PowerPak
Owner’s Manual
Installation Instructions
Unique Features Include:
• High cheek piece for use with optical sights
• Low cheek piece for ghost ring or factory sights
• Spare ammo ready when you need it
• Water tight storage compartment for earplugs, batteries, etc.
ATTENTION: Read and follow all instructions and warnings prior to installation
and/or firing a PowerPak System equipped SpecOps Stock. If you are at all unsure
of your ability to install the PowerPak System safely, please seek the services of a
competent gunsmith.
WARNING: Before you begin installation, make sure that the shotgun is
UNLOADED. Carefully check the chamber and magazine tube making both visual
and touch verification.
Important Notice: Once installed the PowerPak is difficult to remove, so plan con-
figuration carefully prior to installation. Consider the following: What type of sight is
being used (standard, ghost ring, rifle or optical)? Is the shooter left or right handed? Does the shooter desire to carry extra ammunition and/or spare batteries?
Parts List:
• 1 - High Cheek Piece (For use with optical or raised ghost ring sights)
• 1 - Low Cheek Piece (For use with standard bead, rifle or ghost ring sights)
• 1 - Shell Holder
• 1 - Battery/Storage Compartment (Packaged in right handed configuration)
• 1 - Ball End Wrench
• 12 - Mounting Screws (4 Long, 4 Medium, 4 Short)
www.BLACKHAWK.com
©BLACKHAWK! Products Group™NORFOLK, VA U.S.A. 1.800.694.5263
50107101 REV. 04.08
Page 1 Page 2
www.BLACKHAWK.com
©BLACKHAWK! Products Group™NORFOLK, VA U.S.A. 1.800.694.5263
Installation Instructions Installation Instructions
1. If the desired configuration involves the use of the High Cheek Piece proceed to
Step 2. If the desired configuration involves only the use of the Low Cheek Piece
proceed to Step 4.
2. Utilizing the High Cheek Piece requires the use of the Low Cheek Piece. With
the two long flat edges facing down, place the Low Cheek Piece on a level work
surface. Note: The PowerPak Logo should be readable and not upside down.
3. Take the High Cheek Piece in one hand while holding the Low Cheek Piece in a
steady position. Slide the High Cheek Piece down over the top of the Low Cheek
Piece (See Fig. 1). Note: Logo on high cheek piece should align with the logo on
low cheek piece. The High Cheek Piece should lock down and completely cover
the Low Cheek Piece. The rear portion of the High Cheek Piece should be flush
with the rear portion of the Low Cheek Piece.
If the desired configuration does not involve the use of the Shell Holder or
Battery/Storage Compartment proceed to Step 10.
4. If the desired configuration involves the use of both the Shell Holder and
Battery/Storage Compartment it easier to install the Shell Holder first. Installation
of the Shell Holder requires the use of the 4 Long Screws (1/2” OAL) and the Ball
End Wrench. Right hand shooters should install the shell holder on the right side
of the stock.
5. Align the holes in Shell Holder with the holes in the side of cheek piece(s). The
rear of the cheek piece is indicated by the PowerPak logo. The front of the Shell
Holder can be determined by the forward facing arrow molded on the inside.
6. With the Shell Holder properly aligned with the cheek piece, insert the Ball End
Wrench through the holes on the opposite side of the cheek piece (See Fig.2).
Position screw in first hole and begin threading. Hand tighten screw until snug.
Repeat for all 4 screws. If the desired configuration does not involve the use of
the Battery/Storage Compartment proceed to Step 10.
Fig. 1
