Black & Decker ODC460 User Manual

PLEASE READ AND SAVE THIS USE AND CARE BOOK. POR FAVOR LEA ESTE INSTRUCTIVO ANTES DE USAR EL PRODUCTO. VEUILLEZ LIRE ET CONSERVER CE GUIDE D’ENTRETIEN ET D’UTILISATION.
IMPORTANT / IMPORTANTE / IMPORTANT
WASH CARAFE BEFORE FIRST USE!
LAVE LA JARRA ANTES DEL PRIMER USO
LAVER LA CARAFE AVANT LA PREMIÈRE UTILISATION!
1-800-738-0245
USA/Canada 1-800-231-9786 Mexico 01-800-714-2503
www.blackanddecker.com
††
Spacemaker
™
8-Cup Thermal Coffeemaker
Cafetera Térmica de 8 tazas
Cafetière thermoverseuse de 8 tasses
Model Modelo Modèle
❑
ODC460
ODC460Pub1000002779 1/10/06 4:32 PM Page 1
2
1
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be followed to reduce the risk of fire, electric shock, and/or injury to persons, including the following:
❑
Read all instructions.
❑
Do not touch hot surfaces. Use handle or knobs.
❑
To protect against electric shock, do not place cord, plug or appliance in water or other liquids.
❑
Close supervision is necessary when any appliance is used by or near children.
❑
Unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts and before cleaning the appliance.
❑
Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions, or has been damaged in any manner. Return the appliance to the nearest authorized service facility for examination, repair, or adjustment. Or, call the appropriate toll-free number on the cover of this manual.
❑
The use of an accessory not evaluated for use with this appliance may cause injuries.
❑
Do not use outdoors.
❑
Do not let cord hang over the edge of table or counter, or come in contact with hot surfaces.
❑
Do not place on or near a hot gas or electric burner or in a heated oven.
❑
Keep the lid on the carafe when in use.
❑
Do not use this appliance for anything other than its intended use.
❑
To reduce risk of fire, do not mount coffeemaker over or near any portion of a heating or cooking appliance.
❑
To reduce risk of fire or electric shock, do not place any electric or gas heating or cooking appliance under the coffeemaker.
❑
Scalding may occur if the brew basket is removed during the brewing cycle.
❑
To reduce the risk of electric shock, do not mount over the sink.
SAVE THESE INSTRUCTIONS.
POLARIZED PLUG (120V Models Only)
This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug is intended to fit into a polarized outlet only one way. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to modify the plug in any way.
TAMPER-RESISTANT SCREW Warning : This appliance is equipped with a tamper-resistant screw to prevent removal of the outer cover. To reduce the risk of fire or electric shock, do not attempt to remove the outer cover. There are no user-serviceable parts inside.
Repair should be done only by authorized service personnel.
ELECTRICAL CORD
a) A short power-supply cord (or detachable power-supply cord) is to be provided
to reduce the risk resulting from becoming entangled in or tripping over a longer cord.
b) Longer detachable power-supply cords or extension cords are available and
may be used if care is exercised in their use.
c) If a long detachable power-supply cord or extension cord is used,
1) The marked electrical rating of the detachable power-supply cord or extension cord should be at least as great as the electrical rating of the appliance,
2) If the appliance is of the grounded type, the extension cord should be a grounding-type 3-wire cord, and
3) The longer cord should be arranged so that it will not drape over the countertop or tabletop where it can be pulled on by children or tripped over.
Note: If the power supply cord is damaged, it should be replaced by qualified personnel or in Latin America by an authorized service center.
ODC460Pub1000002779 1/10/06 4:32 PM Page 2
4
How to Use
This product is for household use only.
BEFORE FIRST USE
1. Press water reservoir release button and pull water reservoir out from unit. Remove and inventory all packing material, literature and mounting hardware.
2. Brew 8 cups of fresh water through the system using a single paper filter as instructed in Brewing Coffee, but do not add coffee grounds to the paper filter.
3. When water has brewed through, press ON/OFF button.
4. Clean water reservoir, filter basket, thermal carafe and lid. (See Cleaning.)
BREWING COFFEE
Note: Time display will flash when you plug in unit. You may set clock before, during or after brewing. (See Setting the Clock/Timer.) You do not need to set clock before brewing.
1. Remove brew basket. Place paper filter inside and add coffee to be brewed (usually one heaping tablespoon for every cup. Adjust to taste). Replace brew basket.
2. Press water reservoir release button, pull out water reservoir and fill with water through lid to desired cup level. Do not overfill reservoir. Replace water reservoir into unit until it snaps into place.
3. Replace empty thermal carafe and be sure it is "seated" in unit so that it fits against the lever at the back.
4. Press ON/OFF button. "On" appears at upper right. (To set timer for AUTO ON, see Setting the Clock/Timer.)
5. After you finish brewing and serving, press ON/OFF button to turn unit OFF.
About Your Thermal Carafe
Coffee is brewed directly through the carafe brew-thru lid. Turn the lid to the "Lock" position for brewing (align the arrow with the arrow). Coffee may overflow if the brew-thru lid is not properly in place. Thermal carafe keeps coffee hot and may be left away from the coffeemaker for serving. To pour coffee, align pour option on the brew-thru lid with arrow on the handle and proceed to serve. When finished, realign lock arrow with handle and replace thermal carafe. To clean thermal carafe and brew thru lid, unlock brew thru lid by turning lid in unlock direction. After cleaning, replace brew thru lid on thermal carafe and twist towards lock direction until Lock arrow is aligned with handle.
Sneak-A-Cup® Interrupt Feature lets you pour a cup before brewing is complete. To serve a cup, remove the thermal carafe from the coffeemaker and pour. Replace the carafe under the brew basket and the brewing process will continue.
Note: After pouring, replace thermal carafe immediately to prevent overflow. Caution: Do not pull out brew basket when using this feature as it is filled with
hot coffee.
SETTING THE CLOCK/TIMER
You may set the clock before, during or after a brew cycle. To set current time: Press the HOUR, then MIN buttons until you reach the
current time. Hold down buttons to advance quickly.
3
Product may vary slightly from what is illustrated.
1. Digital display
2. Time/program buttons
3. Reservoir cover †4.Water reservoir with level markings (Part # ODC440-01) †5.8-cup thermal carafe (2365 ml) (Part # ODC460-03) †6.Brew-thru lid (Part # ODC460-04)
7. Sneak-A-Cup® Interrupt (under basket) †8.Brew basket (Part # ODC450-01) †9.Mounting bracket (Part # ODC440-06)
† Consumer replaceable/removables parts
† Mounting parts (Part # ODC440-06)
10. 4 screws
11. 4 square nuts
12. Set of 4 washers
13. Set of 32 spacers
MOUNTING PARTS
See separate sheet for additional instruction
ODC460Pub1000002779 1/10/06 4:32 PM Page 4
6
Cuando se utilizan aparatos eléctricos, siempre se debe respetar ciertas medidas de seguridad a fin de reducir el riesgo de un incendio, un choque eléctrico y (o) lesiones a las personas, incluyendo las siguientes:
❑
Por favor lea todas las instrucciones.
❑
No toque las superficies calientes. Utilice las asas o las perillas.
❑
A fin de protegerse contra el riesgo de un choque eléctrico, no coloque el aparato de manera que el cable, el enchufe o el mismo aparato entre en contacto con agua o cualquier otro líquido.
❑
Todo aparato eléctrico utilizado en la presencia de menores de edad o por ellos mismos requiere la supervisión de un adulto.
❑
Desconecte el aparato de la toma de corriente cuando no esté en funcionamiento y antes de limpiarlo. Espere que el aparato se enfríe antes de instalar o retirar las piezas y antes de limpiarlo.
❑
No se debe utilizar ningún aparato eléctrico que tenga el cable o el enchufe averiado, que presente un problema de funcionamiento o que esté dañado. Devuelva el aparato al centro de servicio autorizado más cercano para que lo examinen, reparen o ajusten. Si el producto llegase a fallar dentro del período de la garantía, llame gratis al número apropiado que aparece en la cubierta de este manual para obtener información relacionada al servicio de mantenimiento del aparato.
❑
El uso de un accesorio no evaluado para ser utilizado con este aparato podría ocasionar lesiones personales.
❑
Este aparato no se debe utilizar a la intemperie.
❑
No permita que el cable cuelgue del borde de la mesa o del mostrador ni que entre en contacto con las superficies calientes.
❑
No coloque el aparato sobre ni cerca de las hornillas de gas o eléctricas ni adentro de un horno caliente.
❑
La jarra debe permanecer tapada cuando está en uso.
❑
El aparato se deberá utilizar únicamente con el fin previsto.
❑
Para reducir el riesgo de incendio, no instale la cafetera sobre ni cerca de ningún electrodoméstico que emita calor.
❑
Para reducir el riesgo de choque eléctrico, no coloque ningún aparato de gas ni eléctrico que emita calor, debajo de la cafetera.
INSTRUCCIONES IMPORTANTES
DE SEGURIDAD
5
Setting the Auto Brew Function
1. Set auto-on time: Press the PROG button. (PROGRAM flashes indicating an
auto-brew time is being set.)
2. Press HOUR and MIN buttons until you reach your desired preset brew time. Display returns to real time after a few seconds.
To check preset auto-on time: Press PROG and the preset time displays for a few seconds as PROGRAM flashes. When it stops flashing, the display automatically returns to real time.
3. Follow steps 1-3 for Brewing Coffee.
4. Press AUTO button. The word AUTO appears and remains until brewing begins at preset auto-on time. AUTO goes out at the same time that ON appears.
Care and Cleaning
This product contains no user serviceable parts. Refer service to qualified service personnel.
1. Unplug unit and allow to cool.
2. Wash thermal carafe by hand with warm sudsy water. Wash removable parts or place in top rack of dishwasher.
3. Clean outside surfaces with a soft, damp cloth. Do not use abrasive cleansers or scouring pads. Never immerse unit in water.
MINERAL DEPOSITS AND CLOGGING
Mineral deposits left by hard water can clog unit. Excessive steaming or a prolonged brewing cycle are signs that a cleaning is needed (approximately every 1-3 months). During cleaning, more steaming occurs than when brewing. You may want to remove unit from mounting bracket and place on a counter to clean. (See Removing the Unit.)
1. Fill water reservoir halfway with water and then add vinegar to 8-cup line.
2. Make sure brew basket is in place and turn unit ON.
3. Let half the cleaning solution brew into the thermal carafe, then turn unit off for at least 15 minutes to soften the deposits.
4. Turn unit ON to brew remaining solution.
5. Turn unit OFF and discard cleaning solution.
6. Fill water reservoir with water to the 6-cup line, replace the empty basket and thermal carafe.
7. Turn unit ON for a complete brew cycle to flush out remaining cleaning solution.
8. Wash reservoir, brew basket and thermal carafe as instructed in Cleaning.
REMOVING THE UNIT
1. To remove unit from mounting bracket (for service or cleaning), first remove the thermal carafe. Slide your hand under the unit for support. Slide unit forward on its track guides to remove.
2. To replace the unit, slide it onto mounting bracket and all the way back until it locks into place.
ODC460Pub1000002779 1/10/06 4:32 PM Page 6
