Bompani BI02476-E User Manual [it]
DOUBLE DOOR REFRIGERATOR
FREEZER - FRIDGE
Instruction booklet
FRIGORIFERO A DUE PORTE
Freezer - Frigo
Manuale di istruzioni
BI02476/E
BI02480/E
Contents
BEFORE USING YOUR REFRIGERATOR ............................................ 2
General warnings ........................................................................................... 2
Old and out-of-order fridges ............................................................................ 4
Safety warnings ............................................................................................. 4
Installing and operating your fridge ................................................................. 5
Before Using your Fridge ................................................................................ 5
THE VARIOUS FUNCTION AND POSSIBILITIES .................................. 6
Thermostat Setting ........................................................................................ 6
Accessoires .................................................................................................. 6
Ice tray ........................................................................................................................... 6
ARRANGING FOOD IN THE APPLIANCE .............................................. 7
Refrigerator Compartment .............................................................................. 7
Freezer Compartment .................................................................................... 7
CLEANING AND MAINTENANCE ........................................................... 8
Defrosting ...................................................................................................... 9
Replacing The Light Bulb .............................................................................. 10
SHIPMENT AND REPOSITIONING ...................................................... 10
Repositioning the Door .................................................................................. 10
BEFORE CALLING YOUR AFTER SALES SERVICE .......................... 11
Tips for saving energy ................................................................................... 12
THE PARTS OF THE APPLIANCE AND THE COMPARTMENTS ....... 13
EN - 1 -
PART 1.
BEFORE USING YOUR REFRIGERATOR
General warnings
WARNING: Keep ventilation openings, in the appliance enclosure
or in the built-in structure, clear of obstruction.
WARNING: Do not use mechanical devices or other means to
accelerate the defrosting process, other than those recommended
by the manufacturer.
WARNING: Do not use electrical appliances inside the food storage
compartments of the
appliance, unless they are of the type recommended by the
manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: To avoid a hazard due to the instability of the appliance,
it must be fixed in accordance with the instructions.
• If your appliance uses R600a as a refrigerant – you can learn
this information from the label on the cooler- you should be careful
during shipment and installation to prevent your appliance’s cooler
elements from being damaged. Although R600a is an
environmentally friendly and natural gas. As it is explosive, in the
event of a leak due to damage to the cooler elements, move your
fridge from open flame or heat sources and ventilate the room
where the appliance is located for a few minutes.
• While carrying and positioning the fridge, do not damage the
cooler gas circuit.
• Do not store explosive substances such as aerosol cans with a
flammable propellant in this appliance.
• This appliance is intended to be used in household and similar
applications such as;
- staff kitchen areas in shops, offices and other working
environments
EN - 2 -
- farm houses and by clients in hotels, motels and other residential
type environments
- bed and breakfast type environments;
- catering and similar non-retail applications
• If the socket does not match the refrigerator plug, it must be
replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
• A specially grounded plug has been connected to the power
cable of your refrigerator. This plug should be used with a
specially grounded socket of 16 amperes. If there is no such
socket in your house, please have it installed by an authorized
electrician.
• This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazard involved.
Children shall not play with the appliance. Cleaning and user
maintenance, shall not be made by children without supervision.
• If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similar qualified persons in
order to avoid a hazard.
EN - 3 -
Old and out-of-order fridges
• If your old fridge has a lock, break or remove the lock before discarding it, because
children may get trapped inside it and may cause an accident.
• Old fridges and freezers contain isolation material and refrigerant with
CFC. Therefore, take care not to harm environment when you are discarding
your old fridges.
Please ask your municipal authority about the disposal of the W EEE for the
reuse, recycle and recovery purposes.
Notes:
• Please read the instruction manual carefully before installing and using your appliance.
We are not responsible for the damage occurred due to misuse.
• Follow all instr uctions on your appliance and instruction manual, and keep this
manual in a safe place to resolve the problems that may occur in the future.
• This appliance is produced to be used in homes and it can only be used in domestic
environments and for the specified purposes. It is not suitable for commercial or
common use. Such use will cause the guarantee of the appliance to be cancelled
and our company will not be responsible for the losses to be occurred.
• This appliance is produced to be used in houses and it is only suitable for cooling /
storing foods. It is not suitable for commercial or common use and/or for storing
substances except for food. Our company is not responsible for the losses to be
occurred in the contrary case.
Safety warnings
• Do not use multiple receptacles or extension cord.
• Do not plug in damaged, torn or old plugs.
• Do not pull, bend or damage the cord.
• This appliance is designed for use by adults, do not allow children
to play with the appliance or let them hang off the door.
• Do not plug-in or out the plug from the receptacle with wet hands to
prevent electrocution!
• Do no t place glas s bott le s or beverag e can s in th e freezer
department. Bottles or cans may explode.
• Do not place explosive or flammable material in your fridge for your
safety. Place drinks with higher alcohol amount vertically and by
closing their necks tightly in the fridge department.
• W hen taking ice made in the freezer department, do not touch it, ice
may cause ice burns and/or cuts.
• Do not touch frozen goods with wet hands! Do not eat ice-cream
and ice cubes immediately after you have taken them out of the
freezer department!
EN - 4 -
• Do not re-freeze frozen goods after they have melted. This may cause
health issues like food poisoning.
• Do not cover the body or top of fridge with lace. This affects the
performance of your fridge.
• Fix the accesso ries in the fridg e during transportation to prevent dam ag e to
accesso ries.
Installing and operating your fridge
Before starting to use your fridge, you should pay attention to the following points:
• Operating voltage for your fridge is 220-240 V at 50Hz.
• We do not take the responsibility of the damages that occur due to ungrounded
usage.
• Place your fridge in a place that it would not be exposed to direct sunlight.
• Your appliance should be at least 50 cm away from stoves, Gas
ovens and heater cores, and should be at least 5 cm away from
electrical ovens.
• Your fridge should never be used outdoors or left under the rain.
• When your fridge is placed next to a deep freezer, there should be at
least 2 cm between them to prevent humidity on the outer surface.
• Do not place anything on your fridge, and install your fridge in a
suitable place so that at least 15 cm is available on the upper side.
• The adjustable front legs should be adjusted to make sure your appliance is level
and stable. You can adjust the legs by turning them clockwise (or in the opposite
direction). This should be done before placing food in the fridge.
• Before using your fridge, wipe all parts back with warm water
added w ith a tea spoonfu l of sodium bicarbonate, and then
rinse with clean water and dry. Place all parts after cleaning.
• Install the plastic distance guide (the part with black vanes at the
rear) by turning it 90° as shown in the figure to prevent the
condenser from touching the wall.
• Refrigerator should be placed against a wall with a free distance not exceeding 75
mm.
Before Using your Fridge
• W hen it is operated for the first time or after transportation, keep
your fridge in the upright position for 3 hours and plug it on to
allo w efficient operation. O th erwise, you may damage the
co mpressor.
• Your fridge may have a smell when it is operated for the first time; the smell will fade
away when your fridge starts to cool.
EN - 5 -
PART - 2.
THE VARIOUS FUNCTION AND POSSIBILITIES
Thermostat Setting
• Therm ostat automatically reg ulates the inside temp eratu re of the refrig erator
compartment and freezer compartment.By rotating the knob from position 1 to 5,
colder temperatures can be obtained. «•» position shows thermostat is closed and
no cooling will be avaible.
• For short-term storage of food in the freezer compartment, you can set the knob
between 1 and 3 position.
• For long-term storage of food in the freezer compartment, you can set knop 3-4
position.
Note that ; the ambiant temperature, temperature of the freshly stored food and how often
th e do o r is op ened , affec t s the temper ature in the refr ige r ato r compar tment . If
required,change the temperature setting.
Accessoires
Ice tray
• Fill the ice tray with water and place in freezer compartment.
• After the water completely turned into ice, you can twist the tray as shown below to
get the ice cube.
EN - 6 -
PART - 3.
ARRANGING FOOD IN THE APPLIANCE
Refrigerator Compartment
• To reduce humidity and consequent increase of frost never place liquids in unsealed
containers in the refrigerator. Frost tends to concentrate in the coldest parts of the
evaporator and in time will require more frequent defrosting.
• Never place warm food in the refrigerator. Warm food should be allowed to cool at
room temperature and should be arranged to ensure adequate air circulation in the
refrigerator compartment.
• Nothing should touch on the back wall as it will cause frost and the pack ages can
stick on the back wall. Do not open the refrigerator door too frequently.
• Arrange the meat and cleaned fish(wrapped in pack ages or sheets of plastic) which
you will use in 1-2 days,in the bottom section of the refrigerator compartment(that is
above the crisper) as this is the c oldest section and will ensure the best storing
conditio ns.
• You can put the fruits and vegetables into crisper without packing.
Freezer Compartment
• The use of freezer is, storing of deep-frozen or frozen foods for long periods of time
and making ice cubes.
• To freeze fresh food, ensure that as m uch of the surface as possible of food to be
frozen is in contact with the cooling surface.
• Do not put fresh food with frozen on side by side as it can thaw the frozen food.
• While freezing fresh foods(i.e meat,fish and mincemeat), divide them in parts you
will use in one time.
• Once the unit has been defrosted replace the foods into freezer and remember to
consume them in as short period of tim e.
• Never place warm food in the freezer compartment. As it will disturb the frozen foods.
• For storing the frozen foods;the instructions shown on frozen food packages should
always be followed carefully and if no inform ation is provided food should not be
stored for more than 3 months from the purchased date.
• Wh en buying fr o ze n fo o ds ensure that the s e have bee n froze n at suit able
temperatures and that the packing is intact.
• Frozen foods should be transported in appopriate containers to m aintain the quality
of the food and should be returned to the freezing surfaces of the unit in the shortest
possible time.
• If a package of frozen food shows the sign of humidity and abnorm al swelling it is
probable that it has been previously stored at an unsuitable temperature and that
the contents have deteriorated.
• The strorage life of froozen foods depends on the room temper ature, therm ostat
setting, how often the door is opened, the type of food and the length of time required
to transport the product from the shop to your home. Always follow the instruductions
printed on the package and never exceed the maximum storage life indicated.
Not that; if you want to open again immediately after closing the freezer door, it will not be
opened easily. It’s q uite normal! After reaching equilib rium condition, the doo r will be
opened easily.
EN - 7 -
PART - 4.
• Make sure to unplug the fridge before starting to clean it.
• Do not wash your fridge by pouring water.
• You can wipe the inner and outer sides with a soft cloth
or a sponge using warm and soapy water.
• Remove the parts individually and clean with soapy water.
Do not wash in washing machine.
• Never use flammable, explosive or corrosive material like
thinner, gas, acid for cleaning.
CLEANING AND MAINTENANCE
• You should clean the condenser with broom at least once
a year in order to provide energy saving and increase
the productivity.
Make sure that your fridge is unplugged while cleaning.
EN - 8 -
Loading...
