Blodgett CB24-24E Parts List

g
PARTS LIST
ELECTRIC BOILERS MODELS: CB24-24E CB36-36E
CB36-42E
BLODGETT OVEN CO 44 lakeside Ave Burlington, VT 05446
Tel. 800-331-5842 Fax 802-860-3732 www.blod
April 6, 2007
CB36-24E
ett.com
1 2009-11-02
FIGURE 1
2 2009-11-02
FIGURE 1
ITEM
Part # DESCRIPTION QUANTITY ** 1 41199 Appliance Drain (Pressureless) 1 41200 Appliance Drain (Pressure) 1 2 41814 Square Plug 1/4 NPT 1 3 40431 Connector 3/8C x 3/8 NPT 1 4 41791 Street Elbow 3/4 NPT 150 # 1 5 42962 Close Nipple 3/4" 2 * ** 6 40551 Ball Valve 1 40604 Blowdown Solenoid 1 7 43279 Nipple 3/4 x 2-1/2" 1 8 41789 Elbow 3/4", 150 # 3 9 42966 Nipple 3/4 x 3" 1 10 42942 Ground Joint Union 3/4", 150 # 1 11 40576 Pressure Gauge 30 PSI 1 12 40445 Elbow 3/8C x 3/8 NPT 1 13 40431 Connector 3/8C x 3/8 NPT 2 14 42939 Tee 3/8", 150 # 1 15 40617 Union Elbow 3/4" 1 16 40439 Elbow 3/4C x 3/4 NPT 1 17 40444 Elbow 3/8C x 1/4 NPT 1 18 41009 Water Level Control 1 * 41748 Float 1 * 41747 Switch 1 * 41745 Round Gasket 1 * 41746 Square Gasket 1 * 18 41749 Blowdown Valve 1 ** 19 42371 Anode-Screw Type 1 * 41728 Anode 1
3 2009-11-02
ITEM Part # DESCRIPTION QUANTITY 20 40996 Condensate Thermostat 1 21 43378 Element Cover 1 22 40098 Hex Bolt 5/16 - 18 x 3/4 4 Per
Element ** 23 41379 Element, 24 kW, 208V 1 41380 Element, 24 kW, 240V 1 41381 Element, 24 kW, 480V 1 41385 Element, 24 kW, 220/380V 1 42223 Element, 24 kW, 347V, (600V), 1 41375 Element, (18 kW), 36 kW, 208V 2 41376 Element, (18 kW), 36 kW, 220/380V 2 41377 Element, (18 kW), 36 kW, 240V 2 41378 Element, (18 kW), 36 kW, 480V 2 42220 Element, (18 kW), 36 kW, 347V, (600V) 2 41375 Element, (18 kW), 42 kW, 208V 1 41379 Element, (24 kW), 42 kW, 208V 1 41376 Element, (18 kW), 42 kW, 220/380V 1 41385 Element, (24 kW), 42 kW, 220/380V 1 41377 Element, (18 kW), 42 kW, 240V 1 ** 23 41380 Element, (24 kW), 42 kW, 240V 1 41378 Element, (18 kW), 42 kW, 480V 1 41381 Element, (24 kW), 42 kW, 480V 1 42220 Element, (18 kW), 42 kW, 347V (600V) 1 42223 Element, (24 kW), 42 kW, 347V (600V) 1 41380 Element, (24 kW), 48 kW, 240, 415, 240/415V 2 41385 Element, (24 kW), 48 kW, 220/380, 380V 2 41381 Element, (24 kW), 48 kW, 480V 2 42223 Element, (24 kW), 48 kW, 347V (600V) 2 24 41619 Element Gasket 2
4 2009-11-02
ITEM Part # DESCRIPTION QUANTITY 25 43364 Square Plug 3/4" 1 ** 26 42316 Blank Plate 1 * 42336 Mounting Plate complete with Anode 1 27 41501 Boiler Shell 1 28 40618 Water Gauge Assembly 1 * 41877 Water Gauge Glass - 4-3/4" 1 * 41741 Rods 2 * 41743 Rubber Washers 2 * 41744 Brass Washers 2 29 40611 Relief Valve 15 PSI 1 30 42957 Nipple, ½ x 4" Brass 1 31 41797 Ground Joint Union ½", 150 # 1 32 41970 Street Elbow, ½", 150# 2 33 40432 Connector, 3/8C x ½ NPT 1 34 40615 Steam Trap, ½" 1 35 42938 Tee, 3/4 x ½ x 3/4, 150# 1 36 40578 Pressure Regulator, 3-15 PSI 1 37 42811 Drain Assembly (Pressure) 1 38 42949 Reducer Bushing 1 x 3/4 NPT 1 39 40431 Connector, 3/8C x 3/8 NPT 1 40 404030 Connector, 3/8C x 1/4 NPT 1 41 42216 Drain Hose (Pressureless) 2 42 41800 Gear Clamp 4 43 41890 High Limit Box Cover 1 44 41888 High Limit Thermostat 1 * 43008 Screw 6-32 x 1/4 2 45 43364 Square Head Plug, 3/4 NPT 1
5 2009-11-02
STANDARD CONTROLS
FIGURE 2
6 2009-11-02
FIGURE 2
ITEM
Part # DESCRIPTION QUANTITY 1 40809 Pressure Switch complete with Transducer 2 2 40459 Tee, 1/4C x 1/4 NPT 1 3 40444 Elbow, 1/4 C x 1/4 NPT 1 4 41862 Fuse Holder 1 ** 5 41861 Fuse, 3 Amp., 250V 1 42971 Fuse, 2 Amp., 250V (480V, 42 kW) 1 6 40945 Pilot Light - Green 1 7 41883 ON/OFF Switch 1 8 43007 Screw, 10 - 32 x 1/4 4 9 41456 Control Box Cover 1 10 40443 Elbow, 3/8C x 1/8 NPT 3 11 40592 Water Fill Valve 1 12 40590 Condensate Valve 1 13 40429 Connector, 3/8C x 1/8 NPT 1 ** 14 40981 Transformer, 208/120, 60 Hz, 200VA 1 40978 Transformer, 220/110, 50/60 Hz, 200VA 1 40978 Transformer, 240/120, 50/60 Hz, 200VA 1 40979 Transformer, 380/120, 50/60 Hz, 200VA 1 40979 Transformer, 415/120, 50/60 Hz, 200VA 1 40978 Transformer, 480/120, 50/60 Hz, 200VA 1 42733 Transformer, 600/120, 60 Hz, 200VA 1 15 40734 Terminal Block Section 3 16 40733 End Section 1 17 40708 Terminal Block Section 2 18 40707 End Section 1 19 40840 Ground Lug 1 * 42013 Earth I.D. Tag 1
7 2009-11-02
ITEM Part # DESCRIPTION QUANTITY 20 43009 Screw, 8-32 x 1/4 2 ** 21 40919 Contactor, 24 kW, 208, 220, 240V 2 40919 Contactor, 24 kW, 380, 415, 600, 220/380,
240/415V 40922 Contactor, 36 kW, 208V 2 40919 Contactor, 36 kW, 220, 240V 2 40922 Contactor, 36 kW, 380, 415, 220/380, 240/415V 1 40919 Contactor, 36 kW, 480, 600V 1 40922 Contactor, 42 kW, 208, 220, 240V 2 40924 Contactor, 42 kW, 380, 22/380V 1 40922 Contactor, 42 kW, 415, 480, 240/415V 1 40919 Contactor, 42 kW, 600V 1 40922 Contactor, 48 kW, 240V 2 40924 Contactor, 48 kW, 380, 415, 220/380, 240/415V 1 40922 Contactor, 48 kW, 480V 1 40919 Contactor, 48 kW, 600V 1
* NOT SHOWN. ** SELECT AS REQUIRED.
1
8 2009-11-02
CSD-1 CONTROL BOX FIGURE 3
9 2009-11-02
FIGURE 3
ITEM
Part # DESCRIPTION QUANTITY 1 40809 Pressure Switch complete with Transducer 2 2 40459 Tee, 1/4C x 1/4 NPT 1 3 40442 Elbow, 1/4C x 1/4 NPT 1 4 41862 Fuse Holder 1 ** 5 41861 Fuse, 3 Amp., 250V 1 41860 Fuse, 2 Amp., 250V (480V, 42 kW) 1 6 40945 Pilot Light, Green 1 7 41883 ON/OFF Switch 1 8 42858 Control Panel 1 9 41216 Control Decal 1 10 40950 Pilot Light, Red 3 11 40948 Pilot Light, Amber 1 12 41746 Reset Switch 1 13 43007 Screw 10-32 x 1/4 4 14 42729 Control Box Cover 1 15 40443 Elbow, 3/8C x 1/8 NPT 3 16 40592 Water Fill Valve 1 17 40590 Condensate Valve 1 18 40429 Connector, 3/8C x 1/8 NPT 1 ** 19 40981 Transformer, 208/120, 60 Hz, 200VA 1 40978 Transformer, 220/110, 50/60 Hz, 200VA 1 40978 Transformer, 240/120, 50/60 Hz, 200VA 1 40979 Transformer, 380/120, 50/60 Hz, 200VA 1 40979 Transformer, 415/120, 50/60 Hz, 200VA 1 ** 19 40978 Transformer, 480/120, 50/60 Hz, 200VA 1 42733 Transformer, 600/120, 60 Hz, 200VA 1 20 40734 Terminal Block Section 3
10 2009-11-02
ITEM Part # DESCRIPTION QUANTITY 21 40733 End Section 1 22 42095 Relay Single Pole, 120V 2 23 40840 Ground Lug 1 * 42013 Earth I.D. Tag 1 24 43009 Screw 8-32 x 14 2 25 40708 Terminal Block Section 2 26 40707 End Section 1 ** 27 40919 Contactor, 24 kW, 208, 220, 240V 2 40919 Contactor, 24 kW, 380, 415, 600, 220/380,
240/415V 40922 Contactor, 36 kW, 208V 2 40919 Contactor, 36 kW, 220, 240V 2 40922 Contactor, 36 kW, 380, 415, 220/380, 240/415V 1 40919 Contactor, 36 kW, 480, 600V 1 40922 Contactor, 42 kW, 208, 220, 240V 2 40924 Contactor, 42 kW, 380, 22/380V 1 40922 Contactor, 42 kW, 415, 480, 240/415V 1 40919 Contactor, 42 kW, 600V 1
1
11 2009-11-02
Part # DESCRIPTION QUANTITY
ITEM
** 27 40922 Contactor, 48 kW, 240V 2 40924 Contactor, 48 kW, 380, 415, 220/380, 240/415V 1 40922 Contactor, 48 kW, 480V 1 40919 Contactor, 48 kW, 600V 1 28 41010 Secondary Low Water Cut Off 1 * 41011 Probe 1
* NOT SHOWN. ** SELECT AS REQUIRED.
12 2009-11-02
FIGURE 4
13 2009-11-02
FIGURE 4
CABINET 28" HEIGHT
ITEM Part #
1 43366 Side Panel 2 2 2 2 41140 Magnet Catch 1 2 2 40006 Catch Screw 4 8 8 3 42663 Cabinet Door 1 * 41466 Right Hand Door 1 * 41468 Left Hand Door 1 * 42324 Right Hand Door 1 * 42331 Left Hand Door 1 4 40418 Water Connection 1 1 1
DESCRIPTION 24" 36" 48"
WIDTH
14 2009-11-02
CABINET 32" HEIGHT
FIGURE 4
ITEM Part # DESCRIPTION 24" 36" 42" 44" 48" 60"
1 41473 Side Panel 2 2 2 2 2 2 2 41140 Magnetic Catch 1 2 2 2 2 3 40006 Catch Screws 4 8 8 8 8 12 3 43379 Door 1 * 41467 Right Hand Door 1 * 41469 Left Hand Door 1 * 42329 Right Hand Door 1 * 42335 Left Hand Door 1 * 42323 Right Hand Door 1 * 42330 Left Hand Door 1 * 42328 Right Hand Door 1 * 42334 Left Hand Door 1 * 42326 Right Hand Door 1
WIDTH
* 42333 Left Hand Door 1 * 42327 Centre Door 1 4 40418 Water Connection 1 1 1 1 1
* NOT SHOWN.
15 2009-11-02
