Biostar H61MHV2 User Manual

H61MHV2 Setup Manual
FCC Information and Copyright
This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. There is no guarantee that interference will not occur in a particular installation.
The vendor makes no representations or warranties with respect to the contents here and specially disclaims any implied warranties of merchantability or fitness for any purpose. Further the vendor reserves the right to revise this publication and to make changes to the contents here without obligation to notify any party beforehand.
Duplication of this publication, in part or in whole, is not allowed without first obtaining the vendor’s approval in writing.
The content of this user’s manual is subject to be changed without notice and we will not be responsible for any mistakes found in this user’s manual. All the brand and product names are trademarks of their respective companies.
Dichiarazione di conformità sintetica
Ai sensi dell’art. 2 comma 3 del D.M. 275 del 30/10/2002
Si dichiara che questo prodotto è conforme alle normative vigenti e soddisfa i requisiti essenziali richiesti dalle direttive
2004/108/CE, 2006/95/CE e 1999/05/CE
quando ad esso applicabili
Short Declaration of conformity
We declare this product is complying with the laws in force and meeting all the essential requirements as specified by the directives
2004/108/CE, 2006/95/CE and 1999/05/CE
whenever these laws may be applied
Table of Contents
Chapter 1: Introduction .......................................... 1
1.1 Before You Start......................................................................................... 1
1.2 Package Checklist ..................................................................................... 1
1.3 Motherboard Features .............................................................................. 2
1.4 Rear Panel Connectors .............................................................................. 3
1.5 Motherboard Layout ................................................................................. 3
Chapter 2: Hardware Installation ........................... 4
2.1 Installing Central Processing Unit (CPU) ............................................... 4
2.2 Install a Heatsink ...................................................................................... 6
2.3 FAN Headers .............................................................................................. 7
2.4 Installing System Memory ........................................................................ 8
2.5 Connectors and Slots .................................................................................. 9
Chapter 3: Headers & Jumpers Setup ................... 12
3.1 How to Setup Jumpers ............................................................................ 12
3.2 Detail Settings .......................................................................................... 12
Chapter 4: Useful Help ......................................... 15
4.1 Driver Installation Note .......................................................................... 15
4.2 BIOS Update ............................................................................................. 16
4.3 AMI BIOS Beep Code ............................................................................... 18
4.4 Troubleshooting ....................................................................................... 18
Appendix: SPEC in Other Languages ..................... 21
German ................................................................................................................. 21
French .................................................................................................................. 23
Italian ................................................................................................................ ..25
Spanish .................................................................................................................. 27
Portuguese ............................................................................................................ 29
Polish ................................................................................................................... 31
Russian .................................................................................................................. 33
Arabic .................................................................................................................. 35
Japanese ................................................................................................................ 37
CHAPTER 1: INTRODUCTION
H61MHV2
1.1 B
EFORE YOU START
Thank you for choosing our product. Before you start installing the motherboard, please make sure you follow the instructions below:
Prepare a dry and stable working environment with sufficient
lighting.
Always disconnect the computer from power outlet before
operation.
Before you take the motherboard out from anti-static bag,
ground yourself properly by touching any safely grounded appliance, or use grounded wrist strap to remove the static charge.
Avoid touching the components on motherboard or the rear
side of the board unless necessary. Hold the board on the edge, do not try to bend or flex the board.
Do not leave any unfastened small parts inside the case after
installation. Loose parts will cause short circuits which may damage the equipment.
Keep the computer from dangerous area, such as heat
source, humid air and water.
The operating temperatures of the computer should be 0 to
45 degrees Celsius.
To avoid injury, be careful of:
Sharp pins on headers and connectors Rough edges and sharp corners on the chassis Damage to wires that could cause a short circuit
1.2 PACKAGE CHECKLIST
Serial ATA Cable x2 Rear I/O Panel for ATX Case x1 Quick Installation Guide x1 Fully Setup Driver DVD x1
Note: The package contents may be different due to the sales region or models in which it was sold. For more information about the standard package in your region, please contact your dealer or sales representative.
1
Motherboard Manual
1.3 MOTHERBOARD FEATURES
SPEC
Socket 1155
CPU
Chipset Intel H61
Super I/O
Main Memory
SATA 2 Integrated Serial ATA Controller
LAN RTL8111H 10 / 100 / 1000Mb/s auto negotiation Sound Codec
Slots
On Board Connectors
Rear Panel I/O
Board Size 170 (W) x 191 (L) mm
OS Support Windows XP / Vista / 7 / 8 / 8.1 / 10
Intel Core i7 / i5 / i3 / Pentium / Celeron processor
IT8772E Provides the most commonly used legacy Super I/O functionality Low Pin Count Interface DDR3 DIMM Slots x 2 Max Memory Capacity 16GB Each DIMM supports 512MB/ 1GB/2GB/4GB/8GB DDR3
ALC662 5.1 channels audio out , High Definition Audio
PCI-E Gen3x16 slot x1 (depending on CPU) PCI-E Gen2 x1 slot x1 Supports PCI-E Gen2 x1 expansion card SATA2 Connector x4 Each connector supports 1 SATA2 device Front Panel Connector x1 Supports front panel facilities Chassis Speaker Connector x1 Supports chassis speaker Front Audio Connector x1 Supports front panel audio function CPU Fan Header x1 CPU Fan power supply (with Smart Fan function) System Fan Header x1 System Fan Power supply Clear CMOS Header x1 Restore CMOS data to factory default USB2.0 Connector x2 Each connector supports 2 front panel USB2.0 ports
Serial Port Connector x1 Connects to RS-232 Port
Power Connector (24pin) x1 Connects to Power supply Power Connector (4pin) x1 Connects to Power supply PS/2 Keyboard/ Mouse x1 VGA Port x1 HDMI Port x1 LAN port x1 USB2.0 Port x4 Audio Jack x3
Supports Execute Disable Bit / Enhanced Intel SpeedStep® / Intel Architecture-64 / Extended Memory 64 Technology / Virtualization Technology / Hyper Threading
Environment Control initiatives Hardware Monitor Controller Fan Speed Controller ITE's "Smart Guardian" function Dual Channel Mode DDR3 memory module Supports DDR3 1066 / 1333 Supports DDR3 1600 (depending on CPU) Registered DIMM and ECC DIMM is not supported Data transfer rates up to 3.0 Gb/s SATA Version 2.0 specification compliant
Supports PCI-E Gen2/3 x16 expansion card
Connects to PS/2 Keyboard & Mouse Connect to D-SUB monitor Connect to HDMI monitor Connect to RJ-45 Ethernet cable Connect to USB2.0 devices Provide Audio-In/Out and Mic. Connection
Biostar reserves the right to add or remove support for any OS with or without notice
2
1.4 REAR PANEL CONNECTORS
H61MHV2
Note1: VGA Output requires an Intel Core family processor with Intel Graphics Technology. Note2: VGA Maximum resolution: 2048 x 1536 @75Hz
1.5 MOTHERBOARD LAYOUT
Note1: represents the 1st pin.
3
Motherboard Manual
CHAPTER 2: HARDWARE INSTALLATION
2.1 I
NSTALLING CENTRAL PROCESSING UNIT (CPU)
Step 1: Locate the CPU socket on the motherboard
Note1: Remove Pin Cap before installation, and make good preservation for future use. When
the CPU is removed, cover the Pin Cap on the empty socket to ensure pin legs won’t be damaged. Note2: The motherboard might equip with two different types of pin cap. Please refer below instruction to remove the pin cap.
Step 2: Pull the socket locking lever out from the socket and then raise the lever
up.
Step 3: Remove the Pin Cap.
4
H61MHV2
Step 4: Hold processor with your thumb and index fingers, oriented as shown.
Align the notches with the socket. Lower the processor straight down without tilting or sliding the processor in the socket.
Note: The CPU fits only in one correct orientation. Do not force the CPU into the socket to prevent damaging the CPU.
Step 5: Hold the CPU down firmly, and then lower the lever to locked position to
complete the installation.
5
Motherboard Manual
2.2 INSTALL A HEATSINK
Step 1: Place the CPU fan assembly on top of the installed CPU and make sure
that the four fasteners match the motherboard holes. Orient the assembly and make the fan cable is closest to the CPU fan connector.
Step 2: Press down two fasteners at one time in a diagonal sequence to secure
the CPU fan assembly in place. Ensure that all four fasteners are secured.
Note1: Do not forget to connect the CPU fan connector. Note2: For proper installation, please kindly refer to the installation manual of your CPU heatsink.
6
H61MHV2
2.3 FAN HEADERS
These fan headers support cooling-fans built in the computer. The fan cable and connector may be different according to the fan manufacturer. Connect the fan cable to the connector while matching the black wire to pin#1.
CPU_FAN1: CPU Fan Header
Pin Assignment
1 Ground 2 +12V 3
FAN RPM rate sense
4 Smart Fan Control
(By Fan)
SYS_FAN1: System Fan Header
Pin Assignment
1 Ground 2 +12V 3
FAN RPM rate sense
Note: CPU_FAN1 support 4-pin and 3-pin head connectors. When connecting with wires onto connectors, please note that the red wire is the positive and should be connected to pin#2, and the black wire is Ground and should be connected to GND. SYS_FAN3 support 3-pin head connectors. When connecting with wires onto connectors, please note that the red wire is the positive and should be connected to pin#2, and the black wire is Ground and should be connected to GND.
7
Motherboard Manual
2.4 INSTALLING SYSTEM MEMORY
A. Memory Modules
Step 1: Unlock a DIMM slot by pressing the retaining clips outward. Align a DIMM
on the slot such that the notch on the DIMM matches the break on the slot.
Step 2: Insert the DIMM vertically and firmly into the slot until the retaining chip snap
back in place and the DIMM is properly seated.
Note: If the DIMM does not go in smoothly, do not force it. Pull it all the way out and try again.
8
H61MHV2
B. Memory Capacity
DIMM Socket
Location
DDR3_A1 512MB/1GB/2GB/4GB/8GB
DDR3_B1 512MB/1GB/2GB/4GB/8GB
DDR3 Module
Total Memory
Size
Max is 16GB.
C. Dual Channel Memory Installation
Please refer to the following requirements to activate Dual Channel function: Install memory module of the same density in pairs, shown in the table.
Dual Channel Status
Disabled O X
Disabled X O
Enabled O O
(O means memory installed; X, not installed.)
Note: The DRAM bus width of the memory module must be the same (x8 or x16)
DDR3_A1
DDR3_B1
2.5 CONNECTORS AND SLOTS
SATA1~SATA4: Serial ATA Connectors
These connectors connect to SATA hard disk drives via SATA cables.
Those satisfy the SATA 2.0 spec and with transfer rate of 3.0Gb/s.
Pin Assignment
1 Ground 2 TX+ 3 TX­4 Ground 5 RX­6 RX+ 7 Ground
9
Motherboard Manual
ATXPWR2: ATX Power Source Connector
This connector provides +12V to CPU power circuit.
ATXPWR1: ATX Power Source Connector
This connector allows user to connect 24-pin power connector on the ATX power supply.
Pin Assignment
1 +12V 2 +12V 3 Ground 4 Ground
10
Pin Assignment Pin Assignment
13 +3.3V 1 +3.3V 14 -12V 2 +3.3V 15 Ground 3 Ground 16 PS_ON 4 +5V 17 Ground 5 Ground 18 Ground 6 +5V 19 Ground 7 Ground 20 NC 8 PW_OK 21 +5V 9 Standby Voltage+5V 22 +5V 10 +12V 23 +5V 11 +12V 24 Ground 12 +3.3V
Note1: Before you power on the system, please make sure that both ATXPWR1 and ATXPWR2 connectors have been plugged-in.
Note2: Insufficient power supplied to the system may result in instability or the
peripherals not functioning properly. Use of a PSU with a higher power output is recommended when configuring a system with more power-consuming devices.
H61MHV2
PEX16_1: PCI-Express Gen3 x16 Slot
- PCI-Express 3.0 compliant.
- Maximum theoretical realized bandwidth of 16GB/s simultaneously per
direction, for an aggregate of 32GB/s totally.
- PCI-E 3.0 is supported by Core i7-3xxx / i5-3xxx CPU.
PEX1_1: PCI-Express Gen2 x1 Slot
- PCI-Express 2.0 compliant.
- Data transfer bandwidth up to 500MB/s per direction; 1GB/s in total.
Install an Expansion Card
You can install your expansion card by following steps:
1. Read the related expansion card's instruction document before install the expansion card into the computer.
2. Remove your computer's chassis cover, screws and slot bracket from the computer.
3. Place a card in the expansion slot and press down on the card until it is completely seated in the slot.
4. Secure the card’s metal bracket to the chassis back panel with a screw.
5. Replace your computer's chassis cover.
6. Power on the computer, if necessary, change BIOS settings for the expansion card.
7. Install related driver for the expansion card.
11
Motherboard Manual
CHAPTER 3: HEADERS & JUMPERS SETUP
3.1 H
OW TO SETUP JUMPERS
The illustration shows how to set up jumpers. When the jumper cap is placed on pins, the jumper is “close”, if not, that means the jumper is “open”.
Pin opened Pin closed Pin1-2 closed
3.2 DETAIL SETTINGS
JPANEL1: Front Panel Header
This connector includes Power-on, Reset, HDD LED and Power LED connections. It allows user to connect the PC case’s front panel switch functions.
12
Pin Assignment Function Pin Assignment Function
1 N/A N/A 2 Power LED (+) 3 HDD LED(+) 5 HDD LED(-) 6 Power LED (-) 7 Ground 9 Reset Control 10 Ground
HDD LED
Reset Button
4 Power LED (+)
8 Power Button
Power LED
Power-On Button
H61MHV2
JSPKR1: Chassis Speaker Header
Please connect the chassis speaker to this header.
Pin Assignment
1 +5V 2 N/A 3 N/A 4 Speaker
F_USB1/F_USB2: Headers for USB 2.0 Ports at Front Panel
These headers allow users to connect additional USB cable on the PC front panel, and also can be connected with internal USB devices, like USB card reader.
Pin Assignment
1 +5V (fused) 2 +5V (fused) 3 USB­4 USB­5 USB+ 6 USB+ 7 Ground 8 Ground 9 Key
10 NC
J_COM1: Serial Port Connector
The motherboard has a Serial Port Connector for connecting RS-232 Port.
Pin Assignment
1 Carrier detect 2 Received data 3 Transmitted data 4 Data terminal ready 5Signal ground 6 Data set ready 7 Request to send 8 Clear to send 9 Ring indicator
10 Key
13
Motherboard Manual
2
F_AUDIO1: Front Panel Audio Header
This header allows users to connect the front audio output cable with the PC front panel.
HD Audio AC’97
Pin Assignment Pin Assignment
1 Mic Left in 1 Mic In 2 Ground 2 Ground 3 Mic Right in 3 Mic Power 4 GPIO 4 Audio Power 5 Right line in 5 RT Line Out 6 Jack Sense 6 RT Line Out 7 Front Sense 7 Reserved 8 Key 8 Key 9 Left line in 9 LFT Line Out
10 Jack Sense 10 LFT Line Out
Note1: It is recommended that you connect a high-definition front panel audio module to this connector to avail of the motherboard's high definition audio capability. Note2: Please try to disable the "Front Panel Jack Detection" if you want to use an AC'97 front audio output cable. The function can be found via O.S. Audio Utility.
JCMOS1: Clear CMOS Jumper
The jumper allows users to restore the BIOS safe setting and the CMOS data. Please carefully follow the procedures to avoid damaging the motherboard.
2
1
14
Pin 1-2 Open:
Normal Operation (default).
Pin 1-2 Close:
Clear CMOS data.
1
Clear CMOS Procedures:
1. Remove AC power line.
2. Set the jumper to “Pin 1-2 close”, you can use a metal object like a screwdriver to touch the two pins.
3. Wait for five seconds.
4. After clearing the CMOS values, be sure the jumper is “Pin 1-2 open”.
5. Power on the AC.
6. Load Optimal Defaults and save settings in CMOS.
CHAPTER 4: USEFUL HELP
H61MHV2
4.1 D
RIVER INSTALLATION NOTE
After you installed your operating system, please insert the Fully Setup Driver DVD into your optical drive and install the driver for better system performance. You will see the following window after you insert the DVD
The setup guide will auto detect your motherboard and operating system.
Note: If this window didn’t show up after you insert the Driver DVD, please use file browser to locate and execute the file SETUP.EXE under your optical drive.
A. Driver Installation
To install the driver, please click on the Driver icon. The setup guide will list the compatible driver for your motherboard and operating system. Click on each device driver to launch the installation program.
B. Software Installation
To install the software, please click on the Software icon. The setup guide will list the software available for your system, click on each software title to launch the installation program.
C. Manual
Aside from the paperback manual, we also provide manual in the Driver DVD. Click on the Manual icon to browse for available manual.
Note: You will need Acrobat Reader to open the manual file. Please download the latest version of Acrobat Reader software from http://get.adobe.com/reader/
15
Motherboard Manual
4.2 BIOS UPDATE
There are three ways to update the BIOS: BIOSTAR BIOS Flasher.
Note: The programming procedure may take minutes, please do not make any operation during the programming process.
BIOSTAR BIOS Flasher
BIOSTAR BIOS Flasher is a BIOS flashing utility providing you an easy and simple way to update your BIOS via USB pen drive.
The BIOSTAR BIOS Flasher is built in the BIOS ROM. To enter the utility, press
<F12> during the Power-On Self Tests (POST) procedure while booting up.
Note1: This utility only allows storage device with FAT32/16 format and single partition. Note2: Shutting down or resetting the system while updating the BIOS will lead to system boot
failure.
Updating BIOS with BIOSTAR BIOS Flasher
1. Go to the website to download the latest BIOS file for the motherboard.
2. Then, copy and save the BIOS file into a USB flash (pen) drive.
3. Insert the USB pen drive that contains the BIOS file to the USB port.
4. Power on or reset the computer and then press <F12> during the POST process.
5. After entering the POST screen, the BIOS-FLASHER utility pops out. Choose [fs0] to search for the BIOS file.
16
6. Select the proper BIOS file, and a message asking if you are sure to flash the BIOS file. Click Yes to start updating BIOS.
7. A dialog pops out after BIOS flash is completed, asking you to restart the system. Press the [Y] key to restart system.
H61MHV2
8. While the system boots up and the full screen logo shows up, press <Delete> key to enter BIOS setup.
After entering the BIOS setup, please go to the Save & Exit, using the Restore Defaults function to load Optimized Defaults, and select Save Changes and Reset
to restart the computer. Then, the BIOS Update is completed.
17
Motherboard Manual
4.3 AMI BIOS BEEP CODE
Boot Block Beep Codes
Number of Beeps Description
Continuing Memory sizing error or Memory module not found
POST BIOS Beep Codes
Number of Beeps Description
1 Success booting. 8 Display memory error (system video adapter)
4.4 TROUBLESHOOTING
Probable Solution
1. There is no power in the system. Power LED does not shine; the fan of the power supply does not work
2. Indicator light on keyboard does not shine.
System is inoperative. Keyboard lights are on, power indicator lights are lit, and hard drives are running.
System does not boot from a hard disk drive, but can be booted from optical drive.
System only boots from an optical drive. Hard disks can be read, applications can be used, but system fails to boot from a hard disk.
Screen message shows “Invalid Configuration” or “CMOS Failure.”
System cannot boot after the user installs a second hard drive.
1. Make sure power cable is securely
2. Replace cable.
3. Contact technical support.
Using even pressure on both ends of the DIMM, press down firmly until the module snaps into place.
1. Check cable running from disk to disk
2. Backing up the hard drive is
1. Back up data and applications files.
2. Reformat the hard drive. Re-install
Review system’s equipment. Make sure correct information is in setup.
1. Set master/slave jumpers correctly.
2. Run SETUP program and select
plugged in.
controller board. Make sure both ends are securely plugged in; check the drive type in the standard CMOS setup.
extremely important. All hard disks are capable of breaking down at any time.
applications and data using backup disks.
correct drive types. Call the drive manufacturers for compatibility with other drives.
18
CPU Overheated
If the system shutdown automatically after power on system for seconds, that means the CPU protection function has been activated.
When the CPU is over heated, the motherboard will shutdown automatically to avoid a damage of the CPU, and the system may not power on again.
In this case, please double check:
1. The CPU cooler surface is placed evenly with the CPU surface.
2. CPU fan is rotated normally.
3. CPU fan speed is fulfilling with the CPU speed.
After confirmed, please follow steps below to relief the CPU protection function.
1. Remove the power cord from power supply for seconds.
2. Wait for seconds.
3. Plug in the power cord and boot up the system.
Or you can:
1. Clear the CMOS data.
(See “Close CMOS Header: JCMOS1” section)
2. Wait for seconds.
3.
Power on the system again.
H61MHV2
19
Motherboard Manual
This Page Intentionally Left Blank
20
APPENDIX: SPEC IN OTHER LANGUAGES
G
ERMAN
Spezifikationen
H61MHV2
CPU
Chipsatz
Super E/A
Arbeitsspeich
er
SATA 2
LAN
HD
Audio-Unters
tützung
Socket 1155
Intel Core i7 / i5 / i3 / Pentium / Celeron
Prozessoren
Intel H61
IT8772E
Bietet die häufig verwendeten alten Super
E/A-Funktionen.
Low Pin Count-Schnittstelle
DDR3 DIMM-Steckplätze x 2
Max. 16GB Arbeitsspeicher
Jeder DIMM unterstützt 512MB/
1GB/2GB/4GB/8GB DDR3.
Integrierter Serial ATA-Controller
RTL8111H 10 / 100 / 1000Mb/s Auto-Negotiation
ALC662
Unterstützt Execute Disable Bit / Enhanced Intel
SpeedStep® / Intel Architecture-64 / Extended
Memory 64 Technology / Virtualization Technology /
Hyper Threading
Umgebungskontrolle,
Hardware-Überwachung
Lüfterdrehzahl-Controller/-Überwachung
"Smart Guardian"-Funktion von ITE
Dual-Kanal DDR3 Speichermodul
Unterstützt DDR3 1066 / 1333 / 1600
registrierte DIMMs. ECC DIMMs werden nicht
unterstützt.
Datentransferrate bis zu 3.0Gb/s
Konform mit der SATA-Spezifikation Version 2.0
Unterstützt High-Definition Audio
5.1-Kanal-Audioausgabe
Steckplätze
Onboard-Ans
chluss
PCI-E Gen3 x 16 Steckplatz x1 (je nach CPU)
PCI-E Gen2 x1-Steckplatz x1
SATA2-Anschluss x4 Jeder Anschluss unterstützt 1 SATA2-Laufwerk
Fronttafelanschluss x1 Unterstützt die Fronttafelfunktionen
Front-Audioanschluss x1 Unterstützt die Fronttafel-Audioanschlussfunktion
CPU-Lüfterstromversorgungsanschluss (mit Smart
CPU-Lüfter-Sockel x1
Fan-Funktion)
System-Lüfter-Sockel x1 System-Lüfter-Stromversorgungsanschluss
21
Motherboard Manual
Chassis Lautsprecher-Anschluss x1
"CMOS löschen"-Sockel x1
USB2.0-Anschluss x2 Jeder Anschluss unterstützt 2
Serieller Anschluss x1
Stromanschluss (24-polig) x1
Stromanschluss (4-polig) x1
Spezifikationen
Fronttafel-USB2.0-Anschlüsse
Rückseiten-E
/A
Platinengröße
OS-Unterstüt
zung
PS/2-Tastatur/ Maus x1
VGA-Anschluss x1
HDMIchluss x1
LAN-Anschluss x1
USB2.0-Anschluss x4
Audioanschluss x3
170 mm (B) X 191 mm (L)
Windows XP / Vista / 7 / 8 / 8.1 / 10
Biostar behält sich das Recht vor, ohne Ankündigung
die Unterstützung für ein Betriebssystem
hinzuzufügen oder zu entfernen.
22
FRENCH
H61MHV2
SPEC
UC
Chipset
Super E/S
Mémoire
principale
SATA 2
LAN
Prise en
charge
audio HD
Socket 1155
Processeurs Intel Core i7 / i5 / i3 / Pentium /
Celeron
Intel H61
IT8772E
Fournit la fonctionnalité de Super E/S
patrimoniales la plus utilisée.
Interface à faible compte de broches
Fentes DDR3 DIMM x 2
Capacité mémoire maximale de 16 Go
Chaque DIMM prend en charge des DDR3 de
512Mo/1Go/2Go/4Go/8Go
Contrôleur Serial ATA intégré
RTL8111H 10 / 100 / 1000 Mb/s négociation automatique
ALC662
Prend en charge les technologies d'exécution de bit
de désactivation / Intel SpeedStep® optimisée/
d'architecture Intel 64 / de mémoire étendue 64 / de
virtualisation / Hyper Threading
Initiatives de contrôle environnementales,
Moniteur de matériel
Contrôleur /moniteur de vitesse de ventilateur
Fonction "Gardien intelligent" de l'ITE
Module de mémoire DDR3 à mode à double voie
Prend en charge la DDR3 1066 / 1333 / 1600
Les DIMM à registres et DIMM avec code correcteurs
d'erreurs ne sont pas prises en charge
Taux de transfert jusqu'à 3.0Go/s.
Conforme à la spécification SATA Version 2.0
Prise en charge de l'audio haute définition
Sortie audio à 5.1 voies
Fentes
Connecteur
embarqué
Fente PCI-E Gen3 x 16 x1 (en fonction du CPU)
Fente PCI-E Gen2 x1 x1
Chaque connecteur prend en charge 1 périphérique
Connecteur SATA2 x4
SATA2
Connecteur du panneau avant x1 Prend en charge les équipements du panneau avant
Connecteur Audio du panneau avant x1 Prend en charge la fonction audio du panneau avant
Alimentation électrique du ventilateur UC (avec
Embase de ventilateur UC x1
fonction de ventilateur intelligent)
Embase de ventilateur système x1 Alimentation électrique du ventilateur système
23
Motherboard Manual
Châssis Connecteur Haut-parleur x1
Embase d'effacement CMOS x1
SPEC
E/S du
panneau
arrière
Dimensions
de la carte
Support SE
Connecteur USB2.0 x2
Port série x1
Connecteur d'alimentation x1
(24 broches)
Connecteur d'alimentation x1
(4 broches)
Souris / Clavier PS/2 x1
Port VGA x1
Port HDMI x1
Port LAN x1
Port USB2.0 x4
Fiche audio x3
170 mm (l) X 191 mm (H)
Windows XP / Vista / 7 / 8 / 8.1 / 10
Chaque connecteur prend en charge 2 ports USB2.0
de panneau avant
Biostar se réserve le droit d'ajouter ou de supprimer
le support de SE avec ou sans préavis
24
ITALIAN
H61MHV2
SPECIFICA
CPU
Chipset
Super I/O
Memoria principale
SATA 2
LAN
Socket 1155
Processore Intel Core i7 / i5 / i3 /
Pentium / Celeron
Intel H61
IT8772E
Fornisce le funzionalità legacy Super I/O
usate più comunemente.
Interfaccia LPC (Low Pin Count)
Alloggi DIMM DDR3 x 2
Capacità massima della memoria 16GB
Ciascun DIMM supporta DDR3
512MB/1GB/2GB/4GB/8GB
Controller Serial ATA integrato
RTL8111H Negoziazione automatica 10 / 100 / 1000 Mb/s
Supporto di Execute Disable Bit / Enhanced
Intel SpeedStep® / Architettura Intel 64 /
Tecn olo gi a Ex ten ded Mem ory 64 / Tec nol ogi a
Virtualization / Hyper Threading
Funzioni di controllo dell’ambiente:
Monitoraggio hardware
Controller / Monitoraggio velocità ventolina
Funzione "Smart Guardian" di ITE
Modulo di memoria DDR3 a canale doppio
Supporto di DDR3 1066 / 1333 / 1600
DIMM registrati e DIMM ECC non sono
supportati
Velocità di trasferimento dei dati fino a
3.0Gb/s.
Compatibile specifiche SATA Versione 2.0
Supporto audio HD
Alloggi
Connettori su scheda
ALC662
Supporto audio High-Definition (HD)
Uscita audio 5.1 canali
Alloggio PCI-E Gen3 x16 x1 (a seconda del CPU)
Alloggio PCI Express Gen2 x1 x1
Connettore SATA2 x4 Ciascun connettore supporta 1 unità SATA2
Connettore pannello frontale x1 Supporta i servizi del pannello frontale
Connettore audio frontale x1 Supporta la funzione audio pannello frontale
Alimentazione ventolina CPU (con funzione
Collettore ventolina CPU x1
Smart Fan)
Collettore ventolina sistema x1 Alimentazione ventolina di sistema
Chassis Connettore altoparlante x1
25
Motherboard Manual
Collettore cancellazione CMOS x1
SPECIFICA
I/O pannello posteriore
Dimension i scheda
Sistemi operativi supportati
Connettore USB2.0 x2
Porta seriale x1
Connettore alimentazione x1
(24 pin)
Connettore alimentazione x1
(4 pin)
Mouse/ Tastiera PS/2 x1
Porta VGA x1
Porta HDMI x1
Porta LAN x1
Porta USB2.0 x4
Connettore audio x3
170 mm (larghezza) x 191 mm (altezza)
Windows XP / Vista / 7 / 8 / 8.1 / 10
Ciascun connettore supporta 2 porte USB2.0
pannello frontale
Biostar si riserva il diritto di aggiungere o
rimuovere il supporto di qualsiasi sistema
operativo senza preavviso.
26
SPANISH
H61MHV2
Especificación
CPU
Conjunto de
chips
Súper E/S
Memoria
principal
SATA 2
Red Local
Soporte de
sonido HD
Socket 1155
Procesador Intel Core i7 / i5 / i3 / Pentium /
Celeron
Intel H61
IT8772E
Le ofrece las funcionalidades heredadas de
uso más común Súper E/S.
Interfaz de cuenta Low Pin
Ranuras DIMM DDR3 x 2
Capacidad máxima de memoria de 16GB
Cada DIMM admite DDR de
512MB/1GB/2GB/4GB/8GB
Controlador ATA Serie Integrado
RTL8111H Negociación de 10 / 100 / 1000 Mb/s
ALC662
Admite Bit de deshabilitación de ejecución / Intel
SpeedStep® Mejorado / Intel Architecture-64 /
Tecnología Extended Memory 64 / Tecnología de
virtualización / Hyper Threading
Iniciativas de control de entorno,
Monitor hardware
Controlador/monitor de velocidad de ventilador
Función "Guardia inteligente" de ITE
Módulo de memoria DDR3 de canal Doble
Admite DDR3 de 1066 / 1333 / 1600
No admite DIMM registrados o DIMM compatibles
con ECC
Tasas de transferencia de hasta 3.0 Gb/s.
Compatible con la versión SATA 2.0
Soporte de sonido de Alta Definición
Salida de sonido de 5.1 canales
Ranuras
Conectores
en placa
Ranura PCI-E Gen3 x16 X1 (dependiendo de la CPU)
Ranura PCI-E Gen2 x 1 X1
Conector SATA2 X4 Cada conector soporta 1 dispositivos SATA2
Conector de panel frontal X1 Soporta instalaciones en el panel frontal
Conector de sonido frontal X1 Soporta funciones de sonido en el panel frontal
Cabecera de ventilador de CPU X1 Fuente de alimentación de ventilador de CPU (con
función Smart Fan)
Cabecera de ventilador de sistema X1 Fuente de alimentación de ventilador de sistema
Cabecera de borrado de CMOS X1
27
Motherboard Manual
Chasis Conector de altavoz X1
Conector USB2.0 X2 Cada conector soporta 2 puertos USB2.0 frontales
Puerto serie X1
Especificación
Panel
trasero de
E/S
Tama ño d e
la placa
Soporte de
sistema
operativo
Conector de alimentación X1
(24 patillas)
Conector de alimentación X1
(4 patillas)
Ratón / Teclado PS/2 X1
Puerto VGA X1
Puerto HDMI X1
Puerto de red local X1
Puerto USB2.0 X4
Conector de sonido X3
170 mm. (A) X 191 Mm. (H)
Windows XP / Vista / 7 / 8 / 8.1 / 10
Biostar se reserva el derecho de añadir o retirar el
soporte de cualquier SO con o sin aviso previo.
28
PORTUGUESE
Socket 1155
CPU
Chipset
Especificaçã
o Super I/O
Memória
principal
SATA 2
LAN
Suporte
para áudio
de alta
definição
Ranhuras
Conectores
na placa
Processador Intel Core i7 / i5 / i3 / Pentium /
Celeron
Intel H61
IT8772E
Proporciona as funcionalidades mais
utilizadas em termos da especificação Super
I/O.
Interface LPC (Low Pin Count).
Ranhuras DIMM DDR3 x 2
Capacidade máxima de memória: 16 GB
Cada módulo DIMM suporta uma memória
DDR3 de 512MB/ 1GB/2GB/4GB/8GB
Controlador Serial ATA integrado
RTL8111H Auto negociação de 10 / 100 / 1000 Mb/s
ALC662
Ranhura PCI-E Gen3 x16 x1 (dependendo da CPU)
Ranhura PCI-E Gen2 x 1 x1
Conector SATA2 x4 Cada conector suporta 1 dispositivo SATA2
Conector do painel frontal x1 Para suporte de várias funções no painel frontal
Conector de áudio frontal x1 Suporta a função de áudio no painel frontal
Conector da ventoinha da CPU x1
Conector da ventoinha do sistema x1 Alimentação da ventoinha do sistema
H61MHV2
ESPECIFICAÇÕES
Suporta as tecnologias Execute Disable Bit /
Enhanced Intel SpeedStep® / Intel Arquitecture -64
/ Extended Memory 64 / Virtualization / Hyper
Threading
Iniciativas para controlo do ambiente
Monitorização do hardware
Controlador/Monitor da velocidade da ventoinha
Função "Smart Guardian" da ITE
Módulo de memória DDR3 de canal duplo
Suporta módulos DDR3 1066 / 1333 / 1600
Os módulos DIMM registados e os DIMM ECC não
são suportados
Velocidades de transmissão de dados até 3.0 Gb/s.
Compatibilidade com a especificação SATA versão
2.0
Suporta a especificação High-Definition Audio
Saída de áudio de 5.1 canais
Alimentação da ventoinha da CPU (com a função
Smart Fan)
29
Motherboard Manual
Chassis Conector Speaker x1
Conector para limpeza do CMOS x1
Conector USB2.0 x2
ESPECIFICAÇÕES
Cada conector suporta 2 portas USB2.0 no painel
frontal
Entradas/S
aídas no
painel
traseiro
Ta ma n ho
da placa
Sistemas
operativos
suportados
Porta série x1
Conector de alimentação x1
(24 pinos)
Conector de alimentação x1
(4 pinos)
Rato / Teclado PS/2 x1
Porta VGA x1
Porta HDMI x1
Porta LAN x1
Porta USB2.0 x4
Tomada de áudio x3
170 mm (L) X 191 mm (A)
Windows XP / Vista / 7 / 8 / 8.1 / 10
A Biostar reserva-se o direito de adicionar ou
remover suporte para qualquer sistema operativo
com ou sem aviso prévio.
30
POLISH
H61MHV2
SPEC
Procesor
Chipset
Pamięć
główna
Super I/O
SATA 2
LAN
Socket 1155
Procesor Intel Core i7 / i5 / i3 / Pentium /
Celeron
Intel H61
Gniazda DDR3 DIMM x 2
Maks. wielkość pamięci 16GB
Każde gniazdo DIMM obsługuje moduły
512MB/1GB/2GB/4GB/8GB DDR3
IT8772E
Zapewnia najbardziej powszechne funkcje
Super I/O.
Interfejs Low Pin Count
Zintegrowany kontroler Serial ATA
RTL8111G
Obsługa Execute Disable Bit / Enhanced Intel
SpeedStep® / Intel Architecture-64 / Extended
Memory 64 Technology / Virtualization Technology /
Hyper Threading
Moduł pamięci DDR3 z trybem podwójnego kanału
Obsługa DDR3 1066 / 1333 / 1600
Brak obsługi Registered DIMM oraz ECC DIMM
Funkcje kontroli warunków pracy,
Monitor H/W
Kontroler/Monitor prędkości wentylatora
Funkcja ITE "Smart Guardian"
Transfer danych do 3.0 Gb/s.
Zgodność ze specyfikacją SATA w wersji 2.0
10 /100 /1000Mb/s z automatyczną negocjacją
szybkości
Obsługa
audio HD
Gniazda
Złącza
wbudowane
ALC662
Gniazdo PCI-E Gen3 x16 x1 (w zależności od procesora)
Gniazdo PCI-E Gen2 x 1 x1
Złącze SATA2 x4 Każde złącze obsługuje 1 urządzenie SATA2
Złącze panela przedniego x1 Obsługa elementów panela przedniego
Przednie złącze audio x1 Obsługa funkcji audio na panelu przednim
Złącze główkowe wentylatora
procesora x1
Złącze główkowe wentylatora
systemowego x1
Obsługa High-Definition Audio
5.1 kanałowe wyjście audio
Zasilanie wentylatora procesora (z funkcją Smart
Fan)
Zasilanie wentylatora systemowego
31
Motherboard Manual
Chassis Speaker Connector x1
Złącze główkowe kasowania CMOS x1
SPEC
Back Panel
I/O
Wymiary
płyty
Obsluga
systemu
operacyjne
go
Złącze USB2.0 x2
Port szeregowy x1
Złącze zasilania (24 pinowe) x1
Złącze zasilania (4 pinowe) x1
Mysz / Klawiatura PS/2 x1
Port VGA x1
Port HDMI x1
Port LAN x1
Port USB2.0 x4
Gniazdo audio x3
170 mm (S) X 191 mm (W)
Windows XP / Vista / 7 / 8 / 8.1 / 10
Każde złącze obsługuje 2 porty USB2.0 na panelu
przednim
Biostar zastrzega sobie prawo dodawania lub
odwoływania obsługi dowolnego systemu
operacyjnego bez powiadomienia.
32
RUSSIAN
CPU
(центральн
ый
процессор)
Набор
микросхем
Основная
память
Super I/O
SATA 2
Локальная
сеть
Звуковая
поддержка
жесткого
диска
Слоты
Встроенны
й разъём
Socket 1155
Процессор Intel Core i7 / i5 / i3 / Pentium /
Celeron
Intel H61
Слоты DDR3 DIMM x 2
Максимальная ёмкость памяти 16 ГБ
Каждый модуль DIMM поддерживает
512МБ/1ГБ/2ГБ/4ГБ/8ГБ DDR3
IT8772E
Обеспечивает наиболее используемые
действующие функциональные
возможности Super I/O.
Интерфейс с низким количеством выводов
Встроенное последовательное устройство
управления ATA
RTL8111H Автоматическое согласование 10/ 100 /1000 Мб/с
ALC662
Слот PCI-E Gen3 x16 @ x16 x1 (в зависимости от процессора)
Слот PCI-E Gen2 x 1 x1
Разъём SATA2 x4 Каждый разъём поддерживает 1 устройство SATA2
Разъём на лицевой панели x1 Поддержка устройств на лицевой панели
Входной звуковой разъём x1
Контактирующее приспособление
вентилятора центрального процессора x1
H61MHV2
СПЕЦ
Поддержка технологий Execute Disable Bit /
Enhanced Intel SpeedStep® / Intel Architecture-64
/ Extended Memory 64 Technology / технологии
виртуализация / Hyper Threading
Модуль памяти с двухканальным режимом DDR3
Поддержка DDR3 1066 / 1333 / 1600
Не поддерживает зарегистрированные модули
DIMM and ECC DIMM
Инициативы по охране окружающей среды,
Аппаратный монитор
Регулятор скорости вентилятора/ монитор
Функция ITE "Smart Guardian"
(Интеллектуальная защита)
скорость передачи данных до 3.0 гигабит/с.
Соответствие спецификации SATA версия 2.0
Звуковая поддержка High-Definition
5.1канальный звуковой выход
Поддержка звуковых функций на лицевой
панели
Источник питания для вентилятора центрального
процессора (с функцией интеллектуального
вентилятора)
33
Motherboard Manual
Контактирующее приспособление
вентилятора системы x1
Шасси акустической системы x1
Открытое контактирующее
приспособление CMOS x1
USB2.0-разъём x2
Последовательный порт x1
Разъем питания (24 вывод) x1
Разъем питания (4 вывод) x1
СПЕЦ
Источник питания для вентилятора системы
Каждый разъём поддерживает 2 USB2.0-порта на
лицевой панели
Задняя
панель
средств
ввода-выв
ода
Размер
панели
Поддержка
OS
Мышь/ Клавиатура PS/2 x1
Порт VGA x1
ПортHDMI x1
Порт LAN x1
USB2.0-порт x4
Гнездо для подключения
наушников x3
170 мм (Ш) X 191 мм (В)
Windows XP / Vista / 7 / 8 / 8.1 / 10
Biostar сохраняет за собой право добавлять или
удалять средства обеспечения для OS с или без
предварительного уведомления.
34
ARABIC
د
ا
تﺎﻔﺻاﻮﻤﻟا
H61MHV2
تﺎﻴﻨﻘﺗ ﻢﻋﺪﺗExecute Disable Bit / Enhanced Intel
SpeedStep® / Intel Architecture-64 / Extended
Memory 64 Technology / Virtualization Technology /
Hyper Threading
Intel H61
تﺎﺠﻟﺎﻌﻣIntel Core i7 / i5 / i3 / Pentium /
ﺔﺤﺘﻓDDR3 DIMM دﺪﻋ2
ﺔﺤﺘﻓ ﻞآ ﻢﻋﺪﺗDIMM عﻮﻧ ﻦﻣ ةﺮآاذ ﻢﻋﺪﺗ DDR3 ﺔﻌﺳ
ﺔﻔﻴﻇو"Smart Guardian" ﻦﻣ ITE
ﻰﻟإ ﻞﺼﺗ تﺎﻋﺮﺴﺑ تﺎﻧﺎﻴﺒﻟا ﻞﻘﻧ3.0 ﺖﺑﺎﺠﻴﺟ/ﺔﻴﻧﺎﺛ.
تﺎﻔﺻاﻮﻤﻟ ﺔﻘﺑﺎﻄﻣSATA راﺪﺻﻹا 2.0
ىﻮﺼﻗ ةﺮآاذ ﺔﻌﺳ16 ﺖﻳﺎﺑ ﺎﺠﻴﺟ
/512 و ﺖﻳﺎﺑ ﺎﺠﻴﻣ1/
و2/ و4/ و8 ﺎﺠﻴﺟﺖﻳﺎﺑ
ﺔﺌﻴﺒﻟا ﻲﻓ ﻢﻜﺤﺘﻟا ﻞﺋﺎﺳو:
ةﺰﻬﺟﻷا ﺔﻟﺎﺣ ﺔﻓﺮﻌﻤﻟ ﺐﻗاﺮﻣ
ﺔﺣوﺮﻤﻟا ﺔﻋﺮﺳ ﻲﻓ ﺐﻗاﺮﻣ
ﻲﺋﺎﻘﻠﺗ ضوﺎﻔﺗ10/100/1000 ﺖﻳﺎﺑ ﺎﺠﻴﻣ /ﺔﻴﻧﺎﺛ RTL8111H
ﻋﺪﺗعﻮﻧ ﻦﻣ ةﺮآاﺬﻟا DDR3 تﺎﻌﺳ 1066 / 1333 / 1600
ةﺮآاﺬﻟا ﻖﺋﺎﻗر ﻢﻋﺪﺗ DIMM ﻊﻣ ﻖﻓاﻮﺘﺗ ﻲﺘﻟا ﻚﻠﺗو ECC
ﺔﻔﻴﻇو ﺮﻓﻮﺗSuper I/O ًﺎ ﻣ ا ﺪﺨﺘ ﺳ ا ﺮﺜآﻷا.
Low Pin Count Interface
ﺗﻢﻋﺪ ﺔﻴﻨﻘﺗ
Socket 1155
Celeron ﺑددﺮﺘ ﻰﻟإ ﻞﺼ
ةﺮآاذ ةﺪﺣوDDR3 ﻘﻟا ﺔﺟودﺰﻣةﺎﻨ
ﺎﺠﻴﻣ ﺖﻳﺎﺑ
IT8772E
ﻢﻜﺤﺘﻣSerial ATA ﻞﻣﺎﻜﺘﻣ
ﺔﺠﻟﺎﻌﻤﻟا ةﺪﺣو
ﺔﻳﺰآﺮﻤﻟا
ﺢﺋاﺮﺸﻟا ﺔﻋﻮﻤﺠﻣ
ﺔﻴﺴﻴﺋﺮﻟا ةﺮآاﺬﻟا
Super I/O
SATA 2
ﺔﻴﻠﺧاد ﺔﻜﺒﺷ
ﺔﻴﻨﻘﺗ ﻢﻋﺪﺗﻦﻣ ﻒﻳﺮﻌﺘﻟا ﻲﻟﺎﻋ تﻮﺼﻟا
5.1 تﻮﺼﻟا جﺮﺨﻟ تاﻮﻨﻗ
(ادﺎﻤﺘﻋا ﻰﻠﻋ ةﺪﺣو ﺔﺠﻟﺎﻌﻤﻟا ﺔﻳﺰآﺮﻤﻟا) ﺔﺤﺘﻓPCI-E Gen3 x16 دﺪﻋ1
ﺔﺤﺘﻓPCI-E Gen2 x 1 دﺪﻋ1
ةﺰﻬﺟأ ﻦﻣ ﺪﺣاو ﺬﻔﻨﻣ ﻞآ ﻢﻋﺪﻳSATA2 ﺬﻔﻨﻣSATA2 دﺪﻋ4
ﺠﺗ ﻢﻋﺪﻳﺔﻴﻣﺎﻣﻷا ﺔﺣﻮﻠﻟا تاﺰﻴﻬ ﺔﻴﻣﺎﻣﻷا ﺔﺣﻮﻠﻟا ﺬﻔﻨﻣ دﺪﻋ1
ﺔﻴﻣﺎﻣﻷا ﺔﺣﻮﻠﻟﺎﺑ تﻮﺼﻟا ﺔﻔﻴﻇو ﻢﻋﺪﻳ ﻲﻣﺎﻣﻷا تﻮﺼﻟا ﺬﻔﻨﻣ دﺪﻋ1
ﺔﻔﻴﻇو ﻊﻣ ﺔﺠﻟﺎﻌﻤﻟا ةﺪﺣو ﺔﺣوﺮﻤﻟ ﺔﻗﺎﻄﻟا ﻞﻴﺻﻮﺘﻟSmart Fan ﺔﻳﺰآﺮﻤﻟا ﺔﺠﻟﺎﻌﻤﻟا ةﺪﺣو ﺔﺣوﺮﻣ ﺔﻠﺻو دﺪﻋ1
مﺎﻈﻨﻟا ﺔﺣوﺮﻤﻟ ﺔﻗﺎﻄﻟا ﻞﻴﺻﻮﺘﻟ مﺎﻈﻨﻟا ﺔﺣوﺮﻣ ﺔﻠﺻو ﺪﻋ د1
ALC662
ﻲﻟﺎﻋ تﻮﺼﻟا ﻢﻋ
ﻒﻳﺮﻌﺘﻟا
تﺎﺤﺘﻔﻟا
ﺢﻄﺳ ﻰﻠﻋ ﺬﻓﺎﻨﻤﻟ
ﺔﺣﻮﻠﻟا
35
Motherboard Manual
ﻂﺑار ﺲﻴﺋر ﻞﺑﺎﻗ دﺪﻋ1
ﺢﺴﻣ ﺔﻠﺻوCMOS دﺪﻋ1
ﻲﺘﺤﺘﻓ ﺬﻔﻨﻣ ﻞآ ﻢﻋﺪﻳUSB2.0 ﺔﻴﻣﺎﻣﻷا ﺔﺣﻮﻠﻟﺎﺑ ﺬﻔﻨﻣUSB2.0 دﺪﻋ2
ﻲﻠﺴﻠﺴﺗ ﺬﻔﻨﻣ دﺪﻋ1
ﺔﻗﺎﻄﻟا ﻞﻴﺻﻮﺗ ﺬﻔﻨﻣ)24سﻮﺑد( دﺪﻋ1
ﺔﻗﺎﻄﻟا ﻞﻴﺻﻮﺗ ﺬﻔﻨﻣ)4ﺲﻴﺑﺎﺑد( دﺪﻋ1
تﺎﻔﺻاﻮﻤﻟا
ﻆﻔﺘﺤﺗBiostar نوﺪﺑ وأ رﺎﻄﺧﺈﺑ ﻞﻴﻐﺸﺗ مﺎﻈﻧ يﻷ ﻢﻋﺪﻟا ﺔﻟازإ وأ ﺔﻓﺎﺿإ ﻲﻓ ﺎﻬﻘﺤﺑ
ﺎﻄﺧإر.
170 ﻢﻣ)ضﺮﻋ (X 191 ﻢﻣ)عﺎﻔﺗرا(
Windows XP / Vista / 7 / 8 / 8.1 /10
سوﺎﻣ / ﺢﻴﺗﺎﻔﻣ ﺔﺣﻮﻟPS/2 دﺪﻋ1
ﺬﻓﺎﻨﻣVGA دﺪﻋ1
ﺬﻓﺎﻨﻣHDMI دﺪﻋ1
ﻞﺧد ﺬﻓﺎﻨﻣ/جﺮﺧ
ﺔﻴﻠﺤﻣ لﺎﺼﺗا ﺔﻜﺒﺷ ﺬﻔﻨﻣ دﺪﻋ1
ﺔﻴﻔﻠﺨﻟا ﺔﺣﻮﻠﻟا
ﺬﻓﺎﻨﻣ2.0USB دﺪﻋ4
تﻮﺻ ﺲﺒﻘﻣ دﺪﻋ3
ﺔﺣﻮﻠﻟا ﻢﺠﺣ
ﻞﻴﻐﺸﺘﻟا ﺔﻤﻈﻧأ ﻢﻋد
36
JAPANESE
仕様
H61MHV2
CPU
チップセット
メインメモリ
Super I/O
SATA 2
LAN
HDオーディ
オのサポート
Socket 1155
Intel Core i7 / i5 / i3 / Pentium / Celeron プロ
セッサ
Intel H61
DDR3 DIMMスロット x 2
最大メモリ容量16GB
DIMMは 512MB/1GB/2GB/4GB/8GB DDR3
をサポート
IT8772E
もっとも一般に使用されるレガシーSuper I/O
能を採用しています。
低ピンカウントインターフェイス
統合シリアルATAコントローラ
RTL8111H 10 / 100 / 1000 Mb/秒のオートネゴシエーション
ALC662
Execute Disable Bit / Enhanced Intel SpeedStep® /
Intel Architecture-64 / Extended Memory 64
Technology / Virtualization Technology / Hyper
Threadingをサポートします
デュアル チャンネルモードDDR3メモリモジュール
DDR3 1066 / 1333 / 1600をサポート
登録済みDIMMECC DIMMはサポートされません
環境コントロールイニシアチブ、
H/Wモニター
ファン速度コントローラ/ モニター
ITEの「スマートガーディアン」機能
最高3.0 Gb/秒のデータ転送速度
SATAバージョン2.0仕様に準拠
ハイデフィニションオーディオのサポート
5.1 チャンネルオーディオアウト
スロット
オンボードコ
ネクタ
PCI-E Gen3 x16スロット x1 (CPUに依存)
PCI Express Gen2 x 1スロット x1
SATA2コネクタ x4 各コネクタは1つのSATA2デバイスをサポートします
フロントパネルコネクタ x1 フロントパネル機能をサポートします
フロントオーディオコネクタ x1 フロントパネルオーディオ機能をサポートします
CPUファンヘッダ x1 CPUファン電源装置(スマートファン機能を搭載)
システムファンヘッダ x1 システムファン電源装置
シャーシスピーカーコネクタ x1
CMOSクリアヘッダ x1
37
Motherboard Manual
仕様
背面パネル
I/O
ボードサイズ
OSサポート
USB2.0コネクタ x2
シリアルポート x1
電源コネクタ(24ピン) x1
電源コネクタ(4ピン) x1
PS/2キーボード/ マウス x1
VGAポート x1
HDMIポート x1
LANポート x1
USB2.0ポート x4
オーディオジャック x3
170 mm (幅) X 191 mm (高さ)
Windows XP / Vista / 7 / 8 / 8.1 / 10
各コネクタは2つのフロントパネルUSB2.0ポートをサポ
ートします
Biostarは事前のサポートなしにOSサポートを追加または
削除する権利を留保します。
38
Loading...
