Page 1

HP96K HP12K(D) HP14K(D)

HP122K(D) HP142K(D)

Page 2

Page 3

74 5 6

2 1

15 14

12 13

Page 4

10 9

15 14

Page 5

Page 6

2423

Page 7

ENGLISH

CORDLESS DRILL/SCREWDRIVER HP96K/ HP12K(D)/HP14K(D)/HP122K(D)/HP142K(D)

CONGRATULATIONS!

You have chosen a Black & Decker tool. Our aim is to provide quality tools at an affordable price. We hope that you will enjoy using this tool for many years.

EC DECLARATION OF CONFORMITY

HP96K/HP12K(D)/HP14K(D)/HP122K(D)/ HP142K(D) Black & Decker declares that these tools conform to: 98/37/EC, 89/336/EEC, 73/23/EEC, EN 50260, EN 55014, EN 60335, EN 61000

Level of sound pressure, measured according to EN 50260:

(sound pressure) dB(A) 71 70 75

LWA(acoustic power) dB(A) 84 83 86

(sound pressure) dB(A) 84 82

LWA(acoustic power) dB(A) 97 94

HP96K HP12K(D) HP14K(D)

HP122K(D) HP142K(D)

Always wear ear protection if the sound pressure exceeds 85 dB(A).

Hand/arm weighted vibration value according to EN 50260:

HP96K HP12K(D) HP14K(D) HP122K(D) HP142K(D)

< 2.5 m/s2< 2.5 m/s2< 2.5 m/s26.8 m/s26.0 m/s

BDCI, 4/F, 2 Dai Wang Street

INTENDED USE

Your Black & Decker drill/screwdriver HP96K/ HP12K(D)/HP14K(D) has been designed for screwdriving applications and for drilling in wood, metal and plastics. Your Black & Decker drill/ screwdriver HP122K(D)/HP142K(D) has been designed for screwdriving applications and for drilling in wood, metal, plastics and soft masonry. This tool is intended for consumer use only. Your Black & Decker charger has been designed for charging Black & Decker batteries of the type supplied with this tool.

SAFETY INSTRUCTIONS

Warning symbols

The following symbols are used in this manual:

Denotes risk of personal injury, loss of life or damage to the tool in case of nonobservance of the instructions in this manual.

Denotes risk of electric shock.

Colin Wills

Director of Engineering

Tai Po Industrial Estate Tai Po NT, Hong Kong

Read the manual prior to operation.

Fire hazard.

Page 8

ENGLISH

Know your tool

◆ Warning! When using battery-powered

tools, basic safety precautions, including the following, should always be followed to reduce the risk of fire, leaking batteries, personal injury and material damage.

◆ Read all of this manual carefully before

operating the tool.

◆ Before operating the tool, make sure

that you know how to switch the tool off in an emergency.

◆ Retain this manual for future reference.

General

1. Keep work area clean

Cluttered areas and benches can cause accidents.

2. Consider work area environment

Do not expose the tool to rain. Do not use the tool in damp or wet conditions. Keep the work area well lit. Do not use the tool where there is a risk of causing fire or explosion, e.g. in the presence of flammable liquids and gases.

3. Keep children away

Do not allow children, visitors or animals to come near the work area or to touch the tool.

4. Dress properly

Do not wear loose clothing or jewellery, as these can be caught in moving parts. Preferably wear rubber gloves and non-slip footwear when working outdoors. Wear protective hair covering to keep long hair out of the way.

5. Personal protection

Always use safety glasses. Use a face or dust mask whenever the operations may produce dust or flying particles. Wear ear protection whenever the sound level seems uncomfortable.

6. Do not overreach

Keep proper footing and balance at all times.

7. Stay alert

Watch what you are doing. Use common sense. Do not operate the tool when you are tired.

8. Secure workpiece

Use clamps or a vice to hold the workpiece. It is safer and it frees both hands to operate the tool.

9. Connect dust extraction equipment

If devices are provided for the connection of dust extraction and collection facilities, ensure that these are connected and properly used.

10.Remove keys and adjusting wrenches

Always check that keys and adjusting wrenches are removed from the tool before operating the tool.

11.Use appropriate tool

The intended use is described in this instruction manual. Do not force small tools or attachments to do the job of a heavy-duty tool. The tool will do the job better and safer at the rate for which it was intended. Do not force the tool. Warning! The use of any accessory or attachment or performance of any operation with this tool other than those recommended in this instruction manual may present a risk of personal injury.

12.Check for damaged parts

Before use, carefully check the tool for damage. Check for misalignment and seizure of moving parts, breakage of parts, damage to guards and switches and any other conditions that may affect its operation. Ensure that the tool will operate properly and perform its intended function. Do not use the tool if any part is damaged or defective. Do not use the tool if the switch does not turn it on and off. Have any damaged or defective parts repaired or replaced by an authorised repair agent. Never attempt any repairs yourself.

13.Remove the battery

Where the design permits, remove the battery when the tool is not in use, before changing any parts of the tool, accessories or attachments and before servicing.

14.Avoid unintentional starting

Do not carry the tool with a finger on the on/off switch. Be sure that the tool is switched off when inserting the battery into the tool.

15.Do not abuse cord

Never carry the charger by its cord or pull it to disconnect from the socket. Keep the cord away from heat, oil and sharp edges.

Page 9

ENGLISH

16.Store idle tools

When not in use, tools, batteries and chargers should be stored in a dry, locked up or high place, out of reach of children.

17.Maintain tools with care

Keep cutting tools sharp and clean for better and safer performance. Follow the instructions for maintenance and changing accessories. Keep handles and switches dry, clean and free from oil and grease.

18.Repairs

This tool complies with relevant safety requirements. Repairs should only be carried out by qualified persons using original spare parts; otherwise this may result in considerable danger to the user.

Additional safety instructions for batteries and chargers

Batteries

◆ Never attempt to open for any reason.

◆ Do not expose to water.

◆ Do not store in locations where the

temperature may exceed 40 °C.

◆ Charge only at ambient temperatures between

4 °C and 40 °C.

◆ Charge only using the charger provided with

the tool (see technical data).

◆ Before charging, make sure that the battery is

dry and clean.

◆ Use only the correct type of battery for the tool

(see technical data).

◆ When disposing of batteries, follow the

instructions given in the section “Protecting the environment”.

◆ Under extreme conditions, battery leakage

may occur. When you notice liquid on the battery, proceed as follows:

- Carefully wipe the liquid off using a cloth. Avoid skin contact.

- In case of skin or eye contact, follow the instructions below.

The battery fluid, a 25-30% solution of potassium hydroxide, can be harmful. In case of skin contact, immediately rinse with water.

Neutralise with a mild acid such as lemon juice or vinegar. In case of eye contact, rinse abundantly with clean water for at least 10 minutes. Consult a physician.

Fire hazard! Avoid short-circuiting the contacts of a detached battery (e.g. when storing the battery in a toolbox).

Do not incinerate the battery.

Do not attempt to charge damaged batteries.

Chargers

◆ Use your Black & Decker charger only to

charge batteries of the type supplied with your tool. Other batteries could burst, causing personal injury and damage.

◆ Never attempt to charge non-rechargeable

batteries.

◆ Have defective cords replaced immediately.

◆ Do not expose to water.

◆ Do not open the charger.

◆ Do not probe the charger.

The charger is intended for indoor use only.

Additional safety instructions for drill/ screwdrivers

◆ Before drilling into walls, floors or ceilings,

check for the location of wiring and pipes.

◆ Avoid touching the tip of a drill bit just after

drilling, as it may be hot.

ELECTRICAL SAFETY

Your charger has been designed for a specific mains voltage. Always check that the mains voltage corresponds to the voltage on the rating plate.

Your charger is double insulated in accordance with EN 60335; therefore no earth wire is required.

Page 10

ENGLISH

HP96K/HP12K(D)/HP14K(D)

Never attempt to replace the charger unit with a regular mains plug.

HP122K(D)/HP142K(D) - Mains plug replacement (U.K. & Ireland only)

◆ Should your mains plug need replacing and

you are competent to do this, proceed as instructed below. If you are in doubt, contact an authorised repair agent or a qualified electrician.

◆ Disconnect the plug from the supply and

remove the fuse from the plug.

◆ Cut off the plug and dispose of it safely; a plug

with bared copper conductors is dangerous if engaged in a live socket outlet.

◆ Only fit 13 Amperes BS1363A approved plugs

fitted with a 5 A fuse (1).

◆ The cable wire colours, or a letter, will be

marked at the connection points of most good quality plugs. Attach the wires to their respective points in the plug (see above). Brown is for Live (L) (2), blue is for Neutral (N) (4).

◆ Before replacing the top cover of the mains

plug ensure that the cable restraint (3) is holding the outer sheath of the cable firmly and that the leads are correctly fixed at the terminal screws.

◆ If the plug has a fuse cover, make sure that the

fuse cover is fitted. Do not use the plug if the fuse cover is missing or damaged.

Never use a light socket.

OVERVIEW (fig. A)

1. Variable speed switch (HP12K(D)/HP14K(D)/ HP122K(D)/HP142K(D))

1. Two-speed on/off switch (HP96K)

2. Forward/reverse slider

3. Mode selector / torque adjustment collar

4. Chuck

5. Two-gear selector (HP122K(D)/HP142K(D))

6. Battery charge indicator (HP96K/HP12K/ HP14K/HP122K/HP142K)

7. Straight drilling indicator

8. Bit holder

9. Battery

10. Battery release button

11. Charger (HP96K/HP12K(D)/HP14K(D))

12. Charger receptacle (HP96K/HP12K(D)/HP14K(D))

13. Charger (HP122K(D)/HP142K(D))

14. Charging indicator (HP122K(D)/HP142K(D))

15. End of charge indicator (HP122K(D)/HP142K(D))

ASSEMBLY

Fitting and removing the battery (fig. B)

◆ To fit the battery (9), line it up with the

receptacle on the tool. Slide the battery into the receptacle and push until the battery snaps into place.

◆ To remove the battery, push the release

button (10) while at the same time pulling the battery out of the receptacle.

Fitting and removing a drill bit or screwdriver bit (fig. A & C)

This tool is fitted with a keyless chuck to allow for an easy exchange of bits.

◆ Lock the tool by setting the forward/reverse

slider (2) to the centre position (fig. A).

◆ Open the chuck by turning the front part (16)

with one hand while holding the rear part (17) with the other (fig. C).

◆ Insert the bit shaft (18) into the chuck.

◆ Firmly tighten the chuck by turning the front

part (16) with one hand while holding the rear part (17) with the other.

This tool is supplied with a double-ended screwdriver bit in the bit holder (8) (fig. A).

◆ To remove the screwdriver bit from the bit

holder, lift the bit from the recess.

◆ To store the screwdriver bit, firmly push it into

the holder.

Page 11

ENGLISH

HP12KD/HP14KD/HP122KD/HP142KD Attaching the detector (fig. K)

The tool provides a mounting location where the detector (23) is stored when not in use.

◆ Hang the unit to the holder (24) as shown.

USE

Let the tool work at its own pace. Do not overload.

Charging the battery

The battery needs to be charged before first use and whenever it fails to produce sufficient power on jobs that were easily done before. When charging the battery for the first time, or after prolonged storage, it will only accept an 80% charge. After several charge and discharge cycles, the battery will attain full capacity. The battery may become warm while charging; this is normal and does not indicate a problem.

Do not charge the battery at ambient temperatures below 4 °C or above 40 °C. Recommended charging temperature: approx. 24 °C.

HP96K/HP12K(D)/HP14K(D) (fig. D)

◆ To charge the battery (9), remove it from the

tool.

◆ Slide the charger receptacle (12) onto the

battery as shown.

◆ Plug in the charger (11).

The battery will become warm while charging. After approx. 3 hours of charging, the battery will be fully charged.

◆ Remove the charger receptacle from the

battery.

HP122K(D)/HP142K(D) (fig. E)

◆ To charge the battery (9), remove it from the

tool and insert it into the charger (13). The battery will only fit into the charger in one way. Do not force. Be sure that the battery is fully seated in the charger.

◆ Plug in the charger.

◆ Check if the red charging indicator (14) lights up.

If the green end of charge indicator (15) lights up now instead, the battery is too hot and cannot be charged. If this happens, remove the battery from the charger, let the battery cool down for approx. 1 hour and re-insert it.

After approx. 1 hour of charging, the red charging indicator (14) will stop lighting and the green end of charge indicator (15) will light up. The battery is now fully charged.

◆ Remove the battery from the charger.

HP96K/HP12K/HP14K/HP122K/HP142K Checking the battery condition (fig. F)

This tool is fitted with a battery charge indicator, which allows you to check the condition of the battery.

◆ Press and hold down the button (19).

◆ Check to see how many of the lights (20) are on:

Battery charge 1 light low 2 lights medium 3 lights high

Selecting the direction of rotation (fig. G)

For drilling and for tightening screws, use forward (clockwise) rotation. For loosening screws or removing a jammed drill bit, use reverse (counterclockwise) rotation.

◆ To select forward rotation, push the forward/

reverse slider (2) to the left.

◆ To select reverse rotation, push the forward/

reverse slider to the right.

◆ To lock the tool, set the forward/reverse slider

into the centre position.

Selecting the operating mode or torque (fig. H)

This tool is fitted with a collar to select the operating mode and to set the torque for tightening screws. Large screws and hard workpiece materials require a higher torque setting than small screws and soft workpiece materials. The collar has a wide range of settings to suit your application.

◆ For drilling in wood, metal and plastics, set the

collar (3) to the drilling position by aligning the symbol with the marking (21).

Page 12

ENGLISH

◆ For screwdriving, set the collar to the desired

setting. If you do not yet know the appropriate setting, proceed as follows:

◆ Set the collar (3) to the lowest torque setting.

◆ Tighten the first screw.

◆ If the clutch ratchets before the desired

result is achieved, increase the collar setting and continue tightening the screw. Repeat until you reach the correct setting. Use this setting for the remaining screws.

HP122K(D)/HP142K(D) - Drilling in masonry (fig. H & I)

◆ For drilling in masonry, set the collar (3) to the

hammer drilling position by aligning the symbol with the marking (21).

◆ Slide the two-gear selector (5) towards the

front of the tool (2nd gear).

HP122K(D)/HP142K(D) - Two-gear selector (fig. I)

◆ For drilling in steel and for screwdriving

applications, slide the two-gear selector (5) towards the rear of the tool (1st gear).

◆ For drilling in materials other than steel,

slide the two-gear selector (5) towards the front of the tool (2nd gear).

Straight drilling indicator (fig. J)

This tool is fitted with an indicator to facilitate straight drilling. This feature can be used both in horizontal and in vertical position.

◆ Position the tool as required.

◆ Keep the switch (1) slightly depressed without

switching the tool on.

◆ Slowly move the rear of the tool until the red

indicator (22) lights up.

◆ Press the switch further to start drilling.

HP12KD/HP14KD/HP122KD/HP142KD Detecting pipes or wires (fig. K)

◆ Take the detector (23) out of the holder (24).

◆ Refer to the manual of the detector for further

instructions.

Drilling/screwdriving (fig. A)

◆ Select forward or reverse rotation using the

forward/reverse slider (2).

◆ To switch the tool on, press the switch (1).

The tool speed depends on how far you press the switch.

◆ To switch the tool off, release the switch.

Hints for optimum use

Drilling

◆ Always apply a light pressure in a straight line

with the drill bit.

◆ Just before the drill tip breaks through the

other side of the workpiece, decrease pressure on the tool.

◆ Use a block of wood to back up workpieces

that may splinter.

◆ Use spade bits when drilling large diameter

holes in wood.

◆ Use HSS drill bits when drilling in metal.

◆ Use masonry bits when drilling in soft masonry.

◆ Use a lubricant when drilling metals other than

cast iron and brass.

◆ Make an indentation using a centre punch at

the centre of the hole to be drilled in order to improve accuracy.

Screwdriving

◆ Always use the correct type and size of

screwdriver bit.

◆ If screws are difficult to tighten, try applying a

small amount of washing liquid or soap as a lubricant.

◆ Always hold the tool and screwdriver bit in a

straight line with the screw.

MAINTENANCE

Your Black & Decker tool has been designed to operate over a long period of time with a minimum of maintenance. Continuous satisfactory operation depends upon proper tool care and regular cleaning. Your charger does not require any maintenance apart from regular cleaning.

◆ Before performing any maintenance on

the tool, remove the battery from the tool.

◆ Unplug the charger before cleaning it.

Page 13

ENGLISH

◆ Regularly clean the ventilation slots in your tool

and charger using a soft brush or dry cloth.

◆ Regularly clean the motor housing using a

damp cloth. Do not use any abrasive or solvent-based cleaner.

◆ Regularly open the chuck and tap it to remove

any dust from the interior.

PROTECTING THE ENVIRONMENT

Tools

Should you find one day that your tool needs replacement, or if it is of no further use to you, think of the protection of the environment. Black & Decker repair agents will accept old Black & Decker tools and ensure that they are disposed of in an environmentally safe way.

Batteries

Black & Decker batteries can be recharged many times. At the end of their useful life, discard batteries with due care for our

environment:

◆ Run the battery down completely, then remove

it from the tool.

◆ NiCd and NiMH batteries are recyclable. Take

them to your service agent or a local recycling station. Collected batteries will be recycled or disposed of properly.

Guarantee

Black & Decker is confident of the quality of its products and offers an outstanding guarantee. This guarantee statement is in addition to and in no way prejudices your statutory rights. The guarantee is valid within the territories of the Member States of the European Union and the European Free Trade Area.

If a Black & Decker product becomes defective due to faulty materials, workmanship or lack of conformity, within 24 months from the date of purchase, Black & Decker guarantees to replace defective parts, repair products subjected to fair wear and tear or replace such products to ensure minimum inconvenience to the customer unless:

◆ The product has been used for trade,

professional or hire purposes;

◆ The product has been subjected to misuse or

neglect;

◆ The product has sustained damage through

foreign objects, substances or accidents;

Technical data

HP96K HP12K(D) HP14K(D) HP122K(D) HP142K(D)

Voltage VDC9.6 12 14.4 12 14.4 No-load speed min-1350/700 0-750 0-750 0-400/0-1,200 0-400/0-1,200 Max. torque Nm 10.5 11.8 12.9 23.5 26 Chuck capacity mm 10 10 10 10 10 Max. drilling capacity

in steel/wood/masonry mm 10/20/- 10/25/- 10/30/- 10/25/12 10/30/12

Weight (without battery) kg 1.0 1.0 (1.2) 1.3 (1.4) 1.0 (1.2) 1.3 (1.4)

Battery HP96K HP12K(D) HP14K(D) HP122K(D) HP142K(D)

Battery cat. no. A96 A12 499936-34 A12 499936-35 Voltage VDC9.6 12 14.4 12 14.4 Capacity Ah 1.2 1.2 1.2 1.2 1.2 Weight kg 0.56 0.52 (0.63) 0.76 0.52 0.63

Charger HP96K HP12K(D) HP14K(D) HP122K(D) HP142K(D)

Input voltage VAC230 230 230 230 230 Approx. charging time h 3 3 3 1 1

Page 14

ENGLISH

◆ Repairs have been attempted by persons other

than authorised repair agents or Black & Decker service staff.

To claim on the guarantee, you will need to submit proof of purchase to the seller or an authorised repair agent. You can check the location of your nearest authorised repair agent by contacting your local Black & Decker office at the address indicated in this manual. Alternatively, a list of authorised Black & Decker repair agents and full details of our after-sales service and contacts are available on the Internet at:

www.2helpU.com.

Page 15
