BLUESHAPE MVQUICKAB User Manual

HOT SWAP SYSTEM

FOR V-LOCK LITHIUM ION BATTERIES AND CONVERSION TO
EQUIPMENT WITH 3-STUD GOLD MOUNT

Model

MVQUICKAB

OPERATING INSTRUCTIONS

Revision 2.1

www.blueshape.net Printed in Malta 2012

The user is being alerted of the importance o

f

going through the literature accompanying this
product and getting familiarised with the important
safety and operating instructions, included.

Please follow the safety instructions below.

- Protect the equipment from humid environments.

- Avoid any contact with water or other fluids.

- Do not use if any liquid has been accidentally spilled inside the
equipment.

- Avoid usage near extreme heat sources such as fireplaces,
radiators, stoves or other heat generating equipment.

- Clean only by using a dry cloth.

- Contact qualified service personnel for inspection or repair.

- Read the supplied instructions thoroughly and keep handy.

- Use only as instructed by the manufacturer

- Do not remove cover or dismantle the apparatus. No user­serviceable parts inside

Contents:

 1 x MVQUICKAB
 1 x Liion battery charger 16.8V/3A with mains cord
 1 x operating manual

Technical specifications:

Internal battery:
Type Li-Ion rechargeable
Charger Li-ion 16.8V / 3A with bi-coloured LED
Nominal voltage 14.4V
Nominal capacity 1.5Ah – 21Wh
Max. discharge current 10A

Operating temperature range -20°C ~ +60°C (-4°F ~ +140°F)

2

Storage temperature range 0°C ~ +30°C (32°F ~ 86°F)

Dimensions 142 x 83 x 50mm
Weight 488g

At our own responsibility we declare that this product is CE certified.

Introduction

MVQUICKAB is a hot swap system to be installed as a battery
interface between a V-lock battery and a camera (or any other 3­Stud gold mount compatible device).
The main purpose is to allow camera battery replacement without
any power interruption through an automatic detection of the battery
removal.
Additionally, MVQUICKAB provides an alternative power source of
about 21Wh to be used as UPS in case of a sudden power failure or
extended power requirements.

MVQUICKAB graphic description

1

2

3

1. Installation interface for external V-Lock battery

2. D-Tap connector (on opposite site, not visible in drawing)

D-Tap rating at 14.8 V / 5 A max. 70 Watts

3. LED indicators showing state of charge of internal battery

4. Bottom with 3-Stud gold mount

5. Charging connector

4

5

3
