Blizzard Super G 150 Datasheet

Incredibly powerful and versatile, yet
surprisingly small… just like Prince.

Super-G™ 150 features an ultra-bright and efficient 150W
LED (7500K) light source and high precision glass optics
with a 12° projection angle. It’s as powerful as a full-size
moving head yet lives in a tiny, compact body, sort of like
one of the Olson twins.

This 150W LED beam fixture is equipped with a 7 color+
white color wheel, 1 static gobo wheel with 7 gobos, and 1
rotating gobo wheel with 6 interchangeable gobos +open.
It offers 540°/260° pan/tilt with fine 16-bit adjustments
& speed control, 3-facet prism, smooth dimming, 1-25Hz
strobe + effects, auto mode, and sound active mode.

It features 3 user-selectable DMX modes (12/13/15-channels)
allowing easy and flexible programming, plus scan position
memory and auto reposition after any unexpected
movement. It comes with an easy-to-use 4-button control
panel with high-resolution TFT LCD display, industry
standard powerCON® connections and DMX 3-pin in/out
jacks.

Super-G™ 150 may be compact, but it can compete with the
big boys. It’s the Spud Webb of moving heads.

Main Features

• 150W white 7500K LED light source

• 50,000 hour life span and low power consumption

• 8/16 bit smooth and precise Pan/Tilt

• 540°/260° Pan/Tilt movement

• Optional Pan/Tilt invert function

• High precision glass optics with 12° projection angle

• Rotating gobo wheel with 6 gobos +open

• Static gobo wheel with 7 gobos +open

• Color wheel with 7 colors plus +open

• Linear electronic focus

• Variable direction, speed adjustable rainbow color effects

• 3-facet prism with variable speed and direction

• 0-100% smooth linear LED dimmer

• 1-25Hz fps strobe + variable/random effects

• 12/13/15 DMX channels USITT DMX-512

• 2” TFT LCD display with 4 button control

• Dimensions: 6.7 x 8.9 x 14.3 inches (170 x 226 x 362 mm)

• Weight: 16.2 lbs, 7.34 kg

Optical

150W white 7500K LED

12° beam angle

Flicker-free

Linear electronic focus

Luminous Intensity:

13,641 Lux @ 2.5M

3,187 Lux @5M

Movement

Pan: 540 degree (8-16 bit

resolution)

Tilt: 260 degree (8-16 bit

resolution)

blizzardlighting.com

Control

Protocol: USITT DMX-512

12/13/15-channel DMX

modes

DMX512, standalone, M/S,

auto, & sound

3-pin DMX in/out

4-button 2” TFT LCD

display menu

[e-mail] 1.866.493.6025

Power +

Current

100-240VAC, 50-60 Hz

254W, 3.1A, PF: .71

PowerCON™ compatible

AC power In/Out

connectors

1.866.493.5025

Warranty

2-year limited warranty,

does not cover

malfunction

caused by damage to

LED
