Bertazzoni K100 HER CR A, K100 HER NE A, K100 HER VI A, K120 HER CR A, K120 HER NE A User Manual

...
HOOD
Use and maintenance instructions
Instructions pour l'utilisation et manutention
Istruzioni d'uso e manutenzione
Instrucciones de uso y mantenimiento
EN
FR
IT
ES
3LIOC8LB
C
1
360
160
20
C
A
160
B
400
540 : 960
650 : 750
80
600 - 900
166
229
-1000
-1200
Fig.1
Fig.3
A
EXHAUST MODE - roof venting ÉVACUATION EXTERNE - ventilation au toit EXTRACCIÓN - ventilación para el techo
ASPIRANTE - uscita softto
B
Fig.2
TYPE “A”
1
1
2
EXHAUST MODE - wall venting ÉVACUATION EXTERNE - ventilation au mur
2
3
4
EXTRACCIÓN - ventilación para el muro ASPIRANTE - uscita a parete
C
RECIRCULATING MODE RECIRCULATION INTERNE MODALIDAD RECIRCULATION MODALITA’ FILTRANTE
3LIOC8LB
Fig.4
Fig.5
Fig.6
3LIOC8LB
Fig.7
3
EN Use and maintenance instructions
1. GENERAL
Carefully read the following important information regarding installation safety and maintenance. Keep this information booklet accessible for further consultations.
CONTROL PANEL (Fig.2)
TYPE “A”
1 -First speed 2 -Second speed 3 -Third speed 4 -Fourth speed (maximum)
- Light ON/OFF
2. INSTALLATION INSTRUCTIONS
This hood has been arranged to be installed above a
cook top. It can be used in 2 ways:
If a connection tube composed of two parts is used, the
upper part must be placed outside the lower part. Do not connect the cooker hood exhaust to the same conductor used to circulate hot air or for evacuating fumes from other appliances generated by other than an electrical source.
2.3. MOUNTING THE COOKER HOOD TO THE WALL
Drill holes A-B-C according to indications quoted in
(g.1).
Use screws and screw anchors suitable for wall (e.g.
reinforced cement, plasterboard) for the mounting of
the cooker hood. Where screws and screw anchors are supplied ensure that they are suitable for the type of wall where the cooker hood is to be mounted. Afx the bracket Z to the wall via the drill holes C Hang the cooker hood on the wall using the drill holes A. Fasten the cooker hood using the fastening drill holes B.
EXHAUST MODE: the kitchen vapours are puried by
the metal anti-grease lters and carried outside through
a ducting system. (Fig. 3A; 3B)
RECIRCULATING MODE: the kitchen vapours are
puried by the metal anti-grease lters and an activated carbon lter (sold separately), then conveyed back into
the kitchen. (Fig. 3C)
We suggest to have installation carried out by qualified personnel, in compliance with all the current regulations and in particular with the ones concerning air exhaust and electrical connection. The manufacturer cannot be held liable for damages caused by improper installation or if it has not been carried out according to the state-of-the-art.
2.1 ELECTRIC CONNECTION
The appliance has been manufactured as a class II,
therefore no earth cable is necessary. The connection to the mains is carried out as follows: BROWN = L line BLUE = N neutral
If not provided, connect a plug for the electrical load
indicated on the description label. Where a plug is
provided, the cooker hood must be installed in order
that the plug is easily accessible. An omnipolar switch with a minimum aperture of
3 mm between contacts, in line with the electrical load and local standards, must be placed between
the appliance and the network in the case of direct connection to the electrical network.
2.2. INSTALLATION
The appliance must be installed at a minimum height of
650 mm from an electric cooker stove, or 750 mm from
gas or combined cooker stoves. (Fig.1)
2.4. EXHAUST VERSION
Connect the ange Y to the discharge opening with a connecting tube Fig.5 (do not carry out for lter
version) . Thread the upper connector E to the inside of the lower connector F; hang the two connectors inserting
them vertically on the cooker hood, unthread the
upper connector E towards the top, locking it in with the appropriate screws in the drill holes G of the bracket Z (g. 7) previously afxed to the wall via the drill holes C (g. 1).
2.5 RE-CIRCULATING VERSION
In order to transform your cooker hood from the
exhaust version to the re-circulating version, ask your local retailer for active carbon lters and then carry
out the following instructions.
The lters must be applied to the suction kit located inside the cooker hood (g. 6). The air is replaced
in the environment via the eyelets impressed on the connector E.
2.6. OPERATING CHECKS
Check lights and motor start-up on all speeds.
USE AND MAINTENANCE It is recommended to switch on the appliance before cooking. It is also recommended to leave the appliance in operation for 10 minutes after cooking is terminated in order to completely eliminate cooking vapours and odours. The proper function of the cooker hood is conditioned by the regularity of the maintenance operations, in particular, the active carbon lter. Clean the fan and other surfaces of the cooker hood regularly using a cloth moistened with denatured alcohol or non abrasive liquid detergent.
