Black & Decker H337 Instruction Manual

www.blackanddecker.com

3

1

2

4

English 3
Italiano 6
Español 9
Português 12
∂ППЛУИО· 15

1

5

6 6

3

5

4

2

8

2

7

9

10

A

ENGLISH

Intended use

Your Black & Decker food chopper has been designed for
chopping, beating and mixing food and beverage ingredients.
This product is intended for household use only.

Safety instructions

◆ Warning! When using mains-powered appliances, basic

safety precautions, including the following, should always
be followed to reduce the risk of fire, electric shock and
personal injury.

◆ Read this entire manual carefully before using the appliance.

◆ The intended use is described in this manual. The use of

any accessory or attachment or the performance of any
operation with this appliance other than those
recommended in this instruction manual may present a
risk of personal injury.

◆ Retain this manual for future reference.

Using your appliance

◆ Make sure that the appliance is switched off before

connecting to or disconnecting from the power supply.

◆ Always take care when using the appliance.

◆ Do not use the appliance outdoors.

◆ Always protect the motor unit from water or excessive

humidity.

◆ Do not operate the appliance if your hands are wet.

Do not operate the appliance if you are barefoot.

◆ Do not touch moving parts. Keep long hair and loose

clothing out of the way of the moving parts.

◆ Guide the power supply cord neatly so it does not hang

over the edge of a worktop and cannot be caught
accidentally or tripped over.

◆ Never pull the power supply cord to disconnect the plug

from the socket. Keep the power supply cord away from
heat, oil and sharp edges.

◆ Switch off and wait for the motor to stop running before

disconnecting the appliance from the power supply.

◆ Never detach any part or accessory while the appliance is

still connected to the power supply. Always disconnect
the appliance from the power supply first.

◆ If the power supply cord is damaged during use,

disconnect the appliance from the power supply
immediately. Do not touch the power supply cord before
disconnecting from the power supply.

◆ Disconnect the appliance from the power supply when not

in use, before fitting or removing parts and before cleaning.

Safety of others

◆ Do not allow children or any person unfamiliar with these

instructions to use the appliance.

◆ Do not allow children or animals to come near the work

area or to touch the appliance or power supply cord.

Close supervision is necessary when the appliance is
used near children.

After use

◆ Switch off and remove the plug from the socket before

leaving the appliance unattended and before changing,
cleaning or inspecting any parts of the appliance.

◆ When not in use, the appliance should be stored in a dry

place. Children should not have access to stored appliances.

Inspection and repairs

◆ Before use, check the appliance for damaged or defective

parts. Check for breakage of parts, damage to switches
and any other conditions that may affect its operation.

◆ Do not use the appliance if any part is damaged or defective.

◆ Have any damaged or defective parts repaired or replaced

by an authorised repair agent.

◆ Before use, check the power supply cord for signs of

damage, ageing and wear.

◆ Do not use the appliance if the power supply cord or

mains plug is damaged or defective.

◆ If the power supply cord or mains plug is damaged or

defective it must be repaired by an authorised repair
agent in order to avoid a hazard. Do not cut the power
supply cord and do not attempt to repair it yourself.

◆ Never attempt to remove or replace any parts other than

those specified in this manual.

Double insulation

This appliance is double insulated in accordance
with EN 60335; therefore no earth wire is required.
Always check that the power supply corresponds to
the voltage on the rating plate.

To avoid the risk of electric shock, do not immerse
the cord, plug or motor unit in water or other liquid.

Features

1. Speed control switch

2. Bowl

3. Lid

4. Chopper blade

Assembly

Warning! Before assembly, make sure that the appliance is

switched off and unplugged.

Fitting and removing the bowl (fig. A)

◆ Place the bowl (2) on the pin (7), aligning the lugs (8) with

the recesses (9).

3

ENGLISH

◆ Fix the bowl by turning it counter-clockwise until the lugs

(8) engage in the slots (10).

◆ To remove the bowl from the appliance, turn the bowl

clockwise and take it off.

Assembling the bowl (fig. A)

◆ Carefully place the chopper blade (4) over the raised

centre of the bowl (2).

◆ Put the ingredients in the bowl.

◆ Place the lid (3) on the bowl

◆ Fix the lid by turning it counter-clockwise until the ribs (5)

are seated over the lugs (6).

◆ To remove the lid from the bowl, turn the lid clockwise

and take it off.

Use

Switching on and off

Before switching on, make sure that the bowl (2) is fixed and
check that the lid (3) is seated correctly.

◆ To switch on, move the speed control switch (1) to one of

the two positions: I (low speed) to II (high speed). It is
recommended to start at a low speed, then change to a
higher speed if necessary.

◆ To switch off, move the switch to position 0.

◆ To operate in the pulse mode, move the switch to position

P.

Warning! Do not operate the appliance continuously for more

than 1 minute. After operating the appliance continuously for
1 minute, let it cool down for at least 2 minutes before
operating it again. After operating the appliance for 4 cycles,
let it cool down to room temperature before operating it again.

After use

◆ Remove the bowl from the appliance.

◆ Remove the lid from the bowl.

◆ Carefully remove the blade from the bowl.

◆ Take out the chopped ingredients from the bowl.

Cleaning and maintenance

Warning! Before cleaning and maintenance, unplug the

appliance. Be careful when cleaning the blades - they are sharp.

◆ Wash the bowl, lid and blade in warm soapy water and

dry well.

◆ Wipe the stand with a damp cloth. Do not use any

abrasive or solvent-based cleaner.

Warning! Do not immerse the appliance in water or any other
liquid.

Protecting the environment

Black & Decker provides a facility for recycling
Black & Decker products once they have reached the
end of their working life. This service is provided
free of charge. To take advantage of this service
please return your product to any authorised repair

agent who will collect them on our behalf.
You can check the location of your nearest authorised repair
agent by contacting your local Black & Decker office at the
address indicated in this manual. Alternatively, a list of
authorised Black & Decker repair agents and full details of our
after-sales service and contacts are available on the Internet
at: www.2helpU.com

Technical data

H337

Voltage V 230
Power input W 150

EC declaration of conformity

Black & Decker declares that these products conform to:
98/37/EC, 89/336/EEC, 73/23/EEC, EN 55014, EN 60335,

LpA (sound pressure): 74 dB(A), LWA (acoustic power) 87 dB(A),

hand/arm weighted vibration < 2.5 m/s

EN 61000

2

Operating times and speed settings

Time (s) Speed Maximum

(I or II or P) quantity

Nuts, cheese 10-15 II 120-150 g
Boiled eggs, meat 10-15 II 120 g
Spices 30 II 150 g
Breadcrumbs 10-15 I or II 25 g
Light batter 10-15 I or II 150 ml
Parsley 10-15 I or II 25 g
Garlic, onions, shallots pulse P 150-180 g
Ice cubes pulse P 4-5 small ice cubes

4

Kevin Hewitt

Director of Consumer Engineering

Spennymoor, County Durham DL16 6JG,

United Kingdom

Guarantee

Black & Decker is confident of the quality of its products and
offers an outstanding guarantee. This guarantee statement is
in addition to and in no way prejudices your statutory rights.
The guarantee is valid within the territories of the Member
States of the European Union and the European Free Trade
Area.

If a Black & Decker product becomes defective due to faulty
materials, workmanship or lack of conformity, within 24 months
from the date of purchase, Black & Decker guarantees to replace
defective parts, repair products subjected to fair wear and tear
or replace such products to ensure minimum inconvenience to
the customer unless:

◆ The product has been used for trade, professional or hire

purposes;

◆ The product has been subjected to misuse or neglect;

◆ The product has sustained damage through foreign

objects, substances or accidents;

◆ Repairs have been attempted by persons other than

authorised repair agents or Black & Decker service staff.

To claim on the guarantee, you will need to submit proof of
purchase to the seller or an authorised repair agent. You can
check the location of your nearest authorised repair agent by
contacting your local Black & Decker office at the address
indicated in this manual. Alternatively, a list of authorised
Black & Decker repair agents and full details of our after-sales
service and contacts are available on the Internet at:

www.2helpU.com

Please register at our website www.blackanddecker.com
to be kept up to date on new products and special offers.
Further information on the Black & Decker brand and our range
of products is available at www.blackanddecker.com

ENGLISH

5

ITALIANO

Uso previsto

Il trituratore per alimenti Black & Decker è stato disegnato per
triturare, sbattere e impastare ingredienti solidi e liquidi.
Questo prodotto é destinato esclusivamente all’uso domestico.

Precauzioni di sicurezza

◆ Attenzione! Quando s’impiegano degli elettrodomestici,

per ridurre il rischio di incendio, di scosse elettriche
e infortuni occorre seguire sempre delle precauzioni di
sicurezza di base, fra cui le seguenti:

◆ Prima di adoperare l’elettrodomestico, leggere

attentamente le istruzioni del presente manuale.

◆ L’utilizzo previsto è quello descritto in questo manuale.

L’uso di accessori o attrezzature diversi o l’uso di questo
apparecchio per scopi diversi da quelli indicati nel
presente manuale d’uso comportano il rischio di infortuni.

◆ Conservare questo manuale di istruzioni per successive

consultazioni.

Uso dell’apparecchio

◆ Accertare che l’elettrodomestico sia spento prima di

collegarlo o scollegarlo dall’alimentazione.

◆ Fare sempre attenzione quando si usa l’apparecchio.

◆ Evitare di utilizzare l’apparecchio all’esterno.

◆ Tenere sempre l’unità motore al riparo dall’acqua

o dall’umidità eccessiva.

◆ Non utilizzare l’apparecchio con le mani umide.

Non utilizzare l’apparecchio a piedi scalzi.

◆ Non toccare le parti mobili. Mantenere capelli e abiti

svolazzanti lontani dalle parti in movimento.

◆ Disporre il cavo di alimentazione in modo che non penda

dal bordo di un piano e che non sia possibile inciamparvi
o restarvi impigliati accidentalmente.

◆ Non tirare mai il cavo di alimentazione per disinserire la

spina dalla presa. Mantenere il cavo lontano da fonti di
calore, da olio e bordi taglienti.

◆ Spegnere l’apparecchio e attendere che il motore si fermi

prima di staccarlo dall’alimentazione.

◆ Non smontare mai i componenti o gli accessori con

l’elettrodomestico ancora collegato all’alimentazione.
Scollegare sempre prima l’apparecchio dalla presa di
corrente.

◆ Se il cavo di alimentazione si danneggia durante l’uso,

disinserire immediatamente la spina dell’apparecchio
dalla presa di corrente. Non toccare il cavo di alimentazione
se non dopo aver disinserito la spina dalla presa di corrente.

◆ Scollegare l’elettrodomestico dall’alimentazione quando

non è in uso, prima di installare o rimuovere dei componenti
e prima di pulirlo.

Sicurezza altrui

◆ Vietare l’uso dell’apparecchio ai bambini e agli adulti che

non abbiano letto il presente manuale d’istruzioni.

◆ Vietare a bambini o ad animali di avvicinarsi all’area in cui

si usa l’apparecchio, di toccare l’apparecchio o il cavo di
alimentazione. Fare estrema attenzione quando si usa
l’apparecchio in presenza di bambini.

Dopo l’uso

◆ Prima di lasciare incustodito l’elettrodomestico, e prima di

cambiarne, pulirne o ispezionarne qualsiasi parte,
spegnerlo ed estrarre la spina dalla presa.

◆ Quando non è in funzione, l’apparecchio deve essere

conservato in un luogo asciutto inaccessibile ai bambini.

Ispezione e riparazioni

◆ Prima dell’uso, verificare che non vi siano componenti

danneggiati o difettosi. Verificare anche che non vi siano
parti rotte, che gli interruttori non siano danneggiati e che
non vi sia nulla che comprometta il funzionamento
dell’apparecchio.

◆ Non usare l’elettrodomestico se ci sono elementi

danneggiati o difettosi

◆ Eventuali elementi difettosi o danneggiati devono essere

sostituiti o riparati da un tecnico autorizzato.

◆ Prima dell’uso, controllare che il cavo di alimentazione

non presenti segni di danni, invecchiamento e usura.

◆ Non usare l’elettrodomestico se il cavo di alimentazione o

la spina sono danneggiati o difettosi.

◆ Se il cavo di alimentazione o la spina sono danneggiati o

difettosi devono essere riparati da un tecnico autorizzato,
onde evitare situazioni pericolose. Non tagliare il cavo di
alimentazione e non tentare di ripararlo personalmente.

◆ Non tentare mai di smontare o sostituire componenti

diversi da quelli indicati nel presente manuale.

Doppio isolamento

In ottemperanza della norma EN 60335,
l’apparecchio è dotato di doppio isolamento che
rende superflua la messa a terra. Controllare sempre
che la tensione di alimentazione corrisponda a quella
indicata sulla targhetta.

Per evitare il rischio di scosse elettriche, non
immergere il cavo di alimentazione, la spina o l’unità
di base in acqua o altri liquidi.

6
