Boekel
Orbitron V
Models 281111, 281111-2
Operating Instructions
N2400331 Rev. 2 01/2012
2
Table of Contents
Operating Instructions .................................................................... 1
1.0 Safety .................................................................................... 4
2.0 Product Information ............................................................. 5
3.0 Assembly .............................................................................. 5
3.1 Unpacking the Unit ......................................................................... 5
3.2 Installation ....................................................................................... 5
4.0 Operation ............................................................................. 5
4.1 Identification of Controls (See Figure 1) ....................................... 5
4.2 Timer Operation .............................................................................. 6
4.3 Tray Angle Adjustment (See Figure 2) .......................................... 6
5.0 Technical Specification s ..................................................... 7
6.0 Accessories .......................................................................... 7
7.0 Fault Diagnosis ..................................................................... 7
8.0 Maintenance and Service .................................................. 8
8.1 Cleaning .......................................................................................... 8
8.2 Replacement of Fuses .................................................................... 9
9.0 Warranty ............................................................................... 9
10.0 Service ................................................................................ 10
3
Figure 1
Rotator Front Panel
Power Switch Speed Control Timer Control
4
1.0 Safety
The following symbol marked on the equipment means:
Caution: R ead these operating instructions fully before use and pay
particular attention to sections containing this symbol.
Attention: Suivre attentivement les instructions avant l’usage et
prêtez une attention particulière aux sections comportant ce
symbole.
Always observe the following safety precautions :
• Use only as specified by the ope rating instructions or the intrinsic
protection may be impaired.
• After transport or storage in humid cond i ti on s, dry out the unit
before connecting it to the supply volta ge. During drying out
the intrinsic protection may be impaired.
• Do not lift the Rotator by the Tray.
• Risk of Binding: Assure that other equipment close to the Rotator
does not cause interference with the tray movement.
• Connect only to a power supply that provides a safety ground
terminal.
• Before moving, disconnect at the power supply socket. Do no t
remove the plug from the rear of the unit.
• Ensure that the power switch is easily accessible during use.
• Do not block or restrict ventilation slots.
• If liquid is spilled on top of the unit, disconnect it from the power
supply and have it checked by a competent person.
• It is the user’s responsibility to carry out the appropriate
decontamination if hazardous material is spilled on or inside the
equipment.
• This product must be used with an UL / CSA Certified power
supply cord set rated for a minimum temperature of 90˚C.
• The Power Cord supplied with the unit is the disconnect means.
• Do not position the unit so that it is difficult to operate the
disconnecting means.
• Caution should be taken when operating the Orbitron V with
heavy loads at high speed. Always start the Orbitron V at low
speed and gradually increase the speed to the desired setting.
5
2.0 Product Information
The Boekel Orbitron V is a heavy duty 3-Dimensional gyratory mixer that
is designed for gentle as well as vigorous agitation, making it suitable
for a wide variety of applications. The Orbitron V is supplied with a 30
cm square platform and a non skid rubber mat.
3.0 Assembly
3.1 Unpacking the Unit
Remove the packing materials carefully, and retain for future
shipment or storage of the unit. Inspect for damage. Report all
shipping damage to the carrier immediately. Shipping damage is
covered by the carrier and repair/replacement for shipping
damages must be coordinated through the carrier. Complete and
return the Warranty Registration Card. Packages should contain:
Orbitron V
Power line cord
One 3/16” Hex key for tilt adj ustment
Operating instructions
3.2 Installation
Place the Orbitron V on a clean, flat, and stable work surface to
ensure that the suction feet on the base of the unit will adhere to
the surface and adequately secure the system for use. Make sure
that the unit is placed a minimum of 8” from the edge of the
workbench and there is adequate clearance for the tray rotation to
ensure user safety.
4.0 Operation
4.1 Identification of Controls (See Figure 1)
The Power Switch controls power to the unit.
The Speed Adjustment Knob is used to increase or decrease the
rotational speed of the platform.
Note: The Orbitron V is equipped with a soft start motor control
feature. Upon activation of the speed control the motor will
have a three second delay and softly start the shaking
motion.
The Timer is used for timed operation. The maximum timer duration
is 12 hours.
6
4.2 Timer Operation
For continuous operation turn the Timer to the Hold position. The
unit will continue to operate until either the timer is turned off, or
until the power switch is turned off. For timed operation turn the
Timer until the pointer is aligned with the desired time. The timer
markings are in hour units. The unit will shut off when the time
expires.
4.3 Tray Angle Adjustment (See Figure 2)
Warning! Remove power from the equipment before adjusting Tr ay
angle.
• Remove load from Tray.
• Rotate Speed Adjustment Knob counterclockwise until the
Tray is rotating slowly.
• When the pivot block is easily accessible for adjustment turn
the Power Switch off.
• Insert the supplied 3/16” hex key into the Tightening Screw
and turn it counterclockwise to loosen the screw.
• To Increase the Tray angle, pivot the tray clockwise to a
maximum set angle of 12°.
• To decrease the Tray angle, pivot the platform
counterclockwise to a minimum set angle of 0°.
• After adjusting the angle, tighten the Tightening Screw turning
it clockwise until it is tight.
• Remove hex key and ensure that there are no obstructions
before starting the operation the Orbitron V.
Figure 2
7
5.0 Technical Specificati ons
Ambient Operating
Temperature
0°C to 40°C
Tilt Range
0° to 1 2°
Load Capacity
9 Kg (20 lb)
Supply Ratings
Model 281111: 115 VAC ± 10%, 0.73 A, 60 Hz
50/60 Hz
Power Rating
Model 281111: 50 W
Model 281111-2: 60 W
Rotational Speed
Variable from 5 to 120 rpm
Model Number
Description
260312
Double Stacking Tray
C2202208
Dimpled Rubber Mat
Symptom
Possible Cause
Action Required
Unit does not operate
a. Unit not switched on
a. Switch on
same circuit are
This equipment is for indoor use only and will meet its performance
figures within the ambient temperature range of 0°C to 40°C, with
maximum relative humidity of 80% non-condensing. Installation
category II (transient voltages). Pollution degree 2 in accordance
with IEC 664. F or operation at al titudes of up to 2000 m eters (6500
feet).
Model 281111-2: 230 VAC ± 10%,, 0.7 A,
This product has been tested to the requirements of CAN/CSA later version of the same standard incorporating the same
level of testing requirements.
6.0 Accessories
7.0 Fault Diagnosis
b. Unit not plugged
into power su p ply
c. Fuses blown
d. Power supply failure
b. Plug in, switch on
c. Replace fuses (see
section 8.2)
d. Check that other
electrical
appliances on the
8
working
No rotation
a. Speed Adjustment
a. Turn Speed
service person
8.0 Maintenance and Service
8.1 Cleaning
Knob is positioned
to off position.
b. An obstruction
prevents tray
rotation
c. Motor failure
Adjustment Knob
clockwise until
desired rotation
speed is reached
b. Remove obstruction
c. Have unit checked
by a competent
All Boekel laboratory products are designed to comply with
IEC1010-1. No routine maintenance is required.
Disengage power cord prior to cleaning. If a spill occurs, use
appropriate clean-up procedures as required for radiation or
biohazard control. The outer casing can be cleaned with a cloth
dampened with water. Periodic inspection of the work surface
should be performed to ensure that the surface is clean and the
suction feet on the base of the unit adhere to the work surface to
stabilize the system for use. Do not immerse the Orbitron V in water.
9
Fuse
Drawer
Figure 3
8.2 Replacement of Fuses
There are two supply fuses located in the fuse drawer. To change
the fuses:
Turn power switch to the off position
Disconnect the unit from the power supply
Remove the line cord from the power entry module on the
back of the unit
Pull back on the fuse drawer catch
Pull out the fuse drawer (See Figure 3)
Check and replace with the correct fuses if necessary. The
fuses should be 5mm x 20mm quick acting, rated 250V for
230V units, 5mm x 20mm time delay, rated 250V for 115V units.
Model 281111 (115 V AC): 1.25AT
Model 281111-2 (230 V AC): 1.00AF
Push the fuse drawer back in. Reconnect unit to power
supply.
9.0 Warranty
When used in laboratory conditions and according to these
operating instructions, Boekel warrants this product to be free of
defective material and workmanship for a period of two years from
the date of manufacture. The liability of Boekel for any defective
equipment during the warranty period shall be limited to the repair
of such equipment or replacement thereof without charge for parts
or labor.
10
10.0 Service
Should service be required, contact Boekel Scientific Customer
Service. A Returned Material Authorization (RMA) number is
required before this Boeke l product can be returned for any reason.
A Decontamination Certificate must be completed, signed by the
user, and returned to Boekel Scientific prior to receiving the RMA
number. Please be sure to mark the outside of the returned goods
package with this RMA number to ensure prompt handling.
Boekel Scientific
855 Pennsylvan i a Boulevard
Feasterville, PA 19053
Phone: (215) 396-8200 or (800) 336-6929
Fax: (215) 396-8264
e-mail: boekel-info@boekelsci.com
