To prevent accidents, which could cause serious injury or death, as well as machine damage read these instructions before installation and / or use.

Contents

1. IMPORTANT SAFETY INSTRUCTIONS

1

1.1 INSPECT THE DISHWASHER

2

1.2 HOW TO CONTACT US

2

2. TOOLS WHICH MAY BE NEEDED

3

3. MATERIALS WHICH MAY BE NEEDED

3

4. MATERIALS SUPPLIED

4

4.1 PARTS SUPPLIED

4

4.2 MANUAL BAG

4

4.3 DISHWASHER PARTS BAG 1

4

4.4 DISHWASHER PARTS BAG 2

4

4.5 PARTS ATTACHED TO THE REAR OF THE DISHWASHER

4

5. DISHWASHER SPECIFICATIONS

5

5.1 TECHNICAL FEATURES

5

6. ENCLOSURE PREPARATION

6

6.1 ELECTRICAL PREPARATION

6

6.2 PREPARATION FOR INSTALLING MOUNTING BRACKETS

7

6.3 ADJUSTING HEIGHT

7

6.4 INSTALLING THE SIDE TRIM STRIPS

8

6.5 PREPARING THE WATER CONNECTION (A)

9

6.6 DRAIN PREPARATION

10

6.7 STEAM PROTECTION FOIL

11

7. PLACEMENT OF DISHWASHER INTO THE OPENING

12

7.1 DRAIN HOSE CONNECTION, WATER SUPPLY & ELECTRICAL CONNECTIONS

12

7.2 READJUSTING FOOT LEVELS

17

7.3 ADJUSTING THE MOVABLE TOE KICK

17

7.4 INSTALLING THE OUTER DOOR

18

8. INSTALLER CHECKLIST

24

9. FINAL INSTRUCTIONS

24

10. SELF HELP HINTS

24

INTRODUCTION

Please read this installation manual and particularly the safety instructions

completely and carefully. They will save you time and effort and help to ensure optimum dishwasher performance.

Be sure to observe all listed warnings and cautions. Look particularly for the icons with exclamation marks inside. The information icon also will provide important references.

WARNING CAUTION

Ý Notice

WARNING:

Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.

CAUTION:

Indicates a potentially hazardous situation which, if not avoided, may result in injury. It may also be used to alert against unsafe practices.

Notice:

Indicates a potentially hazardous situation which, if not avoided, may result in damage to the dishwasher, the table-ware, the equipment or the environment.

1. IMPORTANT SAFETY INSTRUCTIONS

In addition to these instructions, the dishwasher shall be installed:

In accordance with all local codes or, in absence of a local code,

In the United States, with the National Electric Code,

In Canada, with the Canadian Electric Code C22.1-latest edition/Provincial and Municipal codes and/or local codes.

Notice :

Read these installation instructions completely before installing and follow them carefully. Save these installation instructions and pass them on to any future user.

WARNING

When installing the dishwasher, follow basic precautions, including the following:

The dishwasher installation must be performed in accordance with this installation manual. If you did not receive an installation manual, order it by

calling 1-800-459-9848 or you may also download it from our web site at www.blombergappliances.com

Installation and repair should be performed by a qualified installer. Work by unqualified persons could be dangerous and may void the warranty.

Do not operate the appliance if damaged, malfunctioning, partially disassembled or if it has missing or broken parts.

Also follow the safety instructions of the user manual.

To reduce the risk of electric shock, fire, or injury to persons, the installer must ensure that the dishwasher is completely enclosed at the time of installation.

Only connect the dishwasher to the power supply when all installation and plumbing work is complete.

If the dishwasher is installed in a location that experiences freezing temperatures (e.g. in a vacation home, cabin, etc.), you must drain all the water from the dishwasher’s interior. Water system ruptures that occur as a result of freezing are not covered by warranty.

Dishwasher must be secured to adjacent cabinetry using the brackets provided. Failure to do this may cause damage to property or bodily injury.

Connect to a properly rated, protected and sized power supply circuit to avoid electrical overload. The dishwasher is designed for an electrical supply of 120 V (volts), 60 Hz (hertz), AC, connected to a dishwasher-dedicated, properly grounded electrical circuit with a fuse or breakers rated for 15 amperes. Electrical supply conductors shall be a minimum of # 14 AWG copper wire rated at 75 °C (167 °F) or higher. These requirements must

1 USA

be met to prevent injury and machine damage. Consult a qualified electrician if in doubt.

Do not use any extension cord or portable outlet device to connect the dishwasher to a power supply.

Ensure that any plastic wrappings, bags, small pieces etc. are disposed of safely and kept out of the reach of children. Danger of suffocation!

Remove the door to the washing compartment when removing an old dishwasher from service or discarding it. Ensure that the appliance presents no danger to children while being stored for disposal.

Old appliances may contain materials that can be recycled. Please contact your local recycling authority about the possibility of recycling these materials.

Notice :

The dishwasher drain hose must be installed with a drain loop at least 28" (710mm) off the cabinet floor; otherwise the dishwasher may not drain properly.

This dishwasher is intended for residential use only, and should not be used in commercial establishments.

New installation - If the dishwasher is a new installation, most of the work must be done before the dishwasher is moved into place.

Replacement - If the dishwasher is replacing another dishwasher, check the existing dishwasher connections for compatibility with the new dishwasher, and replace parts as necessary.

1.1 INSPECT THE DISHWASHER

After unpacking the dishwasher and prior to installation, thoroughly inspect the dishwasher for possible freight or cosmetic damage. Report any damage immediately.

Notice :

Cosmetic defects must be reported within 10 days of installation.

Do not discard any bags or items that come with the original package until after the entire installation has been completed.

1.2 HOW TO CONTACT US :

You may either call our Toll Free Number at 1-800-459-9848 or contact us via the web site at

www.blombergappliances.com

or Contact the Blomberg Distributor for your State or Province as listed on the Distributor Contact List provided.vv

2 USA

Blomberg DWT 14440 User Manual

2. TOOLS WHICH MAY BE NEEDED

3. MATERIALS WHICH MAY BE NEEDED

(Additional materials may be required to comply with local codes)

Hot Water Supply Line - Minimum 3/8” O.D. copper tubing or metal braided dishwasher supply line.

Electrical Supply Cable - Minimum #14AWG, 2 conductors, 1 ground, insulated copper conductors.

90° elbow with 3/8” N.P.T. male threads on one leg, and sized to fit your water supply line (copper tubing/compression fitting, or braided hose) on the other leg.

UL listed conduit connector or strain relief.

Teflon tape or other pipe thread compound to seal plumbing connections.

Shut-off valve and fittings appropriate for hot water supply line (copper tubing/compression fitting, or braided hose).

Silicone

Glue

3 USA

4. MATERIALS SUPPLIED

a.

x1

b.

x1

c.

x1

d.

x6

e.

x1

f.

x1

g.

x1

h.

x1

j.

x1

k.

x1

l.

x1

m.

x3

n.

x4

o.

x1

p.

x1

r. x2

s.

x2

t.

x2

v. x4

y. x4

z. x1

4.1 PARTS SUPPLIED

Parts for your dishwasher will come in several plastic bags. Check your parts bags shown to make sure you have all the parts as listed to the left.

4.2 MANUAL BAG

The dishwasher comes with a manual bag containing:User manual,

Installation manual andQuick reference guide.

4.3 DISHWASHER PARTS BAG 1

This dishwasher bag comes with the following parts:

a.Side Trim Strips (Left)

b.Side Trim Strips (Right)

c.Adjusting Wrench

d.Screws Ø 1/8” x 5/8” (Ø 3.5 mm x 14 mm)

e.Mounting Bracket Left

f.Mounting Bracket Right

g.Spring Clamp

h.Screw Clamp

j.Rubber Connector

k.Toe Kick Bracket - Left

l.Toe Kick Bracket - Right

m.Wire Nuts

n.Clips

o.Toe Kick (toe kick without slots)

p.Toe Kick

r.Screws Ø 1/8” x 3/8” (Ø 3.9 mm x 9 mm)

s.Plastic Caps

t.Screws Ø 3/16” x 1/4” (Ø 4mm x 6mm)

z.Steam Protection Foil

4.4 DISHWASHER PARTS BAG 2

In addition to the manual bag and the dishwasher parts bag 1 DWT 34, DWT 35, DWT 36 and DWT 37 (dishwasher models which can accept a wooden kitchen door) also come with a door panel installation kit which contains:

v. Screws Ø 1/8” x 5/8” (Ø 3.5mm x 14mm) y. Screws Ø 3/16” x 13/4” (Ø 4mm x 43mm)

4.5 PARTS ATTACHED TO THE REAR OF THE DISHWASHER

a.Side Trim Strips (Left)

b.Side Trim Strips (Right)

o.Toe Kick (toe kick without slots)

p.Toe Kick

4 USA

5. DISHWASHER SPECIFICATIONS

357

911mm)-



8



/



-

(861mm

8

/

33 7

239



(5

/



16



98mm)

361

920mm)-













24”

)

4









/







mm







(610



34” - (864mm

















24”









(610

mm)















max





24”

max)



(610mm



5.1 TECHNICAL FEATURES









Load capacity



12 place settings









Permissible water



4.35 - 145 psi (0.3 - 10 bars)

pressure









Electrical connection



120 V (volts), 12 A (amps),



60 Hz (hertz)











Total power



1200 W (watts)







Heater power



1000 W (watts)









Notice :

Because we continually strive to improve our products, we may change our specifications and design without prior notice. This device corresponds to the following directives:

UL 749 Household Dishwasher directive.

5 USA

6. ENCLOSURE PREPARATION

Notice :

For proper dishwasher operation and appearance ensure that the enclosure has the minimum dimensions shown in the figure above.

6.1 ELECTRICAL PREPARATION

WARNING

To avoid electrical shock and/or a fire hazard, make sure electrical work is properly installed. Only qualified electricians should perform electrical work.

Before installation disconnect the power supply to the work area by unplugging the unit, “tripping” the circuit breaker or removing the fuse.

The installer has the responsibility of ensuring that the dishwasher electrical installation is in compliance with all national and local electrical codes and ordinances. The dishwasher is designed for an electrical supply of 120 V, 60 Hz, AC, connected to a dishwasher-dedicated, properly grounded electrical circuit with a fuse or breaker rated for 15 amperes.

(

30”)



A



WARNING

Electrical supply cords must be a minimum #14AWG copper wire.

Position the cable extending approximately 30” (760mm) from the enclosure’s back (Figure A).

Position the cable extending at the bottom (Figure B).

B

Remove 2 15/16” - 315/16” (75mm-100mm) of the cable’s outer casing, and then remove 3/8” -1/2” (9-13mm) of insulation from each wire. (Figure C)

C

6 USA
