PARTS LIST
PRESSURELESS COOKER 6 PAN AND 10 PAN UNITS
Boiler Base, Direct Steam, Kettle, Steam Coil, cabinet Base
MODELS: SB-6,10G SB-6,10E
SB-6,10SC SC-6,10DS
BLODGETT OVEN CO ▪ 44 lakeside Ave ▪ Burlington, VT 05446
Tel. 800-331-5842 ▪ Fax 802-860-3732 ▪ www.blodgett.com
1 2007-07-31
1 2007-07-31
PARTS LIST, PRESSURELESS COOKER 6 PAN & 10 PAN UNIT, MODELS SB-6G, SB-10G
ITEM
1 43516 Hinge Rod 1
2 42137 Door Switch 2 2
3 41631 Striker 2 2
PART NO.
41715 Hinge Rod 1
42285 Actuator Pin Complete With Clip 2 2
41632 Washer 2 2
DESCRIPTION QUANTITY
SB-6 SB-10
40112 Lock Washer 2 2
40114 Nut 2 2
4 43517 Control Decal 1
42577 Control Decal 1
5 40945 Pilot Light, Green 2 2
6 40950 Pilot Light, Red 2 2
7 41633 Perforated Trough 1 1
PARTS LIST, PRESSURELESS COOKER 6 PAN & 10 PAN UNIT, MODELS SB-6G, SB-10G
ITEM
** 8 43265 Dial 60 Minutes, 60 Hz 2 2
9 43264 Spacer 4 4
10 41699 Bushing 8 8
11 41691 Door Assembly 2
PART NO.
43518 Dial 60 Minutes, 50 Hz 2 2
43266 Dial 120 Minutes, 60 Hz 2 2
DESCRIPTION QUANTITY
SB-6 SB-10
41690 Door Assembly 2
12 41675 Handle Assembly 2 2
* 40648 Handle 1 1
* 40647 Handle Plate 1 1
* 40191 Socket Screw, 1/4 - 20 x 1 3/4 2 2
* 40089 Socket Screw, 1/4 - 20 x 3/4 1 1
* 12 40646 Spacer 2 2
PARTS LIST, PRESSURELESS COOKER 6 PAN & 10 PAN UNIT, MODELS SB-6G, SB-10G
ITEM
* 43519 Lock Washer, 1/4 2 2
* 40093 Nut, 1/4 - 20 2 2
* 42258 Decal 2 2
13 41679 Latch Assembly 2 2
14 41672 Door Panel 2
PART NO.
41671 Door Panel 2
DESCRIPTION QUANTITY
SB-6 SB-10
15 41658 Door Gasket 2
41657 Door Gasket 2
16 41665 Door Gasket Plate 2
41664 Door Gasket Plate 2
41875 Screws 12 16
17 40199 Pan Racks 4
40201 Pan Racks 4
PARTS LIST, PRESSURELESS COOKER 6 PAN & 10 PAN UNIT, MODELS SB-6G, SB-10G
ITEM
18 41706 Enclosure Panel 1
19 40551 Steam Control Valve 1 1
20 41925 Steam Supply Tube 2
PART NO.
41708 Enclosure Panel 1
40076 Screws 2 2
42600 Steam Supply Tube 2
DESCRIPTION QUANTITY
SB-6 SB-10
21 40573 Elbow 1 1
22 40549 Pressure Gauge 1 1
23 42142 Steam Manifold 1
23 42143 Steam Manifold 1
24 40585 Transducer 1 1
25 40442 Elbow 1/4C x 1/4 MPT 1 1
26 42145 Steam Tube 1/4 Copper 1
PARTS LIST, PRESSURELESS COOKER 6 PAN & 10 PAN UNIT, MODELS SB-6G, SB-10G
**
*
ITEM
27 40484 Buzzer 1 1
28 40972 Timer, 60 Min. 2 2
29 40447 Elbow, ½ C x 1/4 MPT 2 2 2
PART NO.
43520 Steam Tube 1/4 Copper 1
40973 Timer, 120 Min. 2 2
41881 Rotary Shaft Seal 2 2
DESCRIPTION QUANTITY
SB-6 SB-10
30 43252 Pressure Switch 1 1
31 40595 Steam Solenoid Valve 2 2
32 40460 Tee, 3/8 c x 1/4 MPT 6 6
33 42146 Steam Tube - Front 2 2
34 42147 Steam Tube - Rear 2 2
35 42215 Steam Tube - Crossover 4
40908 Steam Tube - Crossover 4
36 41710 Left Hand Side and Back Panel 1
PARTS LIST, PRESSURELESS COOKER 6 PAN & 10 PAN UNIT, MODELS SB-6G, SB-10G
*
*
*
*
ITEM
37 41702 Compartment Strainer 2 2
38 42216 Compartment Drain Hose 2 2
39 42148 Component Mounting Panel 1 1
40 41716 Top Panel 1 1
41 40614 Thermal Switch (Optional) 2 2
PART NO.
41711 Left Hand Side and Back Panel 1
DESCRIPTION QUANTITY
SB-6 SB-10
* NOT SHOWN.
** SELECT AS REQUIRED.
PARTS LIST, PRESSURELESS COOKER 6 PAN & 10 PAN UNIT, MODELS SB-6G, SB-10G
ALTERNATE PARTS
Page Item Crown Blodgett
3 4 7582-1 42901
7481-1 42902
8 4104-1 42456
11 8-5076-9 43154,
Bottom
8-5076-9 42678, Top
8-5076-8 42681,
Bottom
8-5076-8 42682, Top
12 8-5066-9 43151
4090-1 42453
4 12 9-3320 42454
