Page 1
COMMAND-LINE INTERFACE (CLI) GUIDE
LPB3010, LPB3028A, LPB3052A
GIGABIT
MANAGED
POE+ SWITCH
24/7 TECHNICAL SUPPORT AT 1.877.877.2269 OR VISIT BLACKBOX.COM
LPB3028A clear lacp statistics
LPB3028A
Page 2
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TABLE OF CONTENTS
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
CONTENTS
ABOUT THIS GUIDE ......................................................................................................................................................................................... 9
PURPOSE .........................................................................................................................................................................................................................9
AUDIENCE .......................................................................................................................................................................................................................9
1. CLI MANAGEMENT .................................................................................................................................................................................... 10
1.1 LOGIN ......................................................................................................................................................................................................... 10
1.2 CLI COMMANDS ....................................................................................................................................................................................... 11
1.3 GLOBAL COMMANDS OF CLI ................................................................................................................................................................. 12
2. CABLEDIAG COMMANDS OF CLI ............................................................................................................................................................ 14
3. CLEAR OF CLI ............................................................................................................................................................................................. 15
3.1 A CC ES S ...................................................................................................................................................................................................... 16
3.2 ACCESS-LIST ............................................................................................................................................................................................ 16
3.3 DOT1X ........................................................................................................................................................................................................ 17
3.4 EPS ............................................................................................................................................................................................................. 17
3.5 ER PS ........................................................................................................................................................................................................... 18
3.6 IP ................................................................................................................................................................................................................. 18
3.7 I PV6 ............................................................................................................................................................................................................ 20
3.8 LACP .......................................................................................................................................................................................................... 21
3.9 LINK-OAM .................................................................................................................................................................................................. 21
3.10 LLDP ......................................................................................................................................................................................................... 22
3.11 LOGGING .................................................................................................................................................................................................. 23
3.12 M A C .......................................................................................................................................................................................................... 23
3.13 M E P .......................................................................................................................................................................................................... 24
3.14 M V R .......................................................................................................................................................................................................... 24
3.15 PORT-SECURITY ..................................................................................................................................................................................... 25
3.16 P T P ........................................................................................................................................................................................................... 26
3.17 S F LO W ...................................................................................................................................................................................................... 26
3.18 SPANNING-TREE .................................................................................................................................................................................... 27
3.19 STATISTICS ............................................................................................................................................................................................. 28
3.20 SYSTEM ................................................................................................................................................................................................... 28
4. CONFIGURE COMMANDS OF CLI ............................................................................................................................................................30
4.1 TERMINAL ................................................................................................................................................................................................. 32
4.1.1 A A A ....................................................................................................................................................................................................................... 32
4.1.2 ACCESS ............................................................................................................................................................................................................... 33
4.1.3 ACCESS-LIST ..................................................................................................................................................................................................... 34
4.1. 3.1 A C E..................................................................................................................................................................................................................... 34
4.1.3.2 RATE-LIMITER ................................................................................................................................................................................................ 38
4.1.4 AGGREGATION................................................................................................................................................................................................... 38
4.1.5 BANNER ............................................................................................................................................................................................................... 39
4.1.6 CLOCK .................................................................................................................................................................................................................. 40
4.1.7 DEFAULT ...............................................................................................................................................................................................................41
2
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 3
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TABLE OF CONTENTS
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
4.1.8 D MS .......................................................................................................................................................................................................................41
4.1.9 DO ........................................................................................................................................................................................................................... 42
4.1.10 DO T 1X ..................................................................................................................................................................................................................42
4.1.11 E NA BL E .............................................................................................................................................................................................................. 43
4.1.12 E ND ..................................................................................................................................................................................................................... 44
4.1.13 E PS ...................................................................................................................................................................................................................... 44
4.1.14 ER PS ................................................................................................................................................................................................................... 46
4.1.15 E VE NT ................................................................................................................................................................................................................ 48
4.1.16 GREEN-ETHERNET ..........................................................................................................................................................................................49
4.1.17 G VRP ................................................................................................................................................................................................................... 50
4.1.18 HE LP ................................................................................................................................................................................................................... 50
4.1.19 H OS T NA M E .......................................................................................................................................................................................................51
4.1.20 INTERFACE ........................................................................................................................................................................................................51
4.1. 21 I P ......................................................................................................................................................................................................................... 52
4.1. 2 2 I PMC ................................................................................................................................................................................................................... 55
4.1. 2 3 I PV6 .................................................................................................................................................................................................................... 56
4.1.24 JSON .................................................................................................................................................................................................................. 56
4.1. 2 5 L ACP .................................................................................................................................................................................................................. 57
4.1.26 LINE .................................................................................................................................................................................................................... 58
4.1.27 LLDP ................................................................................................................................................................................................................... 58
4.1.28 LOGGING ............................................................................................................................................................................................................61
4.1.29 LOOP-PROTECT ...............................................................................................................................................................................................62
4.1. 3 0 M AC .................................................................................................................................................................................................................... 63
4.1. 31 M EP .................................................................................................................................................................................................................... 64
4.1.32 MONITOR .......................................................................................................................................................................................................... 69
4.1.33 MVR .....................................................................................................................................................................................................................71
4.1.34 MVRP ................................................................................................................................................................................................................. 72
4.1. 35 N O ....................................................................................................................................................................................................................... 73
4.1. 35 .1 A A A ..................................................................................................................................................................................................................74
4.1.35.2 ACCESS ...........................................................................................................................................................................................................75
4.1.35.3 ACCESS-LIST .................................................................................................................................................................................................75
4.1.35.4 AGGREGATION ..............................................................................................................................................................................................76
4.1.35.5 BANNER ..........................................................................................................................................................................................................76
4.1.35.6 CLOCK ............................................................................................................................................................................................................ 77
4.1.35.7 DEBUG ............................................................................................................................................................................................................ 77
4.1. 35 . 8 D OT 1X ............................................................................................................................................................................................................. 79
4.1. 35 .9 E N AB L E .......................................................................................................................................................................................................... 80
4.1. 35 .10 E P S .................................................................................................................................................................................................................81
4.1. 35 .11 E RP S ............................................................................................................................................................................................................... 81
4.1.35.12 GREEN-ETHERNET .................................................................................................................................................................................... 82
4-1.35 .13 GV RP ............................................................................................................................................................................................................. 82
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
3
Page 4
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TABLE OF CONTENTS
4-1.35.14 HOSTNAME ................................................................................................................................................................................................ 83
4-1.35.15 INTERFACE .................................................................................................................................................................................................. 83
4-1.35 .16 IP .................................................................................................................................................................................................................... 84
4-1.35 .17 IP MC ............................................................................................................................................................................................................. 86
4-1.35 .18 IP V6 ............................................................................................................................................................................................................... 87
4-1.35.19 JSON ............................................................................................................................................................................................................. 87
4-1.35.20 LACP ............................................................................................................................................................................................................ 88
4-1.35.21 LLDP ............................................................................................................................................................................................................. 89
4-1.35.22 LOGGING ..................................................................................................................................................................................................... 90
4-1.35.23 LOOP-PROTECT .........................................................................................................................................................................................91
4-1.35.24 MAC .............................................................................................................................................................................................................. 92
4-1.35.25 MEP .............................................................................................................................................................................................................. 93
4-1.35.26 MONITOR .....................................................................................................................................................................................................95
4-1.35.27 MVR .............................................................................................................................................................................................................. 96
4-1.35.28 MVRP ............................................................................................................................................................................................................ 97
4-1.35.29 NTP ................................................................................................................................................................................................................97
4-1.35.30 POE ................................................................................................................................................................................................................97
4-1.35.31 PORT-SECURIT Y ....................................................................................................................................................................................... 98
4-1.35.32 PRIVILEGE .................................................................................................................................................................................................. 99
4-1.35.33 PROMPT ...................................................................................................................................................................................................... 99
4-1.35.34 PTP ............................................................................................................................................................................................................. 100
4-1.35.35 QOS ............................................................................................................................................................................................................. 101
4-1.35.36 RADIUS-SERVER ..................................................................................................................................................................................... 103
4-1.35.37 RMON ......................................................................................................................................................................................................... 104
4-1.35.38 SFLOW ....................................................................................................................................................................................................... 105
4-1.35.39 SNMP-SERVER ........................................................................................................................................................................................ 106
4-1.35.40 SPANNING-TREE ..................................................................................................................................................................................... 107
4-1.35.41 SV L .............................................................................................................................................................................................................. 108
4-1.35.42 SWITCHPORT .......................................................................................................................................................................................... 109
4-1.35.4 3 SYST E M ......................................................................................................................................................................................................110
4-1.35.44 TACACS-SERVER ..................................................................................................................................................................................... 110
4-1.35.45 UDLD ...........................................................................................................................................................................................................111
4-1.35.46 UPNP ........................................................................................................................................................................................................... 112
4-1.35.47 USERNAME ................................................................................................................................................................................................112
4-1.35.48 VLAN ........................................................................................................................................................................................................... 113
4-1.35.49 VO I C E .......................................................................................................................................................................................................... 114
4-1.35.50 W EB ............................................................................................................................................................................................................. 114
4-1.36 NTP ...................................................................................................................................................................................................................115
4-1.37 POE .................................................................................................................................................................................................................... 116
4-1.38 PORT-SECURITY ............................................................................................................................................................................................117
4-1.39 PRIVILEGE ....................................................................................................................................................................................................... 118
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
4
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 5
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TABLE OF CONTENTS
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
4-1.40 PROMPT ..........................................................................................................................................................................................................118
4-1.41 P T P .................................................................................................................................................................................................................... 119
4-1.42 Q O S ...................................................................................................................................................................................................................121
4-1.43 RADIUS-SERVER ........................................................................................................................................................................................... 125
4-1.44 RMON .............................................................................................................................................................................................................. 126
4-1.45 SFLOW ............................................................................................................................................................................................................. 128
4-1.46 SMTP ............................................................................................................................................................................................................... 129
4-1.47 SNMP-SERVER .............................................................................................................................................................................................. 129
4-1.47.1 ACCESS ........................................................................................................................................................................................................ 130
4-1.47.2 COMMUNITY ...............................................................................................................................................................................................131
4 -1. 4 7. 3 C O NTA CT ..................................................................................................................................................................................................... 132
4-1.47.4 ENGINE-ID.................................................................................................................................................................................................... 132
4 -1. 4 7. 5 H OS T ............................................................................................................................................................................................................. 132
4-1.47.6 LOCATION .................................................................................................................................................................................................... 133
4-1.47.7 SECURITY-TO-GROUP............................................................................................................................................................................... 133
4 -1. 4 7. 8 U SE R ............................................................................................................................................................................................................. 134
4 -1. 4 7.9 V IE W .............................................................................................................................................................................................................. 135
4-1.48 SPANNING-TREE .......................................................................................................................................................................................... 135
4-1.48.1 AGGREGATION ........................................................................................................................................................................................... 135
4-1.4 8.2 E D G E ............................................................................................................................................................................................................. 136
4-1.48.3 MODE ........................................................................................................................................................................................................... 136
4-1.48.4 MST............................................................................................................................................................................................................... 137
4-1.4 8.5 REC OV E R Y .................................................................................................................................................................................................. 138
4-1.48.6 TRANSMIT .................................................................................................................................................................................................. 138
4-1.49 S VL ................................................................................................................................................................................................................... 139
4-1.50 SWITCHPORT ................................................................................................................................................................................................ 139
4-1.51 S Y S TEM .......................................................................................................................................................................................................... 140
4-1.52 TACACS-SERVER ...........................................................................................................................................................................................141
4-1.53 UDLD ................................................................................................................................................................................................................ 142
4-1.5 4 UPN P ............................................................................................................................................................................................................... 143
4-1.55 USERNAME .................................................................................................................................................................................................... 144
4-1.56 VLAN ................................................................................................................................................................................................................ 145
4-1.57 VO ICE ............................................................................................................................................................................................................... 146
4-1.58 WEB .................................................................................................................................................................................................................. 147
5. COPY COMMANDS OF CLI ..................................................................................................................................................................... 148
6. DELETE COMMANDS OF CLI .................................................................................................................................................................. 149
7. DIR COMMANDS OF CLI .......................................................................................................................................................................... 150
8. DISABLE COMMANDS OF CLI ................................................................................................................................................................ 151
9. DO COMMANDS OF CLI ........................................................................................................................................................................... 152
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
5
Page 6
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TABLE OF CONTENTS
10. DOT1X COMMANDS OF CLI .................................................................................................................................................................. 153
11. ENABLE COMMANDS OF CLI ............................................................................................................................................................... 154
12. ERPS COMMANDS OF CLI .................................................................................................................................................................... 155
13. FIRMWARE OF CLI.................................................................................................................................................................................. 156
14. IP COMMANDS OF CLI .......................................................................................................................................................................... 157
15. IPERF COMMANDS OF CLI ................................................................................................................................................................... 158
16. IPERF3 COMMANDS OF CLI ................................................................................................................................................................. 159
17. IPV6 COMMANDS OF CLI ...................................................................................................................................................................... 160
18. LINK-OAM ................................................................................................................................................................................................ 161
19. MORE OF CLI ........................................................................................................................................................................................... 162
20. NO COMMANDS OF CLI ........................................................................................................................................................................ 163
21. PING OF CLI ............................................................................................................................................................................................. 165
22. PLATFORM COMMANDS OF CLI ......................................................................................................................................................... 167
23. PTP COMMANDS OF CLI ...................................................................................................................................................................... 168
24. RELOAD OF CLI ....................................................................................................................................................................................... 170
25. SEND OF CLI ........................................................................................................................................................................................... 171
26. SHOW OF CLI .......................................................................................................................................................................................... 172
26-1 AAA ........................................................................................................................................................................................................ 173
26-2 ACC E S S ................................................................................................................................................................................................. 174
26-3 ACCESS-LIST ....................................................................................................................................................................................... 175
26-4 AGGREGATION ..................................................................................................................................................................................... 176
26-5 BOARD- DATA ........................................................................................................................................................................................ 177
26-6 CLOCK ................................................................................................................................................................................................... 178
26 -7 D OT1X .................................................................................................................................................................................................... 178
26-8 EPS ......................................................................................................................................................................................................... 180
26-9 ERPS ...................................................................................................................................................................................................... 181
26 -10 E VE NT .................................................................................................................................................................................................. 181
26-11 GREEN-ETHERNET ............................................................................................................................................................................18 3
26 -12 H I ST O RY .............................................................................................................................................................................................. 185
26-13 INTERFACE ......................................................................................................................................................................................... 185
26 -14 I P........................................................................................................................................................................................................... 188
26 -15 I P MC .................................................................................................................................................................................................... 191
26 -16 I PV6 ...................................................................................................................................................................................................... 192
26 -17 L AC P .................................................................................................................................................................................................... 193
26-18 LICENSE ........................................................................................................................................................................................................... 194
26 -19 L I NE ...................................................................................................................................................................................................... 195
26-20 LINK-OAM ........................................................................................................................................................................................... 196
26-21 LLDP .................................................................................................................................................................................................... 197
26-22 LOGGING ............................................................................................................................................................................................. 199
26-23 LOOP-PROTECT ................................................................................................................................................................................. 200
26-24 M AC ..................................................................................................................................................................................................... 201
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
6
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 7
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TABLE OF CONTENTS
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
26-25 M EP ......................................................................................................................................................................................................203
26-26 MONITOR ............................................................................................................................................................................................ 204
26-27 MRP .....................................................................................................................................................................................................206
26-28 M V R ..................................................................................................................................................................................................... 207
26-29 NTP ......................................................................................................................................................................................................208
26-30 PL ATFO R M ......................................................................................................................................................................................... 209
26-31 PO E ...................................................................................................................................................................................................... 210
26-32 PORT-SECURITY ................................................................................................................................................................................ 211
26-33 PRIVILEGE .......................................................................................................................................................................................... 212
26-34 PROCESS ............................................................................................................................................................................................ 213
26-35 PTP ...................................................................................................................................................................................................... 213
26-36 PVLAN ................................................................................................................................................................................................. 215
26-37 QOS ...................................................................................................................................................................................................... 216
26-38 RADIUS-SERVER ............................................................................................................................................................................... 218
26-39 RMON .................................................................................................................................................................................................. 219
26-40 RUNNING-CONFIG ............................................................................................................................................................................ 220
26-41 SFLOW ................................................................................................................................................................................................. 221
26-42 SMTP ................................................................................................................................................................................................... 222
26-43 SNMP ..................................................................................................................................................................................................223
26-44 SPANNING-TREE ............................................................................................................................................................................... 225
26-45 SVL ...................................................................................................................................................................................................... 226
26-46 SWITCHPORT ....................................................................................................................................................................................227
26-47 SYSTEM .............................................................................................................................................................................................. 228
26-48 TACACS-SERVER ............................................................................................................................................................................... 228
26-49 TERMINAL .......................................................................................................................................................................................... 229
26-50 U DLD .................................................................................................................................................................................................... 230
26-51 UPNP ................................................................................................................................................................................................... 231
26-52 USER-PRIVILEGE ............................................................................................................................................................................... 231
26-53 USERS ................................................................................................................................................................................................. 232
26-54 VERSION ............................................................................................................................................................................................. 233
26-55 VLAN ...................................................................................................................................................................................................235
26-56 VOICE ..................................................................................................................................................................................................237
26-57 WEB .....................................................................................................................................................................................................238
27. TERMINAL OF CLI ..................................................................................................................................................................................240
28. TRACEROUTE OF CLI ............................................................................................................................................................................ 241
29. CLI COMMAND REFERENCES ..............................................................................................................................................................243
29-1 PRIVILEGE LEVEL ................................................................................................................................................................................243
29-2 COMMAND MODES .............................................................................................................................................................................243
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
7
Page 8
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TABLE OF CONTENTS
DISCLAIMER .................................................................................................................................................................................. 283
TRADEMARKS USED IN THIS MANUAL ...................................................................................................................................... 283
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
8
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 9
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
ABOUT THIS GUIDE
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
ABOUT THIS GUIDE
PURPOSE
This guide gives specific information on how to operate CLI to manage the LPB3010A, LPB3028A, or LPB3052A switch. The examples
show the LPB3028A, but the screens are similar for LPB3010A and LPB3052A.
Here are the differences between the three switch models:
The LPB3010A delivers 8 (10M/100M/1G) RJ-45 with 8 PoE+ (support 802.3at/af, and total up to 130 W) ports, two 10GbE SFP+ ports,
and an RJ-45 Console port.
The LPB3028A has 24 (10M/100M/1G) RJ-45 with 24 PoE+ (support 802.3at/af, and total up to 370 W) ports, 4 10GbE SFP+ ports, and
an RJ-45 Console port.
The LPB3052A offers 48 (10M/100M/1G) RJ-45 with 48 PoE+ (support 802.3at/af, and total up to 740 W) ports, 4 10GbE SFP+ ports, and
an RJ-45 console port.
All three models provide high HW performance and environment flexibility for SMBs and Enterprises.
AUDIENCE
The guide is intended for use by network administrators who are responsible for operating and maintaining network equipment;
consequently, it assumes a basic working knowledge of general switch functions, Internet Protocol (IP), and Telnet Protocol.
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
9
Page 10
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CHAPTER 1: CLI MANAGEMENT
1. CLI MANAGEMENT
The following description is a brief procedure for the network connection.
Attach the RJ-45 serial port on the switch’s front panel to connect to the switch for telnet configuration.
At the “Com Port Properties” Menu, configure the parameters as shown below.
Baud rate 115200
Stop bits 1
Data bits 8
Parity N
Flow control none
1.1 LOGIN
The command-line interface (CLI) is a text-based interface. Users can access the CLI through either a direct serial connection to the
device or a Telnet session (Default IP address: 192.168.1.1). The default user and password to login into the Managed Switch are listed
below:
Username: admin
Password: <none>
NOTE: <none> means an empty string, just press the Enter key.
After you log in successfully, the prompt will be shown as “<sys_name>#“ . This means you are configured as an administrator and have
the privileges to configure the Managed Switch. If you are not logged in as the administrator, the prompt will be shown as “<sys_name>>”.
It means you are configured as a guest and are only allowed to set the system under the administrator. Each CLI command has its
privileges.
Username: admin
Password:
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
10
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 11
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CHAPTER 1: CLI MANAGEMENT
1.2 CLI COMMANDS
The CLI is divided into several modes. If a user has enough privileges to run a particular command, the user has to run the command in
the correct mode. To see the commands of the mode, input “?” after the system prompt, then all commands will be listed in the screen.
The command modes are listed as shown next.
COMMAND MODES TABLE
MODE PROMPT COMMAND FUNCTION IN THIS MODE
exec <sys_name> # Display current configuration, diagnostics,
config <sys_name>(config)# Configure features other than those below
Config-if <sys_name>(config-interface)# Configure ports
Config-if-vlan <sys_name>(config-if-vlan)# Configure static vlan
Config-line <sys_name>(config-line)# Line Configuration
Config-impc-profile <sys_name>(config-impc-profile)# IPMC Profile
Config-snmp-host <sys_name>(config-snmp-host)# SNMP Server Host
Config-stp-aggr <sys_name>(config-stp-aggr)# STP Aggregation
Config-dhcp-pool <sys_name>(config-dhcp-pool)# DHCP Pool Configuration
Config-rfc2544-profile <sys_name>(config-rfc2544-profile)# RFC2544 Profile
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
Commands reside in the corresponding modes and can run only in that mode. If a user wants to run a particular command, he has to
change to the appropriate mode. The command modes are organized as a tree, and users start in enable mode. The following table
explains how to change from one mode to another.
CHANGE BETWEEN COMMAND MODES TABLE
MODE ENTER MODE LEAVE MODE
exec -- --
config Configure terminal exit
config-interfcae Interface <port-type> <port-type-list> exit
config-vlan Interface vlan <vlan_list> exit
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
11
Page 12
CHAPTER 1: CLI MANAGEMENT
1.3 GLOBAL COMMANDS OF CLI
LPB3028A ?
CableDiag Cable Diagnostic keyword
clear Reset functions
configure Enter configuration mode
copy Copy from source to destination
delete Delete one file in flash: file system
dir Directory of all files in flash: file system
disable Turn off privileged commands
do To run exec commands in config mode
dot1x IEEE Standard for port-based Network Access Control
enable Turn on privileged commands
erps Ethernet Ring Protection Switching
exit Exit from EXEC mode
firmware Firmware upgrade/swap
help Description of the interactive help system
ip IPv4 commands
iperf network bandwidth measurement tool
iperf3 network bandwidth measurement tool
ipv6 IPv6 configuration commands
link-oam Link OAM configuration
logout Exit from EXEC mode
more Display file
no Delete trace hunt string
ping Send ICMP echo messages
platform Platform configuration
ptp Misc non persistent 1588 settings.
reload Reload system.
rfc2544 RFC2544 performance tests
send Send a message to other tty lines
show Display statistics cou nters.
terminal Set terminal line parameters
traceroute Send IP Traceroute messages
y1564 Y.1564 service activation tests
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
12
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 13
CHAPTER 1: CLI MANAGEMENT
Exit
Exit from EXEC mode.
Syntax: exit
Parameter: None.
Example:
LPB3028A(config)# exit
LPB3028A
Help
Description of the interactive help system.
Syntax: help
Parameter: None.
Example:
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
LPB3028A help
Help may be requested at any point in a command by entering a question mark
‘?’. If nothing matches, the help list will be empty and you must back up until
entering a ‘?’ shows the available options.
Two styles of help are provided:
1. Full help is available when you are ready to enter a command argument
(e.g. ‘show ?’) and describes each possible argument.
2. Partial help is provided when an abbreviated argument is entered
and you want to know what arguments match the input (e.g. ‘show pr?’.)
LPB3028A
logout
Exit from EXEC mode.
Syntax: logout
Parameter: none
Example:
LPB3028A lo g out
Usern ame:
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
13
Page 14
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CHAPTER 2: CABLEDIAG COMMANDS OF CLI
2. CABLEDIAG COMMANDS OF CLI
Cable Diagnostic keyword
Syntax: CableDiag interface GigabitEthernet <port_type_id>
Parameter:
Interface Interface keyword
GigabitEthernet 1 Gigabit Ethernet Port
<port_type_id> Port ID in 1/1-24
Example:
LPB3028A CableDiag interface GigabitEthernet 1/23
Starting Cable Diagnostic - Please wait
Interface Link Status Test Result Length
---------------------- ------------- ------------- -------------
GigabitEthernet 1/23 Link Down detect error or check cable length is between 7-120 meters
LPB3028A
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
14
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 15
CHAPTER 3: CLEAR OF CLI
3. CLEAR OF CLI
CLEAR Commands Table
CLEAR COMMANDS TABLE
COMMAND FUNCTION
access Access management
access-list Access list
dot1x IEEE Standard for port-based Network Access Control
eps Ethernet Protection Switching
erps Ethernet Ring Protection Switching
ip Interface Internet Protocol config commands
ipv6 IPv6 configuration commands
lacp Clear LACP statistics
link-oam Clear Link OAM statistics
lldp Clears LLDP statistics
logging Syslog
mac MAC Address Table
mep Maintenance Entity Point
mvr Multicast VLAN Registration configuration
port-security Port Security
ptp
sflow Statistics flow
spanning-tree STP Bridge
statistics Clear statistics for one or more given interfaces
system system
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
15
Page 16
CHAPTER 3: CLEAR OF CLI
3.1 A CC ES S
Access management
Syntax: clear access management statistics
Parameter:
management Access management configuration.
statistics Statistics data.
Example:
LPB3028A clear access management statistics
LPB3028A
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
3.2 ACCESS-LIST
Access list.
Syntax: Clear access-list ace statistics
Parameter:
ace Access list entry
statistics Traffic statistics
Example:
LPB3028A clear access-list ace statistics
LPB3028A
16
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 17
CHAPTER 3: CLEAR OF CLI
3.3 DOT1X
IEEE Standard for port-based Network Access Control.
Syntax
Clear dot1x statistics
Clear dot1x statistics interface { [ * ] | GigabitEthernet | 10 GigabitEthernet } < PORT_TYPE_LIST>
Parameter
statistics Clears the statistics counters
interface Interface
* All switches or All ports
GigabitEthernet 1 Gigabit Ethernet Port
10GigabitEthernet 10 Gigabit Ethernet Port
<port_type_list> Port list for all port types
<port_type_list> Port list in 1/1-24
<port_type_list> Port list in 1/1-4
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
EXAMPLE
LPB3028A clear dot1x statistics interface GigabitEthernet 1/1-24
LPB3028A
3.4 EPS
Ethernet Protection Switching.
Syntax
Clear eps <uint> wtr
Parameter
<uint> The EPS instance number.
wtr Clear active WTR.
EXAMPLE
LPB3028A clear eps 2 wtr
LPB3028A
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
17
Page 18
CHAPTER 3: CLEAR OF CLI
3.5 ER PS
Ethernet Ring Protection Switching
Syntax
Clear erps 1 to 64 statistics
Clear erps statistics
Parameter
1 to 64 Zero or more ERPS group numbers
statistics Clear ERPS statistics
EXAMPLE
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
LPB3028A clear erps statistics
LPB3028A
3.6 IP
IP protocol
Syntax
clear ip acd [ | ( begin | exclude | include ) <line> ]
clear ip arp
clear ip dhcp detailed statistics { server | client | snooping | relay | helper | all } [ interface { [ * ] | GigabitEthernet | 10 GigabitEthernet }
< PORT_TYPE_LIST>]
clear ip dhcp relay statistics
clear ip dhcp server binding <ipv4_ucast>
clear ip dhcp server binding type [ automatic | manual | expired ]
clear ip dhcp server statistics
clear ip dhcp snooping statistics [ interface { [ * ] | GigabitEthernet | 10 GigabitEthernet } <
PORT_T YPE_LIST> ]
clear ip igmp snooping statistics
clear ip igmp snooping vlan <vlan_list> statistics
clear ip statistics
18
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 19
CHAPTER 3: CLEAR OF CLI
Parameter
acd Address Conflict Detection
arp Clear ARP cache
dhcp Dynamic Host Configuration Protocol
igmp Internet Group Management Protocol
statistics Traffic statistics
| Output modifiers
begin Begin with the line that matches
exclude Exclude lines that match
include Include lines that match
<line> String to match output lines
detailed Detailed statistics
relay DHCP relay agent configuration
server Miscellaneous DHCP server information
snooping DHCP snooping
all Clear all DHCP related statistics
client DHCP client
helper DHCP normal L2 or L3 forward
relay DHCP relay
server DHCP server
interface Select an interface to configure
<port_type_list> Port list for all port types
<port_type_list> Port list in 1/1-24
<port_type_list> Port list in 1/1-4
binding Clear DHCP binding
statistics DHCP server statistics
<ipv4_ucast> IP address of the binding
type Type of bindings to clear
automatic Clear (expire) automatic bindings
expired Clear (remove) expired bindings
manual Clear (expire) manual bindings
snooping Snooping IGMP
statistics Running IGMP snooping counters
vlan Search by VLAN
<vlan_list> VLAN identifier (VID)
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
19
Page 20
CHAPTER 3: CLEAR OF CLI
EXAMPLE
LPB3028A clear ip arp
LPB3028A
3.7 I PV6
IPv6 configuration commands
Syntax
clear ipv6 mld snooping [ vlan <v_vlan_list> ] statistics
clear ipv6 neighbors
clear ipv6 statistics
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
Parameter
mld Multicasat Listener Discovery
neighbors Ipv6 neighbors
statistics Traffic statistics
snooping Snooping MLD
statistics Running MLD snooping counters
vlan Ipv6 interface traffic
<vlan_list> VLAN identifier(s): VID
EXAMPLE
LPB3028A clear ipv6 mld snooping vlan 3 statistics
LPB3028A clear ipv6 neighbors
LPB3028A Clear ipv6 statistics
20
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 21
CHAPTER 3: CLEAR OF CLI
3.8 LACP
Clear LACP statistics
Syntax
Clear lacp statistics
Parameter
statistics Clear all LACP statistics
EXAMPLE
LPB3028A clear lacp statistics
LPB3028A
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
3.9 LINK-OAM
Clear Link OAM statistics
Syntax
Clear link-oam statistics
Clear link-oam statistics interface *
Clear link-oam statistics interface ( * | GigabitEthernet | 10GigabitEthernet ) <port_type_list>
Parameter
statistics Clear Rx/Tx counters
interface Clear Link OAM statistic on a specific interface or all interfaces.
* All switches or All ports
GigabitEthernet 1 Gigabit Ethernet Port
10GigabitEthernet 10 Gigabit Ethernet Port
<port_type_list> Port list for all port types
<port_type_list> Port list in 1/1-24
<port_type_list> Port list in 1/1-4
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
21
Page 22
CHAPTER 3: CLEAR OF CLI
EXAMPLE
LPB3028A clear link-oam statistics interface 10GigabitEthernet 1/1-3
LPB3028A
3.10 LLDP
Clear LLDP statistics
Syntax
Clear lldp statistic
Clear lldp statistic | [begin | exclude | include] <line>
Clear lldp statistics global
Clear lldp statistics global | [begin | exclude | include] <line>
Clear lldp statistics interface *
Clear lldp statistics interface * | [begin | exclude | include] <line>
Clear lldp statistics interface * <port_type_list>
Clear lldp statistics interface ( GigabitEthernet | 10GigabitEthernet ) <port_type_list>
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
Parameter
statistics Clear LLDP statistics
| Output modifiers
global Clear global counters
interface Interface keyword
begin Begin with the line that matches
exclude Exclude lines that match
include Include lines that match
<line> String to match output lines
* All switches or All ports
GigabitEthernet 1 Gigabit Ethernet Port
10GigabitEthernet 10 Gigabit Ethernet Port
<port_type_list> Port list for all port types
<port_type_list> Port list in 1/1-24
<port_type_list> Port list in 1/1-4
22
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 23
CHAPTER 3: CLEAR OF CLI
EXAMPLE
LPB3028A clear lldp statistics interface *
LPB3028A
3.11 LOGGING
System logging message.
Syntax
clear logging
clear logging [ error ] [informational ] [notice] [ warning ]
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
Parameter
error Severity 3: Error conditions
informational Severity 6: Informational messages
notice Severity 5: Normal but significant condition
warning Severity 4: Warning conditions
EXAMPLE
LPB3028A clear logging informational error warning
LPB3028A
3.12 M A C
MAC Address Table
Syntax
Clear mac address-table
Parameter
address-table Flush MAC Address table.
EXAMPLE
LPB3028A clear mac address-table
LPB3028A
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
23
Page 24
CHAPTER 3: CLEAR OF CLI
3.13 M EP
Maintenance Entity Point
Syntax
Clear mep <uint> ( dm | lb | tst )
Clear mep <uint> lm
Clear mep <uint> lm ( both | rx | tx )
Parameter
<uint> The MEP instance.
dm Clear DM measuring information.
lb Clear LB measuring information.
lm Clear LM measuring information.
tst Clear TST measuring information.
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
EXAMPLE
LPB3028A clear mep <uint> lm
LPB3028A
3.14 M V R
Multicast VLAN Registration configuration.
Syntax
clear mvr name <word16> statistics
clear mvr statistics
clear mvr vlan <vlan_list> statistics
Parameter
name MVR multicast name
statistics Running MVR protocol counters
vlan MVR multicast vlan
< word16> MVR multicast VLAN name
<vlan_list> MVR multicast VLAN list
24
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 25
CHAPTER 3: CLEAR OF CLI
EXAMPLE
LPB3028A clear mvr vlan 25 statistics
LPB3028A
3.15 PORT-SECURITY
Port security
Syntax
Clear port-security dynamic
Clear port-security dynamic address <mac_addr>
Clear port-security dynamic address <mac_addr> vlan <vlan_id>
Clear port-security dynamic interface *
Clear port-security dynamic interface * [ <port_type_list> | vlan <vlan_id>]
Clear port-security dynamic interface ( GigabitEthernet | 10GigabitEthernet ) <port_type_list>
Clear port-security dynamic vlan <vlan_id>
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
Parameter
dynamic Dynamic entries
address Clear a specific (VLAN, MAC) tuple
interface Port interface
vlan Delete all MAC addresses on a given VLAN
<mac_addr> MAC address to clear
vlan VLAN keyword
<vlan_id> VLAN on which to clear all MAC addresses
* All switches or All ports
GigabitEthernet 1 Gigabit Ethernet Port
10GigabitEthernet 10 Gigabit Ethernet Port
<port_type_list> Port list for all port types
<vlan_id> VLANs on interface to clear all MAC addresses for
<port_type_list> Port list in 1/1-24
<port_type_list> Port list in 1/1-4
EXAMPLE
LPB3028A clear port-security dynamic vlan 1
LPB3028A
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
25
Page 26
CHAPTER 3: CLEAR OF CLI
3.16 P T P
Syntax
clear ptp <0-3> servo
Parameter
<0-3>
servo
EXAMPLE
LPB3028A clear ptp 1 servo
LPB3028A
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
3.17 SFLOW
Statistics flow
Syntax
clear sflow statistics receiver
clear sflow statistics samplers
clear sflow statistics samplers interface *
clear sflow statistics samplers interface * <port_type_list>
clear sflow statistics samplers interface ( GigabitEthernet | 10GigabitEthernet ) <port_type_list>
Parameter
statistics sFlow statistics
receiver Clear statistics for receiver.
samplers Clear statistics for samplers
interface Clear statistics for a specific interface or interfaces
* All switches or All ports
GigabitEthernet 1 Gigabit Ethernet Port
10GigabitEthernet 10 Gigabit Ethernet Port
<port_type_list> Port list for all port types
<port_type_list> Port list in 1/1-24
<port_type_list> Port list in 1/1-4
26
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 27
CHAPTER 3: CLEAR OF CLI
EXAMPLE
LPB3028A clear sflow statistics interface
GigabitEthernet 1/1-24
3.18 SPANNING-TREE
STP Bridge
Syntax
clear spanning-tree detected-protocols
clear spanning-tree detected-protocols interface *
clear spanning-tree detected-protocols interface * <port_type_list>
clear spanning-tree detected-protocols interface ( GigabitEthernet | 10GigabitEthernet ) <port_type_list>
clear spanning-tree statistics
clear spanning-tree statistics interface *
clear spanning-tree statistics interface * <port_type_list>
clear spanning-tree statistics interface ( GigabitEthernet | 10GigabitEthernet ) <port_type_list>
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
Parameter
detected-protocols Set the STP migration check
statistics STP statistic
interface Choose port
* All switches or All ports
GigabitEthernet 1 Gigabit Ethernet Port
10GigabitEthernet 10 Gigabit Ethernet Port
<port_type_list> Port list for all port types
<port_type_list> Port list in 1/1-24
<port_type_list> Port list in 1/1-4
EXAMPLE
LPB3028A clear spanning-tree detected-protocols interface *
LPB3028A
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
27
Page 28
CHAPTER 3: CLEAR OF CLI
3.19 STAT ISTICS
Clear statistics for one or more given interfaces.
Syntax
clear statistics *
clear statistics * <port_type_list>
clear statistics ( GigabitEthernet | 10GigabitEthernet ) <port_type_list>
clear statistics interface *
clear statistics interface * <port_type_list>
clear statistics interface ( GigabitEthernet | 10GigabitEthernet ) <port_type_list>
Parameter
interface Interface
* All switches or All ports
GigabitEthernet 1 Gigabit Ethernet Port
10GigabitEthernet 10 Gigabit Ethernet Port
<port_type_list> Port list for all port types
<port_type_list> Port list in 1/1-24
<port_type_list> Port list in 1/1-4
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
EXAMPLE
LPB3028A clear statistics GigabitEthernet 1/1-24
LPB3028A
3.20 SYSTEM
system
Syntax
clear system led status ( all | fatal | software )
clear system led status ( all | fatal | software ) (| ( begin | exclude | include ) <line>)
28
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 29
CHAPTER 3: CLEAR OF CLI
Parameter
led led
status status
all Clear all error status of the system LED and back to normal indication
fatal Clear fatal error status of the system LED
software Clear generic software error status of the system LED
| Output modifiers
begin Begin with the line that matches
exclude Exclude lines that match
include Include lines that match
<line> String to match output lines
EXAMPLE
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
LPB3028A clear system led status software
LPB3028A
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
29
Page 30
CHAPTER 4: CONFIGURE COMMANDS OF CLI
4. CONFIGURE COMMANDS OF CLI
CONFIGURE COMMANDS TABLE
COMMAND FUNCTION
Ter min al Configure from the terminal
aaa Authentication, Authorization, and Accounting
access Access management
access-list Access list
aggregation Aggregation mode
banner Define a banner
clock Configure time-of-day clock
default Set a command to its defaults
dms Enable DMS Maste
do To run exec commands in the configuration mode
dot1x IEEE Standard for port-based Network Access Control
enable Modify enable password parameters
end Go back to EXEC mode
eps Ethernet Protection Switching
erps Ethernet Ring Protection Switching
event Trap event severity level
exit Exit from Configuration mode
green-ethernet Green ethernet (Power reduction)
gvrp Enable GVRP feature
help Description of the interactive help system
hostname Set system’s network name
interface Select an interface to configure
ip Interface Internet Protocol configuration commands
ipmc IPv4/IPv6 multicast configuration
ipv6 IPv6 configuration commands
json JavaScript Object Notation RPC
lacp LACP settings
line Configure a terminal line
lldp Link Layer Discover Protocol
logging System logging message
loop-protect Loop protection configuration
mac MAC table entries/configuration
mep Maintenance Entity Point
monitor Monitoring different system events
mvr Multicast VLAN Registration configuration
mvrp Enable MVRP feature globally
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
30
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 31
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CHAPTER 4: CONFIGURE COMMANDS OF CLI
CONFIGURE COMMANDS TABLE (CONTINUED)
COMMAND FUNCTION
no no
ntp Configure NTP
poe power over Ethernet
port-security This command is obsolete
Privilege Command privilege parameters
prompt Set prompt
ptp Precision time Protocol (1588)
qos Quality of Service
radius-server Configure RADIUS
rmon Remote Monitoring
router Routing process
sflow Statistics flow
smtp Set email information
snmp-server Set SNMP server’s configurations
spanning-tree Spanning Tree protocol
svl Shared VLAN Learning
switchport Set VL AN switching mode characteristics
system Set the SNMP server’s configurations
tacacs-server Configure TACACS+
udld Enable UDLD in the aggressive or normal mode and to set the configurable message timer on all fiber-optic ports
upnp Set UPnP’s configurations
username Establish User Name Authentication
vlan VLAN commands
voice Voice appliance attributes
web Web
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
31
Page 32
CHAPTER 4: CONFIGURE COMMANDS OF CLI
4.1 TERMINAL
Configure from the terminal
Syntax
configure terminal
Parameter
terminal Configure from the terminal
EXAMPLE
LPB3028A configure terminal
LPB3028A(config)#
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
4.1.1 A A A
Authentication, Authorization, and Accounting.
Syntax
aaa authentication login [ ssh | telnet | http | console ] [ local | radius | tacacs ]
aaa authorization ( console | ssh | telnet ) tacacs commands <0-15>
aaa authorization ( console | ssh | telnet ) tacacs commands <0-15> config-commands
aaa accounting ( Console | ssh | telnet ) tacacs exec
aaa accounting ( Console | ssh | telnet ) tacacs commands <0-15>
Parameter
authentication Authentication
authorization Authorization
accounting Accounting
login Login
http Configure HTTP authentication
ssh Configure SSH authentication
telnet Configure Telnet authentication
console Configure Console authentication
local Use local database for authentication
radius Use RADIUS for authentication
tacacs Use TACACS+ for authentication
console Configure Console command authorization
32
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 33
CHAPTER 4: CONFIGURE COMMANDS OF CLI
ssh Configure SSH command authorization
telnet Configure Telnet command authorization
tacacs Use TACACS+ for authorization
commands Enable command authorization
<0-15> Command privilege level. Commands equal and above this level are authorized
config-commands Include configuration commands
console Configure Console command accounting
ssh Configure SSH command accounting
telnet Configure Telnet command accounting
tacacs Use TACACS+ for accounting
commands Enable command accounting
exec Enable EXEC accounting
<0-15> Command privilege level. Commands equal and above this level are accounted
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
EXAMPLE
LPB3028A(config)# aaa authentication login http radius
LPB3028A(config)#
4.1.2 ACCESS
Access management
Syntax
access management <1..16>
access management <1..16> <1..4095> [ <ipv4_ucast> | <ipv6_ucast> ] { [ web ] [ snmp ] [ telnet ] | all }
access management <1..16> <1..4095> [ <ipv4_ucast> | <ipv6_ucast> ] { [ web ] | [ snmp ] | [ telnet ] | [all] }
access management <1..16> <1..4095> [ <ipv4_ucast> | <ipv6_ucast> ] to <ipv4_ucast>
Parameter
management Access management configuration
< 1-16> ID of access management entry
<1..4095> The VLAN ID for the access management entry
<ipv4_ucast> Start IPv4 unicast address
<ipv6_ucast> Start IPv6 unicast address
all All services
snmp SNMP service
telnet TELNET/SSH service
to End address of the range
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
33
Page 34
CHAPTER 4: CONFIGURE COMMANDS OF CLI
web Web service
<ipv4_ucast> End IPv4 unicast address
EXAMPLE
LPB3028A(config)# access management 10 3 192.168.1.1 all
LPB3028A(config)#
4.1.3 ACCESS-LIST
Access list
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
CONFIGURE – ACCESS-LIST COMMANDS TABLE
COMMAND FUNCTION
ace Access list entry
rate-limiter Rate limiter
4.1. 3.1 A C E
Access list entry
SY N TA X
access-list ace <1-512> action [ deny | permit ]
access-list ace <1-384> action { ( deny | permit ) [ dmac-type | frame-type | ingress | logging | mirror | next | policy | rate-limiter | redirect |
shutdown | tag | tag-priority | vid ] }
access-list ace <1-512> action filter interface ( * | GigabitEthernet | 10GigabitEthernet ) [ <port_type_list> | dmac-type | frame-type | ingress |
logging | mirror | next | policy | rate-limiter | redirect | shutdown | tag | tagpriority | vid ]
access-list ace <1-512> action ( deny | permit ) dmac-type ( any | broadcast | multicast | unicast ) [ frame-type | ingress | logging | mirror |
next | policy | rate-limiter | redirect | shutdown | tag | tag-priority | vid ]
access-list ace <1-512> action ( deny | permit ) frame-type { ( any [ dmac-type | ingress | logging | mirror | next | policy | rate-limiter | redirect |
shutdown | tag | tag-priority | vid ] ) }
access-list ace <1-512> action ( deny | permit ) frame-type { ( arp [ arp-flag | arp-opcode | dip | dmac-type | ingress | logging | mirror | next |
policy | rate-limiter | redirect | shutdown | sip | smac | tag | tag-priority | vid ] ) }
access-list ace <1-512> action ( deny | permit ) frame-type { ( etype [ dmac | dmac-type | etype-value | ingress | logging | mirror | next | policy
| rate-limiter | redirect | shutdown | smac | tag | tag-priority | vid ] ) }
access-list ace <1-512> action ( deny | permit ) frame-type { ( ipv4 [ dip | dmac-type | ingress | ip-flag | ipprotocol | logging | mirror | next |
policy | rate-limiter | redirect | shutdown | sip | tag | tag-priority | vid ] ) }
access-list ace <1-512> action ( deny | permit ) frame-type { ( ipv4-icmp [ dip | dmac-type | icmp-code | icmptype | ingress | ip-flag | ipprotocol | logging | mirror | next | policy | rate-limiter | redirect | shutdown | sip | tag | tag-priority | vid ] ) }
34
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 35
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CHAPTER 4: CONFIGURE COMMANDS OF CLI
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
access-list ace <1-512> action ( deny | permit ) frame-type { ( ipv4-tcp | ipv4-udp ) [ dip | dmac-type | dport | ingress | ip-flag | logging | mirror
| next | policy | rate-limiter | redirect | shutdown | sip | sport | tag | tag-priority | vid ] ) }
access-list ace <1-512> action ( deny | permit ) frame-type { ( ipv6 | ipv6-udp ) [ dmac-type | hop-limit | ingress | logging | mirror | next | policy
| rate-limiter | redirect | shutdown | sip | tag | tag-priority | vid ] ) }
access-list ace <1-512> action ( deny | permit ) frame-type { ( ipv6-icmp [ dip | dmac-type | icmp-code | icmptype | ingress | logging | mirror |
next | policy | rate-limiter | redirect | shutdown | sip | tag | tag-priority | vid ] ) }
access-list ace <1-512> action ( deny | permit ) frame-type { ( ipv6-tcp [ dmac-type | dport | hop-limit | ingress | logging | mirror | next | policy |
rate-limiter | redirect | shutdown | sip | sport | tag | tag-priority | tcp-flag | vid ] ) }
access-list ace <1-512> action ( deny | permit ) ingress{ ( any [ dmac-type | frame-type | logging | mirror | next | policy | rate-limiter | redirect |
shutdown | tag | tag-priority | vid ] ) | { interface ( * | GigabitEthernet | 10GigabitEthernet ) [ <port_type_list> | dmac-type | frame-type | ingress
| logging | mirror | next | policy | ratelimiter | redirect | shutdown | tag | tag-priority | vid ] }
access-list ace <1-512> action ( deny | permit ) logging [ disable | dmac-type | frame-type | ingress | mirror | next | policy | rate-limiter |
redirect | shutdown | tag | tag-priority | vid ]
access-list ace <1-512> action ( deny | permit ) mirror [ disable | dmac-type | frame-type | ingress | logging | next | policy | rate-limiter |
redirect | shutdown | tag | tag-priority | vid ]
access-list ace <1-512> action ( deny | permit ) next ( <1-512> | last ) [ dmac-type | frame-type | ingress | logging | mirror | policy | rate-limiter |
redirect | shutdown | tag | tag-priority | vid ]
access-list ace <1-512> action ( deny | permit ) policy <0-127> [ dmac-type | frame-type | ingress | logging | mirror | next | policy-bitmask |
rate-limiter | redirect | shutdown | tag | tag-priority | vid ]
access-list ace <1-512> action ( deny | permit ) rate-limiter ( <1-16> | disable ) [ dmac-type | frame-type |
ingress | logging | mirror | next | policy | redirect | shutdown | tag | tag-priority | vid ]
access-list ace <1-512> action ( deny | permit ) redirect { ( disable [ dmac-type | frame-type | ingress | logging | mirror | next | policy |
rate=limiter| shutdown | tag | tag-priority | vid ] ) } | { interface ( * | GigabitEthernet | 10GigabitEthernet ) [ <port_type_list> | dmac-type |
frame-type | ingress | logging | mirror | next | policy | ratelimiter | shutdown | tag | tag-priority | vid ] }
access-list ace <1-512> action ( deny | permit ) shutdown [ disable | dmac-type | frame-type | ingress | logging | mirror | next | policy | ratelimiter | redirect | tag | tag-priority | vid ]
access-list ace <1-512> action ( deny | permit ) tag ( any | tagged | untagged ) [ dmac-type | frame-type | ingress | logging | mirror | next |
policy | rate-limiter | redirect | shutdown | tag-priority | vid ]
access-list ace <1-512> action ( deny | permit ) tag-priority ( 0-1 | 0-3 | 2-3 | 4-5 | 4-7 | 6-7 | <0-7> | any )
[ dmac-type | frame-type | ingress | logging | mirror | next | policy | rate-limiter | redirect | shutdown | tag | vid ]
access-list ace <1-512> action ( deny | permit ) vid ( <1-4095> | any ) [ dmac-type | frame-type | ingress | logging | mirror | next | policy | ratelimiter | redirect | shutdown | tag | tag-priority ]
access-list ace update <1-512> [ action | dmac-type | frame-type | ingress | logging | mirror | next | policy | ratelimiter | redirect | shutdown |
tag | tag-priority | vid ]
Parameter
<1-512> ACE ID
update Update an existing ACE
action Access list action
dmac-type The type of destination MAC address
frame-type Frame type
ingress Ingress
logging Logging frame information. NOTE: The logging feature only works when the packet length is less than 1518
(without VLAN tags) and the System Log memory size and logging rate are limited.
mirror Mirror frame to destination mirror port
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
35
Page 36
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CHAPTER 4: CONFIGURE COMMANDS OF CLI
next insert the current ACE before the next ACE ID
policy Policy
rate-limiter Rate limiter
redirect Redirect frame to specific port
shutdown Shutdown incoming port. The shutdown feature only works when the packet length is less than 1518 (without
VLAN tags).
tag Tag
tag-priority Tag priority
vid VID field
deny Deny
filter Filter
permit Permit
interface Select an interface to configure
* All switches or All ports
GigabitEthernet Gigabit Ethernet Ports
10GigabitEthernet 10Gigabit Ethernet Ports
<port_type_list> Port list for all port types
<port_type_list> Port list in 1/1-24
<port_type_list> Port list in 1/1-4
any Don’t-care the type of destination MAC address
broadcast Broadcast destination MAC address
multicast Multicast destination MAC address
unicast Unicast destination MAC address
any Don’t-care the frame type
arp Frame type of ARP
etype Frame type of EtherType
ipv4 Frame type of IPv4
ipv4-icmp Frame type of IPv4 ICMP
ipv4-tcp Frame type of IPv4 TCP
ipv4-udp Frame type of IPv4 TCP
ipv6 Frame type of IPv6
ipv6-icmp Frame type of IPv6 ICMP
ipv6-tcp Frame type of IPv6 TCP
ipv6-udp Frame type of IPv6 UDP
arp-flag ARP flag
arp-opcode ARP/RARP opcode field
dip Destination IP address field
sip Source IP address field
smac Source MAC address field
dmac Destination MAC address field
dmac-type The type of destination MAC address
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
36
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 37
CHAPTER 4: CONFIGURE COMMANDS OF CLI
etype-value Ether type value
ip-flag IP flag
ip-protocol IPv4 protocol field
icmp-code ICMP code field
icmp-type ICMP type field
dport TCP/UDP destination port field
sport TCP/UDP source port field
tcp-flag TCP flag
hop-limit IPv6 hop limiter field
disable Disable logging
<1-512> The next ID
last Place the current ACE to the end of access list
<0-127> Policy ID
policy-bitmask The bitmask for policy ID
<1-16> Rate limiter ID
disable Disable rate-limiter
disable Disable
any Don’t-care tagged or untagged
tagged Tagged
untagged Untagged
0-1 The range of tag priority
0-3 The range of tag priority
2-3 The range of tag priority
4-5 The range of tag priority
4-7 The range of tag priority
6-7 The range of tag priority
<0-7> The value of tag priority
any Don’t-care the value of tag priority field
<1-4095> The value of VID field
any Don’t-care the value of VID field
<0-7> The value of tag priority
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
EXAMPLE
LPB3028A(config)# access-list ace 10 action deny
LPB3028A(config)#
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
37
Page 38
CHAPTER 4: CONFIGURE COMMANDS OF CLI
4.1.3.2 RATE-LIMITER
Rate limiter
SY N TA X
access-list rate-limiter ( 10pps <0-500000> ) | ( 25kbps <0-400000> ) | <1-16> (10pps <0-500000> | 25kbps <0-400000>)
Parameter
10pps 10 packets per second
25kbps 25k bits per second
<1-16> Rate limiter ID
<0-500000> Rate value
<0-400000> Rate value
<0-7> The value of tag priority
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
EXAMPLE
LPB3028A(config)# aaccess-list rate-limiter 25kbps 0
LPB3028A(config)#
4.1.4 AGGREGATION
Aggregation mode
SY N TA X
aggregation mode [ dmac | ip | port | smac ]
Parameter
mode Traffic distribution mode
dmac Destination MAC affects the distribution
ip IP address affects the distribution
port IP port affects the distribution
smac Source MAC affects the distribution
38
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 39
CHAPTER 4: CONFIGURE COMMANDS OF CLI
EXAMPLE
LPB3028A(config)# aggregation mode dmac
LPB3028A(config)#
4.1.5 BANNER
Define a banner
SY N TA X
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
banner [ <LINE> ]
banner ( exec | login | motd ) <LINE>
Parameter
<LINE> c banner-text c, where ‘c’ is a delimiting character
exec S et EXEC process creation banner
login Set login banner
motd Set Message of the Day banner
EXAMPLE
LPB3028A(config)# banner exec LINE
Enter TEXT message. End with the character ‘L’.
L
LPB3028A(config)#
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
39
Page 40
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CHAPTER 4: CONFIGURE COMMANDS OF CLI
4.1.6 CLOCK
Configure time-of-day clock
SY N TA X
clock summer-time <word16> date ( [ <1-12> ] ) | ( <1-12> <1-31> <2000-2097> <hhmm> <1-12> <1-31> <2000-2097> <hhmm> [ <1-1439> ] )
clock summer-time <word16> recurring ( [ <1-5> ] ) | (<1-5> <1-7> <1-12> <hhmm> <1-5> <1-7> <1-12> <hhmm> [ <1-1439> ] )
clock timezone <word16> <-23-23> [ <0-59> <0-9> ]
Parameter
summer-time Configure summer (daylight savings) time
timezone Configure time zone
<word16> name of time zone in summer (the string ‘’ is a special syntax that is reserved for null input)
date Configure absolute summer time
recurring Configure recurring summer time
<1-12> Month to start
<1-31> Date to start
<2000-2097> Year to start
<hhmm> Time to start (hh:mm)
<1-12> Month to end
<1-31> Date to end
<2000-2097> Year to end
<hhmm> Time to end (hh:mm)
<1-1439> Offset to add in minutes
<1-5> Week number to start
<1-7> Weekday to start
<-23-23> Hours offset from UTC
<0-59> Minutes offset from UTC
<0-9> Sub type of time zone
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
EXAMPLE
LPB3028A(config)# clock clock timezone taipei 8
LPB3028A(config)#
40
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 41
CHAPTER 4: CONFIGURE COMMANDS OF CLI
4.1.7 DEFAULT
Set a command to its defaults.
SY N TA X
default access-list rate-limiter [ <1-16> ]
Parameter
access-list Access list
rate-limiter Rate limiter
<1-16> Rate limiter ID
EXAMPLE
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
LPB3028A(config)# default access-list rate-limiter 3
LPB3028A(config)#
4.1.8 D MS
Enable DMS Maste
SY N TA X
dms
dms mode [ disabled | enabled | high-priority ]
Parameter
mode DMS mode
disabled DMS mode is disabled
enabled DMS mode is enabled
high-priority DMS mode is high priority
EXAMPLE
LPB3028A(config)# dms mode high-priority
LPB3028A(config)#
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
41
Page 42
CHAPTER 4: CONFIGURE COMMANDS OF CLI
4.1.9 DO
To run exec commands in the configuration mode
SY N TA X
do < LINE > [ < LINE > ]
Parameter
<line> Exec Command
EXAMPLE
LPB3028A(config)# do clear statistics interface GigabitEthernet 1/1-1
LPB3028A(config)#
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
4.1.10 DO T 1X
IEEE Standard for port-based Network Access Control.
SY N TA X
dot1x authentication timer re-authenticate <1-3600>
dot1x authentication timer inactivity <10-1000000>
dot1x feature { [ guest-vlan ] [ radius-qos ] [ radius-vlan ] }
dot1x guest-vlan [ <1-4095> | supplicant ]
dot1x max-reauth-req <1-255>
dot1x re-authentication
dot1x system-auth-control
dot1x timeout ( tx-period <1-65535> ) | ( quiet-period <10-1000000> )
Parameter
authentication Authentication
feature Globally enables/disables a dot1x feature functionality
guest-vlan Guest VLAN
max-reauth-req The number of times a Request Identity EAPOL frame is sent without response before considering entering the
Guest VLAN
re-authentication Set Re-authentication state
system-auth-control Set the global NAS state
timeout timeout
42
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 43
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CHAPTER 4: CONFIGURE COMMANDS OF CLI
timer timer
inactivity Time in seconds between check for activity on successfully authenticated MAC addresses.
re-authenticate The period between re-authentication attempts in seconds
<10-1000000> seconds
<1-3600> seconds
guest-vlan Globally enables/disables state of guest-vlan
radius-qos Globally enables/disables state of RADIUS-assigned QoS.
radius-vlan G lobally enables/disables state of RADIUS-assigned VLAN.
<1-4095> Guest VLAN ID used when entering the Guest VLAN
supplicant The switch remembers if an EAPOL frame has been received on the port for the lifetime of the port. Once the switch
considers whether to enter the Guest VLAN, it will first check if this option is enabled or disabled. If disabled (unchecked,
default), the switch will only enter the Guest VLAN if an EAPOL frame has not been received on the port for the life-time
of the port. If enabled (checked), the switch will consider entering the Guest VLAN even if an EAPOL frame has been
received on the port for the lifetime of the port.
<1-255> number of times
quiet-period Time in seconds before a MAC-address that failed authentication gets a new authentication chance.
tx-period the time between EAPOL retransmissions.
<1-65535> seconds
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
EXAMPLE
LPB3028A(config)# dot1x authentication timer re-authenticate 1000
LPB3028A(config)#
4.1.11 E NA BL E
Modify enable password parameters.
SY N TA X
enable password ( level <1-15> <word32> ) | ( <word32> )
enable secret ( 0 | 5 ) ( level <1-15> <word32> ) | ( <word32> )
Parameter
password Assign the privileged level clear password
secret Assign the privileged level secret
<word32> The UNENCRYPTED (clear-text) password
level Set exec level password
<1-15> Level number
0 Specifies an UNENCRYPTED password will follow
5 Specifies an ENCRYPTED secret will follow
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
43
Page 44
CHAPTER 4: CONFIGURE COMMANDS OF CLI
EXAMPLE
LPB3028A(config)# enable password level 10 999
LPB3028A(config)#
4.1.12 E ND
Go back to EXEC mode.
Syntax
end
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
Example
LPB3028A (config)# end
LPB3028A
4.1.13 E PS
Ethernet Protection Switching
SY N TA X
eps <1-100> 1plus1 ( [ bidirectional ] ) | ( [ unidirectional ] aps )
eps <1-100> command [ exercise | forced | freeze | lockout | lockoutlocal | manualp | manual ]
eps <1-100> domain ( port | pw ) architecture ( 1for1 | 1plus1 ) work-flow { (GigabitEthernet |
10GigabitEthernet ) <port_type_id> } | ( <unit> protect-flow ) [ GigabitEthernet | 10GigabitEthernet | <uint> ]
eps <1-100> holdoff <uint>
eps <1-100> mep-work <uint> mep-protect <uint> mep-aps <uint>
eps <1-100> revertive ( [ 10m | 10s | 11m | 12m | 30s | 5m | 6m | 7m | 8m | 9m ] ) | wtr-value <uint>
Parameter
<1-100> The EPS instance number
1plus1 EPS 1+1 architecture
command EPS command
44
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 45
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CHAPTER 4: CONFIGURE COMMANDS OF CLI
domain The domain of the EPS.
holdoff Hold off timer.
mep-work Working MEP instance.
revertive Revertive EPS.
bidirectional EPS 1+1 bidirectional protection type.
unidirectional EPS 1+1 unidirectional protection type
aps EPS 1+1 unidirectional with APS protection type.
exercise Exercise of the protocol - not traffic effecting. This is only allowed in case of ‘Bidirectional’ protection type
forced Force switch normal traffic to protection.
freeze Local Freeze of EPS.
lockout Lockout of protection.
lockoutlocal Local lockout of EPS.
manualp Manual switch normal traffic to protection.
manualw Manual switch normal traffic to working. This is only allowed in case of ‘non-revertive’ mode.
port This EPS is protecting in the Port domain.
pw This EPS is protecting in the MPLS-TP Pseudo-Wire domain.
tunnel-tp This EPS is protecting in the MPLS-TP tunnel domain.
architecture The EPS architecture.
1for1 The architecture is 1 for 1.
1plus1 The architecture is 1 plus 1.
work-flow The working flow instance that the EPS is related to.
GigabitEthernet Gigabit Ethernet Ports
10GigabitEthernet 10Gigabit Ethernet Ports
<uint> The working flow instance number when not in the port domain.
<port_type_list> Port list in 1/1-24
<port_type_list> Port list in 1/1-4
protect-flow The protecting flow instance that the EPS is related to.
<uint> The hold off timer value in 100 ms. Max 10 sec.
<uint> Working MEP instance number.
mep-protect Protecting MEP instance.
<uint> Protecting MEP instance number.
mep-aps APS MEP instance.
<uint> APS MEP instance number
10m WTR is 10 min.
10s WTR is 10 sec.
11m WTR is 11 min.
12m WTR is 12 min.
30s WTR is 30 sec.
5m WTR is 5 min.
6m WTR is 6 min.
7m WTR is 7 min.
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
45
Page 46
CHAPTER 4: CONFIGURE COMMANDS OF CLI
8m WTR is 8 min.
9m WTR is 9 min.
wtr-value WTR as value.
<uint> The WTR value in seconds. Range is 1 to 720 seconds.
EXAMPLE
LPB3028A(config)# eps 1 revertive wtr-value 1
LPB3028A(config)#
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
4.1.14 ER PS
Ethernet Ring Protection Switching
SY N TA X
erps 1-64 guard 10-2000
erps 1-64 holdoff 0-10000
erps 1-64 major port0 interface (GigabitEthernet | 10GigabitEthernet) <port_type_id> port1 interface (GigabitEthernet | 10GigabitEthernet)
<port_type_id> [ interconnect ]
erps 1-64 mep port0 sf <1-3124> aps <1-3124> port1 sf <1-3124> aps <1-3124>
erps 1-64 revertive 1-12
erps 1-64 rpl ( neighbor | owner ) [ port0 | port1 ]
erps 1-64 sub port0 interface ( GigabitEthernet | 10GigabitEthernet ) <port_type_id> ( interconnect 1-64 [ virtual-channel ] ) | port1 interface
( GigabitEthernet | 10GigabitEthernet ) <port_type_id> [ virtual-channel ]
erps 1-64 topology-change propagate
erps 1-64 version [ 1 | 2 ]
erps 1-64 vlan { ( add | remove ) <vlan_list> } | { [ <vlan_list> | none ] }
Parameter
1-64 ERPS group number
guard Guard
holdoff Hold-off time
major Major ring
mep MEP
revertive Revertive
rpl Ring Protection Link
sub Sub-ring
topology-change Topology Change
46
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 47
CHAPTER 4: CONFIGURE COMMANDS OF CLI
version Version
vlan VLAN
10-2000 Guard time in ms
0-10000 Hold-off time in ms
port0 ERPS Port 0 interface
interface Select an interface to configure
GigabitEthernet Gigabit Ethernet Ports
10GigabitEthernet 10Gigabit Ethernet Ports
<port_type_list> Port list in 1/1-24
<port_type_list> Port list in 1/1-4
port1 ERPS Port 1 interface
interconnect Major ring is interconnected
sf Signal Fail
<1-3124> Index of Port 0 SignalFail MEP
aps Automatic Protection Switching
<1-3124> Index of Port 0 APS MEP
port1 ERPS Port 1 interface
<1-3124> Index of Port 1 SignalFail MEP
<1-3124> Index of Port 1 APS MEP
1-12 Wait-to-restore time in minutes
neighbor Neighbor role
owner Owner role
1-64 Major ring group number
virtual-channel Enable virtual channel for sub-ring
propagate Propagate
1 E RPS version 1
2 ERPS version 2
<vlan_list> List of VLANs
add Add to set of included VLANs
none Do not include any VLANs
remove Remove from set of included VLANs
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
EXAMPLE
LPB3028A(config)# erps 1 rpl neighbor port0
LPB3028A(config)#
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
47
Page 48
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CHAPTER 4: CONFIGURE COMMANDS OF CLI
4.1.15 E VE NT
Trap event severity level
SY N TA X
event group [ aclaccess-mgmt | arp-inspection | auth-failed | bsc-protection | cold-start | dhcp | dhcp-snooping | ip-source-guard | lacp | linkupdown | login | logout | loop-protection | mac-table | maintenance | mgmt-ipchange | nas | port | port-security | rmon | sfp | spanning-tree |
system | user | warm-start ] { [ level < 0-7 > ] | { syslog [ enable | disable ] } | { trap [ enable | disable ] } | { smtp [ enable | disable ] }}
event group [ acl | aclaccess-mgmt | arp-inspection | auth-failed | bsc-protection | cold-start | dhcp | dhcpsnooping | ip-source-guard | lacp
| link-updown | login | logout | loop-protection | mac-table | maintenance | mgmt-ip-change | nas | port | port-security | rmon | sfp | spanningtree | system | user | warm-start ] [ level | syslog | trap | smtp ]
event group [ acl | aclaccess-mgmt | arp-inspection | auth-failed | bsc-protection | cold-start | dhcp | dhcpsnooping | ip-source-guard | lacp
| link-updown | login | logout | loop-protection | mac-table | maintenance | mgmt-ip-change | nas | port | port-security | rmon | sfp | spanningtree | system | user | warm-start ] [ level | syslog | trap ] < 0-7 > { syslog [ enable | disable ] [ trap ] } | { trap [ enable | disable ] [ syslog ] }
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
Parameter
group Trap Event group name
acl Group ID ACL
access-mgmt Group ID ACCESS-MGMT
arp-inspection Group ID ARP-INSPECTION
auth-failed Group ID AUTH-FAILED
bsc-protection Group ID BCS-PROTECTION
cold-start Group ID COLD-START
dhcp Group ID DHCP
dhcp-snooping Group ID DHCP-SNOOPING
ip-source-guard Group ID IP-SOURCE-GUARD
lacp Group ID LACP
link-updown Group ID LINK-UPDOWN
login Group ID LOGIN
logout Group ID LOGOUT
loop-protection Group ID LOOP-PROTECTION
mac-table Group ID MAC-TABLE
maintenance Group ID MAINTENANCE
mgmt-ip-change Group ID MGMT-IP-CHANGE
nas Group ID NAS
port Group ID PORT
port-security Group ID PORT-SECURITY
rmon Group ID RMON
sfp Group ID SFP
spanning-tree Group ID SPANNING-TREE
system Group ID SYSTEM
user Group ID USER
48
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 49
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CHAPTER 4: CONFIGURE COMMANDS OF CLI
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
warm-start Group ID WARM-START
level event group level
smtp smtp mode
syslog syslog mode
trap trap mode
<0-7> <0> Emergency ,<1> Alert ,<2> Critical ,<3> Error ,<4> Warning ,<5> Notice ,<6> Informationl ,<7> Debug (0..7)
enable syslog mode enable
disable syslog mode disable
enable trap mode enable
disable trap mode disable
disable smtp mode disable
enable smtp mode enable
EXAMPLE
LPB3028A(config) # event group lacp trap enable
LPB3028A(config) #
4.1.16 GREEN-ETHERNET
Green ethernet (Power reduction)
SY N TA X
green-ethernet eee optimize-for-power
Parameter
eee Powering down of PHYs when there is no traffic.
optimize-for-power Set if EEE shall be optimized for least power consumption (else optimized for least traffic latency).
EXAMPLE
LPB3028A(config)# green-ethernet eee optimize-for-power
LPB3028A(config)#
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
49
Page 50
CHAPTER 4: CONFIGURE COMMANDS OF CLI
4.1.17 G VRP
Enable GVRP feature
SY N TA X
gvrp
gvrp max-vlans <1-4094>
gvrp time [ join-time <1-20> ] [ leave-time <60-300> ] [ leave-all-time <1000-5000> ]
Parameter
max-vlans Number of simultaneously VLANs that GVRP can control
time Configure GARP protocol timer parameters. IEEE 802.1D-2004, clause 12.11.
<1-4094>
join-time Set GARP protocol parameter JoinTime.
leave-all-time Set GARP protocol parameter LeaveAllTime.
leave-time Set GARP protocol parameter LeaveTime.
<1-20> join-time in units of centiseconds. Range is 1-20. Default is 20.
<1000-5000> leave-all-time in units of centiseconds Range is 1000-5000. Default is 1000.
<60-300> leave-time in units of centiseconds. Range is 60-300. Default is 60.
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
EXAMPLE
LPB3028A(config)# gvrp max-vlans 333
LPB3028A(config)# gvrp time join-time 13 leave-all-time 3000 leave-time 200
LPB3028A(config)#
4.1.18 HE LP
Description of the interactive help system.
SY N TA X
help
Parameter
none
50
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 51
CHAPTER 4: CONFIGURE COMMANDS OF CLI
EXAMPLE
LPB3028A(config)# help
Help may be requested at any point in a command by entering a question mark
‘?’. If nothing matches, the help list will be empty and you must backup until
entering a ‘?’ shows the available options.
Two styles of help are provided:
1. Full help is available when you are ready to enter a command argument (e.g.
‘show ?’) and describes each possible argument.
2. Partial help is provided when an abbreviated argument is entered and you
want to know what arguments match the input(e.g. ‘show pr?’.)
LPB3028A(config)#
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
4.1.19 H OS T NA M E
Set system’s network name.
SY N TA X
hostname <hostname>
Parameter
<host_name> This system’s network name.
EXAMPLE
LPB3028A(config)# hostname abc
abc(config)#
4.1.20 INTERFACE
Select an interface to configure.
SY N TA X
interface { * [ <port_type_list> ] } | { ( GigabitEthernet | 10GigabitEthernet ) <port_type_list> { [ * | GigabitEthernet | 10GigabitEthernet ] }
[ <port_type_list> ] }
interface llag 1-26
interface vlan <vlan_list>
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
51
Page 52
CHAPTER 4: CONFIGURE COMMANDS OF CLI
Parameter
* All switches or All ports
GigabitEthernet Gigabit Ethernet Ports
10GigabitEthernet 10Gigabit Ethernet Ports
llag Local link aggregation interface configuration
vlan VLAN interface configurations
<port_type_list> Port list for all port types
<port_type_list> Port list in 1/1-24
<port_type_list> Port list in 1/1-4
1-26 ID of LLAG interface
<vlan_list> List of VLAN interface numbers
EXAMPLE
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
LPB3028A(config)# interface GigabitEthernet 1/1-24
LPB3028A(config-if)#
LPB3028A(config-if)# interface vlan 3
LPB3028A(config-if-vlan)#
4.1. 21 I P
Interface Internet Protocol configuration commands
SY N TA X
ip arp inspection
ip arp inspection entry interface ( GigabitEthernet | 10GigabitEthernet ) <port_type_id> <vlan_id> <mac_ucast> <ipv4_ucast>
ip arp inspection translate [ interface ( GigabitEthernet | 10GigabitEthernet ) <port_type_id> <vlan_id> <mac_ucast> <ipv4_ucast> ]
ip arp inspection vlan <vlan_list> [ logging ( all | deny | permit) ]
ip dhcp excluded-address <ipv4_addr> [ <ipv4_addr> ]
ip dhcp pool <word32>
ip dhcp relay information [ option ]
ip dhcp relay information policy ( drop | keep | replace )
ip dhcp server
ip dhcp snooping
ip dns proxy
ip domain name <domain_name> | dhcp [ ipv4 | ipv6 ] [ interface vlan <vlan_id> ]
ip helper-address <ipv4_ucast>
ip http ( secure-certificate [ delete | generate | upload <url_file> ] ) | [ secure-redirect | secure-server ]
ip igmp host-proxy [ leave-proxy ]
52
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 53
CHAPTER 4: CONFIGURE COMMANDS OF CLI
ip igmp snooping [ vlan <vlan_list> ]
ip igmp ssm-range <ipv4_mcast>
ip igmp unknown-flooding
ip name-server <0-3> [ <ipv4_ucast> | <ipv6_ucast> | dhcp ( interface | ipv4 | ipv6 ) vlan <vlan_id> [ ipv4 | ipv6 ] ]
ip route <ipv4_addr> <ipv4_netmask> <ipv4_ucast> [ <1-255> ]
ip source binding interface ( GigabitEthernet | 10GigabitEthernet ) <port_type_id> <vlan_id> <ipv4_ucast> <mac_ucast>
ip ssh
ip verify source [ translate ]
Parameter
arp Address Resolution Protocol
dhcp Configure DHCP server parameters
dns Domain Name System
domain IP DNS Resolver
helper-address DHCP helper server address
http Hypertext Transfer Protocol
igmp Internet Group Management Protocol
name-server Domain Name System
route Add IP route
routing Enable routing for IPv4 and IPv6
source source command
ssh Secure Shell
verify verify command
inspection ARP inspection
entry ARP inspection entry
translate ARP inspection translate all entries
vlan ARP inspection vlan setting
interface Select an interface to configure
GigabitEthernet Gigabit Ethernet Ports
10GigabitEthernet 10Gigabit Ethernet Ports
<port_type_list> Port list in 1/1-24
<port_type_list> Port list in 1/1-4
<vlan_id> Select a VLAN id to configure
<mac_ucast> Select a MAC address to configure
<ipv4_ucast> Select an IP Address to configure
<vlan_list> arp inspection vlan list
logging A RP inspection vlan logging mode configuration
all log all entries
deny log denied entries
permit log permitted entries
excluded-address Prevent DHCP from assigning certain addresses
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
53
Page 54
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CHAPTER 4: CONFIGURE COMMANDS OF CLI
pool Configure DHCP address pools
relay DHCP relay agent configuration
server Enable DHCP server
snooping DHCP snooping
<ipv4_addr> Low IP address
<ipv4_addr> High IP address
<word32> Pool name in 32 characters
Information DHCP information option (Option 82)
option DHCP option
policy Policy for handling the receiving DHCP packet already include the information option
drop Drop the package when receive a DHCP message that already contains relay information
keep Keep the original relay information when receive a DHCP message that already contains it
replace Replace the original relay information when receive a DHCP
proxy DNS proxy service
name Define the default domain name
<domain_name> Default domain name
dhcp Dynamic Host Configuration Protocol
Interface Select an interface to configure
ipv4 DNS setting is derived from DHCPv4
ipv6 DNS setting is derived from DHCPv6; Default selection
<ipv4_ucast> IP address of the DHCP relay server
secure-certificate HTTPS certificate
secure-redirect Secure HTTP web redirection
secure-server Secure HTTP web server
delete Delete the current certificate
generate Generate a new self-signed RSA certificate
upload Upload a certificate PEM file
<url_file> Uniform Resource Locator. It is a specific character string that constitutes a reference to a resource. Syntax
<protocol> ://[<username>[:<password>]@] <host>[:<port>][/<path>]/<file_name> If the following special
characters: space !”#$%&’()*+,/:;<=>?@[\]^`{|}~ need to be contained in the input URL string, they should be
percent-encoded. A valid file name is a text string drawn from alphabet (A-Za-z), digits (0-9), dot (.), hyphen (-),
under score (_). The maximum length is 63 and hyphen must not be first character. The file name content that
only contains ‘.’ is not allowed.
host-proxy IGMP proxy configuration
snooping Snooping IGMP
ssm-range IPv4 address range of Source Specific Multicast
unknown-flooding Flooding unregistered IPv4 multicast traffic
leave-proxy IGMP proxy for leave configuration
vlan IGMP VLAN
<vlan_list> VLAN identifier (VID)
<ipv4_mcast> Valid IPv4 multicast address
<0-3> Preference of DNS server. Default selection is 0
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
54
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 55
CHAPTER 4: CONFIGURE COMMANDS OF CLI
<ipv4_ucast> A valid IPv4 unicast address
<ipv6_ucast> A valid IPv6 unicast address
dhcp Dynamic Host Configuration Protocol
<ipv4_addr> Network
<ipv4_netmask> Netmask
<ipv4_ucast> Gateway
<1-255> Distance value for this route
<mac_ucast> Select a MAC address to configure
source verify source
translate IP verify source translate all entries
EXAMPLE
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
LPB3028A(config)# ip arp inspection
LPB3028A(config)#
4.1. 2 2 I PMC
IPv4/IPv6 multicast configuration.
SY N TA X
ipmc profile <word16>
ipmc range <word16> [ <ipv4_mcast> | <ipv6_mcast> ]
Parameter
profile IPMC profile configuration
range A range of IPv4/IPv6 multicast addresses for the profile
<word16> Profile name in 16 characters
<word16> Range entry name in 16 characters
<ipv4_mcast> V alid IPv4 multicast address
<ipv6_mcast> Valid IPv6 multicast address
EXAMPLE
LPB3028A(config)# ipmc profile test
LPB3028A(config-ipmc-profile)#
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
55
Page 56
CHAPTER 4: CONFIGURE COMMANDS OF CLI
4.1. 2 3 I PV6
IPv6 configuration commands
SY N TA X
ipv6 mld host-proxy [ leave-proxy ]
ipv6 mld snooping [ vlan <vlan_list> ]
ipv6 mld ssm-range <ipv6_mcast>
ipv6 mld unknown-flooding
Parameter
mld Multicast Listener Discovery
route Configure static routes
host-proxy MLD proxy configuration
snooping Snooping MLD
ssm-range IPv6 address range of Source Specific Multicast
unknown-flooding Flooding unregistered IPv6 multicast traffic
leave-proxy MLD proxy for leave configuration
vlan MLD VLAN
<vlan_list> VLAN identifier (VID)
<ipv6_subnet> IPv6 prefix x:x::y/z
<ipv6_mcast> Valid IPv6 multicast address
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
EXAMPLE
LPB3028A(config)# ipv6 mld host-proxy
LPB3028A(config)# ipv6 mld snooping
LPB3028A(config)#
4.1.24 JSON
JavaScript Object Notation RPC
SY N TA X
json notification host <word32>
json notification listen <cword>
56
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 57
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CHAPTER 4: CONFIGURE COMMANDS OF CLI
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
Parameter
notification Notification request object
host Notification host
listen JSON-RPC notification event subscription
<word32> Name of Notification host
<cword> Valid words are ‘acl.status.ace.crossedThreshold.update’ ‘aggregation.status.notification.update’
‘alarm.status.update’ ‘arpInspection.status.crossedThreshold.update’ ‘ddmi.status.interface.
crossedThreshold.update’ ‘ethernetLinkOam.statistics.interface.criticalLinkEvent.update’ ‘ip.status.
acd.ipv4.update’ ‘ip.status.interface.dhcpClient.update’ ‘ip.status.interface.ipv4.update’ ‘ip.status.
interface.ipv6.update’ ‘ip.status.interface.link.update’ ‘ip.status.route.ipv4.update’ ‘ip.status.route.
ipv6.update’ ‘mep.status.instance.update’ ‘mep.status.instancePeer.update’ ‘mep.status.lmHli.update’
‘mep.status.lmNotif.update’ ‘port.status.update’ ‘portSecurity.status.global.notification.update’
‘portSecurity.status.interface.notification.update’ ‘qos.status.global.update’
EXAMPLE
LPB3028A(config)# json notification host test
LPB3028A(config-json-noti-host)#
4.1. 2 5 L ACP
LACP settings
SY N TA X
lacp system-priority <1-65535>
Parameter
system-priority System priority
<1-65535> Priority value, lower means higher priority
EXAMPLE
LPB3028A(config)# lacp system-priority 333
LPB3028A(config)#
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
57
Page 58
CHAPTER 4: CONFIGURE COMMANDS OF CLI
4.1.26 LINE
Configure a terminal line
SY N TA X
line { <0–16> | console 0 | vty <0–15> }
Parameter
<0–16> List of line numbers
console Console terminal line
vty Virtual terminal
0 Console Line number
<0–15> List of vty numbers
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
EXAMPLE
LPB3028A(config)# line console 0
LPB3028A(config-line)#
4.1.27 LLDP
Link Layer Discover Protocol
SY N TA X
lldp holdtime <2-10>
lldp med datum [ wgs84 | nad83_navd88 | nad83_mllw ]
lldp med fast <1-10>
lldp med location-tlv altitude [ meters | floors ] <word11>
lldp med location-tlv civic-addr ( additional-code | additional-info | apartment | block | building | city | country | county | district | floor | houseno | house-no-suffix | landmark | leading-street-direction | name | p-o-box | plasetype | postal-community-name | room-number | state |
street | street-suffix | trailing-street-suffix | zip-code ) <line250> [ <line250> ]
lldp med location-tlv elin-addr <dword25>
lldp med location-tlv latitude ( north | south ) <word8>
lldp med location-tlv longitude ( west | east ) <word9>
lldp med media-vlan-policy <0-31> ( guest-voice | guest-voice-signaling | softphone-voice | streaming-video | video-conferencing | videosignaling | voice | voice-signaling ) tagged <vlan_id> [ dscp <0-63> ] | [ l2-priority <0-7> ] dscp <0-63>
lldp med media-vlan-policy <0-31> ( guest-voice | guest-voice-signaling | softphone-voice | streaming-video |video-conferencing | videosignaling | voice | voice-signaling ) ubtagged [ dscp <0-63> ]
lldp reinit <1-10>
lldp timer <5-32768>
58
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 59
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CHAPTER 4: CONFIGURE COMMANDS OF CLI
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
lldp transmission-delay <1-8192>
Parameter
Holdtime Sets LLDP hold time (The neighbor switch will discarded the LLDP information after ‘hold time’ multiplied with
‘timer’ seconds).
Med Media Endpoint Discovery.
Reinit LLDP tx reinitialization delay in seconds.
timer Sets LLDP TX interval (The time between each LLDP frame transmitted in seconds).
transmission-delay Sets LLDP transmission-delay. LLDP transmission delay (the amount of time that the transmission of LLDP
frames will delayed after LLDP configuration has changed) in seconds.)
<2-10> 2-10 seconds.
datum Datum (geodetic system) type.
fast Number of times to repeat LLDP frame transmission at fast start.
location-tlv LLDP-MED Location Type Length Value parameter
media-vlan-policy Create a policy, which can be assigned to an interface.
nad83_mllw Mean lower low water datum 1983
nad83_navd88 North American vertical datum 1983
wgs84 World Geodetic System 1984
<1-10>
altitude Altitude parameter.
civic-addr Civic address information and postal information. The total number of characters for the combined civic
address information must not exceed 250 characters.
NOTES:
1) A non-empty civic address location will use two extra characters in addition to the civic address] location
text.
2) The 2 letter country code is not part of the 250 characters limitation.
elin-addr Emergency Call Service ELIN identifier data format is defined to carry the ELIN identifier as used during
emergency call setup to a traditional CAMA or ISDN trunk-based PSAP. This format consists of a numerical
digit string, corresponding to the ELIN to be used for emergency calling. Emergency Location Identification
Number, (e.g. E911 and others), such as defined by TIA or NENA.
latitude Latitude parameter.
longitude Longitude parameter.
floors Specify the altitude in floor
meter Specify the altitude in meters
<word11> Altitude value. Valid range -2097151.9 to 2097151.9
additional-code Additional code - Example: 1320300003.
additional-info Additional location info - Example: South Wing.
apartment Unit (Apartment, suite) - Example: Apt 42.
block Neighborhood, block.
building Building (structure) - Example: Low Library.
city City, township, shi (Japan) - Example: Copenhagen.
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
59
Page 60
CHAPTER 4: CONFIGURE COMMANDS OF CLI
country The two-letter ISO 3166 country code in capital ASCII letters - Example: DK, DE or US.
county County, parish, gun (Japan), district.
district City division, borough, city district, ward, chou (Japan).
floor Floor - Example: 4.
house-no House number - Example: 21.
house-no-suffix House number suffix - Example: A, 1/2.
landmark Landmark or vanity address - Example: Columbia University.
leading-street-direction Leading street direction - Example: N.
name Name (residence and office occupant) - Example: John Doe.
p-o-box Post office box (P.O. BOX) - Example: 12345.
place-type Place type - Example: Office.
postal-community-name Postal community name - Example: Leonia.
room-number Room number - Example: 450F.
state National subdivisions (state, canton, region, province, prefecture).
street Street - Example: Oxford Street.
street-suffix Street suffix - Example: Ave, Platz.
trailing-street-suffix Trailing street suffix - Example: SW.
zip-code Postal/zip code - Example: 2791.
<line250> Value for the corresponding selected civic address.
<dword25> ELIN value
north Setting latitude direction to north.
south Setting latitude direction to south.
<word8> Latitude degrees (0.0000-90.0000).
east Setting longitude direction to east.
west Setting longitude direction to west.
<word9> Longitude degrees (0.0000-180.0000).
<0-31> Policy id for the policy which is created.
guest-voice Create a guest voice policy.
guest-voice-signaling Create a guest voice signaling policy.
softphone-voice Create a softphone voice policy.
streaming-video Create a streaming video policy.
video-conferencing Create a video conferencing policy.
video-signaling Create a video signaling policy.
voice Create a voice policy.
voice-signaling Create a voice signaling policy.
tagged The policy uses tagged frames.
untagged The policy uses untagged frames.
<vlan_id> The VLAN the policy uses tagged frames.
dscp Differentiated Services Code Point. If not given then DSCP value is set to 0.
l2-priority Layer 2 priority. If not given then L2 priority value is set to 0.
<0-63> DSCP value 0-63.
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
60
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 61
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CHAPTER 4: CONFIGURE COMMANDS OF CLI
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
<0-7> Priority 0-7.
<1-10> 1-10 seconds.
<5-32768> 5-32768 seconds.
<1-8192> 1-8192 seco nds.
EXAMPLE
LPB3028A(config)# lldp holdtime 5
LPB3028A(config)# lldp med fast 5
LPB3028A(config)# lldp reinit 3
LPB3028A(config)# lldp timer 555
LPB3028A(config)# lldp transmission-delay 333
NOTE: According to IEEE 802.1AB-clause 10.5.4.2 the transmission-delay must not be larger
than LLDP timer * 0.25. LLDP timer changed to 13332
4.1.28 LOGGING
System logging message
SY N TA X
logging host [ <hostname> | <ipv4_ucast> ]
logging level [ error | informational | notice | warning ]
logging notification listen <kword127> level ( error | informational | notice | warning ) <line255>
logging on
Parameter
host host
level Severity level
notification notification
on Enable Switch logging host mode
<domain_name> A valid name consist of a sequence of domain labels separated by ‘.’, each domain label starting and ending
with an alphanumeric character and possibly also containing ‘-’ characters. The length of a domain label must
be 63 characters or less.
<ipv4_ucast> The IPv4 address of the log server
error Severity 3: Error conditions
informational Severity 6: Informational messages
notice Severity 5: Normal but significant condition
warning Severity 4: Warning conditions
listen listen
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
61
Page 62
CHAPTER 4: CONFIGURE COMMANDS OF CLI
<kword127> A name identifying the listen command
level Severity level
<line255> Identification of the notification source
EXAMPLE
LPB3028A(config)# logging host 3 192.155.3.2
LPB3028A(config)#
LPB3028A(config)# logging on
LPB3028A(config)#
4.1.29 LOOP-PROTECT
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
Loop protection configuration
SY N TA X
loop-protect [ ( shutdown-time <0-604800> ) | ( transmit-time <1-10> ) ]
Parameter
shutdown-time Loop protection shutdown time interval
transmit-time Loop protection transmit time interval
<0-604800> Shutdown time in second
<1-10> Transmit time in second
EXAMPLE
LPB3028A(config)# loop-protect
LPB3028A(config)# loop-protect shutdown-time 333
LPB3028A(config)# loop-protect transmit-time 3
LPB3028A(config)#
62
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 63
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CHAPTER 4: CONFIGURE COMMANDS OF CLI
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
4.1. 3 0 M AC
MAC table entries/configuration
SY N TA X
mac address-table aging-time <0,10-1000000>
mac address-table learning vlan <vlan_list>
mac address-table static <mac_addr> vlan <vlan_id> [ interface { * [ <port_type_list> ] } | { ( GigabitEthernet | 10GigabitEthernet ) <port_
type_list> { [ * | GigabitEthernet | 10GigabitEthernet ] } [ <port_type_list> ] }
Parameter
address-table MAC table entries/configuration
aging-time Mac address aging time
learning Mac Learning
static Static MAC address
<0,10-1000000> Aging time in seconds, 0 disables aging
vlan VLAN
<vlan_list>
<mac_addr> 48 bit MAC address: xx:xx:xx:xx:xx:xx
vlan VLAN keyword
<vlan_id> VLAN IDs 1-4095
interface Select an interface to configure
* All switches or All ports
GigabitEthernet Gigabit Ethernet Ports
10GigabitEthernet 10Gigabit Ethernet Ports
<port_type_list> Port list for all port types
<port_type_list> Port list in 1/1-24
<port_type_list> Port list in 1/1-4
EXAMPLE
LPB3028A(config)# mac address-table aging-time 3333
LPB3028A(config)#
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
63
Page 64
CHAPTER 4: CONFIGURE COMMANDS OF CLI
4.1. 31 M EP
Maintenance Entity Poin
SY N TA X
mep <1-3124> ais [ fr1m | fr1s ] | [ protect ]
mep <1-3124> aps <0-7> { [ laps ] | ( multi | uni ) ( laps | raps ) | raps [ octet ] }
mep <1-3124> cc <0-7> [ fr100s | fr10s | fr1m | fr1s | fr300s | fr6h | fr6m ] [ rx-only ]
mep <1-3124> ccm-tlv
mep <1-3124> client domain ( evc | vlan ) flow <uint> [ ais-prio ] [ <0-7> | ais-highest | lck-prio | level ]
mep <1-3124> client domain ( evc | vlan ) flow <uint> [ lck-prio ] [ <0-7> | ais-prio | lck-highest | level ]
mep <1-3124> client domain ( evc | vlan ) flow <uint> [ level <0-7> ] [ ais-prio | lck-prio ]
mep <1-3124> dm <0-7> dual flow interval <uint> last-n <uint>
mep <1-3124> dm <0-7> dual flow multi interval <uint> last-n <uint>
mep <1-3124> dm <0-7> dual flow uni mep-id
mep <1-3124> dm <0-7> dual interval <uint> last-n <uint>
mep <1-3124> dm <0-7> dual multi ( flow | rdtrp ) interval <uint> last-n <uint>
mep <1-3124> dm <0-7> dual multi interval <uint> last-n <uint>
mep <1-3124> dm <0-7> dual rdtrp interval <uint> last-n <uint>
mep <1-3124> dm <0-7> dual rdtrp multi interval <uint> last-n <uint>
mep <1-3124> dm <0-7> dual rdtrp uni mep-id
mep <1-3124> dm <0-7> dual uni mep-id
mep <1-3124> dm bin { ( fd | ifdv ) <2-10> } | ( threshold <1-50000> )
mep <1-3124> dm ( ns | overflow-reset | proprietary | synchronized )
mep <1-3124> ( down | up ) domain ( evc | port | vlan ) [ flow <uint> ] level <0-7> [ interface ( GigabitEthernet |
10GigabitEthernet ) <port_type_id> ] | vid <vlan_id>
mep <1-3124> lb <0-7> { [ count <uint> ] | dei | multi | [ uni ( mac | mep-id ) ] }
mep <1-3124> lck [ fr1m | fr1s ]
mep <1-3124> level <0-7>
mep <1-3124> link-state-tracking
mep <1-3124> lm <0-7> [ dual | flr | fr100s | fr10s | fr1s | fr6m | meas | multi | single | size |
slm-testid | synthetic | threshold | uni ] <uint>
mep <1-3124> lm flow-counting
mep <1-3124> lm oam-counting [ all | y1731 ]
mep <1-3124> lm rx [ synthetic ] [ flr <uint>] | [ prio | <0-7> ] | [ threshold <1-100> ]
mep <1-3124> lm-avail ( interval <1-1000> flr-threshold <0-1000> ) | maintenance
mep <1-3124> lm-hli flr-threshold <0-1000> interval <uint>
mep <1-3124> lm-notif los-int-cnt-holddown <uint> los-th-cnt-holddown <uint> hli-cnt-holddown <uint>
mep <1-3124> lm-sdeg tx-min <uint> flr-threshold <0-1000> bad-threshold <uint> good-threshold <uint>
mep <1-3124> lt <0-7> [ mac <mac_addr> ] | [ mep-id <uint> ttl <0-255> ]
mep <1-3124> meg-id <word> ( ieee [ name <word> ] ) | [ itu ] | [ itu-cc ]
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
64
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 65
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CHAPTER 4: CONFIGURE COMMANDS OF CLI
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
mep <1-3124> mep-id <uint>
mep <1-3124> mip ( down | up) domain ( evc | port | vlan ) [ flow <uint> ] level <0-7>
[ interface ( GigabitEthernet | 10GigabitEthernet ) <port_type_id> ] | vid <vlan_id>
mep <1-3124> peer-mep-id <uint> [ mac <mac_addr> ]
mep <1-3124> performance-monitoring
mep <1-3124> syslog
mep <1-3124> tst <0-7> { ( dei mep-id ) | mep-id } <uint> { ( all-one | all-zero | one-zero ) | sequence }
rate <uint> size <uint>
mep <1-3124> tst ( rx | tx )
mep <1-3124> vid <vlan_id>
mep os-tlv oui <0-0xFFFFFF> sub-type <0-0xFF> value <0-0xFF>
Parameter
<1-3124> The MEP instance number.
os-tlv Organization-Specific TLV
ais Alarm Indication Signal
aps Automatic Protection Switching protocol.
cc Continuity Check.
ccm-tlv The CCM TLV enable/disable
client
dm Delay Measurement.
down This MEP is a Down-MEP.
lb Loop Back.
lck Locked Signal.
level The MEG level of the MEP.
link-state-tracking Link State Tracking. When LST is enabled in an instance, Local SF or received ‘isDown’ in CCM
Interface Status TLV, will bring down the residence port. Only valid in Up-MEP. The CCM rate must be 1
f/s or faster.
lm Loss Measurement. Either Service frame or Synthetic Frame LM.
lm-avail Availability for Loss Measurement
lm-hli High Loss Interval for Loss Measurement
lm-notif Loss Measurement JSON notifications
lm-sdeg Signal Degrade for Loss Measurement
lt Link Trace.
meg-id The ITU/IEEE MEG-ID.
mep-id The MEP ID.
mip This MEP instance is a half-MIP.
peer-mep-id The peer MEP ID.
performance-monitoring Performance monitoring Data Set collection (MEF35).
syslog Enable syslog.
tst Test Signal
up This MEP is a Up-MEP.
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
65
Page 66
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CHAPTER 4: CONFIGURE COMMANDS OF CLI
vid The MEP VID.
fr1m Frame rate is 1 f/min.
fr1s Frame rate is 1 f/s.
protect The AIS can be used for protection. At the point of state change three AIS PDU is transmitted as fast as
possible.
<0-7> Priority in case of tagged OAM. In the MPLS and EVC domain this is the COS-ID.
laps Linear Automatic Protection Switching protocol.
multi OAM PDU is transmitted with multicast MAC. Must me ‘multi’ in case of RAPS.
raps Ring Automatic Protection Switching protocol.
uni OAM PDU is transmitted with unicast MAC. The MAC is taken from peer MEP MAC database. Only possible in
case of LAPS.
octet Then last OCTET in the multicast MAC. Only possible in case of RAPS.
fr100s Frame rate is 100 f/s.
fr10s Frame rate is 10 f/s.
fr300s Frame rate is 300 f/s.
fr6h Frame rate is 6 f/hour.
fr6m Frame rate is 6 f/min.
rx-only CCM transmission and LOC detection is not enabled. Only RX parameters (priority and frame rate) are
configured.
domain Client flow domain.
evc EVC client flow.
flow Client flow instance.
vlan VLAN client flow.
<uint> Client flow instance number value.
ais-prio AIS injection priority.
lck-prio LCK injection priority.
level The MEG level on the client layer
<0-7> AIS injection priority value.
ais-highest Request the highest possible AIS priority.
<0-7> LCK injection priority value.
lck-highest Request the highest possible LCK priority.
bin Delay Measurement Binning.
ns Nanoseconds
overflow-reset Reset all Delay Measurement results on total delay counter overflow.
proprietary Proprietary Delay Measurement.
synchronized Near-end and far-end is real time synchronized.
dual Delay Measurement based on 1DM PDU transmission.
flow The two way delay is calculated as round trip symmetrical flow delay. The far end residence time is subtracted.
interval Interval between PDU transmission in 10ms. Min value is 10.
multi OAM PDU is transmitted with multicast MAC.
rdtrp The two way delay is calculated as round trip delay. The far end residence time is not subtracted.
single Delay Measurement based on DMM/DMR PDU.
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
66
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 67
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CHAPTER 4: CONFIGURE COMMANDS OF CLI
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
uni OAM PDU is transmitted with unicast MAC. The MAC is taken from peer MEP MAC database.
<uint> Interval value.
<uint> The last N value.
mep-id Peer MEP ID for unicast DM. The MAC is taken from peer MEP MAC database.
last-n The last N delays measurements used for average last N calculation. Min value is 10. Max value is 100
fd the number of FD Measurement Bins.
ifdv the number of IFDV Measurement Bins.
threshold the threshold for each Delay Measurement Binning.
<2-10> the number of FD Measurement Bins.
<1-50000> the threshold for each Delay Measurement Binning.
domain The domain of the MEP.
evc This MEP is a EVC domain MEP.
port This MEP is a Port domain MEP.
vlan This MEP is a VLAN domain MEP.
flow In case the MEP is a VLAN, EVC, MPLS-TP link, tunnel, LSP or Pseudo-Wire domain MEP, the flow instance that
the MEP is related to must be given.
level The MEG level of the MEP.
vid In case the MEP is a Port domain Up-MEP or a EVC domain customer MIP (on the UNI), the VID must be given.
<uint> The VLAN, EVC, MPLS-TP link, MPLS-TP tunnel, MPLS-TP LSP or MPLS-TP Pseudo-Wire flow instance number.
<0-7> The MEG level value.
interface Select an interface to configure
GigabitEthernet Gigabit Ethernet Ports
10GigabitEthernet 10Gigabit Ethernet Ports
<port_type_list> Port list in 1/1-24
<port_type_list> Port list in 1/1-4
<vlan_id> The port Domain MEP or EVC domain customer MIB VID.
<0-7> Priority in case of tagged OAM. In the MPLS and EVC domain this is the COS-ID.
count The number of LBM PDUs to send in one loop test. The value 0
indicate infinite transmission (test behavior). This is hardware based LBM/LBR and Requires VOE.
dei Drop Eligible Indicator in case of tagged OAM.
multi OAM PDU is transmitted with multicast MAC. Not used for MPLS-TP.
uni OAM PDU is transmitted with unicast MAC. The MAC is taken from peer MEP MAC database. Not used for
MP L S-T P.
<uint> Number of LBM PDUs to send value.
mac Loop Back unicast MAC to be used in case of LB against MIP.
mep-id Peer MEP ID for unicast LB. The MAC is taken from peer MEP MAC database. Not used for MPLS-TP.
flow-counting Loss Measurement is counting service frames per flow – all priority in one.
oam-counting Loss Measurement is counting OAM frames either as Y1731 or all
rx Receive and respond to LM PDUs from LM initiator.
dual Dual ended LM is based on CCM PDU or 1SL PDU in case of ‘synthetic’.
flr The Frame Loss Ratio interval.
fr100s Frame rate is 100 f/s. Is only allowed for ‘synthetic’ LM.
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
67
Page 68
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CHAPTER 4: CONFIGURE COMMANDS OF CLI
fr10s Frame rate is 10 f/s.
fr1s Frame rate is 1 f/s.
fr6m Frame rate is 6 f/min. Is not allowed for dual ended ‘service frame’ LM (CCM PDU based).
multi OAM PDU is transmitted with multicast MAC.
single Single ended LM is based on LMM/LMR PDU or SLM/SLR PDU in case of ‘synthetic’.
slm-testid SLM Test ID
synthetic Do synthetic LM using SLM/1SL OAM PDUs. Synthetic LM allows multiple peer MEP configured. Service frame
LM allows only one peer MEP.
threshold Frame Loss threshold
uni OAM PDU is transmitted with unicast MAC. The MAC is taken from peer MEP MAC database. In case of LM
there is only one peer MEP.
interval Availability interval
maintenance Availability Maintenance indicator.
<1-1000> Availability interval - number of measurements with same availability in order to
change Availability state.
flr-threshold Availability FLR Threshold
<0-1000> Availability FLR Threshold in permille.
flr-threshold High Loss Interval FLR Threshold
<0-1000> High Loss Interval FLR Threshold in permille
interval High Loss Interval consecutive interval (number of measurements)
<uint> High Loss Interval consecutive interval (number of measurements)
los-int-cnt-holddown Hold down timer for JSON notification updates for near and far end frame loss interval count
<uint> Timer value in seconds.
hli-cnt-holddown Hold down timer for JSON notification updates for near and far end High Loss Interval count
tx-min Minimum number of frames that must be transmitted in a measurement before FLR is tested against the SDEG
FLR threshold.
<uint> Minimum number of frames that must be transmitted in a measurement before FLR is tested against the SDEG
FLR threshold.
flr-threshold Signal Degrade FLR threshold
<0-1000> Signal Degrade FLR threshold in permille
bad-threshold Number of consecutive bad interval measurements required to set degrade state.
<uint> Number of consecutive bad interval measurements required to set degrade state.
good-threshold Number of consecutive good interval measurements required to clear degrade state.
<uint> Number of consecutive good interval measurements required to clear degrade state.
mac Link Trace target unicast MAC to be used in case of LT against MIP.
mep-id Peer MEP ID for Link Trace target unicast MAC. The MAC is taken from peer MEP MAC database.
<uint> Peer MEP ID value.
ttl Time To Live.
<0-255> Time To Live value.
<word> The MEG-ID string. This is either the ITU MEG-ID or the IEEE Short MA, depending on the selected MEG-ID
format. The ITU max. is 13 characters. The ITU-CC max. is 15 characters. The IEEE max. is 16 characters.
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
68
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 69
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CHAPTER 4: CONFIGURE COMMANDS OF CLI
ieee The MEG-ID (Short MA Name) has IEEE Character String format. The MEG-ID max. is 16 characters.
itu The MEG-ID has ITU format (ICC - UMC). The MEG-ID max. is 13 characters.
itu-cc The MEG-ID has ITU Country Code format (CC - ICC - UMC). The MEG-ID max. is 15 characters
<uint> The MEP ID value.
rx Receive Test Signal.
tx Transmit Test Signal.
all-one Test pattern is set to all one.
all-zero Test pattern is set to all zero.
one-zero Test pattern is set to 10101010.
sequence Enable sequence number in TST PDU
rate The TST frame transmission bit rate - in Mega bits pr. second. Limit is 400 Mbps. This is the bit rate of a standard frame
without any encapsulation. If 1 Mbps rate is selected in a EVC MEP, the added tag will give a higher bitrate on the wire.
size The TST frame size. This is entered as the wanted size (in bytes) of a un-tagged frame containing TST OAM PDU -
including CRC (four bytes). Example when ‘Size’ = 64 => Un-tagged frame size = DMAC(6) + SMAC(6) + TYPE(2) + TST
PDU LENGTH(46) + CRC(4) = 64 bytes. The transmitted frame will be four bytes longer for each tag added - 8 bytes in
case of a tunnel EVC. There are two frame MAX sizes to consider. Switch RX frame MAX size: The MAX frame size
(all inclusive) accepted on the switch port of 10240 Bytes. CPU RX frame MAX size: The MAX frame size (all inclusive)
possible to copy to CPU of 10240 Bytes. Consider that the Peer MEP must be able to handle the selected frame size.
Consider that in order to calculate the ‘RX rate’ a received TST PDU must be copied to CPU. Warning will be given if
selected frame size exceeds the CPU RX frame MAX size. Frame MIN Size is 64 Bytes.
oui Organizationally Unique Identified.
<0-0xFFFFFF>
sub-type Sub-Type
<0-0xFF> Sub-Type value - one octet.
Value value
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
EXAMPLE
LPB3028A(config)# mep 1 syslog
LPB3028A(config)#
4.1.32 MONITOR
Monitoring different system events.
SY N TA X
monitor session <1-5>
monitor session <1-5> destination [ interface { * [ <port_type_list> ] } | { ( GigabitEthernet | 10GigabitEthernet ) <port_type_list> { [ * |
GigabitEthernet | 10GigabitEthernet ] } [ <port_type_list> ] }
monitor session <1-5> destination remote vlan <vlan_id> reflector-port ( GigabitEthernet | 10GigabitEthernet ) <port_type_list>
monitor session <1-5> source cpu [ both | rx | tx ]
monitor session <1-5> source interface * ( [ <port_type_list> ] | [ both ] | [ rx ] | [ tx ] )
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
69
Page 70
CHAPTER 4: CONFIGURE COMMANDS OF CLI
monitor session <1-5> source interface [ ( GigabitEthernet | 10GigabitEthernet ) <port_type_list> ]
monitor session <1-5> source remote vlan <vlan_id>
monitor session <1-5> source vlan <vlan_id>
Parameter
session Configure a MIRROR session
<1-5> MIRROR session number
destination MIRROR destination interface or VLAN
source MIRROR source interface, VLAN
interface MIRROR destination interface
remote MIRROR destination Remote
* All switches or All ports
GigabitEthernet Gigabit Ethernet Ports
10GigabitEthernet 10Gigabit Ethernet Ports
<port_type_list> Port list for all port types
<port_type_list> Port list in 1/1-24
vlan MIRROR destination Remote number
<vlan_id> Remote MIRROR destination RMIRROR VLAN number
reflector-port Remote MIRROR reflector interface
cpu MIRROR source CPU
interface MIRROR source interface
remote MIRROR source Remote
vlan MIRROR source VLAN
both MIRROR source CPU receive both
rx MIRROR source CPU receive Rx
tx MIRROR source CPU receive Tx
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
EXAMPLE
LPB3028A(config)# monitor session 1 source vlan 1
LPB3028A(config)#
70
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 71
CHAPTER 4: CONFIGURE COMMANDS OF CLI
4.1.33 MVR
Multicast VLAN Registration configuration
SY N TA X
mvr
mvr ( name | vlan <vlan_list> ) <word16> channel <word16>
mvr ( name | vlan <vlan_list> ) <word16> election
mvr ( name | vlan <vlan_list> ) <word16> frame [ priority <0-7> ] | [ tagged ]
mvr ( name | vlan <vlan_list> ) <word16> igmp-address <ipv4_ucast>
mvr ( name | vlan <vlan_list> ) <word16> last-member-query-interval <0-31744>
mvr ( name | vlan <vlan_list> ) <word16> mode [ compatible | dynamic ]
Parameter
name MVR multicast name
vlan MVR multicast VLAN
<word16> MVR multicast VLAN name
channel MVR channel configuration
election Act as an IGMP Querier to join Querier-Election
frame MVR control frame in TX
igmp-address MVR address configuration used in IGMP
last-member-query-interval Last Member Query Interval in tenths of seconds
mode MVR mode of operation
<word16> Profile name in 16 characters
priority Interface CoS priority
tagged Tagged IGMP/MLD frames will be sent
<0-7> CoS priority ranges from 0 to 7
<ipv4_ucast> A valid IPv4 unicast address
<0-31744> 0 - 31744 tenths of seconds
compatible Compatible MVR operation mode
dynamic Dynamic MVR operation mode
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
EXAMPLE
LPB3028A(config)# mvr vlan 10 mode dynamic
LPB3028A(config)#
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
71
Page 72
CHAPTER 4: CONFIGURE COMMANDS OF CLI
4.1.34 MVRP
Enable MVRP feature globally
SY N TA X
mvrp
mvrp managed vlan <vlan_list>
mvrp managed vlan ( add | except | remove ) <vlan_list>
mvrp managed vlan ( all | none )
Parameter
managed Set list of MVRP-managed VLANs
vlan Set managed VLANs of MVRP
<vlan_list> VLAN IDs of the managed VLANs of MVRP
add Add VLANs to the current list
all All VLANs
except All VLANs except the following
none No VLANs
remove Remove VLANs from the current list
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
EXAMPLE
LPB3028A(config)# mvrp managed vlan all
LPB3028A(config)#
72
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 73
CHAPTER 4: CONFIGURE COMMANDS OF CLI
4.1. 35 N O
no.
CONFIGURE — NO COMMANDS TABLE
COMMAND FUNCTION
aaa Authentication, Authorization, and Accounting
access Access management
access-list Access list
aggregation Aggregation mode
banner Define a banner
clock Configure time-of-day clock
debug Debugging functions
dot1x IEEE Standard for port-based Network Access Control
enable Modify enable password parameters
eps Ethernet Protection Switching.
erps Ethernet Ring Protection Switching
green-ethernet Green ethernet (Power reduction)
gvrp Enable GVRP feature
hostname Set system’s network name
interface Select an interface to configure
ip Interface Internet Protocol configuration commands
ipmc IPv4/IPv6 multicast configuration
ipv6 IPv6 configuration commands
json JSON-RPC related configuration
lacp LACP settings
lldp Link Layer Discover Protocol
logging System logging message
loop-protect Loop protection configuration
mac MAC table entries/configuration
mep Maintenance Entity Point
monitor Monitoring different system events
mvr Multicast VLAN Registration configuration
mvrp
ntp Configure NTP
poe Power Over Ethernet
port-security Port Security
Privilege Command privilege parameters
Prompt Default the prompt to hostname
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
73
Page 74
CHAPTER 4: CONFIGURE COMMANDS OF CLI
CONFIGURE — NO COMMANDS TABLE
COMMAND FUNCTION
ptp Precision time Protocol (1588)
radius-server Configure RADIUS
rmon Remote Monitoring
router Routing process
sflow Statistics flow
snmp-server Set SNMP server’s configurations
spanning-tree STP Bridge
svl Unmap Shared VLAN Learning for a range or all FIDs
switchport VLAN
system Set the SNMP server’s configurations
tacacs-server Configure TACACS+
udld Disable UDLD configurations on all fiber-optic ports.
upnp Set UPnP’s configurations
username Establish User Name Authentication
vlan Vlan commands
voice Voice appliance attributes
web web
4.1. 35 .1 A A A
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
Authentication, Authorization, and Accounting
SY N TA X
no aaa accounting ( console | ssh | telnet )
no aaa authentication login ( console | http | ssh | telnet )
no aaa authorization ( console | ssh | telnet )
Parameter
authentication Authentication
authorization Authorization
accounting
console
ssh
telnet
login Login
console Disable Console authentication
http Disable HTTP authentication
ssh Disable SSH authentication
74
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 75
CHAPTER 4: CONFIGURE COMMANDS OF CLI
telnet Disable Telnet authentication
console Disable Console authorization
ssh Disable SSH authorization
telnet Disable Telnet authorization
EXAMPLE
LPB3028A(config)# no aaa authentication login ssh
LPB3028A(config)#
4.1.35.2 ACCESS
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
Access management
SY N TA X
no access management [ <1-16>]
Parameter
management Access management configuration
<1-16> ID of access management entry
EXAMPLE
LPB3028A(config)# no access management
LPB3028A(config)#
4.1.35.3 ACCESS-LIST
Access list
SY N TA X
no access-list ( ace <1-512> ) | ( rate-limiter [ <1-16> ] )
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
75
Page 76
CHAPTER 4: CONFIGURE COMMANDS OF CLI
Parameter
ace Access list entry
rate-limiter Rate limiter
<1-512> ACE ID
<1-16> Rate limiter ID
EXAMPLE
LPB3028A(config)# no access-list ace 1
LPB3028A(config)#
4.1.35.4 AGGREGATION
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
Aggregation mode.
SY N TA X
no aggregation mode
Parameter
mode Traffic distribution mode
EXAMPLE
LPB3028A(config)# no aggregation mode
LPB3028A(config)#
4.1.35.5 BANNER
Define a banner
SY N TA X
no banner [ exec | login | motd ]
Parameter
exec Set EXEC process creation banner
login Set login banner
motd Set Message of the Day banner
76
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 77
CHAPTER 4: CONFIGURE COMMANDS OF CLI
EXAMPLE
LPB3028A(config)# no banner login
LPB3028A(config)#
4.1.35.6 CLOCK
Configure time-of-day clock
SY N TA X
no clock [ summer-time | timezone ]
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
Parameter
summer-time Configure summer (daylight savings) time
timezone Configure time zone
EXAMPLE
LPB3028A(config)# no clock summer-time
LPB3028A(config)#
4.1.35.7 DEBUG
Debugging functions
SY N TA X
no debug mep <uint> dm tx ( dual | single ) <0-7> [ interval <uint> ] [ synchronized ]
no debug mep <uint> raps forward
no debug mep <uint> test tx ( lb | tst ) ( <0-7> | all ) [ all-one | all-zero | one-zero ] [ dei | rate | size ]
no debug mep <uint> test tx ( lb | tst ) ( <0-7> | all ) [ dei ] [ all-one | all-zero | one-zero | rate | size ]
no debug mep <uint> test tx ( lb | tst ) ( <0-7> | all ) rate <uint> [ all-one | all-zero | dei | one-zero | size ]
no debug mep <uint> test tx ( lb | tst ) ( <0-7> | all ) size <uint> [ all-one | all-zero | dei | one-zero | rate ]
no debug mep <uint> volatile
no debug mep inject ( afi | single ) ( down | up ) pdu <uint> prio <uint> [ isdx <uint> ] | [ pipeline-point <uint> ] | [ tagged ]
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
77
Page 78
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CHAPTER 4: CONFIGURE COMMANDS OF CLI
Parameter
mep Maintenance Entity Point.
<uint> The MEP instance number.
inject
dm Delay Measurement.
raps The MEP instance get RAPS forwarding enabled.
test Test Generation.
volatile The MEP instance is change to volatile.
tx Transmit DM/1DM.
dual Dual ended - 1DM based.
single Single ended - DMM/DMR based.
<0-7> Priority in case of tagged OAM. In the MPLS and EVC domain this is the COS-ID.
interval Interval between PDU transmission in 10ms. Min value is 10.
synchronized Near-end and far-end is real time synchronized.
<uint> Interval value.
tx Transmit Test.
lb Loop Back test
tst Test Signal test
all all priorities.
all-one Data pattern is set to all one.
all-zero Test pattern is set to all zero.
dei Drop Eligible Indicator in case of tagged OAM.
one-zero Data pattern is set to 10101010.
rate The TEST frame transmission bit rate - in Kbps. This is the bit rate of a standard frame without any encapsulation.
If 1 Mbps rate is selected in a EVC MEP, the added tag will give a higher bitrate on the wire.
size The TEST frame size. This is entered as the wanted size (in bytes) of an untagged frame containing TST OAM PDU -
including CRC (four bytes). Example when ‘Size’ = 64 : Untagged frame size = DMAC(6) + SMAC(6) + TYPE(2) + TST PDU
LENGTH(46) + CRC(4) = 64 bytes. The transmitted frame will be four bytes longer for each tag added - 8 bytes in case of
a tunnel EVC. Minimum Size is 64 Bytes. Maximum Size is 9600 Bytes (1526 for MPLS).
afi AFI frame injection.
single Single frame injected
down DOWN injection.
up UP injection.
pdu PDU type.
<uint> The PDU type opcode.
prio Priority.
<uint> The priority in TAG.
isdx ISDX.
pipeline-point pipeline_point.
tagged tagged.
<uint> The pipeline point.
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
78
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 79
CHAPTER 4: CONFIGURE COMMANDS OF CLI
EXAMPLE
LPB3028A(config)# no debug mep 1 dm tx single 1
LPB3028A(config)#
4.1. 35 . 8 D OT 1X
IEEE Standard for port-based Network Access Control
SY N TA X
no dot1x authentication timer ( inactivity | re-authenticate )
no dot1x feature [ guest-vlan ] | [ radius-qos ] | [ radius-vlan ]
no dot1x guest-vlan [ supplicant ]
no dot1x ( max-reauth-req | re-authentication | system-auth-control )
no dot1x timeout ( quiet-period | tx-period )
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
Parameter
authentication Authentication
feature Globally enables/disables a dot1x feature functionality
guest-vlan Guest VLAN
max-reauth-req The number of time a Request Identity EAPOL frame is sent without response before considering entering the
Guest VLAN
re-authentication Set Re-authentication state
system-auth-control Set the global NAS state
timeout timeout
timer timer
re-authenticate The period between re-authentication attempts in seconds
guest-vlan Globally enables/disables state of guest-vlan
radius-qos Globally enables/disables state of RADIUS-assigned QoS.
radius-vlan Globally enables/disables state of RADIUS-assigned VLAN.
supplicant The switch remembers if an EAPOL frame has been received on the port for the life-time of the port. Once
the switch considers whether to enter the Guest VLAN, it will first check if this option is enabled or disabled.
If disabled (unchecked, default), the switch will only enter the Guest VLAN if an EAPOL frame has not been
received on the port for the life-time of the port. If enabled (checked), the switch will consider entering the
Guest VLAN even if an EAPOL frame has been received on the port for the life-time of the port.
quiet-period Time in seconds before a MAC-address that failed authentication gets a new authentication chance.
tx-period The time between EAPOL retransmissions
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
79
Page 80
CHAPTER 4: CONFIGURE COMMANDS OF CLI
EXAMPLE
LPB3028A(config)# no dot1x authentication timer re-authenticate
LPB3028A(config)# no dot1x guest-vlan supplicant
LPB3028A(config)# no dot1x max-reauth-req
LPB3028A(config)# no dot1x re-authentication
LPB3028A(config)# no dot1x system-auth-control
LPB3028A(config)# no dot1x timeout tx-period
LPB3028A(config)#
4.1. 35 .9 E N AB L E
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
Modify enable password parameters
SY N TA X
no enable password [ level <1-15> ]
no enable secret [ 0 | 5 { level <1-15> }]
Parameter
password Assign the privileged level clear password
secret Assign the privileged level secret
0 Specifies an UNENCRYPTED password will follow
5 Specifies an ENCRYPTED password will follow
level Set exec level password
<1-15> Level number
EXAMPLE
LPB3028A(config)# no enable secret level 15
LPB3028A(config)# no enable password level 15
LPB3028A(config)#
80
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 81
CHAPTER 4: CONFIGURE COMMANDS OF CLI
4.1. 35 .10 E P S
Ethernet Protection Switching
SY N TA X
no eps <uint> [ command | holdoff | revertive ]
Parameter
<uint> The EPS instance number.
command Clear command on EPS.
holdoff
revertive Revertive EPS.
EXAMPLE
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
LPB3028A(config)# no eps 1 command
LPB3028A(config)#
4.1. 35 .11 E RP S
Ethernet Ring Protection Switching
SY N TA X
no erps 1-64 ( guard | holdoff | mep | revertive | rpl | version | vlan)
no erps 1-64 topology-change propagate
Parameter
1-64 ERPS group number
guard Guard
holdoff Hold-off time
mep MEP
revertive Revertive
rpl Ring Protection Link
sub Sub-ring
topology-change Topology Change
version Version
vlan VLAN
propagate Propagate
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
81
Page 82
CHAPTER 4: CONFIGURE COMMANDS OF CLI
EXAMPLE
LPB3028A(config)# no erps version
LPB3028A(config)#
4.1.35.12 GREEN-ETHERNET
Green ethernet (Power reduction)
SY N TA X
no green-ethernet eee optimize-for-power
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
Parameter
eee Powering down of PHYs when there is no traffic.
optimize-for-power Set if EEE shall be optimized for least power consumption (else optimized for least traffic latency).
EXAMPLE
LPB3028A(config)# no green-ethernet eee optimize-for-power
LPB3028A(config)#
4-1.35 .13 GV RP
Enable GVRP feature
SY N TA X
no gvrp
no gvrp max-vlans <1-4094>
no gvrp time [ join-time <1-20> ] [ leave-time <60-300> ] [ leave-all-time <1000-5000> ]
Parameter
max-vlans Number of simultaneously VLANs that GVRP can control
time Config GARP protocol timer parameters. IEEE 802.1D-2004, clause 12.11.
join-time Set GARP protocol parameter JoinTime. See IEEE 802.1D-2004, clause 12.11
leave-all-time Set GARP protocol parameter LeaveAllTime. See IEEE 802.1D-2004, clause 12.11
leave-time Set GARP protocol parameter LeaveTime. See IEEE 802.1D-2004, clause 12.11
<1-20> join-time in units of centiseconds. Range is 1-20. Default is 20.
82
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 83
CHAPTER 4: CONFIGURE COMMANDS OF CLI
<1000-5000> leave-all-time in units of centiseconds Range is 1000-5000. Default is 1000.
<60-300> leave-time in units of centiseconds. Range is 60-300. Default is 60.
EXAMPLE
LPB3028A(config)#no gvrp max-vlans 1
LPB3028A(config)#
4-1.35.14 HOSTNAME
Set system’s network name
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
SY N TA X
no hostname
Parameter
none
EXAMPLE
LPB3028A(config)# no hostname
LPB3028A(config)#
4-1.35.15 INTERFACE
Select an interface to configure.
SY N TA X
no interface ( llag 1-26 ) | ( vlan <vlan_list> )
Parameter
llag Local link aggregation interface configuration
vlan VLAN interface configurations
1-26 ID of LLAG interface
<vlan_list> List of VLAN interface numbers
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
83
Page 84
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CHAPTER 4: CONFIGURE COMMANDS OF CLI
EXAMPLE
LPB3028A(config)# no interface vlan 10
LPB3028A(config)#
4-1.35 .16 IP
Interface Internet Protocol configuration commands
SY N TA X
no ip arp inspection
no ip arp inspection entry interface ( GigabitEthernet | 10GigabitEthernet ) <port_type_id> <vlan_id> <mac_ucast> <ipv4_ucast>
no ip arp inspection vlan <vlan_list> [ logging ]
no ip dhcp excluded-address <ipv4_addr> [ <ipv4_addr> ]
no ip dhcp pool <word32>
no ip dhcp relay information [ option | policy ]
no ip dhcp [ server | snooping ]
no ip dns proxy
no ip domain name
no ip helper-address
no ip http ( secure-redirect | secure-server )
no ip igmp host-proxy [ leave-proxy ]
no ip igmp snooping [ vlan <vlan_list> ]
no ip igmp ( ssm-range | unknown-flooding )
no ip name-server [ <0-3> ]
no ip route <ipv4_addr> <ipv4_netmask> <ipv4_ucast>
no ip routing
no ip source binding interface ( GigabitEthernet | 10GigabitEthernet ) <port_type_id> <vlan_id> <ipv4_ucast> <mac_ucast>
no ip ssh
no ip verify source
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
Parameter
arp Address Resolution Protocol
dhcp Configure DHCP server parameters
dns Domain Name System
domain IP DNS Resolver
helper-address
http Hypertext Transfer Protocol
igmp Internet Group Management Protocol
84
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 85
CHAPTER 4: CONFIGURE COMMANDS OF CLI
name-server Domain Name System
route
routing Disable routing for IPv4 and IPv6
source source command
ssh Secure Shell
verify verify command
inspection ARP inspection
entry ARP inspection entry
vlan ARP inspection vlan setting
interface Select an interface to configure
GigabitEthernet Gigabit Ethernet Ports
10GigabitEthernet 10Gigabit Ethernet Ports
<port_type_list> Port list in 1/1-24
<port_type_list> Port list in 1/1-4
<vlan_id> Select a VLAN id to configure
<mac_ucast> Select a MAC address to configure
<ipv4_ucast> Select an IP Address to configure
<vlan_list> arp inspection vlan list
logging ARP inspection vlan logging mode configuration
excluded-address Prevent DHCP from assigning certain addresses
pool Configure DHCP address pools
relay DHCP relay agent configuration
server Enable DHCP server
snooping DHCP snooping
<ipv4_addr> Low IP address
<ipv4_addr> High IP address
<word32> Pool name in 32 characters
Information DHCP information option (Option 82)
option DHCP option
policy Policy for handling the receiving DHCP packet already include the information option
proxy DNS proxy service
name Define the default domain name
secure-redirect Secure HTTP web redirection
secure-server Secure HTTP web server
host-proxy IGMP proxy configuration
snooping Snooping IGMP
ssm-range IPv4 address range of Source Specific Multicast
unknown-flooding Flooding unregistered IPv4 multicast traffic
leave-proxy IGMP proxy for leave configuration
vlan IGMP VLAN
<vlan_list> VLAN identifier (VID)
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
85
Page 86
CHAPTER 4: CONFIGURE COMMANDS OF CLI
<0-3> Preference of DNS server. Default selection is 0
<ipv4_addr> Network
<ipv4_netmask> Netmask
<ipv4_ucast> Gateway
binding IP source binding
<mac_ucast> Select a MAC address to configure
source verify source
EXAMPLE
LPB3028A(config)# no ip ssh
LPB3028A(config)#
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
4-1.35 .17 IP MC
IPv4/IPv6 multicast configuration
SY N TA X
no ipmc ( profile | range ) [ <word16> ]
Parameter
profile IPMC profile configuration
range A range of IPv4/IPv6 multicast addresses for the profile
<word16> Profile name in 16 characters
<word16> Range entry name in 16 characters
EXAMPLE
LPB3028A(config)# no ipmc profile aa
LPB3028A(config)#
86
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 87
CHAPTER 4: CONFIGURE COMMANDS OF CLI
4-1.35 .18 IP V6
IPv6 configuration commands
SY N TA X
no ipv6 mld host-proxy [ leave-proxy ]
no ipv6 mld snooping [ vlan <vlan_list> ]
no ipv6 mld ssm-range
no ipv6 mld unknown-flooding
no ipv6 mld route <ipv6_subnet>
Parameter
mld Multicast Listener Discovery
route Configure static routes
host-proxy MLD proxy configuration
snooping Snooping MLD
ssm-range IPv6 address range of Source Specific Multicast
unknown-flooding Flooding unregistered IPv6 multicast traffic
leave-proxy MLD proxy for leave configuration
vlan MLD VLAN
<vlan_list> VLAN identifier (VID)
<ipv6_subnet> IPv6 prefix x:x::y/z
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
EXAMPLE
LPB3028A(config)# no ipv6 mld snooping
LPB3028A(config)#
4-1.35.19 JSON
JSON-RPC related configuration
SY N TA X
no json notification host <word32> [ | ( begin | exclude | include ) <line> [ <line> ] ]
no json notification listen [ | ( begin | exclude | include ) <line> [ <line> ] ] [<word256> ]
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
87
Page 88
CHAPTER 4: CONFIGURE COMMANDS OF CLI
Parameter
notification JSON-RPC notification configuration
host JSON-RPC notification destination host
listen JSON-RPC notification event subscription
<word32> Name of JSON-RPC notification destination host
| Output modifiers
begin Begin with the line that matches
exclude Exclude lines that match
include Include lines that match
<line> String to match output lines
<word256> Name of JSON-RPC notification to subscript to
EXAMPLE
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
LPB3028A(config)# no json notification listen
LPB3028A(config)#
4-1.35.20 LACP
LACP settings
SY N TA X
no lacp system-priority <1-65535>
Parameter
system-priority System priority
<1-65535> Priority value, lower means higher priority
EXAMPLE
LPB3028A(config)# no lacp system-priority 1
LPB3028A(config)#
88
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 89
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CHAPTER 4: CONFIGURE COMMANDS OF CLI
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
4-1.35.21 LLDP
Link Layer Discover Protocol
SY N TA X
no lldp holdtime
no lldp med datum
no lldp med fast
no lldp med location-tlv altitude
no lldp med location-tlv civic-addr [ additional-code | additional-info | apartment | block | building | city | country | county | district | floor |
house-no | house-no-suffix | landmark | leading-street-direction | name | p-o-box | plasetype | postal-community-name | room-number |
state | street | street-suffix | trailing-street-suffix | zip-code ]
no lldp med location-tlv elin-addr
no lldp med location-tlv latitude
no lldp med location-tlv longitude
no lldp med media-vlan-policy <0~31>
no lldp reinit
no lldp timer
no lldp transmission-delay
Parameter
Holdtime Sets LLDP hold time (The neighbor switch will discard the LLDP information after ‘hold time’ multiplied with
‘timer’ seconds).
Med Media Endpoint Discovery.
Reinit Sets LLDP reinitialization delay.
timer Sets LLDP TX interval (The time between each LLDP frame transmitted in seconds).
transmission-delay Sets LLDP transmission-delay. LLDP transmission delay (the amount of time that the transmission of LLDP
frames will delayed after LLDP configuration has changed) in seconds.
datum Set datum to default value.
fast Set fast repeat count to default value.
location-tlv LLDP-MED Location Type Length Value parameter
media-vlan-policy Delete a policy.
altitude Setting altitude to default.
civic-addr Civic address information and postal information.
elin-addr Set ELIN address to default value.
latitude Setting Latitude parameter to default.
longitude Setting longitude to default.
<0 - 31> Policy to delete.
additional-code Additional code - Example: 1320300003.
additional-info Additional location info - Example: South Wing.
apartment Unit (Apartment, suite) - Example: Apt 42.
block Neighborhood, block.
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
89
Page 90
CHAPTER 4: CONFIGURE COMMANDS OF CLI
building Building (structure) - Example: Low Library.
city City, township, shi (Japan) - Example: Copenhagen.
country The two-letter ISO 3166 country code in capital ASCII letters - Example: DK, DE or US.
county County, parish, gun (Japan), district.
district City division, borough, city district, ward, chou (Japan).
floor Floor - Example: 4.
house-no House number - Example: 21.
house-no-suffix House number suffix - Example: A, 1/2.
landmark Landmark or vanity address - Example: Columbia University.
leading-street-direction Leading street direction - Example: N.
name Name (residence and office occupant) - Example: John Doe.
p-o-box Post office box (P.O. BOX) - Example: 12345.
place-type Place type - Example: Office.
postal-community-name Postal community name - Example: Leonia.
room-number Room number - Example: 450F.
state National subdivisions (state, canton, region, province, prefecture).
street Street - Example: Oxford Street.
street-suffix Street suffix - Example: Ave, Platz.
trailing-street-suffix Trailing street suffix - Example: SW.
zip-code Postal/zip code - Example: 2791.
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
EXAMPLE
LPB3028A(config)# no lldp holdtime
LPB3028A(config)# no lldp med location-tlv civic-addr floor
LPB3028A(config)# no lldp reinit
LPB3028A(config)# no lldp timer
LPB3028A(config)# no lldp transmission-delay
LPB3028A(config)#
4-1.35.22 LOGGING
System logging message
SY N TA X
no logging host
no logging notification listen [ <kword127> ]
no logging on
90
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 91
CHAPTER 4: CONFIGURE COMMANDS OF CLI
Parameter
host host
notification notification
on Enable Switch logging host mode
listen listen
<kword127> A name identifying the listen command
EXAMPLE
LPB3028A(config)# no logging host 3
LPB3028A(config)# no logging on
LPB3028A(config)#
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
4-1.35.23 LOOP-PROTECT
Loop protection configuration
SY N TA X
no loop-protect [ shutdown-time | transmit-time ]
Parameter
shutdown-time Loop protection shutdown time interval
transmit-time Loop protection transmit time interval
EXAMPLE
LPB3028A(config)# no loop-protect shutdown-time
LPB3028A(config)# no loop-protect transmit-time
LPB3028A(config)#
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
91
Page 92
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CHAPTER 4: CONFIGURE COMMANDS OF CLI
4-1.35.24 MAC
MAC table entries/configuration
SY N TA X
no mac address-table aging-time [ <0,10-1000000> ]
no mac address-table learning vlan <vlan_list>
no mac address-table static <mac_addr> vlan <vlan_id> [ interface { * [ <port_type_list> ] } | { ( GigabitEthernet | 10GigabitEthernet ) <port_
type_list> { [ * | GigabitEthernet | 10GigabitEthernet ] } [ <port_type_list> ] }
Parameter
address-table Mac table entries/configuration
aging-time Mac address aging time
learning Mac Learning
static Static MAC address
<0,10-1000000> Aging time in seconds, 0 disables aging
vlan VLAN
<vlan_list>
<mac_addr> 48 bit MAC address: xx:xx:xx:xx:xx:xx
vlan VLAN keyword
<vlan_id> VLAN IDs 1-4095
interface Select an interface to configure
* All switches or All ports
GigabitEthernet Gigabit Ethernet Ports
10GigabitEthernet 10Gigabit Ethernet Ports
<port_type_list> Port list for all port types
<port_type_list> Port list in 1/1-24
<port_type_list> Port list in 1/1-4
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
EXAMPLE
LPB3028A(config)# no mac address-table aging-time
LPB3028A(config)#
92
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 93
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CHAPTER 4: CONFIGURE COMMANDS OF CLI
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
4-1.35.25 MEP
Maintenance Entity Point
SY N TA X
no mep <uint> [ ais | aps | cc | ccm-tlv ]
no mep <uint> [ client domain ( evc | lsp | vlan ) flow ( <uint> | all ) ]
no mep <uint> dm [ bin] ( fd <2-10>) | ( ifdv <2-10> ) | ( threshold <1-50000> )
no mep <uint> [ ns | overflow-reset | proprietary | synchronized | lb | lck | link-state-tracking | lm-hli | lm-notif | lm-sdeg | lt | performancemonitoring | syslog | vid ]
no mep <uint> lm [ both | flow-counting | oam-counting | rx | tx ]
no mep <uint> lm [ oam-counting ] [ all | y1731 ]
no mep <uint> lm-avail [ maintenance ]
no mep <uint> peer-mep- id ( <uint> | all )
no mep <uint> tst ( rx | tx )
Parameter
<uint> The MEP instance number.
ais Alarm Indication Signal.
aps Automatic Protection Switching protocol.
cc Continuity Check.
ccm-tlv The CCM TLV enable/disable
client Client flow instance number.
dm Delay Measurement.
lb Loop Back.
lck Locked Signal
link-state-tracking Link State Tracking. When LST is enabled in an instance, Local SF or received ‘isDown’ in CCM Interface Status
TLV, will bring down the residence port. Only valid in Up-MEP. The CCM rate must be 1 f/s or faster.
lm Loss Measurement
lm-avail Availability for Loss Measurement
lm-hli High Loss Interval for Loss Measurement
lm-notif Loss Measurement JSON notifications
lm-sdeg Signal Degrade for Loss Measurement
lt Link Trace
peer-mep-id The peer MEP ID
performance-monitoring Performance monitoring Data Set collection (MEF35)
syslog Enable syslog
tst Test Signal
Vid
domain Client flow domain
evc EVC client flow.
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
93
Page 94
CHAPTER 4: CONFIGURE COMMANDS OF CLI
lsp MPLS-TP LSP client flow
vlan VLAN client flow
flow Client flow instance
<uint> Client flow instance number value
all Delete all client flow instances
bin Delay Measurement Binning
ns Nanoseconds
overflow-reset Reset all Delay Measurement results on total delay counter overflow.
proprietary Proprietary Delay Measurement
synchronized Near-end and far-end is real time synchronized.
fd the number of FD Measurement Bins
ifdv the number of IFDV Measurement Bins
threshold the threshold for each Delay Measurement Binning
<2-10> the number of FD Measurement Bins.
<2-10> the number of IFDV Measurement Bins.
<1-50000> the threshold for each Delay Measurement Binning.
both Disable both LM PDU transmission and loss calculation when receiving LM PDUs.
flow-counting Loss Measurement is counting service frames per flow – all priority in one.
oam-counting Loss Measurement is counting OAM frames either as Y1731 or all
rx Disable loss calculation when receiving LM PDUs.
tx Disable LM PDU transmission (default).
all Loss Measurement is counting all OAM frames as service frames.
y1731 Loss Measurement is counting OAM frames as service frames as described in Y1731.
maintenance Availability Maintenance indicator.
<uint> The peer MEP ID value.
all All peer MEP IDs will be deleted.
rx Receive Test Signal.
tx Transmit Test Signal.
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
EXAMPLE
LPB3028A(config)# no mep 1 lm rx
LPB3028A(config)#
94
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 95
CHAPTER 4: CONFIGURE COMMANDS OF CLI
4-1.35.26 MONITOR
Monitoring different system events
SY N TA X
no monitor session <1-5>
no monitor session <1-5> destination [ interface { * [ <port_type_list> ] } | { ( GigabitEthernet |
10GigabitEthernet ) <port_type_list> { [ * | GigabitEthernet | 10GigabitEthernet ] } [ <port_type_list> ] }
no monitor session <1-5> destination remote
no monitor session <1-5> source cpu [ both | rx | tx ]
no monitor session <1-5> source interface * ( [ <port_type_list> ] | [ both ] | [ rx ] | [ tx ] )
no monitor session <1-5> source interface [ ( GigabitEthernet | 10GigabitEthernet ) <port_type_list> ]
no monitor session <1-5> source remote
no monitor session <1-5> source vlan <vlan_list>
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
Parameter
session Configure a MIRROR session
<1-5> MIRROR session number
destination MIRROR destination interface, or VLAN
source MIRROR source interface, VLAN
interface MIRROR destination interface
remote MIRROR destination Remote
* All switches or All ports
GigabitEthernet Gigabit Ethernet Ports
10GigabitEthernet 10Gigabit Ethernet Ports
<port_type_list> Port list for all port types
<port_type_list> Port list in 1/1-24
<port_type_list> Port list in 1/1-4
cpu MIRROR source CPU
interface MIRROR source interface
remote MIRROR source Remote
vlan MIRROR source VLAN
both MIRROR source CPU receive both
rx MIRROR source CPU receive Rx
tx MIRROR source CPU receive Tx
both MIRROR source receive both
rx MIRROR source receive Rx
tx MIRROR source receive Tx
<vlan_list> MIRROR source VLAN list
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
95
Page 96
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CHAPTER 4: CONFIGURE COMMANDS OF CLI
EXAMPLE
LPB3028A(config)# no monitor session 1 destination
LPB3028A(config)#
4-1.35.27 MVR
Multicast VLAN Registration configuration
SY N TA X
no mvr [ ( name <word16> ) | ( vlan <vlan_list> ) ] [ channel | election | ( frame ( priority | tagged ) ) | igmp-address | last-member-queryinterval | mode ]
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
Parameter
name MVR multicast name
vlan MVR multicast VLAN
<word16> MVR multicast VLAN name
channel MVR channel configuration
election Act as an IGMP Querier to join Querier-Election
frame MVR control frame in TX
igmp-address MVR address configuration used in IGMP
last-member-query-interval Last Member Query Interval in tenths of seconds
mode MVR mode of operation
priority Interface CoS priority
tagged Tagged IGMP/MLD frames will be sent
EXAMPLE
LPB3028A(config)# no mvr
LPB3028A(config)#
96
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 97
CHAPTER 4: CONFIGURE COMMANDS OF CLI
4-1.35.28 MVRP
none
SY N TA X
no mvrp
EXAMPLE
LPB3028A(config)# no mvrp
LPB3028A(config)#
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
4-1.35.29 NTP
Configure NTP.
SY N TA X
no ntp
no ntp server <1-5>
Parameter
server Configure NTP server
<1-5> index number
EXAMPLE
LPB3028A(config)# no ntp server 2
LPB3028A(config)#
4-1.35.30 POE
Power Over Ethernet
SY N TA X
no poe [ capacitor-detect | management mode | ping-check | profile id <1-16> ]
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
97
Page 98
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CHAPTER 4: CONFIGURE COMMANDS OF CLI
Parameter
capacitor-detect Disable capacitor detection
management Use management mode to configure PoE power management method.
ping-check Enable POE Ping Check.
profile erase poe scheduling profile
supply Specify the maximum power the power supply can deliver. Max power supply for a single PoE controller board
is 180W and for a dual PoE controller board is 90W.
mode mode
ping-check Enable POE Ping Check.
profile erase poe scheduling profile
id erase poe scheduling profile id
<1-16> profile id from 1 to 16
EXAMPLE
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
LPB3028A(config)# no ntp server 2
LPB3028A(config)#
4-1.35.31 PORT-SECURIT Y
Port Security
SY N TA X
no port-security ( aging | hold ) [ time ]
Parameter
aging Enable/disable port security aging.
hold Configure hold options
time Time in seconds between check for activity on learned MAC addresses.
time Violating MAC addresses are held non-forwarding for 300 seconds
EXAMPLE
LPB3028A(config)# no port-security hold
LPB3028A(config)#
98
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
Page 99
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CHAPTER 4: CONFIGURE COMMANDS OF CLI
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
4-1.35.32 PRIVILEGE
Command privilege parameters
SY N TA X
no privilege <cword> level <0-15> <line128> [ <line128> ]
Parameter
<cword> Valid words are ‘config-vlan’ ‘configure’ ‘dhcp-pool’ ‘exec’ ‘if-vlan’ ‘interface’ ‘ipmc-profile’ ‘json-noti-host’ ‘line’ ‘llag’
‘qos-map-egress’ ‘qos-map-ingress’ ‘router-if’ ‘snmps-host’ ‘stp-aggr’
level Set privilege level of command
<0-15> Privilege level
<line128> Initial valid words and literals of the command to modify, in 128 characters
EXAMPLE
LPB3028A(config)# no privilege config-vlan level 1
LPB3028A(config)#
4-1.35.33 PROMPT
Default the prompt to hostname
SY N TA X
no prompt
Parameter
none
EXAMPLE
LPB3028A(config)# no prompt
LPB3028A(config)#
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
99
Page 100
NEED HELP?
LEAV E TH E TEC H TO US
LIVE 24/7
CHAPTER 4: CONFIGURE COMMANDS OF CLI
4-1.35.34 PTP
Precision time Protocol (1588)
SY N TA X
no ptp
no ptp <0-3> [ afi–announce | afi-sync | clk | domain | localpriority | log | path-trace-enable | priority1 | priority2 | servo displaystates
| uni <0-4> ]
no ptp <0-3> mode [ bcfrontend | boundary | e2etransparent | master | p2ptransparent | slave ]
no ptp <0-3> virtual-port [ accuracy | class | local-priority | priority1 | priority2 | variance ]
no ptp <0-3> virtual-port io-pin [ | ( begin | exclude | include ) <line> ] <line>
no ptp [ ext | ho-spec | system-time ]
no ptp io-pin <0-3>
TECHNICAL
SUPPORT
1. 8 7 7. 8 7 7. 2 2 69
Parameter
<0-3> Instance number: 0-3
ext Set the 1PPS and External clock output configuration and VCXO frequency rate adjustment option to default
values
ho-spec Clear the Holdover specification for G8275 PTP clocks
io-pin Clear input/output pin configuration (i.e disable the pin)
system-time Disable synchronization between PTP and System time
afi-announce Disable PTP Announce automatic frame injection
afi-sync Disable PTP Sync automatic frame injection
clk Set PTP slave clock options to free running
domain Default Clock domain
localpriority Default Clock local priority
log Disable the PTP debug logging
mode Delete PTP clock instance
path-trace-enable Disable path trace option (i.e. no Path Trace added to Announce messages)
priority1 Default Clock priority 1
priority2 Default Clock priority 2
servo Set Servo parameters
uni Clear a Unicast Slave configuration entry
virtual-port
bcfrontend Delete if Boundary clock front end
boundary Delete if boundary clock
e2etransparent Delete if e2e TC
master Delete if master only
p2ptransparent Delete if p2p TC
slave Delete if slave only
displaystates Enable logging of servo parameters on the console
100
1. 8 7 7. 87 7. 2 2 69 BLACKBOX.COM
