beyerdynamic Lagoon ANC User Manual

Lagoon ANC

luetooth® Headphones

B

Traveller (black blue/black) Order # 715.517

xplorer (grey/brown) Order # 718.238

E

FEATURES

• MOSAYC sound personalisation (via MIY app)

• Best sound in its class

• Outstanding wearing comfort
due to soft ear pads

• Digital Active Noise Cancelling (ANC) in two stages

• Operation via touchpad

• beyerdynamic Light Guide System to display
various operating states

DESCRIPTION

The Lagoon ANC combines sound perfection and
technical intelligence. The Lagoon ANC features an
excellent sound whether with activated or deactivated
noise cancelling. With the beyerdynamic MIY app, users
can personalise the sound of their headphones. The
hea of this app is the innovative MOSAYC sound
personalisation based on research by Mimi Hearing
Technologies. The sound is exactly adapted to the
personal hearing profile of the user. At the same time, the
app provides information about the liening habits of
the user, so that the hearing can be preserved. The app
is available for Apple iOS and Android and can be
downloaded from the Apple App Store and Google Play
Store.
The Bluetooth® wireless technology can be used with all
Bluetooth®-enabled devices such as smartphones, tablets
or computers. A range of up to 10 meters allows sufficient
freedom of movement. The following codecs are used for
Bluetooth® transmission: Qualcomm® aptX™ Low Latency
(for sound transmission with minimum delay), aptX™ and
AAC. If no Bluetooth® device is available or the recharge­able battery is empty, the headphones can also be used
with the supplied mini jack cable (3.5 mm).

• Bluetooth® 4.2 with the latest audio codecs
(Qualcomm® aptX™ Low Latency, aptX™, AAC)

• Qualcomm® cVc™ technology
for best intelligibility of speech

• Range up to 10 m

• Runtime Bluetooth® up to 45 hours (without ANC)

• USB-C charging socket

The closed design prevents music from penetrating to
the outside and ambient noise from penetrating to the
inside. Due to the digital Active Noise Cancelling with
hybrid technology, disturbing noise can easily be
suppressed via two adjustable intensity levels – perfect
when travelling by train or plane. Active Noise Cancelling
works particularly well at low frequencies, which are
typically encountered in trains or aircrafts.
The innovative Light Guide System in the housing shells
indicates the operating status. For conversations the
housing shell has an integrated microphone. Qualcomm®
cVc™ is used for superior intelligibility of speech in head­set operation. Media playback and phone calls are
controlled via a touchpad on the right-hand side. Voice
prompts in German or English, e.g. for battery status, also
contribute to a user-friendly operation. A USB-C port is
used to charge the integrated battery.
When the headphones are not in use, they can be stored
in the supplied high-quality hard case.

1 of 2

beyerdynamic GmbH & Co. KG
Theresienr. 8 • 74072 Heilbronn – Germany
Tel. [phone] / 617 - 300 • [e-mail] • www.beyerdynamic.com

For fuher diributors worldwide, please go to www.beyerdynamic.com
Non-contractual illurations. Contents subject to change without notice. E1/Lagoon ANC (04.19)

Lagoon ANC

TECHNICAL SPECIFICATIONS

Transducer type. . . . . . . . . . . . dynamic

Operating principle . . . . . . . . closed

Frequency response. . . . . . . . 10 – 30,000 Hz

Nominal impedance. . . . . . . . 20 Ω

Nominal SPL . . . . . . . . . . . . . . . . 91 dB SPL (@ 1 mW @ 500 Hz)

Max. SPL. . . . . . . . . . . . . . . . . . . . 107 dB SPL (@ 40 mW @ 500 Hz)

T.H.D. . . . . . . . . . . . . . . . . . . . . . . . < 0.02 % ((@ 1 mW @ 500 Hz)

Speaker diameter . . . . . . . . . . 40 mm

Nominal power handling

capacity . . . . . . . . . . . . . . . . . . . 40 mW

Sound coupling to the ear. . circumaural
Nominal headband

pressure. . . . . . . . . . . . . . . . . . . . 5.4 N

ANC . . . . . . . . . . . . . . . . . . . . . . . . digital, hybrid

(feedback and
feed-forward),
adjustable in two stages

Bluetooth®. . . . . . . . . . . . . . . . . . version 4.2, power class 1,

compatible with playback
devices from Bluetooth®
version 4.0

Supported profiles . . . . . . . . . AVRCP 1.6

A2DP 1.3
HSP 1.2
HFP 1.7
GAP 1.3
SDP 2.1
SPP 1.2

Supported codecs . . . . . . . . . aptX Low Latency™

aptX™
AAC
SBC
mSBC

Frequency range . . . . . . . . . . . 2.402 – 2.480 GHz

Transmission power . . . . . . . . 10 dBm

Qualcomm® cVc™ . . . . . . . . . . yes

Range . . . . . . . . . . . . . . . . . . . . . . up to 10 m

Pairing via NFC . . . . . . . . . . . . . yes

Volume . . . . . . . . . . . . . . . . . . . . . adjustable in 32 steps (A2DP)

Firmware update possible. . yes

Runtime Bluetooth®. . . . . . . . . up to 45 hrs. (without ANC)

up to 24.5 hrs. (with ANC)
Runtime

without Bluetooth® . . . . . . . . . up to 31.5 hrs. (with ANC)

Talktime Bluetooth®. . . . . . . . . up to 47 hrs.

Charging time . . . . . . . . . . . . . . approx. 3 hrs.

Battery type. . . . . . . . . . . . . . . . Lithium polymer

Battery capacity . . . . . . . . . . . 1100 mAh

Battery cycle life . . . . . . . . . . . min. 500 full charging cycles

Charging port . . . . . . . . . . . . . . USB-C

Operating temperature

range . . . . . . . . . . . . . . . . . . . . . . 0 to 40 °C

Charging temperature

range . . . . . . . . . . . . . . . . . . . . . . 0 to 40 °C

Weight (without cable) . . . . . 283 g

Connecting cable . . . . . . . . . . 1.20 m, mini jack

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . (3.5 mm/3-pole),

single sided on the

right-hand side, detachable

SUPPLIED ACCESSORIES

• Hard case for storage

• Charging cable USB-A to USB-C

• Analogue audio cable with mini jack (3.5 mm)
