Blue Rhino GBT702W-C User Manual

OWNER’S MANUAL

Made from 70% Bagasse

(Environmentally Friendly Sugar

Cane Pulp By-product)

Outdoor LP Gas Barbecue Grill

Model No. GBT702W-C

WARNING

FOR YOUR SAFETY:

For Outdoor Use Only

(outside any enclosure)

WARNING

FOR YOUR SAFETY:

1. Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage.

2. Read the installation, operation, and maintenance instructions thoroughly before installing or servicing this equipment.

3. Failure to follow these instructions could result in ﬁre or explosion, which could cause property damage, personal injury, or death.

Table of Contents

Important Safeguards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 2

Exploded View & Hardware. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Assembly Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Operating Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Checking for Leaks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

First Use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Lighting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Turning Off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Cooking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Tips. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Cleaning and Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Product Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Save these instructions for future reference. If you are assembling this unit for someone else, give this manual to him or her to read and save for future reference.

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

The use and installation of this product must conform to local codes. In absence of local codes, use the National Fuel Gas Code, ANSI Z223.1/NFPA 54, CAN/CGA-B149.1,

Natural Gas and Propane Installation Code.

Manufactured in China for: Blue Rhino Global Sourcing, Inc Winston-Salem, NC USA

1.800.762.1142, www.bluerhino.com

Outdoor LP Gas Barbecue Grill Model No. GBT702W-C

DANGER

If you smell gas -

1. Shut off gas to appliance.

2. Extinguish any open flame.

3. Open lid.

4. If odor continues, keep away from the appliance and immediately call your gas supplier or your fire department.

DANGER: Failure to follow the dangers, warning and cautions in this manual may result in serious bodily injury or death, or in a fire or an explosion

causing damage to property.

WARNING: This grill is for outdoor use only, and shall not be used in a building,

garage, or any other enclosed area. This grill is NOT for commercial use. This is not a tabletop grill. Therefore, do not operate this grill on any type

of tabletop surface This grill is for use with liquid propane (LP) gas only. The conversion to

or attempted use of natural gas in this LP gas grill is dangerous and will

void your warranty.

LP gas Characteristics: a. LP gas is flammable and hazardous if handled improperly. Become

aware of the characteristics before using any LP gas product.

b. LP gas is explosive under pressure, heavier than air, and settles and

pools in low areas.

c. LP gas in its natural state has no odor. For your safety, an odorant is

added that smells like rotten cabbage.

d. Contact with LP gas can cause freeze burns to skin.

LP gas tank needed to operate. Only tanks marked “propane” may be

used. The LP gas supply tank must be constructed and marked in accordance

with the Specifications for LP gas Cylinders of the U.S. Department of

Transportation (DOT) or the National Standard of Canada, CAN/CSA-B339,

Cylinders, Spheres and Tubes for the Transportation of Dangerous Goods;

and Commission.

LP gas tank must be arranged for vapor withdrawal. Dented or rusted LP gas tanks may be hazardous and should be checked

by your LP gas supplier prior to use. The LP gas tank should not be dropped or handled roughly. LP gas tanks must be stored outdoors out of the reach of children and

must not be stored in a building, garage, or any other enclosed area. Your

tank must never be stored where temperatures can reach over 125°F. Never attempt to attach this grill to the self-contained LP gas system of

a camper trailer, motor home, or house. The use of alcohol, or prescription or non-prescription drugs may

impair the consumer’s ability to properly assemble or safely operate the

appliance. Never use charcoal, lighter fluid, lava rocks, gasoline, kerosene, or

alcohol with this product. Your grill has been checked at all factory connections for leaks. Recheck

all connections, as movement in shipping can loosen connections. Check for leaks even if your unit was assembled for you by

someone else. Do not operate if gas leak is present. Gas leaks may cause a fire or

explosion. You must follow all leak-checking procedures before operating. To

prevent fire or explosion hazard when testing for a leak:

a. Always perform leak test before lighting the grill and each time the

tank is connected for use.

b. No smoking. Do not use or permit sources of ignition in the area

while conducting a leak test. c. Conduct the leak test outdoors in a well-ventilated area. d. Do not use matches, lighters, or a flame to check for leaks. e. Do not use grill until any and all leaks are corrected.

If you are unable to stop a leak, disconnect the LP gas supply. Call

our customer care, gas appliance serviceman or your local LP gas

supplier.

Do not use in an explosive atmosphere. Keep grill area clear and free

from combustible materials, gasoline and other flammable vapors and liquids.

Keep all combustible items and surfaces at least 21 inches (53 cm) away

from the grill at all times. DO NOT use this grill or any gas product under any overhead or near any unprotected combustible constructions.

It is essential to keep the grill’s valve compartment, burners, and

circulating air passages clean. Inspect grill before each use.

Do not alter grill in any manner.

1. Do not store spare LP cylinder within 10 feet (3.05 m) of this appliance.

2. Do not store or use gasoline or other liquids with flammable vapors within 25 feet (7.62 m) of this or any other appliance.

3. An LP cylinder not connected for use shall not be stored in the vicinity of this or any other appliance.

Do not use the grill unless it is COMPLETELY assembled and all parts are

securely fastened and tightened. This grill should be thoroughly cleaned and inspected on a regular basis. Use only the regulator provided. Any replacement regulator shall be

specified by the manufacturer. Use only Blue Rhino Global Sourcing, Inc. factory authorized parts. The

use of any part that is not factory authorized can be dangerous. This will

also void your warranty. Do not use this appliance without reading “Operating Instructions” in

this manual. Do not touch metal parts of grill until it has completely cooled (about

45 min.) to avoid burns, unless you are wearing protective gear (pot

holders, gloves, BBQ mittens, etc.). Do not install or use in or on boats or recreational vehicles. When cooking, fire extinguishing materials shall be readily accessible.

In the event of an oil grease fire, do not attempt to extinguish with water.

Use type BC dry chemical fire extinguisher or smother with dirt, sand or

baking soda. Do not use grill in high winds. Never lean over the grill when lighting. Do not leave a lit grill unattended, especially keep children and pets

away from grill at all times. Do not attempt to move grill when in use. Allow the grill to cool before

moving or storing. Storage of grill indoors is permissible only if the tank is disconnected,

removed from the grill and properly stored outdoors. While wearing a protective glove or mit, open grill lid carefully and

slowly as heat and steam trapped within grill can severely burn you. Do not attempt to disconnect the gas regulator from the tank or any gas

fitting while the grill is in use. Disconnect cylinder when not in use. Always use your grill on a hard, non-combustable level surface. An

asphalt or blacktop surface may not be acceptable for this purpose. Do not use directly on wooden decks. Keep all electrical cords away from a hot grill. Do not use grill for indoor cooking or heating. TOXIC fumes can

accumulate and cause asphyxiation. After a period of storage and/or nonuse, check for leaks, and burner

obstructions. Failure to open lid while igniting the grill’s burner, or not waiting 5

minutes to allow the gas to clear if the grill does not light, may result in

an explosive flame-up. If grill is not in use, the gas must be turned off at the supply tank. Never operate grill without heat plate installed. Always use a meat thermometer to ensure food is cooked to a safe

temperature. Do not store a spare LP gas tank under or near this appliance. Please use protective gloves when assembling this product. Do not force parts together as this can result in personal injury or

damage to the product. Never cover entire cooking area with aluminum foil.

Deaths, serious injury or damage to property may occur if the above is

not followed exactly.

WARNING

FOR YOUR SAFETY

Contact 1.800.762.1142 for assistance. Do not return to place of purchase.

page no.

Parts List

Lid Handle

Cooking Grid

Lid

Heat Plate

Top Hinge (2)

Burner

Igniter Wire

Bottom Hinge (2)

Side Handle (2)

Handle Heat Plate (2)

Warming Rack

Heat Plate Support (2)

55-07-195

55-07-187

55-07-194

55-07-191

55-07-204

55-07-186

55-15-059

55-14-712

55-07-203

55-07-189

55-07-205

55-07-192

Exploded View

Bottom Bowl

Wind Cover

Lock

Igniter

Left Leg Assembly

Right Leg Assembly

Regulator/Control Valve

55-07-185

55-07-209

55-07-196

55-14-988

55-07-193

55-07-199

55-14-720

Hardware

A B C D E F G

Screw

Bolt

Wing Nut

M4x12 Nickel Plated Phillips Truss Head

M5x12 Nickel Plated Phillips Truss Head

M6x12 Nickel Plated Phillips Truss Head

M6x12 Zinc Plated

M4 Steel

M5 Steel

M6 Steel

2 pcs

6 pcs

4 pcs

2 pcs

6 pcs

10 pcs

Tools Required for Assembly (Not Included)

#2 Phillips Head Screwdriver

I J K L

N O P

Washer

Lock Washer

Cotter Pin

ø4 Zinc Plated

ø5 Zinc Plated

ø6 Zinc Plated

ø6 Heat Resistant

ø4 Zinc Plated

ø5 Zinc Plated

ø6 Zinc Plated

ø5 x 30 Zinc Plated

ø1.4 x 30 Steel

2 pcs

6 pcs

11 pcs

9 pcs

2 pcs

6 pcs

11 pcs

2 pcs

Assembly Instructions

Outdoor LP Gas Barbecue Grill Model No. GBT702W-C

DO NOT RETURN PRODUCT TO STORE.

For assistance call 1.800.762.1142 toll free. Please have your owner’s manual and serial number available for reference.

For Easiest Assembly:

• To avoid losing any small components or hardware, assemble your product on a hard level surface that does not have cracks or openings.

• Clear an area large enough to layout all components and hardware.

• When applicable, tighten all hardware connections by hand first. Once the step is completed go back and fully tighten all hardware.

• Follow all steps in order to properly assemble your product.

To complete assembly you will need:

• (1) Leak Detection Solution (Instructions on how to make solution are included in “Operating Instructions” section)

• (1) 14.1 oz or (1) 16.4 oz LP gas tank.

Note: You must follow all steps to properly assemble grill.

Attach Lid Handle and Top Hinges

x 2

Typical assembly: approximately 30 minutes.

Attach Bottom Hinges and Buckle

x 2

x 4

x 2

Attach Side Handles, Heat Plate Supports and Igniter

x 2

x 4

x 2

x 4

x 2

x 4

x 1

x 4

x 5

x 1

x 5

Contact 1.800.762.1142 for assistance. Do not return to place of purchase.

page no.

Unfold Legs

Attach Legs

Attach Burner and Igniter Wire

Attach Wind Guard

x 4

Attach Regulator/Control Valve

Note: Once attached, the regulator/control valve will freely rotate to accomodate for the LP gas tank.

x 1

Assembly Instructions (continued)

Outdoor LP Gas Barbecue Grill Model No. GBT702W-C

Attach Lid

Insert Warming Rack

Insert Heat Plate

x 2

Lock Lid

Insert Cooking Grid

Unlock Lid
