Blomberg KGM 9550P, KGM 9550PX, KGM 9550 User Manual

Fridge Freezer

KGM 9550 KGM 9550P KGM 9550PX

Bedienungsanleitung Operating instructions

Please read this manual first!

Recycling

Dear Customer, We hope that your product, which has been produced in a 1st-class

manufacturing facility and checked under the most meticulous quality control procedures, will provide you with years of good service.

For this, we recommend you to carefully read the entire manual of your product before using it and keep it at hand for future reference.

This manual

• Will help you use your appliance quickly and safely.

• Read the manual before installing and operating your product.

• Follow the instructions, especially those for safety.

• Keep the manual in an easily accessible place as you may need it later.

• Besides, read also the other documents provided with your product.

Please note that this manual may be valid for other models as well.

Symbols and their descriptions

This instruction manual contains the following symbols:

C Important information or useful usage tips. A Warning against dangerous conditions for life and property. B Warning against electric voltage.

This product is supplied with the selective sorting symbol for waste electrical

and electronic equipment (WEEE). This means that this product must be handled pursuant to European Directive 2002/96/EC in order to be recycled or dismantled to minimise its impact on the environment. For further information, please contact your local or regional authorities.

Electronic products not included in the selective sorting process are potentially dangerous for the environment and human health due to the presence of

hazardous substances.

1 Your refrigerator 3

2 Warnings 4

ELECTRICAL REQUIREMENTS ......... 5

WARNING! THIS APPLIANCE MUST

BE EARTHED .................................... 5

ENERGY SAVING TIPS ...................... 6

3 Installation 7

TRANSPORTATION INSTRUCTIONS .7 REPLACING THE INTERIOR LIGHT

BULB ...............................................9

REVERSING THE DOORS ............... 10

5 Using your refrigerator 14

TEMPERATURE CONTROL AND

ADJUSTMENT ................................. 14

SUGGESTED ARRANGEMENT OF

FOOD IN THE FRIDGE/FREEZER .... 15

STORING FROZEN FOOD ...............16

FREEZING FRESH FOOD ................16

MAKING ICE CUBES ....................... 16

DEFROSTING .................................. 17

6 Maintenance and cleaning 18

7 Do's and Don'ts 19

4 Before operating 13

Final Check .....................................13

8 How To Obtain Service 21

9 Guarantee Details 22

1 Your refrigerator

Congratulations on your choice of a BLOMBERG quality Appliance which has

been designed to give you service for many years.

6 7

1. Temperature setting knob

2. Interior light

3. Cabinet shelves

4. Defrost water collection channel

5. Salad crisper

6. Ice bank

7. Freezer fan

9. Frozen food storage drawers

10. Adjustable feet

11. Door shelves

12. Egg tray

13. Winerack

14. Fridge compartment

15. Freezer compartment

8. Fast freeze compartment

• Figures that take place in this instruction manual are schematic and may not correspond exactly with your product. If the subject parts are not included in the product you have purchased, then it is valid for other models.

2 Warnings

•DO NOT connect your appliance to

the electricity supply until all packing and transit protectors have been removed.

• Leave to stand for at least 4

hours before switching on to allow compressor oil to settle if transported horizontally.

• If you are discarding an old

refrigerator with a lock or latch fitted

to the door, disable the lock/latch,

ensure that it is left in a safe condition to prevent the entrapment of young children.

• This fridge/freezer must only be used

for its intended purpose i.e the storing and freezing of edible foodstuff.

• Do not dispose of the appliance on

a fire. At BLOMBERG, the care and

protection of our environment is an ongoing commitment. This appliance which is among the latest range introduced is particularly environment

friendly. Your appliance contains non CFC / HFC natural substances in the cooling system (Called R600a) and in the insulation (Called cyclopentane)

which are potentially flammable if exposed to fire. Therefore, take care not to damage, the cooling

circuit / pipes of the appliance in

transportation and in use. In case of damage do not expose the appliance to fire or potential ignition source and immediately ventilate the room where the appliance is situated.

• We suggest you contact your local

authority for disposal information and facilities available.

• See Installation Instructions on on

page 8 for information on suitable location.

• To obtain the best possible

performance and trouble free operation from your appliance it is very important to carefully read these instructions.

• On delivery, check to make sure that

the product is not damaged and that all the parts and accessories are in perfect condition.

• Ensure that the plug remains readily

accessible. Do not use multiple adapter bar or extension cable.

• Failure to observe these instructions

may invalidate your right to free service during the guarantee period.

• Keep ventilation openings, in the

appliance enclosure or in the built-in structure, clear of obstruction.

• Do not use mechanical devices

or other means to accelerate the defrosting process, other than those recommended by the manufacturer.

• Do not damage the refrigerant circuit.

• Do not use electrical appliances

inside the food storage compartments of the appliance, unless they are of the type recommended by the manufacturer.

• We suggest you keep these

instructions in a safe place for easy reference.

• This appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

• Children should be supervised to

ensure that they do not play with the appliance.

ELECTRICAL REQUIREMENTS

Before you insert the plug into the wall

socket make sure that the voltage and the frequency shown on the rating plate inside the appliance corresponds to your electricity supply.

Rating label is on the left hand side of

fridge inner liner. We recommend that this appliance be

connected to the mains supply via a suitable switched and fused socket.

The appliance must be positioned so that the plug is accessible.

Should the mains lead of the appliance

become damaged or should it need replacing at any time, it must be

replaced by a special purpose made mains lead which can only be obtained

from a BLOMBERG Authorised Service Agent.

WARNING! THIS APPLIANCE MUST BE EARTHED

If the fitted moulded plug is not suitable for your socket, then the plug should be cut off and an appropriate plug fitted. Destroy the old plug which is cut off as a plug with bared cord could cause a shock hazard if inserted into a socket elsewhere in the house.

The moulded plug on this appliance

incorporates a 13 A fuse. Should

the fuse need to be replaced an

ASTABEAB approved BS 1362 fuse

of the same rating must be used. Do not forget to refit the fuse cover. In the event of losing the fuse cover the plug must not be used until a replacement fuse cover has been fitted. Colour of the replacement fuse cover must be the same colour as that visible on the pin face of the plug. Fuse covers are available from any good electrical store.

IMPORTANT! FITTING A DIFFERENT PLUG

As the colours of the wires in the

mains lead of this appliance may not correspond with the coloured markings identifying the terminals in

your plug proceed as follows: (See diagram).

1. Connect the green-yellow or green

(Earth) wire to the terminal in the plug

marked ‘E’ or with the symbol coloured green and yellow or green.

2. Connect the blue (Neutral) wire to the terminal in the plug marked ‘N’ or

coloured black.

3. Connect the brown (Live) wire to

the terminal in the plug marked ‘L’ or coloured red.

With alternative plugs a 13 A fuse must

be fitted either in the plug or adaptor or in the main fuse box. If in doubt contact a qualified electrician.

GREEN & YELLOW

GREEN

BLUE

BLACK

6mm.

32mm.

BROWN

RED

22mm.

6mm.

CORD GRIP

6mm.

FUSE

12mm.

FITTED WITH

CARTRIDGE FUSE

FIT BS 1362 REPLACEMENT

BS 1362 13A FUSE ALWAYS

ENERGY SAVING TIPS

1- Ensure your appliance is installed in a well ventilated area.

2- Ensure the time between buying

chilled/frozen food and placing them in

your appliance is kept to a minimum, particularly in summer. We recommend you use a cool bag or a special carrier bag to carry frozen food.

3- Do not leave the door (s) of your

appliance open longer than necessary and ensure they are closed properly after each opening.

4- Defrost frozen food in the fridge compartment, so that frozen food acts as an ice pack to assist cooling in the fridge.

3 Installation

TRANSPORTATION INSTRUCTIONS

1. The appliance should be

transported only in a vertical upright position. The packing as supplied must be intact during transportation.

2. If during the course of transport

the appliance has to be transported horizontally, it must only be laid on its right hand side when standing in the

frontof the appliance. After bringing

it to upright position,it must not be operated for at least 4 hours to allow the system to settle.

3. Failure to comply with the

above instructions could result in damage occuring to the appliance. The manufacturer will not be held responsible if these instructions are disregarded.

4. The appliance must be protected

against rain, moisture and other atmospheric influences.

5. When positioning your appliance

take care not to damage your flooring, pipes, wall coverings etc. Do not move the appliance by pulling by the door or handle.

6. Empty any water in the drain

tray before moving. See section

‘Defrosting’ and ‘Care & cleaning’ for further information.

7. Make sure that the defrost water

pipe at the back of the product is fixed to the plastic evaporating pan on the top of the compressor, to avoid defrost water spillage on the floor.

IMPORTANT : Care must be taken while cleaning / carrying the appliance

to avoid touching the bottom of the condenser metal wires at the back of

the appliance as you might injure your

fingers and hands. Do not attempt to sit or stand on top

of your appliance as it is not designed

for such use. You could injure yourself

or damage the appliance.

“IMPORTANT: Make sure that

mains cable is not caught under the appliance during and after carrying

/ moving the appliance, to avoid

the mains cable becoming cut or damaged.”Do not allow children to play with the appliance or tamper with the controls.

BLOMBERG declines to accept any

liability should the instructions not be followed.
