Helmet Communicator
UCLEAR-DIGITAL
MOTION INFINITY
User Manual
1
MOTION INFINITY Helmet Communicator
Note
Welcome To UCLEAR-DIGITAL
User Manual
UCLEAR-DIGITAL
2
Contents
Contents --------------------------------------------- 2
Quick User Guide ------------------------------------ 3
Warnings and Safety Instructions ------------------ 7
Features --------------------------------------------- 9
Installation ------------------------------------------ 10
General Operations --------------------------------- 13
Mobile Phone Operations --------------------------- 15
Music Streaming Operations ----------------------- 17
Intercom Operations ------------------------------- 18
Button Configurations Summary ------------------ 19
Status Indicator Configurations Summary -------- 20
Technical Data -------------------------------------- 21
Notices ---------------------------------------------- 22
UCLEAR-DIGITAL
3
Your MOTION at a glance
Up button
Speaker /
charging socket
Down button
Status
indicator
Answer
button
Charge
o To charge, use the provided charging cable connecting it
either to a USB port or to the adaptor provided.
o While charging, the status indicator would show red.
o Upon fully charged, the status indicator would show blue.
Low Battery Indicator
o You would need to charge the helmet communicator when
the status indicator blinks red every 2 seconds with a
beep every minute.
Charger
GENERAL FUNCTIONS
Before using your MOTION unit please charge it first!
Quick User Guide
UCLEAR-DIGITAL
4
Power On
o Hold Answer for 3 seconds.
Power Off
o Hold Answer for 5 seconds.
Reset
o Press all 3 buttons
together.
Volume Up
o Press Up once.
Volume Down
o Press Down once.
Pairing
o Hold Up and Down buttons together for 2 seconds. The
status indicator would alternately blink blue and red.
o From your mobile phone Bluetooth menu, search for
‘MOTION INFINITY’.
o Your phone would prompt you for a passcode, enter
‘0000’.
Quick User Guide
*NOTE: The volumes for mobile phone, music and intercom
functions are controlled separately.
MOBILE PHONE FUNCTIONS
Pairing your HBC100 with your mobile phone
UCLEAR-DIGITAL
5
Answer Incoming Call
o Use voice pickup, say ‘hello’
or ‘pickup’.
OR
o Manually press Answer
button once.
Voice Dial
Last Number Redial
o Hold Answer and Up
button for 2 second.
Reject/ End Incoming Call
o Hold Answer button for 2 seconds.
3 Way Calling
o To swap between 2
concurrent calls, press
the Answer button once.
MUSIC STREAMING FUNCTIONS
*NOTE: For music dongles you would need to pair the
music dongle before using it with HBC100.
Play/ Stop (Toggle
Functions)
o Press the Answer button
2 times.
Pairing (for Music
Dongle Only)
o Hold Up and Down buttons
together for 2 seconds.
Quick User Guide
o Hold Answer and Down
button for 2 second.
UCLEAR-DIGITAL
6
INTERCOM FUNCTIONS
Helmet 1
(Master Unit)
Helmet 2
(Secondary Unit)
Pairing (Needs to be done once)
o The helmet communicator needs to be switched off
before performing the following steps:
Press Answer and Down buttons for 5 seconds on
helmet 1 & press Answer and Up buttons for 5
seconds on helmet 2.
Initiate or Terminate Conversation
(Toggle Functions)
o Hold the Up button for 2 seconds.
Fast Forward
o Press the Up button 2
times.
Backtrack
o Press the Down button
2 times.
Quick User Guide
UCLEAR-DIGITAL
7
!
!
Warnings and Safety Instructions
!
This manual uses the and icons to highlight
certain instructions. Below is an explanation of the icons.
- This icon highlights special instructions and precautions
- This icon provides precautions important to prevent injuries to
Attention
- Please read through the operating instructions to understand
Warning
- Please note that there are some countries that by law disallow
- Please note that in some countries the use of both speakers
- Please check with the relevant authorities for local safety
UCLEAR-DIGITAL
Attention
intended to avoid damage to the system. Non-compliance
may void the product warranty.
Warning
the user.
how to operate the system, in particular the safety
instructions.
the rider to set the UCLEAR
volume that prevents you from perceiving the surrounding.
simultaneously is authorised only out of pubic traffic
conditions.
legislation before using the UCLEAR
the road.
TM
helmet communicator to a
TM
helmet communicator on
8
- Prolonged exposure to loud sounds may lead to permanent
!
Warnings and Safety Instructions
hearing damage.
- Do not attempt to place an outgoing call through the mobile
phone while riding on the motorcycle at any point of time.
- Please do not use the UCLEAR
anyway that may distract you or hinder your judgment whilst
on the move. Never ever compromise your safety and the
safety of others.
Attention
- Charging and handling rechargeable battery products
incorrectly may cause them to overheat, catch fire or explode.
To prevent this please follow the instructions below:
i) Never change the batteries yourself, always bring it to an
authorised dealer to perform the replacement for you.
ii)When charging, use ONLY the charging cable provided or a
replacement cable from the UCLEARTM dealer. Using similar,
compatible or any other cables may lead to permanent
product damage and will void the product warranty.
- Never make any modifications to any parts of the UCLEAR
helmet communicator in any way as it may cause the system
to malfunction causing hurt to you.
- Do not modify your helmet to use with this system – it is not
necessary to do so.
TM
helmet communicator in
TM
UCLEAR-DIGITAL
9
Installation
Microphone
The UCLEARTM MOTION helmet communicator package
contains:
o A UCLEAR
control unit
o A pair of hi-fi stereo headset with embedded
microphones
o Velcro for speakers
o A clip bracket and anti slip rubber patch
o A metal mounting bracket with double sided tape
o An AC charger and USB charging cable
o A user manual
Install Speakers
Use the velcros to install the
speakers into the ear cavity of the
helmet.
The microphones MUST be placed
facing out.
Left and right speakers must be
installed symmetrically.
TM
MOTION helmet communicator
UCLEAR-DIGITAL
10
Installation
Your UCLEARTM MOTION helmet communicator package
comes with 2 types of mounting bracket: a clip bracket
and a metal mounting bracket. Use either of the
brackets to install the MOTION control unit onto your
helmet.
Install Clip Bracket
Position and fasten the clip bracket onto the helmet.
When in the correct position, the clip bracket should be firmly
secured onto the helmet.
Use additional anti slip rubber patch provided if required.
Remove the metal handles after clip bracket has been
installed.
UCLEAR-DIGITAL
11
Installation
Install Metal Mounting Bracket
Identify a position on the helmet to adhere the Metal
Mounting Bracket.
Peel off the double sided tape protective film.
Carefully place the Metal Mounting Bracket onto the position
identified in step 1. (You may only do this step once)
Apply slight pressure onto the metal mounting bracket to
ensure that the metal mounting bracket is firmly secured.
Install Main Unit
Slide main unit onto the clip bracket. You should hear a ‘click’
sound when fully inserted.
Fully insert the speaker USB connector.
UCLEAR-DIGITAL
12
Up button
Speaker /
charging socket
Down button
Status
indicator
Answer
button
General Operations
Your UCLEARTM MOTION helmet communicator is now
setup and ready to go!
The operations described here are applicable to all modes
of operations.
Power On
Hold the Answer button for 3 seconds to power on the helmet
communicator. The status indicator will blink blue and a
power up tone can be heard.
Power Off
To switch off the helmet communicator, press and hold the
Answer button for 5 seconds. The status indicator will blink
red 5 times followed by a long beep before fully shutting
down.
Power Save Mode (Auto Power Off)
If intercom had been in use before, and all other Bluetooth
devices have been disconnected, the system will auto
shutdown in 2 hour. Else system would auto power off after
10 minutes of not connecting to any other device.
Low battery
When the battery level is low, the status indicator would flash
red every 2 seconds while emitting a warning beep every
minute.
UCLEAR-DIGITAL
13
General Operations
Charging the Unit
To charge the helmet communicator, connect the provided
charging cable to the speaker/ charging socket. Upon
charging, if the unit is on, system would automatically initiate
power down.
Volume Control
The volume control of the helmet communicator can be
controlled using the Up and Down buttons. Pressing the Up or
Down button one time would increase or reduce the volume
respectively. The volume control for each mode is
independent of each other.
Automatic Speaker Loudness (Communication only)
The speaker loudness will be automatically adjusted
depending on the environment noise level. However you can
still adjust the volume manually.
Automatic Pairing
The helmet communicator has the ability to connect to the
last paired device automatically for two features – music and
mobile phone.
Automatic pairing of the helmet communicator with music
dongles is dependent on the music dongle.
Automatic Profile Switch
The helmet communicator supports multiple profiles
concurrently, but at any point of time only one profile is
active. The automatic profile switch determines which profile
should be active at any point of time starting from the highest
priority: (1) Mobile Phone functions (2) Intercom functions
and (3) Music functions.
UCLEAR-DIGITAL
14
Mobile Phone Operations
To use the helmet communicator with your mobile phone
for the first time, you must first connect them wirelessly
by pairing.
Pairing
To connect the helmet communicator to a mobile phone, hold
the Up and Down buttons for 2 seconds. This puts the helmet
communicator into paring mode. The status indicator would
blink blue and red alternately.
Next, turn on the mobile phone Bluetooth functions and
search for Bluetooth devices. Select ‘MOTION INFINITY’ to
pair with the desired device.
When prompted to enter a passcode, enter ‘0000’.
*Most mobile phones when paired would be automatically
connected with both phone and music Bluetooth capabilities.
After pairing the helmet communicator to your mobile
phone, you may now use the helmet communicator to
answer your calls or make outgoing calls or listen to
music.
Voice Activated Pick Up Calls
When a call comes to the mobile phone, say ‘hello’ or ‘pick-
up’ to answer the call OR Press the Answer button once.
Reject Calls
To reject an incoming call or an incorrectly placed outgoing
call hold the Answer button for 2 seconds.
Voice Call
UCLEAR-DIGITAL
15
Mobile Phone Operations
To activate voice call, hold the Down and Answer buttons for
2 second. The accuracy of this function is dependent on the
mobile phone.
Last Number Redial
To redial the last number, hold the Up and Answer buttons for
2 second. The capability of this function is dependent on the
mobile phone used.
3 way calling
Whilst on a call, if an incoming call comes in, you may answer
the call by pressing the Answer button once.
To swap between 2 concurrent calls, press the Answer button
once.
To end a call during a 3 way call, holding the Answer button
for 2 seconds would end the active call. Upon terminating the
active call, the call on hold would automatically be the active
call.
Music feature
If the mobile phone supports A2DP/AVRCP profile, user may
activate the music by playing it directly from the phone or by
using controlling the phone via the helmet. To operate refer
to Music Streaming Operations section. Should the
documented steps do not work, refer to the phone user
manual on how to activate the A2DP/ACRCP feature.
UCLEAR-DIGITAL
16
Music Streaming Operations
To use the helmet communicator with your music dongle
you must connect them first wirelessly first by pairing.
This step is only required for music streaming dongles.
Pairing
To connect the helmet communicator to a music dongle, hold
the Up and Down buttons for 2 seconds. This puts the helmet
communicator into paring mode. The status indicator would
blink blue and red alternately.
Next, put the music dongle to pairing mode. Both the helmet
communicator should automatically bind to each other.
After pairing the helmet communicator to a music dongle, you
may use the helmet communicator to listen to the music stored
in the music player connected to the dongle.
In order to use the helmet communicator to remotely control
the music streaming device, the music dongle /music streaming
device needs to have Bluetooth Audio/Video Remote Control
capability, AVRCP profile.
Play & Stop
The Play and Stop command is a toggle function. To play
music press the Answer button 2 times. Pressing the Answer
button 2 two times whilst music is playing would stop it.
Fast Forward
To skip to the next track, press the Up button 2 times.
Backtrack
To skip to previous track, press the Down button 2 times.
UCLEAR-DIGITAL
17
Intercom Operations
2-Party Intercom
To use the intercom for the first time, you must let the
communicators to recognize each other through pairing.
Pairing process needs to be carried out only once.
Pairing
With both helmet communicators powered off, hold for 5 seconds
Answer and Down buttons on one helmet and Answer and Up
buttons on the other. The indicators of both helmets would
blink purple.
When one of the communicator’s status indicator turns blue,
the pairing process is completed. (the other communicator
will still blink purple but just ignore it )
It is recommended to restart the devices after the pairing
process.
Start Intercom
To enable the intercom, hold the Up button for 2 seconds.
Stop Intercom
To disable the intercom, hold the Down button for 2 seconds.
UCLEAR-DIGITAL
18
Intercom Operations
Large Group Intercom (3-party or more)
You can daisy-chain multiple MOTION units to form bigger
group intercom. A chain of 10 or more parties is achievable.
To setup group intercom, you must first allow all the MOTION
units to recognize each other through pairing process. Pairing
process needs to be carried out only once.
Pairing
1. Power off all the MOTION communicators first.
2. Pick one unit as the 1
button for 5 seconds. The status indicator would blink
purple.
3. For the 2nd device, press Answer and Up buttons for 5
seconds. The status indicator would blink purple. Wait until
the 1st device status indicator turns blue, then proceed to
pair the next device.
4. Press 5 seconds Answer and Up buttons on the 3
status indicator will blink purple. Wait for the 2nd device
status indicator to turn blue, then proceed to pair the next
device.
5. Repeat 4 for all other units until all the devices are paired.
6. The last device will remain blinking in purple. You can press
any button on the device to end the pairing process, the
status indicator should turn blue.
It is recommended that after the pairing process is successful,
restart all the helmet communicators.
Start Intercom
To start/connect the intercom, hold the Up button for 2
seconds.
All the devices will be chained up automatically, in the
sequence same as the pairing process.
UCLEAR-DIGITAL
st
device, hold Answer and Down
rd
device,
19
Stop Intercom
Intercom Operations
To stop the intercom, hold the Down button for 2 seconds.
All the devices in the chain will be disconnected automatically.
Privacy Conversation Mode
During group intercom, you can have privacy conversation with
the member who has performed a 2-party intercom pairing with
you before.
For example, to setup privacy conversation with your passenger
1. Perform a 2-party pairing with your passenger first.
2. Perform a group intercom pairing with all other members.
During the pairing process, please ensure your device and
the passenger’s device is in consecutive order.
If group intercom is currently active
To start private conversation
Press the Answer button once
Both party will hear a beep tone and you are in privacy
conversation mode
To end private conversation
Both party stop talking for 5 seconds.
You will hear a double beep tone when the system exits
privacy mode
If group intercom is currently not connected and inactive
To connect
Press Answer button 2 seconds
(Note: pressing Up button 2 seconds will trigger auto-chain
reaction, all group members will be connected)
To disconnect
UCLEAR-DIGITAL
20
Press down button 2 seconds
Intercom Operations
Intercom, Phone Call and Music Switching
All the intercom units can be connected to phone during
operation.
Phone call has the highest priority. If you are currently in
intercom mode, incoming call will interrupt the intercom and
after the phone call, intercom will be resumed immediately. If
you are currently having a phone call, incoming intercom
request will be rejected.
Music has the lowest priority. If you are in music mode,
incoming intercom request will stop the music and you will be
connected to intercom. If you need to switch from intercom to
music mode, you need to disconnect from the intercom by
pressing the down button 2 seconds, music will resume
automatically after that.
Other Functions
Firmware Upgrade
Please check up www.uclear-digital.com for new firmware
update
UCLEAR-DIGITAL
21
Action
Button
Common Instruction Commands
Power on
Hold Answer for 2 seconds
Power off
Hold Answer for 5 seconds
Activate Bluetooth pairing
Hold Up & Down for 2 seconds
Volume up
Press Up once
Volume down
Press Down once
Reset
Press Answer, Up & Down together
Voice Calling
Pick up incoming call
Press Answer once
End call in progress
Hold Answer for 2 seconds
Reject incoming call
Hold Answer for 2 seconds
Voice dial
Hold Answer & Down for 2 seconds
Last number redial
Hold Answer & Up for 2 seconds
Music Streaming
Play
Stop
Intercom
(
Pairing as helmet 2
(all subsequent units)
Upon power up, hold Answer and
Up for 5 seconds
Connect intercom
Hold Up for 2 seconds
Disconnect intercom
Hold Down for 2 seconds
Button Configurations Summary
The table below shows the button configurations.
Press Answer 2 times
Press Answer 2 times
Fast forward track Press Up button 2 times
Backtrack Press Down button 2 times
Pairing as helmet 1
1st unit)
UCLEAR-DIGITAL
Upon power up, hold Answer and
Down for 5 seconds
22
State
Status Indicator
1
Off (No power)
-
2
On (BT* not connected)
Blink blue fast
3
On (BT* connected)
Blink blue slowly
4
Phone & Music dongle
Pairing mode
Blink blue & red alternately
5
Call in progress
Blink blue very slowly
6
In-coming call
Blink blue & red
alternately
7
Battery low
Blink red every 2 seconds
8
Power down
Blink red 5 times
9
Intercom connected
Blink blue twice every 2
seconds
10
Intercom Pairing mode
(Answer & down button )
Blink purple slowly
Intercom Pairing mode
(Answer & up button )
Blink purple fast
12
Battery charging
Solid Red
Battery fully charged
Solid Blue
14
Battery faulty
Solid purple
Status Indicator Configurations Summary
The table below shows the status indicator configurations.
11
13
*
BT - Bluetooth
UCLEAR-DIGITAL
23
Unit
Dimensions (L x W x H)
60mm x 40mm x 15mm
Weight
36g
Audio
Frequency response
30Hz to 20kHz
Sampling rate
48kHz, 16 bit
SPL
105dB + 2dB
Bluetooth
Version
V5.0
Profiles
HSP, HFP, A2DP, AVRCP, Intercom
Radio
Carrier frequency
2.402 – 2.480 GHz
Range
Up to 1200m (open field)
Power input (charging)
5V / 400mA / 2W
Music/talk time
Up to 10 hours
Standby time
400 hours
Temperature
Operation temperature
-10°C to +60°C (14°F to +140°F)
Charging temperature
0°C to +45°C (+32°F to +113°F)
Storage temperature
-40°C to +80°C (-38°F to +176°F)
Technical Data
RF output power 19.61 dBm(max)
Power
Power consumption 200mW (max)
Built-in battery 3.7V, 650mAh, Lithium-ion Polymer
UCLEAR-DIGITAL
(Rechargeable)
24
Notices
BATTERY WARNING:
The UCLEAR
lithium ion polymer battery. To reduce risks of fire or burns, do
not disassemble, crush, puncture, short external contacts or
dispose in fire or water.
CHARGING NOTICE:
To reduce the risk of personal injury, electrical shock, fire or
damage to equipments, please follow all the instructions below:
- Do not immerse the product, AC adaptor or speakers in water.
- Do not install, place or use the product near any source of
heat for example: stove, radiator, oven, toaster, coffee maker
or other apparatus that gives off heat.
- Always use the provided AC power adaptor and cable included
in the package to charge the product. Use of any incorrect
power supply to charge the product may cause permanent
damage to the product and render the warranty void.
WARRANTY:
Without prejudice of legal warranty, the product is covered
under a 1 year warranty by manufacturer from the date of
purchase. Please produce the proof of purchase when you
return the item to the supplier.
The warranty covers material and manufacturing defects only.
The warranty is voided by any unauthorized repairs, misuse,
misapplication, tampering of the product, modifications,
upgrading or results of any failures to follow the guidelines as
set out in the product brochure or by any of the actions
specified in this brochure or anywhere in our technical
publishing released to the public from time to time which would
have voided the warranty.
Warranty does not cover data recovery and physical
deterioration due to use, damages resulting from accidents,
storage, loss or data loss or damage during repairs or transits.
TM
helmet communicator contains a rechargeable
UCLEAR-DIGITAL
25
Notices
The sender will bear all transportation charges for functioning
products but which were declared defective.
LIMITATIONS OF WARRANTY:
All product warranties for the product by UCLEARTM are limited to
those mentioned in the product manual.
WAIVER AND DISCLAIMER:
BITwave and all their representatives, agents, distributors,
suppliers and resellers shall not be liable and will be held
harmless from any and all litigation, claims, debts, demands,
actions and liability which may arise, directly or indirectly, from
operating or using the product for any damages, losses,
distress, pain, suffering, discomfort, loss and injuries including
bodily harm illness, strains, fractures, partial and/or total
paralysis, death or other ailments that could cause serious
disability either to any persons, or any parties whether the user
or other third parties or their possessions, or to any goods,
vehicles, properties, assets among others including your own
suffered by any persons, organizations, or any third parties
whether physical or otherwise and which may accrue to you in
the future, to the fullest extent permitted by law as a result of
the use, operation, malfunctioning, misuse, disposal or repairs
of the product or any other reasons, conditions or circumstances
or attempts to do so whether due negligence, omissions or
otherwise of BITwave or any of their representatives, partners,
agents, distributors, suppliers, resellers, designer, manufacturer
or any others in its supply and distribution chain or any third
parties involved.
All risks from operating or usage of the product rest solely and
entirely with the user of this product, the original purchaser or
any third parties, who assumes full responsibility for all injuries,
losses and/ or damages, whether caused in whole or in part by
the negligence, omissions or other conduct of others, including
that of BITwave and all their representatives, partners, agents,
UCLEAR-DIGITAL
26
Notices
Notices
Notices
distributors, suppliers, resellers and all others in its supply and
distribution chain either due to the designer’s or manufacturer’s
negligence or omissions or any third parties involved.
Always comply with the local law and traffic regulations. Where
use of the product is not permitted or allowed by any laws and
regulations including the traffic laws of your country, we warn
you not to go against such restrictions. You will bear the full
responsibilities of any breaches of law and regulations.
You should not allow the operations or use of the product or any
attempts to use it by any persons including yourself to
compromise anyone’s safety including your own or to cause
harm to any vehicles, property, objects, livestock, inventories,
assets and the like under any circumstances. You or any users
of the product are to take all necessary safety measures and
precautions and to remain alert to all surrounding conditions.
You are warned not to operate the product if you are not
physically capable of doing so in a safe manner, if you have or
will consume any alcohol or any mind-altering substance during
its operation so that your alertness is compromised or if you
have any medical conditions or needs that may compromise
your abilities to do so in a safe manner.
We warn you of the inherent, unforeseeable and unlimited risks
and dangers in using the product while in traffic, including injury
or illness, strains, fractures, partial and/or total paralysis, death
or other ailments that could cause serious disability due to any
causes.
This product is only for use by persons eighteen (18) years of
age and above who have understood the warnings, risks and
the terms of use.
You confirm that you have read this release of liability and fully
understand its terms and that you have given up substantial
rights by using or attempting to use the product.
CORRECT DISPOSAL OF THIS PRODUCT:
UCLEAR-DIGITAL
27
Do not dispose this product with other household wastes at the
end of its working life. There is a separate collection system for
used electronic products in accordance with legislation that
requires proper treatment, recovery and recycling.
Household users should contact either the retailer where they
purchased this product, or their local government office, for
details of where and how they can take this item for
environmentally safe recycling. Business users should contact
their suppliers and refer to the terms and conditions of the
purchase contract. This product should not be mixed with other
commercial wastes for disposal.
PRODUCT INFORMATION:
BITwave and all their representatives, agents, distributors,
suppliers or resellers shall not be held responsible for any
consequences arising from any errors or omissions in the guide
or resulting directly or indirectly from the use of the information
herein. BITwave reserveS the right to amend or improve the
product design or user guide without any restrictions and
without any obligation to notify users.
All information here is accurate as of the date of printing.
Please check for the latest version of any the modified or
upgraded product on the website www.uclear-digital.com from
time to time.
PERSONAL SAFETY:
Do not open the seal of the hardware, tamper, repair or modify
any parts. Do not touch the product with metal objects or parts
or chemical products. Violation of the above will lead to
potential fire hazards and mishaps.
Please contact the technical support or your local supplier if
your product malfunctions.
UCLEAR-DIGITAL
28
Notices
TECHNICAL SUPPORT:
For additional information please visit our website at
www.uclear-digital.com
For technical support please contact us at:
technical@uclear-digital.com
COPYRIGHTS:
Copyright © 2010 BITwave Pte Ltd. All rights reserved. No part
of this guide may be reproduced in any form or by any process
whatsoever without prior written consent from BITwave Pte Ltd.
LICENCES:
The UCLEARTM trademark and logo is exclusively owned by
BITwave Pte Ltd. Any use of the mark by any other parties
without prior written permission of BITwave Pte Ltd constitutes
an infringement of legal rights.
The Bluetooth
used under license by BITwave Pte Ltd.
IC SAR STATEMENT
This EUT is compliance with SAR for general
population/uncontrolled exposure limits in IC RSS-102 and had
been tested in accordance with the measurement methods and
procedures specified in IEEE 1528 and IEC 62209. This
equipment should be installed and operated with minimum
distance 0 mm between the radiator and your head. This device
and its antenna(s)must not be co-located or operating in
conjunction with any other antenna or transmitter.
Cet appareil est conforme aux limites d'exposition DAS
incontrôlée pour la population générale de la norme CNR-102
d'Industrie Canada et a été testé en conformité avec les
méthodes de mesure et procédures spécifiées dans IEEE 1528
TM
trademark is owned by Bluetooth SIG and is
UCLEAR-DIGITAL
29
et IEC 62209. Cet équipement doit être installé et utilisé avec
une distance minimale de 0 mm entre le radiateur et votre tête.
Cet appareil et sa ou ses antennes ne doivent pas être colocalisés ou fonctionner en conjonction avec tout autre antenne
ou transmetteur.
FCC/SAR COMPLIANCE STATEMENT
Changes or modifications not expressly approved by the party
responsible for compliance
could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the
limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide
reasonable protection against harmful interference in a
residential installation. This
equipment generates, uses and can radiate radio frequency
energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio
communications. However, there is no guarantee that
interference will not occur in a
particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can
be determined by turning the equipment off and on, the user is
encouraged to try to correct
the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the Equipment into an outlet on a circuit different
from that to which the receiver
is connected.
UCLEAR-DIGITAL
30
-- Consult the dealer or an experienced radio/TV technician for
help.
FCC RF Exposure requirements:
The highest SAR value reported under this standard during product
certification for use next to the head with the minimum separation distance
of 0mm is 0.919W/Kg. This transmitter must not be collocated or operating
in conjunction with any other antenna or transmitter.
This product is compliance to FCC RF Exposure requirements and refers
to FCC website https://apps.fcc.gov/oetcf/eas/reports/GenericSearch.cfm
search for FCC ID: NMC-MOTION
Note: The manufacturer is not responsible for any radio or tv
interference caused by unauthorized modifications to this
equipment. Such modifications could void the user’s authority to
operate the equipment
UCLEAR-DIGITAL
Loading...
