H a m m e r

& H a m m e r D r i l l

Too l s & A c c e s s o r i e s

Introducing the Bosch 35 lb. “Best in Class” Breaker Hammer

11335K

Jack 35 lb. Breaker Hammer

Section Guide

Tools

Hammer Drills ...............................................32-33

Rotary Hammers ............................................33-37

Combination Hammers .................................. 37-38

Demolition/Breaker Hammers ....................... 39-42

Accessories

Hammer Attachments ......................................... 43

Hammer Drill Bits ............................................... 44

SDS-plus® Accessories ..................................44-47

SDS-max® Accessories ..................................47-52

Boschtools.com

Toll Free: 877-BOSCH-99

Hammer Quick Reference Guide

Item #

Drive System

Hammer Classification

Amperage 7 8 8.5 4.8

Impact Energy (ft.-lbs.)

Max. Concrete Capacity

Optimal Range 1/8" - 5/16" 1/8" - 3/8" 1/8" - 3/8" 1/8" - 5/16" 5/32" - 5/8" 3/16" - 5/8" 3/16" - 5/8"

Core Bits N/A N/A N/A N/A 1-1/2" 2-1/2" 2-1/2"

No Load RPM 0-3,000

No Load BPM 0-48,000

Modes of Operation

Length 11" 16" 13.25" 11.9" 13.25" 16.5" 14.8"

Weight 4.1 lbs. 5.3 lbs. 6 lbs. 4.6 lbs. 5.4 lbs. 8.5 lbs. 6.4 lbs.

1191VSR(K) 1194VSR(K) 1199VSR(K) 11258VSR 11250VSR 11221DVS 11253VSR

Round Round Round SDS-plus® SDS-plus® SDS-plus® SDS-plus®

Hammer Drill Hammer Drill Hammer Drill Rotary Rotary

6 6.9 7.2

N/A N/A N/A 1.6 1.6 1.6 2.2

5/8" 3/4" 3/4" 5/8" 3/4" 7/8" 1"

Rotation Only

Hammer Drill

0-1,000 /

0-2,600

0-16,000 /

0-41,600

Rotation Only

Hammer Drill

0-1,100 /

0-3,000

0-18,000 /

0-48,000

Rotation Only

Hammer Drill

0-1,700 0-1,100 0-1,040 0-1,300

0-4,400 0-4,400 0-5,750 0-5,800

Rotation Only

Rotary Hammer

Rotation Only

Rotary Hammer

Combination Combination

Rotation Only

Rotary Hammer

Hammer Only

Rotation Only

Rotary Hammer

Hammer Only

Item #

Drive System

Hammer Classification

Amperage 6.9 7.2 7.2 7.5

Impact Energy (ft.-lbs.)

Max. Concrete Capacity

Optimal Range 3/16" - 5/8" 3/16" - 5/8" 3/16" - 3/4" 1/4" - 7/8" 1/4" - 7/8" N/A

Core Bits 2-1/2" 2-1/2" 3" 3" 3" N/A

No Load RPM 0-1,100 0-1,300 0-1,050 0-850 300-700 N/A

No Load BPM 0-6,150 0-5,800 0-4,000 0-3,900 1,650-3,900 N/A

BPM N/A N/A N/A N/A N/A 3,500

Modes of Operation

Length 17.5" 17.3" 12.9" 15.25" 15.25" 14.75"

Weight 6.5 lbs. 6.7 lbs. 7.8 lbs. 9.3 lbs. 10.1 lbs. 7.9 lbs.

*11224VSRC Includes 3 Jaw Chuck

11224VSR(C)* 11255VSR 11239VS 11236VS 11222EVS(G) 11320VS

SDS-plus® SDS-plus® SDS-plus® SDS-plus® SDS-plus® SDS-plus®

Combination Combination Combination Combination Combination Chipping

7.8 6.5

1.6 2.2 2.4 2.6 2.6 3.2

7/8" 1" 1" 1-1/8" 1-1/8" N/A

Rotation Only

Rotary Hammer

Hammer Only

Rotation Only

Rotary Hammer

Hammer Only

Rotation Only

Rotary Hammer

Rotation Only

Rotary Hammer

Hammer Only

Rotation Only

Rotary Hammer

Hammer Only

Hammer Quick Reference Guide

Item #

Drive System

Hammer Classification

Amperage 10 10 11 11

Impact Energy (ft.-lbs.)

Max. Concrete Capacity

Optimal Range 1/2" - 1-3/8" 1/2" - 1-3/8" 1/2" - 1-3/8" 1/2" - 1-3/8" 5/8" - 1-9/16" 3/4" - 1-3/4"

Through Hole Bits 2-1/2" 2-1/2" 2-1/2" 2-1/2" 3-1/8" 3-1/8"

Core Bits 4" 4" 4" 4" 6" 6"

No Load RPM 400 400 170-340 170-340 145-280 120-250

No Load BPM 3,000 3,000 1,700-3,300 1,700-3,300 1,350-2,800 1,100-2,500

Modes of Operation

Length 17.25" 17.25" 18" 18" 21" 23.5"

Weight 13.2 lbs. 13.6 lbs. 14 lbs. 14.4 lbs. 17.9 lbs. 24.5 lbs.

11240 11247 11241EVS 11248EVS 11263EVS 11245EVS

SDS-max® Spline/Round Hex SDS-max® Spline/Round Hex SDS-max® SDS-max®

Combination Combination Combination Combination Combination Combination

13.5 14

5.2 5.2 6.2 / 7.4 6.2 / 7.4 9.6 / 11.1 13.3

1-9/16" 1-9/16" 1-9/16" 1-9/16" 1-3/4" 2"

Rotary Hammer

Hammer Only

Rotary Hammer

Hammer Only

Rotation Only

Rotary Hammer

Hammer Only

Rotary Hammer

Hammer Only

Rotary Hammer

Hammer Only

Item #

Drive System

Hammer Classification

Amperage 10 10 11 14

Impact Energy (ft.-lbs.)

BPM 2,800 2,800 1,300-3,000 900-1,890 850-1,800 1,300 1,400

Modes of Operation

Length 17.5" 17.5" 17.75" 22.5" 22" 30.4" 29.75"

Weight 12 lbs. 11.6 lbs. 12.5 lbs. 22.5 lbs. 22 lbs. 38 lbs. 64 lbs.

11387 11388 11318EVS 11316EVS 11317EVS 11335K 11304(K)

Round Hex SDS-max® SDS-max® SDS-max® 3/4" Hex 1-1/8" Hex Collar 1-1/8" Hex Collar

Demolition Demolition Demolition Demolition Demolition

12.8 15 15

5.9 5.9 8.8 4.4 - 18.4 4 - 16.5 34 43

Hammer Only Hammer Only Hammer Only Hammer Only Hammer Only Hammer Only Hammer Only

Breaker Breaker

BRUTE

™

Toll Free: 877-BOSCH-99

Boschtools.com

Toll Free: 877-BOSCH-99

BOSCH

Hammer Drills

1191VSR(K)

Hammer Drill

Carrying Case Included

1194AVSR(K)

1/2" Dual Torque Hammer Drill

Features

• Light Weight Design - Perfect for small diameter drilling applications

• 7 AMP Motor - Provides the highest performance to weight ratio in its class

• 2-Mode Selector - Easily coverts from rotation only to hammer drill

• Compact Design - Aggressive impact mechanism in combination with a more powerful motor outperforms the competition

• 360° Auxiliary Handle with Built-in Quick Release Depth Gauge

• Variable Speed Trigger

• 1/2" 3-Jaw Chuck - For rugged hammer drilling applications

Features

• 8.0 Amps, 0-1000/2600 RPM, 0-16,000/0-41,600 BPM

• 2 Speed gear box - Matches speed and torque to the job

• Dual function control - Quickly converts from rotation-only to hammer with rotation

• Variable Speed Reversing Switch - Complete control for drilling, driving and removing bits or screws

• All ball and roller bearing construction - Smooth Power transmission and extended tool life

• Ergonomic handle - Multiple gripping positions for increased comfort and control

• 360° Side-handle with depth gauge - Wide range of movement along with consistent drilling depth

• Lock-on Button

Specifications

Rating 120V AC Amperage 7 No Load RPM 0-3,000 No Load BPM 0-48,000 Spindle Size 1/2"-20 Maximum Capacities (in.)

Concrete 5/8" Steel 1/2" Wood 1-1/2"

Aluminum 5/8" /3/8" in 2nd Length (in.) 11.0" Weight (lbs.) 4.2

Includes

360° Auxiliary Handle ........... 2 602 025 094

Depth Gauge .......................... 2 603 001 009

Chuck Key ............................... 3 608 571 511

1191VSRK

Carrying Case ..................................Included

See page 44 for hammer drill accessories.

Specifications

Rating 120V AC Amperage 8.0 No Load RPM 0-1,000 / 0-2,600 No Load BPM 0-16,000 / 0-41,600 Spindle Size 1/2"-20" Maximum Capacities (in.)

Concrete 3/4" /3/8" in 2nd

Steel 1/2" /1/4" in 2nd

Wood 1-1/2"

Aluminum 5/8" /3/8" in 2nd Length (in.) 16" Weight (lbs.) 5.3

Includes

360° Auxiliary Handle ........... 1 612 025 024

Depth Gauge .......................... 1 613 001 010

Chuck Key .......................................... CRK005

1194AVSRK

Carrying Case ........................ 2 605 438 284

Carrying Case Included

See page 44 for hammer drill accessories.

BOSCH

Hammer Drills/Rotary Hammers

BOSCH

Specifications

Rating 120V AC Amperage 8.5 No Load RPM 0-1,100 / 0-3,000 No Load BPM 0-18,000 / 0-48,000 Spindle Size 1/2" -20" Maximum Capacities (In.)

Concrete 3/4" (3/8" in 2nd) Steel 1/2" (1/4" in 2nd)

Wood 1-1/2" Length (in.) 13-1/4" Weight (lbs.) 6.0

Includes

360° Auxiliary Handle ........... 2 602 025 118

Depth Gauge .......................... 1 613 001 010

1199VSRK

Carrying Case ........................ 2 605 438 074

See page 44 for hammer drill accessories.

Specifications

Rating 120V Amperage 4.8 No Load RPM 0-1,700 No Load BPM 0-4,400 Impact Energy (ft./lbs.) 1.6 Maximum Capacities (in.)

Concrete 5/8"

Steel 1/2"

Wood 1-1/2" Optimal Concrete Capacity Range (in.)

Length (in.) 11.9" Weight (lbs.) 4.8

3/16" - 5/16"

Includes

Side Handle ............................2 602 025 149

Depth Gauge .......................... 2 603 001 009

3/16" SDS-plus® Bit ........................HC2011

1/4" SDS-plus® Bit ...........................HC2041

3/8" SDS-plus® Bit .......................... HC2061

Carrying Case ..................................Included

11258VSRC

3-Jaw ClicLoc™ Chuck ...................Included

SDS-plus® ClicLoc™ Chuck ...........Included

Carrying Case ..................................Included

Features

• Bosch-built High-output - 8.5 Amp Motor

• 1/2" 3 jaw chuck - For rugged hammer drilling applications

• Dual-Mode Selector - Easily converts from rotation only to hammer drill mode

• Patented Rotating Brush Plate - Provides equal power in reverse to easily back out bound-up bits and doubles brush life

• Pistol-Grip Handle - Compact ergonomic design with soft grip

• Variable-speed Reversing Trigger - For accurate bit starting, as well as removing fasteners or bound bits

• 2-Speed Gear Box - Select high-speed or hightorque applications

• Ambidextrous Lock-on Button - Helps reduce fatigue

• 360° auxiliary handle with built-in depth gauge - Wide range of movement along with consistent drilling depth

• Integral slip clutch - Helps minimize torque reaction

• 12 foot power cord - For added user reach and convenience

• Metal Gear Housing - For long life and rugged job site durability

• Patented cord turret - Allows cord to pivot 35° on a ball joint for added flexibility and longer cord life

Features

• Light Weight Design – At 4.8 amps and 4.8 pounds, the tool is perfect for small diameter drilling applications, especially overhead

• SDS-plus® Tool Holder – Tool-free bit changes with automatic bit locking, dust protection and maximum impact energy transfer rate

• Variable-Speed Trigger – For accurate bit starting, as well as removing fasteners or bound bits

• 2-Mode Selector – Easily converts from rotation only to rotary hammer

• Cushion Grip Handle –Optimized design provides increased comfort

• 360° Auxiliary Handle with built-in Quick Release Depth Gauge – Provides wide range of movement along with consistent drilling depth

• Integral Clutch – Helps minimize torque reaction

11258VSRC also features

• ClicLoc™ Chuck Change System – Choose between the SDS-plus® tool holder for drilling in concrete and masonry or the three-jaw carbide tipped chuck for drilling wood and metal

Concrete

Masonry

1199VSR(K)

1/2" Dual Torque Hammer Drill

Carrying Case Included

11258VSR(C)

5/8" SDS-plus® Concrete Drill

Flexibility to work in a variety of materials

Metal

SDS-plus

Wood

3-jaw chuck

See pages 44–47, 203–208 for SDS-plus® accessories.

Toll Free: 877-BOSCH-99

Boschtools.com

Carrying Case Included

Boschtools.com

Toll Free: 877-BOSCH-99

BOSCH

Rotary Hammers

BOSCH

11250VSR

3/4" SDS-plus® Rotary Hammer

Carrying Case Included

11253VSR

1" SDS-plus® Bulldog™ Xtreme Rotary Hammer

Carrying Case Included

Features

• Powerful 6.1 amp motor

• SDS-plus® tool holder - Tool-free bit changes with automatic bit locking, dust protection and maximum impact energy transfer rate

• Dual mode selector - Easily converts from rotation only to rotary hammer mode

• Patented rotating brush plate - Provides equal power in reverse and extends brush life

• Pistol grip handle - Compact ergonomic design with soft grip

• Integral clutch - Helps minimize torque reaction

• Variable-speed reversing trigger - For accurate bit starting, as well as removing fasteners or bound bits

• 13-foot power cord - For added user reach and convenience

Features

• 7.2 Amp; 0-1,300 RPM; 0-5,800 BPM

• Multi-function Selector - 3 modes of operation, rotation only, rotary hammer and hammeronly mode

• Vario-Lock™ Positioning - Rotates and locks chisel into 36 different positions to optimize working angle

• Patented Rotating Brush Plate - Provides equal power in forward and reverse

• Patented Cord Turret - 35° pivot for added flexibility and longer cord life

• SDS-plus® Bit System - Tool-free bit changes with automatic bit locking, dust protection and maximum impact energy transfer rate

• Variable-speed Reversing Trigger - For accurate bit starting as well as removing fasteners or bound bits

• Integral Clutch - Helps minimize torque reaction

• Pistol-Grip design

Specifications

Rating 120V Amperage 6.1 No Load RPM 0-1,100 No Load BPM 0-4,400 Impact Energy (ft./lbs.) 1.6 Thin Wall Core Bit 1-1/2" Length (in.) 13-1/4" Weight (lbs.) 5.4

Includes

360° Auxiliary Handle ........... 2 602 025 118

Depth Gauge .......................... 1 613 001 010

Carrying case ......................... 2 605 438 524

See pages 44–47, 203–208 for SDS-plus® accessories.

Specifications

Rating 120V Amperage 7.2 No Load RPM 0 - 1,300 No Load BPM 0 - 5,800 Impact Energy (ft./lbs.) 2.2 Maximum Capacities (in.)

Concrete 1" Concrete-Thin Wall Core Bit 2-5/8" Steel 1/2" Wood 3/4"-1"

Optimal Concrete Capacity Range (in.)

Length (in.) 14-3/4” Weight (lbs.) 6.4

3/16" - 5/8"

Includes

Auxiliary Handle ..................... 2 602 025 141

Depth Gauge .......................... 1 613 001 010

Carrying Case ..................................Included

See pages 44–47, 203–208 for

SDS-plus® accessories.

11255VSR

1" SDS-plus® Bulldog™ Xtreme Rotary Hammer

HammerHook™

Carrying Case Included

Features

• 7.2 Amp; 0-1,300 RPM; 0-5,800 BPM

• HammerHook™ allows quick tool storage during the job.

• Multi-function Selector - 3 modes of operation, rotation only, rotary hammer and hammeronly mode

• Vario-Lock™ Positioning - Rotates and locks chisel into 36 different positions to optimize working angle

• Patented Rotating Brush Plate - Provides equal power in forward and reverse

• Patented Cord Turret - 35° pivot for added flexibility and longer cord life

• SDS-plus® Bit System - Tool-free bit changes with automatic bit locking, dust protection and maximum impact energy transfer rate

• Variable-speed Reversing Trigger - For accurate bit starting as well as removing fasteners or bound bits

• D-Handle design - Ideal for overhead and downward drilling applications

• Integral Clutch - Helps minimize torque reaction

Specifications

Rating 120V Amperage 7.2 No Load RPM 0 - 1,300 No Load BPM 0 - 5,800 Impact Energy (ft./lbs.) 2.2 Maximum Capacities (in.)

Concrete 1" Concrete-Thin Wall Core Bit 2-5/8" Steel 1/2" Wood 3/4"-1"

Optimal Concrete Capacity Range (in.)

Length (in.) 17-1/4" Weight (lbs.) 6.7

3/16" - 5/8"

Includes

Auxiliary Handle ..................... 2 602 025 141

Depth Gauge .......................... 1 613 001 010

Carrying Case ..................................Included

See pages 44–47, 203–208 for SDS-plus® accessories.

BOSCH

Rotary Hammers

BOSCH

Specifications

Rating 120V Amperage 7.2 No Load RPM 0-1,050 No Load BPM 0-4,000 Impact Energy (ft./lbs.) 2.4 Maximum Capacities (in.)

Concrete 1" Concrete-Thin Wall Core Bit 3" Steel 7/8" Wood 1"

Optimal Concrete Capacity Range (in.)

Length (in.) 12.9" Weight (lbs.) 7.8

3/16"-3/4"

Includes

Auxiliary Handle ..................... 2 602 025 112

Depth Gauge .......................... 1 613 001 003

Carrying Case ........................ 2 605 438 482

See pages 44–47, 203–208 for SDS-plus® accessories.

Specifications

Rating 120V Amperage 7.5 No Load RPM 0-850 No Load BPM 0-3,900 Impact Energy (ft./lbs.) 2.6 Maximum Capacities (in.)

Concrete 1-1/8" Concrete-Thin Wall Core Bit 3" Steel 1" Wood 1-1/4"

Optimal Concrete Capacity Range (in.)

Length (in.) 15-1/4" Weight (lbs.) 9.3

1/4"-7/8"

Includes

Auxiliary Handle ..................... 2 602 025 077

Depth Gauge .......................... 1 613 001 003

Carrying Case ........................ 2 605 438 389

Features

• SDS-plus® bit system - Tool-free bit changes with automatic bit locking, dust protection and maximum impact energy transfer rate

• Variable speed 3 finger trigger - Better operator control and accurate bit starting

• Dual mode selector - 2 modes of operation, rotation only and rotary hammer mode

• Innovative service modules - Designed so a qualified service technician can quickly replace the brushes and cord

• Padded rear handle - Absorbs shock for operator comfort

• 360° Auxiliary handle with built-in depth gauge - Wide range of movement along with consistent drilling depth

• Integral clutch - Helps minimize torque reaction

Features

• SDS-plus® bit system - Tool-free bit changes with automatic bit locking, dust protection and maximum impact energy transfer rate

• Multi-function selector - 3 modes of operation, rotation only, rotary hammer and hammer only mode

• Variable speed 3 finger trigger - Better operator control and accurate bit starting

• Vario-Lock™ positioning - Rotates and locks chisel into 36 different positions to optimize working angle

• Padded rear handle - Absorbs shock for operator comfort

• 360° Auxiliary handle with built-in depth gauge - Wide range of movement along with consistent drilling depth

• Integral clutch - Helps minimize torque reaction

11239VS

1" SDS-plus® Rotary Hammer

Carrying Case Included

11236VS

1-1/8" SDS-plus® Rotary Hammer

See pages 44–47, 203–208 for SDS-plus® accessories.

Specifications

Rating 120V Amperage 7.8 No Load RPM 300-700 No Load BPM 1,650-3,900 Impact Energy (ft./lbs.) 2.6 Maximum Capacities (in.)

Concrete 1-1/8" Concrete-Thin Wall Core Bit 3" Steel 1/2" Wood 1-1/4"

Optimal Concrete Capacity Range (in.)

Length (in.) 15-1/4" Weight (lbs.) 10.1

1/4"-7/8"

Includes

Auxiliary Handle ..................... 2 602 025 077

Depth Gauge .......................... 1 613 001 003

Carrying Case ........................ 2 605 438 376

See pages 44–47, 203–208 for SDS-plus® accessories.

Features

• SDS-plus® bit system - Tool-free bit changes with automatic bit locking, dust protection and maximum impact energy transfer rate

• Multi-function selector - 3 modes of operation, rotation only, rotary hammer and hammer only mode

• Variable-speed dial - For accurate bit starting and controlled chipping applications

• Constant-Response™ Circuitry - Provides soft-start, maintains constant speed under load, provides overload protection

• Service Minder™ light - Indicates when preventative maintenance is required

• Vario-Lock™ positioning - Rotates and locks chisel into 36 different positions to optimize working angle

• Padded rear handle - Absorbs shock for comfort

• 360° Auxiliary handle - Provides a wide range of movement along with operator comfort

• Integral clutch - Helps minimize torque reaction

11222EVSG also features

• Grounded feature designed for the pest control industry

• The best speed for the diameter of bits used by the pest control industry

Carrying Case Included

11222EVS(G)

1-1/8" SDS-plus® Rotary Hammer

Carrying Case Included

Toll Free: 877-BOSCH-99

Boschtools.com

Toll Free: 877-BOSCH-99

Rotary Hammers

BOSCH

The World’s Best Selling Rotary Hammers

The Bulldog™ series of hammers are well recognized by professionals worldwide. Their aggressive performance in concrete combined with versatile features such as stop rotation (models 11221DVS, 11224VSR, 11224VSRC, 11253VSR and 11255VSR) for light chipping has set the Bulldog™ apart from other hammers over the past 20 years.

11221DVS

7/8" SDS-plus® Rotary Hammer

Carrying Case Included

11224VSR

7/8" SDS-plus® Bulldog™ Rotary Hammer

Features

• SDS-plus® bit system - Tool-free bit changes with automatic bit locking, dust protection and maximum impact energy transfer rate

• Multi-function selector - 3 modes of operation, rotation only, rotary hammer and hammer only mode

• Variable-speed reversing trigger - For accurate bit starting, as well as removing fasteners or bound bits

• Constant-Response™ Circuitry - Provides soft-start, maintains constant speed under load, provides overload protection

• Vario-Lock™ positioning - Rotates and locks chisel into 36 different positions to optimize working angle

• 360° Auxiliary handle with built-in depth gauge

• Integral clutch - Helps minimize torque reaction

Features

• SDS-plus® bit system - Tool-free bit changes with automatic bit locking, dust protection and maximum impact energy transfer rate

• Multi-function selector - 3 modes of operation, rotation only, rotary hammer and hammer only mode

• Variable-speed reversing trigger - For accurate bit starting, as well as removing fasteners or bound bits

• Vario-Lock™ positioning - Rotates and locks chisel into 36 different positions to optimize working angle

• D-handle design - For extra control, ideal for overhead and downward drilling applications

• 360° Auxiliary handle with built-in depth gauge - Wide range of movement along with consistent drilling depth

• Integral clutch - Helps minimize torque reaction

Specifications

Rating 120V Amperage 6.9 No Load RPM 0-1,040 No Load BPM 0-5,750 Impact Energy (ft./lbs.) 1.6 Maximum Capacities (in.)

Concrete 7/8" Concrete-Thin Wall Core Bit 2-1/2" Steel 1/2" Wood 1"

Optimal Concrete Capacity Range (in.)

Length (in.) 16-1/2" Weight (lbs.) 8.5

3/16"-5/8"

Includes

Auxiliary Handle ..................... 2 602 025 118

Depth Gauge .................................Integrated

Dust Extraction Fixture ........ 1 618 190 006

Hose (23" length) ................... 2 600 712 002

Adapter for Paper Dust Bags ... 2 607 000 178

Cloth Bag Assembly .............. 2 605 411 044

Carrying Case ........................ 2 605 438 126

See pages 44–47, 203–208 for SDS-plus® accessories.

Specifications

Rating 120V Amperage 6.9 No Load RPM 0-1100 No Load BPM 0-6,150 Impact Energy (ft./lbs.) 1.6 Maximum Capacities (in.)

Concrete 7/8" Concrete-Thin Wall Core Bit 2-1/2" Steel 1/2" Wood 1"

Optimal Concrete Capacity Range (in.)

Length (in.) 17-1/2" Weight (lbs.) 6.5

3/16" - 5/8"

Includes

Auxiliary Handle ..................... 2 602 025 118

Depth Gauge .......................... 1 613 001 010

Carrying Case ........................ 2 610 994 810

Carrying Case Included

See pages 44–47, 203–208 for SDS-plus® accessories..

Rotary/Chipping/Combination Hammers

BOSCH

Specifications

Rating 120V Amperage 6.9 No Load RPM 0-1,100 No Load BPM 0-6,150 Impact Energy (ft./lbs.) 1.6 Maximum Capacities (in.)

Concrete 7/8" Concrete-Thin Wall Core Bit 2-1/2" Steel 1/2" Wood 1"

Optimal Concrete Capacity Range (in.)

Length (in.) 17-1/2" Weight (lbs.) 6.5

3/16" - 5/8"

Includes

Auxiliary Handle ..................... 2 602 025 070

Depth Gauge .......................... 1 613 001 010

3-Jaw ClicLoc™ Chuck ......... 1 618 572 000

SDS-plus® ClicLoc™ Chuck ... 1 618 573 000

Carrying Case ........................ 2 610 994 810

See pages 44–47, 203–208 for SDS-plus® accessories.

Specifications

Rating 120V Amperage 6.5 No Load BPM 0 - 3,500 Impact Energy (ft./lbs.) 3.2 Length (in.) 15" Weight (lbs.) 7.9

Includes

Auxiliary Handle ..................... 1 612 025 059

Viper Flat Chisel .................... 2 608 692 928

Tile Chisel ............................... 2 608 682 973

Carrying Case ........................ 2 605 438 294

See pages 44–47, 203–208 for SDS-plus® accessories.

Features

• SDS-plus® bit system - Tool-free bit changes with automatic bit locking, dust protection and maximum impact energy transfer rate

• ClicLoc™ Chuck Change System - Easily remove the SDS-plus® bit holder and snap on the included keyless carbide-tipped 3-jaw chuck

• Multi-function selector - 3 modes of operation, rotation only, rotary hammer and hammer only mode

• Variable-speed reversing trigger - For accurate bit starting, as well as removing fasteners or bound bits

• Vario-Lock™ positioning - Rotates and locks chisel into 36 different positions to optimize working angle

• D-handle design - For extra control, ideal for overhead and downward drilling applications

• 360° Auxiliary handle with built-in depth gauge - Wide range of movement along with consistent drilling depth

• Integral clutch - Helps minimize torque reaction

Features

• Powerful 6.5 Amp Motor - For highest removal rate in its class

• Specially-designed Impact Mechanism - Smooth change between no-load and hammering modes. Superior tool control for easier positioning and precision chiseling.

• SDS-plus® Bit System - Tool-free bit changes with auto bit locking, dust protection and maximum impact energy transfer. Eliminates problems associated with proprietary types of steel.

• Next-Generation SDS-plus® Bit Holder - For extended lifetime

• Variable-speed Trigger Switch with Recessed Lock-On Button - For exact adjustment of impact force, comfort and less fatigue.

• Soft Start - Smooth change from no-load into hammering mode.

• Soft-Grip Handle - Absorbs shock and vibration for operator comfort and less fatigue.

• Light Weight - Highest power-to-weight ratio in its class

• Vario-Lock™ positioning - Bit can be angled in any of 12 positions

• Oil Lubrication - For good cold-start and excellent lubrication in all working positions

• Innovative Service Modules - Designed so a qualified service technician can quickly replace the brushes and cord

11224VSRC

7/8" SDS-plus® Bulldog™ Rotary Hammer

with ClicLoc™

Concrete

Masonry

Flexibility to work in a variety of materials

SDS-plus

Metal

Wood

3-jaw chuck

Carrying Case Included

11320VS

SDS-plus® Chipping Hammer

Carrying Case Included

Specifications

Rating 120V Amperage 10 No Load RPM 400 No Load BPM 3,000 Impact Energy (ft./lbs.) 5.2 Maximum Capacities (in.)

Concrete 1-9/16" Concrete-Thru Hole Bit 2-1/2" Concrete-Core Bit 4"

Optimal Concrete Capacity Range (in.)

Length (in.) 17.25" Weight (lbs.) 13.2

1/2" - 1-3/8"

Includes

Auxiliary Handle ..................... 1 612 025 055

Carrying Case ........................ 3 605 438 536

See pages 47–50, 52 for SDS-max® accessories.

Features

• SDS-max® bit system - Tool-free bit changes with automatic bit locking, dust protection and maximum impact energy transfer rate

• “Combination” dual mode selector - 2 modes of operation, rotary hammer and hammer only mode

• Vario-Lock™ positioning - Rotates and locks chisel into 12 different positions to optimize working angle

• Innovative service modules - Designed so a qualified service technician can quickly replace the brushes and cord

• 360° Auxiliary handle - Provides a wide range of movement along with operator comfort

• Integral clutch - Helps minimize torque reaction

Toll Free: 877-BOSCH-99

11240

1-9/16" SDS-max® Combination Hammer

Carrying Case Included

Boschtools.com

Toll Free: 877-BOSCH-99

Combination/Rotary Hammers

BOSCH

11241EVS

1-9/16" SDS-max® Combination Hammer

Carrying Case Included

11263EVS

1-3/4" SDS-max® Rotary Hammer

Carrying Case Included

Features

• SDS-max® bit system - Tool-free bit changes with automatic bit locking, dust protection and maximum impact energy transfer rate

• “Combination” dual mode selector - 2 modes of operation, rotary hammer and hammer only mode

• Auto-Max® dial - Variable speed dial designed to automatically insure the maximum speed and power every time the tool is plugged in

• Constant-Response™ Circuitry - Provides soft-start, maintains constant speed under load, provides overload protection

• Turbo™ Power - Delivers 20% more power in hammer only mode

• Service Minder™ light - Indicates when preventative maintenance is required

• Power light - Ensures operator that power feed is live

• Vario-Lock™ positioning - Service modules or brushes and cord

• Innovative service modules - Designed so a qualified service technician can quickly replace the brushes and cord

• Vibration dampening handle - Reduces vibration up to 40%, providing uncompromising user comfort for extended periods of work

• Patented cord turret - Provides added flexibility and reduces cord wear

• 360° Auxiliary handle - Provides a wide range of movement along with operator comfort

• Integral clutch - Helps minimize torque reaction

Features

• SDS-max® bit system - Tool-free bit changes with automatic bit locking, dust protection and maximum impact energy transfer rate

• “Combination” dual mode selector - 2 modes of operation, rotary hammer and hammer only mode

• Variable speed dial - For accurate bit starting and controlled chipping applications

• Constant Response™ circuitry - Provides soft-start, maintains constant speed under load, provides overload protection

• Turbo™ Power Feature - Delivers 20% more power in hammer only mode

• Service Minder™ light - Indicates when preventative maintenance is required

• Vario-Lock™ positioning - Rotates and locks chisel into 12 different positions to optimize working angle

• Soft grip rear handle - Absorbs shock and vibration for operator comfort and less fatigue

• 360° Auxiliary handle - Provides a wide range of movement along with operator comfort

Specifications

Rating 120V Amperage 11 No Load RPM 170-340 No Load BPM 1,700-3,300 Impact Energy (ft./lbs.)

Rotary Hammer Mode 6.2 Turbo™ 7.4

Maximum Capacities (in.)

Concrete 1-9/16" Concrete-Thru Hole Bit 2-1/2" Concrete-Core Bit 4"

Optimal Concrete Capacity Range (in.)

Length (in.) 17.25" Weight (lbs.) 14

1/2" - 1-3/8"

Includes

Auxiliary Handle ..................... 1 612 025 055

Carrying Case ........................ 3 605 438 536

See pages 47–50, 52 for SDS-max® accessories.

Specifications

Rating 120V Amperage 13.5 No Load RPM 145-280 No Load BPM 1,350-2,800 Impact Energy (ft./lbs.)

Rotary Hammer Mode 9.6 Turbo™ 11.1

Maximum Capacities (in.)

Concrete 1-3/4" Concrete-Thru Hole Bit 3-1/8" Concrete-Core Bit 6"

Optimal Concrete Capacity Range (in.)

Length (in.) 21.0" Weight (lbs.) 17.9

5/8" - 1-9/16"

Includes

Auxiliary Handle ..................... 2 602 025 103

Carrying Case ........................ 3 605 438 396

See pages 47–50, 52 for

SDS-max® accessories.

11245EVS

2" SDS-max® Combination Hammer

Carrying Case Included

Features

• SDS-max® bit system - Tool-free bit changes with automatic bit locking, dust protection and maximum impact energy transfer rate

• “Combination” dual mode selector - 2 modes of operation, rotary hammer and hammer only mode

• Variable-speed dial - For accurate bit starting and controlled chipping applications

• Constant-Response™ Circuitry - Provides soft-start, maintains constant speed under load, provides overload protection

• Service Minder™ light - Indicates when preventative maintenance is required

• Vario-Lock™ positioning - Rotates and locks chisel into 12 different positions to optimize working angle

• Padded rear handle - Absorbs shock for operator comfort

• 360° Auxiliary handle - Provides a wide range of movement along with operator comfort

• Integral clutch - Helps minimize torque reaction

Specifications

Rating 120V Amperage 14.0 No Load RPM 120-250 No Load BPM 1,100-2,500 Impact Energy (ft./lbs.) 13.3 ft. lbs. Maximum Capacities (in.)

Concrete 2" Concrete-Thru Hole Bit 3-1/8" Concrete-Core Bit 6"

Optimal Concrete Capacity Range (in.)

Length (in.) 23.5" Weight (lbs.) 24.5

3/4"-1-3/4"

Includes

Auxiliary Handle ..................... 2 602 025 086

Carrying Case ........................ 2 605 438 322

See pages 47–50, 52 for SDS-max® accessories.

Demolition Hammers

BOSCH

Specifications

Rating 120V Amperage 10 No Load BPM 2,800 Impact Energy (ft./lbs.) 5.9 Length (in.) 17.5" Weight (lbs.) 11.6

Includes

Auxiliary Handle ..................... 1 612 025 055

Carrying Case ........................ 3 605 438 534

See pages 47–50, 52 for SDS-max® accessories.

Specifications

Rating 120V Amperage 11 No Load BPM 1,300-3,300 Impact Energy (ft./lbs.) 8.8 Length (in.) 17.75" Weight (lbs.) 12.5

Includes

Auxiliary Handle ..................... 1 612 025 055

Carrying Case ........................ 3 605 938 534

See pages 47–50, 52 for SDS-max® accessories.

Features

• SDS-max® bit system - Tool-free bit changes with automatic bit locking, dust protection and maximum impact energy transfer rate

• Vario-Lock™ positioning - Rotates and locks chisel into 12 different positions to optimize working angle

• 360° Auxiliary handle - Provides a wide range of movement along with operator comfort

• Innovative service modules - Designed so a qualified service technician can quickly replace the brushes and cord

Features

• SDS-max® bit system - Tool-free bit changes with automatic bit locking, dust protection and maximum impact energy transfer rate

• Auto-Max® dial - Variable speed dial designed to automatically insure the maximum speed and power every time the tool is plugged in

• Constant Response™ circuitry - Provides softstart, maintains constant speed under load, provides overload protection

• Service Minder™ light - Indicates when preventative maintenance is required

• Power light - ensures operator that power feed is live

• Vario-Lock™ positioning - Rotates and locks chisel into 12 different positions to optimize working angle

• Innovative service modules - Designed so a qualified service technician can quickly replace the brushes and cord

• Vibration dampening handle - Reduces vibration up to 40%, providing uncompromising user comfort for extended periods of work

• Patented cord turret - Provides added flexibility and reduces cord wear

• 360° Auxiliary handle - Provides a wide range of movement along with operator comfort

11388

SDS-max® Demolition Hammer

Carrying Case Included

11318EVS

SDS-max® Demolition Hammer

Carrying Case Included

Specifications

Rating 120V Amperage 14.0 No Load BPM 900-1,890 Impact Energy (ft./lbs.) 4.4-18.4 Length (in.) 22.5" Weight (lbs.) 22.5

Includes

Auxiliary Handle ..................... 2 602 025 076

Carrying Case ........................ 2 605 438 297

See pages 47–50, 52 for SDS-max® accessories.

Features

• SDS-max® bit system - Tool-free bit changes with automatic bit locking, dust protection and maximum impact energy transfer rate

• Variable-speed dial - For controlled chipping applications

• Constant Response™ circuitry - Provides soft-start, maintains constant speed under load, provides overload protection

• Service Minder™ light - Indicates when preventative maintenance is required

• Vario-Lock™ positioning - Rotates and locks chisel into 12 different positions to optimize working angle

• Padded rear handle - Absorbs shock for operator comfort

• 360° Auxiliary handle - provides a wide range of movement along with operator comfort

Toll Free: 877-BOSCH-99

11316EVS

SDS-max® Demolition Hammer

Carrying Case Included

Boschtools.com

Toll Free: 877-BOSCH-99

Combination/Demolition Hammers

BOSCH

11247

1-9/16" Spline Combination Hammer

Carrying Case Included

11248EVS

1-9/16" Spline Combination Hammer

Carrying Case Included

Features

• Spline/round hex bit system - Tool-free bit changes, with automatic bit locking

• “Combination” dual mode selector - 2 modes of operation, rotary hammer and hammer only mode

• Vario-Lock™ positioning - Rotates and locks chisel into 12 different positions to optimize working angle

• Innovative service modules - Designed so a qualified service technician can quickly replace the brushes and cord

• 360° Auxiliary handle - Provides a wide range of movement along with operator comfort

• Integral clutch - Helps minimize torque reaction

Features

• Spline/round hex bit system - Tool-free bit changes, with automatic bit locking

• Auto-Max® dial - Variable speed dial designed to automatically insure the maximum speed and power every time the tool is plugged in

• Constant Response™ Circuitry - Provides soft-start, maintains constant speed under load, provides overload protection

• “Combination” dual mode selector - 2 modes of operation, rotary hammer and hammer only mode

• Turbo™ Power - Delivers 20% more power in hammer only mode

• Service Minder™ light - Indicates when preventative maintenance is required

• Power light - Ensures operator that power feed is on

• Vario-Lock™ positioning rotates and locks chisel into 12 different positions to optimize working

- Designed so a qualified ser vice technician can quickly replace the brushes and cord - Provides added flexibility and reduces cord wear.

• Vibration dampening handle - Reduces vibration up to 40%, providing uncompromising user comfort for extended periods of work

Specifications

Rating 120V Amperage 10 No Load RPM 400 No Load BPM 3000 Impact Energy (ft./lbs.) 5.2 Maximum Capacities (in.)

Concrete 1-9/16" Concrete-Thru Hole Bit 2-1/2" Concrete-Core Bit 4"

Optimal Concrete Capacity Range (in.)

Length (in.) 17.25" Weight (lbs.) 13.6

1/2" - 1-3/8"

Includes

Auxiliary Handle ..................... 1 612 025 055

Carrying Case ........................ 3 605 438 536

See pages 50–52 for Spline accessories.

Specifications

Rating 120V Amperage 11 No Load RPM 170-340 No Load BPM 1,700-3,300 Impact Energy (ft./lbs.)

Rotary Hammer Mode 6.2 Turbo™ 7.4

Maximum Capacities (in.)

Concrete 1-9/16" Concrete-Thru Hole Bit 2-1/2" Concrete-Core Bit 4"

Optimal Concrete Capacity Range (in.)

Length (in.) 18" Weight (lbs.) 14.4

1/2" - 1-3/8"

Includes

Auxiliary Handle ..................... 1 612 025 055

Plastic Case............................ 3 605 438 536

See pages 50–52 for

Spline accessories.

11387

Round Hex Demolition Hammer

Carrying Case Included

Features

• Round hex tool holder - Tool-free demolition steel changes, with automatic locking

• Vario-Lock™ positioning - Rotates and locks chisel into 12 different positions to optimize working angle

• 360° Auxiliary handle - Provides a wide range of movement along with operator comfort

• Innovative service modules - Designed so a qualified service technician can quickly replace the brushes and cord

Specifications

Rating 120V Amperage 10 No Load BPM 2,800 Impact Energy (ft./lbs.) 5.9 Length (in.) 17.5" Weight (lbs.) 12

Includes

Auxiliary Handle ..................... 1 612 025 055

Carrying Case ........................ 3 605 438 534

See page 51 for round hex accessories.

Demolition/Breaker Hammers

BOSCH

Specifications

Rating 120V Amperage 12.8 No Load BPM 850 - 1,800 Impact Energy (ft./lbs.) 4.0-16.5 Length (in.) 22.0" Weight (lbs.) 22.0

Includes

Auxiliary Handle ..................... 2 602 025 076

Carrying Case ........................ 2 605 438 297

See page 51 for 3/4" hex accessories.

Specifications

Rating 120V Amperage 15 No Load BPM 1,300 Impact Energy (ft./lbs.) 34 Length (in.) 30" Weight (lbs.) 38

Includes

Pointed Chisel (400 mm) ................ HS2861

Articulating Auxiliary Handle .........Included

Carrying Case with Wheels ... 2 605 438 628

Features

• 3/4" hex tool holder

• Variable speed dial - For controlled chipping applications

• Constant Response™ circuitry - Provides soft-start, maintains constant speed under load, provides overload protection

• Service Minder™ light - Indicates when preventative maintenance is required

• Padded rear handle - Absorbs shock for operator comfort

• 360° Auxiliary handle - Provides a wide range of movement along with operator comfort

Features

• 15.0 Amps; 1300 BPM

• Impact force of 34 ft-lbs and powerful 1750 W motor - Fastest removal rate in its class

• Vibration Reducing Handle - Shock absorbing top handle reduces vibration by up to 40% vs. the competition

• In-Line Design – Ultimate tool balance with multiple grip positions for maximum per formance in angled, horizontal, and vertical applications

• Large Main handle – Increased control and handling

• Well Positioned lock on switch – Eliminates unintentional shut off.

• 360° Articulating Auxiliar y Handle – Provides a wide range of movement along with operator comfort

• 2-Way Tool Retainer – Accepts standard 1-1/8" (28mm) hex, air tool steel with retaining collar or Bosch internal locking combo steel.

11317EVS

3/4" Hex Demolition Hammer

Carrying Case Included

11335K

Jack 35 lb.

Breaker Hammer

See page 52 for 1-1/8" hammer steel accessories.

Highest Removal Rate

in its Class

Lasts 2 Times Longer than

the Closest Competitor

MEET JACK

The Newest Member of the Legendary Bosch Wrecking Crew

Carrying Case Included

Active Vibration Control™

Reduces Vibration by 40%

Toll Free: 877-BOSCH-99

Boschtools.com

Toll Free: 877-BOSCH-99

BOSCH

Breaker Hammers

11304(K)

Brute™ Breaker Hammer

Features

• The plug-in anywhere hammer - Does not need a compressor

• Total por tability - Operates on 115/120V AC/DC, 15 amp outlet or 2500 watt por table generator

• Service Minder™ brush system - Shuts the Brute™ off when brush replacement, lubrication or preventive maintenance is needed

• Grease packed gear box and hammer mechanism

- Eliminates uncertainty of job site lubrication

• Shock mounted handles - Absorb vibration to reduce operator fatigue

113304K

Hammer Hauler Cart

• 8" Diameter semi-pneumatic, ball bearing wheels

- Easy rolling over rough job sites

• Rugged 1" diameter all welded steel frame, plus heavy-duty rubber tie-down - For convenient storage and easy transportation

• 4 Sockets - Holds any 1-1/8" hex collar insert tools

2-Way Tool Retainer

Two-way insert tool retainer accepts standard 1-1/8" hex, air tool steel with retaining collar or Bosch internal locking combo steel.

Specifications

Rating 115/120V AC/DC Amperage 15.0 No Load BPM 1400 Impact Energy (ft./lbs.) 43 Length (in.) 29-3/4" Weight (lbs.) 64

11304K Includes

Breaker Hammer ................................. 11304

Moil Points (2)................................... HS2161

Narrow Chisels (2) ........................... HS2163

Hammer Hauler Cart ...........................T1657

See page 52 for 1-1/8" hammer steel accessories.

Hammer Hauler

Up for combo steel.

Down for air tool steel.

The Plug-In-Anywhere Brute™ Breaker Hammer

A legend for more than 20 years, the Brute™ continues to perform through any working condition. A favorite among the rental industry for its long-term sustained durability and minimal down time, the Brute™ breaker is always at home on the jobsite.

• Remove side handle to attach

• Tool length increases by 2-3/4"

• Tool length is offset by less than the shank insertion depth into the bit holder

• Impact strength is reduced by approximately 40%

Hammer Attachments

1 618 580 000 SDS-plus® Right Angle Attachment

Angle drill head for effortlessly drilling concrete in hard to reach spots. Pivots through 360° ensuring correct positioning for any application.

• For SDS-plus 11224VSR/VSRC, 11250VSR

SDS-plus® is a registered trademark of Robert Bosch GmbH.

Rotary Hammer Item #s

1 618 571 014 Chuck With Integral SDS-plus® Shank

• 1/2" capacity chuck with integral SDS-plus® shank.

• Use for straight shank drill bits.

• For wood, metal and fastening.

• Can be used in the drill only mode.

• For all Bosch SDS-plus® Rotary Hammers.

Item # Description

1 610 508 015 Replacement Dust Boot CRK005 Replacement Chuck Key

1 618 190 006 Dust Extraction Fixture

• Attaches to tool and vacuum cleaner hose to provide excellent dust collection when drilling in dust-sensitive areas, such as computer rooms and medical facilities

• For use with bits up to 3/4" in diameter (depending on tool's bit capacity) for extracting fine dust

• Built-in depth gauge and adjustable depth limiter

• Easy attachment to compatible tools and auxiliar y handles (see Dust Extraction Compatibility Charts)

• Includes Dust Cover 1 610 591 006

• Does not fit Item # 11239VS

Item # Description

VAC001 15' Vacuum Hose (Fixture to Vacuum) 1 610 591 006 Replacement Dust Cover

1 618 190 009 Dust Extraction Fixture

• Attaches to tool and vacuum cleaner hose to provide excellent dust collection when drilling in dust-sensitive areas, such as computer rooms and medical facilities

• For use with bits up to 1-9/16" in diameter (depending on tool's bit capacity) for extracting fine dust, wood or metal drilling debris

• Built-in depth gauge and adjustable depth limiter

• Easy attachment to compatible tools and auxiliar y handles (see Dust Extraction Compatibility Charts)

• Includes Dust Cover 1 615 502 004

• Does not fit Item # 11239VS

Item # Description

VAC001 15' Vacuum Hose (Fixture to Vacuum) VAC002 Connects 1-1/4" or 1" hoses to tools that have ports for 35mm hoses VAC009 Anti-static 19mm 3-meter (9.85-ft. locking hose) VAC010 Anti-static 19mm 5-meter (16.4-ft. locking hose) 1 610 502 004 Replacement Dust Cover

2 607 018 296 SDS-plus® Chipping Adapter

• For SDS-plus® Rotary Hammer

Item #s 11225VSR, 11225VSRH and 11250VSR.

Toll Free: 877-BOSCH-99

Boschtools.com

Toll Free: 877-BOSCH-99

Masonry/Concrete Drilling

Hammer Drill Bits

HCBG800

Blue Granite™ Carbide Hammer Drill Bit Sets

Fast impact drilling in concrete, stone and masonr y. Low voltage, high temperature brazing prevents carbide cutting edge from breaking out even when heat builds up during deep drilling. Various usable lengths up to 10".

• Milled u-f lute and deep-cut spiral single-flute designs combined with a diamond ground carbide tip to provide fast removal of drilling dust

• Perfect "on-center" diamond tip grinding for fast starts and drilling

• Inductive hardening process provides a softer shank for better gripping power

Item # Description Sizes

HCBG500

HCBG600T

HCBG700

HCBG800

5 pc. Industrial Hammer

Drill Bit Starter Set

6 pc. Industrial Hammer

Drill Bit Tapcon® Set

7 pc. Industrial Hammer

Drill Bit Set

8 pc. Industrial Hammer

Drill Bit Master Set

1/8" x 2" x 3"; 3/16" x 4" x 6"; 1/4" x 4" x 6"; 5/16" x 4" x 6";

and 3/8" x 4" x 6"

3 ea. of 5/32" x 4" x 6"

and 3/16" x 4" x 6"

One 1/8" x 2" x 3", Two 5/32" x 3" x 6", Two 3/16" x 4" x 6", One 1/4" x 4" x 6",

One 3/8 x 4" x 6"

One 3/16" x 4" x 6", Two 1/4" x 4" x 6", One 5/16" x 4" x 6", Two 3/8" x 4" x 6",

One 1/2" x 4" x 6", and One 5/8" x 4" x 6"

Blue Granite™ Carbide Hammer Drill Bits

Item # Diameter

HCBG01 1/8" 2" 3" 1 HCBG0105 1/8" 2" 3" 5 HCBG01B25 1/8" 2" 3" 25 HCBG02 5/32" 4" 6" 1 HCBG0205 5/32" 4" 6" 5 HCBG02B25 5/32" 4" 6" 25 HCBG03 3/16" 2" 3" 1 HCBG0305 3/16" 2" 3" 5 HCBG03B25 3/16" 2" 3" 25 HCBG04 3/16" 4" 6" 1 HCBG0405 3/16" 4" 6" 5 HCBG04B25 3/16" 4" 6" 25 HCBG05 7/32" 4" 6" 1 HCBG0505 7/32" 4" 6" 5 HCBG05B25 7/32" 4" 6" 25 HCBG06 1/4" 4" 6" 1 HCBG0605 1/4" 4" 6" 5 HCBG06B25 1/4" 4" 6" 25 HCBG07 1/4" 6" 8" 1 HCBG08 1/4" 10" 12" 1 HCBG09 5/16" 4" 6" 1 HCBG0905 5/16" 4" 6" 5 HCBG09B25 5/16" 4" 6" 25 HCBG10 5/16" 7-1/2" 10" 1 HCBG11 5/16" 10" 12" 1 HCBG12 3/8" 4" 6" 1 HCBG1205 3/8" 4" 6" 5 HCBG12B25 3/8" 4" 6" 25 HCBG13 3/8" 8" 10" 1 HCBG14 3/8" 10" 12" 1 HCBG15 7/16" 4" 6" 1 HCBG1505 7/16" 4" 6" 5 HCBG15B25 7/16" 4" 6" 25 HCBG16 1/2" 4" 6" 1 HCBG1605 1/2" 4" 6" 5 HCBG16B25 1/2" 4" 6" 25 HCBG17 1/2" 8" 10" 1 HCBG18 1/2" 10" 12" 1 HCBG19 9/16" 7-1/2" 10" 1 HCBG20 5/8" 4" 6" 1 HCBG2005 5/8" 4" 6" 5 HCBG20B25 5/8" 4" 6" 25 HCBG21 5/8" 10" 12" 1 HCBG22 3/4" 4" 6" 1 HCBG23 3/4" 10" 12" 1 HCBG24 7/8" 4" 6" 1 HCBG25 7/8" 10" 12" 1 HCBG26 1" 4" 6" 1 HCBG27 1" 10" 12" 1

Usable Length

Overall Length Quantity

SDS-plus®

Hammer Carbide

Anchor Drive Installation Kit

SDS-plus® shank bits for use with Tapcon® / Condrive systems. Hex drive on bit fits into driver sleeve.

• 1/4" hex shoulder for drive sleeve used to set masonr y screws

Item # Description

HC2309

Tapcon® is a registered trademark of Illinois Tool Works. SDS-plus® is a registered trademark of Robert Bosch GmbH. Allen® is a registered trademark of Industrial Fasteners Inc.

Phillips

is a registered trademark of Phillips Screw Co.

9 pc. anchor drive installation kit—5/32" x 7" and 3/16" x 7"

Tapcon® hex bits, #2 & #3 Phillips® insert bits, bit holder, 5-3/4"

sleeve, 1/4" & 5/16" sockets and Allen® wrench

Masonry/Concrete Drilling

InZ]kh8P8¦8;nmm^kl

8\hkmZ]hk^l8

InZ]kh8P

=f[hnml8_hk^ml8

InZ]kh8P8jnZ]knie^l8

SDS-plus® Spade Chisel Works Longer, Faster And Sharper: The New SDS-plus® Spade Chisels.

With a Double-Length spade, Bosch has considerably extended the service life of the spade chisel. The material removal rate has also been signicantly increased. The chisel is self-sharpening due to the at shape of its spade, meaning no downtime from time-consuming and tedious resharpening of the chisel.

Self-sharpening

Flat shape of the spade•

Bracing Ribs

Stability for demolition work•

Optimized Total Length

Considerably improved handling •

in narrow spaces

HS1465

HS1472

HS1470

SDS-plus® Hammer Steel

Bosch offers a full assortment of SDS-plus® hammer steel points and chisels.

• HS1470 is the new long life SDS-plus® Viper flat chisel featuring an innovative cutting chisel that further disperses the energy of each impact. 30% longer service life and 15% higher material removal

• HS1472 is the new long life SDS-plus® pointed chisel. 30% longer service life and 15% higher material removal

• HS1465 is the new SDS-plus® tile chisel which allows removal of tiles at a faster rate and with much less effort. Bosch’s new tile chisel removes material up to 40% quicker than conventional tile chisels. Ideal for smaller grout joints and specially shaped for prying and removing tiles in one piece

Item # Description

HS1415 10" point HS1420 3/4" x 10" chisel HS1425* 1-1/2" x 10" wide chisel self-sharpening HS1427* 2-1/2" x 10" wide chisel self-sharpening HS1430 1/4" x 7" wood chisel HS1435 1/2" x 7" wood chisel HS1440 3/4" x 7" wood chisel HS1445 1" x 7" wood chisel HS1450 1-1/4" x 7" wood chisel HS1465 1-1/2" x 10" Tile chisel HS1470 3/4" x 10" Viper flat chisel (long life) HS1472 10" point (long life) HS1475 10" Gouging chisel HS1480 8" Carbide tipped point HS1485 1-1/2" x 5-3/4" Stubby scaling chisel HS1490 5-3/4" Stubby point HS1495 3/4" x 5-3/4" Stubby flat chisel

*Available 4Q 2007

SDS-plus® is a registered trademark of Robert Bosch GmbH.

NOTE: Drill bits (or extension + drill bit) in excess of 8" should never exceed 600 RPM.

30%

Higher Removal Rate

HCK001

SDS-plus® Rotary Hammer Bit Sets

Bosch SDS-plus® rotary hammer bits feature a patent-pending 4-flute design which provides fast dust removal. The carbide-tipped drill bit heads are harder, tougher and more resistant to extreme loads.

• HCK001 and HCK005 are 7-piece and 5-piece kits, respectively, featuring popular SDS-plus® bits in a r ugged index case

Item # Includes

HCK001

HCK005

SDS-plus® Wild-Bore™ With Quadro-X™ Rotary Hammer Bits

Item # Diameter

HC2222 3/4" 6" 8" 1 HC2224 3/4" 10" 12" 1 HC2227 3/4" 16" 18" 1 HC2242 7/8" 6" 8" 1 HC2244 7/8" 10" 12" 1 HC2247 7/8" 16" 18" 1 HC2263 1" 8" 10" 1 HC2267 1" 16" 18" 1 HC2283 1-1/8" 8" 10" 1 HC2287 1-1/8" 16" 18" 1

One 3/16" x 2" x 4", One 1/4" x 2" x 4", Two 1/4" x 4" x 6", One 5/16" x 4" x 6", One 3/8" x 4" x 6", and One 1/2" x 4" x 6" One 3/16" x 4" x 6", One 1/4" x 2" x 4", One 1/4" x 4" x 6", One 3/8" x 4" x 6", and One 1/2" x 4" x 6"

Usable Length

Overall Length Quantity

Toll Free: 877-BOSCH-99

Boschtools.com

Toll Free: 877-BOSCH-99

KD

long

l i fe

Masonry/Concrete Drilling

SDS-plus® Rotary Hammer Bits

15% more life time in concrete (compared to the last version of S4)

• Optimized brazing and hardening process for top resistance in reinforced concrete

• Optimized flute design to reduce stress and make the bit run cooler

• 4-flute design for fast dust removal

• Centric tip for optimal hole geometr y

Item # Diameter

HC2000 5/32" 2" 4" 1 HC2001 5/32" 4" 6" 1 HC2001B5 5/32" 4" 6" 5 HC2001B25 5/32" 4" 6" 25 HC2010 3/16" 2" 4" 1 HC2010B5 3/16" 2" 4" 5 HC2010B25 3/16" 2" 4" 25 HC2011 3/16" 4" 6" 1 HC2011B5 3/16" 4" 6" 5 HC2011B25 3/16" 4" 6" 25 HC2012 3/16" 6" 8" 1 HC2012B5 3/16" 6" 8" 5 HC2012B25 3/16" 6" 8" 25 HC2013 3/16" 8" 10" 1 HC2013B5 3/16" 8" 10" 5 HC2013B25 3/16" 8" 10" 25 HC2014 3/16" 10" 12" 1 HC2014B5 3/16" 10" 12" 5 HC2014B25 3/16" 10" 12" 25 HC2015 3/16" 12" 14" 1 HC2015B5 3/16" 12" 14" 5 HC2015B25 3/16" 12" 14" 25 HC2020 .202" 2-3/4" 4-3/4" 1 HC2020B5 .202" 2-3/4" 4-3/4" 5 HC2020B25 .202" 2-3/4" 4-3/4" 25 HC2021 .202" 4-1/2" 6-1/2" 1 HC2021B5 .202" 4-1/2" 6-1/2" 5 HC2021B25 .202" 4-1/2" 6-1/2" 25 HC2022 .202" 6-1/2" 8-1/2" 1 HC2022B5 .202" 6-1/2" 8-1/2" 5 HC2022B25 .202" 6-1/2" 8-1/2" 25 HC2023 .202" 7-1/2" 9-1/2" 1 HC2023B5 .202" 7-1/2" 9-1/2" 5 HC2023B25 .202" 7-1/2" 9-1/2" 25 HC2031 7/32" 4" 6" 1 HC2031B5 7/32" 4" 6" 5 HC2031B25 7/32" 4" 6" 25 HC2032 7/32" 6" 8" 1 HC2032B5 7/32" 6" 8" 5 HC2032B25 7/32" 6" 8" 25 HC2034 7/32" 10" 12" 1 HC2034B5 7/32" 10" 12" 5 HC2034B25 7/32" 10" 12" 25 HC2040 1/4" 2" 4" 1 HC2040B5 1/4" 2" 4" 5 HC2040B25 1/4" 2" 4" 25 HC2041 1/4" 4" 6" 1 HC2041B5 1/4" 4" 6" 5 HC2041B25 1/4" 4" 6" 25 HC2042 1/4" 6" 8" 1 HC2042B5 1/4" 6" 8" 5 HC2042B25 1/4" 6" 8" 25 HC2043 1/4" 8" 10" 1 HC2045 1/4" 12" 14" 1 HC2051 5/16" 4" 6" 1 HC2051B5 5/16" 4" 6" 5 HC2051B25 5/16" 4" 6" 25 HC2054 5/16" 10" 12" 1

Usable Length

Overall Length Quantity

SDS-plus® S4® Rotary Hammer Bits continued

Item # Diameter

HC2061 3/8" 4" 6" 1 HC2061B5 3/8" 4" 6" 5 HC2061B25 3/8" 4" 6" 25 HC2064 3/8" 10" 12" 1 HC2064B5 3/8" 10" 12" 5 HC2064B25 3/8" 10" 12" 25 HC2067 3/8" 16" 18" 1 HC2068 3/8" 22" 24" 1 HC2071 7/16" 4" 6" 1 HC2074 7/16" 10" 12" 1 HC2081 1/2" 4" 6" 1 HC2081B5 1/2" 4" 6" 5 HC2081B25 1/2" 4" 6" 25 HC2084 1/2" 10" 12" 1 HC2084B5 1/2" 10" 12" 5 HC2084B25 1/2" 10" 12" 25 HC2087 1/2" 16" 18" 1 HC2088 1/2" 22" 24" 1 HC2091 9/16" 4" 6" 1 HC2094 9/16" 10" 12" 1 HC2097 9/16" 16" 18" 1 HC2098 9/16" 23" 28" 1 HC2099 9/16" 31" 36" 1 HC2102 5/8" 6" 8" 1 HC2102B5 5/8" 6" 8" 5 HC2102B25 5/8" 6" 8" 25 HC2104 5/8" 10" 12" 1 HC2107 5/8" 16" 18" 1 HC2108 5/8" 22" 24" 1 HC2112 11/16" 6" 8" 1 HC2122 3/4" 6" 8" 1 HC2124 3/4" 10" 12" 1 HC2127 3/4" 16" 18" 1 HC2128 3/4" 22" 24" 1 HC2137 27/32" 6" 8" 1 HC2142 7/8" 6" 8" 1 HC2144 7/8" 10" 12" 1 HC2147 7/8" 16" 18" 1 HC2163 1" 8" 10" 1 HC2167 1" 16" 18" 1

Usable Length

Overall Length Quantity

SDS-plus® S4® Tapcon® Hex Rotary Hammer Bits

For use with Tapcon® / Condrive systems. Hex drive on bit fits into driver sleeve.

Item # Diameter

HC2301 5/32" 3" 6" 1 HC2301B25 5/32" 3" 6" 25 HC2302 5/32" 4" 7" 1 HC2302B25 5/32" 4" 7" 25 HC2310 3/16" 2" 5" 1 HC2310B25 3/16" 2" 5" 25 HC2311 3/16" 3" 6" 1 HC2311B25 3/16" 3" 6" 25 HC2312 3/16" 4" 7" 1 HC2312B25 3/16" 4" 7" 25

Usable Length

Overall Length Quantity

Tapcon® is a registered trademark of Illinois Tool Works. SDS-plus® is a registered trademark of Robert Bosch GmbH.

NOTE: Drill bits (or extension + drill bit) in excess of 8" should never exceed 600 RPM.

Masonry/Concrete Drilling

SDS-plus® Rotary Hammer Core Bits

Bosch SDS-plus® rotary hammer core bits are designed for core drilling with smaller hammers with a core body length of 4-1/8" and a usable cutting depth of 3"

Core Bit Item #

T3900 1" N/A N/A T3901 1-1/8" N/A N/A T3902 1-1/4" T3925 T3930 T3903 1-3/8" T3925 T3931 T3904 1-1/2" T3925 T3932

T3905 1-3/4" T3926 T3933 T3906 2" T3926 T3934 T3907 2-1/2" T3926 T3935 T3908 3" T3926 T3936 T3909 3-1/2" T3926 T3937 T3910 4" T3926 T3938

SDS-max®

Bit

Diameter

Center Pin

Item #

Hammer Carbide

Guide Plate

Item #

Shank Item #

4-1/8" shank

length T3917

11-7/8" shank

length T3918

4-1/8" shank

length T3919

11-7/8" shank

length T3920

SDS-max® Rotary Hammer Bits

Bosch carbide rotary hammer bits feature tips that stay sharper longer and deliver more holes within their ANSI specification than competitors’ bits. Also, Bosch shafts wear at a much slower rate than most others and can take more abuse because of Bosch’s technologically advanced conditioning process.

• Manufactured to ANSI standards, Bosch bits also meet and exceed ISO (International Standards Organization) standards. 98% of the carbide tips are molded to the specific ANSI size. Only 2% (specials) of all bit diameters are ground to size

• SDS-max® rotary hammer bits not only fit Bosch SDS-max® hammers, but also competitive SDS-max® drive hammers and Hilti hammers using TE-Y and TE-FY shanks

Item # Diameter

HC5005 3/8" 8" 13" HC5010 1/2" 8" 13" HC5011 1/2" 16" 21" HC5012 1/2" 11" 16" HC5013 1/2" 21" 28" HC5015 9/16" 8" 13" HC5016 9/16" 16" 21" HC5017 9/16" 21" 28"

Usable Length

Overall

Length

SDS-plus® Core

Shank

Thin Wall

Core Bit

Centering

Speed-Core™ Thin Core Bits

Core Bit Assembly

(1) Screw core bit onto shank

(2) Centering pin in hole

(3) Attach guide plate

Thru-Hole Bits

Bosch thru-hole bits are one-piece bits designed for fast working without the need to change shanks. The all-in-one core with SDS-max® or Spline shank transmits power directly to the end of the bit. In addition, thru-hole bits are economical due to their long life (dimensions are nominal).

Aggressive Wild-Bore

Designed for fast break-through and large chip removal

Special Flute

Designed for faster chip removal

Tip

Guide

Plate

SDS-max® Thru-hole Rotary Hammer Bits

One-piece thru-hole bits are designed for fast working without the need to change shanks. The all-in-one core with SDS-max® shank transmits power directly to the end of the bit. Additionally, thru-hole bits are economical due to their long life.

Item # Diameter

HC6501 1-3/4" 18" 24" HC6511 2-1/8" 18" 24" HC6521 2-1/2" 18" 24" HC6531 3-1/8" 18" 24"

SDS-plus® and SDS-max® are registered trademarks of Robert Bosch GmbH.

NOTE: Drill bits (or extension + drill bit) in excess of 8" should never exceed 600 RPM.

Usable Length

Overall

Length

Toll Free: 877-BOSCH-99

Thru-Hole Bit Features

• Ideal for horizontal drilling applications

• Drill all the way through material without stopping

Boschtools.com

Toll Free: 877-BOSCH-99

InZ]kh8P8¦8;nmm^kl

8\hkmZ]hk^l8

InZ]kh8P

=f[hnml8_hk^ml8

InZ]kh8P8jnZ]knie^l8

Masonry/Concrete Drilling

SDS-max® Hammer Carbide

Wild-Bore™ with Quadro-X™ Technology Rotary Hammer Bits

Narrow flute back for reduced

friction between bit and material

Main cutter is fully embedded in the drill bit body for top power and impact transmission

Quadro-X™ Enhancements: Under 1"

Shorter head with extended flutes for fast, straight dust transport

Wild-Bore™ is a specially formulated Tungsten Carbide which provides superior wear resistance in tough applications.

Quadro-X

masonry materials. This aggressive tip design is more effective when hitting rebar.

Wild-Bore

™

is a patented Four-Cutter tip design that provides optimal performance when drilling larger diameter holes in

™

with Quadro-X™ Technology Rotary Hammer Bits are available in SDS-plus®, SDS-max® and Spline shanks.

Large flute volume for fast drilling dust transport and less clogging

Secondary cutters are not connected to the main cutters, eliminating tensioning in carbide, for a longer life

1" and Larger

Larger Incline for fast

drilling dust transport

Smaller Incline for less wear and clean drilling

dust removal

Updated tip and head design provides 15% faster removal rate and 30% longer life

SDS-max® Core Bits

Bosch Core Bits with Wave Design

• Larger, cleaner holes up to 6" in diameter

• Used for vertical drilling applications

All-In-One Core

Transmits power directly

to the end of the bits

Available in SDS-max

shank

Unique design transfers energy

thru the bit more effectively for up

to 40% better drilling performance

Carbide-Tipped Active Centering Bit (Item# HC88)

Wave Design

Asymmetrical Tooth Design for Fast Cutting Speed

Tungsten carbide teeth for longer life in tough drilling applications

No Wave Wave

SDS-max® Wild-Bore™ Rotary Hammer Bits with Quadro-X™ Design

Item # Diameter

HC5020 5/8" 8" 13" HC5021 5/8" 16" 21" HC5022 5/8" 11" 16" HC5023 5/8" 31" 36" HC5026 11/16" 16" 21" HC5030 3/4" 8" 13" HC5031 3/4" 16" 21" HC5032 3/4" 11" 16" HC5033 3/4" 31" 36" HC5036 13/16" 16" 21" HC5039 27/32" 16" 21" HC5040 7/8" 8" 13" HC5041 7/8" 16" 21" HC5042 7/8" 11" 16" HC5050 1" 8" 13" HC5051 1" 16" 21" HC5052 1" 11" 16" HC5053 1" 31" 36" HC5056 1-1/16" 18" 23" HC5060 1-1/8" 10" 15" HC5061 1-1/8" 18" 23" HC5070 1-1/4" 10" 15" HC5071 1-1/4" 18" 23" HC5073 1-1/4" 31" 36" HC5076 1-5/16" 18" 23" HC5081 1-3/8" 18" 23" HC5086 1-7/16" 18" 23" HC5091 1-1/2" 18" 23" HC5096 1-9/16" 18" 23" HC5098 1-3/4" 18" 23" HC5099 2" 18" 23"

Usable Length

Overall

Length

Masonry/Concrete Drilling

SDS-max® Rotary Hammer Core Bits

Bosch SDS-max® rotary hammer core bits are carbide tipped with an integral shank for better power transmission. Maximum core size is 4" deep.

Item #

HC8501 1-3/4" 7" 12" HC8506 1-3/4" 17" 22" HC8510 2" 7" 12" HC8515 2" 17" 22" HC8521 2-5/8" 7" 12" HC8526 2-5/8" 17" 22" HC8530 3" 7" 12" HC8531 3-1/4" 7" 12" HC8536 3-1/4" 17" 22" HC8540 3-9/16" 7" 12" HC8545 3-9/16" 17" 22" HC8550 4" 7" 12" HC8555 4" 12" 17" HC8575 5' 17" 22" HC8595 6" 17" 22" HC88 Centering Bit & Drif Pin

Bit

Diameter

— — 5-5/16"

Usable Length

Overall Length

SDS-max® R-Tec

How Does R-Tec Work?

The next generation of SDS-max® chisels and points features the innovation you’ve come to expect from Bosch, the professional’s choice in concrete drilling and demolition. Reflection technology is the latest innovation in demolition steel, so Bosch has incorporated its new R-Tec reflection point into each chisel or point. With each beat of the hammer, energy is dispersed. Our new R-Tec reflection element reflects the hammer’s energy back into the work material, increasing the rate of removal by 15%. And the R-Tec chisel features a unique cutting head with extra wedges for increased breakout. Bosch SDS-max chisels and points produce faster results in less time and help increase overall jobsite productivity and profitability.

Star Point Tip

Self Sharpening, less binding

High-quality Hardened Steel

Can be re-sharpened, re-forged and provides long service life.

Bosch Marking

R-Tec

Toll Free: 877-BOSCH-99

Conventional ChiselR-Tec Chisel

The reflection element reflects the energy of the return shock and converts it into new impact energy.

Patented SDS-max® Shank

Innovative Reflection Element

Increases material removal rate by up to 15%.

Boschtools.com

Toll Free: 877-BOSCH-99

Asphalt Cutter

Bushing Tool One Piece

Scaling Chisel

Flat Chisel

Bull Point

Scraping Chisel Ground Rod Driver

Seam Tool Tamper Plate Shank

Slotting Tool

Clay Spade

SDS-max® Hammer Steel

Bosch offers a full assortment of SDS-max® hammer steel points and chisels.

Masonry/Concrete Drilling

Item # Description Size Quantity

HS1903 R-Tec flat chisel 1" x 16" 1 HS1903B10 R-Tec flat chisel 1" x 16" 10 HS1904 R-Tec bull point 16" 1

Round SpadeFloor Scraper

Winged Channel Chisel

Gouge

Tamper Plate

HS1904B10 R-Tec bull point 16" 10

HS1934*

HS1934B10*

HS1906 Asphalt cutter 5" x 15" 1

HS1909 Bushing tool, one piece

HS1910 Scaling chisel 3" x 12" 1 HS1911 Flat chisel 1" x 12" 1 HS1911B20 Flat chisel 1" x 12" 20 HS1912 Flat chisel 1" x 18" 1 HS1912B10 Flat chisel 1" x 18" 10 HS1913 Bull point 12" 1 HS1913B20 Bull point 12" 20 HS1914 Bull point 18" 1 HS1914B10 Bull point 18" 10 HS1915 Tile chisel 2" x 12" 1 HS1916 Scaling chisel 1-1/2" x 12" 1 HS1917 Scaling chisel self-sharpening 2" x 14" 1 HS1918 Floor scraper 6" x 25" 1 HS1920 Seam tool 1-1/8" x 15" 1 HS1921 Slotting tool 1-1/8" x 15" 1 HS1922 Clay spade 4-1/2" x 17" 1 HS1924 Ground rod driver 5/8" & 3/4" rods 1 HS1926 Round spade 4-1/2" x 16" 1 HS1927 Tamper plate shank 12" 1 HS1928 Winged channel chisel 1" x 15" 1 HS1929 Gouge 1" x 12" 1 HS1828 Tamper plate 5" x 5" 1

*Available 4Q 2007

SDS-max® is a registered trademark of Robert Bosch GmbH.

R-Tec Star Point chisel self-sharpening R-Tec Star Point chisel self-sharpening

16" 1

16" 10

16 tooth head, 1-3/4" square x 9-1/4"

Spline

Hammer Carbide

Spline Rotary Hammer Bits

Bosch spline rotary hammer bits are carbide tipped and fit Bosch as well as other spline hammers.

Item #

HC4501 3/8" 6" 11" HC4510 1/2" 6" 11" HC4511 1/2" 11" 16" HC4512 1/2" 18" 23" HC4513 1/2" 22" 27" HC4514 1/2" 31" 36" HC4516 9/16" 11" 16" HC4520 5/8" 6" 11" HC4521 5/8" 11" 16" HC4522 5/8" 18" 23" HC4530 3/4" 6" 11" HC4531 3/4" 11" 16" HC4532 3/4" 18" 23" HC4540 7/8" 11" 16" HC4541 7/8" 18" 23" HC4550 1" 11" 16" HC4551 1" 18" 23" HC4561 1-1/8" 18" 23" HC4571 1-1/4" 18" 23" HC4591 1-1/2" 18" 23"

Bit

Diameter

Usable Length

Overall

Length

Spline Wild-Bore™ Rotary Hammer Bits with Quadro-X™ Design

Item #

HC4020 5/8" 6" 11" HC4021 5/8" 11" 16" HC4022 5/8" 18" 23" HC4023 5/8" 22" 27" HC4024 5/8" 31" 36" HC4026 11/16" 11" 16" HC4030 3/4" 6" 11" HC4031 3/4" 11" 16" HC4032 3/4" 18" 23" HC4033 3/4" 22" 27" HC4034 3/4" 31" 36" HC4039 27/32" 11" 16" HC4040 7/8" 11" 16" HC4041 7/8" 18" 23" HC4050 1" 11" 16" HC4051 1" 18" 23" HC4053 1" 31" 36" HC4060 1-1/8" 11" 16" HC4061 1-1/8" 18" 23" HC4070 1-1/4" 11" 16" HC4071 1-1/4" 18" 23" HC4073 1-1/4" 31" 36" HC4081 1-3/8" 18" 23" HC4091 1-1/2" 18" 23"

Bit

Diameter

Usable Length

Overall Length

Spline Thru-hole Rotary Hammer Bits

Thru-hole bits offer less vibration and quieter operation thanks to an efficient design which maximizes the power of the hammer

Item #

HC6001 1-3/4" 18" 24" HC6011 2-1/8" 18" 24" HC6021 2-1/2" 18" 24" HC6031 3-1/8" 18" 24"

Bit

Diameter

Round Hex / Spline

Bushing Tool

Scaling Chisel

Bushing Head Shank

Seam Tool

Usable Length

Overall

Length

Hammer Steel

Pointed Spade

Tamper Plate Shank

Masonry/Concrete Drilling

Spline Rotary Hammer Core Bits

Bosch spline rotary hammer core bits feature an integral shank for better power transmission.

• Maximum core size of 2-5/8" deep (dimensions are nominal

Item #

HC8000 1-1/2" 7" 12" HC8005 1-1/2" 17" 22" HC8010 2" 7" 12" HC8015 2" 17" 22" HC8020 2-1/2" 7" 12" HC8025 2-1/2" 17" 22" HC8030 3-1/8" 7" 12" HC8035 3-1/8" 17" 22" HC8040 3-9/16" 7" 12" HC8045 3-9/16" 17" 22" HC8050 4" 7" 12" HC8055 4" 17" 22" HC8070 5" 7" 12" HC8075 5" 17" 22" HC89 Centering Tip — — 4-3/4"

Bit

Diameter

Usable Length

Overall Length

Flat Chisel

Bull Point

Scraping Chisel

Bosch offers a full assortment of round hex/spline hammer steel points and chisels.

Item # Description Size Quantity

HS1809 Bushing tool one piece

HS1809B10 Bushing tool one piece

HS1810 Scaling chisel 3" x 12" 1 HS1810B10 Scaling chisel 3" x 12" 10 HS1811 Flat chisel 1" x 12" 1 HS1811B20 Flat chisel 1" x 12" 20 HS1812 Flat chisel 1" x 18" 1 HS1812B10 Flat chisel 1" x 18" 10 HS1813 Bull point 12" 1 HS1813B20 Bull point 12" 20 HS1814 Bull point 18" 1 HS1814B10 Bull point 18" 10 HS1815 Scraping chisel 2" x 12" 1 HS1816 Scaling chisel 1-1/2" 12" 1 HS1817 Scaling chisel 2" x 12" 1 HS1817B10 Scaling chisel 2" x 12" 10

HS1521 Bushing head

HS1818 Bushing head shank 12" 1 HS1820 Seam tool 1-1/8" x 15" 1 HS1821 Slotting tool 1-1/8" x 15" 1 HS1822 Clay spade 4-1/2" x 16" 1 HS1822B3 Clay spade 4-1/2" x 16" 3 HS1824 Ground rod driver 5/8" & 3/4" rods 1 HS1826 Pointed spade 4-1/2" x 16" 1 HS1827 Tamper plate shank 12" 1 HS1828 Tamper plate 5" x 5" 1

Slotting Tool

Clay Spade

Ground Rod Driver

16 tooth head, 1-3/4" square x 9-1/4" 16 tooth head, 1-3/4" square x 9-1/4"

16 tooth head, 1-3/4" square

Tamper Plate

Bushing Head

3/4" Hex

Scraping Chisel

Scaling Chisel

Clay Spade

Asphalt Cutter

Bosch offers a full assortment of 3/4" hex hammer steel points and chisels.

Item # Description Size Quantity

HS1502 Scraping chisel 2" x 12" 1 HS1503 Scaling chisel 3" x 12" 1 HS1503B10 Scaling chisel 3" x 12" 10 HS1504 Clay spade 4-1/2" x 17" 1 HS1506 Asphalt cutter 5" x 15" 1

HS1521 Bushing head

HS1508 Bushing head shank 12" 1 HS1515 Bull point 12" 1 HS1515B20 Bull point 12" 20 HS1516 Bull point 18" 1 HS1516B10 Bull point 18" 10 HS1517 Flat chisel 1" x 12" 1 HS1517B20 Flat chisel 1" x 12" 20 HS1518 Flat chisel 1" x 18" 1 HS1518B10 Flat chisel 1" x 18" 10

HS1520 Bushing tool one piece

HS1520B10 Bushing tool one piece

HS1524 Ground rod driver 5/8" & 3/4" rods 1 HS1526 Pointed spade 4-1/2" x 16" 1 HS1527 Tamper plate shank 12" 1 HS1828 Tamper plate 5" x 5" 1

Hammer Steel

Bushing Head Shank

Bull Point

Flat Chisel

Bushing Tool

16 tooth head, 1-3/4" square

16 tooth head, 1-3/4" square x 9-1/4" 16 tooth head, 1-3/4" square x 9-1/4"

Pointed Spade

Tamper Plate Shank

Bushing Head

Tamper Plate

Toll Free: 877-BOSCH-99

Boschtools.com

Toll Free: 877-BOSCH-99

Masonry/Concrete Drilling

Hexagonal & SDS-max® Star-pointed Chisel More Power: New Star-pointed Chisel

20 40 60 80

Cross section of

Star-pointed Chisel

30%

Star-shaped and self-sharpening cutting edge: this means more material removal with each impact. Removal rate of star-pointed chisels remains constantly high over entire service life. This saves downtime and eliminates service costs caused by time-consuming resharpening.

Higher Removal Rate

Tip Shape Over Worklife

Brute™ 1-1/8" Hex

Narrow Chisel

3" Chisel

Clay Spade

Frost Wedge

(hours)

Hammer Steel

100

Tamper Plate

Air Tool

Moil Point

Narrow Chisel

Bosch offers a full assortment of air tool steel points and chisels. For use with pneumatic hammers only.

Item # Description

HS2260 Moil point 18" 7/8" hex 1 HS2261 Moil point 14" 7/8" hex 1 HS2262 Narrow chisel 18" 7/8" hex 1 HS2263 Narrow chisel 14" 7/8" hex 1 HS2264 3" chisel 20-1/2" 7/8" hex 1 HS2267 5" asphalt cutter 17-1/2" 7/8" hex 1 HS2269 5-1/2" clay spade 20" 7/8" hex 1 HS2360 Moil point 18" 1" hex 1 HS2361 Moil point 14" 1" hex 1 HS2362 Narrow chisel 18" 1" hex 1 HS2363 Narrow chisel 14" 1" hex 1 HS2364 3" chisel 20-1/2" 1" hex 1 HS2367 5" asphalt cutter 17-1/2" 1" hex 1 HS2369 5-1/2" clay spade 20" 1" hex 1 HS2460 Moil point 18" 1-1/4" hex 1 HS2461 Moil point 14" 1-1/4" hex 1 HS2462 Narrow chisel 18" 1-1/4" hex 1 HS2463 Narrow chisel 14" 1-1/4" hex 1 HS2464 3" chisel 20-1/2" 1-1/4" hex 1 HS2467 5" asphalt cutter 17-1/2" 1-1/4" hex 1 HS2469 5-1/2" clay spade 20" 1-1/4" hex 1

Steel

Asphalt Cutter

Clay Spade

3" Chisel

Overall

Length Shank Quantity

Superkut Chisel

Asphalt Cutter

Bosch offers a full assortment of Brute™ / 1-1/8" hex hammer steel points and chisels.

Item # Description Overall Length Quantity

HS2124 Tamper plate 6" x 6" 1 HS2125 Tamper plate 8" x 8" 1 HS2126 Tent stake driver 5-1/2" 1 HS2861 Star Point self-sharpening 16" 1 HS2161 Moil point 20" 1 HS2161B5 Moil point 20" 5 HS2863 Flat chisel 16" 1 HS2163 Narrow chisel 20" 1 HS2163B5 Narrow chisel 20" 5 HS2164 3" chisel 20" 1 HS2164B5 3" chisel 20" 5 HS2166 Superkut chisel 20-1/2" 1 HS2167 5" asphalt cutter 19" 1 HS2167B3 5" asphalt cutter 19" 3 HS2168 3" digging chisel 22-1/2" 1 HS2169 5-3/8" clay spade 21" 1 HS2169B3 5-3/8" clay spade 21" 3 HS2170 Frost wedge 24-1/2" 1 HS2171 Spike / pin driver 14-1/2" 1 HS2172 Ground rod driver 15-1/2" 1 HS2173 Tamper shank 15-1/2" 1

Spike / Pin Driver

Ground Rod Driver

Tamper ShankDigging Chisel

Tent Stake Driver

Moil Point

Adapters & Other Accessories

SDS-max® Rotary Hammer Adapters

Bosch offers adapters to make it easy to move up to SDS-max® while still utilizing your current SDS-plus® and spline accessories.

Item # Description

HA1030 SDS-max® to SDS-plus® adapter HA1031 SDS-max® to spline adapter HA1032 SDS-max® 3 jaw chuck adapter 1/2"-20 thread HA1033 SDS-max® to 3/4" hex adapter T4000 SDS-max® 9" core bit adapter shank T4001 SDS-max® 16" core bit adapter shank

Spline Rotary Hammer Adapters

Use these Bosch adapters with a spline hammer to utilize B taper and SDS-plus® accessories.

Item # Description

HA1020 Spline drive to SDS-plus® adapter T1831 Spline drive to “B”-taper adapter 1 601 030 009 Drift pin (for T1831)

SDS-plus® and SDS-max® are registered trademarks of Robert Bosch GmbH.

NOTE: Drill bits (or extension + drill bit) in excess of 8" should never exceed 600 RPM.

Bosch 11224VSR, 11253VSR, 11255VSR, 11221DVS User Manual

Specifications and Main Features

Frequently Asked Questions

User Manual
