BONNET GRANDE CUISINE
Registered office:
Rue des Frères Lumière - Z.I Mitry Compans
OPTIMUM,
Electric cooking unit, 4 ELECTRIC RINGS on electric oven
4 ELECTRIC RINGS
F-77292 MITRY MORY Cedex
B1O7PE8FE
OPTIMUM ASSETS
FlushTop : Module can be butt jointed.
AirFlexSystem : Convected air onto 3 levels.
GENERAL
* Upper structure totally stainless (top 2mm thick and inset side faces in 1.5mm laser welded)
* All stainless steel construction designed to avoid any infiltration.
* Unfailing sturdy equipment for direct wall fixation.
* Controls grouped together and recessed protecting them for impact and spillages.
* Appliance delivered with 200mm fixed stand with 4 adjustable feet.
ELECTRIC RINGS
* One piece pressed top fitted with 4 cast iron rapid heat rings 220mm diameter.
* Each ring is controlled by a 6 position switch and has an indicator light.
* High limit thermostat built into each ring.
ELECTRIC OVEN
* The GN2/1 (530 x 650mm) oven cavity has a steel base, removable side runners and is insulated with rockwool.
* Heavy duty door with integral hinges that are spring counterbalanced, fitted with an insulated handle. Seal is high temperature silicone.
* Controlled by 4 position switch: Off, Top, Bottom or Both, 50/300°C thermostat and indicator light.
* Safety thermostat at 400°C.
* The oven is supplied with a nickelled GN 2/1 grill and a 40mm deep GN 2/1 tray Gastronorm.
ACCESSORIES
* See technical data : General features.
STANDARDS
EN 60335-2-36: European standards relating to the safety of electric appliances.
(French standards: Classification index C 73-836).
IP 25 and IK 9: Protection indexes.
XP U 60-010: Hygiene.
: Compliance with standards
B1O7PE8FE
ELECTRICAL connection
Electric inlet at 615mm from the floor
(Flexable cable 1.5 m in length)
BONNET GRANDE CUISINE
Registered office:
Rue des Frères Lumière - Z.I Mitry Compans
F-77292 MITRY MORY Cedex
DIMENSIONS (mm)
Width 800
Depth x Height 790 x 927
Diameter of plate 220
PACKAGING (mm)
Width 940
Depth x Height 1060 x 1150
WEIGHT (KG)
COMPOSITION OF TOP
Round plate 2.6 kW 4
COMPOSITION OF BOTTOM PART
Electric oven 5.1 kW 1
ELECTRICITY (Triphasé 230V+E or 400V+E)
Power (kW) 230V 3a.c. 15.5
400V 3a.c. 15.5
Max. Intensity (A) 230V 3a.c. 41.9
400V 3a.c. 24.1
125
Non contractual Document 01/2012 edition – 3BE B1O7PE8FE
