Page 1
BERTAZZONI PROFESSIONAL SERIES
36” 5 BURNER GAS OVEN RANGE
PRO36 5 GAS X
Bertazzoni Professional Series ranges bring the authentic experience of Italian cooking to the heart of your
home. The Professional 36” gas range has an oven with balanced air-flow convection fan to provide even
heat distribution for single and multi-level roasting and baking with no flavor crossover. The oven includes
telescopic glide shelves, soft-motion door hinges for easy one-hand operation, and triple-glass windows
to minimize heat loss. The beautiful worktop is precision-molded off of one sheet of stainless steel. It is
configured with five versatile gas burners in brass, including Bertazzoni’s signature dual-ring power burner
with independently controlled flames for high power to delicate simmer. The worktop is designed for highefficiency in heat delivery without energy waste. Each burner is equipped with the thermocouple gas shutoff safety system for maximum safety. Complete your Bertazzoni range with any of the available ventilation
and backsplash solutions, as well as low profile trim, toekick and other beautiful accessories.
BRASS BURNER
Bertazzoni’s exclusive power burners
in brass have independently operated
flame rings giving maximum flexibility of
operation from delicate low simmer to
full power.
SOFT MOTION DOOR
The soft-motion oven door is specially
designed and carefully balanced for
easy opening and smooth closing with
one hand.
TO COOK BEAUTIFULLY
TELESCOPIC GLIDE SHELVES
The telescopic oven rack provides more
convenient oven access and easier
handling of hot and heavy dishes.
Page 2
25" 3⁄16
35"
1
⁄2 min
37"
1
⁄4 max
4"
4"
32"
4"
1" 9⁄16
2" 3⁄8
19" 15⁄16 1" 5⁄16
35" 7⁄8
4"
32"
1" 9⁄16
35" 7⁄8
25" 3⁄16
1
⁄2 min
1
⁄4 max
4"
4"
32"
4"
1" 9⁄16
2" 3⁄8
19" 15⁄16 1" 5⁄16
35" 7⁄8
BERTAZZONI PROFESSIONAL SERIES
36” 5 BURNER GAS OVEN RANGE - PRO36 5 GAS X
Gas burners 5
Burner type brass
Maintop one piece stainless steel sheet
Burner controls knobs
Knobs metal finish
Grates cast iron
Backguard standard 4 inches
Gas safety device thermocouple technology
One hand ignition standard
Standard accessories wok ring & simmer plate
Dual Power burner 750 - 18,000 Btu/h
Rapid burner 11,000 Btu/h
Semi-rapid burner 6500 Btu/h
Auxiliary burner 3400 Btu/h
Simmer rate 750 Btu/h
Main oven
Main oven functions
Main oven volume 4.4 ft
Inner oven door full - width triple glass
Oven equipment
Legs
ACCESSORIES
Toe kick panel (TKS 36 X), flat island trim (IRF 36 X), side trim (ST 36 X)
Available LPG version PRO36 5 GAS X LP
MATCHING VENTILATION SOLUTIONS
Bertazzoni offers a variety of matching ventilation solutions for this
range. Please check our website under the ventilation tab for a
complete overview of all choices
gas convection with gas infrared
broiler
traditional bake, gas convection,
broil, defrost/dehydrate
3
1 telescopic glide shelf, 1 baking
tray, 2 heavy gauge wire shelves,
1 grill trivet for tray
flap storage compartment
height adjustable stainless steel
wrapped legs
TECHNICAL SPECIFICATIONSFEATURES
Voltage, frequency 120 V, 60Hz
Max Amp Usage, power rating 1.5 A - 150 W
Certification CSA
Warranty 2 years parts and labor
25" 3⁄16
3" 1⁄8
35" 7⁄8
2"
11
⁄16
4"
1
35"
⁄2 min
1
⁄4 max
37"
32"
35" 7⁄8
1" 11⁄16
1"
Gas
54"
20"
25" 3⁄16
2" 3⁄8
4"
35" 7⁄8
3"
2"
Electricity
24" 13⁄16
3"
INSTALLATION INSTRUCTIONS
Bertazzoni recommends to operate the
1
⁄2 min
35"
37"
1
⁄4 max
appliance after it has been installed
in a cabinet. The kitchen cabinets
shall be made of materials capable
of withstanding temperatures at least
117°F (65°C) above room temperature
4"
in order to avoid possible damage to the
cabinets during oven usage. For further
installation instructions refer to the
19" 15⁄16 1" 5⁄16
installation manual.
Disclaimer: while every effort has been made to insure the accuracy of the information contained in
this brochure, Fratelli Bertazzoni reserves the right to change any part of the information at any time
without notice.
Fratelli Bertazzoni, Bertazzoni and the winged wheel brand icon are registered trademarks of
Bertazzoni Spa.
15
⁄16
7
⁄8 "
6" 9⁄16
3" 1⁄2 min
5" 1⁄4 max
bertazzoni.com
