PARTS LIST
BLODGETT GAS BOILERS
M O D E L S : C B 2 4 - 1 4 0 G
CB24-200G
BLODGETT OVEN CO ▪ 44 lakeside Ave ▪ Burlington, VT 05446
Tel. 800-331-5842 ▪ Fax 802-860-3732 ▪ www.blodgett.com
1 2009-11-02
FIGURE 1
GAS BOILER SHELLS 24” WIDE
(Choose Replacement boiler shell based on description and shape of flue)
ITEM
PART NO. DESCRIPTION
1 41731 200,000, 250,000, 300,000 BTU
USED ON ALL COOKERS IN 36”
CABINET BASE OR LARGER
ALSO BOILER BASE UNITS
I.E. CB36-200G LOW RECTANGULAR
FLUE
2 41732 200,000, 250,000, 300,000 BTU
USED ON UNITS THAT HAVE 6 GAL.
DIRECT STEAM KETTLE MOUNTED
ON THE CABINET WITH COOKER
HIGH RECTANGULAR FLUE
3 41733 200,000, 250,000, 300,000 BTU
USED ON UNITS THAT HAVE 10 GAL.
DIRECT STEAM KETTLE MOUNTED
ON THE RIGHT HAND SIDE OF
CABINET WITH A COOKER
FLUE DROPS DOWN ON RIGHT SIDE
4 41734 200,000, 250,000, 300,000 BTU
FLUE DROPS DOWN ON BOTH SIDES
5 41735 200,000, 250,000, 300,000 BTU
USED WITH A 42” CABINET BASE
FLUE DROPS DOWN ON LEFT SIDE
2 2009-11-02
PARTS LIST, GAS BOILERS, MODELS CB24-140G, CB24-200G
FIGURE 2
PARTS LIST, GAS BOILERS, MODELS CB24-140G, CB24-200G
FIGURE 2
ITEM
Part # DESCRIPTION 140 200
1 42096 Top Insulation Panel 1 1
** 2 42371 Cathodic Descaler (Screw Type) 1 1
* 41727 Cathodic Descaler 1 1
3 40416 Connector 3/8C x 1/4 MP 1 1
4 40576 Pressure Gauge 1 1
5 40444 Elbow 3/8C x 1/4 MP 1 1
6 40877 Safety Sensor 1 1
7 41477 Sensor Box 1 1
8 41504 Cover Plate 1 1
9 41505 Hand Hole Gasket 1 1
10 41506 Yoke 1 1
11 40208 Nut 1 1
12 43045 Water Gauge Assembly 1 1
* 41879 Gauge Glass 5-1/2" 1 1
* 41741 Rod 2 2
* 41743 Rubber Washer 2 2
* 41744 Brass Washer 2 2
13 42942 Union 3/4" 1 1
14 42925 Nipple 3/4" x 1.75" 1 1
15 41791 St. Elbow 3/4" 1 1
** 16 41156 Combination Gas Control, Natural 1
41157 Combination Gas Control, LP 1
41158 Combination Gas Control, Natural 1
41159 Combination Gas Control, LP 1
** 16 41103 Combination Gas Control, Natural, Electronic Ignition 1
41104 Combination Gas Control, LP, Electronic Ignition 1
41105 Combination Gas Control, Nat, Electronic Ignition 1
41106 Combination Gas Control, LP, Electronic Ignition 1
PARTS LIST, GAS BOILERS, MODELS CB24-140G, CB24-200G
ITEM Part # DESCRIPTION 140 200
17 40617 Union Elbow 3/4" 1 1
18 42925 Nipple 3/4 x 2.125" 2 2
19 41789 Elbow 3/4" 1 1
20 41502 Manifold Assembly 1
40250 Manifold Assembly 1
21 43261 Orifice Nipple 5 5
** 22 42297 Orifice #37, Natural 5
42304 Orifice #52, LP 5
42296 Orifice #31, Natural 5
42302 Orifice #49, LP 5
** 23 40238 Burner 5
* 41481 Burner complete with Pilot Burner Bracket 1
* 41482 Burner Assembly, Electronic Ignition 1
* 41480 Burner 4
24 42022 Burner Box 1
42865 Burner Box 1
25 40639 Pilot Burner Bracket 1
** 26 41160 Pilot Burner, Natural 1 1
41161 Pilot Burner, LP 1 1
** 26 42349 Pilot complete with Ignitor Natural, Electronic Ignition 1 1
42350 Pilot complete with Ignitor LP, Electronic Ignition 1 1
27 41163 Thermocouple 1 1
28 42099 Front Insulation Panel 1 1
* NOT SHOWN.
** SELECT AS REQUIRED.
PARTS LIST, GAS BOILERS, MODELS CB24-140G, CB24-200G
FIGURE 3
PARTS LIST, GAS BOILERS, MODELS CB24-140G, CB24-200G
ITEM
Part # DESCRIPTION 140 200
1 43364 Square Plug 3/4" 1 1
2 43363 Tee 3/4 x ½ x 3/4 1 1
3 40615 Steam Trap ½" 1 1
4 40418 Connector 3/8C x ½ FPT 1 1
5 41790 St. Elbow ½" 1 1
6 40422 Connector 3/4C x 3/4 MPT 2 2
7 40611 Relief Valve 15 PSI 1 1
8 43364 Square Plug 3/4" 1 1
9 41792 Tee 3/4" 1 1
10 43380 Nipple 3/4 x 2-1/4" 1 1
11 41789 Elbow 3/4" 1 1
FIGURE 3
12 41009 Low Water Cut Off Control 1 1
* 41748 Float 1 1
* 41747 Switch 1 1
* 41745 Round Gasket 1 1
* 41746 Square Gasket 1 1
* 41749 Blowdown Valve 1 1
13 40297 Square Plug-Brass 1/4" 1 1
14 40445 Elbow 3/8C x 3/8 MPT 2 2
15 40290 Elbow 3/8" 1 1
16 42951 Square Plug 3/8" 1 1
17 43381 Union Coupling 3/4C 1 1
18 42967 Nipple ½ x 3-1/2" Brass 1 1
19 41797 Union 150# ½" 1 1
20 41790 Street Elbow ½" 1 1
21 42098 Right Hand Side Panel 1 1
22 41065 Drain Tube Assembly, Level Control 1 1
* NOT SHOWN.
PARTS LIST, GAS BOILERS, MODELS CB24-140G, CB24-200G
FIGURE 4
PARTS LIST, GAS BOILERS, MODELS CB24-140G, CB24-200G
Part # DESCRIPTION 140 200
ITEM
1 40444 Elbow 3/8C x 1/4 MPT 2 2
2 40595 Over Ride Solenoid 1 1
3 40445 Elbow 3/8C x 3/8 MPT 1 1
4 40431 Connector 3/8C x 3/8 MPT 2 2
5 42939 Tee 3/8" 1 1
6 42970 Close Nipple 3/8" 1 1
7 42941 Reducer Tee 3/4 x 3/8 x 3/4 1 1
8 42962 Close Nipple 3/4 Brass 1 1
9 42097 Left Hand Side Panel 1 1
FIGURE 4
10 42968 Nipple 3/4 x 5-1/2 Brass 1 1
11 42954 Pipe Cap 3/4" 1 1
12 43382 Connector 3/8C x 3/4 MPT 1 1
13 42949 Reducer Bushing 1 x 3/4 1 1
14 41814 Square Plug 1/4" 2 2
15 40422 Connector 3/4C x 3/4 MPT 1 1
** 16 41199 Appliance Drain (Pressure-less) 1 1
41200 Appliance Drain (Pressure) 1 1
17 41791 St. Elbow 3/4" 2 2
18 42924 Nipple 3/4 x 1-1/2" 2 2
19 41797 Union 150 # ½" 1 1
** 20 40551 Ball Valve (Manual Blowdown) 1 1
40604 Blowdown Valve 1 1
21 42932 Nipple 3/4 x 5-3/8" 1 1
22 40430 Connector 3/8C x 1/4 MPT 1 1
23 42683 Baffle Plate 1 1
24 41789 Elbow 3/4" 2 2
PARTS LIST, GAS BOILERS, MODELS CB24-140G, CB24-200G
ITEM Part # DESCRIPTION 140 200
25 42926 Nipple, 3/4 x 2-7/8" 1 1
26 42927 Nipple, 3/4 x 3-1/4" 1 1
27 42933 Nipple, 3/4 x 5-7/8" 1 1
28 42937 Tee 1 x 1 x 3/4 1 1
29 42952 Square Plug 1" 1 1
30 42216 Drain Hose 2 2
31 41800 Gear Clamp 4 4
32 42944 Liquid Tite Elbow 3/8 3 3
33 42945 Liquid Tite Connector 1 1
** 34 43383 Exhaust Drain (Pressure) 1 1
** SELECT AS REQUIRED.
PARTS LIST, GAS BOILERS, MODELS CB24-140G, CB24-200G
F I G U R E 5
PARTS LIST, GAS BOILERS, MODELS CB24-140G, CB24-200G
ITEM
Part # DESCRIPTION 140 200
1 40809 Pressure Switch complete with Transducer 2 2
2 40459 Tee, 1/4C 1 1
3 40442 Elbow, 1/4C x 1/4 MP 1 1
4 40945 Pilot Light - Green, 125V 1 1
5 41883 Power Switch 1 1
6 41455 Control Box Cover 1 1
7 40071 Cover Screws 4 4
8 40443 Elbow, 3/8C x 1/8 MP 3 3
9 40592 Water Fill Solenoid 1 1
FIGURE 5
10 40590 Cooling Solenoid 1 1
11 40429 Connector 3/8C x 1/8 MP 1 1
12 40068 Terminal Block Screws 4 4
13 40708 Terminal Block Section 2 2
14 40707 End Section 1 1
15 40996 Drain Thermostat 1 1
16 40011 Thermostat Screws 2 2
PARTS LIST, GAS BOILERS, MODELS CB24-140G, CB24-200G
CSD-1 CONTROLS
FIGURE 6
PARTS LIST, GAS BOILERS, MODELS CB24-140G, CB24-200G
CSD1 CONTROLS
Part # DESCRIPTION 140 200
ITEM
1 40809 Pressure Switch complete with Transducer 3 3
2 40442 Elbow, 1/4C x 1/4 MP 3 3
3 40945 Pilot Light, Green, 125V 1 1
4 41883 Power Switch 1 1
5 42859 Inner Panel 1 1
6 41216 Decal 1 1
7 42727 Control Box Cover 1 1
8 40950 Pilot Light - Red, 125V 3 3
9 40948 Pilot Light - Amber, 125V 1 1
10 41729 Reset Switch 1 1
FIGURE 6
11 40071 Cover Screws 4 4
12 40443 Elbow, 3/8C x 1/8 MP 3 3
13 40592 Waterfill Solenoid 1 1
14 40590 Cooling Solenoid 1 1
15 40429 Connector, 3/8C x 1/8 MP 1 1
16 40068 Terminal Block Screws 4 4
17 40708 Terminal Block Section 2 2
18 40707 End Section 1 1
19 42095 Relay - Single Pole, 120V 2 2
20 40996 Drain Thermostat 1 1
21 40011 Thermostat Screws 2 2
22 41010 Low Water Cut Off Secondary 1 1
* 41011 Probe 1 1
* NOT SHOWN.
PARTS LIST, GAS BOILERS, MODELS CB24-140G, CB24-200G
F I G U R E 7
ELECTRONIC IGNITI ON PART S
ITEM
Part # DESCRIPTION QUANTITY
1 40957 Relay 1
2 40664 Control Box Cover 1
3 42352 Ignition Cable 1
4 41885 Transformer, 115/230-24V, 50/60 Hz, 50VA 1
5 42351 Ignition Module 1
PARTS LIST, GAS BOILERS, MODELS CB24-140G, CB24-200G
FIGURE 8
CABINET
PARTS LIST, GAS BOILERS, MODELS CB24-140G, CB24-200G
24" CABINET
ITEM
Part # DESCRIPTION QUANTITY
1 43366 Side Panel 2
2 42663 Cabinet Door 1
3 41140 Magnet Catch 2
40006 Catch Screw 4
** 4 40152 Flue (140,000 BTU) 1
40153 Flue (GCX-2) 1
40154 Flue (GCX-10) 1
42626 Flue (200,000 BTU) 1
FIGURE 8
** 5 42664 Flue Cover (GCX-2-140, CG140, CG200) 1
43102 Flue Cover (GCX-10) 1
6 40418 Water Connection 1
** SELECT AS REQUIRED.
PARTS LIST, GAS BOILERS, MODELS CB24-140G, CB24-200G
CABINET 28" HEIGHT
Part #
43366 Side Panel 2 2 2
41466 Right Hand Door (3204-1) 1
41468 Left Hand Door (3209-1) 1
42663 Door 1
42324 Right Hand Door 1
42331 Left Hand Door 1
41140 Magnetic Catch 1 2 2
40006 Catch Screws 4 8 8
DESCRIPTION CABINET WIDTH
36" 48"
24"
PARTS LIST, GAS BOILERS, MODELS CB24-140G, CB24-200G
CABINET 32" HEIGHT
Part #
43366 Side Panel 2 2 2 2 2 2
43384 Door 1
41467 Right Hand Door 1
41469 Left Hand Door 1
42329 Right Hand Door 1
42335 Left Hand Door 1
42323 Right Hand Door 1
42330 Left Hand Door 1
42328 Right Hand Door 1
42334 Left Hand Door 1
42326 Right Hand Door 1
42333 Left Hand Door 1
42327 Centre Door 1
DESCRIPTION CABINET WIDTH
36" 42" 44" 48” 60"
24"
41140 Magnetic Catch 1 2 2 2 2 3
40006 Catch Screws 4 8 8 8 8 12
