GAS CONVECTION COUNTER STEAMER
PARTS LIST
MODEL SN-5G
Revised September 15, 2010
BLODGETT OVEN CO ▪ 44 lakeside Ave ▪ Burlington, VT 05446
Tel. 800-331-5842 ▪ Fax 802-860-3732 ▪ www.blodgett.com
PARTS LIST, GAS CONVECTION COUNTER STEAMER, MODEL SN-5G
FIGURE 1
ITEM
1. 41697 Hinge Rod 1
2. 41690 Door Assembly 1
3. 40201 Pan Rack 2
4. 41198 Left Hand Side and Back Panel 1
5. 40843 Rack Pin Assembly 4
6. 40369 Steam Diverter 2
7. 40114 Hex Nut 1
8. 40112 Lock Washer 1
9. 41632 Washer 1
10. 41631 Striker 1
11. 42542 Control Decal 1
12. 40945 Pilot Light - Green 2
13. 40950 Pilot Light - Red 1
Part # DESCRIPTION QTY.
** 14. 42456 Dial - 60 Minutes 1
42456 Dial - 120 Minutes 1
15. 41059 Compartment Strainer 1
16. 41633 Perforated Door Trough 1
17. 41182 Operation Instruction Decal 1
** 18. 41860 Fuse, 2A, 250V, (120V Unit) 1
41859 Fuse, 1A, 250V, (220V Unit) 1
19. 41844 Fuse Holder 1
20. 41190 Component Mounting Board 1
21. 41887 Operating Thermostat 1
22. 42095 Relay 2
23. 43174 Power Switch 1
24. 40487 Buzzer 1
25. 40707 End Section 1
ITEM
40708 Terminal Block Section 2
26. 40840 Ground Lug 1
** 27. 42452 Level Control, 10K, OHM, 120V 1
40625 Level Control, 10K, OHM, 208V 1
41063 Level Control, 1 M, OHM, (Optional) 1
41064 Level Control, 1 M, OHM, 208V 1
28. 41093 Ignition Module, (3 Try) 1
40871 Wire Harness 1
29. 42093 Relay 1
30. 40076 Screw, 10-32 x ½ 17
31. 41197 Right Hand Side Panel 1
32. 40443 Elbow, 3/8 c x 1/8 MPT. 2
32A. 40441 Elbo w, 1/4 c x 1/8 MPT 1
Part # DESCRIPTION QTY.
33. 40424 Connector, 1/4 c x 1/8 MPT 1
34. 41036 Solenoid Valve 2
35. 42706 Cord Set, 120V 1
36. 42137 Door Switch 1
42285 Switch Actuator c/w Clip 1
** 37. 40972 Timer, 60 Minutes 1
43275 Timer, 120 Minutes 1
38. 43572 Hose Barb Elbow 2
** 39. 41052 Right Hand Steam Jet Tube 1
** * 39. 41053 Left Hand Steam Jet Tube 1
40. 41359 Generator Tank 1
41. 40879 High Limit Sensor 1
42. 40450 Elbow, ½ c x 3/4 MPT 1
43. 40601 Blowdown Solenoid 1
44. 40421 Connector, 5/8 c x 3/4 MPT 1
PARTS LIST, GAS CONVECTION COUNTER STEAMER, MODEL SN-5G
ITEM
45. 41044 Down Tube 1
46. 43280 Elbow, 3/4" 1
47. 43279 Nipple, 3/4" x 2 ½" 1
48. 41078 Relief Valve, 5 PSI 1
49. 40794 Top Cover 1
50. 43276 Plug, 3/4" 1
51. 43277 Tee, 3/4" 1
52. 43278 Close Nipple, 3/4" 1
53. 40472 Probe - Low Level Cut Off 1
54. 40470 Probe - High Level 1
55. 40471 Probe - Low Level 1
56. 43288 Flue Assembly 1
57. 43419 Flue Cover Assembly 1
Part # DESCRIPTION QTY.
58. 43018 Screw, 1/4 - 20 x ½ 6
** 59. 40406 Right Hand Union Connector, ½ C 1
* 40411 Left Hand Elbow, ½ C 1
*** 43571 Hos e Clamp 1
60. 41881 Rotary Shaft Seal 1
** 61. 41194 Right Hand Side Riser 1
* 61. 41193 Left Hand Side Riser 1
62. 41191 Front Riser 1
* 41192 Rear Riser 1
63. 41135 Appliance Leg 4
* 64. 41142 Wire Harness 1
* 65. 40205 Thermostat Bulb Fitting 1
* 66. 40475 Water Supply Connector 2
* NOT SHOWN.
** SELECT AS REQUIRED.
PARTS LIST, GAS CONVECTION COUNTER STEAMER, MODEL SN-5G
FIGURE 2
FIGURE 2
ITEM
1. 41649 Door Frame 1
2. 41675 Door Handle Assembly 1
42258 Door Handle Decal 1
3. 41679 Latch Assembly 1
4. 41699 Bushing 4
5. 43264 Spacer 2
6. 41671 Door Panel 1
7. 41657 Door Gasket 1
8. 41664 Gasket Plate 1
9. 41874 Gasket Panel Screws 8
10. 41690 Door Assembly 1
Blod. # DESCRIPTION QUANTITY
FIGURE 3
PARTS LIST, GAS CONVECTION COUNTER STEAMER, MODEL SN-5G
BURNER PARTS, NATURAL GAS ONL Y
ITEM
1. 41035 Spark Electrode 1
2. 41033 Spark Electrode Bracket 1
3. 41184 Gas Manifold Assembly 1
4. 40386 Orifice #43 2
5. 41813 Plug, 1/8 NPT 1
6. 41185 Burner Mounting Bracket 1
7. 41183 Burner 2
8. 41056 Burner Support 1
9. 40270 Fender Washer, 1/4 2
10. 43015 Hex Cap Screw, 1/4 - 20 x 1 ½ 1
11. 43005 Machine Screw, 10 - 32 x 3/8 2
12. 43420 Hex Cap Screw, 1/4 - 20 x ½ 1
43284 Lock Washer, 1/4 1
Part # DESCRIPTION QUANTITY
13. 43285 Machine Screw, 8 - 32 x 3/8 4
14. 43421 Machine Screw, 6 - 32 x 3/8 1
FIGURE 4
BURNER PARTS - PROPANE GAS ONLY
ITEM
1. 43286 Hex Screw, 8 - 32 x 1/4 4
2. 41094 Pilot Burner 1
3. 41237 Burner Mounting Bracket 1
4. 43010 Machine Screw 2
5. 42446 Spark Electrode 1
6. 42805 Pilot Tube 1
7. 43422 Machine Bolt 2
8. 41813 Plug, 1/8 NPT 1
9. 41298 Gas Manifold Assembly 1
10. 40441 Elbow, 1/4 C x 1/8 MPT 1
11. 42736 Jet Orifice, #63 4
12. 41238 Twin Burners 2
13. 43002 Sheet Metal Screw 4
Part # DESCRIPTION QUANTIT
Y
14. 43011 Machine Screw 2
* 15. 41362 Burner Kit, Natural to Propane
Conversion
* NOT SHOWN.
1
PARTS LIST, GAS CONVECTION COUNTER STEAMER, MODEL SN-5G
FIGURE 5
ITEM
1. 40551 Ball Valve, 3/4" 1
2. 43077 Screw, #10 - 32 x 12 2
3. 41187 Gas Supply Pipe Assembly 1
4. 41872 Reducing Coupling 1
5. 41790 90 Degree Street Elbow 1
6. 41779 Close Nipple, ½" 1
7. 40616 Union Elbow, ½" 1
** 8. 41045 Combination Gas Control - Natural 1
41046 Combination Gas Control - Propane 1
9. 41804 Flex Tube, ½" x 18 1
** SELECT AS REQUIRED.
Blod. # DESCRIPTION QUANTITY
