Black & Decker CS2245, CS2040 User Manual

www.blackanddecker.com.au www.blackanddecker.co.nz
CS2040 CS2245
2
7
7
A
C D
8
6
B
151416
18 17
E
F
3
G
H
I
K L
4
J
M
N
O
5
ENGLISH
(Original instructions)
Intended use
Your BLACK+DECKERTM chainsaw has been designed for pruning and felling trees and cutting logs. This tool is intended for consumer use only.
Safety instructions
General power tool safety warnings
Warning! Read all safety warnings and all
@
Save all warnings and instructions for future reference. The term "power tool" in all of the warnings listed below refers to your mains operated (corded) power tool or battery oper­ated (cordless) power tool.
1. Work area safety a. Keep work area clean and well lit. Cluttered or dark
b. Do not operate power tools in explosive atmospheres,
c. Keep children and bystanders away while operating a
2. Electrical safety a. Power tool plugs must match the outlet. Never modify
b. Avoid body contact with earthed or grounded
c. Do not expose power tools to rain or wet conditions.
d. Do not abuse the cord. Never use the cord for
e. When operating a power tool outdoors, use an
f. If operating a power tool in a damp location is
6
instructions. Failure to follow the warnings and
instructions listed below may result in electric
shock, re and/or serious injury.
areas invite accidents.
such as in the presence of ammable liquids, gases
or dust. Power tools create sparks which may ignite the dust or fumes.
power tool. Distractions can cause you to lose control.
the plug in any way. Do not use any adapter plugs with earthed (grounded) power tools. Unmodied plugs
and matching outlets will reduce risk of electric shock.
surfaces such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock
if your body is earthed or grounded.
Water entering a power tool will increase the risk of electric shock.
carrying, pulling or unplugging the power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of
electric shock.
extension cord suitable for outdoor use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of
electric shock.
3. Personal safety a. Stay alert, watch what you are doing and use common
sense when operating a power tool. Do not use a
power tool while you are tired or under the inuence
of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal
injury.
b. Use personal protective equipment. Always wear eye
protection. Protective equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal
injuries.
c. Prevent unintentional starting. Ensure the switch is in
the off-position before connecting to power source and/or battery pack, picking up or carrying the tool.
Carrying power tools with your nger on the switch or
energising power tools that have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to a
rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at
all times. This enables better control of the power tool in
unexpected situations.
f. Dress properly. Do not wear loose clothing or
jewellery. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jewellery or long hair
can be caught in moving parts.
g. If devices are provided for the connection of dust
extraction and collection facilities, ensure these are connected and properly used. Use of dust collection can
reduce dust-related hazards.
4. Power tool use and care a. Do not force the power tool. Use the correct power
tool for your application. The correct power tool will do
the job better and safer at the rate for which it was
designed.
b. Do not use the power tool if the switch does not turn it
on and off. Any power tool that cannot be controlled with
the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the
battery pack from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of
starting the power tool accidentally.
d. Store idle power tools out of the reach of children and
do not allow persons unfamiliar with the power tool or these instructions to operate the power tool. Power
tools are dangerous in the hands of untrained users.
(Original instructions)
ENGLISH
e. Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and any other condition that may affect the power tools operation. If damaged, have the power tool repaired before use. Many accidents are caused by poorly
maintained power tools.
f. Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are less likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in
accordance with these instructions, taking into account the working conditions and the work to be performed. Use of the power tool for operations different
from those intended could result in a hazardous situation.
5. Service a.
person using only identical replacement parts. This
will ensure that the safety of the power tool is maintained.
b. Power to the tool should always be supplied via
residual current device with a rated residual current of 30mA or less.
Additional power tool safety warnings
Warning! Additional safety warnings for
@
u Keep all parts of the body away from the saw chain
u Always hold the chainsaw with your right hand on the
u Hold the power tool by insulated gripping surfaces
u Wear safety glasses and hearing protection. Further
u Do not operate a chainsaw in a tree. Operation of a
u Always keep proper footing and operate the chain saw
chainsaws
when the chainsaw is operating. Before you start the chainsaw, make sure the saw chain is not contacting anything. A moment of inattention while operating chain
saws may cause entanglement of your clothing or body with the chain saw.
rear handle and your left hand on the front handle.
increases the risk of personal injury and should never be done.
only, because the saw chain may contact hidden wir­ing or its own cord. Saw chains contacting a "live" wire
may make exposed metal parts of the power tool "live" and could give the operator an electric shock.
protective equipment for head, hands, legs and feet is recommended. Adequate protective clothing will reduce
the saw chain.
chainsaw while up in a tree may result in personal injury.
Slippery or unstable surfaces such as ladders may cause a loss of balance or control of the chainsaw.
u When cutting a limb that is under tension be alert
for spring back.
released the spring loaded limb may strike the operator and/or throw the chain saw out of control.
u Use extreme caution when cutting brush and saplings.
The slender material may catch the saw chain and be whipped toward you or pull you off balance.
u Carry the chain saw by the front handle with the chain
saw switched off and away from your body. When
guide bar cover. Proper handling of the chain saw will
reduce the likelihood of accidental contact with the moving saw chain.
u Follow instructions for lubricating, chain tensioning
and changing accessories. Improperly tensioned or
lubricated chain may either break or increase the chance for kickback
u Keep handles dry, clean, and free from oil and grease.
Greasy, oily handles are slippery causing loss of control.
u Cut wood only. Do not use chainsaw for purposes not
intended. For example: do not use the chainsaw for cutting plastic, masonry or non-wood building materi­als. Use of the chainsaw for operations different than
intended could result in a hazardous situation.
Causes and operator prevention of kickback
Kickback may occur when the nose or tip of the guide bar touches an object, or when the wood closes in and pinches the saw chain in the cut. Tip contact in some cases may cause a sudden reverse reac­tion, kicking the guide bar up and back towards the operator. Pinching the saw chain along the top of the guide bar may push the guide bar rapidly back towards the operator. Either of these reactions may cause you to lose control of the chainsaw which could result in serious personal injury. Do not rely exclusively upon the safety devices built into your chainsaw. As a chainsaw user, you should take several steps to keep your cutting jobs free from accident or injury. Kickback is the result of tool misuse and / or incorrect operat­ing procedures or conditions and can be avoided by taking proper precautions as given below:
u -
cling the chainsaw handles. With both hands on the chainsaw, position your body and arm to allow you to resist kickback forces. Kickback forces can be control-
led by the operator, if proper precautions are taken. Do not let go of the chainsaw.
u Do not overreach and do not cut above shoulder
height. This helps prevent unintended tip contact and
enables better control of the chainsaw in unexpected situ­ations.
7
ENGLISH
(Original instructions)
u Only use replacement guide bars and chains specied
by the manufacturer. Incorrect replacement guide bars
and chains may cause chain breakage and/or kickback.
u Follow the manufacturer's sharpening and mainte-
nance instructions for the saw chain. Decreasing the
depth gauge height can lead to increased kickback.
u Striking metal, cement or any other hard material near the
wood, or buried in the wood can cause kickback.
u A dull or loose chain can cause kickback. u Do not try to insert into a previous cut. As this could cause
kickback. Make a fresh cut every time.
Safety recommendations for the chainsaw
u We strongly recommend that rst time users obtain practi-
cal instruction in the use of the chainsaw and protective equipment from an experienced user. Initial practice should be completed sawing logs on a saw horse or cradle.
u Maintain your chainsaw when not in use. Do not store
your chainsaw for any length of time without rst remov­ing the saw chain and guide bar which should be kept immersed in oil. Store all parts of your chainsaw in a dry, secure place out of reach of children.
u We recommend you drain the oil reservoir prior to storage. u Be sure of your footing and pre-plan a safe exit from a
falling tree or branches.
u Use wedges to help control felling and prevent binding the
guide bar and saw chain in the cut.
u Saw chain care. Keep the saw chain sharp and snug on
the guide bar. Ensure the saw chain and guide bar are clean and well oiled. Keep handles dry, clean and free from oil and grease.
Avoid cutting
u Prepared timber. u Into the ground. u Into wire fences, nails. etc.
Additional safety instructions
u Ensure someone is nearby (but at a safe distance) in case
of an accident.
u If for any reason you have to touch the saw chain, make
sure your chainsaw is disconnected from the mains.
u The noise from this product can exceed 85 dB(A). We
therefore recommend you take appropriate measures for the protection of hearing.
u When handling the product the chain bar may become
hot, handle with care.
Safety of others
u This appliance is not intended for use by persons (includ-
ing children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concern­ing use of the appliance by a person responsible for their safety.
u Children should be supervised to ensure that they do not
play with the appliance.
Residual risks.
Additional residual risks may arise when using the tool which may not be included in the enclosed safety warnings. These risks can arise from misuse, prolonged use etc. Even with the application of the relevant safety regulations and the implementation of safety devices, certain residual risks can not be avoided. These include:
u Injuries caused by touching any rotating/moving parts. u Injuries caused when changing any parts, blades or ac-
cessories.
u Injuries caused by prolonged use of a tool. When using
any tool for prolonged periods ensure you take regular breaks.
u Impairment of hearing. u Health hazards caused by breathing dust developed when
using your tool (example:- working with wood, especially oak, beech and MDF.)
Vibration
The declared vibration emission values stated in the technical data and the declaration of conformity have been measured in accordance with a standard test method provided by EN 60745 and may be used for comparing one tool with another. The declared vibration emission value may also be used in a preliminary assessment of exposure.
Warning! The vibration emission value during actual use of the power tool can differ from the declared value depending on the ways in which the tool is used. The vibration level may increase above the level stated.
When assessing vibration exposure to determine safety
measures required by 2002/44/EC to protect persons regularly
using power tools in employment, an estimation of vibration exposure should consider, the actual conditions of use and the way the tool is used, including taking account of all parts of the operating cycle such as the times when the tool is switched off and when it is running idle in addition to the trigger time.
8
(Original instructions)
E
ENGLISH
Labels on tool
The following pictograms are shown on the tool:
Warning! To reduce the risk of injury, the user
:
R
must read the instruction manual.
Wear eye, ear and head protectionwhen using this product.
Wear non-silp safety footwear when using the product.
Wear non-silp, heavy dutygloves when using this product.
Do not expose the tool to rain or high humidit
Directive 2000/14/EC guaranteed sound power.
Remove plug from the mains immediately before maintenance or if cable is damaged or cut.
Caution: Do not over tighten. Tighten by hand. Finger tight only.
Chain oil.
Moving direction of the chain (Marked under teh sprocket cover)..
Rotate to adjust chain tension, clockwise tighten the chain, Anti-clockwise to loose the chain.
Electrical safety
This tool is double insulated; therefore no earth wire is required. Always check that the power
#
supply corresponds to the voltage on the rating plate.
u If the supply cord is damaged, it must be replaced by the
manufacturer or an authorised BLACK+DECKER Service Centre in order to avoid a hazard.
Using an extension cable
u Always use an approved extension cable suitable for the
power input of this tool (see technical data). The extension cable must be suitable for outdoor use and marked ac-
y.
cordingly. Up to 30 m of HO7RN-F 2 X 1.5 mm² extension cable can be used without loss of product performance. Before use, inspect the extension cable for signs of damage, wear and ageing. Replace the extension cable if damaged or defective. When using a cable reel, always unwind the cable completely.
Voltage drops
u Under certain power supply conditions this product may-
cause short-time voltage drops during start-up.
u Other equipment may be affected. For example, electri-
clights may temporarily reduce in brightness.
u Contact the supply authority, if necessary, to determine
that the impedance of the power supply is lower than
0.172/0.293 ohms. Disturbances are unlikely to occur under this condition.
Guard against electric shock
u Prevent body contact with earthed or grounded surfaces
(e.g. metal railings, lamp-posts etc.). Electric safety can be further improved by using a high-sensitivity (30 mA/ 30mS) Residual Current Device (RCD).
Hold and operate the saw properly with both hands.
Do not operate the saw using only one hand.
Contact of teh guide bar tip with any object should be avoided! Tip contact may case the guide bar to move suddenly upward and backward, which may cause serious injury.
Warning! Do not touch chain at the chip ejection point.
Warning! The use of an RCD or other circuit
:
breaker unit does not release the operator of your chainsaw from the safety instructions and safe working practices given in this user manual.
Features
1. On/off switch
2. Lock-off button
3. Front guard/chain brake assembly
4. Guide bar
5. Chain
6. Chain cover assembly
9
ENGLISH
(Original instructions)
7. Chain adjust locking knob
8. Chain tension adjustment wheel
9. Chain sheath
10. Power cord
11. Power cord retainer
12. Oil cap
13. Oil level indicator
Assembly
Warning! Always wear protective gloves when
@ @
@
working on your chainsaw.
Warning! Before performing any assembly or maintenance on power tools, switch off and disconnect from mains.
Warning! Remove the cable tie that attaches the chain to the chainbar before assembly.
u Place the chainsaw onto a stable surface. u Set the front guard/chain brake assembly (3) to the
u Rotate the chain adjust locking knob (7) counterclockwise
u Place the chain (5) over the guide bar (4) making sure that
the saw chain cutters on the upper part of the guide bar
Before use and after every 10 minutes of use, you must check the chain tension.
u Disconnect the tool from the mains supply u
tension is correct when the chain (5) snaps back after be­ing pulled 3 mm away from the guide bar (4). There should be no "sag" between the guide bar (4) and the chain (5)
u Loosen the chain adjust locking knob (7) counterclockwise
one half turn.
u Turn the chain tension adjustment wheel (8) clockwise
until slight resistance is felt.
u Check tension - see 'Checking the chain tension'.
u If satisfactory, re-tighten locking knob (7), or if
more tension is required, turn adjustment wheel (8). Then
re-tighten locking Knob (7). Note: Do not over-tension the chain as this will lead to excessive wear and will reduce the life of the guide bar and the chain. Note: When the chain is new, check the tension frequently
use because a new chain stretches slightly.
Use
W
arning! Let the tool work at its own pace. Do not overload.
u Guide the chain (5) around the guide bar (4) and pull it to
create a loop to one side at the rear end of the guide bar (4).
u Guide the chain (5) around the drive sprocket (14), line up
the slot in the guide bar and the centre hole of the chain
Note: rotate chain tensioning wheel as necessary to line centre hole with bolt (15). Warning! Make sure that the front guard/chain brake assem-
u Place the chain cover assembly (6) onto the chainsaw. u Make sure that the tab (17) on the chain cover assembly
E).
u Rotate the chain adjust locking knob (7) clockwise until
snug.
u Check the tension - see 'Checking the chain tension'
below.
uIf chain tension is loose - see 'Increasing the chain tension'
below.
10
u
recommended chain oil. You can see the oil level in the oil
u Periodically switch off and check the oil level indicator
(13); if it is less than a quarter full, disconnect your chain-
Oiling the chain
This chainsaw is equipped with an automatic oiling system that keeps the saw chain and guide bar constantly lubricated. We recommend that you use only BLACK+DECKER oil during the lifetime of your chainsaw because mixtures of different oils could lead to the oil becoming degraded, which can drastically shorten the lifetime of the saw chain and create additional risks.
Never use waste oil, thick oil or very thin sewing machine oil. These may damage your chainsaw .Only use the correct grade of oil (cat. no. A6023-50).
u The chain saw will automatically feed oil to the chain dur
ing use.
(Original instructions)
ENGLISH
u It is normal for a small amount of excess oil to from the
chain saw bar and chain during storage. Do not store chain saw on top of anything that may be damaged by the dripping oil.
u Make sure that the tool is disconnected from the mains
supply.
u Pull the front guard/chain brake assembly (3) back into the
u The tool is now ready to use.
Switching on
Note: It will not be possible to switch the tool on if the front
guard/chain brake assembly is not in the "set" position.
u
off button (2) and then push the on/off switch (1) to start.
u When the motor starts, remove your thumb from the lock
button (2) and grip the handle firmly. Do not force the tool, allow the tool to do the work. It will do a better and safer job at the speed for which it is designed. Excessive force will stretch the saw chain (5).
How the anti-kickback chain brake works
In the event of kickback, your left hand comes in contact with the front guard, pushing it forwards, toward the workpiece, and stops the tool within a few fractions of a second.
How to test the anti-kickback chain brake (fig. A)
u Always check that the kickback brake operates correctly
before use.
u Grip the tool firmly in both hands on a firm surface make
sure the saw chain (5) is clear of the ground and switch on
(see" How to switch the chainsaw on").
u Rotate your left hand forward around the front handle so
that the back of your hand comes in contact with the front
guard/chain brake assembly (3) and push it forwards,
toward the workpiece (fig. A). The saw chain (5) should
stop within a few fractions of a second. To reset after the operation of the front guard/chain brake assembly (3) follow the instructions for "How to set the chain brake". Note: Avoid re-starting the tool until you hear the motor come to a complete rest. Note: If chain brake in malfunctioning take the product to an approved BLACK+DECKER service centre.
If the saw chain (5) or guide bar (4) becomes jammed
u Switch the tool off. u Disconnect the tool from the mains supply.
u Open the cut with wedges to relieve the strain on the
guide bar (4). Do not try to wrench the chainsaw free.
u Start a fresh cut.
Felling (fig. I - K)
Inexperienced users should not attempt to fell trees. The user may suffer injury or cause damage to property as a result of failure to control the direction of fall, the tree may splinter or damaged/dead branches may fall during cutting. The safe distance between a tree to be felled and bystanders, buildings and other objects is at least 2 1/2 times the height of the tree. Any bystander, building or object within this distance is at risk from being struck by the tree when felled.
Before attempting to fell a tree:
u Make sure that there are no local by-laws or regulations
that would prohibit or control the felling of the tree.
u Consider all conditions that may affect the direction of fall,
including:
u The intended direction of fall. u The natural lean of the tree. u Any unusual heavy limb structure or decay. u Surrounding trees and obstacles including overhead
lines and underground drains.
u The wind speed and direction.
Pre-plan a safe exit from falling trees or branches. Make sure that the exit route is clear of obstacles that would prevent or hinder movement. Remember that wet grass and freshly cut bark is slippery.
u Do not attempt to fell trees where the tree diameter is
greater than the cutting length of the chainsaw.
u Cut a direction notch to determine the direction of fall. u Make a horizontal cut to a depth of between 1/5th and
1/3rd of the diameter of the tree, perpendicular to the line
u
and make a notch of about 45°.
u Make a single horizontal felling cut from the other side 25
J). Do not cut through to the direction notch, you could lose control of the direction of fall.
u Drive a wedge or wedges into the felling cut to open it and
Pruning trees
Make sure that there are no local by-laws or regulations that would prohibit or control the pruning of the tree limbs. Pruning should only be undertaken by experienced users there is an increased risk of the saw chain pinching and kick back.
11
ENGLISH
(Original instructions)
Before pruning consideration should be given to conditions affecting the direction of fall including:
u The length and weight of the branch to be cut. u Any unusual heavy limb structure or decay. u Surrounding trees and obstacles including overhead. u The wind speed and direction. u The branch being intertwined with other branches.
The operator should consider access to the tree limb and the direction of fall. The tree branch is liable to swing towards the tree trunk. In addition to the user bystanders, objects and property below the branch will be at risk.
u -
tion to a maximum depth of one third the diameter of the
branch.
u
How you should cut depends on how the log is supported. Use a saw horse whenever possible. Always start a cut with the saw chain running and the spiked bumper (20) in contact
tion of the spiked bumper against the wood.
When supported along its whole length:
u Make a downward cut, but avoid cutting the earth as this
will blunt your saw chain quickly.
When supported at both ends:
u First, cut one third down to avoid splintering and second,
When supported at one end:
u First cut one third up to avoid splintering and second, cut
down to prevent splintering.
When on a slope:
u Always stand on the uphill side.
u Secure the workpiece using chocks or wedges. The user
or a bystander should not steady the log by sitting or
standing on it. Make sure that the saw chain does not
contact the ground.
This is strongly recommended whenever possible.
u Position the log in a stable position. Always cut on the
outside of the saw horse arms. Use clamps or straps to
secure the workpiece.
Removing the branches from a fallen tree. When limbing, leave larger lower limbs to support the log off the ground. Remove the small limbs in one cut. Branches under tension should be cut from the bottom of the branch towards the top to avoid binding the chain saw. Trim limbs from opposite side keeping tree stem between you and saw. Never make cuts with saw between your legs or straddle the limb to be cut.
Troubleshooting
Problem Possible cause Possible solution
Tool will not start
-
Chain does not stop
within 2 seconds
when the tool is
switched off
Bar/chain appear hot/
smoking
Chainsaw does not
cut well
Chainsaw not using
oil
Lock button not
pressed.
Front guard in the
brake position
Blown fuse Replace fuse
Tripped RCD Check RCD
TMains loead not
connected
Chain tension is too
slack
Oil tank empty Check oil tank level
Oil hole blocked on
chain bar
Chain tension is too
tight
Guide bar sprocket
nose needs greasing
Chain on backwards
Debris in tank
Oil hole in cap blocked
Debris in chain bar
Debris in oil outlet Remove debris
Press the lock button.
Reset front guard
Check mains supply
Check chain tension
E) and clear the groove
around the edge of the
chainbar.
Check chain tension
Oil the guide bar
sprocket nose
Check/modify chain
direction
Sharpen
Empty oil from tank and
replace
Remove debris from
hole
Remove debris and
clean the chain bar
12
(Original instructions)
ENGLISH
Maintenance
Regular maintenance ensures a long effective life for the tool. We recommend you make the following checks on a regular basis.
Warning! Before performing any maintenance on power tools:
u Switch off and disconnect the tool from the mains supply.
Oil level
The level in the reservoir should not be allowed to fall below a quarter full.
u After every few hours of use and before storage, remove
the guide bar (4) and the saw chain (5) and clean them
thoroughly.
u Make sure that the guard is clean and free from debris. u On reassembling, turn the guide bar (4) through 180° ,
remove the chain tensioning wheel with a screwdriver and
re-attatch to the opposite side of the guide bar. Warning! Do not overtighten.
u Oil sprocket nose via the sprocket lubriation hole (19), this
ensure an even distribution of wear around the guide bar
rails.
Saw chain sharpening
If you are to get the best possible performance from the tool it is important to keep the teeth of the saw chain sharp. Guidance for this procedure is found on the sharpener pack­age. For this purpose we recomment the purchase of teh BLACK+DECKER saw chain sharpening kit (available from BLACK+DECKER service agents and selected dealers).
Replacing worn out saw chains
Replacement saw chains are available through retailers or BLACK+DECKER service agents. Always use genuine spare parts (Replacement chain part number A6245CS-XJ).
Mains plug replacement (U.K. & Ireland only)
u Safely dispose of the old plug. u Connect the brown lead to the live terminal in the new
plug.
u Connect the blue lead to the neutral terminal.
Warning! No connection is to be made to the earth terminal.
Recommended fuse: 13 A.
Protecting the environment
Separate collection. This product must not be disposed of with normal household waste.
needs replacement, or if it is of no further use to you, do not dispose of it with household waste. Make this product avail­able for separate collection.
Separate collection of used products and
z
Local regulations may provide for separate collection of elec­trical products from the household, at municipal waste sites or by the retailer when you purchase a new product.
BLACK+DECKER provides a facility for the collection and re­cycling of BLACK+DECKER products once they have reached the end of their working life. To take advantage of this service please return your product to any authorised repair agent who will collect them on our behalf.
You can check the location of your nearest authorised repair
packaging allows materials to be recycled and used again. Re-use of recycled materials helps prevent environmental pollution and reduces the demand for raw materials.
Saw chain sharpness
The saw chain cutters will blunt immediately if they touch the ground or a nail while cutting.
Saw chain tension
Regularly check the saw chain tension.
What to do if your chainsaw needs repair.
Your chainsaw is manufactured in accordance with the rel­evant safety requirements. Repairs should only be carried out
may result in considerable danger to the user. We recommend you keep this user manual in a safe place.
address indicated in this manual. Alternatively, a list of author­ised BLACK+DECKER repair agents and full details of our after-sales service and contacts are available on the Internet at: www.2helpU.com
13
Technical data
Voltage V
Power input W
Length mm
Chain speed (no load) m/s
Max cutting length mm
Oil capacity ml
CS2040
(Type 1)
ac
230V 230V
2000W 2200W
400 450
12.5m/s 12.5m/s
397 436
200ml 150ml
CS2245
(Type 1)
Weight kg 5.5 5.66
Safety class II II
Level of sound pressure according to EN 60745:
L
(sound pressure) 85.7/95 dB(A), Uncertainty (K) 3/2.5 dB(A)
pA
L
(sound power)102.1/106dB(A), Uncertainty (K) 3/2.5 dB(A)
WA
Vibration total values (triax vector sum) according to EN 60745:
Vibration emission value (a
) 4.5/5.5m/s2, uncertainty (K) 1.5 m/s
h
2
(Original instructions)
ENGLISH
15
15
Australia & New Zealand
Stanley Black & Decker
www.blackanddecker.com.au
www.blackanddecker.co.nz
Tel.1800 338 002 (Aust) or Tel. 0800 339 258 (NZ)
00000000 05/2015
Loading...
