transformer by rupert neve designs
BOOST WITH BLOOM
The Bogner Harlow is a unique boost pedal with a “Bloom” compression feature, which serves
up dynamic three-dimensional punch and tastefully transparent squeeze. Delivering a wide range
of boost - from crystal-clear light boost to a thick and meaty high-output assault on your amp’s
input section – you’ll never want to turn it off. At the heart of the Harlow is a custom audio
transformer created by legendary audio pioneer Mr. Rupert Neve.
®
LEVEL
Sets the amount of the boost level
BLOOM
Adjusts the amount of compression.
Most of the effect can be heard in the
first half of the control.
TONE
Adjusts the tonal coloring of the
boosted signal. Center position of
the control is flat (transparent with
no tonal coloring). Turning clockwise
increases the highs and diminishes
the bass. Turning counter clockwise
will have the opposite effect of
increasing the bass and diminishing
the highs.
FOOTSWITCH
Engages and true bypasses the pedal.
JEWEL LIGHT
The jewel light with illuminate red
when the pedal is turned on. The light
will react to the dynamics of your
playing, depending on the output
level of your instrument.
AUDIO CONNECTORS
The input is on the right side
indicated by a triangle on the top
panel. The output is on the opposite
left side.
POWER
9 volt DC, 50mA or greater, negative
tip, power connector or internal 9V
battery (accessible by removing the
bottom plate).
Mr. Rupert Neve is a living legend renowned for having designed
professional recording equipment and early large-format mixing
consoles which feature outstanding sound thanks to his custom
transformer-coupled inputs and outputs. Countless iconic rock and
roll records were cut with Mr. Neve’s equipment including such
classics as “Rumours” by Fleetwood Mac, “Damn the Torpedoes”
by Tom Petty and the Heartbreakers, and Nirvana’s “Nevermind”
to name just a few.
Mr. Neve has received the Lifetime Achievement Technical Grammy
Award, is an inducted member of the Mix Hall of Fame, has been
named man of the century by Studio Sound Magazine and was
selected by his peers as the number one audio personality of the
20th century, and continues to design into the 21st century…
Masterminds Reinhold Bogner and Mr. Rupert Neve have
teamed up to produce superb audio-effects pedals that serve up
rich, buttery tones, ultra-dynamic response and a stunning, three-
dimensional sound quality inspired by the classic mixing consoles
STUDIO SERIES
The Harlow, Wessex and Burnley are available in a Bubinga exotic
hardwood top panel, reminiscent of vintage mixing consoles from the
60’s. Each panel is formed, sanded, lasered and finished by hand
in our Los Angeles custom shop.
studio series
WARRANTY
BOGNER PEDALS LIMITED WARRANTY Bogner offers a three (3) year warranty to the original
purchaser that this Bogner product will be free from defects in material and workmanship. A dated sales
receipt will establish coverage under this warranty. This warranty does not cover service or parts to repair
damage caused by accident, neglect, normal & wear, disaster, misuse, abuse, negligence, inadequate packing
or shipping procedures and service, repair or modifications to the product which have not been authorized or
approved by Bogner. If this product is defective in materials or workmanship as warranted above, your sole
remedy shall be repair or replacement as provided below.
RETURN PROCEDURES
In the unlikely event that a defect should occur, follow the procedure outlined below. Defective products
must be shipped, together with a dated sales receipt, freight pre-paid and insured directly to Bogner. A
Return Authorization Number must be obtained from our Customer Service Department prior to shipping the
product. Products must be shipped in their original packaging or its equivalent; in any case, the risk of loss
or damage in transit is to be borne by the purchaser. The Return Authorization Number must appear in large
print directly below the shipping address. Always include a brief description of the defect, along with your
correct return address and telephone number.
DISCLAIMER: This Bogner pedal features an audio transformer designed by Mr. Rupert Neve of Rupert
Neve Designs. The word/name Neve® is a registered trademark of AMS Neve Ltd. and is in no way affiliated
with this product.
CUSTOMER SUPPORT
Our dedicated staff is ready to help you with any warranty
or product questions at 818-765-8929 (9:00AM - 4:00PM)
Pacific Standard Time.
When calling to inquire about a returned product, always refer to the Return Authorization Number.
If Bogner determines that the unit was defective in
materials or workmanship at any time during the warranty period, Bogner has the option of repairing or
replacing the product at no additional charge, except as set forth below. All replaced parts become a
property of Bogner. Products replaced or repaired under this warranty will be returned via ground shipping
within the United States-freight prepaid. Bogner is not responsible for costs associated with expedited
shipping, either to Bogner or the return of the product to the customer.
INCIDENTAL OR CONSEQUENTIAL DAMAGE In no event is Bogner liable for any incidental or
consequential damages arising out of the use or inability to use of any Bogner product, even if an Bogner
dealer has been advised of the possibility of such damages, or any other claim by any other party. Some
states do not allow the exclusion or limitation of consequential damages, so the above limitation and
exclusion may not apply to you. This warranty gives you specific legal rights and you may also have other
rights which may vary from state to state.
FOR YOUR PROTECTION
Please complete the online warranty registration within (10) ten days of the date of purchase so that we
may contact you directly in the event a safety notification issued in accordance with the 1972 Consumer
Product Safety Act.
bogneramplification.com
© 2014 Bogner Amplification
printed in U.S.A.
