SC-6DS,SC-10DS and SC-16DS
DIRECT STEAM CONVECTION STEAMER
INSTALLATION – OPERATION – MAINTENANCE
BLODGETT OVEN COMPANY
www.blodgett.com
44 Lakeside Avenue, Burlington, Vermont 05401 USA Telephone (800) 331-5842, (802) 860-3700 Fax: (802) 864-0183
S00048 Rev C (12/08)
1
![](/html/05/05c6/05c65c59eddc689aee9621029625fa97eafce4a1bc67fdeefe86701e53287c47/bg2.png)
IMPORTANT NOTES FOR INSTALLATION AND OPERATION
It is recommended that this manual be read thoroughly and that all instructions be
followed carefully.
This is the safety alert symbol. It is used to alert you to
potential personal injury hazards. Obey all safety messages
that follow this symbol to avoid possible injury or death.
WARNING: Improper installation, operation, adjustment,
alteration, service or maintenance can cause property damage,
injury or death. Read the installation, operating and
maintenance instructions thoroughly before installing,
operating or servicing this equipment.
CAUTION: Operating, testing, and servicing should only be
performed by qualified personnel.
NOTICE: Contact the factory, the factory representative or local service
company to perform maintenance and repairs.
Intended for commercial use only. Not for household use.
This manual should be retained for future reference.
2
![](/html/05/05c6/05c65c59eddc689aee9621029625fa97eafce4a1bc67fdeefe86701e53287c47/bg3.png)
TABLE OF CONTENTS
DESCRIPTION PAGE
Important Notes 2
1.0 Service Connections 4
2.0 Installation Instructions 5
3.0 Operating Instructions 8
4.0 Periodic Maintenance 9
5.0 Troubleshooting 9
6.0 Cooking Chart 10
3
![](/html/05/05c6/05c65c59eddc689aee9621029625fa97eafce4a1bc67fdeefe86701e53287c47/bg4.png)
1.0 SERVICE CONNECTIONS
ELECTRICAL CONNECTION: 1/2" conduit connection to controls. 120VAC-60Hz-1PH 2 AMPS
DRAIN: 2" IPS piped to open floor drain. No Solid Connection.
COLD WATER: 3/8" O.D. tubing at 25-50 PSI (170-345 kPa).
STEAM SUPPLY: 3/4" IPS for in coming steam at 80 lbs./hr. @ 10 psi. (36 kg/hr @ 69 kPa) min. 100 psi (690 kPa)
S
maximum supply pressure
DIMENSIONS ARE IN INCHES [MM]
55.5 [1410] SC-6DS
68.50 [1740] SC-10DS
67 [1702] SC-16DS
REAR FLANGED FOOT DETAIL
2 EQUALLY SPACED Ø
ON 2.5 [63] B.C.
S
7/16" [11mm] HOLES
2.75 [70]
3.5 [89]
1.5 [38]
9.5 [241]
28 [711]
18 [457] SC-6DS &
SC-10DS
17 [432]
8.75 [222]
6 [152] SC-16DS
5.75 [146]
0 [0]
20.5 [521]
24 [610]
15.25 [387]
2 [51]
0 [0]
16.75 [425]
SC-6DS & SC-10DS TOP VIEW
0 [0]
2.5 [64]
10 [254]
S
33 [838]
25 [635]
SC-16DS TOP VIEW
S
4
