ELECTRIC SELF CLEAN OVEN MODEL
/ From the desk of the President
From the desk of the President
Dear new owner of a Bertazzoni,
I want to thank youDear new owner of a Bertazzoni appliance.
I want to thank you for choosing one of our beautiful products for your home.
My family started manufacturing kitchen appliances in Italy in 1882, building a reputation for quality of engineering and passion for good food.
Today, our products stand out because of their unique blend of authentic Italiandesignandsuperiorappliancetechnology.Itisourmissiontomake products that function perfectly and bring joy to their owners.
By making beautiful products we respond to our customers’ ﬂ air for good design. By making them versatile and easy-to-use, cooking with
Bertazzoni becomes a real pleasure.
This manual will help you learn to use and care for your Bertazzoni appliance in the safest and most e ective way, so that it can give you the highest satisfaction for years to come.
/ Table of contents
TABLE OF CONTENTS
WARNINGS ___________________________________________________________________ 4 WORKTOP AND KNOBS LAYOUT ________________________________________________ 8 INDUCTION COOKTOP __________________________________________________________ 9 Cooking with induction ________________________________________________________ 9 Turning on the induction element ________________________________________________ 9 Using special functions ________________________________________________________ 9 Suitable induction pans ________________________________________________________ 10 Induction dimension __________________________________________________________ 10 Recommendations __________________________________________________________ 11 ELECTRIC OVEN _______________________________________________________________ 12 Shelves positions _____________________________________________________________ 12 Cooling fan __________________________________________________________________ 12 Preheating the oven ___________________________________________________________ 12 Using the oven _______________________________________________________________ 12 Oven cooking modes __________________________________________________________ 12 Special functions _____________________________________________________________ 13 Condensation _______________________________________________________________ 14 Getting the best results ________________________________________________________ 14 Oven cooking recommendations ________________________________________________ 14 Broiling recommendations _____________________________________________________ 15 Troubleshooting common problems with oven cooking _____________________________ 15 Oven temperature indicator _____________________________________________________ 16 Self cleaning ________________________________________________________________ 17 Telescopic glides ____________________________________________________________ 19 KEEPING YOUR BERTAZZONI CLEAN _____________________________________________ 20 SIMPLE MAINTENANCE _________________________________________________________ 21 Replacing oven lights _________________________________________________________ 21 Cleaning inside glass door _____________________________________________________ 22 TROUBLESHOOTING ___________________________________________________________ 23 TWO YEAR LIMITED WARRANTY _________________________________________________ 24
Warning and Important Safety Instructions appearing in this manual are not meant to cover all possible conditions and situations that may occur. Common sense, caution, and care must be exercised when installing, maintaining, or operating the appliance.
Read and follow all instructions before using this appliance to prevent the potential risk of ﬁre, electric shock, personal injury or damage to the appliance as a result of improper usage of the appliance. Use appliance only for its intended purpose as described in this manual.
Save this Manual for local electrical inspector’s use. Read and save these instructions for future reference. Observe all governing codes, ordinances and regulations.
To avoid risk of property damage, personal injury or death; follow information in this manual exactly to prevent a ﬁ re or explosion. DO NOT store or use gasoline or other ﬂ ammable vapors and liquids nearbythis or any appliance.
What to do if you smell gas:
Do not light any appliance. Do not touch any electricalswitch.Donotuseanyphoneinyour building. Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions. If you cannot reach your gas supplier, call the ﬁre department.
NOTE: Installation and service must be performed by a qualiﬁ ed installer, service agency or the gas supplier.
All gas products must be installed by a “Massachusetts” licensed plumber or gasﬁ tter. A “T” handle type manual gas valve must be installed in the gas line connected to this appliance.
To ensure proper and safe operation: Appliance must be properly installed and grounded by a qualiﬁ ed technician. DO NOT attempt to adjust, repair, service, or replace any part of your appliance unless it is speciﬁ cally recommended in this manual.All other servicing should be referred to a qualiﬁ ed servicer. Have the installer show you the location of the gas shut-o valve and how to shut it o in an emergency.
A certiﬁ ed technician is required for any adjustments or conversions to Natural or LP gas.
To Prevent Fire or Smoke Damage
•Be sure all packing materials are removed from the appliance before operating it.
•Never let clothing, potholders, or other ﬂ ammable materials come in contact with or too close to any element, top burner or burner grate until it has cooled.
•If appliance is installed near a window, proper precautions should be taken to prevent curtains from blowing over burners.
•Never leave any items on the cooktop. The hot air from the vent may ignite ﬂ ammable items and may increase pressure in closed containers which may cause them to burst.
•Many aerosol-type spray cans are EXPLOSIVE when exposed to heat and may be highly ﬂ ammable. Avoid their use or storage near an appliance.
In Case of Fire
Turn o appliance and ventilation hood to avoid spreading the ﬂ ame. Extinguish ﬂ ame then turn
•Cooktop: Smother ﬁ re or ﬂ ame in a pan with a lid or cookie sheet.
•NEVER pick up or move a ﬂ aming pan.
•Oven: Smother ﬁ re or ﬂ ame by closing the oven door. DO NOT use water on grease ﬁ res. Use baking soda, a dry chemical or foamtype extinguisher to smother ﬁ re or ﬂ ame, if available, a
multipurpose dry chemical or foam type extin- guisher.on hood to remove smoke and odor.
•NEVER leave children alone or unsupervised near the appliance when it is in use or is still hot.
•NEVER allow children to sit or stand on any part of the appliance as they could be injured or burned.
•DO NOT store items of interest to children over the unit. Children climbing to reach those items could be seriously injured.
•Once the unit has been installed as outlined in the Installation Instructions, it is important that the fresh air supply is not obstructed. The use of a gas cooking appliance results in the production of heat and moisture in the room in which it is installed.
•Ensure that the kitchen is well-ventilated. Keep natural venting holes open or install a mechanical ventilation device. Prolonged or intensive use of the appliance may call for additional (such as opening a window) or more e ective ventilation (such as increasing the level of a mechanical ventilation if present).
•NEVER use aluminum foil to cover oven racks or oven bottom. This could result in risk of electric shock, ﬁ re, or damage to the appliance. Use foil only as directed in this guide.
•To eliminate the hazard of reaching over hot surface burners, cabinet storage should not be provided directly above a unit. Temperatures may be unsafe for some items, such as volatile liquids, cleaners or aerosol sprays.
•ALWAYS place a pan on a surface burner before turning it on. Be sure you know which knob controls which surface burner. Make sure the correct burner is turned on and that the burner has ignited. When cooking is completed, turn burner o before removing pan to prevent exposure to burner ﬂ ame.
•ALWAYS adjust surface burner ﬂ ame so that it does not extend beyond the bottom edge of the pan. An excessive ﬂ ame is hazardous, wastes energy and may damage the appliance, pan or cabinets above the appliance. This is based on safety considerations.
•NEVER leave a surface cooking operation unattended especially when using a high heat setting or when deep fat frying. Boilovers cause smoking and greasy spillovers may ignite. Clean up greasy spills as soon as possible. DO NOT use high heat for extended cooking operations.
•DO NOT heat unopened food containers, build up of pressure may cause the container to explode and result in injury.
•ALWAYS let quantities of hot fat used for deep fat frying cool before attempting to move or handle.
•NEVER wear garments made of ﬂ ammable material or loose ﬁ tting or long-sleeved apparel while cooking. Clothing may ignite or catch utensil handles. DO NOT drape towels or materials on oven door handles. These items could ignite and cause burns.
•ALWAYS place oven racks in the desired posi-
tions while oven is cool. Slide oven rack out to add or remove food, using dry, sturdy pothol-
•ALWAYS avoid reaching into the oven to add or remove food. If a rack must be moved while hot, use a dry pot-holder.
•ALWAYS turn the oven o at the end of cooking.
•Use care when opening the oven door. Let hot air or steam escape before moving or replacing food.
•DO NOT cook directly on the oven bottom. This could result in damage to your appliance.
Always use the oven racks when cooking in the oven.ders.
Do not connect any appliances to the plugs above or near to the induction cooktop; connection cable insulation can melt if in contact with heat, and this may result in an injury and a property damage.
•Use pans with ﬂ at bottoms and handles that are easily grasped and stay cool. Avoid using unstable, warped, easily tipped or loose-han- dled pans. Also avoid using pans, especially small pans, with heavy handles as they could be unstable and easily tip. Pans that are heavy to move when ﬁ lled with food may also be hazardous.
•Be sure utensil is large enough to properly contain food and avoid boilovers. Pan size is particularly important in deep fat frying. Be sure pan will accommodate the volume of food that is to be added as well as the bubble action of fat.
•To minimize burns, ignition of ﬂ ammable materials and spillage due to unintentional contact with the utensil, DO NOT extend handles over adjacent surface burners. ALWAYS turn pan handles toward the side or back of the appliance, not out into the room where they are easily hit or reached by small children.
•NEVER let a pan boil dry as this could damage the utensil and the appliance.
•Follow the manufacturer’s directions when using oven cooking bags.
•Only certain types of glass, glass/ceramic, ceramic or glazed utensils are suitable for rangetop surface or oven usage without breaking due to the sudden change in temperature. Follow manufacturer’s instructions when using glass.
Induction Cooking Surfaces
•Surface areas on or adjacent to the unit may be hot enough to cause burns. Do not touch the cooking area as long as the light indicating residual heat on the glass-ceramic cooktop area, is “on”; this indicates that the temperature in the relative area is still high.
•DO NOTCOOK ON BROKEN COOKING SURFACE – If cooking surface should break, cleaning solutions and spillovers may penetrate the broken cooking surface and create a risk of electric shock. Contact a qualiﬁ ed technician immediately.
•Keep a close eye on children because they are unlikely to see the residual heat warning lights. The cooking zones are still very hot for some time after use, even if they are switched o . Make sure that children never touch them.
•NEVER use aluminum foil to to hold the food while cooking on a glass-ceramic cooktop area.
•Never place pan with bottoms which are not perfectly ﬂ at and smooth on the cooktop area.
•If you drop a heavy pot on your cooktop area it will not break. On the contrary, if a hard object, suchasthesaltshakerorthespicebottlestrikes the edge or the corner of the cooktop area, the cooktop area may break.
•Never use the glass-ceramic cooktop area as support surface.
•Only use cleaning products made speciﬁ cally for ceramic glass cooking surfaces.
•Metal items such as cutlery or lids must never be placed on the surface of the cooktop area since they may become hot.
Radio Interference - Induction Ranges
This unit generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this unit does cause harmful interference to radio or television reception, which can be determined by turning the unit o and on, the user is encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna
•Increase the distance between the unit and receiver
•Connect the unit into an outlet on a circuit different from that to which the receiver is connected.
Oven Heating Elements
•NEVER touch oven bake and broil burner areas or interior surfaces of oven.
•Bake and broil burners may be hot even though they are dark in color. Areas near burners and interior surfaces of an oven may become hot enough to cause burns.
•During and after use, DO NOT touch or let clothing or other ﬂ ammable materials contact heating elements, areas near elements, or interior surfaces of oven until they have had suf- ﬁ cient time to cool. Other surfaces of the oven may become hot enough to cause burns, such as the oven vent opening, the surface near the vent opening, and the oven door window.
•Turn o all controls and wait for appliance parts to cool before touching or cleaning them. DO NOT touch the burner grates or surrounding areas until they have had su cient time to cool.
•Clean the range with caution. Avoid steam burns; DO NOT use a wet sponge or cloth to clean the range while it is hot. Some cleaners produce noxious fumes if applied to a hot surface. Follow directions provided by the cleaner manufacturer.
•DO NOT clean, rub, damage, move or remove the door gasket. It is essential for a good seal during baking. If the gasket becomes worn or excessively soiled with food particles, replace gasket to assure a tight seal.
Power failure warning
Due to safety considerations and the possibility of personal injury in attempting to light and extinguish the oven burners, the grill and the oven burner should not be used during a power failure. The oven control knob should always remain in the “OFF” position during a power failure.
NEVER use appliance as a space heater to heat or warm a room to prevent potential hazard to the user and damage to the appliance. Also, DO NOT use the rangetop or oven as a storage area for food or cooking utensils.
Electrical shock hazard
Make sure all controls are OFF and oven is COOL before cleaning. Failure to do so can result in burns or electrical shock.
DO NOT touch a hot oven light bulb with a damp cloth as the bulb could break. Should the bulb break, disconnect power to the appliance before removing bulb to avoid electrical shock.
NEVER cover any slots, holes or passages in the oven bottom or cover an entire rack with materials such as aluminum foil.Doing so blocks air ﬂ ow through the oven and may cause carbon monoxide poisoning. Aluminum foil linings may also trap heat, causing a ﬁ re hazard.
The oven door, especially the glass, can get hot.
DO NOT touch the oven door glass!
Children and adults can tip over the range if it has not been secured.This may lead to fatal injuries.
To reduce the risk of the appliance tipping, it must be secured and connected using the anti-tip device according to the installation instructions. Re-engage the anti-tip device if the range is moved.
Do not operate the range without te anti-tipdevice in place and engaged. Do not use the range if the anti-tip device has not been properly installed and engaged. See installation instructions for details.
Failure to observe the information contained in the installation instructions can lead to serious or fatal injuries for children and adults.
Cancer and Reproductiv Harm-
/ Worktop and knobs layout
WORKTOP AND KNOBS LAYOUT
1Oven functions selector
3Left front induction element
4Left rear induction element
5Right front induction element
6Right rear induction element
1Oven functions selector
3Left front induction element
4Left rear induction element
5Central induction element
6Right front induction element
7Right rear induction element
