2014 Product Presentation

1

Beverage-Air

®

Contacts

Factory Headquarters Sales Office

3779 Champion Blvd
Winston-Salem, NC 27105
Phone: [phone]
Fax: [phone]
Email: [e-mail]
Web: www.beverage-Air.com

Factory Customer Service

Phone: [phone]
Fax: [phone]

Customer Service Team

Debra Goins- [e-mail]
Joe Garrison – [e-mail]
Melody Neville – [e-mail]
Lakin Rogers – [e-mail]
Christopher Faulwetter – [e-mail]

24-Hour Warranty Dispatch – [phone]

Manufacturing Facility

119 Progress Street
Brookville, PA 15825

Warehouse

1028 Route 28
Brookville, PA 15825

Factory Technical Service

Phone: [phone]
Fax: [phone]

Technical Service Team

Glenda Howard – [e-mail]
Darren Roberts – [e-mail]
Cedric Leverett – [e-mail]
Justin Vettel – [e-mail]
Steve Reynolds – [e-mail]
Mike Humphrey – [e-mail]
Courtney Sherwood – [e-mail]

2

Beverage-Air®Product Offerings

Offering You The Most Complete Product Offering,

Unmatched Quality & Leading Innovation

Reach-Ins

Milk Coolers

Blast Chillers

Food Preparation

Glass Door Merchandisers

Worktops/

Bar Equipment

Undercounters

Open Air Merchandisers

3

Beverage-Air

®

Warranty

Effective January 1, 2013

Standard warranty – 3 years parts & labor

Additional 2 years (compressor parts only)

CT/CF models carry 1 year parts/labor/compressor

warranty

4

Beverage-Air

Manufactured in Brookville, PA USA

®

Made in the USA

Corporate Headquarters in Winston-Salem, NC / LEED® certification

5

Beverage-Air

What Separates Us

• Celebrating 70 years of American made innovation in 2014

• 2” thick CFC & HCFC-free foam refrigerant

• Unmatched, Award winning customer service & support

• Breadth of product offering

• 24 hour, 7 day a week Service Center

• Phone: [phone]

®

• ANY certified refrigeration contractor can work on Beverage-Air equipment under warranty

• Equipment & accessories receive your same discount

• Online warranty processing with 24-hour acknowledgement

• Online warranty registration

6

Prep Tables

Ambient

Class

of 100°F

7

Sandwich Prep Tables

Ambient

Standard Top Prep Tables

Mega Top Prep Tables

Cutting Top Prep Tables

A complete line of food prep tables

Class

of 100°F

Sandwich Prep

Drawer Units

Pizza Prep Tables

Pizza Prep Tables

With Drawers

8

Prep Table Specifications

Ambient

Sandwich prep tables – all SPE series

Standard specifications

Performs in high ambient kitchen temps
Field reversible doors
Locking divider bars
Heavy-duty pan liner
Accommodates up to 6” deep pans; 4” deep pans included
Snap-in magnetic gaskets
2 shelves per section (1 large + 1 small)
Self-closing heavy-duty cartridge style hinge
120° stay-open door feature
Heavy-duty insulated lids
Standard, Mega, Cutting Top models available
Reversible cutting boards

Standard and Mega Tops feature 10” deep poly cutting boards

Cutting tops feature 17” deep poly cutting board
Cutting top models – great option for pizza/deli prep option vs. raised rail units 17” cutting board
ADA compliant models available – 3” caster height
Drawer units available

Top drawers accomodate 4” deep pans
Bottom drawers accommodate up to 6” deep pans

Class

of 100°F

Unmatched capacity

SPE27” – 7.3 CU. FT.

COMPETITOR 1 – 6.5 CU. FT.
COMPETITOR 2 – 6.5 CU. FT.

SPE36” – 10.2 CU. FT.

COMPETITOR 1 – 8.5 CU. FT.
COMPETITOR 2 – 9.5 CU. FT.

SPE48” – 13.9 CU. FT.

COMPETITOR 1 – 12 CU. FT.
COMPETITOR 2 – 12 CU. FT.

SPE60” – 17.1 CU. FT.

COMPETITOR 1 – 15.5 CU. FT.
COMPETITOR 2 – 15.5 CU. FT.

SPE72” – 21.5 CU. FT.

COMPETITOR 1 – 19 CU. FT.
COMPETITOR 2 – 19 CU. FT.

9

Prep Tables

Air flow – all SPE series

10

Prep Table

Line Drawings

Differentiating specifications

Standard top models features a 10” deep poly cutting board; measures 29” depth front to back
Mega top models feature a 3rdrow of pans for 50% greater pan capacity; measures 34” depth front to back
Cutting top models feature a 17” deep cutting board for added space; measures 34” depth front to back

Standard top Mega top

SPE72-18

10” deep cutting board

* Pan opening can be reversed when specified at time of order

* Available on Standard, Cutting, & Mega Top Models

10” deep cutting board

SPE48-08 standard

SPE72-30M

SPE48-08 pan opening reversed

Cutting top

SPE72-18C

17” deep cutting board

11

Prep Table Specifications

Ambient

Class

of 100°F

Field-reversible doors

Field-reversible doors (see competition)

Locking divider bars

Eliminates pans from moving
Allows flexibility of pan configurations

Heavy-duty pan liner

Eliminates food spillage into the cabinet
Protects base cabinet temperature
Unexposed evaporator coil (see competition)
Holds up to 6” deep pans

Snap-in magnetic gaskets

Provides positive seal to prevent cold air from escaping unit
will stay colder longer and use less energy

Easy to remove for cleaning or reversible for additionaluse

Cartridge-style door hinges

Eliminates door sagging
Designed to withstand weight of triple pane glass doors
Field-reversible doors (see competition)

Field-

Reversible

Locking

Divider Bars

Heavy-Duty

Pan Liner

Gaskets

Cartridge-Style Door

Hinges

12

Prep Table Specifications

Shown with optional Side Guard Kit

Ambient

See-thru lid prep tables

Class

of 100°F

Standard specifications

Same great benefits & features as all of our prep tables
1-piece hinge with hydraulic lift
Self-closing lid
Lightness of lid
Lid features variable set points for height variations
Side guards not required if sides not exposed to customer
Optional overshelf with side guards available
Locking divider bars
Heavy-duty pan liner
Self-closing heavy-duty cartridge hinge with 120° stay-open feature
Models: SPE48-18M-STL, SPE60-24M-STL, SPE72-30M-STL

13

Prep Table Specifications

Condiment Stations

Standard specifications

Same great benefits & features as all of our prep tables
Locking divider bars
NSF approved sneezeguard
Optional door locks & thermometers
Single or dual access
Heavy-duty pan liner
Self-closing heavy-duty cartridge hinge with 120° stay-open feature
Finished back
Accommodates up to 6” deep pans
Models: SPE27-SNZ, SPE48-12-SNZ

Ideal for ice cream topping bars, salsa bars, condiments

Ambient

Class

of 100°F

NSF APPROVED

SNEEZEGUARD

14

Prep Table Specifications

Dual-Sided Prep Tables

Dual-Sided specifications

Same great benefits & features as standard prep tables
Dual-sided hood assembly or lift-off lid option

(only dual-sided hood assembly in the industry)

Front 10” deep cutting board / Back ledge 12” deep cutting board
Doors/Drawers available (1 side only)
Cutting board options
Pass-Thru overshelves
Single/Double overshelves available
Optional night covers available
Models: SPE27-12M-B-DS, SPE36-15M-DS SPE48-18M-DS,

SPE60-24M-DS, SPE72-30M-DS

Ambient

Class

of 100°F

Available in 27”, 48”, 60” & 72” mega top widths

Example of optional night covers & composite cutting boards

15

Prep Table Options

Options

6” casters standard; 3” casters or 6” legs no charge
at time of order
Overshelf assemblies
Composite cutting boards (poly standard)
Puzzle piece cutting boards (poly standard)
Crumbcatchers

Field retrofittable (no drilling required)

Front or side crumbcatchers available
Locks
Night covers
Bun tray racks
12” crossbars
Lo-profile casters (ADA)
Bottle divider kit
Shelf organizers (adjustable)

Ambient

Class

of 100°F

Single overshelf

Crumbcatcher

Night covers

Shelf organizers

Bottle divider kit

(keeps temps of bottles 36° – 38°F)

16

Pizza Prep Tables

DP Series – all models

Standard specifications

19” deep reversible cutting board
Snap-in magnetic gaskets
Self-closing heavy-duty cartridge style hinge with 120° stay-open feature
2 shelves per section
Heavy duty interior liner
Heavy duty insulated covers
Accomodates up to 6” deep food service pans – pans not included
3” casters
Raised rail maintains product temperatures between 36 – 38F
SPE Cutting top models – great option for pizza/deli prep option vs. raised rail units

- 17” cutting board

Drawer units available

Drawer slides have locking mechanism
Drawers accommodate 4” or 6” deep pans – pans not included
Pan divider supports included
Snap-in magnetic gaskets for positive seal
Drawers extend 23” (when opened)

17

Worktops/

Ambient

Class

of 100°F

Undercounters

18

Worktops & Undercounters

Standard specifications

S/S front, sides & top
Anodized aluminum interior
Field reversible self-closing doors
Cartridge style hinges with 120° stay-open feature
Snap-in magnetic gaskets
2” thick polyurethane insulation
Freezers operate at 0°F
Adjustable epoxy coated steel wire shelves (1 large + 1

small)

6” casters, 2 with brakes standard on 29” & 32” depth units
Shallow depth models available
Refrigerators utilize R134a; Freezers utilize R404A
Drawer availability
Glass door models available
Offering the smallest undercounters in the industry -

UCR/UCF20, UCR34Y

Double stacking offers low cost dual-temp options

Ambient

Class

of 100°F

29” & 32”

Base Models

Shallow

Depth Models

Dual-Temp

Models

Options

UCR20/UCF20, UCR27/UCF27 & UCR27A/UCF27A
stacking collar

Overshelf assemblies
Bottle divider kits
Roller kits
ADA models available
Puzzle-piece cutting board assemblies

19

Chef Bases

Ambient

Class

of 100°F

20

Chef Bases

Standard specifications

Lifetime warranty on all drawers & slides
S/S exterior, interior, top (complete unit 100% S/S)
16 gauge S/S insulated top to eliminate heat penetration into cabinet
No heat shield required
Heavy-duty 12 gauge drawer frames & slides
Three s/s ball bearing wheels per slide
Heavy-duty s/s full marine drip guard edge
Flat top models without marine edge available upon request
Top drawers accommodate two 6” deep 12” x 20” pans
Bottom drawers accommodate two 4” deep 12” x 20” pans
Certified to 100°F ambients
Exterior digitial thermometer
Front air breathing
Workflow handles
Heavy-duty 6” casters standard

Add 12” on

Ambient

Class

of 100°F

either side for
extended top!

21

A Complete Line of

Ambient

WTRCS36

Series

WTRCS36-1 WTRCS36-1-48

WTRCS60/6

4 SERIES

WTRCS72

SERIES

Chef Bases

Class

of 100°F

WTRCS52

SERIES

WTRCS52-1 WTRCS52-1-60 WTRCS52-1-72

WTRCS84

SERIES

WTRCS84-1

WTRCS84-1-89

WTRCS112-1

WTRCS84-1-108

WTRCS112

SERIES

WTRCS84-1-96

22

WTRCS112-1-120

Ambient

Class

of 100°F

Horizon Series

Top Mount Reach-In’s

23

Horizon Series

Top Mount Reach-In’s

Standard specifications

1 piece grille
Full electronic control with 1-touch defrost
Stainless steel front
Aluminum interior
Expansion valve (freezer models)
Door locks
Field reversible doors
Snap-in magnetic gaskets
Recessed plenum
Cam-lift hinges
Incandescent light – solid doors
Fluorescent light – glass doors

LED Lighting optional – glass doors
2 pane lowE glass – glass door models
Anti-microbial handles

Recessed

New

Lights!

Ambient

Class

of 100°F

H – Horizon Series Top-Mount Cabinet

R- Cooler / F- Freezer

P – Stainless Steel Exterior Sides

Electronic control

Electronic control features a digital display of cabinet
temperature, easy to adjust temperature set point & 1­touch defrost

1-touch

defrost

Set temp

Adjust temps

S – Stainless Steel Interior

1 – Single Section

1 - 115 volt

S - Solid Door

24

Horizon Series

Top Mount Reach-In’s

 ENERGY STAR® qualified
 More energy efficient components (better energy

efficiency)

 New compressor technology
 Improved airflow
 All refrigerators are designed to maintain 33°-40°F
 All freezers are designed to maintain 0° to -10°F

Ambient

Class

of 100°F

25

Horizon Series

Top Mount Reach-In’s

Expansion Valve – Freezers (TXV Valve)

 Benefits of expansion valve

 Maximum efficiency over a wide temperature & load

condition.

 Improved refrigerant return to compressor ensure better

cooling at wide range of temperatures & reduces the
possibility of liquid slugging which can destroy the
compressor.

Ambient

Class

of 100°F

 Variations of capacity over the ambient temperature range

of 80°F can cause a performance loss of 85% with a cap
tube system on freezers maintaining 0° to -10°F. An
expansion valve system will use less than ½ this amount
while maintaining better cabinet temperature control.

 When temperatures rise, the expansion valve balances

the refrigerant flow to the heat load by sensing the
temperature of the refrigerant leaving the evaporator &
opens when necessary to increase refrigerant to provide

quicker recovery.

26

Horizon Series

Top Mount vs. Bottom Mount –

1/2 solid vs. solid

When do I order a Top Mount vs. a Bottom Mount?

Answer: Ideally, Top Mount units should be used in the “front of

the house”/cook line. Bottom Mount units ideally are meant for

“back of the house” dry storage. Dust/dirt potential for clogging

of coil (for bottom mount units placed in the front of the house).

Horizon Top
Mount

Ambient

Class

of 100°F

When to use a 1/2 solid door unit?

Answer: Cooler or freezer next to

fryer/dump stations or 90°F + kitchens

Horizon Bottom

Mount

K Series Bottom

Mount

27

Ambient

Class

of 100°F

Horizon Series

Bottom Mount Reach-in’s

28

Horizon Series

Bottom Mount Reach-In’s

Standard specifications

Stainless steel interior/exterior standard
1 piece grille
Expansion valve (freezer models)
Electronic control
Door locks
Snap-in magnetic gaskets
Cartridge-style hinges
Incandescent light – solid doors
Fluorescent light – glass doors
2 pane lowE glass
Anti-microbial handles
Optional LED lighting on glass door
units
Specify hinging at time of order (not field reversible)

Ambient

Class

of 100°F

Model Nomenclature

Refrigerators

HBR23-1
HBR27-1
HBR49-1
HBR72-1

Dual-Temp

Models Now

Available!

Freezers

HBF23-1
HBF27-1
HBF49-1
HBF72-1

29

Ambient

Class

of 100°F

K-Series/RI18 Series

Bottom Mount

30

K-Series

Bottom Mount Reach-In’s

Standard specifications

S/S front
CFC & HCFC-free polyurethane insulation
Enhanced digital control
Door open indicator alarm
120° stay-open door feature
Workflow handles
White expoxy shelves
Locking shelf clips
3” casters, 2 with brakes

Ambient

Class

of 100°F

Enhanced Digital

Control Adds Function

31

RI18 Series

Bottom Mount Reach-In’s

Model expansion + Benefits

Option 1: ½ Glass, Solid Doors
Option 2: ½ Solid Doors
Option 3: 1 Full Glass Door
Reach-In or Pass-Thru
69” height
S/S exterior/interior
4 shelves per section
27” depth (Shallow Depth)
18 cubic feet

Ambient

Class

of 100°F

1 SECTION

27 1/4” WIDTH

32

Dual-Temp

Ambient

Class

of 100°F

Reach-in’s

33

Top Mount

Dual-Temp Reach-in’s

Standard specifications

S/S interior/exterior
Solid and half-solid door models available
Field-reversible doors
Anti-microbial door handles
Snap-in door gaskets
3 shelves her door section
Incandescent interior lights
6” legs standard

Ambient

Class

of 100°F

PRF12-12-1HS-02

PRF24-24-1AS-02

PRF48-24-1AS-02

34

Ambient

Class

of 100°F

Heated Cabinets

35

Heated Cabinets

Standard specifications

S/S door & front
Aluminum exterior sides & interior – S/S options available
Reach-in & Pass-Thru models available
Self-closing doors
Door locks standard
Snap-in door gaskets
Anti-microbial door handles
Dial thermometer (80°-180°F)
3 shelves her door section
Incandescent interior lights
6” legs standard

Ambient

Class

of 100°F

PH1-1S/PH1-1S-PT

PH2-1S/PH2-1S-PT

36

Spec Series

Ambient

Class

of 100°F

37

Spec Series

Reach-in Refrigerator/Freezer

Standard Features:

Reach-in, Roll-In, Roll-Thru, & Pass-Thru Models Available
S/S exterior and interior.
Full 2” thick polyurethane insulation.
Durable foamed in place centre mullion.
Anti-microbial workflow handles - Easy to keep clean.
Down-Duct & Balanced Refrigeration System
Cam lift hinges with 120° stay open feature
Doors are field reversible.
Adjustable epoxy coated wire shelves with 1/2” intervals.
3 shelves per section
6” S/S legs and locks are standard.
Optional tray slide packages are standard.
Available in Solid, Half-Solid, Glass and Half-Glass Door
configurations.

Ambient

Class

of 100°F

38

Tray Slides

Wire Rod Kit

(18” x 26” pans)

Tray Module Slide

(18” x 26” pans)

Not available on K Series or HBR/HBF Series

Rim Support Kit
(12” x 20” pans)

Bottom Angle Tray Slide

(18” x 26” pans)

Universal Tray Slide

(18” x 26” pans, 14” x 18”

pans, 12” x 20” pans)

5 Tray Slide

Kits Available!

39

Reach-in Cross Reference

s

REACH-IN'S

Refrigera tion Mount

Exterior Finish
Interior Fi nish
Standa rd Ca ste rs
Ca bi n et Heig h t
Ca b in et Heigh t /Caster s
Solid Door Model
Gla ss Door Model
1/2 Glass Door Model
Control Type
Temperature
Cooler
Freezer
Locks Sta nda rd

K Ser ie

Bottom Bottom Top Top Top Top Bottom

S/S Front, Gray

sides

s/s Floor Stainless Aluminum Aluminum Stainless Stainles s Stainless

3" 3" 6" 6" 6" 6" 3"
78" 78" 78 1/2" 78 1/2" 78 1/2" 78 1/2" 69 1/ 4"
81" 81" 84 1/2" 84 1/2" 84 1/2" 84 1/2" 72 1/ 4"

Yes Yes Yes Yes Yes Yes Yes

No Yes Yes Yes Yes Yes Yes
No No Yes Yes Yes Yes Yes

Digital Electronic Electronic Electronic Electronic Electronic Thermostat

38/-10 de grees 38/-10 de grees 38/-10 de grees 38/-10 degrees 38/ -10 deg rees 38/-10 degrees 38

Cap Tube Cap Tube Cap Tube Cap Tube Cap Tube Cap Tube Cap Tube
Cap Tube Expans i on V al ve Ex pansion Valve Expans i on V al ve Expans i on Valve Expans i on V al ve N/A

Yes Yes Yes Yes Yes Yes No

HB Ser ies H series HP se r ies HS se r ies HPS ser ies RI se r ies

S/S Front &

Sides

S/S Front, Gray

si des S/ S F ront & Si des

S/S Front, Gray

sides

S/S Front &

Sides

S/S Front &

Sides

40

Bar Equipment

41

A Complete Line of Bar

Equipment

DEEP WELL BOTTLE

COOLERS

BARMOBILE

BACK BAR

REFRIGERATORS

DIRECT DRAW BEER

DISPENSERS

WINE

MERCHANDISERS

GLASS FROSTERS

42

Bar Equipment

Remote Units

Available on

What is a remote unit?

Answer:
Remote units are provided with the evaporator, but the condensing
unit/compressor is not provided (provided by other)

each bar

series!

43

Back Bar

Refrigerators

44

Back Bar Refrigerators

Standard specifications

Available in both shallow (23”) and deep depth (27”)
Black & s/s finish options available
Field reversible doors with 90° stay open feature
Locks standard
2 shelves per section
T-8 fluorescent lighting (glass doors)
Incandescent lighting (solid doors)
Approved for prepacked products
40° - 60°F wine models available

Sliding glass door options

Models: BB48GSY, BB58GS, BB72GSY
Double pane, lowE argon glass
Lightweight
Energy efficient
Door latch standard

Pass-Thru models

available on 48”,

72”, 78” & 94”

NOW A VAILABLE

1. 24” model now available

2. Standard features underbar & finished top models
available

3. Food rated models available

4. Black & stainless finish options available

45

Back Bar Refrigerators

Capacities

Back Bar
Capacity

BB24 140 180 110

BB36 220 240 170

BB48 300 288 325

BB58 440 528 365

BB68 550 672 435

BB72 480 540 505

BB78 630 740 560

BB94 785 920 675

12 oz.

Bottles

12 oz.

Cans

Long Neck

Bottles

46

Back Bar Refrigerators

Options

Casters/legs
Lane dividers for bottled beverages
Black interior
Black shelves
Wine racks

Common Options

47

Deep Well

Bottle Coolers

48

Deep W ell Bottle Coolers

Deep Well Bottle Coolers

Standard specifications

Black & s/s finish options available
36°-38°F operating temp
S/S top, easy glide lids & countertop with edge
2” thick foamed-in-place polyurethane insulation
Bottle cap opener & cap catcher standard
Adjustable epoxy coated dividers
New, robust lid
Low profile caster option
40° - 60°F wine models available

Deep Well Bottle Coolers – Frost Brew

Standard specifications – All benefits of standard cabinet

Same great benefits & features as standard Deep Wells
Only bottle cooler in the industry that maintains at 30° -32°F

Glass Frosters

Standard specifications

Black & s/s finish options available
S/S top, easy glide lids & countertop with edge
Foamed-in-place polyurethane insulation
Shelf(s) & floor rack standard
Adjustable shelf ledge
New lid
Low profile caster option

49

Common Options

Deep Well Bottle Coolers

One-piece S/S top & raised edge

Beverage-Air’s Deep Well Lids are 100% Metal

Adjustable dividers for multiple positions

One-piece S/S top & raised edge Lids are 100% metal Adjustable dividers

50

Deep W ell Capacities

Deep Well Capacity 12 oz. Bottles 12 oz. Cans

SF34 222 276 175
DW49 420 576 330
DW64 606 834 480
DW79 768 1098 625

Long Neck

Bottles

DW94 936 1338 775

51

Glass Frosters

52

Glass Frosters

GF24

GF34

GF48

53

Glass Frosters

One-piece S/S top & raised edge

Beverage-Air’s Glass Froster Lids are 100% Metal

GLASS FROSTERS ADJUSTABLE SHELF LEDGE

2 shelf ledges with 3 adjustable set points

One-piece S/S top & raised edge

Lids are 100% metal

Adjustable dividers

54

Glass Frosters

Capacities

10 oz.

Glass Froster Capacity

GF24 105 76 100
GF34 175 94 150
GF48 252 164 250

Mug 12 oz. Mugs 8" Plates

55

Direct Draw

Beer Dispensers

56

Direct Draw Dispensers

Standard specifications

Black & s/s finish options available
Available in both deep (28” depth) & shallow depth (23” depth)
S/S top & floor
3” insulated towers
Field reversible doors with 90° stay open feature
Approved for packaged product
Club top models available

Options

3 tap tower
Adapter (1 or 2 taps)
Low profile casters
Wine Temperature Models A vailable
Shelves & pilasters available

1-5 tap tower available

Relocation of

Tower/Taps

available!

Must specify

on order

Back Bar & Direct Draw

combo units

now available!!

Mode l Towe rs Std. Total Faucets Fauce t breakdow n Ke g l i nes

BM 23 1 1 1 Si ngle F aucet 1
DD24 1 1 1 Si ngle 1
DD36 1 2 1 Dual F aucet 2 way
DD48 1 2 1 Dual F aucet 2 way
DD50 1 2 1 Dual F aucet 2 way
DD58 2 3 1 Si ngle F aucet, 1 Dual Faucet 3 way
DD68 2 3 1 Si ngle F aucet, 1 Dual Faucet 3 way
DD72 2 4 2 Dual Faucets 4 way

*All Direct Draws require a drain – excluding the BM23

Underbar models

available!

Unit will be drilled for beer

lines, tower , & taps located on

counters.

57

Bar Mobiles

Only commercial grade barmobile in the industry

certified for outdoor use

(S/S Models ONLY)

Meets ALL UL certifications and rain tests

Black or stainless steel Finish

Self-contained with waste bottle

Holds up to (4) 1/6 size kegs

1-4 tap towers available

58

Common Features

Direct Draw Beer Dispensers

Certified for storage of beer, wine, & prepackaged food

Shallow Depth models approved for bottled beverages and prepackaged food

products – certified for open food when purchased with s/s interior (36”, 48”,

& 72”)

59

Direct Draw Dispensers

Tower Configurations

Direct Draw Tower

Configuration Towers Total Fa uce t s Competition Towers Total Faucets

BM23 1 1 TRUE 1 1 Equal
DD24 1 1 TRUE 1 1 Equal
DD36 1 2 TRUE No equal No equal N/A
DD48 1 2 TRUE 1 1 $481 List add on
DD50 1 2 TRUE No equal No equal N/A
DD58 2 3 TRUE 2 2 $481 List add on
DD68 2 3 TRUE 2 2 $481 List add on
DD72 2 4 TRUE No equal No equal N/A
DD78 2 4 TRUE 1 No equal N/A
DD94 2 4 TRUE 2 2 $962 List add on

Competitors List add

Note: -WINE models use different towers and manifolds than

standard Direct Draw Beer Models

on

60

Direct Draw Dispensers

Tower Change

If a customer orders a Direct Draw Unit and they are substituting one tap for another, they deduct full list
value of one and add full list value of the other. Manifolds should also be handled the same way.

Example below:

DD48Y-1-B-079 Direct Draw Black Triple Draft Arm- SUBSTITUTING ONE FAUCET FOR ANOTHER
Unit Price $6350
Minus one dual -$ 496.13
Add one triple +$1128.75
Minus 2 way manifold -$ 120.75
Add 3 way manifold +$ 141.75

= $7003.62

SUBSTITUTING FAUCETS FOR HOLE COVERS ONLY

If a customer is taking a tap off and only replacing with a hole cover, they only get ½ of the list deducted
from unit price plus the hole cover price added.

Example below:

DD94-1-B-022 – No faucets hole covers only
Unit price $7145.
Minus list of (2 dual faucets) -$248.06 X 2 - $496.12
Plus (2) hole covers – each $55.13 X 2 + $110.26

= $6759.14

61

Direct Draw

Capacities

MODEL #: Configuration 1 Configuration 2 Configuration 3 Configuration 4

BM 23 1 X 1/2 St d. Keg 4 X 1/ 6 K eg 2 X 1/ 6, 1 X 1/ 4 S l i m 2 X 1/4 Sl i m
DD24 1 X 1/2 St d. Keg 4 X 1/ 6 K eg 2 X 1/ 6, 1 X 1/ 4 S l i m 2 X 1/4 Sl i m
DD36 1 X 1/2 St d. Keg 4 X 1/ 6 K eg 2 X 1/ 6, 1 X 1/ 4 S l i m 2 X 1/4 Sl i m

DD48 2 X 1/2 S td. Keg

DD50 2 X 1/2 S td. Keg

DD58 3 X 1/2 S td. Keg

DD68 3 X 1/2 S td. Keg

DD72 3 X 1/2 S td. Keg

DD78 4 X 1/2 S td. Keg

DD94 5 X 1/2 S td. Keg

2 X Std. 1 / 2 Keg,
2 X 1/6 K eg
2 X Std. 1 / 2 Keg,
2 X 1/6 K eg
3 X 1/2 S td. Keg,
2 X 1/6 K eg
3 X 1/2 S td. Keg,
2 X 1/6 K eg
3 X 1/2 S td. Keg,
2 X 1/6 K eg
4 X 1/2 S td. Keg,
2 X 1/6 K eg
5 X 1/2 S td. Keg,
1 X 1/6 K eg

2 X 1/2 St d. Keg, 1 X
1/4 Keg
2 X 1/2 St d. Keg, 1 X
1/4 Keg
3 X 1/2 St d. Keg, 1 X
1/4 S l i m , 1 X 1/6 Keg
3 X 1/2 St d. Keg, 1 X
1/4 S l i m , 1 X 1/6 Keg
3 X 1/2 St d. Keg, 1 X
1/4 S l i m , 1 X 1/6 Keg
4 X 1/2 St d. Keg, 1 X
1/4 S l i m , 2 X 1/6 Keg
5 X 1/2 St d. Keg, 1 X
1/4 Slim Keg

62

Direct Draw

Capacities

BM23/DD24/DD36 KEG CAPACITY:

1/6

Std. ½

Std. ½

Keg

Keg

1/6

1 Std. ½ Keg 4 X 1/6 2 X 1/6

DD48/DD50 KEG CAPACITY

Std. ½

Keg

Std. ½

Keg

Std. ½

1/6

1/6

Keg

1/6

1/6

1 X ¼ Slim

Std. ½

Keg

1/6

1/4

1/6

1/4

2 X ¼ Slim

Std. ½

Keg

1/4

1/4

Std. ½

Keg

2 Std. ½ Keg 2 Std. ½ Keg

2 X 1/6 Keg

2 Std ½ Keg

63

1 X ¼ Slim

Direct Draw

DD58/68/72KEGCAPACITY:

Capacities

Std.½

Keg

Std.½

Keg

3Std.½Keg 3Std.½Keg

DD78KEGCAPACITY

Std.½

Keg

Std.½

Keg

Std.½

Keg

Std.½

Keg

Std.½

Keg

2X1/6Keg

Std.½

Std.½

Keg

Keg

1/6

Std.½

Keg

DD94KEGCAPACITY

Std.½

Keg

1/6

Std.½

Keg

Std.½

Keg

Std.½

Keg

3Std.½Keg
1X¼SlimKeg
1X1/6Keg

Std.½

Keg

Std.½

Keg

Std.½

Keg

1/4

1/6

Std.½

Keg

4Std.½Keg

5Std½Keg

(reducedforpresentation)

64

LumaVue

Glass Door

Merchandisers

65

LumaVue™

Standard specifications

Black, white or s/s exterior finish options available
Pass-Thru models available
Sliding & hinge doors
Double pane, lowE argon gas
1 piece grille
120° self-closing doors with automatic hold-open feature
Snap-in door gaskets
5 shelves per door (LV10 = 3 shelves, LV12 = 4 shelves)
Lighted sign pane & 5 free sign options (LV10/12 – 2 door decals) at time of purchase
Whisper quiet operation operating at 65 decibles or less
Recessed pocket door handle
Optional LED lighting
Certified for packaged food and bottled beverage
Open food models available
Coil does not hang into usable cabinet space, which allows for even distribution of air throughout cabinet
Custom graphics – Sides, Top, Door Decals (LV10/12/15/17), Sign Panels are available for customized

branding
Agency certifications: UL, cUL, UL-EPH, ENERGY STAR® (ENERGY STAR excludes LV10 & LV12)

Models:

LV10, LV12, LV15, LV15-54, LV17,
LV17-54, L V23, LV27, LV38, LV45,

LV49, LV66Y, LV72Y

66

LumaVue ™ /MarketMax ™

Standard/Custom (Custom/Standard)

Lighted, stainless, black,

white sign header panels

Black, white

or s/s exterior

Wine

merchandiser

33°F Beer

cooler

Black, white

or s/s interior

Floral

merchandiser

White or

black shelves

Fluorescent/LED

lighting

67

MarketMax™

Glass Door

Merchandisers

68

MarketMax™

Standard specifications

Black, white or s/s exterior finish options available
Expansion valve technology (freezers)
White or black interior finishes available
Fluorescent lighting standard/LED optional
Full electronic control with 1-touch defrost
5 shelves per door section standard
Double pan glass, lowE argon (refrigerators)
Triple pane glass (freezers)
Coolers 38°F / Freezers -15°F
Whisper quiet operation operating at 65 decibles or less
MMF49: Only 2 glass door freezer in the industry that operates on 115

voltage
1 piece grille
120° self-closing doors with automatic hold-open feature
Field-reversible doors (excludes glass door freezers; hinge kit required)
Snap-in door gaskets
Anti-microbial door handles
Coil does not hang into usable cabinet space, which allows for

even distribution of air throughout cabinet

Agency certifications: UL, cUL, UL-EPH, ENERGY STAR®

Maximum Efficiency, Maximum

Capacity, Maximum Performance

Electronic control

1-touch

defrost

Set temp

Adjust
temps

Models:

MMR23, MMR27, MMR49, MMR72

MMF23, MMF27, MMF49, MMF72

69

A Complete Line of Merchandisers

REFRIGERATORS

38°F

MarketMax™ - Coolers & Freezers

DUAL-TEMP

FREEZERS

-15°F

ICE

MERCHANDISERS

20-25°F

MMR23

MMF23 MMF27 MMF49 MMF72

MMF27-ICE

MMR27

MMF49-ICE

MMR49

MMR72

MMRF49 shown

3 door configurations available:

Cooler / Cooler / Freezer
Freezer / Cooler / Cooler

DIMENSIONS

MODEL W D H

MMR/F23 27.25" 33.74" 78"
MMR/F27 30" 33.74" 78"
MMR/F49 52" 33.74" 78"
MMR/F72 75" 33.74" 78"

70

MarketMax™ Dual-Temp

The only dual-temp merchandiser in the industry

OPTION 2 OPTION 1

OPTION 1

FREEZER

OPTION 2

MMRF49

MMRF49 2-door configurations available:

Freezer / Cooler
Cooler / Freezer

MMRF72 3-door configurations available:

Cooler / Cooler / Freezer
Freezer / Cooler / Cooler

71

MarketMax™

Full Electronic Control

Optional Audible/Visual Alarm A vailable

1-touch

defrost

Set temp

Temperature can be adjusted to operate 33°F for cold beer

Adjust
temps

storage

72

MarketMax™

Refrigerator & Freezer Features

Freezers Only

Heated door frames
Heated door perimeters
Heated glass (anti-fog)
Anti-microbial door handles -Helps to combat the growth of germs
Fluorescent or LED lighting

Refrigerators & Freezer

LED lighting
Improved visibility
Reduced maintenance costs
Bulbs last up to 10x longer than fluorescent
Solid with no filiment prevents damage
Produce 8 watts/hour, compared to 15 for fluorescent
Mercury free
Up to 50% energy savings vs. fluorescent

73

Countertop

Merchandisers

74

Countertop Merchandisers

Standard Specifications

3 to 7 cubic foot capacity
Certified for packaged product
Lighted canopies
Interior fluorescent lighting

-10°F Freezer (Cold Wall)
Options: 2 stand options for CT96 provides added height

Tall stand 23.44”H with casters / accessory # 00C27S027A

Short stand 9.61”H with casters / accessory # 00C27-028A

CF3

CRD5GE

CT96/CTF96

CTR3

75

Open-Air

Merchandisers

76

V

ueMax™

Open-Air Merchandisers

Standard Specifications

Black, White or Gray exterior options
Night curtain standard
6” legs standard
Electronic control
Bumper
Recessed horizontal & vertical LEDlighting standard
120 volt/60Hz/1 phase
Only 51” merchandiser in the industry that operates on 115 voltage
Options: Security cage, 5” casters, custom signage & graphics, bar/bag hooks, price tag

molding, spring loaded product dispensers

NEW FOR

2014!

VM15

VM7

VM12

VM15

VM18

77

Breeze™

Open-Air Merchandisers

Standard Specifications

Models: BZ13
Certified for packaged product
White, black or gray exterior available
One-piece grille
Open front with side shields
Interior lighting (2 interior lights)
Gravity flow organizers standard
Options: Black dividers, gray exterior finish, black shelves, roller kits, custom signage & graphics

available

78

Specialty Freezers

79

Specialty Freezers

Back of the house Meat Freezer

Stainless steel exterior

Aluminum interior

6” casters standard

Forced-air refrigeration

No manual defrost required

Lift up lids

NEW!

24 & 34

Models

coming soon!

80

Specialty Freezers

Dipping Cabinets & Novelty Cases

Dipping Cabinets (BDC8 & BDC12)

Cold wall refrigeration
Operating temperature of -15°F
Baskets & dividers
Lid lock & keys
Casters standard
Drain plug for easy cleaning

NEW!

Novelty Cases (NC28, NC34, NC43, NC51)

Cold wall refrigeration
Operating temperature of -15°F
Baskets & dividers
Lighted sign panels available (NC28, NC43, NC51 models only)
Lid lock & keys
Casters standard
Drain plug for easy cleaning

81

Blast Chillers

82

Blast Chillers/Freezers

Standard specifications

S/S construction
Core probe with sensor
Ergonomic handles
Adjustable legs
Self-closing doors
Control board with display
18 and 26 lb. countertop capacities
40 lb. model capacity

Core Concepts

Maintain food quality
Safety compliance
Operational benefits
Sound financial sense

Food quality

Increased shelf life
Retention of moisture in foods

Food safety

Compliant with current safety standards
Hazard Analysis Critical Control Point (HACCP)

18 lb. Countertop Capacity

CONTROL BOARD

WITH DISPLAY

40 lb. Floor Capacity

83

Blast Chillers

Worktop Blast
Chillers

WBC35

Reach-in Blast
Chillers

WBC60

Williams by Beverage-Air

Roll-in/Roll-Thru Blast Chillers

Optional POD System

Remote Condenser

Floor & Ramps

Combi Footprint

®

Options:

WBC75

WBC110

WBC175/220/350 WBC480/660

WBC175/220/350 compartment accepts 1 roll-in cart (27”W x 40”D x 72”H)
WBC480/660 compartment accepts 2 roll-in carts (27”W x 40”D x 72”H)

84

Blast Chillers

Williams by Beverage-Air

®

85

Milk Coolers

86

Milk Coolers

Cold Wall Milk Coolers

Cold wall refrigeration system
S/S door & lids
Dial thermometer
Floor drain
4” casters, 2 with brakes standard
Locks standard
S/S interior liner
White & S/S options available
Single or Dual Access available
Options: Corner bumpers, wrap-around bumpers

Forced-Air Milk Coolers

Patented forced-air refrigeration system
S/S door & lids
Digital thermometer
Floor drain
7” casters, 2 with brakes standard (single access)
5” casters, 2 with brakes standard (dual access)
Locks standard
S/S interior liner
White & S/S options available
Single or Dual Access available
Options: Corner bumpers, wrap-around bumpers

Milk Cooler Liner

One piece bottom liner- 3 support channels
300 series stainless steel
Durable & rust resistant

87

Deli Cases

88

Deli Cases

Standard Specifications

Cabinets feature a curved glass front with Euro profile style
Cabinet exterior is heavy-duty coated steel with 14” s/s top
Cabinet interior is heavy-duty coated steel & s/s floor
Dry display cases are equipped with a low velocity interior fan
Cabinets come with sliding glass doors at rear of cabinet to provide convenient access to displayed products
Brightly illuminated display area is achieved with canopy light & 2 shelf lights suspended from adjustable

with epoxy coated shelves
Mirrored interior sides are standard
Models are UL and CUL listed to meet the safety standards of USA & Canada

89

Thank You

Phone: [phone]
Fax: [phone]
Email: [e-mail]

90
