BinTec BIANCA, BRICK-X21 Getting Started

BIANCA/BRICK-X21

Getting Started

Version 1.0 March1999 Document #71020I

Notes:

This manual provides a description of an initial, first-time configuration of the BIANCA/BRICK-X21 router with software version 4.9.3.

While every effort hasbeen made to ensure the accuracy of all information in this document, BinTec Communications AG assumes no liability to any party for any loss or damage caused by errors or omissions or by statements of any kind in this document.

The information in this manual is subject to change without notice. For additions or changes to this document please refer to the most recent version of this document which is available at BinTec’s World Wide Web server at: http://www.bintec.de

BinTec and the BinTec logo are registered trademarks of BinTec Communications AG. All other product names and trademarks are the property of their respective companies.

All rights reserved. No part of this publication may be reproduced or transmitted in any form or by any means – graphic, electronic, or mechanical – including photocopying, recording in any medium, taping, or storagein an information retrieval systems, without the prior written permission of the copyright owner.

BinTec Communications AG March1999

How to contact BinTec Communications

Ways to contact BinTec Telephone number or address Telephone +49 911 96 73 0 FAX +49 911 688 07 25

BinTec Communications AG

Mail

WWW http://WWW.BinTec.DE

Südwestpark 94 D-90449 Nürnberg GERMANY

Getting Started

BIANCA/BRICK-X21

GETTING STARTED

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2

Software Installation . . . . . . . . . . . . . . . . . . . . . . . . .3

Installing the BRICK . . . . . . . . . . . . . . . . . . . . . . . . . .4

LED Indicators. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

Conﬁguration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Gathering the Information . . . . . . . . . . . . . . . . . . 8

Accessing the BRICK. . . . . . . . . . . . . . . . . . . . . . .9

Over Serial Port. . . . . . . . . . . . . . . . . . . . . . . . . . .10

Over LAN Interface . . . . . . . . . . . . . . . . . . . . . . .10

Over ISDN . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11

Additional Conﬁguration Possibilities. . . . . . . . . 11

Conﬁguration with Setup Tool . . . . . . . . . . . . . . 13

Licenses. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

System. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14

Setting up the LAN Interface . . . . . . . . . . . . . . . 15

Setting up the ISDN Interface. . . . . . . . . . . . . . . 16

BIANCA/BRICK-X21 GETTING STARTED

Dialup Line . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16

Incoming Call Answering . . . . . . . . . . . . . . . . . . . 17

WAN Partner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

WAN Numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

PPP Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

IP Partner Conﬁguration . . . . . . . . . . . . . . . . . . . . 20

IP Conﬁguration . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Leased Line. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22

WAN Partner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

IP Partner Conﬁguration . . . . . . . . . . . . . . . . . . . . 24

IP Conﬁguration . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Saving your Conﬁguration. . . . . . . . . . . . . . . . . .25

Testing your Conﬁguration . . . . . . . . . . . . . . . . . . .26

Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . .26

Getting the latest BRICK News and Software. .27

Setting up a BinTec Router in the UK. . . . . . . . . .29

Differences in the UK . . . . . . . . . . . . . . . . . . . . . .29

Multiple Subscriber Numbering (MSN) . . . . . . . . 29

Calling Line Identiﬁcation (CLIP) . . . . . . . . . . . . . 30

International ISDN Calls . . . . . . . . . . . . . . . . . . . . 30

Conﬁguring your BRICK . . . . . . . . . . . . . . . . . . . .30

Setup Tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30

SNMP Client Shell . . . . . . . . . . . . . . . . . . . . . . . . . 33

1BIANCA/BRICK-X21

Getting Started

Welcome! Thismanual hasbeendesigned tohelp youquicklyinstall and conﬁgure your new router using Setup Tool.

First,we’llprovide a shortlist of theavailable features on the BRICK, then we’ll cover installing the additional software included with your BRICK.

Physically Installing the BRICK begins on page 4.

Conﬁguring the BRICK is divided into 3 steps and is described beginning on page 7.

Finally, we’ll describe a few simple tests that you can usetoverifythatyourconﬁgurationwassuccessful(p.26).

BIANCA/BRICK-X21 GETTING STARTED

Features

The BIANCA/BRICK-X21 is BinTec’s cost effective

and ﬂexible BRI/X.21 multiprotocol router, particularly attractive for midrange communication environments.

The BIANCA/BRICK-X21 satisﬁes all the require-

ments of today’s LAN - WAN connections by combining the functions of a Gateway, Router,Bridge, and Telematic Server in a single, compact product.

The BRICK’s most important features include:

• Support forTCP/IProuting, IPXrouting, andbridg-

ing.

• Remote CAPI services for many communications

applicationsunder Windows3.x,Windows95,Windows 98 and Windows NT.

• Configuration via serial connection (V.24), telnet

(TCP/IP), isdnlogin (ISDN), separate SNMP managers, or special Windows software (DIME Browser).

• Integrated Firewall, using NAT (Network Address

Translation) and Access Lists.

• Accounting of ISDN and TCP/IP connections.

• Fast Ethernetinterfacewith auto-sensing10Base-T/

100BaseT (RJ45) port .

• Double-BRI ISDN interface with automatic detec-

tion/configuration of protocol settings.

• X.21 interface for directly accessing public X.25 net-

works.

• Windows and UNIX software for configuring and

administering the BRICK.

• HTTP and Java Status Monitors.

Software Installation

Your BRICK includes several helper/utility programs for Windows and UNIX.

SOFTWARE INSTALLATION

BRICKware for Windows

RVS-COM

BRICKware for Windows consists of the following programs(for detailedinformation,please referto theonline BRICKware for Windows documentation):

• DIME Tools – A set of tools for administering your BRICK whichincludes:BootP Server, TFTP Manager,

Syslog Server, Time Server, and ISDN and CAPI Trace Utility.

• DIME Browser–An SNMPmanagerwith agraphical user interface for administering your BRICK.

• BRICK at COM1/2 – Preconfigured Windows terminal sessions for accessing your BRICK over your computer’s serial ports.

• Remote CAPI clients for CAPI 1.1 and 2.0.

If youintendon conﬁguring your BRICK fromaPC or using it as a CAPI server for PC applications you should install the software as explained in the online document BRICKware for Windows.

RVS-COM for Windows 95 and Windows NT (Lite Version) is an application that runs using the CAPI interfaceand providestelecommunicationsservices, suchasTOnline (formerly Btxor Datex-J), Fax, Voice Mail, and Euroﬁletransfer. Complete instructions can be found in the online documentation included on the CD.

BRICKtools for UNIX

BRICKtools for UNIX includes a Euroﬁletransfer server and client as wellas ISDN and CAPI trace tools for various UNIX platforms (refer to the Software Reference).

BIANCA/BRICK-X21 GETTING STARTED

Installing the BRICK

Select a ﬂat, stable location for your BRICK and connect the included cables to the ports located on the back plane as shown in the diagram below.

All the examples in this documentation are for the

BRICK-X21with aFast Ethernetadapter (CM-100BT),one

ISDN adapter (CM-2BRI) and an X.21 adapter (CM-X21).

Step 1

Connect the includedlaplink cable to your terminal or computer and the9 pin serial port.

Step 2

Connect your BRICK to your ethernet’s cabling using the UTP port.

Step 5

Connect the power cord to the BRICK-X21 and your local power supply.

Step 3

Connect the included ISDN cable (RJ-45) to your BRICK’s ISDNport(s) andyourISDN outlet.

Step 4

Connect the included X.21 cable to your BRICK’s X.21 port and your X.21 outlet.

Note that the BRICK-X21 does not have a power switch. The system will power up as soon as it is connected to

your power source. You may decide to wait until you’re ready to access the BRICK before connecting the power source.

LED Indicators

☞ ☞

INSTALLING THE BRICK

Each time you power up the system, the BRICK switches intoPower Up Modeand performsaself-test toverify the integrity of the system. The LEDs on the front panel correspond to various stages of the test.

Upon successfulcompletion of the self test, theBRICK then switches into BOOTmonitor Mode, (the middle six LEDs remain on) as described in the User’s Guide.

If the ERR indicator remains on (see table below) there may be a problem with the cabling. Verify the ISDN and LAN cabling is correct and power up the system again.

Also note that the once the rooter is up, the system may beaccessed via theISDN using thefactory-set passwords. Changing the default passwords is described on page 14.

BIANCA/BRICK-X21 GETTING STARTED

After4seconds, the systemthen switches into Normal

Operation Mode. During normal operation, the front

panel indicators display status information as follows.

LED State Meaning

PWR On

Fast Ethernet

X21

ISDN 2BRI

ERR Blinking

A On Currently receiving a packet.

B On Currently sending a packet.

A On Currently receiving an X.21 frame.

B On Currently sending an X.21 frame.

On One B channel is currently in use on

Blinking Two B channels are currently in use

On One B channel is currently in use on

Blinking Two B channels are currently in use

Power: Power is being supplied.

unit 0.

on unit 0.

unit 1.

on unit 1.

Error: Data transferproblem onone of the slots. Check the cabling.

Conﬁguration

Conﬁguringyournew BRICK involvesthree simple steps which are described in the following sections.

CONFIGURATION

Gathering the Information (p. 8)

Accessing the BRICK (p.9)

Conﬁguration with Setup Tool (p.13)

1. First, you will needto know several pieces ofinfor-

mation about your network setup. At a minimum

you will need toknowthe information listed in the

table shownon the following page. Fill inthe ﬁelds

now and refer to them later when needed.

2. Next, you needto decide whether youwant to con-

ﬁgureyourBRICKoverits Ethernet,ISDN, orserial

port. The section Accessing the BRICK describes the

possible ways of gaining access to your new

BRICK.

Nomatter whichmethod youselect,you willarrive

at an SNMP shell login prompt and can continue

with the conﬁguration using the Setup Tool.

3. The last step involves logging into the BRICK as

admin, using the bintec password, and issuing

setup at the shell prompt. Using the Setup Tool is

the easiest way toget your BRICK up and running.

After logging into the BRICK, use the information

you gathered for your local setup, and proceed to

the section Conﬁguration with Setup Tool.

BIANCA/BRICK-X21 GETTING STARTED

Gathering the Information

In the following example network setup, the host merlin will be acting as thenameserverand timeserver for brick, the BRICK we will be conﬁguring with Setup Tool. The routerpartnerbrickwill serveasthe remoterouterfor connecting the Partner LAN over ISDN.

Your LAN

199.1.1.1 merlin

199.1.1.2 mybrick

091112341 091112342

ISDN

200.1.1.1

partnerbrick

08965432

Partner LAN

200.1.1.2 sauron

Fill in the table below with the conﬁguration parame-

ters for your local setup, then proceed to the next section.

Parameters See page Our example Your BRICK

License Information 14 – (see license card)

IP Address 10/15 199.1.1.2

Hostname 10/15 mybrick

Your BRICK-X21’s ISDN telephone #

Remote router’s IP Address

20/24 200.1.1.1

091112341

091112342

Remote router’s Hostname

Remote router’s ISDN telephone #

Remote partner’s PPP password

18 partnerbrick

18 08965432

18 secret

Accessing the BRICK

TheBRICK can beconﬁgured overany ofits interfaces using a variety of methods.

CONFIGURATION

Serial Connection

(9600,8,n,1)

Setup Tool

Access Methods

Setup Tool

• Telnet

• DIME Tools

LAN (Ethernet, Token Ring)

• isdnlogin

• LAPB(HDLC)

ISDN

As shownabove, there areseveralways of accessing your BRICK once connected to the network interfaces.

• Over a Serial Connection (p. 10)

◆

From a computer or terminal.

• Over Ethernet (p. 10)

◆

From a Windows PC using DIME Tools.

◆

From any computer on the LAN using telnet.

• Over ISDN (p. 11)

◆

From a computer connected to another BRICK

◆

Other ISDN stations capable of LAPB (HDLC).

The simplest method involves using the Setup Toolover a Serial Connection. This method requires a terminal or a computer running a terminal program to be attached directly to the BRICK’s serial port.

BIANCA/BRICK-X21 GETTING STARTED

Over Serial Port

With a terminal or terminal program (UNIX or PC)

• Connect the computer or terminal using the included cable to the BRICK’s serial port.

• Set your communications parameters to: 9600 bps, 8 data bits, no parity, 1 stop bit, softwarehandshake (XON,XOFF) andVT100 terminal emulation.

• After pressing the <Return> key, you should receive a login prompt.

ForWindowsPCs: You can alsouse thepreconﬁgured terminal programs BRICK at COM1/COM2 included in the BRICKware suite.

• Continue with the Conﬁguration with Setup Tool as described on page 13.

Over LAN Interface

From a Windows PC using DIME Tools

You can access the BRICK from a Windows PC on the LAN. This requiresBRICKwareand a TCP/IP stack to be installed on a PC on the same LAN segment as the BRICK. Power up your BRICK; then with DIME Tools running:

•ABootP Server window will open automatically once the PC receives a BOOTP request from the BRICK.

• In this window, enter the BRICK’s IP address, netmask, and hostname. The nameserver and timeserver’s address can also be set here.

• Using a VT100compatible telnetprogram, telnet to your BRICK using the IP address you assigned it with BootP Server.

• Continue with the Conﬁguration with Setup Tool as described on page 13.

Over ISDN

CONFIGURATION

From any computer using telnet

Once the BRICK is assigned it’s IP address (i.e. using BRICKwareand BootP Server as mentionedabove)you can access thesystem from any computer on the LAN.

• Using a VT100compatible telnetprogram, telnet to the BRICK at it’s IP address.

• Continue with the Conﬁguration with Setup Tool as described on page 13.

From a computer connected to another BRICK

The BRICK automatically conﬁgures its ISDN interface at boot time if the system is attached to an ISDN dialupline.Youcanloginto yournewBRICKfrom this computer over ISDN using the isdnlogin program.

• Login to your existing BRICK.

• At the shell prompt, issue isdnlogin <telno> where telno is the ISDN number your new BRICK is connected to.

• Continue with the Conﬁguration with Setup Tool as described on page 13.

Additional Conﬁguration Possibilities

SNMP shell

Of course, the BRICK can be conﬁgured manually from the SNMP shell or by using an external SNMP manager such asDIMEBrowser for Windows. Thesemechanisms require a greater understanding of the BRICK’s internal data structures, SNMP, and the MIB (management information base).

For information on working with the SNMP shell or using DIME Browser, refer to the Software Reference and BRICKwarefor Windowsrespectively(both areincludedon the Companion CD).

BIANCA/BRICK-X21 GETTING STARTED

Third party SNMP Manager

The BRICK can also be conﬁgured using third party SNMP Managers such as HP OpenView, Sun/Netmanager, and Transview. The Management Information Base implemented on the BRICK must be imported into your SNMP manager. The complete MIB is included on the Companion CD. See your SNMP manager documentation on importing MIBs.

CONFIGURATION

Conﬁguration with Setup Tool

If you haven’t already done so, login to the BRICK now by entering admin at the login prompt and bintec at the password prompt. Enter setup now. Setup Tool’s main menu will be displayed as follows.

BIANCA/BRICK-X21 Setup Tool BinTec Communications AG

brick

Licenses

Slot1: CM-100BT, Fast Ethernet

Slot 2: CM-X21 Slot3: CM-2BRI, ISDN S0, Unit 0

CM-2BRI, ISDN S0, Unit 1

WAN Partner IP IPX PPP X.25 FR VPN ISDN CAPI

Configuration Management Monitoring and Debugging Exit

Press <Ctrl-n>, <Ctrl-p> to scroll, <Space> tag/untag DELETE, <Return> to edit

Navigating the Menus

lowing keys:

System

The Setup Tool menus can be navigated using the fol-

Return

Tab

↓

Spacebar

Esc

Enters the currently highlighted menu item.

Moves forward and backward between

↓↑

menus and ﬁelds.

Scrolls among entries in a list of possible

↓

ﬁeld values.

Selects/unselects (toggles) special ﬁelds

or scrolls a list of ﬁeld entries.

Entering two successive Esc charac-

Esc

ters returns you to the previous menu.

☞

As youmove between menus, thelines at thetopand bottom of your screen will display status information for the respective menu/ﬁeld you are currently editing.

BIANCA/BRICK-X21 GETTING STARTED

Licenses

Select the [Licenses] menu and then [ADD] to enter your license information. You will need to enter your Serial Number, Mask and Key, as shown on your License card.

After enteringyour information and selecting [SAVE],

the system will display a list of licensed features.

If the system states that the license is “not ok” then you have entered an invalid Serial Number, Mask, and Key

combination. Delete the invalid entry (marking the entry for deletion with the spacebar, then selecting delete) and enter your information again.

You can use the ‹Tab› key to move directly from one ﬁeld

☞

to the next. Useful for moving from a ﬁeld containing a long list of entries directly to the next ﬁeld.

Once you have entered your license information,

select [EXIT] to return to the main menu.

System

☞

Select[System] fromthemain menu.The onlyrequiredentries at this time are the ﬁrst two ﬁelds (System Name and Local PPP ID); this information will be used as the BRICK’s hostname and PPP ID. With the exception of the admin, read, and write Password/Community ﬁelds, the other ﬁelds are not required and can be edited later. The SNMP Community ﬁelds deﬁne the passwords that are required for logging into your BRICK via the network.

You can, of course, enter the same name in both ﬁelds. In our example both System Name and Local PPP ID are set to brick (see page 8).

Select [SAVE] to accept the entries and return to the

main menu.

CONFIGURATION

Setting up the LAN Interface

Select [CM-100BT, Fast Ethernet] to conﬁgure your ethernetinterface. Inthe following menuyou willneed toenter the IP address, local netmask1, and type of encapsulation to use on your BRICK. For now, you can select Ethernet II encapsulation.

The settings for our example setup on page 8 are shown below.

BIANCA/BRICK-X21 Setup Tool BinTec Communications AG [SLOT 3 ETHERNET]: Conﬁgure Ethernet Interface mybrick

IP-Configuration

local IP-Number 199.1.1.2 local Netmask 255.255.255.0 Encapsulation Ethernet II

IPX-Configuration

local IPX-NetNumber 0

Encapsulation none Bridging enabled Advanced Settings >

SAVE CANCEL

Enter IP address (a.b.c.d or resolvable hostname)

Once your entries are correct, select [SAVE].

1. If you are using a standard netmask (e.g. 255.255.255.0), you can leave this ﬁeld empty.

BIANCA/BRICK-X21 GETTING STARTED

Setting up the ISDN Interface

Select[CM-2BRI, ISDN S0, Unit0] to conﬁgureyour ISDN interface. Note that you can conﬁgure your ISDN interface eitheras an ISDN dialup lineor as a leased line.Since the menu entries differ slightly depending on what type of ISDN line you are using, continue with the conﬁguration by performing the appropriate section as follows:

• For a Dialup Line configuration, referto pages 16 - 22.

• For a Leased Line configuration, refer to pages 22 - 25.

Dialup Line

Depending on which protocol your ISDN subscriber interface uses and whether or not the ISDN autoconﬁgurationwassuccessful, the [CM-2BRI,ISDN S0, Unit0] menu may be displayed as follows:

BIANCA/BRICK-X21 Setup Tool BinTec Communications AG [SLOT 2 UNIT 0 ISDN BRI]: Conﬁgure ISDN Basic Rate Interface mybrick

Result of autoconfiguration: Euro ISDN, point to multipoint ISDN Switch Type autodetect on bootup

D-Channel dialup B-Channel 1 dialup B-Channel 2 dialup

Advanced Settings > Incoming Call Answering >

SAVE CANCEL

Use <Space> to select

The ISDN autoconﬁguration procedure runs until either the proper protocol is detected or the switch type is set manually. If the cables are connected and auto detec-

tionjustkeeps running, youmay have toselect the appro-

priate ISDN protocol manually by scrolling through the

entries inthe ISDN Switch Type ﬁeld using thespacebar or

the left and right arrow keys.

Leaving the Switch Type setting to “autodetect on bootup”usually allowsthe BRICKtoautomatically detect the proper ISDN protocol each time the system boots.

To ensure data transfers are possible over ISDN, verify that the autoconﬁguration is correct or set your ISDN

switch type appropriately.

Once the switch type andchannelﬁelds are correct select [Incoming Call Answering >].

Incoming Call Answering

In this menu you will specify how your BRICK responds toincoming ISDNcallsand whichservicesit willsupport.

To enablerouting(i.e. toallowIP connectionsvia ISDN calls), use [ADD] to create a new entry and select PPP (routing)inthe Item ﬁeld(using the spacebar). Thenenter one of your BRICK’s ISDN numbers (or an EAZ) in the Number ﬁeld.

CONFIGURATION

BIANCA/BRICK-X21 Setup Tool BinTec Communications AG [][INCOMING]: Incoming Call Answering myBrick

Item Number Mode Username

ADD DELETE EXIT

BIANCA/BRICK-X21 GETTING STARTED

If you want to login to your new BRICK via the isdnlogin program, you also need to create an ISDN Login entry. A

differentNumber mustbe speciﬁed.Normally,thisis done by usinga different MultipleSubscriber Number (in Euro ISDN) or a different EAZ (for 1TR6).

Onceyour entriesarecorrect select[EXIT]to returnthe

[CM-2BRI, ISDN S0, Unit 0] menu; select [SAVE] to com- plete the conﬁguration of the ISDN interface and return to the main menu.

WAN Partner

Select [WAN Partner]. This menu displays a list of known WAN partners and initially will be empty.

To adda newWANpartner select[ADD]. Amenu sim-

ilar to the following will be displayed. For our example setup, we have already ﬁlled in the appropriate ﬁelds.

BIANCA/BRICK-X21 Setup Tool BinTec Communications AG [WAN][ADD]: Conﬁgure WAN Partner mybrick

Partner Name partnerbrick Encapsulation PPP

Compression none Encryption none Calling Line Identification no

WAN Numbers > PPP > Advanced Settings >

IP > IPX > Bridge >

SAVE CANCEL

Enter string, max length = 25 chars

In the Partner Name ﬁeld, enter a name for this partner;

normally the partner’shostname is used. You can specify

CONFIGURATION

theencapsulation touse,and whetherornot tocompress/ encrypt data.Calling Line ID, (CLID) isenabled automatically once you conﬁgure am ISDN number (in the next step).

WAN Numbers

After adding the WAN partner information, select the [WAN Numbers >] submenu. This menu lists the WAN numbers this partner can be reached at and initially will be empty. Select [ADD] to enter a new WAN number for the partner you just conﬁgured.

In the ISDN number ﬁeld, enter the ISDN telephone number your partner’s router can be reached at. To take advantage of ISDN’s CLID feature, select “both (CLID)” in the Direction ﬁeld.

Select [SAVE], and then [EXIT] to returnto the partner settings menu.

PPP Settings

Now go into the [PPP >] submenu and conﬁgure the PPP settings to useforthis link. Here we deﬁne the type ofauthentication to use for call setup. In our example we are routing IP trafﬁc, and will use both PAP and CHAP au-

BIANCA/BRICK-X21 GETTING STARTED

thentication. Then enter the PPP Password the remote site must match when performing authentication.

BIANCA/BRICK-X21 Setup Tool BinTec Communications AG [WAN][ADD][PPP]: Conﬁgure WAN Partner mybrick

Authentication CHAP + PAP Partner PPP ID partnerbrick Local PPP ID mybrick PPP Password secret

Keepalives off Link Quality Monitoring off

OK CANCEL

Enter string, max length = 25 chars

Select[OK] toreturnto themain [WAN Partner]menu.

IP Partner Conﬁguration

Selectthe [IP>] submenuandconﬁgurethe IPparameters for this WAN partner. Depending on whether you areus-

CONFIGURATION

ing a transfer network, enter the IP Network address and netmask1 for your WAN Partner.

BIANCA/BRICK-X21 Setup Tool BinTec Communications AG [WAN][ADD][IP]: IP Conﬁguration (partnerbrick) mybrick

IP Transit Network no

Partner’s LAN IP Address 200.1.1.0 Partner’s LAN Netmask 255.255.255.0

SAVE CANCEL

Enter IP address (a.b.c.d or resolvable hostname)

Select[SAVE]twice, andthen [EXIT]toreturntoSetup Tool’s main menu.

IP Conﬁguration

From the main menu select [IP]. From the submenus which are displayed select [Routing]. This menu displays a list of routes known to the BRICK. Initially, the list will beempty.Select [ADD]to createa newdefaultroute. Your display will be similar to the menu shown below.

In the Route Type ﬁeld, select “Default route”.

In the Networkﬁeld select the appropriate entry (using the spacebar) to specify whether the default route should be over the LAN or WAN. For WAN routes,select the appropriate entry depending on whether you are using a transfer network.

In the Partner / Interface ﬁeld select the partner name the default route leads to. For our example, we added a

1. If you are using a standard netmask (e.g. 255.255.255.0), you can

leave this ﬁeld empty.

BIANCA/BRICK-X21 GETTING STARTED

default route without a transfer network to partnerbrick via ISDN.

BIANCA/BRICK-X21 Setup Tool BinTec Communications AG [IP][ROUTING][ADD]: Conﬁgure IP Routes mybrick

Route Type Default route Network WAN without transit network

Partner / Interface partnerbrick Metric 1

SAVE CANCEL

Use <Space> to select

Then select [SAVE] and then [EXIT] until you return

to the main menu.

Your conﬁguration is almost complete. Now proceed

to the section Saving your Conﬁguration on page 25.

Leased Line

If you connected your BRICK to an ISDN leased line, the WAN Interface submenu will appear similar to the following except thatthe ISDN Switch Type ﬁeld will display “autodetecton bootup”and eachof thechannel ﬁeldswill be set as “dialup” channels.

To conﬁgure the BRICK’s ISDN interface for use with

a leased line you will need to set the ISDN Switch Type, and D and B channel ﬁelds manually.

Scrollthrough the entries in theISDN Switch Type ﬁeld

andselect theentryforthenumber orchannels yourISDN line uses. Upon exiting this ﬁeld the cursor will jump to the ﬁrst channel used. For each channel used, specify which mode the channel should operate in.

CONFIGURATION

BIANCA/BRICK-X21 Setup Tool BinTec Communications AG [SLOT 2 UNIT 0 ISDN BRI]: Conﬁgure ISDN Basic Rate Interface mybrick

Result of autoconfiguration: autoconﬁguration disabled ISDN Switch Type leased line B1 channel (64s)

D-Channel not used B-Channel 1 leased dte B-Channel 2 not used

Incoming Call Answering > Advanced Settings >

SAVE CANCEL

Use <Space> to select

Once your entries are correct, select [SAVE] to return to the main menu.

WAN Partner

Select [WAN Partner] from the main menu. Select the “Leased, Slot 2 (0)” partner name. A menu similar to the following will be displayed.

BIANCA/BRICK-X21 Setup Tool BinTec Communications AG [WAN][ADD]: Conﬁgure WAN Partner mybrick

Partner Name Leased, Slot 2 (0) Encapsulation PPP

Compression none Encryption none Calling Line Identification no

WAN Numbers > PPP > Advanced Settings >

IP > IPX > Bridge >

SAVE CANCEL

Enter string, max length = 25 chars

BIANCA/BRICK-X21 GETTING STARTED

IP Partner Conﬁguration

Select the [IP >] submenu to set the IP parameters for this WAN partner. Depending on whether you are using a transfer network, enter the IP Network address and netmask1 for your WAN Partner’s LAN.

As shown on the following page we added the IP ad-

dressand netmask for partnerbrick.No transit network is needed in our example.

When ready, select [SAVE] twice, and then [EXIT]to

return to the main menu.

BIANCA/BRICK-X21 Setup Tool BinTec Communications AG [WAN][ADD][IP]: IP Conﬁguration (Leased, Slot 2 (0)) mybrick

IP Transit Network no Partner’s LAN IP Address 200.1.1.0

Partner’s LAN Netmask 255.255.255.0

SAVE CANCEL

Enter IP address (a.b.c.d or resolvable hostname)

IP Conﬁguration

From the main menu select [IP]. From the submenus which are displayed select [Routing], then [ADD] to add a default route for the BRICK to use.

In the Route Type ﬁeld, select “Default route”. In the

Network ﬁeld specify whether the default route should be over theLAN or WAN. For WAN routes,select the appropriate entry depending on whether you areusing a trans-

1. If you are using a standard netmask (e.g. 255.255.255.0), you can leave this ﬁeld empty.

CONFIGURATION

fer network. In the Partner / Interface ﬁeld select the partner name the default route leads to. For our example we added a default route without a transfer network to partnerbrick via ISDN. (See the following page).

BIANCA/BRICK-X21 Setup Tool BinTec Communications AG [IP][ROUTING][ADD]: Conﬁgure IP Routes mybrick

Route Type Default route Network WAN without transit network

Partner / Interface Leased, Slot 2 (0) Metric 1

SAVE CANCEL

Use <Space> to select

Then select [SAVE]. Return to the main menu by selecting [EXIT] twice. Your conﬁguration is almost complete. Now proceedto the next section Saving yourConﬁg- uration.

Saving your Conﬁguration

Once you have ﬁnished conﬁguring either your ISDN dialup or leased line, select [Exit] from the main menu.

For an initial conﬁguration you should select [Save as boot conﬁguration and exit]. Your initial conﬁguration is now complete and is saved in a ﬂash ROM ﬁle named “boot”. You are then returned to the BRICK’sSNMPshell prompt.

The conﬁguration ﬁle saved as “boot” will be used upon

☞

each new system start.

BIANCA/BRICK-X21 GETTING STARTED

For information on conﬁguration management and

the transfer of conﬁguration ﬁles to/from remote hosts via TFTP refer to the BRICK User’s Guide.

Testing your Conﬁguration

LAN Test

ISDN Test

To test your new conﬁguration try issuing a simple ping command to a PC ontheBRICK’s LAN to verify the LAN interface is properly conﬁgured. In our example, we would issue:

ping -c 5 199.1.1.1

If theLAN portion of theconﬁguration was successful

you should receive output similar to the following:

PING 199.1.1.1: 64 date bytes

64 bytes from 199.1.1.1: icmp_seq=0. time=8. ms

64 bytes from 199.1.1.1: icmp_seq=1. time=1. ms

64 bytes from 199.1.1.1: icmp_seq=2. time=1. ms

64 bytes from 199.1.1.1: icmp_seq=3. time=1. ms

64 bytes from 199.1.1.1: icmp_seq=4. time=1. ms

----199.1.1.1 PING Statistics----

5 packets transmitted, 5 packets received, 0% packet loss

round-trip (ms) min/avg/max = 1/2/8

To verify the ISDN portion of the conﬁguration is correct, try the samecommand using the IP address of the remote router (200.1.1.1 in our example) or a host on the remote LAN.

Ifthe pingcommand to theremoterouter issuccessful,

try issuing another ping command using the IP address of a computer on the remote partner’s LAN.

Once all ping commands are successful, your conﬁg-

uration is complete.

Troubleshooting

If anyof the ping commands areunsuccessful, refer tothe Troubleshooting chapter in the BRICK User’s Guide.

Getting the latest BRICK News and Software

Now that your BRICK is up and running, you might like to visit our WWW site at

http://www.bintec.de

to keep abreast of new developments at BinTec Communications GmbH.

Via our WWW server BinTec provides you free of charge with the most recent versions of:

• User documentation for your BinTec software and hardware in Portable Document Format (PDF).

• System software for your BRICK.

You will find instructions on how to update system

☞

software in the User’s Guide, chapter 8, section Upgrading System Software.

• Release notes for upgrading your BRICK’s system software.

• Windows software and UNIX Tools applications.

BIANCA/BRICK-X21 GETTING STARTED

BINTEC ROUTERS IN THE UK

BinTec ROUTERS

Setting up a BinTec Router in the UK

To get your BinTec router up and running in the UK you should follow the UK-speciﬁc instructions given below.

Please note that we will use the term BRICK here to in-

☞

Differences in the UK

clude all models of the BIANCA/BRICK family of routers.

IN THE UK

☞

Multiple Subscriber Numbering (MSN)

In the UK, unlike in other European countries, you only get one ISDN telephone number by default.

This makes accepting calls for different ISDN services a little more difﬁcult—a solution is presented on the following pages.

An optional service called MSN (Multiple Subscriber Numbering) is availableat a charge, and providesa block of ten consecutive numbers for incoming callers to use (e.g. 811910, 811911, …, 811919).

If you want to use the CAPI services (e.g. Euro ﬁle transfer or Fax server)ofyour BRICK in addition to TCP/IP or PPP connections, you will have to order the MSN service from your telephone company.

BINTEC ROUTERS IN THE UK

Calling Line Identiﬁcation (CLIP)

The CLIP feature (calling line identiﬁcation presentation) is also a purchasable option.

For security reasons PPP connections should there-

fore be conﬁgured to use either the PAP or the CHAP authentication protocols—or both—for incoming call identiﬁcation; see section WAN Partner / PPP on pages 31 (Setup Tool) or 34 (SNMP client shell).

Also note that international calls from the Republic of

Ireland do not contain a CLI information.

If you want the additional security of calling line identi-

☞

ﬁcation for PPP connections, both you and your communication partner(s) have to order the CLIP feature.

International ISDN Calls

The code for dialling international ISDN calls from the UK is not 00 (as with normal voice calls), but 000. The

British Telecom willsometimes route callsprecededby 00 over normal audio lines, even when they originate from the ISDN.

Conﬁguring your BRICK

The UK-speciﬁcsettings for your BRICK aredescribedon the following pages. The ﬁrst section (starting below) deals withconﬁguring your BRICK using thebuilt-in Setup Tool, subsequently (from page 33) the same settings are explained using the BRICK’s SNMP Client Shell.

Setup Tool

Follow the instructions from the “Getting Started” manual up to “Incoming Call Answering”.

SETTING UP A BINTEC ROUTER IN THE UK

Routing

In this menu you will specify how your BRICK responds to incoming ISDN calls and which services it will support.

BIANCA/BRICK Setup Tool BinTec Communications AG

[WAN][INCOMING]: Incoming Call Answering mybrick

____________________________________________________________________

Item Number Mode

ADD DELETE EXIT

____________________________________________________________________

To enable routing (i.e. to allow IP connections via ISDN calls), use [ADD] to create a new entry and select PPP(routing)in the Item ﬁeld(usingthe spacebar). Leave the Number ﬁeld blank—this will accept all incoming calls.

WAN Partner / PPP

Do not additionally make an ISDN Login entry. A way to enable logging in to your BRICK via ISDN can be found in section Login via ISDN on page 33.

Once yourentries are correctselect [SAVE] to returnto the [CM-1BRI, ISDN S0] menu; select [SAVE] once more to complete the conﬁguration of the ISDN interface and return to the main menu.

Select [WAN Partner]. This menu displays a list of known WAN (i.e. ISDN) partners and initially will be empty. To add a WAN partner select [ADD]. A menu similar to the following will be displayed. For our example setup, we have already ﬁlled in the appropriate ﬁelds.

BINTEC ROUTERS IN THE UK

BIANCA/BRICK Setup Tool BinTec Communications AG

[WAN][ADD]: Conﬁgure WAN Partner mybrick

____________________________________________________________________

Partner Name partnerbrick Enabled Protocols <X> IP Encapsulation PPP Identify by Calling Number no PPP Authentication Protocol CHAP and PAP Partner PPP ID partnerbrick Local PPP ID (sysName) mybrick PPP Password secret

ISDN Numbers > IP >

Advanced Settings >

____________________________________________________________________ Enter string, max length = 25 chars

As youedit each ﬁeld the remainingﬁeldswill change

depending on which options you select.

In thePartner Name ﬁeld, entera name for thispartner;

normally the partner’s hostname is used.

You can specify whichprotocols to route,the encapsu-

lation to use (PPP), and the type of authentication to use for call setup (CHAP and PAP). In our example we are routing IP trafﬁc, do not use the calling line identiﬁcation feature (CLIP), andwilluse both PAPand CHAP authentication for security reasons.

SAVE CANCEL

Ifthe remotehost isa BRICK thenthe PartnerPPP IDmust be set to the remote BRICK’s hostname (i.e. the contents

of sysName up to the ﬁrst dot (“.”).

Then enter the PPP Password the remote site must

match when performing authentication.

From here you can continue your conﬁguration as de-

scribed in the ISDN Numbers section in this manual.

SETTING UP A BINTEC ROUTER IN THE UK

SNMP Client Shell

If you want to conﬁgureyour BRICK from the SMNP Client Shell (see User’s Guide), you can enter the following commands directly at the BRICK’s command prompt after logging in to your BRICK as user admin with the password bintec (please refer to your Getting Started manual for different ways of accessing your BRICK).

Routing To enable routing (via IP, IPX, X.25, or bridging) enter

the following commands:

isdnDispatchTable

This will display the isdnDispatchTable, which should be empty if you access your BRICK for the ﬁrst time. Here you can create an entry to accept incoming PPP calls. The LocalNumber ﬁeld can remain empty— this will accept all PPP calls received by your BRICK.

StkNumber=0 Item=ppp

ISDN (e.g. from another BRICK) you have to enter the following command:

isdnLoginOnPPPDispatch=allow

This allows incoming ISDN calls with an ISDN service indicator of “telephony” to be connected to the isdnlogin daemon even though the call has a matching service in the isdnDispatchTable (isdnDspItem).

To login to your BRICK from another BRICK use the command

isdnlogin ‹ISDN number of your BRICK› telephony

If you are already using a BinTec ISDN product for UNIX you can enter the line

BINTEC ROUTERS IN THE UK

to your /usr/bianca/conﬁg/services ﬁle and then use the command

to login to your BRICK.

* bricktel 001001

isilogin -s bricktel ‹ISDN number of your BRICK›

WAN Partner / PPP

Now you can setup a PPP interface for incoming calls.

First create a new entry in the biboPPPTable, select both CHAP and PAP as authentication protocols, and enter the name and password for your communications partner:

biboPPPType=isdn_dialup ➯

biboPPPAuthentication=both ➯ biboPPPAuthIdent=partnerbrick ➯ biboPPPAuthSecret=secret

Then display the biboPPPTable and note down the

IfIndex ofthis entry. Youcan nownamethe interface entry by assigning a new value to the Descr ﬁeld with the appropriate IfIndex in the IfTable.

IfTable

Descr:‹inx›=partnerbrick

Finally enter the ISDN number of your communica-

tion partner in the biboDialTable:

biboDialTable

1. The arrows “➯” atthe end of these lines indicate that the command

continues on the next line, and you have to type all the lines as one command (entering the “Return” key only after the last line).

SETTING UP A BINTEC ROUTER IN THE UK

IfIndex=partnerbrick ➯ Number=‹ISDN number› ➯ Direction=outgoing

Now all incoming calls and outgoing calls to your partner are handled by the PPP interface.

For further instructions on conﬁguring your BinTec router please refer to its User’s Guide.

BINTEC ROUTERS IN THE UK

BinTec BIANCA, BRICK-X21 Getting Started

Specifications and Main Features

Frequently Asked Questions

User Manual

Features

Software Installation

Installing the BRICK

LED Indicators

CONFIGURATION

Gathering the Information

Accessing the BRICK

Over Serial Port

With a terminal or terminal program (UNIX or PC)

Over LAN Interface

From a Windows PC using DIME Tools

Over ISDN

From any computer using telnet

From a computer connected to another BRICK

SNMP shell

Third party SNMP Manager

Licenses

System

Setting up the LAN Interface

Setting up the ISDN Interface

Dialup Line

Incoming Call Answering

WAN Partner

WAN Numbers

PPP Settings

Leased Line

WAN Partner

Troubleshooting

Getting the latest BRICK News and Software

BINTEC ROUTERS IN THE UK

Setting up a BinTec Router in the UK

Differences in the UK

Multiple Subscriber Numbering (MSN)

International ISDN Calls

Setup Tool

SNMP Client Shell
