BORK WP700P17-6 Exploded view

WP700(S)P17-6 Microwave Oven Components List (GS)

Component No. Name Model Quantity

C01 Wave filter DNV0818A-0500 1

C02 H.V.Capacitor

CH85 1.0

¦Ì

F 2100V

1

C03 Fan motor SP-6309-230 or 2Z-9DU 1
C04 H.V.Fuse T.H.V.-060T(5KV 0.7A) 1
C05 H.V.Diode HVM12(450mA) or CL01-12 1
C06 Timer KN30MCA01E or TMFM30MZA1 1
C07 Turntable motor SS-5-240-TD or TYJ50-8A7 1
C08 Transformer GAL-700E-1S 1
C09 Magnetron 2M210-M1G 1
C10 Microswitch V-5230Q or VP533B-OFB 2
C11 Microswitch V-5220Q or VP532B-OFB 1
C12 Thermostat KSD180 1
C13 Oven lamp KEI 230V 20W or MTR 230V 20W 1

WP700(S)P17-6 Microwave Oven Parts List(GS)

PART NO. NAME QUANTITY PART NO. NAME QUANTITY

P01 Knob

2

P28 Splash proof film

1

P02 Door release button

1

P29 Shaft

1

P03 Button spring

2

P30 Washer

1

P04 Control panel

1

P31 Ring wheel

3

P05 Button lever

1

P32

Roller ring

1

P06 Lower hinge

1

P33 Glass tray

1

P07 Base plate

1

P34 Mica sheet

1

P08 Foot

4

P35 Upper hinge

1

P09 Foot pin

4

P36 Sponge

1

P10 Sponge

1

P37 Exhaust guide

1

P11 Shock proof rubber

1

P38 Oven cavity

1

P12 Label

1

P39 Outer enclosure

1

P13 Microswitch mounting

1

P40 Insulating film

1

bracket P41 Air duct

1

P14 Inner rotary arm

1

P42 Lamp socket

1

P15 Outer rotary arm

1

P43 Wire harness 1 set

P16 Power cord holder

1

P44 Power cord

1

P17 Fan shroud

1

P45 Nameplate

1

P18 Sponge

1

B01 Foam cushion

2

P19 H.V.fuse holder

1

B02 Foam cushion

2

P20 Fan blade

1

B03 Owner's manual

1

P21 Capacitor holder

1

B04 Plastic bag

1

P22 Latch spring

1

B05 Plastic film

1

P23 Door latch

1

B06 Plastic bag

1

P24 Door frame 1 B07 Foam cushion

2

P25 Door window 1 B08 Carton

1

P26 Door

1

B09 Packing belt

1

P27 Choke cover

1

B10 Wrapping nail

12
