Black & Decker KC3610 User Manual
ENTR
www.blackanddecker.com.tr
KC3610
ENGLISH
(Original instructions)
4
5
6
1
2
3
A
B
2
(Original instructions)
ENGLISH
3
ENGLISH
(Original instructions)
Intended use
Your BLACK+DECKER screwdriver KC3610
has been designed for screwdriving
applications. This tool is intended for
consumer use only.
Safety instructions
General power tool safety warnings
Warning! Read all safety warnings
and all instructions. Failure to
follow the warnings and instructions
listed below may result in electric
shock, fire and/or serious injury.
Save all warnings and instructions for
future reference.
The term “power tool” in all of the warnings
listed below refers to your mains operated
(corded) power tool or battery operated
(cordless) power tool.
1. Work area safety
a. Keep work area clean and well lit.
Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive
atmospheres, such as in the presence of
flammable liquids, gases or dust. Power
tools create sparks which may ignite the
dust or fumes.
c. Keep children and bystanders away
while operating a power tool.
Distractions can cause you to lose
control.
2. Electrical safety
a. Power tool plugs must match the outlet.
Never modify the plug in any way. Do
not use any adapter plugs with earthed
(grounded) power tools. Unmodified
plugs and matching outlets will reduce
risk of electric shock.
b. Avoid body contact with earthed or
grounded surfaces such as pipes,
radiators, ranges and refrigerators.
There is an increased risk of electric
shock if your body is earthed or
grounded.
c. Do not expose power tools to rain or wet
conditions. Water entering a power tool
will increase the risk of electric shock.
d. Do not abuse the cord. Never use the
cord for carrying, pulling or unplugging
the power tool. Keep cord away from
heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the
risk of electric shock.
e. When operating a power tool outdoors,
use an extension cord suitable for
outdoor use. Use of a cord suitable for
outdoor use reduces the risk of electric
shock.
f. If operating a power tool in a damp
location is unavoidable, use a residual
current device (RCD) protected supply.
Use of an RCD reduces the risk of electric
shock.
3. Personal safety
a. Stay alert, watch what you are doing and
use common sense when operating a
power tool. Do not use a power tool
while you are tired or under the
influence of drugs, alcohol or
medication. A moment of inattention
while operating power tools may result in
serious personal injury.
b. Use personal protective equipment.
Always wear eye protection. Protective
equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing
protection used for appropriate
conditions will reduce personal injuries.
c. Prevent unintentional starting. Ensure
the switch is in the o-position before
connecting to power source and/or
battery pack, picking up or carrying the
tool. Carrying power tools with your
finger on the switch or energising power
tools that have the switch on invites
accidents.
d. Remove any adjusting key or wrench
before turning the power tool on. A
wrench or a key left attached to a
rotating part of the power tool may result
in personal injury.
4
(Original instructions)
ENGLISH
e. Do not overreach. Keep proper footing
and balance at all times. This enables
better control of the power tool in
unexpected situations.
f. Dress properly. Do not wear loose
clothing or jewellery. Keep your hair,
clothing and gloves away from moving
parts. Loose clothes, jewellery or long
hair can be caught in moving parts.
g. If devices are provided for the
connection of dust extraction and
collection facilities, ensure these are
connected and properly used. Use of
dust collection can reduce dust-related
hazards.
4. Power tool use and care
a. Do not force the power tool. Use the
correct power tool for your application.
The correct power tool will do the job
better and safer at the rate for which it
was designed.
b. Do not use the power tool if the switch
does not turn it on and o. Any power
tool that cannot be controlled with the
switch is dangerous and must be
repaired.
c. Disconnect the plug from the power
source and/or the battery pack from the
power tool before making any
adjustments, changing accessories, or
storing power tools. Such preventive
safety measures reduce the risk of
starting the power tool accidentally.
d. Store idle power tools out of the reach
of children and do not allow persons
unfamiliar with the power tool or these
instructions to operate the power tool.
Power tools are dangerous in the hands
of untrained users.
e. Maintain power tools. Check for
misalignment or binding of moving
parts, breakage of parts and any other
condition that may aect the power
tools operation. If damaged, have the
power tool repaired before use. Many
accidents are caused by poorly
maintained power tools.
f. Keep cutting tools sharp and clean.
Properly maintained cutting tools with
sharp cutting edges are less likely to bind
and are easier to control.
g. Use the power tool, accessories and tool
bits etc., in accordance with these
instructions, taking into account the
working conditions and the work to be
performed. Use of the power tool for
operations dierent from those intended
could result in a hazardous situation.
5. Battery tool use and care
a. Recharge only with the charger specified
by the manufacturer. A charger that is
suitable for one type of battery pack may
create a risk of fire when used with
another battery pack.
b. Use power tools only with specifically
designated battery packs. Use of any
other battery packs may create a risk of
injury and fire.
c. When battery pack is not in use, keep it
away from other metal objects, like
paper clips, coins, keys, nails, screws, or
other small metal objects, that can make
a connection from one terminal to
another. Shorting the battery terminals
together may cause burns or a fire.
d. Under abusive conditions, liquid may be
ejected from the battery; avoid contact.
If contact accidentally occurs, flush with
water. If liquid contacts eyes,
additionally seek medical help. Liquid
ejected from the battery may cause
irritation or burns.
6. Service
a. Have your power tool serviced by a
qualified repair person using only
identical replacement parts. This will
ensure that the safety of the power tool is
maintained.
Special Safety Advice for
Screwdriver
Hold power tool by insulated gripping
surfaces, when performing an operation
where the fastener may contact hidden
wiring. Fasteners contacting a "live" wire
may make exposed metal parts of the power
tool "live" and could give the operator an
electric shock.
5
ENGLISH
(Original instructions)
Only plug the Battery Charger in 230V
mains. Recharge the Battery only with the
provided charger. Before starting any work
on walls, floors or similar, make sure that all
power lines in the work area are switched
o at the main switchboard. Use a suitable
device such as a metal or electricity line
detecting device. If in doubt contact a
qualified electrician or your utility provider.
Both tools and work-pieces can heat up
considerably during the drilling operation.
Allow a sucient period of cooling before
handling. Wear appropriate gloves.
Safety Advice for Charger
Important! Danger! There are 3 pcs 1.2V
Ni-cd battery in screwdriver, Never
short-circuit the battery or expose it to
moisture. Do not store it together with any
metal parts which could short-circuit the
contacts. the machine could overheat, start
burning or explode.
Warning!
1. This appliance is not intended for use by
persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning use
of the appliance by a person responsible
for their safety.
2. Do not recharge non-rechargeable
batteries
Vibration
The declared vibration emission values
stated in the technical data and the
declaration of conformity have been
measured in accordance with a standard
test method provided by EN 60745 and may
be used for comparing one tool with
another. The declared vibration emission
value may also be used in a preliminary
assessment of exposure.
Warning! The vibration emission value
during actual use of the power tool can
dier from the declared value depending on
the ways in which the tool is used. The
vibration level may increase above the level
stated.
When assessing vibration exposure to
determine safety measures required by
6
2002/44/EC to protect persons regularly
using power tools in employment, an
estimation of vibration exposure should
consider, the actual conditions of use and
the way the tool is used, including taking
account of all parts of the operating cycle
such as the times when the tool is switched
o and when it is running idle in addition to
the trigger time.
Labels on tool
The following pictograms are shown on the
tool; along with the date code
Warning! To reduce the risk of injury,
the user must read the instruction
manual.
The charger is intended for indoor
use only.
Read this entire manual carefully
before using the appliance.
Position of date barcode
The Date Code, which also includes the year
of manufacture, is printed into the housing.
Example:
2014 XX JN
Year of manufacturing
Electrical safety
Your charger is double insulated;
therefore no earth wire is required.
Always check that the mains voltage
corresponds to the voltage on the rating
plate. Never attempt to replace the charger
unit with a regular mains plug.
• If the supply cord is damaged, it must be
replaced by the manufacturer or an
authorised BLACK+DECKER Service
Centre in order to avoid a hazard.
Product Features
1. Tool Holder
2. LED light
3. Switch
4. LED switch
5. Charging indicator
6. Charging hole
