Blue Rhino GBC873W-C User Manual

GOLD

OWNER’S MANUAL

Made from 70% Bagasse

(Environmentally Friendly Sugar

Cane Pulp By-product)

Outdoor LP Gas Barbecue Grill

Model No. GBC873W-C

WARNING

FOR YOUR SAFETY:

For Outdoor Use Only

(outside any enclosure)

WARNING

FOR YOUR SAFETY:

1. Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage.

2. Read the installation, operation, and maintenance instructions thoroughly before installing or servicing this equipment.

3. Failure to follow these instructions could result in ﬁre or explosion, which could cause property damage, personal injury, or death.

Table of Contents

Important Safeguards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Page 2

Exploded View & Hardware. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Assembly Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Installling LP Gas Tank . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Insert LP Gas Tank. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Secure LP Gas Tank. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Connect LP Gas Tank. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10

Operating Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Checking for Leaks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Operating Main Burners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Operating Sear Burner. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Operating Side Burner. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Operating Infrared Back Burner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Save these instructions for future reference. If you are assembling this unit for someone else, give this manual to him or her to read and save for future reference.

Operating Digital Timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Cleaning and Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Product Registration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Limited Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

The use and installation of this product must conform to local codes. In absence of local codes, use the National Fuel Gas Code, ANSI Z223.1/NFPA 54, CAN/CGA-B149.1,

Natural Gas and Propane Installation Code.

Manufactured in China for: Blue Rhino Global Sourcing, Inc Winston-Salem, NC USA

1.800.762.1142, www.bluerhino.com

GOLD

Outdoor LP Gas Barbecue Grill Model No. GBC873W-C

DANGER

If you smell gas -

1. Shut off gas to appliance.

2. Extinguish any open flame.

3. Open lid.

4. If odor continues, keep away from the appliance and immediately call your gas supplier or your fire department.

DANGER: Failure to follow the dangers, warning and cautions in this manual may result in serious bodily injury or death, or in a fire or an explosion

causing damage to property.

WARNING: This grill is for outdoor use only, and shall not be used in a building,

garage, or any other enclosed area.

Do NOT operate, light or use this appliance within 8 feet of walls,

structures or buildings. This grill is NOT for commercial use. This grill is for use with liquid propane (LP) gas only. The conversion to

or attempted use of natural gas in this LP gas grill is dangerous and will

void your warranty. LP gas Characteristics:

a. LP gas is flammable and hazardous if handled improperly. Become

aware of the characteristics before using any LP gas product.

b. LP gas is explosive under pressure, heavier than air, and settles and

pools in low areas.

c. LP gas in its natural state has no odor. For your safety, an odorant is

added that smells like rotten cabbage.

d. Contact with LP gas can cause freeze burns to skin.

LP gas tank needed to operate. Only tanks marked “propane” may be

used. The LP gas supply tank must be constructed and marked in accordance

with the Specifications for LP gas Cylinders of the U.S. Department of

Transportation (DOT) or the National Standard of Canada, CAN/CSA-B339,

Cylinders, Spheres and Tubes for the Transportation of Dangerous Goods;

and Commission.

LP gas tank must be arranged for vapor withdrawal. The LP gas tank must have a listed overfilling prevention device (OPD). Only use 20-pound cylinders equipped with a cylinder connection device

compatible with the connection for outdoor cooking appliances. The LP gas tank must have a tank collar to protect the tank valve. Never use an LP gas tank with a damaged body, valve, collar, or footing. Dented or rusted LP gas tanks may be hazardous and should be checked

by your LP gas supplier prior to use. The LP gas tank should not be dropped or handled roughly. Tanks must be stored outdoors out of the reach of children and must not

be stored in a building, garage, or any other enclosed area. Your tank

must never be stored where temperatures can reach over 125°F. Never keep a filled LP gas tank in a hot car or car trunk. Heat will cause

the gas pressure to increase, which may open the relief valve and allow

gas to escape. Place dust cap on cylinder valve outlet whenever the cylinder is not in

use. Only install the type of dust cap on the cylinder valve outlet that is

provided with the cylinder valve. Other types of caps or plugs may result

in leakage of propane. Do not store a spare LP gas tank under or near this appliance. Never fill the tank beyond 80 percent full. A fire causing, serious injury or damage to property may occur if the

above is not followed exactly. Never attempt to attach this grill to the self-contained LP gas system of

a camper trailer, motor home, or house. The use of alcohol, or prescription or non-prescription drugs may

impair the consumer’s ability to properly assemble or safely operate the

appliance. Never use charcoal, lighter fluid, lava rocks, gasoline, kerosene, or

alcohol with this product. Your grill has been checked at all factory connections for leaks.

Recheck all connections as described in the “Operating Instructions”

section of the manual, as movement in shipping can loosen connections. Check for leaks even if your unit was assembled for you by someone

else. Do not operate if gas leak is present. Gas leaks may cause a fire or

explosion. You must follow all leak-checking procedures before operating. To

prevent fire or explosion hazard when testing for a leak:

a. Always perform leak test before lighting the grill and each time the

tank is connected for use.

b. No smoking. Do not use or permit sources of ignition in the area

while conducting a leak test. c. Conduct the leak test outdoors in a well-ventilated area. d. Do not use matches, lighters, or a flame to check for leaks.

1. Do not store or use gasoline or other flammable liquids or vapors in the vincinity of this or any other appliance.

2. An LP cylinder not connected for use shall not be stored in the vicinity of this or any other appliance.

e. Do not use grill until any and all leaks are corrected.

If you are unable to stop a leak, disconnect the LP gas supply. Call a gas appliance serviceman or your local LP gas supplier.

Do not store or use gasoline or other flammable liquids or vapors within

25 feet (7.62 m) of this appliance.

Do not use in an explosive atmosphere. Keep grill area clear and free

from combustible materials, gasoline and other flammable vapors and liquids.

Minimum clearance from sides and back of unit to combustible

construction, 21 inches from side and 21 inches from back. Do not use this appliance under overhead combustible surfaces.

It is essential to keep the grill’s valve compartment, burners, and

circulating air passages clean. Inspect grill before each use. Do not alter grill in any manner. Do not use the grill unless it is COMPLETELY assembled and all parts are

securely fastened and tightened. This grill should be thoroughly cleaned and inspected on a regular basis.

Clean and inspect the hose before each use of the appliance. If there

is evidence of abrasion, wear, cuts, or leaks, the hose must be replaced

prior to the appliance being put into operation. Use only the regulator and hose assembly provided. The replacement

regulator and hose assembly shall be that specified by the manufacturer. Use only Blue Rhino Global Sourcing, Inc. factory authorized parts. The

use of any part that is not factory authorized can be dangerous. This will

also void your warranty. Do not use this appliance without reading “Operating Instructions” in

this manual. Do not touch metal parts of grill until it has completely cooled (about

45 min.) to avoid burns, unless you are wearing protective gear (pot

holders, gloves, BBQ mittens, etc.). When cooking, fire extinguishing materials shall be readily accessible.

In the event of an oil grease fire, do not attempt to extinguish with water.

Use type BC dry chemical fire extinguisher or smother with dirt, sand or

baking soda. Do not install or use in or on boats or recreational vehicles. Do not use grill in high winds. Never lean over the grill when lighting. Do not leave a lit grill unattended, especially keep children and pets

away from grill at all times. Do not attempt to move grill when in use. Allow the grill to cool before

moving or storing. Storage of grill indoors is permissible only if the tank is disconnected,

removed from the grill and properly stored outdoors. Always open grill lid carefully and slowly as heat and steam trapped

within grill can severely burn you. Do not attempt to disconnect the gas regulator from the tank or any gas

fitting while the grill is in use. Always place your grill on a hard non-combustible, level surface. An

asphalt or blacktop surface may not be acceptable for this purpose. Move gas hoses as far away as possible from hot surfaces and dripping

hot grease. Keep all electrical cords away from a hot grill. Do not use grill for indoor cooking or heating. TOXIC fumes can

accumulate and cause asphyxiation. After a period of storage and/or nonuse, check for leaks, burner

obstructions and inspect for any abrasion, wear, cuts to the hose. Failure to open lid while igniting the grill’s burners, or not waiting 5

minutes to allow the gas to clear if the grill does not light, may result in

an explosive flame-up. If grill is not in use, the gas must be turned off at the supply tank. Never operate grill without heat plates installed. Always use a meat thermometer to ensure food is cooked to a safe

temperature. Please use protective gloves when assembling this product. Do not force parts together as this can result in personal injury or

damage to the product. Never cover entire cooking area with aluminum foil.

Deaths, serious injury or damage to property may occur if the above is

not followed exactly.

WARNING

FOR YOUR SAFETY

Contact 1.800.762.1142 for assistance. Do not return to place of purchase.

page no.

Parts List

Warming Rack

Cooking Grid (3)

Heat Plate (3)

Grease Tray

Thermometer

Basket (2)

Tool Hook (8)

Towel Bar (2)

Left Side Shelf Side

Left Side Shelf

Grill Body Assembly

Side Burner Grid

Left Side Shelf Front

Digital Timer

55-07-551

55-07-501

55-08-076

55-07-509

55-07-547

55-08-067

55-07-549

55-07-548

55-08-081

55-08-079

55-08-074

55-07-543

55-08-080

55-08-073

Exploded View

Infrared Back Burner

Main Burner (3)

Sear Burner

Side Burner

Right Side Shelf

Right Side Shelf Side

Grease Cup

Grease Cup Support

Regulator

Right Side Shelf Front

Control Knob Support (6)

Control Knob (6)

Basket Support A (4)

55-07-513

55-08-086

55-08-109

55-08-110

55-08-094

55-08-096

55-07-507

55-07-508

55-08-091

55-08-095

55-08-071

55-08-070

55-08-065

Basket Support B (2)

Left Cart Panel

Rear Cart Panel

Tank Retainer Wire

Right Cart Panel

Left Door

Door Handle (2)

Right Door

Lighting Rod

Front Cart Support

Base Cart Panel

Left Skirt

Locking Wheel (2)

55-08-066

55-08-077

55-08-090

55-07-522

55-08-092

55-08-078

55-08-011

55-08-093

55-07-520

55-07-505

55-08-064

55-08-082

55-07-528

Hardware

A B C D E F G

Screw

Nut

Washer

AAA Batteries 2 pcs

M4x8 Nickel Plated Phillips Truss Head

M6x15 Nickel Plated Phillips Truss Head

M6x15 Nickel Plated Hex Head

M6x46 Nickel Plated Phillips Truss Head

M6 Zinc Plated

ø6.5 Nickel Plated

Tools Required for Assembly (Included)

#1 Phillips Head Screwdriver

20 pcs

29 pcs

21 pcs

11 pcs

7 pcs

8 pcs

Wheel (2)

Right Skirt

Center Skirt

LP Gas Tank Tray

55-07-506

55-08-097

#2 Phillips Head Screwdriver

55-08-069

55-08-085

M10-M6 Wrench

GOLD

Assembly Instructions

Outdoor LP Gas Barbecue Grill Model No. GBC873W-C

DO NOT RETURN PRODUCT TO STORE.

For assistance call 1.800.762.1142 toll free. Please have your owner’s manual and serial number available for reference.

Note: The serial number can be found on the back of the cart assembly.

For Easiest Assembly:

• To avoid losing any small components or hardware, assemble your product on a hard level surface that does not have cracks or openings.

• Clear an area large enough to layout all components and hardware.

• When applicable, tighten all hardware connections by hand first. Once the step is completed go back and fully tighten all hardware.

• Follow all steps in order to properly assemble your product.

To complete assembly you will need:

• (1) Leak Detection Solution (Instructions on how to make solution are included in the “Operating Instructions” section of this manual)

• (1) Precision Filled LP Gas Grill Tank with Acme Type 1 external threaded valve connection (4-5 gallon size)

Note: You must follow all steps to properly assemble the grill.

Assemble Skirt

Typical assembly: approximately 1 (one) hour.

Attach Skirt to Base Cart Panel

Attach Wheels

Note: Locking wheels should be placed at the back.

x 4

x 7

Contact 1.800.762.1142 for assistance. Do not return to place of purchase.

page no.

Attach Side Panels

Attach Front Cart Support and LP Gas Tank Tray

Attach Basket Supports B

x 11

Attach Basket Supports A

x 4

x 8

x 4

x 2

x 8

GOLD

Assembly Instructions (continued)

Outdoor LP Gas Barbecue Grill Model No. GBC873W-C

Attach Doors and Insert Baskets

Attach Grill Body

Remove Digital Timer Battery Cover

Attach Left Side Shelf Front and Towel Bar

x 4

Install Digital Timer AAA Batteries

x 2

x 4

Contact 1.800.762.1142 for assistance. Do not return to place of purchase.

page no.

Attach Left Side Shelf Panel

Attach Right Side Shelf Front and Towel Bar

Attach Right Side Shelf Panel

x 3

Attach Left Side Shelf Assembly

Note: Leave 5/8” (2 mm) of bolt threads exposed. Do not fully tighen until step 18.

x 4

x 3

x 2

GOLD

Assembly Instructions (continued)

Outdoor LP Gas Barbecue Grill Model No. GBC873W-C

Attach Right Side Shelf Assembly

Note: Leave 5/8” (2 mm) of bolt threads exposed. Do not fully tighen until step 19.

Secure Left Side Shelf Assembly

Secure Right Side Shelf Assembly

x 2

Attach Regulator, Control Knob Support and Control Knob

x 5

x 4

x 2

Contact 1.800.762.1142 for assistance. Do not return to place of purchase.

page no.

Attach Side Burner, Side Burner Grid, and Igniter Wire

Insert Heat Plates

Insert Cooking Grid and Warming Rack

x 2

Insert Grease Tray

GOLD

Outdoor LP Gas Barbecue Grill Model No. GBC873W-C

Assembly Instructions (continued)

Attach Grease Cup and Grease Cup Support

Installing LP Gas Tank

To operate you will need (1) precision-filled standard grill LP gas tank (20#) with external valve threads.

Note: An empty standard grill LP gas tank weighs approximately 18 lbs. A precision-filled standard grill LP gas tank should weigh no more than 38 lbs.

Insert LP Gas Tank

Place precision filled LP gas tank upright into hole in the tank tray so the tank valve is facing the gas line connection.

Secure LP Gas Tank

Slide the tank tray all the way back and secure by sliding tank retainer wire over shoulder of LP gas tank.

Connect LP Gas Tank

Before connecting, be sure that there is no debris caught in the head of the LP gas tank, head of the regulator valve or in the head of the burner and burner ports.

Connect gas line to tank by turning knob clockwise until it stops.

Disconnect LP Gas Tank

Before disconnecting make sure the LP gas tank valve is “OFF”.

Disconnect gas line from LP gas tank by turning knob counterclockwise until it is loose.

Need a tank of gas? Try tank exchange service. It’s easy, fast, safe, and available at tens of thousands of conveniently located retail outlets nationwide. You can purchase a new full tank or exchange your empty for a precision filled one.

+ 22 hidden pages
