BONNET CIDELCEM GRANDE CUISINE
Siége social:
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
PREMIUM, Neutral unit on cupboard
P075281: 500 wide P075398: 1750 wide P075282: 1000 wide
GENERAL FEATURES
* One-piece 3mm thick stainless steel upper section (top and flush welded sides) permits edge-to-edge assembly and confers outstanding
sturdiness.
* Fully stainless steel construction designed to eliminate any infiltration.
* End panels in 30/10 provide exceptional strength and permit virtually flush assembly.
* Solid chrome-plated brass controls, grouped and recessed to provide protection against knocks or spillage.
* Device delivered fitted with 4 adjustable fibreglass reinforced black polyamide legs
NEUTRAL TOP
* One piece neutral top.
* Available in 500, 750 and 1000mm widths.
CUPBOARD
* Cupboard compatible with GN 1/1 trays, the stainless steel bottom has upward folded edges to divert liquid (500, 750 or 1000mm wide units).
* Doors: 500 wide (left hand hinged), 750 wide (2 doors) or 1000 wide (2 doors). Stainless steel lined with magnetic closure and insulated handle.
OPTIONS
* Blown air heating kit (not available for 750 wide units) controlled by 30/85°C thermostat with high safety limit and heating indicator.
* Fixed common 200 mm high leg stand, fitted with adjustable polyamide legs replacing fixed individual legs. (See specific data sheet).
* Mobile 200 mm high leg stand fitted with 4 stainless casters of which 2 fitted with brakes replacing fixed individual or common legs. (see specific
data sheet).
* Frame fitted on a wall or a central base
ACCESSORIES
* Storage runner kit for the cupboard (not available in width 750), top hung and removable, 4 levels at 68mm intervals to take GN 1/1 oven ware or
containers to be used as drawers. A pair for each 500mm section.
* Stainless plating rail (polished finish) 38 mm diameter per linear metre.
STANDARD
EN 60335-2-49: European standards relating to the safety of electric appliances.
(French standard: classification index C 73-849).
IP 25 and IK 9: Protection rating.
NF X 60-010: Hygiene.
: Complies with
ELECTRICAL conexion
(Leave 1.5 m cable tails)
BONNET CIDELCEM GRANDE CUISINE
Siége social:
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
P075281 P075398 P075282
MODEL
DIMENSIONS (mm)
B-B9P.DN500 B-B9P.DN750 B-B9P.DN1000
Height 1023 1023 1023
Width 500 750 1000
Depth 950 950 950
PACKAGING (mm)
Height 1150 1150 1150
Width 600 850 1100
Depth 1050 1050 1050
WEIGHT (KG)
TOP COMPRISES
65 85 105
Cupboard width 500 750 1000
ELECTRICITY (For optional heated cupboard)
Voltage Single phase 230V a.c.
Power (kW) 1 - 2
Intensity max (A) 4.5 - 9
ELECTRICAL CONNECTION
200 mm from floor
Non contractual document Edition 01/2004 – 3BE0220
