Data Sheet
Digital Storage Oscilloscopes
2550 Series
The 2550 series digital storage oscilloscopes
provide high performance and value in 2-channel
and 4-channel configurations. With bandwidth
from 70 MHz to 300 MHz and 2 GSa/s sample
rates, these oscilloscopes offer 24 kpts/Ch
waveform memory, 32 automatic measurements,
and advanced triggering capabilities including
math functions. Engineered to allow you to see
more of your signal under test, the 2550 series’
widescreen 7” TFT display offers a significantly
larger viewing area than typical economy
oscilloscopes (5.7”).
Maximize productivity with PC connectivity via
LAN and USB. The downloadable PC software
lets you easily capture, save, and analyze
measurement results. All oscilloscope parameters
can be controlled via a PC without the need for
programming.
Additionally, these oscilloscopes can be
integrated with AWGs using B&K Precision's
waveform editing software, WaveXpress.
WaveXpress allows users to easily modify
waveforms downloaded from the scope and
can also be used for analysis of deep memory
acquisitions.
Educators who want to teach waveform
measurement fundamentals can benefit from
the ability to disable the Auto set button, a
function that automatically sets up the scope
to display a signal.
The 2550 series oscilloscopes are ideal for
applications in design and debug, service and
repair, and education.
Features & Benefits
■ Bandwidth up to 300 MHz
■ 2 GSa/s sample rate
■ 4-channel acquisition (on select models)
■ Large 7” widescreen color display
■ FFT including four additional math
functions - Add, Subtract, Multiply, and
Divide
■ 32 automatic measurements
■ 50 Ω input coupling (200 MHz and 300
MHz models)
■ Standard LAN (supports SCPI) and USB
device port (USBTMC compliant)
■ Front and rear panel USB host port for saving
and recalling waveform setups, data, and
screenshots on a USB flash drive
■ Software provided for remote PC control
■ Advanced tools include digital filters with
adjustable limits, pass/fail testing and
waveform recorder mode
■ Multi-language user interface and context
sensitive help
Model 2552 2553 2554 2555 2556 2557 2558 2559
Bandwidth 70 MHz 100 MHz 200 MHz 300 MHz
Channels 2 4 2 4 2 4 2 4
For more information, visit www.bkprecision.com/WaveXpress
Technical data subject to change
© B&K Precision Corp. 2013
www.bkprecision.com
Digital Storage Oscilloscopes
2550 Series
Front panel
Widescr ee n disp la y
The 7" widescreen color
display lets you see more
of your signal.
US B host p ort
Connect your USB flash
drive to conveniently
store and recall waveform data, setups, and
screenshots.
Me nu On/Of f button
Configure the menu
parameters and hide the
menu with the push of a
button to view your signal
in full screen.
Pr int b utton
Simply press the Print
button to save a
screenshot in bitmap
format to a USB flash
drive.
Context sens it ive h elp
A pop up window will
display the functionality of
a control while help mode
is active.
Wavefor m ana lysis with math
and F FT
Analyze your signals with add, subtract,
multiply, and divide functions. View the
signal’s frequency spectrum and perform
harmonic distortion analysis.
Au to setup
Vertical, horizontal,
and trigger controls
are automatically
adjusted for fast signal
display.
Ad van ced tr ig ge ring
Isolate the signal with
advanced triggering
including pulse width and
selectable video trigger.
Intui ti ve ch annel
opera ti on
All channels in the 2550
series are clearly indicated
by their own color, labeled
on the input, knobs, and
display.
Rear panel
2
Kensi ng ton s ecurity sl ot
Helps to secure your
oscilloscope and prevent theft.
USB host port
Additional USB port on rear
for data storage to a USB flash
drive.
Co mm unica ti on
LAN and USB ports enable
remote control from a PC.
www.bkprecision.com
Digital Storage Oscilloscopes
2550 Series
The tools you need
Powerful measurement functions Digital filtering
Filter OFF
Filter ON
Display and measure the input signal’s frequency spectrum. Select
one of the 4 FFT windows: Rectangular, Hanning, Hamming, and
Blackman. Use cursors to measure the spectral component’s
Filter out unwanted signal components such as various types of noise
with built-in digital filters. Choose from Low-Pass, High-Pass,
Band-Pass, and Band-Stop filters.
magnitude and frequency.
Waveform recorder Delayed sweep/zoom
Monitor and analyze long-term signal behavior by recording data
continuously over an extensive period of time and playing it back for
post acquisition analysis. Data is recorded in a sequence of up to
Use the oscilloscope’s delayed sweep feature to zoom in a particular
area of a signal in real time while viewing the entire captured
waveform simultaneously.
2500 frames.
Large internal storage Pass/Fail testing
Minimize debug time by saving and recalling setups and waveforms
from internal memory. Save and recall up to 20 different oscilloscope
setups and 20 different waveforms.
3
Generate user-defined pass/fail limits to quickly identify go/no go
test results.
www.bkprecision.com
Digital Storage Oscilloscopes
2550 Series
PC connectivity
PC software is provided (free download at B&K
Precision’s website at www.bkprecision.com) for
seamless integration between the oscilloscope
and PC. Capture and transfer waveforms, screen
images, setups and measurement results to a
Windows PC via the USB device port on the
back of the instrument. A USB host port on the
front and rear allows for quick and easy screen
saving.
High bandwidth passive oscilloscope probes
PR250B & PR500BPR150B
Avoid limiting the bandwidth of your measurement system. All 2550 series models come standard with
high bandwidth, slimline passive probes (one per channel) to help you get the most out of your scope.
Features
■ Slim, stylish body
■ Snap-locking sprung hook
■ Easily replaceable tip
■ Large accessory set
■ Meets IEC 61010-031 CATII
■ RoHS compliant
Model Included Probes
2552 two 150 MHz bandwidth, x1/x10 probes (model PR150B)
2553 four 150 MHz bandwidth, x1/x10 probes (model PR150B)
2554 two 150 MHz bandwidth, x1/x10 probes (model PR150B)
2555 four 150 MHz bandwidth, x1/x10 probes (model PR150B)
2556 two 250 MHz bandwidth, x10 probes (model PR250B)
2557 four 250 MHz bandwidth, x10 probes (model PR250B)
2558 two 500 MHz bandwidth, x10 probes (model PR500B)
2559 four 500 MHz bandwidth, x10 probes (model PR500B)
4
www.bkprecision.com
Digital Storage Oscilloscopes
2550 Series
Specifications 2552 2553 2554 2555 2556 2557 2558 2559
Performance Characteristics
Bandwidth 70 MHz 100 MHz 200 MHz 300 MHz
Real Time Sampling Rate
2 GSa/s (half-channel interleaved)
Channels 2 4 2 4 2 4 2 4
Rise Time < 5 ns < 3.5 ns < 1.8 ns < 1.2 ns
Ch to Ch Isolation
(Both channels in same V/div setting)
Max Memory Depth
>100:1 at 35 MHz >100:1 at 50 MHz >100:1 at 100 MHz >100:1 at 150 MHz
24 kpts (half-channel interleaved)
Vertical Resolution 8 bit
Vertical Sensitivity 2 mV/div -10 V/div (1-2-5 order)
DC Gain Accuracy
＜±3.0%: 5 mV/div to 5 V/div in fixed gain ranges
＜±4.0%: 2 mV/div in variable gain ranges
Maximum Input Voltage 400 V (DC+AC pk-pk, 1 MΩ input impedance, X10), CAT I, 5 Vrms (50 Ω input impedance)
Position Range
2 mV–100 mV: ±800 mV
102 mV – 5 V: ±40 V
Bandwidth Limit 20 MHz ±40% (Note: BW limited below 20 MHz when using probe in X1)
Horizontal Scan Range 5 ns/div – 50 s/div 2.5 ns/div – 50 s/div 1 ns/div – 50 s/div
Timebase Accuracy ±100 ppm measured over 1 ms interval
Input Coupling AC, DC, GND
Input Impedance 1 MΩ ± 2% || 13 pF ± 3 pF
Vertical and Horizontal Zoom Vertically or horizontally expand or compress a live or stopped waveform
I/O Interface
USB Front and rear USB host ports support USB flash drives, USBTMC compliant USB device port for connecting to PC
LAN Supports SCPI commands for remote control
Pass/Fail Pass/Fail output
Acquisition Modes
Sampling Display sample data only
Peak Detect Capture the maximum and minimum values of a signal
Average Waveform averaged, selectable from 4, 16, 32, 64, 128, 256
Trigger System
Edge, Pulse Width, Video*, Slope, Alternative
Trigger Types
*Support signal Formats: PAL/SECAM, NTSC
Trigger condition: odd field, even field, all lines, or line number
Trigger Modes Auto, Normal, Single
Trigger Coupling AC, DC, LF reject, HF reject
Trigger Source CH1, CH2, CH3, CH4, EXT, EXT/5, AC Line
Pulse Width Trigger
Slope Trigger
Trigger Modes: Positive Pulse (＞,＜, ＝), Negative Pulse (＞, ＜, ＝)
Positive slope (＞,＜, ＝), Negative slope (＞,＜, ＝)
Time: 20 ns-10 s
CH1 trigger type: Edge, Pulse, Video, Slope
Alternate Trigger
CH2 trigger type: Edge, Pulse, Video, Slope
CH3 trigger type: Edge, Pulse, Video, Slope
CH4 trigger type: Edge, Pulse, Video, Slope
Notes:
(1) On 4-Ch models, Ch1 and Ch2 are interleaved, and Ch3 and Ch4 are interleaved. Half channel operation means that only Ch1 or Ch2 and/or only Ch3 or Ch4 is active.
(2) When timebase is 25 ns or faster and maximum data depth mode is enabled.
(1)
, 1 GSa/s (per channel)
(1)(2)
, 12 kpts (per channel)
1 MΩ ± 2% || 13 pF ± 3 pF,
50 Ω ± 2%
5
www.bkprecision.com
Digital Storage Oscilloscopes
2550 Series
Specifications 2552 2553 2554 2555 2556 2557 2558 2559
Hardware Frequency Counter
Reading Resolution 6 digits
Accuracy ± 0.01%
Range DC couple, 10 Hz to MAX bandwidth
Signal Types Satisfying all trigger signals (except pulse width trigger and video trigger)
Waveform Math and Measure
Math Operation Add, Subtract, Multiply, Divide, FFT
FFT
Vpp, Vmax, Vmin, Vamp, Vtop, Vbase, Vavg, Mean, Crms, Vrms, ROV, FOV, RPRE, FPRE,
Measure
Cursors
FREQ, Period, Rise Time, Fall Time, BWid, + Wid, - Wid, + Duty, - Duty, Phase, FRR, FRF,
Types Voltage, Time
Measurements ΔV, ΔT, 1/ΔT (frequency)
Display System
Display 7 in. Color TFT, 480 x 234 resolution, 64K color
Display Contrast (Typical state) 150:1
BacklightIintensity (Typical state) 300 nit
Wave Display Range 8 x 18 div
Wave Display Mode Dots, Vector
Persistence Off, 1 sec, 2 sec, 5 sec, Infinite
Menu Display 2 sec, 5 sec, 10 sec, 20 sec, Infinite
Screen-Saver Off, 1 min, 2 min, 5 min, 10 min, 15 min, 30 min, 1 hr, 2 hr, 5 hr
Waveform Interpolation Sin(x)/x, Linear
Color Mode Normal, Invert
Environmental and Safety
Temperature
Humidity
Altitude
Electromagnetic Compatibility
Safety Low voltage directive 2006/95/EC, EN61010-1:2001
General
Power Requirements 100-240 VAC, CAT II, 50 VA max, 45 Hz to 440 Hz
Dimensions (W x H x D) 14.1” x 6.14” x 4.65” (358 x 156 x 118 mm)
Weight
Supplied Accessories User manual, passive probes (one per channel), power cord, certificate of calibration, USB (Type A to B) communication cable
Window mode: Hanning, Hamming, Blackman, Rectangular
Sampling points: 1024
FFR, FFF, LRR, LRF, LFR, LFF
Operating: 50° F to 104 °F (10 °C to +40 °C)
Not operating: -4 °F to 140 °F (-20 °C to +60 °C)
Operating: 85%RH, 104 °F (40 °C), 24 hours
Not operating: 85%RH, 149 °F (65 °C), 24 hours
Operating: 9,842.5 ft (3,000 m)
Not operating: 50,085.3 ft (15,266 m)
EMC Directive 2004/108/EC,
EN61326:2006
2-channel models: Approx. 9.5 lbs (4.3 kg)
4-channel models: Approx. 9.9 lbs (4.5 kg)
Three-Year Warranty
6 www.bkprecision.com
v040513
