integrated vibration damper in the main
handle and hammer mechanism reduces
vibrations (Fig. 1).
-11-
BM 1619929800 01-08 1/8/08 9:39 AM Page 12
BATTERY CHARGED CONDITION
INDICATOR
The battery is equipped with a charged
condition indicator (Fig. 10).
BUTTON
GREEN
INDICATOR LIGHTS
INDICATOR LIGHT
FIG. 10
RED
By pressing the button ON, the charged
condition can be checked when the battery is
removed or when the machine is not in use.
After approx. 5 seconds, the charged indicator
switches off automatically.
• • • When all three lights are illuminated, this
indicates the battery pack is between 67% and
100% charged.
• • When only two lights illuminate, this
indicates the battery pack is between 33% and
66% charged.
INSERTING AND RELEASING BATTERY PACK
Set Forward/Reversing lever to the center (off
position). Slide charged battery pack into the
housing until the battery pack locks into
position and the red warning label is no longer
visible (Fig. 1).
Your battery pack is equipped with a
secondary locking latch to prevent the battery
pack from completely falling out of the handle,
should it become loose due to vibration.
To remove the battery pack, press the battery
pack release button and slide the battery pack
forward. The red warning label will become
• When only one light illuminates, this
indicates the battery pack is less than 33%
charged.
When one light blinks the battery pack is
almost fully discharged.
TEMPERATURE INDICATOR LIGHT
The red indicator light signals whether the
battery or tool (with battery inserted) is in the
optimum temperature range. When the
temperature is too high, the tool will not operate
at full capacity.
If the red indicator light illuminates continuously
when the battery is inserted into the charger.
The battery is outside the charging temperature
range and cannot be charged.
If the red indicator light blinks when the button
or on/off switch (with battery inserted) is
pressed, the battery is outside the operating
range of -10 ˚C to +60 ˚C.
When the temperature is above 70 ˚C the
battery turns off until it’s in the optimum
temperature range.
partially visible. Press the battery pack release
button again and slide the battery pack
completely out of tool housing (Fig. 11).
FIG. 11
CHARGER INDICATORS, SYMBOLS AND MEANING
If the indicator lights are “OFF”, the charger is
not receiving power from power supply outlet.
If the green indicator light is
“ON”, the charger is plugged in
but the battery pack is not
inserted, or the battery pack is fully charged.
If the green indicator light is
“BLINKING”, the battery pack is
being fast-charged. Fastcharging will automatically stop when the
battery pack is fully charged.
-12-
BM 1619929800 01-08 1/8/08 9:39 AM Page 13
If the red indicator light is “ON”,
the battery pack is too hot or cold
for fast-charging. The charger
will automatically switch to fast-charging once
a suitable temperature is reached.
CHARGING BATTERY PACK (BC830 1 HOUR CHARGER)
Plug charger cord into your standard power
outlet, then insert battery pack into charger
(Fig. 12).
The charger’s green indicator light will begin to
“BLINK”. This indicates that the battery is
receiving a fast charge. Fast-charging will
automatically stop when the battery pack is
fully charged.
When the unit beeps and the indicator light
stops “BLINKING” (and becomes a steady
green light) fast charging is complete.
The battery pack may be used even though
the light may still be blinking. The light may
require more time to stop blinking depending
on temperature. When you begin the charging
process of the battery pack, a steady red light
If the red indicator light is
“BLINKING”, the battery pack
cannot accept a charge or the
contacts of the charger or battery pack are
contaminated. Clean the contacts of the
charger or battery pack only as directed in
these operating instructions or those supplied
with your tool or battery pack.
could also mean the battery pack is too hot or
too cold.
The purpose of the green light is to indicate
that the battery pack is fast-charging. It does
not indicate the exact point of full charge. The
light will stop blinking in less time if the battery
pack was not completely discharged.
When needed, the internal fan of the charger
will turn on to aid the charging process and
speed.
When charging several batteries in sequence,
the charge time may slightly increase.
When the battery pack is fully charged, unplug
the charger (unless you're charging another
battery pack) and slip the battery pack back
into the tool.
FIG. 12
BATTERY PACK
RED LIGHT
CHARGER
GREEN LIGHT
-13-
BM 1619929800 01-08 1/8/08 9:39 AM Page 14
IMPORTANT CHARGING NOTES
1. The charger was designed to fast charge
the battery only when the battery temperature
is between 32˚F (0˚C) and 113˚F (45˚C). If the
b
attery pack is too hot or too cold, the charger
w
ill not fast charge the battery. (This may
happen if the battery pack is hot from heavy
use). When the battery temperature returns to
between 32˚F (0˚C) and 113˚F (45˚C), the
charger will automatically begin charging.
2. A substantial drop in operating time per
charge may mean that the battery pack is
nearing the end of its life and should be
replaced.
3. Remember to unplug charger during storage
period.
4. If battery does not charge properly:
a. Check for voltage at outlet by plugging in
some other electrical device.
b
light switch which turns power “off” when lights
are turned off.
c. Check battery pack terminals for dirt.
Clean with cotton swab and alcohol if
necessary.
d. If you still do not get proper charging,
take or send tool, battery pack and charger to
your local Bosch Service Center. See “Tools,
Electric” in the Yellow Pages for names and
addresses.
Note: Use of chargers or battery packs not
sold by Bosch will void the warranty.
. Check to see if outlet is connected to a
Following a few simple tips will reduce wear
TOOL TIPS
on the tool and the chance of injury to the
operator.
NOTE: The high efficiency available from the
rotary hammers can only be obtained if sharp
and undamaged accessories are used. The
“cost” to maintain sharp and undamaged
accessories is more than offset by the “time
saved” in operating the tool with sharp
accessories.
You will extend the life of your bits and do
neater work if you always put the bit in contact
with the workpiece BEFORE pulling the trigger.
During operation, hold the drill firmly and exert
moderate, steady pressure. Too much
pressure at low speed will stall the hammer.
Too little pressure will keep the bit from cutting
and cause excess friction by sliding over the
surface. This can be damaging to the drill and
bit.
Shanks of all drill bits should be wiped clean
prior to using and immediately after removing.
Recall these instructions for safe operation:
1. Some materials require slow drilling
speeds; whereas, others require higher speed
to produce the best results.
2. All work must be supported or secured
before drilling and steady, even pressure
applied in line with the drill bit.
3. As the drill bit cuts through the opposite
side, reduce the pressure and continue
running the drill as the bit is withdrawn.
Materials such as glass, porcelain, ceramics,
tiles, plastics, etc., should be drilled at low
speeds with specially designed drill bits and
lubricants.
DRILLING WOOD OR PLASTIC
If backing block is not used, ease up on the
pressure just before the bit breaks through the
wood to avoid splintering. Complete the hole
from the opposite side immediately after the
point breaks through. If bit binds, reverse the
drilling operation to help remove the bit from
the work.
DRILLING METAL
Make a center punch in the material for easier
starting. Use enough pressure to keep the bit
cutting. If the bit is allowed to merely spin in the
hole, it will become dull within a short time.
When drilling a larger hole, it is faster and
easier on your power pack to first make a
smaller hole and enlarge it to the required size.
Lubricate the tip of the bit occasionally with
CUTTING OIL for easier metal drilling. If bit
binds, reverse the drilling to help remove the
bit from the work.
DRILLING MASONRY
Use carbide-tipped masonry bit for cinder
block, mortar, common brick, soft stone and
other materials. The amount of pressure to
be used is dependent upon the type of
material being drilled. Soft materials require
less pressure while the hard materials need
more pressure to prevent the drill bit from
spinning.
-14-
Loading...
