BONNET GRANDE CUISINE
Siège social:
Rue des Frères Lumière - Z.I Mitry Compans
OPTIMUM,
Electric cooking unit, SOLID PLATE on electric oven
SOLID PLATE
B1O7CE8FE
77292 MITRY MORY Cedex
OPTIMUM ASSETS
EasyCleaningSystem : Surface flush with the worktop.
AirFlexSystem : Convected air onto 3 levels.
GENERAL
* Upper structure totally stainless (top 2mm thick and inset side faces in 1.5mm laser welded)
* All stainless steel construction designed to avoid any infiltration.
* Unfailing sturdy equipment for direct wall fixation.
* Controls grouped together and recessed protecting them for impact and spillages.
* Appliance delivered with 200mm fixed stand with 4 adjustable feet.
SOLID PLATE
* Fitted with one special iron plates 15mm thick, offering 44 dm² for close positioning of all sizes of pan.
* The appliance is equipped with 2 round back 1700 Watt hobs and 2 square front 4000 Watt hobs allowing rapid temperature rise with virtually no
inertia.
* Each hearth is controlled by a thermostat with indicator light allowing temperature control from 80° to 500°C on 2 independent heating zones.
The cooking surface can shift from simmering to boiling or any possible combination.
* Thermal safety under each hearth.
ELECTRIC OVEN
* The GN2/1 (530 x 650mm) oven cavity has a steel base, removable side runners and is insulated with rockwool.
* Heavy duty door with integral hinges that are spring counterbalanced, fitted with an insulated handle. Seal is high temperature silicone.
* Controlled by 4 position switch: Off, Top, Bottom or Both, 50/300°C thermostat and indicator light.
* Safety thermostat at 400°C.
* The oven is supplied with a nickelled GN 2/1 grill and a 40mm deep GN 2/1 tray Gastronorm.
OPTION
* One-piece wall or central top.
ACCESSORIES
* See technical data : General features.
STANDARDS
EN 60335-2-36: European standards relating to the safety of electric appliances.
(French standards: Classification index C 73-836).
IP 25 and IK 9: Protection indexes.
XP U 60-010: Hygiene.
: Compliance with standards
B1O7CE8FE
ELECTRICAL connection
Electric inlet at 615mm from the floor
(Flexable cable 1.5 m in length)
BONNET GRANDE CUISINE
Siège social:
Rue des Frères Lumière - Z.I Mitry Compans
77292 MITRY MORY Cedex
DIMENSIONS (mm)
Width 800
Depth x Height 790 x 927
Plate 400 x 550
Useful surface (dm2) 44
PACKAGING (mm)
Width 940
Depth x Height 1060 x 1150
WEIGHT (KG)
COMPOSITION OF TOP
Front hob 4 kW 2
Rear hob 1.7 kW 2
COMPOSITION OF THE BOTTOM PART
Electric oven 5.1 kW 1
ELECTRICITY (Three-phase 400V+N+E)
Power (kW) 400V 3Na.c. 16.5
Max. Intensity (A) 400V 3Na.c. 28.4
145
Document non contractuel Edition 01/2012 – 3BE B1O7CE8FE
