Blomberg LTP 2832W User Manual
Dryer
User Manual
LTP 2832W
Please read these instructions first before using your appliance
Thank you for choosing a Blomberg appliance.
Please take some time to read this user manual before using your appliance, to ensure you
know how to safely operate the controls and functions.
Carefully follow all unpacking and installation instructions to ensure the appliance is correctly
connected and fitted prior to use.
Please write your product model and serial number on the last page of this user manual, and
store in a safe location close to the appliance for easy future reference.
This user manual may also be applicable for several other models. Differences between
models will be listed.
If you have any questions or concerns, please call our contact centre or find help and
information online at www.blomberguk.com
Explanation of symbols used throughout this User Manual
Read the instructions.
Important information or useful hints about usage.
C
Warning for hazardous situations with regard to life and property.
A
Warning against electric shock.
B
Warning against hot surfaces.
Warning against fire hazard.
Packaging materials of the product are manufactured from recyclable materials in
accordance with our National Environment Regulations.
Do not dispose of the packaging wastes with the domestic waste or other wastes, discard
them to the dedicated collection points designated by the local authorities.
TABLE OF CONTENTS
1 Important safety and environmental
instructions 4
1.1 General safety .....................................4
1.1.1 Electrical safety .............................5
1.1.2 Product safety................................6
1.2 Mounting over a washing machine ......8
1.3 Intended use ........................................9
1.4 Child safety ..........................................9
1.5 Compliance with the WEEE regulation
and disposing of the waste product .........10
1.6 Compliance with RoHS Directive:......10
1.7 Package information ..........................10
1.8 Technical specifications ..................... 11
2 Your Dryer 12
2.1 Overview............................................12
2.2 Package contents ..............................13
3 Installation 14
3.1 Appropriate installation location .........14
3.2 Removing the transportation safety
assembly .................................................14
3.3 Connecting the drain .........................14
3.4 Adjusting the feet ...............................15
3.5 Electrical connection..........................15
3.6 Transportation of the dryer ................15
3.7 Warnings about sounds .....................15
3.8 Changing the illumination lamp ........16
6 Operating th product 20
6.1 Control panel .....................................20
6.2 Screen symbols .................................20
6.3 Preparing the machine ......................21
6.4 Programme selection.........................21
6.5 Programme selection and consumption
table .........................................................22
6.6 Auxiliary function................................23
6.7 Warning symbols ...............................23
6.8 End duration ......................................24
6.9 Starting the Programme ....................24
6.10 Child lock .........................................24
6.11 Changing the Programme after it has
started......................................................25
6.12 Cancelling the Programme ..............25
6.13 Programme end ...............................25
7 Maintenance and cleaning 26
7.1 Cleaning lint filter / Loading door inner
surface .....................................................27
7.2 Cleaning the sensor ..........................27
7.3 Draining the water tank......................27
7.4 Cleaning the filter drawer ..................27
7.5 Cleaning the evaporator ....................29
8 Troubleshooting 30
4 Electrical Connection 17
4.1 Attention!............................................17
4.2 Electrical requirements ......................17
4.3 Fitting a different plug .......................17
4.4 Washer/dryer combination .................17
5 Preparation 18
5.1 Laundry suitable for drying in the dryer 18
5.2 Laundry not suitable for drying in the
dryer ........................................................18
5.3 Preparing laundry for drying ..............18
5.4 Things to be done for energy saving .18
5.5 Correct load capacity .........................19
Important safety and environmental
1 Important safety and environmental
instructions
instructions
This section contains safety instructions that will help protect
from risk of personal injury or property damage. Failure to
follow these instructions shall void any warranty.
1.1 General safety
• The dryer can be used by children at and above 8
years old and by persons whose physical, sensory or
mental capabilities were not fully developed or who
lack experience and knowledge provided that they are
supervised or trained on the safe usage of the product
and the risks it brings out. Children should not play with
the product. Cleaning and maintenance works should not
be performed by children unless they are supervised by
someone.
• Children of less than 3 years should be kept away unless
continously supervised.
• Adjustable feet should not be removed. The gap between
the dryer and the floor should not be reduced with
materials such as carpet, wood and tape. This will cause
problems with the dryer.
• Always have the installation and repairing procedures
carried out by the Authorised Service. Manufacturer
shall not be held liable for damages that may arise from
procedures carried out by unauthorised persons.
• Never wash the dryer by spraying or pouring water onto it!
There is the risk of electric shock!
4 / EN
Dryer / User Manual
Important safety and environmental
instructions
1.1.1 Electrical safety
Electrical safety instructions should be followed while
A
A
• Connect the dryer to a grounded outlet protected by a
fuse at the value specified on the type label. Have the
grounding installation performed by a qualified electrician.
Our company shall not be liable for any damages that
will arise when the dryer is used without grounding in
accordance with the local regulations.
• The voltage and allowed fuse protection is stated on the
type label plate.
• The voltage specified on the type label must be equal to
your mains voltage.
electrical connection is made during the installation.
The appliance must not be supplied through an
external switching device, such as a timer,or
connected to a circuit that is regularly switched on
and off by utility.
• Unplug the dryer when it is not in use.
• Unplug the dryer from the mains during installation,
maintenance, cleaning and repair works.
• Do not touch the plug with wet hands! Never unplug by
pulling on the cable, always pull out by grabbing the plug.
• Do not use extension cords, multi-plugs or adaptors to
connect the dryer to power supply in order to decrease the
risk of fire and electric shock.
• Power cable plug must be easily accessible after
installation.
Damaged mains cable should be changed by an
B
Dryer / User Manual
Authorised Service agent.
5 / EN
Important safety and environmental
instructions
If the dryer is faulty, it must not be operated unless it
B
1.1.2 Product safety
is repaired by an authorised service agent! There is
the risk of electric shock!
• Superheating of the clothes inside of the dryer can
occur if you cancel the programme or in the event
of a power failure whilst the dryer is running, this
concentration of heat can cause self-combustion
and fire so always activate the ventilation
programme to cool down or quickly remove all
laundry from the dryer in order to hang them up
and dissipate the heat.
Points to be taken into consideration for fire
hazard:
Below specified laundry or items must not be dried
in the dryer because of fire hazard.
6 / EN
• Unwashed laundry items
• Items soiled with oil, acetone, alcohol, fuel oil,
kerosene, stain removers, turpentine, paraffin or
solvents must be washed in hot water with plenty of
detergent before being dried in the dryer.
Dryer / User Manual
Important safety and environmental
instructions
Below specified laundry or items must not be
dried in the dryer due to the fire hazard:
• Garments or pillows bolstered with rubber foam
(latex foam), shower caps, water resistant textiles,
materials with rubber reinforcement and rubber
foam pads.
• Clothing cleaned with industrial chemicals.
Items such as lighters, matches, coins, metal parts,
needle etc. may damage the drum set or may lead to
functional problems. Therefore check pockets off the
laundry that you will load into your dryer.
Never stop your dryer before the programme
completes. If you must do this, remove all laundry
quickly and lay them out to dissipate the heat.
Clothes that are washed inadequately may ignite on
their own and even may ignite after drying ends.
• You must provide enough ventilation in order to prevent
gases exiting from devices operating with other types of
fuels including the naked flame from accumulating in the
room due to the back fire effect.
Clothing that contains metal reinforcements should
A
C
C
Dryer / User Manual
not be dried in the dryer. Dryer may be damaged
if metal reinforcements come loose and break off
during drying.
Use softeners and similar products in accordance
with the instructions of their manufacturers.
Always clean the lint filter before or after each
loading. Never operate the dryer without the lint filter
installed.
7 / EN
Important safety and environmental
instructions
• Never attempt to repair the dryer by yourself. Do not
perform any repair or replacement procedures on the
product even if you know or have the ability to perform the
required procedure unless it is clearly suggested in the
operating instructions or the published service manual.
Otherwise, you will be putting your life and others’ lives in
danger.
• There must not be a lockable, sliding or hinged door that
may block the opening of the loading door in the place
where your dryer is to be installed.
• Install your dryer in a suitable place that is dry, well
ventilated and unlikely to get below 5 degrees Centigrade.
• Make sure that pets do not enter the dryer. Check the
inside of the dryer before operating it.
• Do not lean on the loading door of your dryer when it is
open, otherwise it may fall over.
• The lint must not be allowed to accumulate around the
tumble dryer
1.2 Mounting over a washing machine
• A fixing device should be used between the two machines
when installing the dryer above a washing machine. The
fitting device can be obtained through spare part suppliers.
• Total weight of the washing machine and the dryer -with
full load- when they are placed on top of each other
reaches to approx. 180 kilograms. Place the products on a
solid floor that has sufficient load carrying capacity!
Washing machine cannot be placed on the dryer.
A
8 / EN
Pay attention to the above warnings during the
installation on your washing machine.
Dryer / User Manual
Important safety and environmental
instructions
Installation Table for Washing Machine and Dryer
Washing Machine Depth
Dryer
Depth
54 cm
60 cm
62 cm
Can be installed
Can be installed
60 cm
54 cm
Cannot be installed
Cannot be installed
< 50 cm
1.3 Intended use
• Dryer has been designed for domestic use. It is not
suitable for commercial use and it must not be used out of
its intended use.
• Use the dryer only for drying laundry that are marked
accordingly.
• The manufacturer waives any responsibility arisen from
incorrect usage or transportation.
• Original spare parts will be available to repair the dryer for
a period of 10 years.
1.4 Child safety
• Packaging materials are dangerous for the children. Keep
packaging materials away from children.
• Electrical products are dangerous for the children. Keep
children away from the product when it is operating. Do not
let them tamper with the dryer. Use the child-proof lock in
order to prevent the children to tamper with the dryer.
Child-proof lock is on the control panel. (See Child
C
Dryer / User Manual
lock)
9 / EN
Important safety and environmental
instructions
• Keep loading door closed even when the dryer is not in
use.
1.5 Compliance with the WEEE regulation
and disposing of the waste product
This product does not contain the harmful and
prohibited substances which are specified in the
“Control of the Waste Electrical and Electronic
Equipment” as published by Republic of Turkey
Ministry of Environment and Urbanization. It
complies with the WEEE Directive.
This product was made of high quality items and materials
which are recyclable and reusable. Therefore, do not
dispose of the product at the end of its service life with the
domestic and other wastes. Take it to a collection point for
the recycling of electrical and electronic equipment. Please
consult your local authorities to learn the nearest collection
point. Help protect the environment and natural resources
by recycling used products. For children’s safety, cut the
power cable and break the locking mechanism of the door, if
any, so that it will be non-functional before disposing of the
product.
1.6 Compliance with RoHS Directive:
The product you have purchased complies with EU RoHS
Directive (2011/65/EU). It does not contain harmful and
prohibited materials specified in the Directive.
1.7 Package information
Packaging materials of the product are manufactured
from recyclable materials in accordance with our National
Environment Regulations. Do not dispose of the packaging
materials together with the domestic or other wastes. Take
them to the packaging material collection points designated
by the local authorities.
10 / EN
Dryer / User Manual
Important safety and environmental
instructions
1.8 Technical Specifications
EN
Height (Min. / Max.) 84,6 cm / 86,6 cm*
Width 59,7 cm
Depth 58,9 cm
Capacity (max.) 8 kg**
Net weight (± 4 kg) 44 kg
Voltage
See type label***Rated power input
Model code
* Min. height: Height with adjustable feet are closed.
Max. height: Height with adjustable feet are opened
maximum.
** Dry laundry weight before washing.
*** Type label is located behind the loading door.
Technical specifications of the dryer are subject to
specification without notice to improve the quality of
C
C
C
Dryer / User Manual
the product.
Figures in this manual are schematic and may not
match the product exactly.
Values stated on markers on the dryer or in the other
published documentation accompanying with the
dryer are obtained in laboratory in accordance with
the relevant standards. Depending on operational and
environmental conditions of the dryer, these values
may vary.
11 / EN
2
Your Dryer
2.1 Overview
11
1
10
9
8
7
1. Top panel
2. Control panel
3. Loading door
4. Kick plate opening button
5. Ventilation grids
6. Adjustable legs
7. Kick plate
8. Type label
9. Lint filter
10. Water tank drawer
11. Power cord
2
3
4
5
6
Dryer / User Manual12 / EN
Loading...
